Condition: used, Year of construction: 1985, For sale: Dwedpfx Aszzw Tbed Sob MAHO MH 1000C milling machine Factory number 11429 BKW GmbH model S.05ES Year of manufacture: 1985 18 bar, Vol. 1.6 m3/h; 3000 1/min; kW 0.36; 50/60 Hz; V 190-240; A 2.85 Net price: 7000 Euro

Condition: good (used), Year of construction: 1974, functionality: fully functional, Technical details Dwsdszzwzfspfx Ad Sob x-travel 500 mm y-travel 300 mm z-travel 380 mm table surface area 800 x 420 mm table load capacity 400 kg tool taper ISO 40 spindle turning speed range 40 - 2000 U/min feeds longditudinal/cross/vertical 10 - 500 mm/min rapid traverse 1500 mm/min main drive 3 kW weight of the machine ca. 1,3 t Additional information * 3-axis digital readout (Heidenhain) * Adjustable vertical milling head with quill adjustment * Additional horizontal spindle * REPAR 2 safety device * Machine light * Anti-vibration mounts Transport dimensions: The machine will be loaded onto a heavy-duty pallet; Dimensions: 1800 x 1100 x 2100 mm (length x width x height)

Condition: good (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 3,800 mm,

Condition: like new (used), Year of construction: 2019, operating hours: 9,620 h, functionality: fully functional, machine/vehicle number: 7607, feed length X-axis: 550 mm, feed length Y-axis: 340 mm, feed length Z-axis: 355 mm, travel distance X-axis: 415 mm, travel distance Y-axis: 340 mm, travel distance Z-axis: 355 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 42,000 rpm, spindle speed (min.): 5 rpm, total height: 2,450 mm, total width: 2,250 mm, total length: 2,350 mm, type of input current: three-phase, table load: 500 kg, overall weight: 4,000 kg, input voltage: 400 V, workpiece weight (max.): 500 kg, distance table to spindle center: 495 mm, space requirement width: 2,500 mm, space requirement length: 2,600 mm, space requirement height: 2,600 mm, warranty duration: 6 months, input current: 25 A, input frequency: 50 Hz, Equipment: documentation/manual, rotational speed infinitely variable, HSC 300/3 - 3-axis TNC640 High-speed milling machine Factory refurbished Technical data: Working area X/Y/Z 415x340x355 Workpiece weight max. 500 kg Distance machine table - spindle nose 495 mm Machine dimensions (W x D x H) 2250x2350x2450 mm Machine weight approx. 4000 kg Power connection three-phase 400V/50Hz Equipment Color light/telegraph gray Control Heidenhain TNC640 NC-34059008 SP1HF1 Milling spindle Steptec HVC140 Speed 42000 rpm Dwodpfxezzklqe Ad Ssb Tool holder HSK40-E Tool positions 16 Tool measurement with laser Handwheel Renishaw measuring probe OMP400 Minimum quantity lubrication Adjustable air supply Dust extraction L.CUT1 with attachment silencer Services including transport, on-site inspection, training Options on request: Automation with AWEX50/5 50 electrode changing positions 5 pallet changing positions

Condition: used, Travel ranges: x 400 mm y 375 mm z 250 mm Table size 200 x 800 mm Spindle speeds 50 - 3150 rpm Tool holder SK 40 Spindle quill travel 50.0 mm Rapid traverse rate 2.4 / 1.6 m/min Control system: Philips Dimensions L-W-H 1860 x 1790 x 1750 mm Dedpfx Adszzxfrj Sowb

