Used Highspeed radial drilling machines for sale
6
bore capacity in steel (diameter) 40 / 50 mm
arm length 635 - 1230 mm
workpiece height max. 707 mm
thread capacity M28 / M32
spindle taper MT 4
spindle stroke - max. 200 mm
turning speed range - drilling 56 - 1120 U/min
Bu0qhdcfaz
spindle feeds: 9
feed range - boring 0,08 - 1,25 mm/U
base plate surface area 1300 x 710 mm
total power requirement 4 / 3,4 kW
weight of the machine ca. 2,5 t
dimensions of the machine ca. 2,1 x 1,5 x 2,76 m
6
bore capacity in steel (diameter) 23,0 mm
arm length 900 mm
spindle taper MT 3 MK
bore depth 130 mm
turning speeds 70 - 1550 U/min
column diameter 150 mm
table surface area 1200 x 500 mm
feed range 0,075/0,15/0,3 mm/U
total power requirement 4,0 kW
weight of the machine ca. 2,0 t
Furnishing:
- automatic spindle feed
Bjaduoxvhe
- Electromotive drill head adjustment
- Boom can be moved back and forth and swiveled horizontally
- hydraulic clamping
- Pole changing motor
- Gear shift
- Lateral cla...
4
Make: KOVOSVIT MAS
Type: VOM 50
Year: 1991
Specifications
Metric US Standard
Arm Length
2070 mm
Cbtf9hekoo
Max. drill Ø cast
50 mm
Max. tap Ø
M48 M
Stroke pinole
350 mm
Max. distance spindle - table
1550 mm
Min. distance spindle - table
305 mm
Floor / table area
X Travel 1200 mm
Speeds / ranges
800 Rpm
Spindle Taper
5 ISO/Bt/Mk
Power
8 kW
Dimensions (Estimate)
Length
5800 mm
Width
2100 mm
Height
3440 mm
Weight
6750 kg
Please Note: The information on this page has been obtained to the best of ...
4
1 used high speed radial drilling machine
make Donau
type Alpha 30
Year 2015
Gyv3js
drilling capacity in steel 30 mm
Boom travel 900 mm
drilling radius min. 420 mm / max. 1,320 mm
spindle speed 60 - 3,050 rpm (18 steps)
Tapping attachment
Tool holder MK 4
Hydraulic clamping for boom and lifting column
Electromagnetic feed clutch
Machine light
4
Technical data :
Drilling capacity 32 mm
Cbshbptosv
motor power 1,8 / 2,2 kW
mounting MK 4
quill stroke approx. 160 mm
.
12 speeds 102 - 2000 rpm
3 feeds 0.1 / 0.2 / 0.3 mm/rev.
.
Horizontal movement of the drill head approx. 800 mm
Distance spindle to round column below, approx. 20 - 820 mm
Table clamping surface approx. 450 x 1200 mm
.
7
bore capacity in steel (diameter) 40 mm
arm length 800 mm
workpiece height max. ca. 600 mm
table surface area 1065 x 400 mm
spindle taper MK 4
bore capacity in cast iron 50 mm
threading M 33 (St 60)
threading M 45 (GG 22)
spindle turning speed range 35 - 1800 U/min
column diameter 195 mm
bore spindle stroke 200 mm
distance spindle nose and table min. 350 / max. 800 mm
drilling radial min./max. 305 / 905 mm
feeds 0,075 - 0,15 - 0,30 mm/U
feeds 0,45 - 0,6 mm/U
total power requirement 5 kW
dimen...
3
CONTROLS
.. CNC controls
WORKING RANGE -BORING-
.. drilling capacity full bore (steel): 40 mm
.. throat (max): 800 mm
MILLING SPINDLE / HEAD
.. spindle revolutions (min): 335 /min
.. spindle revolutions (max): 1800 /min
.. number of gears: 2
.. tool fixture: MK 4
TECHNICAL SPECIFICATION
.. table surface (left-right): 1000 mm
.. table surface (front-back): 500 mm
ELECTRICAL SPECIFICATIONS
.. mains voltage: 400 V
.. mains frequency: 50 Hz
DIMENSIONS / WEIGHTS
.. space requirements -left/r...
