Grinding machines offers
+++ This auction is held in cooperation with a long-time Maschinensucher dealer. +++
General:
Control: Siemens - Sinumerik 802D
Control type: CNC
year of construction: 2005 modernized, original year of construction: 1982
Cai8zdwa3t
Working range:
Grinding diameter: 500 mm
grinding length: 2.750 mm
grinding wheel diameter: 750 mm
grinding wheel thickness: 120 mm
Workpiece weight: Max. 2.500 kg
Center distances (grinding lengths): 1,000 - 6,000 mm
Schneeberger Corvus BBA-1100 6-Axis CNC Broach Grinder. Fanuc 160i MA CNC. Indexing Work Head and Mag Chuck FG Flat & Spiral Broaches. 110 mm- X Travel. Well Equipped. 2003.
SPECIFICATIONS:
CNC Axis Travels :
X-Axis (Longitudinal) 43.30” (1100 mm)
Yuzmag
Y-Axis (Traverse) 11.80” (300 mm)
Z-Axis (Vertical) 11.80” (300 mm)
A-Axis (Tool Carrier) 360°
B-Axis (Rotation of Grinding Head) 210°
C-Axis (Rotation of Grinding Head) 320°
Grinding Head :
Twin Motor Spindle for Up 6 Grinding Wheels
...
1
273A HEALD UNIVERSAL INTERNAL GRINDER
FULLY REMANUFACTURED
STANDARD CATALOG SPECIFICATIONS
Maximum swing over table..... 558mm
Swing work head swiveled..... 90 degrees – 305mm
Swing inside standard chuck guard..... 558mm
Angular adjustment of work head..... 90 degrees
Work head cross slide travel..... 444.5mm
Maximum table travel..... 508mm
Grinding stroke maximum..... 406.4mm
Wheel head cross slide travel..... 38mm
Center of work head spindle to floor..... 1105mm
Diameter of work head spindle ...
SPECIFICATIONS:
Cone Distance Max (30" Spiral Angle & 7-1/2" Cutter) 4-1/4"
Gear Pitch Diameter Max 10 to 1
10 to 1 Ratio 8 - 1/2"
2 to 1 Ratio 7 - 1/2"
1 to 1 Ratio 6"
Diametral Pitch (Coarsest) 4
Full Depth Max .625"
Face Width Max 1 - 1/4"
Number of Teeth 5 to 150
WORK SPINDLE :
Diameter of Taper Hole at Large End 3 - 29/32"
Taper per Foot 89/64"
Depth of Taper 6"
Cavdev7mdx
Diameter of Hole Through Spindle 2 - 7/16"
Diameter of Spindle Nose 5 - 11/82"
Cutter Diameter 3 - 1/2",...
1
GCH "NEW" CYLINDRICAL UNIVERSAL GRINDER
356mm x 914mm
Standard catalog specifications
Swivel range (lower swivel, right & left)..... 90 degrees
(upper swivel, right & left)..... 30 degrees
Grinding wheel (dia. x face x hole) …………..... 14" x 1 1/2" x 5"
Cross feed
Automatic infeed at table reversal:
Diameter reduction..... (low)..... .0002" to .005"
(high)..... .0005" to .0125"
Wheelhead movement per turn of cross feed:
Hand wheel..... (low)..... .050"
(h...
Bryant Center Hole Grinder. Self-Centering Vise. Tailstock. Dresser. 42” Centers. -1974
SPECIFICATIONS:
Workpiece Length Standard Range Machine 2" - 42"
Clearance from Tailstock Center to Column 6.2"
Vise Capacity (Standard Jaws) .060" - 6"
Cone Angle of Center Holes Ground 60 Deg.
Max Center Hole Ground 2"
Minimum Center Hole Ground (Large End) .050
Grinding Spindle Speeds (with Pulley Change) 13000/21500/45000 RPM
Planetary Drive Speed 330 RPM
Angular Grinding Stroke .005" - .100"
Wh...
