Condition: good (used), Year of construction: 2004, In good technical condition. GO 2004. CNC control based on an industrial PC. Measuring system: Tilting device for measuring the workpiece diameter with automatic corrections. Max. grinding length: 630 mm. Center height: 140 mm. Machine dimensions: Height 1600 mm, width 2300 mm, length 3750 mm, and machine weight approx. 3000 kg. Machine accessories Cobjwfnvwe Ed Ulvogt Complete technical documentation for the machine DE Manuals for using the CNC control system CZ

Year of construction: 2008, Condition: ready for operation (used), Control Unit Brand HEIDENHAIN Model TNC426 Main Drive Spindle speed range 3500 Tool taper 50 ISO Movement X-Axis Movement 1600 mm Y-Axis Movement 920 mm Cgsb Edjwd Uyys Ulvjt Z-Axis Movement 950 mm Table Outer length 850 mm (extends to 1600 mm with supports) Outer width 850 mm Table load 3000 kg (5000 kg with supports) Media Chip conveyor Yes This 4-axis TOS WFQ 80 CNC boring machine was manufactured in 2008. It features a working spindle diameter of 128 mm, a clamping taper of 50 ISO, and a spindle speed of 3500 rpm. The table can handle loads up to 5000 kg with additional supports and includes a chip conveyor and SIEMENS motors and drives. A great opportunity to buy this TOS WFQ 80 CNC boring machine. Contact us for further details regarding this boring machine. Application Types Other Machine Tools

Condition: good (used), Year of construction: 1979, Functionality: unexamined, machine/vehicle number: 419.324.012, drilling depth: 1,200 mm, total length: 6,500 mm, total width: 3,500 mm, total height: 2,900 mm, spindle speed (min.): 50 rpm, spindle speed (max.): 3,000 rpm, table length: 1,050 mm, table width: 1,050 mm, - Operating voltage: 380 V - Frequency: 50 Hz - Connected load: 25 kW - Spindle speed: 50 – 3,000 rpm - Center height above table: 240 – 1,040 mm - Table dimensions: 1,050 x 1,050 mm - Feed: infinitely variable - Feed rate: - Row 2: 18 – 160 mm/min, 35 – 320 mm/min - Rapid traverse speed: 3.5 m/min - Rated motor speed: 1,400 rpm - Drilling depth: up to approx. 1,200 mm EQUIPMENT: - 3-axis digital display from Heidenhain Csb Ed Ujwdnzkolvegt - Coolant system included

Year of construction: 1992, Condition: excellent (used), machine/vehicle number: 238828, Available: Immediately Cob Eepr Uvred Ulvegt

Condition: used, Year of construction: 1995, bore capacity in steel (diameter) 60 mm Cgjb Eowcg H Ajd Ulvst throat 400 mm bore stroke 240 mm 5 speeds 63 - 1250 U/min table-size 840 x 670 mm total power requirement 4 / 5,5 kW weight 1450 kg dimensions 1000 x 1400 x 2450 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard * RPM display * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by 360° * Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck 0 - 16 mm - T-Nuts -expectors - Operating tool - BMP 160 machine vice

Condition: good (used), Year of construction: 1983, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 2,000 mm, table load: 2,000 kg, X-axis / X-axis: 6000 mm Y-axis / Y-axis: 3000 mm Z-axis / Z-axis: 2000 mm Antriebsleistung / Drive power: 83 kW clamping table / table: 2500 x 2500 mm max. Werkstückmasse auf Tisch / Workpiece mass: 20 t Bearbeitungsbreite auf Tisch / Processing width on table: 5770 mm Bearbeitungshöhe auf Tisch / Processing height on table: 2800 mm max. Bearbeitungstiefe / Processing depth: 1985 mm Cgeb Edjwhdcxj Ulvot Spindle diameter / Spindle diameter: 200 mm Schieberquerschnitt / Slide cross-section: 530 x 550 mm Zusatzeinrichtungen / Additional equipment: Winkelkopf großer / Winkelkopf klein

