Used Jig boring machines for sale
spindle diameter:95 mm
x-travel:2000 mm
distance between columns:2400 mm
table clamping surface::1800 x 2200
cross rail - adjustment:1000 mm
Distance-Boring spindle & boring table-adjustable:1200 mm
spindle stroke:320 mm
spindle turning speed range:40 - 1800 U/min
spindle taper: ISO:40
spindle motor:4 kW
Boring power:65 mm
weight of the machine ca.:12 t
Bdb2kkcs0e
total power requirement:10 kW
dimensions of the machine ca.:4,2 x 3,8 x 3,4 m
Machine retrofit with Heidenhain NC control TNC 310 ...
10
spindle diameter 70 mm
x-travel 420 mm
y-travel 240 mm
Ibk3foh
z-axis 120 mm
w-axis 450 mm
bore capacity in St 50 - in full material 20 mm
30 cm3/Min
thread dia. M 20
spindle throat 274 mm
distance work spindle /surface of the table 560 mm
table surface area 730 x 280 mm
table load capacity 200 kg
turning speed range - stepless 50 - 9200 U/min
spindle feeds - stepless 0,02 - 0,3 mm/U
total power requirement 5 kW
weight of the machine ca. 1,3 t
dimensions of the machine ca. 2x2x2.4 m
Precisi...
4
CONTROLS
.. CNC controls GE FANUC SERIES 15-M
TECHNICAL SPECIFICATION
.. longitudinal travel: 1600 mm
.. cross travel: 1100 mm
Isr9eto30
.. vertical travel: 1000 mm
.. Max. distance between spindle-table: 720 mm
.. number of spindles: 1
.. Tool holding fixture ISO SK: 50
.. Spindle required power: 15 kW
.. Spindle speed from: 10 /min
.. .. to: 6000 /min
.. feed velocity (min): 0 mm/min
.. feed velocity (max): 10000 mm/min
.. Advance vertical: 0 mm/min
.. .. to: 6000 mm/min
.. tab...
5
Ortlinghaus gearbox for hamlet
Caie7gtt7z
Incomplete. As a spare parts donor.
4
spindle diameter 60 mm
x-travel max. 1000 - min. 100 mm
y-travel max. 1000 - min. 100 mm
bore capacity in steel max. 40 mm
thread capacity max. M24
Thickness max. 60 - min. 5 mm
spindle turning speed - stepless einstellbar 1 - 1.000 U/min
feed stepless einstellbar, Eilgang 1 - mm/min
feed stepless einstellbar, Arbeitsgang mm/min
feed power 16 KN
tool taper SK 40
spindle stroke 600 mm
positioning speed in allen Achsen 1 - 10.00 mm/min
positioning accuracy auf 300 mm = +/- 0,01 mm
table load max...
6
spindle diameter 150 mm
x-travel 1500 mm
W3s9c
distance between columns 3000 mm
quill stroke 280 mm
travel -y axis 1450 mm
travel -z axis 800 mm
spindle taper ISO 50
spindle turning speed - stepless 0 - 3000 U/min
table surface area 1750 x 1650 mm
table load 5000 Kg
distance spindle nose and table 1050 mm
spindle drive 25 kW
total power requirement 40 kW
weight of the machine ca. 13 t
dimensions of the machine ca. 5 x 4 x 3,5 m
HEIDENHAIN TNC 145 control
12
Jig boring machine  / Coö rdinate jig boring machine / milling machine
Qintl
Manufacturer:  C. Matheys
Type: 35-NC
Travel:  450x300x300mm
Boring depth: 140mm
Table:  870x300mm
Including Sony Digital-readout
9
spindle diameter 90 mm
x-travel 700 mm
y-travel 500 mm
bore capacity in steel 40 mm
spindle taper MT 4
bore spindle stroke 170 mm
number of spindle speeds 2
stepless 10-2000 U/min
ll diameter 230 mm
table dimension - longitudinal 900 mm
table dimension - cross 770 mm
vertical travel of crossrail 630 mm
boring spindle 6 Stück
from/to 0.02-0..20 U/min
distance between columns 900 mm
distance between spindle and table 815
spindle drive 4.0 PS
total power requirement 380 V
weight of the machine c...