6
STUDER INTERNALCYLINDRICAL GRINDER WITH
INTERPOLATING B-AXIS
Excellent Condition!
Equipped with 2x 60000 rpm and 2x 90000 rpm ID spindles. In process measuring probe. Drop down rotary disk dresser. Sensitron contact detection system. This machine has been used with oil coolant only and looks almost new. There is an Ebbco Evolution coolant system as well to go with this special machine.
Dapa2rt
Detail length max. 300 mm
Grinding length max. 150 mm
Height of the centers over a table 150 mm
Spind...
12
SPECIFICATIONS:
Swing over Table 400mm (15.75")
Distance between Centers 630mm (24.80")
Wheelhead Feeding Angle to Workpiece Center 90 Degree
Max. Grinding Dia. 300mm (11.84")
Max. Load between Centers 300 kg (661 lbs)
GRINDING WHEEL:
Outside Dia x Inside Dia. 760mm x 304.8mm (30" x 12")
Max. Width using current tooling 100mm(3.93")
Spindle Speed 1505 RPM
WHEELHEAD:
Full Stroke 407mm (16.02")
Rapid feedrate (dia.) 15,000 mm/min (591 IPM)
Cw78xwow
Least input increment (dia.) 0.0001mm
TABLE:
Stro...
2
SDG6-42 GARDNER HORIZONTAL SPINDLE DOUBLE OPPOSED DISC GRINDER
REMANUFACTURED & UPGRADED IN 2016
CE APPROVED
SIEMENS CNC CONTROLS
S/N DD 898-87
Cos0j9x
STANDARD SPECIFICATIONS
Grinding wheel capacity……………. 1067mm
(2) 50 H.P. Spindle motors.
Siemens Sinumerik CNC controls.
Rapid and incremental feeds.
550 RPM Auto cycle.
Rapid retract.
Motorized swing arm dresser (with automatic dress cycle) .
Variable speed carrier.
Coolant thru spindles.
Power hood lifter.
Trabon lubrication system.
Free...
Supertec STC-12 Centerless Grinder. 5.5” Wheel. 2” Dia. 5 HP. Hydraulic Dressers. – 1981 (2)
SPECIFICATIONS:
Max. Work Diameter (with Standard Workrest) 1-30mm (0.04”-1.18”)
Max. Work Diameter (with Special Workrest) 30-50mm (1.18”-2”)
Infeed Grinding Range 2-30mm (0.08”-1.18”)
Grinding Wheel :
Size (Dia x Width x Bore) 305x140x127mm (12”x5.51”x5”)
Spindle Speeds 1,900 rpm
Feed of Dressing Handwheel per Graduation 0.02mm (0.05”)
Feed of Dressing Handwheel per Revolution 2mm (0.05”)
Regu...
3
SDG6-42 GARDNER HORIZONTAL SPINDLE DOUBLE OPPOSED DISC GRINDER
TOOLED FOR CONNECTING RODS
REBUILT IN 2015
CE APPROVED
SIEMENS CNC CONTROLS
S/N DD 898-89
STANDARD SPECIFICATIONS
Grinding wheel capacity……………. 1067mm
Servo driven reciprocating "Connecting Rod" carrier.
(2) 50 H.P. Siemens spindle motors.
Rapid and incremental feeds.
Auto cycle.
Rapid retract.
Motorized swing arm dresser.
Variable speed carrier.
Coolant thru spindles.
AC powered hood lifter.
Vogel lubrication system.
Free st...
3
SHIGIYA GU-30B-60A CYLINDRICAL GRINDING MACHINE
B9o8gxl9o8
S/N 080198
SPECIFICATIONS
CAPACITY
Swing Over Table Diameter..... 410mm
Max Grinding Diameter..... 400mm
Distance Between Centers..... 600mm
Max Workpiece Mass……………..150 KG.
WHEELHEAD
Swivel Angle..... + / - 30 Degrees
Wheel Size..... 355mm x 32mm x 152.4mm
Wheel Speed..... 33m / sec
Total Travel..... 284mm
Rapid Feed Travel..... 40mm
WORKHEAD
Work Spindle..... Swivel, Dead / Live Spindle
Rotation Speed..... 60 HZ
Center Hole...