Condition: used, core drilling diameter max. 400 mm bore depth 3500 mm swing diameter 850 mm Control Siemens 840D full boring Ø 20 - 200 mm core boring Ø - 400 mm drilling out Ø - 400 mm mm method of boring BTA motor output at 1500-5000 rpm 100 kW speed range step 1 10 - 499 U/min speed range step 2 500 - 2000 U/min spindle bore Ø 120 mm feed speeds 0 - 7000 mm/min rapid speed 7000 mm/min total power requirement 200 kW weight of the machine ca. 16 t dimensions of the machine ca. 14 x 8,35 x 2,2 m Equipment / Accessories: - set-up station with loading gantry for parallel set-up during drilling process - drill pipes - 2 circular roundabouts for vibration dampers (large/small) - half-shell clamping device (small/medium/large) - cone discs - radial clamping discs - chip conveyor (2004) - oil cooling and filtering system with band filter - chip shredder and centrifuge (2017) - oil tank 20000 l (emptied) - cooling lubricant pumps - 3 screw spindle pumps - stop for counterholder - hydraulic cylinder Ø 25.4 x 120 mm stroke - counterholder - hydraulic cylinder Ø 82.6 x 95 stroke - guide slide Cjb Eowcrwasd Ulvsgt - motor output 55 Nm at 2000 rpm - contact force max. 40 KN - longitudinal travel max. 500 mm in front of fixed headstock - clamping diameter for BTA drilling oil supply Ø 490 mm - feed speed 0-7000 mm/min - rapid speed 7000 mm/min - shell-type tailstock - motor output 18 Nm at 2000 rpm - feed speed 0-7000 mm/min - rapid speed 7000 mm/min - toothed belt 40T10/1390 - various spare parts - documentation

Year of construction: 1990, Condition: ready for operation (used), Control Unit Brand HEIDENHAIN Model iTNC 530 Cgjb Edjwd Uyte Ulvet Main Drive Spindle speed range 5000 rpm Tool taper ISO 50 Additional Equipment Automatic tool changer: 40 positions Working spindle diameter: 128 mm This 4-axis TOS WFQ80NCA-CNC/50 boring machine was manufactured in 1990. Consider the opportunity to buy this TOS WFQ80NCA-CNC/50 boring machine. Contact us for more information. Application Types Other Machine Tools

Condition: good (used), Functionality: unexamined, machine/vehicle number: 6104, total height: 2,500 mm, drilling capacity: 40 mm, total width: 1,400 mm, total length: 2,500 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 15 rpm, overall weight: 3,000 kg, table length: 1,200 mm, table height: 820 mm, table width: 600 mm, TECHNICAL DATA: - Drilling capacity (into solid material): Ø 40 mm - Tool holder: SK 40 - Column diameter: 195 mm - Table dimensions: 1,200 x 600 mm - Number of T-slots: 4 - T-slot spacing: 125 mm - Distance from spindle nose to table: 185 mm - Distance from spindle nose to base plate: min. 985 mm, max. 1,595 mm - Drilling radius: min. 540 mm, max. 1,290 mm Cgjb Edowdn Iwj Ulvot - Swivel range: 330° - Worktable height: 820 mm - Quill stroke: 200 mm - Column stroke: 410 mm RAPID TRACTIONS: - X-axis (at a drilling radius of 1,000 mm): 5 m/min - Y-axis: 4 m/min SPINDLE: - Speed: 15 – 2,800 rpm - Feed rates (infinitely variable): 5 – 2,000 mm/min EQUIPMENT: - Two-axis digital display

Condition: excellent (used), Functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 60 rpm, feed rate X-axis: 500 m/min, table length: 550 mm, table width: 320 mm, table load: 400 kg, spindle mount: MK 2, total height: 1,650 mm, drill spindle length: 130 mm, total length: 1,200 mm, total width: 1,150 mm, Equipment: rotational speed infinitely variable, HENRI HAUSER OP3 Unique Piece Jig boring machine/jig boring machine in excellent, exceptional condition, second-hand (last owner 41 years). Electrical system partially overhauled and modernized. Extensive tool package in mint condition, including tool cabinet optional for an additional charge. Photos upon request. The machine was last located in a prototype workshop of a large company and has not been used for many years. The jig boring machine features the very rare option of a motorized table drive on the X and Y axes and a potentiometer. This eliminates the need for laborious movement of individual coordinates over long distances using hand cranks. Furthermore, it features the rare thermal stabilization and expansion compensation. Two heaters are provided for this purpose, which can and must be switched on separately before starting work and to maintain high accuracy and pitch. This explains the factory-set high positioning accuracy of 0.002 mm with a resolution of 0.001 mm. What's unique is that the Hauser features two Heidenhain digital readouts with a total of four glass scales with 1 μm resolution, including the spindle feed. This is a huge advantage for precise drilling and facing at depth with Wohlhaupter, spindle tools, etc. With the options mentioned and in this first-class condition, this is currently a unique piece on the market and certainly not available again. Experts at these machines, which are primarily used in the watchmaking industry, precision engineering, materials testing, and the optical industry, know the value of these masterpieces of mechanical engineering. They are also ideally suited for testing laboratories, technical universities, materials engineering, special machine construction, etc. All documents, manuals, electrical diagrams, etc. are, of course, available in their original form! Technical specifications: Table length = 550 mm, table width = 320 mm, longitudinal travel X-axis = 400 mm, transverse travel Y-axis = 250 mm, vertical travel Z-axis = 400 mm Max. workpiece weight on the table = 400 kg, spindle mount MT 2, drill spindle stroke (Z-axis) = 130 mm Distance from table to spindle = 590 mm, spindle speed continuously adjustable from 60 rpm to 3000 rpm Feed rates: Drill spindle slide: 2 steps from 0.03 mm/rev to 0.06 mm/rev Connection 50 Hz 3x 380 volts, spindle motor 0.80 HP Cgebov S Exwe Ed Ulvst Machine dimensions: Length = 1200 mm, width = 1150 mm, height = 1650 mm Machine weight approx. 1500 kg, weight of the tool cabinet including contents approx. 150 kg. Electrical system partially overhauled and modernized where necessary! Please only serious inquiries with full name and address, thank you!