8
bore capacity in steel (diameter) 32,0 mm
Btxrvkn
bore capacity in cast iron 45,0 mm
arm length 235 - 835 mm
turning speeds steps 18 Stufen
revolutions per minute 41 - 1800 U/min
bore spindles - Morse Taper 4 MK
feed range 0,1/0,15/0,20/0,30 mm/min
feed steps 4 Stufen
table surface area 500 x 1200 mm
quill stroke 190 mm
distance spindle /table 260 - 660 mm
work height max. 870 mm
total power requirement 2,2 kW
weight of the machine ca. 1.480 kg
range L-W-H 1200 x 1600 x 1950 mm
Furnishing:
- ...
1
bore capacity in steel (diameter):50 mm
spindle cone:V MK
spindle stroke:340 mm
hight above plate:1230 mm
revolutions of the spindle, 16 steps:25 - 2000 U/min
Height adjustment:580 mm
automatic feed rates:0,04 - 3,2 mm
travel of the spindle head on the arm:1250 mm
table height:500 mm
dimension of the dice table:630 x 500 x 500 mm
Motor output:4 kW
range L-W-H:2500 x 1070 x 2840 mm
weight:3500 kg
Machine description:
- stable cast body
- Gearbox with hardened and ground gear wheels in oil bath
-...
7
bore capacity in steel (diameter) 40 mm
arm length 392 - 1117 mm
workpiece height max. 330 - 750 mm
spindle turning speed - stepless 186 - 3150 U/min
total power requirement 5 kW
weight of the machine ca. 3 t
Dxiybq
dimensions of the machine ca. 2,5 x 1,5 x 2,2 m
7
bore capacity in steel (diameter) 23 mm
arm length 920 mm
workpiece height max. 550 mm
bore capacity in cast iron 30 mm
spindle taper MT 3 MK
bore depth 130 mm
turning speeds 12: 70 - 1550 U/min
column diameter 150 mm
table surface area 1200 x 500 mm
Cozww0n9o
feed range 0,075/0,15/0,3 mm/U
threading cutting capacity: M 20 / Guss M 26
bore spindle drive 1,1 / 1,6 kW
stroke drive 1,5 kW
weight of the machine ca. 1,38 t
Overall size 1200 x 1700 x 1710/2160 mm
Video available on our website.
E...
3
bore capacity in steel (diameter) 32 mm
arm length 410 - 1000 mm
workpiece height max. 765 mm
Bs0hjvyl07
coolant ja
boring spindle diameter 38 mm
diameter of quill 70 mm
spindle stroke 225 mm
boring spindle MK 4 mm/min
spindle turning speed - stepless 70 - 2000 U/min
feed range - spindle 0,04 - 0,32 mm/U
column diameter 225 mm
bore radius max./min max. 1130 mm
table surface area 630 x 1320 mm
height adjustment 500 mm
base plate 1500 x 1000 mm
T-slots 4 Stück
T-slot - distance 18 mm
total power ...
1
No. 4657:
1 used radial drilling machine
make DONAU
type DR 28 Z
table 1200 x 500 mm
drive power: 2 / 3 kW
Thread cutting device
spindle MK 3,
speed range 45-2240 min-1
Drilling spindle stroke 200 mm
feeds 0,075 - 0,6 mm/rev
Table height 800 mm above floor
T-slots lateral + rear
Drill head stroke vertical approx. 430 mm
Distance. clamping surface / spindle nose approx. 310-740 mm
Drill head stroke radial approx. 1000 mm
O7pmb
Space requirement approx. 2.5 x 2.5 x 3 m,
weight machine a...
7
threading 30 M
bore capacity in steel (diameter) 40,0 mm
workpiece height max. 380 - 785 mm
Bv70a3shpz
arm length 985 mm
spindle taper 4 MK
boring head swiweling right/left -80 / +80 Grad
table surface area 1210 x 520 mm
turning speeds 50 - 2000 U/min
column diameter 220 mm
column diameter 220 mm
table surface area 1.210 x 520 mm
quill stroke 200 mm
feed range - spindle 0,08 - 0,5 mm/U
total power requirement 2,2 kW
weight of the machine ca. 2.800 kg.
dimensions of the machine ca. 2,45 x 1,2 x 2...