6
CONTROLS
.. CNC controls SIEMENS 840 C
TECHNICAL SPECIFICATION
.. longitudinal travel: 1600 mm
.. cross travel: 1100 mm
.. vertical travel: 1000 mm
.. Max. distance between spindle-table: 720 mm
.. number of spindles: 1
.. tool fixture: ISO SK 50
.. Spindle required power: 11 kW
.. Spindle speed from: 10 /min
.. .. to: 6000 /min
.. feed velocity (min): 0 mm/min
.. feed velocity (max): 10000 mm/min
.. Advance vertical: 0 mm/min
.. .. to: 6000 mm/min
.. table surface (left-right): ...
5
CNC Double Column Coordinate Boring and Milling Machine with independent NC Controlled Deep Hole Drilling Unit
Kolb KBN G 120
Year of manufacture 1984 / Retrofitted with Heidenhain TNC 426 in 2006
Table size 2200 x 3240 mm
Table load max. 14 t
Table longitudinal travel X 3000 mm
Main spindle cross travel Y 2180 mm
G0xee227
Deep hole drilling support cross travel A - 2000 mm
Spindle vertical travel Z 500 mm
Distance between the columns 2750 mm;
Spindle to table 100 - 1300 mm;
Spindle...
2
The machine is in good technical condition, by prior arrangement the possibility of test drive. control - SIEMENS Sinumerik 802C max. stroke X 600 mm drilling length - 660 mm Y 400 mm spindle speed - 6000 rpm Z 1.000 mm mounting - SK 40 W 250 mm
W9b9xxyo
9
Single column coordinate boring machine make WMW Mikromat type BKoE 400 x 630/1
Czcqczam
machine # 1203.14.44
for single-part, small-part and medium-part production of high-quality gauges, fixtures
tools and workpieces with tight tolerance requirements
Technical data:
Table size 630 x 400 mm
table feeds 63 / 160 / 400 / 1000 mm/min
19 spindle speeds 45 - 2800 rpm.
spindle feed 0,014 - 0,5 mm/rev.
headstock feed 0,006 - 0,22 mm/rev.
drilling spindle stroke 100 mm
spindle diameter 80 mm
tool holde...
14
Jig boring machine  / Coö rdinate jig boring machine / milling machine
Manufacturer:  C. Matheys
Type: 35-NC
8v3yixo
Travel: 500x300x300mm
Boring depth: 140mm
Table:  870x300mm
12
Catalog No. : 5530
Type: HYDROPTIC-7
Producer: SIP
Made in: GO 2021
Characteristic:
Length of the working table: 1570 mm
Width of the working table: 1024 mm
Maximum table load (evenly distributed): 2000 kg
Minimum rotary speed of the spindle: 40 1/min
Maximum rotary speed of the spindle: 2000 1/min
X-Axis travels: 1400 mm
Y-Axis travels: 1000 mm
Z-Axis travels: 300 mm
W-Axis travels: 900 mm
Taper: MORSE 4
Spindle diameter: 135 mm
Passage under drill spindle: 365-1265 mm
Table adjust...
1
CNC jig drilling / milling machine
SMA-REF-6424
Type: table type boring mills
Manufacturer: Fehlmann
Model: Picomax 100 CNC
Year: 1984
Spindle:
50 - 7.100 rpm
5 kW
SF 32
No8al
Working range:
X: 850 mm
Y: 435 mm
Z: 210 mm
W: 590 mm
Table: 1.570 x 500 mm
Features:
Control: Heidenhain
Condition:
ready for action
under power
Location: Western Germany
Dimensions: Weight: 3 tons
Availability: on demand
Terms of delivery: ex works
Terms of payment: 100% before dismantling/loading
12
Double Column CNC Jig Boring Machine / Cordinate Drilling Machine
Oerlikon KB5
Year 1970
With CNC Point-to-Point Controller Heidenhain TNC 124
Table size 2000 x 1300 mm
X 2000 mm
Y 1363 mm
Z 330 mm
W 1130 mm
Delivery includes BOXES AND BOXES OF TOOLING - HUGE VALUE !
B0uejj0vel
Machine is running in a factory and can be inspected under power.