Condition: good (used), Year of construction: 1995, functionality: fully functional, feed length X-axis: 700 mm, feed length Y-axis: 315 mm, feed length Z-axis: 175 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 315 mm, travel distance Z-axis: 495 mm, feed rate X-axis: 9 m/min, feed rate Y-axis: 9 m/min, feed rate Z-axis: 4 m/min, spindle speed (max.): 9,000 rpm, spindle speed (min.): 50 rpm, quill travel distance: 175 mm, rapid traverse X-axis: 9 m/min, rapid traverse Y-axis: 9 m/min, rapid traverse Z-axis: 4 m/min, total width: 2,480 mm, total length: 1,620 mm, table width: 1,230 mm, table length: 410 mm, position of the milling head: vertikal, type of input current: AC, rotational speed (max.): 9,000 rpm, rotational speed (min.): 50 rpm, overall weight: 3,200 kg, input voltage: 400 V, workpiece weight (max.): 250 kg, space requirement width: 2,500 mm, space requirement length: 2,500 mm, space requirement height: 2,450 mm, input current: 25 A, input frequency: 50 Hz, Equipment: documentation/manual, rotational speed infinitely variable, Due to restructuring measures, we are selling our CNC milling machine – Fehlmann Picomax 80 CNC 2/3 - robust Swiss precision machine - year of manufacture 1995 - low operating hours - very good condition considering its age - Heidenhain 315B control system - 4 axes (X, Y, Z + A [rotary axis]) - axes can be moved in parallel - travel distances X700 x Y315 x Z170 (+W495) mm - table 1,320 x 410 mm - 4th axis (rotary axis) AT100 original Fehlmann with 140mm three-jaw chuck and collet chuck - manual control panel - spindle 50 – 9,000 rpm Dwodpjzzd Hhsfx Ad Ssb - complete steel sheet enclosure with safety glass - fully functional - complete operating and programming manual - spare parts and service available from Fehlmann - machine can be inspected while powered on Depending on the price, a wired measuring probe (Renishaw), an electric fine milling and grinding spindle from RAY (Switzerland) 10,000 - 40,000 rpm, and various tool holders can be included. This offer is subject to change. Subject to prior sale. No online sales. The sale is only to commercial customers after inspection and acceptance on site. Due to the age of the machine, the sale is made with the exclusion of any warranty. Pick-up only (EXW) - no shipping.

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 9220212, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 2,000 rpm, workpiece weight (max.): 4,000 kg, TECHNICAL DETAILS X-axis travel: 3,200 mm Y-axis travel: 1,000 mm Z-axis travel: 1,000 mm B-axis rotation: 360° C-axis rotation: 360° Spindle speed range: 40 – 2,000 rpm Dwsdpfjzza U Iox Ad Sjb Tool holder: ISO 50 Main spindle power: 15 kW Number of axes: 3 Table length: 3,500 mm Table width: 800 mm Maximum workpiece weight: 4,000 kg MACHINE DETAILS Control system: Conventional Model: Bed milling machine with traversing table Dimensions & Weight Dimensions (L x W x H): 5,300 x 3,000 x 2,700 mm Shipping weight: 11,000 kg Number of shipping packages: 1 EQUIPMENT Digital display: Sony 3-A

Condition: used, Year of construction: 1967, total height: 2,000 mm, total width: 1,500 mm, total length: 1,800 mm, Colour: Grey Empty weight: 3.000 kg - Year: 1967 - Documentation available: Yes - CE certificate present: No - Serial number: 2166 - Drive system: Conventional - Horizontal/vertical: vertical - Power [kW]: 4.5 - Number of axes [pcs]: 3 - X-axis travel [mm]: 900 - Y-axis travel [mm]: 220 - Z-axis travel [mm]: 380 - B-axis rotation [°]: 360 Dwodpfx Aoyym Risd Sob - Table length [mm]: 1300 - Table width [mm]: 300 - Tool holder: ISO40 - Main spindle power [kW]: 3.5 - Min. spindle speed [rpm]: 40 - Max. spindle speed [rpm]: 1360 - Transport dimensions: 1800mm x 1500mm x 2000mm (l x w x h) - Transport weight [kg]: 3000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Control system: MAHO 432 Spindle mount: SK 40 Spindle speeds: 20 - 4000 RPM Travel distances: X 500 mm, Y 380 mm, Z 350 mm Djdpfx Aozzxhgod Sswb 16-position tool changer Table load capacity: 250 kg The machine can be inspected while in operation (under load).