1
SHIGIYA GPA-20-50 CYLINDRICAL GRINDING MACHINE
S/N 20132
SPECIFICATIONS
CAPACITY
Swing Over Table 200mm
Max Grinding Diameter 200mm
Distance Between Centers 500mm
Max Workpiece Mass……………..20 KG.
WHEELHEAD
Swivel Angle + / - 30 Degrees
Wheel Size 305mm x 25mm x 127mm
Wheel Speed 33m / sec
Total Travel 185mm
Rapid Feed Travel 20mm
I3wcljw3k
WORKHEAD
Work Spindle Live & Dead
Rotation Speed 60 HZ
Center Hole Taper……………MT. No. 2
TAILSTOCK
Type…………….Manual Lever
Spindle Stroke………...
1
#2 OM CINCINNATI CENTERLESS GRINDER
REBUILT
STANDARD CATALOG SPECIFICATIONS
Wbcbzm0z
CAPACITY
(Depending on which work rest is ordered, not included in price)
Standard work rest..... 2mm to 89mm dia.
Low thru feed work rest..... 51mm to 121mm dia.
Bar work..... 3mm to 51mm dia. 457mm long
GRINDING WHEEL (Not supplied)
Width..... 102mm, 152mm, or 203mm Hole..... 305mm
Maximum diameter..... 508mm
Minimum diameter..... 356mm
REGULATING WHEEL (Not supplied)
Width..... 102mm, 152mm, or 203mm ...
1
SEIKO SEIKI SCG15 CNC EXTERNAL GRINDER
S/N 280 Year: 1999
STANDARD SPECIFICATIONS
Distance between centers……………..….. 150mm
Center height from the floor level...…………….. 1000mm
Swing over table…………… 240mm
Grinding wheel head:
Maximum stroke……………... 120mm
Infeed rate……………. 0.0001 – 50mm/min
Manual feed pulse handle (per one rotation)…………… 0.01 x 1mm
Manual feed pulse handle (per one scale)…………… 0.001 x 1mm
Switcher of x1, x10, x50 magnification
Grinding wheel:
Size of grinding……………. ϕ355 x...
1
# 18 ABRASIVE ROTARY FACE GRINDER
STANDARD SPECIFICATIONS
Type
Face Grinder, Hand Feeds.
Work Table
Work surface…………….....…. 330mm x 914mm
4 T-slots…………….…. 14mm
Spaced…………….…… 84mm
Spindle
Extra heavy, ball bearing, motorized…..…15 H.P., 900 RPM heavy duty motor
Wheels
Segmental……………... Solid wheel 457mm O.D.
Optional segmented chuck ring can be quoted.
Feeds
All movements by hand feed only.
Traverse……………..………… 76mm
Vertical……………..……….... 127mm
Longitudinal……………..……… 610mm when using m...
1
DISKUS-WERKE DDS 600 III CRA VERTICAL DISC GRINDER
S/N 7477 Year: 1980
STANDARD CATALOG SPECIFICATIONS
Grinding wheels diameter.....23.6”.....600mm
Grinding wheels height x width 2.9” x 5.9”.....75 x 150mm
B9lvkmr9xa
WORK PIECE DIMENSIONS:
Grinding height x grinding with....1.96” x 4.7”....50 x 120mm
Vertical adjustment of each grinding head 5.9”.....150mm
Hydraulic infeed impulse.....0.001- 0.02mm
External diameter of work piece carrier disc.....31.4” - 800mm
Feeds of rotary work piece ...