Proposal Number V(B)-6210
5
Coordinate drilling machine, manufacturer: SIP / HAUSER, type: MP 52, year of construction: 1981, control: Heidenhaim Heroes 4.19, travel: (X-axis) 900mm x (Y-axis) 600mm x (Z-axis) 600mm, connection: 50 Hz 3x 380 Volt, table length: approx. 1.000 mm, table width: approx. 800 mm, machine weight: approx. 6.000 kg
Yuuomo
5
2630
CNC Lehrenbohrwerk
0koswd
BURKHARDT&WEBER, HYOP 120 NCW
Bauj. 1979,----Ueberholung in 2000-----
Steuerung Heidenhain TNC 426 PB
Arb.-Ber.: 1250 x 630 x 560 mm
Antriebsleistung: 44 kW
Zubehoer:
Starrtisch 1200 x 710, Zusatztischplatte Hoehe 200 mm,
36-fach Werkzeugwechsler, Kuehlmitteleinrichtung.
- der abgebildete Zusatz- / Magnetspanntisch gehoert nicht zum Lieferumfang ! -
Spindel ISO 50, Drehzahlbereich 30-3000 min-1
max. Drehmoment 522 Nm
Vorschuebe 3-2000 mm, Eilgang 10 m/min
ma...
5
>> Condition very good!
>> Speed: 45 - 4000 rpm.
>> Fehlmann cross table: 380 x 750 mm
>> XYZ: 420/300/500 mm
>> Motorized height adjustment of the drilling head
Htw8pwlc8
5
Catalog No. : 5366
Type: BLZ 750/110
Producer: WMW
Made in: 1979
Characteristic:
Length of the working table: 1200 mm
Bt8artf8fx
Width of the working table: 900 mm
2016: DRO of X / Y / Z axes
CNC drilling machine with X-Y coordinates cross table
and automatically controlled feed
Manufacturer: IXION
Type: PC 2-8 with drilling head BS 30 AVST(G)
Year of manufacture: 1998
tool holder: MK4
max. motor power: 2,3 kw
max. drilling diameter: 35mm
Lmmlte8v
max. tapping diameter: M30
spindle speed: 80-1400/160-2800 rpm
table size: 1040mm X 380mm
working stroke:: X 600mm; Y 320mm
quill stroke: 150mm
throat depth:
Spindle-table distance: 85-750mm
Workpiece weight: max 200kg
Max workpiece height:...
5
Control: Heidenhain TNC 360 (1992)
Table size: 1000 x 1000 mm
Table size with front extension: 1345 x 1000 mm
Table load max.: 2000 kg
Distance spindle centre to column min/max.: 270 ~ 1270 mm
Distance spindle nose to table min/max.: 0 – 1100 mm
Distance between the upright columns: 1855 mm
Table longitudinal travel : 1400 mm
Boring ram carriage cross travel: 900 mm
Crossrail vertical travel: 850 mm
Boring spindle travel: 370 mm
Spindle motor rating: 6 KW
Spindle speed range:...
4
High precision drilling and milling machine
Fehlmann model Picomax 51 CNC 2 control Heidenhain
good condition, daily in use
Technical data:
>> year of manufacture: 1989 machine no. 13089298
Hkjgv8uio
>> travel X/Y/Z 420/ 240/ 120 mm
>> travel W 450 mm
>> Clamping surface (L x W) 730 x 280 mm
>> Quick tool change system SF 32
>> speed range infinitely variable 9000 rpm
>> drive power 3.7 kW
>> Space requirement approx.(W x D x H) 2.0 x 1.5 x 2.4 m
Can be inspected under power. Handwheel needs to ...
15
The machine is complete and operational. Lot of equipment.