Condition: ready for operation (used), Year of construction: 1997, operating hours: 13,465 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 400 mm, table load: 1,000 kg, controller model: Heidenhain iTNC 430, TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 450 mm Dsdezwmx Sopfx Ad Sowb Travel range, Z-axis: 400 mm Table load: max. 1,000 kg Tool holder: SK 40 MACHINE DETAILS Control system: Heidenhain iTNC 430 Operating voltage: 400 V Control voltage: 24 V Machine weight: approx. 6,000 kg Operating hours: 48,690 h Spindle hours: 13,465 h EQUIPMENT Tool holders SK 40 Documentation Heidenhain programming manual Machine vise Clamping jaws

Year of construction: 2017, condition: used, Number of axes: 5, max. spindle speed: 50,000rpm, spindle taper: HSK E25, working area dimensions: 410x294x210mm, table dimensions: 450x300mm, T-slots: 12mm, spacing: 50mm, max. workpiece weight: 100kg, feed rate: 0-42,000mm/min, tool changer positions: 18 (linear), max. current consumption: 18A, connected load: 10kVA, length: 1995mm, width: 2480mm, height: 2080mm, weight: 3.2t, operating hours: 57,869h, spindle hours: 1,797h, an on-site inspection is possible. Dsdpjzzqc Aefx Ad Sowb

Condition: excellent (used), Year of construction: 2019, operating hours: 7,000 h, functionality: fully functional, MACHINE CONSTRUCTION: - Cast iron bed, spindle head, and saddle system developed through computer-aided design and analysis (CAD/CAE), ensuring high rigidity and vibration damping - Fully supported table guide in every working position - X-axis (table movement) on 2 precision cylindrical roller guides, supported by 6 runner blocks each - Y-axis with 2 precision cylindrical roller guides - Z-axis with hardened and ground guideways, with TURCITE-B coating - Guideway protection via metal telescopic covers - Hydraulic counterweight / balance system - CE conformity Axes: - Preloaded ballscrews with large pitch for long-lasting precision - Digitally controlled, liquid-cooled ballscrew on the X-axis - Gear-driven ballscrews, ballscrew nuts with centralized lubrication, and lifetime-lubricated bearings CONTROLLER & ELECTRONICS + CAPACITY: - High-speed CNC, 1 ms block processing time - Storage capacity: 120 GB SSD - Technology program memory: 100 GB SSD - Number of processor cores: 4 CNC operating system: - User interface operating system: Windows 10 - Technology program storage: WINDOWS file system - Total storage capacity (system program, PLC, parameters, technology program memory) on a single SSD - New user interface (40-00005216-00w) SCREEN: Color graphical LCD touchscreen COMMUNICATION: USB, Ethernet, EtherCAT MEASURING SYSTEM: - HEIDENHAIN absolute EnDat 2.2 - PROGRAMMING: ISO, myNCT TECHNICAL DATA: - X-travel: 2100 mm - Y-travel: 1500 mm - Z-travel: 1000 mm Distance from spindle nose to table surface: 200~1000 mm Distance between columns: 1650 mm Distance between table and gantry/crossrail: 1710 mm AXES: - Rapid traverse speed X / Y / Z axis: 20 / 20 / 15 m/min - Max. working speed: 10 m/min - Motor power: 4 kW ACCURACY (according to JIS6338): - Positioning accuracy: +/- 0.01 mm (In the entire working area!) - Repeatability: +/- 0.004 mm TOOLING: - Max. tool diameter / with adjacent tool omitted: 125 / 215 mm - Max. tool length: 400 mm - Max. tool weight: 20 kg - Optional tool taper: SK50 Accessories & Equipment: - Angle head (manual) - Chip conveyor - Coolant flush gun - 15 pcs of SK50 tool holders Dsdpfxezzf Ruo Ad Sowb - Machine leveling feet - Manuals The machine is in good used condition and operates accurately.