5
bore capacity in steel (diameter):33 mm
arm length:900 mm
workpiece height max.:500 mm
Hluqp0fby
bore capacity in cast iron:40 mm
work height max.:800 mm
table surface area:1230 x 500 mm
total power requirement:1,3/1,8 kW
weight of the machine ca.:1500 kg
Rapid radial drilling machine, radial drilling machine, drilling machine, boom drilling machine
-Clamping table 1060 x 390 mm
-Projection 880 mm
-Taper mount MT3
-Motor power 1.1 / 1.6 kW
-Speeds 70-1550 rpm
-Pillar O 150 mm
-Spindle stroke 130 mm
-Threading device
-Feed 0.075 - 0.3 mm / rev
Bw3rvqnd3l
-Dimensions 1640/1200 / H1790 mm
-Weight 1396 kg
9
bore capacity in steel (diameter) 23 mm
arm length 650 mm
table surface area 1200x800 mm
swivable table: 700x240 mm
feed - independent 0,075-0,3 mm
turning speeds 70-1550 U/min
total power requirement kW
Ytuwyo
weight of the machine ca. 2 t
dimensions of the machine ca. 2 x 1,6 x 1,9 m
10
bore capacity in steel (diameter) 35 mm
arm length 1050 mm
workpiece height max. 450 mm
driling depth/spindle stroke 165 mm
thread capacity M30
spindle taper MK 4
crossrail adjustment horizontal 750 mm
pivoting angle 330 Grad
distance spindle nose and table 50 - 665 mm
feeds 0,02 - 0,7 mm/U
spindle turning speed range 20 - 3200 U/min
working height table 900 mm
Table dimensions 1200 x 600 mm
table surface area 1050 x 500 mm
total power requirement 4 kW
weight of the machine ca. 2,3 t
dimension...
5
bore capacity in steel (diameter):32 mm
arm length:240 - 850 mm
workpiece height max.:650 mm
clamping table:1200 x 500 mm
power capacity:1,05 / 1,8 kW
total power requirement:2 kW
weight of the machine ca.:1,5 t
dimensions of the machine ca.:1,7 x 0,5 x 1,95 m
adjustment of quills each:190 mm
taper MK:4
table-size:1200 x 600 mm
surface area:1060 x 500 mm
column diameter:200 mm
speeds:41 - 1800 U/min
Mte9sw
automatic feeds:0,1; 0,15; 0,2; 0,3
10
bore capacity in steel (diameter) 23,0 mm
arm length 900 mm
spindle taper MT 3 MK
bore depth 130 mm
turning speeds 70 - 1550 U/min
column diameter 150 mm
table surface area 1200 x 500 mm
Ruvi7jw
feed range 0,075/0,15/0,3 mm/U
total power requirement 4,0 kW
weight of the machine ca. 2.200 kg
** from a maintenance workshop
** good condition (!!)
Furnishing:
- automatic spindle feed
- Electromotive drill head adjustment
- Outrigger can be moved back and forth and pivoted horizontally
- hydrauli...
7
2 - axis positioning display X / Y coordinates
working table 600mm x 1200mm
cantilever travel 750mm
Tool holder MK 4
Stepless speed max. 3.200 rpm.
Stepless feed
Protective device on drill
Tapping device
Coolant device
Test report for mechanics and electrics
Documentation
Sv2vbs
4
CNC path control
spindle speeds 35 - 1800 rpm (18 steps)
autom. feeds with limit switching: 0,075-0,15-0,3-0,45-0,6 mm/rev.
spindle mounting SK40
drilling spindle stroke: 200m
Thread cutting device
max. throat depth: 1207mm
clamping surface: 1200 x 500mm (18mm T-slots)
work table height: 800mm
C3a93ztfy
Column diameter: 195mm
max. distance between table and spindle: 800mm
Min. distance between table and spindle: 350mm
Solid drilling (steel): s: 0,30 - 40mm in St60
Full drilling (cast iron): s: 0...