2
12" X 39" TOYODA SELECT G100-II CNC CYLINDRICAL GRINDER
Specifications
MODEL ..... SELECT G100-II
YEAR ..... 2007
SWING ..... 12.6"
DISTANCE BETWEEN CENTERS ..... 39.4"
MAX GRINDING DIAMETER ..... 11.8"
MAX LOAD BETWEEN CENTERS ..... 330 LBS
CENTERLINE HEIGHT FROM FLOOR ..... 42.5"
WHEELHEAD:
WHEEL SIZE (OD X ID) ..... 20" X 8"
WHEEL USE RANGE (30° CONFIGURATION ..... 20" TO 14.96"
MAX WHEEL WIDTH ..... 3.9"
WHEEL SURFACE SPEED ..... 8,500 SFPM
SPINDLE..... TOYODA STAT BEARING
MIN MOVE INCREMEN...
1
BUTLER NEWALL LANDING GEAR GRINDER
STANDARD SPECIFICATIONS
CAPACITY
Swing Over Table…………….……………36”
Swing In Gap……………120”
Distance Between Centers:
Gap Open……………144”
Gap Closed……………..90”
Wheelhead Carriage Travel……………76”
Wheelhead Swivel:
Towards The Workhead……………..+12 Degrees
Away From The Workhead…………….-6 Degrees
GRINDING WHEELHEAD
Grinding Wheel (Dia. X Face x Bore)…………….36”x 3”x 12”
Spindle Speed (Variable 4000 – 8000ft / min)………500 – 1500 RPM
HEADSTOCK
Number Of Speed...
1
406mm x 813mm WELDON CNC PLAIN CYLINDRICAL GRINDER
Model 1632
S/N 653 Year: 1983
STANDARD SPECIFICATIONS
Swing over table – maximum……………. 406mm
Grinding diameter, maximum (with new 14” wheel)………. 406mm
Grinding length, maximum (work length)…………….. 660mm
Wheel slide angle…………….....…………… 90˚
Grinding wheel, maximum diameter (with new wheel)………. 356mm
Grinding wheel, maximum width……………... 76mm
Grinding wheel, hole diameter……………... 127mm
Table rapid traverse rate……………. 100 IPM
Table feed rates...
1
OKUMA GP-35N 2-AXIS CNC CYLINDRICAL GRINDER
S/N 0395 Year: 1994
STANDARD SPECIFICATIONS
Distance between centers……………. 350.012mm
Swing over table…………….. 304.8mm
Maximum diameter of work to be ground……………... 304.8mm
Maximum work weight between centers……………. 98 lbs.
Grinding wheel dimensions……………. 609mm x 124mm x 304.8mm
Controls: Okuma 5020 OPS.
Single point dresser mounted on head stock.
Servo controlled infeed, table traverse and work head.
Showa automatic lube system.
Hydraulic tail sto...
1
OKUMA GP-24N CNC CYLINDRICAL GRINDER
S/N 020-0218 Year: 1989
STANDARD SPECIFICATIONS
Distance between centers……………. 350mm
Swing over table…………… 230mm
Maximum diameter of work to be ground…………….... 105mm
Maximum grinding wheel width…………….. 50mm
Maximum work weight (between centers)……………... 25 KG-F
Maximum work weight (on live spindle)……………. 20 KG-F
Grinding Wheel
Grinding wheel dimensions……… 405mm 50mm x width x 127mm
Grinding wheel spindle speeds……………. 2120 – 2600 RPM
Number of wheel spin...
1
STUDER S31 LEAN CNC UNIVERSAL CYLINDRICAL GRINDER
B9lveejjsl
S/N 310066
STANDARD SPECIFICATIONS
Internal Grinding Attachment……………..Yes
Wheelhead……………Full B – Axis
(2) OD Wheels – Size……………..508mm x 76mm & 406mm x 76mm
Swing…………….....……………...356mm
Center Height……………...175mm
Center Distance……………650mm
Max Workpiece Weight……………...80 KG
X-Axis Travel……………...…………...254mm
Z-Axis Travel……………...…………800mm
EQUIPPED WITH
Full B Axis.
No ID attachment.
Rebuild / Retrofit control.
Parts drawing.
Stock remov...