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: G0E 1075, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 460 mm, spindle speed (max.): 12,000 rpm, controller model: Mitsubishi 64S, No minimum price – guaranteed sale to the highest bidder! Dwjdpfx Adozx Ahxs Seb TECHNICAL DETAILS Travel in X-axis: 600 mm Travel in Y-axis: 400 mm Travel in Z-axis: 460 mm Spindle speed: 12,000 rpm Tool holder: BT40 Table size: 700 x 410 mm Maximum table load: 250 kg Number of tool magazine slots: 24 MACHINE DETAILS CNC control: Mitsubishi 64S Coolant pressure: 20 bar Dimensions & Weight Machine dimensions (L x W x H): 1,880 x 3,550 x 2,790 mm Machine weight: 4,300 kg Operating hours: The seller estimates the operating hours to be approximately 20,000 hours. EQUIPMENT Spindle cooling Chip conveyor Extraction system Electronic handwheel Renishaw measuring probe Ethernet interface Approx. 100 tool holders including cabinet

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details x-travel 4000 mm Dwjdpozzw Nijfx Ad Seb y-travel 1350 mm z-travel (Vert.) 1600 mm Control Heidenhain iTNC 530 table surface area 4200 x 1150 mm table load 13 t tool taper ISO 50 spindle turning speed - stepless 0 - 3000 U/min transmission ratio 2 spindle motor 28/38 kW feed range 5000 mm/min rapid traverse (X/Y) 12 m/min rapid traverse (Z) 10 m/min weight of the machine ca. 37 t dimensions of the machine ca. 12,9 x 6,53 x 3,79 m Additional information In January and October 2025 the milling head was overhauled (new bevel gears and bearings). Total costs 51.000,- Euro. Working hours (dated 31. July 2025): Machine on: 38.483 h Auto cycle: 12.798 h Spindle hours: 11.645 h A current geometry measurement report is available. * CNC-control HEIDENHAIN iTNC 530 * Electronic handwheel * 50-position tool changer * Controlled universal milling head, indexable 2.5 / 2.5 deg. * Coolant device * Cooling through the spindle * 2 chip conveyors * Oil cooler * Measuring probe * Machine documentation

Condition: good (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 3,600 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 900 mm, spindle speed (max.): 18,000 rpm, The complete photo gallery is available only upon exclusive request from end-user customers. Dodpfx Adozznnvs Sjwb DMG / DECKEL MAHO DMF 360 linear Year of manufacture: 2013 Working area X: 3,600 mm Y: 1,100 mm Z: 900 mm Moving table design 2 working spaces for pendulum machining removable working space partition direct measuring systems Dynamics / Axes Linear drive X-axis Rapid traverse X/Y/Z: 80 / 60 / 60 m/min Acceleration X/Y/Z: 5 / 6 / 6 m/s² Active cooling for main spindle and linear motor Swivel head / Main spindle CNC swivel head B-axis Speed range: 20–18,000 rpm Tool holder: HSK-A63 According to DIN 69893 Power: 35 / 25 kW at 40 / 100 % duty cycle Tool magazine 60 tool positions Magazine version compatible with HSK-A63 / SK40 Chain magazine Double gripper Chip-to-chip time: 7.5 s Control system HEIDENHAIN iTNC 530 3D control smarT.NC ERGOline Control 19" screen Table / Rotary table Fixed table: 4,200 × 1,100 mm Integrated rotary table Rotary table Ø 1,050 mm Arranged on the left Max. load capacity: 1,200 kg Hydraulic clamping Hydraulic clamping 30–240 bar 2 circuits Coolant / Production Internal coolant through the spindle 40 bar Coolant system 980 liters Chip conveyor Spray gun Rotary through-spindle Purge air for linear measuring systems Blow-through air through the spindle center Blow-through air selectable via M-function Maintained compressed air with low oil content Measuring technology Infrared measuring probe HEIDENHAIN TS 649 DMG Laser tool breakage detection Further standard equipment Automatic working space doors 2 rotating viewing windows 4-color signal light Electronic handwheel Operating mode 4 / Process monitoring Safety package in case of power failure Overvoltage protection Undervoltage monitoring Fast brake control Torque support HSK-A63 / SK40 / CAT40 Tool package for aluminum machining DMG Messenger Web DMG Netservice Client