5
drill capacity in steel 32 mm
drill capacity in cast iron 45 mm
outreach 235 up to 835 mm
drill spindle holder MK 4
drill spindle stroke 190 mm
thread cutting device
speeds - 18 steps - 41 up to 1,800 rpm
Qicyp
advance speeds - 4 - 0.1 / 0.15 / 0.20 / 0.30 mm per
rotation
table size 1,200 x 500 mm
distance spindle - table 260 up to 660 mm
working height 870 mm
coolant device
electrical data 380 V / 2.2 KW
space requirements width - 1,200 x depth - 1,600 x height -
1,950 mm
weight ...
10
bore capacity in steel (diameter) 35 mm
bore capacity in cast iron 40 mm
workpiece height max. 550 mm
72cta3e
1200 x 580 mm
spindle taper MT 4
throat 1000 mm
bore spindle stroke 160 mm
spindle turning speed range nax. 2880 U/min
feed per revolution stufenlos
voltage 380 V
connected load 6,0 kW
weight of the machine ca. 2,2 t
dimensions of the machine ca. 1,6 x 1,3 x 2,3 m
4
power capacity:2,2 kW
clamping table:1300 x 550 mm
arm length:1000 mm
bore capacity in steel (diameter):32 mm
bore spindles - Morse Taper:MK4
turning speed range - stepless:80 - 1500 U/min
Lqpl2mpn
dimensions of the machine ca.:1,2 x 1,2 x 2,3 m
feed:8 Stufen 0,003 - 0,25 mm/min
workpiece height max.:650 mm
lighting:Ja
column diameter:210 mm
coolant:Ja
total power requirement:3,2 kW
weight of the machine ca.:1,3 t
6
Universal Grinding Machine from Blohm ( Germany ) apply for toolmaker , mold maker, education and Locksmith
Drilling Cap. 32mm
Table : 1175 x 525 x 830 mm
Drilling capacity 32mm
Spindle mount MK 4
Quill stroke 150mm
Swcjx0
Speeds / Steps 102-2000
Feeds / Steps 0,1 0,2 0,3mm/U
Motor 1,5 KW
6
5-axis CNC high-speed radial drilling machine
Ca3jscqem3
Work table 4000mm x 800mm
Travels:
X u. U: 4000mm
Y: 1050mm
Z: 200mm
W: 400mm
Tool holder SK 40
Coolant device
Tapping device
Documentation
Test report for mechanics and electrics
8
Capacity Ø 35 mm, spindle stroke 180 mm, MT-4, throat 250-970 mm, table - spindle high max. 640 mm, motor 4 KW, spindle speed 100-2000 rpm stepless, table size 1530x560 mm, working high 800 mm, dimension 1530x1700x2400 mm, ca. 2300 kgs
B0uctvhaox
8
Used high speed radials
Internal machine number: m3301
Producer Donau
type DR 50
Ma. Number 5004-3
table size 1.200 x 750 mm
throat 1.050 mm
Speed 28 up to 1.420 rpm.
Mounting MK 5
Max. Total height approx. 2.90 m
Weight approx. 3,400 kg
The external cable has been renewed and re-routed through the column. The boom can be rotated 360° again.
Item location: 58730 Fröndenberg/Ruhr
The machine can be inspected with pleasure under power.
A forklift / crane for loading is available.
Subject to prior...
9
High speed radial drilling machine make GENKO type ATB 30 S
year of manufacture 1972 with motorized travel = 1900 mm on basic slide
technical data:
drilling capacity i. ST 60 25 mm
drilling capacity i. ST 60 32 mm
spindle mount MK 3
quill stroke 150 mm
distance spindle/bottom kl./gr. 620 / 1800 mm
radial arm adjustable vert. 1180 mm
Movement horizontal on slide mot. 1900 mm
Movement of boom hor. 600 mm
Boom rotatable 360
Spindle head inclinable up to 45° on both sides
14 spindle speeds 22 - 1920...