1
ESTARTA CENTERLESS GRINDER
Model 310
S/N Stock 6738
STANDARD SPECIFICATIONS
CAPACITY
Maximum grinding diameter……………... 2mm to 51mm
Maximum infeed grinding length……………... 127mm
Grinding wheel (dia. x width x bore)…mm x 178mm W x 127mm B
Spindle speed…………….…...……….. 1,900 RPM
Grinding wheel motor…………….……………. 10 H.P.
Regulating wheel (dia. x width x bore)…03mm x 127mm x 127mm
Regulating wheel speeds (4 speeds)…...…………. 22 to 335 RPM
Approximate machine weight………...………….. 1542 kg
Approximate...
14R LANDIS CENTERLESS GRINDER
S/N 863-56
STANDARD SPECIFICATIONS
WORK CAPACITY (DIAMETER)
Regular thru feed and infeed work rests..... 12.7mm to 101mm
Heavy duty thru feed and infeed work rests..... 50mm to 152mm
Bar grinding work rests..... 203mm max.
WHEELS
Grinding wheel, 304mm hole..... 25mm to 355mm widths
508mm max. dia.
355mm min. dia.
Regulating wheel, 127mm hole..... 25mm to 355mm widths
355mm max. dia.
228mm min. dia.
MOTORS
Grinding wheel drive motor, tota...
1
K.O. LEE SILVER EAGLE MODEL 660 CNC UNIVERSAL GRINDER
S/N C660L2
STANDARD SPECIFICATIONS
Work Capacity:
Distance between centers……………. 660mm
Wheel head rotation……………. +/- 30˚
Swing over table…………….. 360mm
Maximum weight - between centers……………. 160 kg
- on work head……………. 82 kg
Work Head:
Swivel…………… 135˚ (90˚ CCW/45˚ CW)
Speed (variable)...…………….. 30 to 600 RPM
Through hole…………….. 33mm
Center taper…………… 5 MT
Pilot diameter x length…………… 110mm diameter x 5mm
Tail Stock:
Center taper………...
1
TRIPET TST 201 CNC HIGH PRECISION INTERNAL GRINDER
S/N 4950-21-201
TECHNICAL DATA
Grinding diameter range (production)………… 3 – 150mm (12" – 6")
(on request up to diameter 225mm – 8.9")
Grinding length…………….. 200mm (7.9")
Center height above table…………….. 162mm (6.3")
Max. table travel…………… 480mm (18.9")
Work head angular setting……………. + 45˚ to 30˚
Work head spindle bore diameter…………….. 40mm (1.57")
Max. weight on spindle nose……………. Approx. 50 kg (110 lbs.)
(on request up to 100 kg – 220 lbs).
W...
1
DANOBAT RCP1-1200 CNC INTERNAL GRINDER
S/N 2181 Year: 2000
STANDARD SPECIFICATIONS
General
I.D. travel approximately…………….. 1000mm
Centers height…………… 172mm
Swing over table…………… 345mm
Wheel Head Feed (X-Axis)
Total traverse travel……………. 275mm
Maximum speed to program…………… 15000 mm/min
Minimum speed to program……………. 0.01 mm/min
Minimum increment to program…………….. 0.005mm
Wheel
Maximum dimensions……………. 60 x 25 x 20mm
Wheel Head Cross Fed (Z-Axis)
Total tracerse travel……………... 1380mm
Maxi...
1
356mm X 610mm KELLENBERGER MODEL 600 U
UNIVERSAL CYLINDRICAL GRINDER
STANDARD SPECIFICATIONS
356mm Actual swing over table
610mm distance between centers
TABLE
900mm Maximum travel of table
11 Degrees maximum swivel
WHEELSLIDE
284mm Maximum travel
40mm Forward & reverse rapid wheel slide
WHEELHEAD
399mm O.D. x 48mm width x 127mm bore
1500, 1700, 2200 R.P.M. spindle speeds
WORKHEAD
360 degree swivel
20-400 R.P.M. speeds infinitely variable
5 Internal taper of spindle morse
MOTORS
4 H.P. 3...
1
R-57 CINCINNATI UNIVERSAL CYLINDRICAL GRINDER
STANDARD SPECIFICATIONS
Capacity
Maximum grinding length……………..……. 439mm
Maximum distance between centers……………..….. 445mm
Height of centers……………..…. 127mm
Maximum swing diameter…………….... 254mm
Maximum diameter machine will grind with full size wheel… 152mm
Minimum diameter machine will grind with worn wheel………..….. 0
Maximum weight of work between centers (without steady rest) 25kg
Maximum weight of work held in chuck……………..... 15 kg
Table
Table t...