Condition: used, Year of construction: 2007, total height: 2,550 mm, total width: 3,700 mm, total length: 5,250 mm, workpiece weight (max.): 3,000 kg, overall weight: 8,000 kg, power: 22 kW (29.91 HP), MTE K-15 Bed Milling Machine Technical Specifications: Clamping Surface: 1,700 × 750 mm Spindle Speed: 40–3,000 rpm Dedpfx Adjzzk Hue Sjwb Tool Clamping Force: 1,500 daN Milling Feed Rate: 0–12,000 mm/min Positioning Feed Rate: 15 m/min Positioning Accuracy: < 0.012 mm Repeatability: < 0.007 mm Machine Weight with ATC: approx. 8,500 kg Tool holder type: SK 50 DIN 2080 Dimensions (LxWxH) approx.: 5250 x 3700 x 2550 mm Weight approx.: 8,000 kg Travel Y-axis: 800 - mm Power: 22 kW Control: Heidenhain Travel Z-axis: 800 - mm Component weight max.: 3,000 kg Travel X-axis: 1500 - mm Year of construction: 2,007 Condition: in working order Terms of payment: to be agreed upon Terms of delivery: Loaded on truck under power: No

Condition: ready for operation (used), Year of construction: 1991, functionality: limited functionality, machine/vehicle number: 9731, feed length X-axis: 5,000 mm, feed length Y-axis: 5,000 mm, feed length Z-axis: 5,000 mm, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 420 mm, feed rate X-axis: 7 m/min, feed rate Y-axis: 7 m/min, feed rate Z-axis: 6 m/min, quill stroke: 75 mm, quill travel distance: 75 mm, quill diameter: 55 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, rapid traverse X-axis: 7 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 7 m/min, table length: 900 mm, table width: 458 mm, table height: 900 mm, type of input current: three-phase, total height: 1,890 mm, total length: 3,970 mm, total width: 3,740 mm, overall weight: 2,300 kg, input voltage: 380 V, space requirement width: 3,740 mm, space requirement length: 3,970 mm, space requirement height: 1,890 mm, milling spindle length: 75 mm, year of last overhaul: 2015, grinding spindle motor power: 59 W, Equipment: documentation/manual, rotational speed infinitely variable, Control system: HEIDENHAIN TNC 407 Dsdpfx Aezyp Twsd Sswb Travel range: X = 600, Y = 400, Z = 420 mm Spindle speed range: 20 – 4000 rpm Gear stages: 3 Tool holder: SK 40 Arbor stroke: 75 mm Spindle motor: 5.9 kW Feed rate range: 1 – 5000/6000 mm/min (manual/program) Rapid traverse rate x, y: 7 m/min Rapid traverse rate z: 6 m/min Clamping area: 900 x 458 mm Weight: approx. 2300 kg With coolant system, electric handwheel, various tools (without cabinet).

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 2170112, spindle speed (max.): 1,650 rpm, total height: 1,800 mm, total length: 4,000 mm, total width: 1,000 mm, For sale is a Kärcher ROBO 30 pipe drilling and milling machine, manufactured in 2012. Motor power: 1.85 kW Compressed air: 6 bar The ROBO 30 is designed for the quick and dimensionally accurate machining of pipes, flat material, and profiles. The self-centering clamping device allows different workpieces to be quickly and precisely clamped and machined. Djdpozyntpjfx Ad Sjwb The machine enables angular drilling and milling operations and is particularly suitable for the production of railings, handrails, and similar structures. Inspection is possible by appointment.