2
Drilling in pc. 60 40 mm
Drilling in GG 22 50 mm
Thread cutting capacity in St. 60 M 36
Thread cutting capacity in GG 22 M 45
Infinitely variable feeds 5 - 2000 mm/min
Spindle speeds infinitely variable 15 - 2800 rpm
quill stroke 200 mm
drilling radius min/max 540 / 1590 mm
Throat min/max 330 / 1390 mm
2rthsa
Table top 1800 x 600 mm
6
A used very well preserved high-speed radial drilling machine from Donau
drilling capacity into full in St- 60: 28 mm
drilling capacity in GG 22: 35 mm
Threading capacity in St- 60 to: M30
Tapping capacity in GG 22 to: M36
quill stroke: 135 mm
max. Distance between table and spindle nose: 750 mm
Min. distance between table and spindle nose: 300 mm
Max. drilling radius drilling radius at 800 mm throat depth: 905 mm
Min. drilling radius at 800 mm throat depth: 305 mm
Spindle adaptor: MK 3
18 speed...
4
Machine version
- Work table 1800 x 600 mm with 4T grooves
- extension arm travel 1050 mm
- Drilling spindle SK 40 with tool clamping device
- Stepless speed programming
- Stepless quill feed via three-phase servo motor
- 2 T-slots 18 mm at the rear of the machine base frame
- 2 T-slots 18 mm at the machine base on the left side
- Thread cutting device
- Central lubrication
- Coolant device
- machine light
- CE marking
- Protective device on the drill
Cr2z70c
- USB interface
Dimensions and trave...
3
Code 111258
Transcription quick radials
Make DONAU
Type DR 24
Machine no. 2300 - 3
Year of manufacture 1984
Drilling into the solid in St 60 28 mm
Drilling into the solid in GG 22 35 mm
Tapping capacity in St 60 M 20
Tapping capacity in GG 22 M 30
Morse taper of drilling spindle 3 MK
Throat 309 - 905 mm
Table 1200 x 500 mm
clamping T-slots 3 x 18 mm
Height adjustment of the drilling spindle head 450 mm
Spindle stroke 135 mm
spindle nose - table max / min 665 - 215 mm
18 spindle speeds...
5
Radial drilling machine Donau
type: DB 25
Bmrhzcrosk
table size 1100 x 400 mm
spindle stroke 600 mm
arm length approx. 700 mm
machine was regularly serviced and is in very good condition
3
high speed radial drilling machine make DONAU type DR 13 G
Machine # 332-1 Year of manufacture 1967
Technical data:
Drilling capacity ST 60 / GG 22 13 / 16 mm
Nupwj
Thread St 60 / GG 22 M 10 / M 12
Throat 800 mm
table size 630 x 915 mm
spindle stroke 100 mm
Spindle size MK 2
Speeds infinitely variable 200 - 3400 rpm.
Weight approx. 800 kg
with
- Thread cutting device
- Machine lamp
used, in good condition
6
MIKROSA high-speed radial drilling machine
drilling capacity in steel (diameter) 32 mm
throat 1180 mm
workpiece height - max. 500 mm
spindle throat min. 470 mm
spindle taper MK 4
distance table - spindle min./max. 120/610 mm
spindle stroke 140 mm
Yukeas
spindle speed - infinitely variable 1 - 2800 rpm
table area 1050 x 400 mm
feeds stepless
column diameter 200 mm
Threading capacity up to M 20
total power requirement 1,8 KW
machine weight approx. 2,2 t
Space requirement approx. 1.82 x 1.2 x 2.1 (...
6
Technical data:
- Drilling capacity into solid steel ST 60 23 mm
- Drilling capacity into solid steel ST 60 30 mm
- Drilling capacity GG 25 40 mm
- Drilling capacity GG 25 25 mm
Bm8c9sgz
- Thread cutting ST 60 M 24
- Thread cutting GG M 30
- Drilling spindle adaptor MK 3
- quill stroke 200 mm
- Drilling spindle speed infinitely variable 80 - 1400 rpm
- 8 drilling feeds 0.003 - 0.25 mm/rev
- Height adjustment of drilling column 400 mm
- column diameter 170 mm
- drilling radius min / max ...