Hrdnl233u
8
Control FAGOR
C0pgn09
tool holder ISO 50
Axles XYZW 1550/1000/400/850 mm
Table 1570/1180 mm
The distance from the spindle to the table 100 to 1150 mm
Passage between columns 1700 mm
Table load 4000 kg
Spindle speed 11-2240 U / min (24 degrees)
Spindle power 7.5 kW
XY axis feed 1-1000 mm / min (17 degrees), the Z-axis 0.018 to 3.15 mm / rev
Quick run 5 m / min (1.25 m / min - axis)
Power consumption 20 kVA
Machine weight 12000 kg (with a control panel)
5
Catalog No. : 5567
Type: VXR 50 CNC
Producer: MAS
Made in: 1991, GO 2017
Characteristic:
Control system: NS632A
Length of the working table: 830 mm
Width of the working table: 500 mm
Maximum table load (evenly distributed): 500 kg
X-Axis travels: 1000 mm
Y-Axis travels: 450 mm
Z-Axis travels: 450 mm
Machine length: 3050 mm
Machine width: 2500 mm
Bx8eccjdzn
Machine weight: 6 t
Equipment:
Chuck
Inserts
6
Manufacturing origin Swiss
Voltage 380/50/3
Netweight abt. 760 kg
Dimensions abt. 1250x1000x1700 mm
TECHNICAL DATA
WORK CAPACITY
Travel X and Y 200x200 mm
Vertical slide travel 250 mm
Travel of drilling spindle 70 mm
Max free passage between table and spindle nose 330 mm
Free passage between column and centre of spindle 260 mm
Max drilling capacity (steel) 10 mm
Max reaming capacity 50 mm
TABLE
Usable surface 400x300 mm
Ju28fi
Admitted load 100 kg
Travels X and Y through motors
Number of ...
4
Good working Coordinate drilling machine
Hgoyclrj
3
Coordinate drilling rig KBA40 // 15000
Bs3vrcngbn
BJ2017 // approx. 800 operating hours.
Equipment : Tool changer 10-fold, minimum quantity lubrication spindle fed through, cooling lubricant supply, vices 8 pcs. pneumatic, software, 15 inch monitor.
The machine is set up and commissioned by us!
Additionally it will be checked before delivery.
If you have any questions, please do not hesitate to contact us.
14
Henri Hauser M5 DR jig boring machine
spindle diameter 90 mm
x-travel 700 mm
y-travel 500 mm
Drilling capacity in steel 40 mm
spindle mounting MK 4
drilling spindle stroke 170 mm
number of spindle revolutions 2
infinitely variable 10-2000 rpm
Boring diameter max. 230 mm
Table dimension - longitudinal 900 mm
Table dimension - crosswise 770 mm
Vertical travel of cross beam 630 mm
Drilling spindle 6 pieces
from/to 0.02-0..20 rpm
Clearance between uprights 900 mm
Passage between spindle and table 81...
14
CNC vertical jig boring machine WMW MIKROMAT
Travel X: 1120 mm
Travel Y: 710 mm
Spindle travel Z: 315 mm
Travel W: 630 mm
Numerical Command: CNC NUM 1060
Spindle: Ø 125 mm
Cone: SA40
Rotation: from 36 to 2240 RPM
Bbgktihm
Table size: 1400 x 900 mm
Distance between colums: 1080 mm
Maxi distance spindle nose/table: from 0 to 900 mm max
Maxi eligible load on table: 1000 kg max
Separate electrical panel
Machine renewed in 2000 with CN NUM1060
Voltage: 380 V
Dimensions (L x W x H): 4000 x 2460 x 3030...
8
Catalog No. : 5569
Type: WKV 100
Producer: MAS
Made in: 1966
Characteristic:
Length of the working table: 1600 mm
Width of the working table: 1000 mm
B8ua0r7e3u
Maximum table load (evenly distributed): 2000 kg
Power of the spindle drive: 4 kW
Machine height: 3312 mm
Machine length: 4030 mm
Machine width: 3130 mm
Machine weight: 16 t
Equipment:
Turntable
DRO NEWALL
Tools
Folding table
2
jig boring machine Burkhardt HYPO 65 , year 1962
Travel : XYZ 700 x 500 x 400 mm
New glass scales Brigel and digital display 0,001 ( 2018 )
Various accessories
Bvni07hn3e
3
function not known
Hwslm7xl
1
Efficient drilling and milling in the trade.
We would be pleased to present our CNC controlled drilling machine KBA 40 to you in our company and invite you to be advised.
Bufzeenrd0
We look forward to hearing from you.
15
Jig boring machine DIXI type 75 ON
Travel X: 780 mm
Buuvjyttvt
Travel Y: 680 mm
Travel Z: 430 mm
Travel W Spindle exit: 750 mm
Rotary table 870 x 700 mm
Scale: HEIDENHAIN 4 axes
Delivered with several tools
Separate electrical panel
Voltage: 380 V
Dimensions (L x W x H): 4200 x 2300 x 2475 mm
Weight: approx 10 T.