1
254mm x 787mm R75 CINCINNATI UNIVERSAL CYLINDRICAL GRINDER
STANDARD SPECIFICATIONS
Swing over table……………. 254mm
Distance between centers…………… 787mm
Table
Maximum table travel…………….. 787mm
Infinitely variable traverse speeds…………… 50.8mm - 6096mm
Table traverse per rev. of hand wheel…………….. 2.54mm & 12.7mm
Infinitely variable table tarry…………… 0 to 6 sec.
Maximum swivel of table (+/-)…………… 10 deg.
Head Stock
Infinitely variable spindle speeds……………. 60 to 480 RPM
Ivp2g9ux0
Swivel range……………. 0-90...
1
1311 JONES & SHIPMAN UNIVERSAL CYLINDRICAL GRINDER
STANDARD SPECIFICATIONS
Swing over table…………… 250mm
Distance between centers …….…...….……………. 460mm
Table swivels……………..19 Degrees Total
Table traverse speed……………75-3650mm/min
WHEEL HEAD
Traverse……………205mm
B9hxbgj9pi
Swivel……………...360 Degrees
Wheel……………305x25x127mm
Speeds……………1670 and 2200 RPM
Motor…………….3.75 Kw
WORK HEAD
Speed……………..Various
Capabilities…………….Live/Dead
Swivel………15 Degrees Clock Wise & 90 Degrees Anti-Clock Wise
EQUIPED WITH
...
2
STUDER RHU 400 UNIVERSAL GRINDER
S/N 776.51
STANDARD SPECIFICATIONS
CAPACITY
Centre Height…..……………127mm
Distance Between Centres……………..406mm Longitudinal Travel……………..……..432mm max
Swing……………..254mm
Workpiece Weight……………..80 kgs
TABLE
Table Size……………...914mm L x 152mm W
Table Speed (Infinitely Adjustable)……………....0.17 – 18.33 FPM
Dwell At Table Reversal…………….0 – 6 Seconds
Table Swivel……………...12 Degrees max
Travel Per Handwheel Revolution……………..25mm
WORKHEAD
Swivel Towards Grinding Wheel…...
1
STUDER RHU 1000 UNIVERSAL GRINDER
S/N 32.28
STANDARD SPECIFICATIONS
Capacity
Heights of centers…………… 125mm
Distance between centers…………… 1000mm
Maximum table swivel…………… 8°
Work Head
Swivel towards wheel……………. 90°
Spindle speed, steplessly variable…….. 30-675 U/min t/min RPM
Spindle nose taper…………….. Morse 5
Wheel Head
Grinding wheel:
Diameter…………….. 400mm
Maximum width…………….. 50mm
B9hw20u0gw
Grinding wheel motor……………. 3 (6.25) kW
EQUIPMENT & FEATURES
Tail stock dresser.
Hydraulic tail sto...
4
EJ 29 Silver is a multi-functional cylindrical grinding machine for manufacturing single components and batch lots. This machine type covers a wide range of grinding applications. Designed for complex applications that require a high level of workmanship. Software on the CNC control system, FANUC 21i, offers simple operation and programming. It offers large-scale digital axis drives and a precise absolute measuring system in all CNC axes. Separate electronic hand wheels for the X- and Z-axis all...
1
MICRON MD450-RDT-CNC CENTERLESS GRINDER
S/N 4819 Year: 1999
STANDARD SPECIFICATIONS
EQUIPMENT & FEATURES
Fanuc 180-T controller.
GWD – Servo w/ Diamond roll.