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 5752, travel distance X-axis: 1,250 mm, travel distance Y-axis: 540 mm, travel distance Z-axis: 520 mm, spindle speed (max.): 2,000 rpm, controller manufacturer: Heidenhain, TECHNICAL DETAILS Travel range, X-axis: 1,250 mm Travel range, Y-axis: 540 mm Travel range, Z-axis: 520 mm Table length: 1,800 mm Table width: 400 mm Tool holder: BT50 Main spindle power: 7.5 kW Spindle speed: 275–2,000 rpm MACHINE DETAILS Control: CNC Control system: Heidenhain Number of axes: 3 Connected power: 12 kW Dimensions & Weight Dimensions (L × W × H): 2,100 × 2,100 × 2,200 mm Net weight: 3,600 kg Number of transport packages: 2 EQUIPMENT Tools Documentation Dsdjzxdxlopfx Ad Sewb CE marking

Condition: excellent (used), Year of construction: 2008, machine/vehicle number: 1780021272, functionality: fully functional, 3 spindle copy router elumatec KF 178/00 Dwsdjzy Stajpfx Ad Seb Top routing unit: Cutting range using stops or copy templates 340 x 100 mm Travel 110 mm Bottom routing unit: Cutting range using stops or copy templates 240 x 85 mm Travel at front 95 mm Travel at back 45 mm Spindle speed 12,000 rpm Clamping range for profiles 115 x 100 mm Power supply 230/400 V, 3~, 50 Hz Power output per motor 0.74 kW Cobtjzmn N Reiaf Smorg Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 980 mm, depth 1,250 mm, height 1,610 mm, weight 360 kg We can ship the machine to your address.

Condition: excellent (used), Year of construction: 2014, Equipment: documentation/manual, MECOF MASTERMILL HPC3 X: 4000 MM Y: 1600 MM Z (VERTICAL): 3000 MM RAM SECTION: 500 X 500 ROTARY TABLE: 2000 X 2500 - TRAVEL 1500 MM - CAPACITY 30 TONS Dwedpszzp Dxefx Ad Seb SPINDLE SPEED: 6000 RPM TOOL CHANGER: 80 POSITIONS HEAD: BI-ROTATIVE HEAD WITH AUTOMATIC MILLIMETER-ACCURATE POSITIONING HIGH INTERNAL SPINDLE PRESSURE - RENISHAW FOR TOOL MEASUREMENT CNC: HEIDENHAIN TNC 530i

Condition: used, Year of construction: 1987, Universal CNC Milling Machine CNC MAHO MH 400 E Travel X: 400 mm Travel Y: 375 mm Travel Z: 250 mm Numerical Command CNC PHILIPS 432 Table: 700 x 270 mm Cone: SA40 Dsdpfx Adozy Rrzj Sswb Spindle speed: from 80 to 4000 RPM Year of construction: 1987 Central lubrication Manually swivel head Supplied with doc + machine parameters Voltage: 380 V Width: 2200 mm Depth: 2000 mm Total height: 2000 mm Weight: approx 1,5 T

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, Deckel FP 1 MK Aktiv TNC 113 Djdpfxszy Rlne Ad Sswb Year of manufacture: 1991 Spindle speeds: 40 - 2000 rpm, SK 40 Travel ranges: X 300, Y 160, Z 340 Stepless feed rate + rapid traverse in all axes Weight: approx. 880 kg Accessories: fixed angular table (optional universal table), electric central lubrication system, direct collet chuck set, 8 tool holders SK 40, machine vise Röhm, coolant system, machine feet, chip tray, documentation. Condition: Original, not repainted, smooth operation at all spindle speeds and axis movements, guides in perfect condition. Of course, the machine can be inspected while powered on. Free loading at D - 88433 Schemmerhofen.