4
Machine version
- Work table 1800 x 600 mm with 4T grooves
- extension arm travel 1050 mm
- Drilling spindle SK 40 with tool clamping device
- Stepless speed programming
- Stepless quill feed via three-phase servo motor
- 2 T-slots 18 mm at the rear of the machine base frame
- 2 T-slots 18 mm at the machine base on the left side
- Thread cutting device
- Central lubrication
- Coolant device
Cajxaiykb3
- machine light
- CE marking
- Protective device on the drill
- USB interface
Dimensions and tr...
6
Code 71150
Transcription quick radials MK-4
Make DONAU
Type DR-32
Engine no. 704 - 2
Year of manufacture 1970
Vp7pk
Capacitance in steel 60 32 mm
Capacities in GG 45 mm
Tapping in steel 60 M 26
Thread cutting in GG M 36
Spindle holder 4 MK
Throat 1220 mm
Table 500 x 1200 mm
Vertical movement of the boom 400 mm
Spindle stroke 190 mm
Spindle table min. - max. 260 - 660 mm
18 spindle speeds 41 - 1800 rpm
spindle feeds 0,1 - 0,15 - 0,2 - 0,3 mm/rev
Power 1,5 / 2,2 kW - 380 Volt
Access...
High-speed radial drilling machine make VOLZ type BRB-32F
Machine # 4/97/12 Year of construction 1997
technical data:
drilling capacity in St 3 - 32 mm
drilling capacity in Gg 3 - 40 mm
Thread cutting in St M2 -- M32
Thread cutting in Gg M2 - M33
B2oxd8oa
Morse taper MK 4
quill stroke 180 mm
min. distance spindle / column 380 mm
swivelling of the boom 360
min./max. distance table / spindle 115 / 625 mm
clamping surface 1050 x 400 mm
infinitely variable spindle speeds 12.5 - 3150 rpm
6 automatic ...
4
5-axis CNC high-speed radial drilling machine
Work table 4000mm x 800mm
Travels:
X u. U: 4000mm
Y: 1050mm
Z: 200mm
W: 400mm
Tool holder SK 40
Coolant device
Tapping device
Documentation
B7j2zs9usb
Test report for mechanics and electrics
3
Code 81221
Description Position Controlled Fast Radial Drilling machine
Make DONAU
Model DR 32 NC
Serial No. 7107
Year 1984
Control Heidenhain TNC 145
Drilling cap. in St. 60 in full 32 mm
Drilling cap. in Castiron GG 22 in full 45 mm
Thread cutting in St. 60 M 26
Thread cutting in Castiron GG 22 M 36
Table 1120 x 800 mm
X – Axis 800 mm
Y – Axis 630 mm
Z – Axis ( Quill ) 170 mm
Max. distance Column-Spindel 750 mm
Vertical movement Spindelhead 400 mm
Spindle tap...
7
Work table 600mm x 1200mm
cantilever travel 600mm
tool holder MK 3
drilling capacity 23mm in steel
Thread cutting device
Coolant device
Iqtamfs
Electrical system 24V control voltage
emergency stop 2-channel
Protective device on drill
General overhauled 2022
12 months warranty
New painting RAL 7035/7031
10
Code 51004171314
Description Controlled rapide radialdrilling machine
Make DONAU
Model DANUMERIC 340
Serial No. 6110 – 3
Year 1995
Control Donau
Drilling cap. in St. 60 in full 40 mm
Drilling cap. in Castiron GG 22 in full 50 mm
Bcyoehy0xq
Thread cutting in St. 60 M 36
Thread cutting in Castiron GG 22 M 45
Spindle taper ISO 40
Spindle speeds stepless 15 - 2800 rpm
Quill movement 200 mm
Feeds stepless 5 - 2000 mm/min
Min/max radius of spindle 540 / 1590 mm
...