RWD – Manual Comp w/ AC traverse.
Servo transmission.
Dual servo infeed.
Loader assembly.
Bunsi filtration unit w/ 211 GPM chiller.
Hydraulic tank.
Dzbylu
MICRON MD-600III4W CENTERLESS GRINDER
Kjryivoz
S/N 4488 Year: 1997
EQUIPMENT & FEATURES
Fanuc Powermate controller.
GWD – Servo w/ Diamond roll.
RWD – Manual Comp w/ AC traverse.
Servo transmission.
Dual servo infeed.
Bunsi filtration unit w/ 211 GPM chiller.
Hydraulic tank.
4
203mm VIKING CNC 200 CENTERLESS GRINDER
S/N 9168A0196-0033 New: 1996
STANDARD SPECIFICATIONS
Work Capacity
Maximum work piece diameter……………. 64mm
Minimum work piece diameter……………. 1.3mm
Grinding Wheel
Maximum new wheel diameter……………. 547mm
Minimum worn wheel diameter with 16” wheel…………….. 270mm
Maximum wheel width……………. 205mm
Wheel mounting hole diameter……………. 203mm
Type of support…………….. Twin Grip, removable spindle
Type of bearing…………….. Anti-friction roller
Type of lubrication……………. Gr...
1
TECHNICA CENTER HOLE GRINDER
S/N 5100
STANDARD SPECIFICATIONS
Work piece length – standard range……………..…….. 50mm to 106mm
Clearance tail stock center to column……………..…… 157.48mm
Vise capacity (standard jaws)…………….…. 1.524mm to152.4mm
Maximum center hole ground (large end)……………..….. 50mm
Minimum center hole ground (large end)……………..…….. 1.27mm
Grinding spindle speeds…………….…. 13000 / 21500 / 45000 RPM
B889lr3lm0
Planetary drive speed……………..……. 330 RPM
Angular grinding stroke…………….……. 0.127m...
5
KELLENBERGER MODEL UR 175 x 1000
UNIVERSAL CNC CYLINDRICAL GRINDER
S/N 650093
STANDARD SPECIFICATIONS
CAPACITY
Distance between centers..... 1,000mm
Height of centers..... 175mm
Max swing over table..... 249mm
TABLE (Z-Axis)
Max travel..... 1,115mm
Feed rates..... . 000010 - .009990
Table feed..... .1 – 394
Jogging feeds..... .000100
Rapid traverse..... 10,008mm min
Dwell of reversal..... 0-99
Max swivel..... 9 degrees
WHEELSLIDE (X-Axis)
Max travel..... 270mm
Cont. infeed rates..... ....
3
GIUSTINA R242 HORIZONTAL DOUBLE DISC GRINDER
STANDARD SPECIFICATIONS
Grinding Wheel Diameter……………..915mm
Power……………..75 KW
Control……………CNC (Bosch)
Wheel Rotation Axis…………….....Horizontal
Grinding Wheel Size, Usable Width……………..65mm
B88kqsu3o3
Grinding Wheel Size, Peripheral Speed…………….30ms
Spindle Motors……………...75 KW
Grinding Feed Rate……………0.1 – 1000 mm/min
Spindle Type……………...Moving Quill
Angular Contact Spindle Bearings……………..ABEC-7 (ISO4)
Slide Position Accuracy……………..0.001mm
Coolant Flow Ra...
1
254mm x 508mm LANDIS 2SE CNC 30˚ ANGLE HEAD PLAIN GRINDER
STANDARD SPECIFICATIONS
Swing over table…………… 254mmmm
Distance between centers…………….. 508mm
Grinding wheel size…………… 610mm x 127mm x 305mm
Wheel speed…………….. 8500 SFPM
Head stock work speed……………. 30-600 RPM
Head stock spindle adaptor……………... 5-A2
Stroke of tail stock center……………. 102mm
Tail stock work center…………….. 4MT
Approximate weight…………….. 25,000 lbs.
EQUIPPED WITH
Heavy duty cast iron bed.