Condition: excellent (used), Year of construction: 2019, operating hours: 29,081 h, functionality: fully functional, CNC control HEIDENHAIN TNC 640, 15" Main computer MC Controller unit CC Keyboard TE 15" TFT color flat screen with softkeys RAM: 4 GB Hard disk: 32 GB, of which at least 21 GB program memory Input resolution / display increment linear axes: up to 0.1 µm Input resolution / display increment rotary axes: up to 0.0001° Input range: max. 99,999.9999 mm or 99,999.9999° Circular interpolation in 3 axes with tilted machining plane Helical interpolation Linear interpolation in 5 axes Block processing time: 0.5 ms Ethernet: 2 x 1000BaseT USB: 1 x front USB 2.0, 4 x rear USB 3.0 Handwheel HEIDENHAIN HR510 Axis selection via buttons / softkeys Buttons for continuous axis movement Emergency stop button Magnetic attachment Enable buttons / dead man's buttons according to CE Travel ranges X-axis / longitudinal axis: 4,000 mm Y-axis / transverse axis: 2,500 mm Z-axis / vertical axis: 1,300 mm Feed / connection / pneumatics Max. feed rate interpolating axes: 40 m/min Installed power: 60 kVA Max. power consumption: 150 A Dwodpfx Ajyrndmed Seb Air requirement pneumatics: 400 Nl/min Working pressure pneumatics: 6 bar Machine table / floor plate Machine table recessed, with leveling units Table size: 2,500 x 4,000 mm Table height: 300 mm Load capacity: 10 t/m² T-slot width: 28 H12 mm T-slot spacing: 250 mm Milling head / universal milling head Universal milling head with continuous movement in 2 axes 5-axis machining Direct drives for rotary axes Rotary axes as interpolated CNC axes Automatic tool clamping Undercut machining up to 10° possible Integrated cooling of the torque motors and spindle bearings C-axis swivel range: +/- 270° A-axis swivel range: +/- 185° Max. speed A/C axes: 30 rpm Working torque A/C axes: 450 Nm Clamping torque axes: 1,400 Nm Positioning accuracy A/C axes: 8 arcsec Positioning repeatability A/C axes: 4 arcsec Main spindle Spindle power S1 / S6: 22 / 33 kW Spindle torque S1 / S6: 84 / 128 Nm Max. spindle speed: 18,000 rpm Constant power: 2,500 - 18,000 rpm Constant torque: 10 - 2,500 rpm Tool holder: HSK-A63 DIN 69893 Rigid tapping for electric spindle Software / calibration Dynamic RTCP software AUTOCAL software for automatic calibration 3D Form Inspect M&H software Software for measuring 3D shapes, tools, molds and dies Measurement program creation directly via coordinate points / surface points Vibration / collision monitoring Sensor for detecting vibrations Detection of collisions and excessive vibrations on 3 axes Reaction time approx. 1 ms Electronic interface for functional testing Tool changer Tool changer with arm for tool changes Overlapped-wheel design Full enclosure for operator safety Tool positions: 80 Max. tool diameter: 75 mm Max. tool diameter with free adjacent positions: 125 mm Max. tool weight: 10 kg Max. tool length: 600 mm for 40 tools Max. tool length: 250 mm for 40 tools Tool type: HSK-A63 DIN 69893

Condition: used, Year of construction: 1989, Universal CNC Milling Machine MAHO MH 600 E2 Travel X: 600 mm Travel Y: 400 mm Travel Z: 450 mm Dsdpfx Adjzy Rruo Sowb Numerical Command CNC PHILIPS 432 Cone SA40 Spindle speed: from 20 to 4000 RPM Table size: 900 x 480 mm TravelSpindle sleeve travel: 80 mm Year of construction: 1989 1 lubricant tank Voltage: 380 V Width: 2500 mm Depth: 2400 mm Total height: 2000 mm Weight: approx 3,5 T