Condition: reconditioned (used), -Drilling diameter 5~25 mm -Drilling depth 1500 mm -Tailstock -Tank Ceb Ed Uehuil Rslvogt -pump -Filter

Condition: good (used), Year of construction: 1987, travel distance X-axis: 11,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 2,000 mm, X-way (horizontal) / X-way: 11500 mm Y-way (vertical): 4500 mm W-way (RAM travel): 1600 mm Z-way (spindle travel): 2000 mm Csb Ed Ujwhc U Hjlvogt Spindle diameter / Spindle diameter: 200 mm

Condition: ready for operation (used), Year of construction: 1982, drilling capacity: 55 mm, 1250mm arm hydraulic lock 55mm drilling capacity cube Cgjb Ejv S Uryod Ulvot

Condition: good (used), Year of construction: 1971, Drilling capacity in steel St 60: 55 mm Drilling capacity in cast iron Gg 22: 70 mm Spindle mount MK 5 Thrust 1600 mm small Distance from outer column edge: 350 mm Vertical movement of the boom: 860 mm Max. distance between spindle and table top: 1560 mm Spindle stroke: 400 mm Drill spindle  80 mm Spindle speeds: 22 – 1600 rpm Cgjb Ed Uowcm D Uolvst Feed range: 0.05 – 2.5 mm/rev Column diameter: 400 mm Motor power: 4 / 5.5 kW Table clamping area: 1750 x 1000 mm Dimensions (L x W x H) (with motor): 2500 x 1130 x 3150 mm Loading dimensions (L x W x H) (without motor): 2500 x 1130 x 2850 mm Weight: 5600 kg Accessories / Special features: • Electromechanical central clamping • Electrohydraulic preselection of speeds and Feeds • Right-left rotation • Drilling depth limit switch • Cube table • Multi-disk clutch for thread cutting • Emergency stop switch • Coolant system Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Line drilling machine - 2 machines: Speed 90 - 1000 1/min. - 4 machines: Speed 4000 - 6000 1/min. - Coolant device Cgeb Ejhpl R Sod Ulvot - tool holder: MK2 - width: 200 cm - height: 200 cm - Depth: 100 cm Good condition fully functional can be viewed and tried on site. Shipping also abroad. Viewing : Basically, I would like to point out that to avoid misunderstandings, the item is welcome to be inspected and tested under power before purchase. Please ask questions before buying to avoid ambiguity. For general questions or to make an appointment for a viewing, I am, at the phone number below or above, always available. Errors in the description and subject to prior sale. VAT is shown separately on my invoices. Shipping with forwarding agent.

Condition: ready for operation (used), Radial Drill, Used Equipment Brand: CSEPEL Model: R.F. 2a Description: Column Diameter: 350 mm Vertical Travel of the Arm: 1200 mm Horizontal Travel of the Drill Head: 1000 mm Vertical Travel of the Spindle: 400 mm Spindle Diameter: 65 mm 12 Spindle Speeds: 47.5 – 2100 RPM Cgsb Eewfrmtsd Ulvet 8 Feed Rates: 0.048 – 1.2 m/min Motor Power: 9 HP

Condition: used, Year of construction: 2008, machine/vehicle number: 0702-240017, Cross transfer tables as a chain drag system for the cross transport of sectional steel in steel construction and steel trade. These sturdy cross transfer tables were used on a Kaltenbach bandsaw line and are in very good condition. 5 pieces of overhauled cross drags as chain drag system with antitrailing bar for discharge side, incl. 1 x motor and 4 x shafts, length 3300 mm, height 600 mm, Cgeb Ejr Rddwed Ulvet

Condition: excellent (used), Year of construction: 2017, ALZMETALL ALZSTAR 30/S Drilling capacity in steel E335 (St 60) mm 30 Threading in steel E335 (St 60) mm M 16 Short spindle MT 3 Throat mm 293 Support surface of machine table mm 515 x 360 Spindle-to-table distance min./max. mm 132 / 724 Column diameter mm 115 Spindle stroke mm 140 Manual feed Power kW 1.0 / 1.6 Spindle speed 225 / 4300 Cgsb Ed Uljwc Auvjvst Year of manufacture 2017

Condition: excellent (used), I am selling WMW HECKERT BT 2 table drill. - Drill in bdb condition. Cjb Ed Ueud Atqolvsgt - Includes table + vise.

Condition: ready for operation (used), Year of construction: 1984, 5 drilling heads 1 PMA25 head capacity 25MM 3 MTM10 heads capacity 10MM Cob Edjwgauno Ulvogt 1 head capacity 5MM table 2500X470MM

Condition: good (used), Gillardon GT 16 bench drill - MK2 holder - infinitely variable speed Good condition, fully functional, can be inspected and tested on site. Shipping also abroad. Inspection : Cgsbeum Staj Ed Ulvst Basically, I would like to point out that the item can be inspected and tested under power before purchase to avoid misunderstandings. Please ask questions before buying to avoid any ambiguities. For general questions or to make an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale reserved. VAT is shown separately on my invoices. Shipping with forwarding agent.

Condition: not inspected (used), Maintained radial drilling machine drilling capacity in steel: 40,0 mm throat: 1300 mm tool holder: MK4 max. swivel angle: +/- 180 degrees quill stroke: 280 mm Min. distance column - drilling spindle (X) 593 mm Max distance column - drilling spindle (X) 1473 mm Speed: 52 - 2000 rpm (12 steps) Feed rate: 0,05-0,1-0,2-0,3 mm/rev (4 steps) column diameter: 250 mm spindle diameter: 68 mm Ceb Ed Uloirngasvogt clamping area: approx. 1445 x 810 mm operating voltage: 400 V Total power requirement: 5.5 kW Machine weight: approx. 2815 kg. Space requirement (L x W x H): 2010 x 820 x 2495 mm Equipment: - electric height adjustment - hydraulic clamping of the drilling slide and the column - cube clamping table with T-slots - automatic spindle feed - R/L run of the drilling spindle - electric height adjustment from boom - speed adjustment manual - feed adjustment manual - handwheel for drill carriage adjustment We will be pleased to demonstrate the machine under power on site. All data without guarantee. Subject to prior sale. The object of purchase is sold under exclusion of any warranty. The exclusion does not apply to claims for damages arising from grossly negligent or intentional breach of obligations of the seller and for any injury to life, limb and health.

Condition: excellent (used), WOTAN 160 floor borer Spindle 160 mm Travels: 5000 x 2000 mm Rotary table: 2500 x 2000 mm 4 floor plates 3500 x 1750 x 350 mm DRO, Facing Head and vertical head Ceb Ed Ulev Eglrevjgt

Condition: good (used), Morse taper sleeve, tool holder, Morse taper, Morse cone, taper sleeve, adapter, extension sleeve, reducing sleeve, cone sleeve, adapter sleeve, spindle sleeve -Adapter sleeve: Morse taper sleeve MK6 2 pieces -Type: PTPk-6/5 / MK6/5 -Shipping/Price: complete -Transport dimensions: 127/64/H148 mm -Weight: 4.0 kg Cgeb Ed Ulewb A E Eevst

Year of construction: 1991, operating hours: 50,562 h, Condition: ready for operation (used), Control Unit Brand SIEMENS Model Sinumerik S3 Main Drive Number of axis 5 This 5-axis Peddinghaus TDK 1000/9E drilling machine was manufactured in 1991. Consider the opportunity to buy this Peddinghaus TDK 1000/9E drilling machine if you are looking to get high-quality drilling capabilities. Contact us for more information. Cjb Edewchubj Ulvogt Application Types Other Machine Tools