15 HP AC Grinding spindle w/Allen Bradle...
1
254mm x 508mm MODEL 2R LANDIS PLAIN TWO AXIS
ANGULAR WHEEL HEAD GRINDER
SPECIFICATIONS
254mm x 508mm Grinding capacity.
610mm x 76mm Wheel
FEATURES
Swivel table
Rotary diamond dresser
Wheel head slide - Servo driven with ball screw
MPC II-C Electronic Programmable Machine Control System
Live & dead head stock spindle - Multi speed servo driven
Hydraulic tail stock - 15 HP
Wheel drive
Carriage drive
B87c7v8qob
Work drive (Indramat DC Servo)
1
MITSUBISHI RA23 CNC ANGLE HEAD CYLINDRICAL GRINDER
S/N GKO-72
STANDARD SPECIFICATIONS
Machining Capacity
Wheel slide - swing…………… 231mm
- Center distance……………. 351mm
Maximum work diameter…………… 150mm
Maximum work weight…………….. 80 kg.
Grinding Wheel
Outside diameter…………… 404mm
Inside diameter X width……………. 127mm x 51mm
Peripheral speed……………. 148 ft/s
Bil002a8
Rotational speed……………. 2,122 RPM
Wheel Slide
Rapid speed……………. 42.7 ft/s
Infeed rate……………0.002-249mm min.
Least unit……………......
1
MYFORD MG12 PLAIN CYLINDRICAL GRINDER
S/N: S53000
Specifications
MAXIMUM GRINDING DIAMETER ..... 76mm
Ddokpon
SWING OVER TABLE ..... 127mm
MAXIMUM TABLE TRAVEL ..... 349mm
CAPACITY BETWEEN CENTERS ..... 305mm
TABLE SWIVELS EITHER WAY ..... 7 DEGREES
TABLE TRAVEL PER REVOLUTION OF HANDWHEEL ... 52mm & 13mm
WHEELHEAD
TOTAL TRAVEL ..... 76mm
FINE FEED ADJUSTER (NUMBERED DIVISIONS) ..... 0.0001"
WHEEL SPEEDS (2) ..... 1830 & 1988 RPM
GRINDING WHEEL (RECESSED) ..... 305mm X 38mm X ...
1
SMTW PLAIN CYLNIDRICAL GRINDER
Cayvdfkk
Model M1332B/1000
STANDARD SPECIFICATIONS
Swing over table……………... 355mm
Distance between centers…………….. 1016mm
Grinding diameter - with steady rest – min./max…………….…… 10/60mm
- without steady rest – min./max…………….... 8/320mm
Max. upper work table swing angle clockwise……………. 3°
Max. longitudinal work table travel…………….. 1050mm
Wheel dimensions OD x W x ID – max…………… 600 x 75 x 305mm
- worn…………… 450 x 75 x 305mm
Wheel peripheral speed…………….. 35 m/s
Wheel ...
1
BAHMULLER ASP400 ATE PLAIN CYLINDRICAL GRINDER
Qd8wh
S/N 120116 Year: 1986
STANDARD SPECIFICATIONS
Nominal distance between centers……………. 400mm
Nominal center height…………… 125mm
Grinding wheel dimensions…………… 508mm x 1.01mm x 127mm
Wheel head support rapid motion…………….. 50mm
Wheel head support infeed electro-mechanically…………….. 19.99mm
Grinding wheel diameter……………500mm
Grinding wheel width maximum……………80mm/100mm
Maximum peripheral speed…………… 45 m/s
Grinding spindle drive power up to……………7....
1
STANDARD SPECIFICATIONS
Grinding capacity…………….…………… 3.0mm- 120mm
Grinding wheel size……………..…………… 610mm x 405mm
Grinding wheel dresser
Profile.
AC motor on traverse.
Manual diamond advance.
Regulating wheel dresser
Profile.
B80ftpy3e7
AC motor on traverse.
Manual diamond advance.
Equipment
Regulating wheel drive……………. AC Variable Frequency Drive
Servo compensation……………. Fanuc
Thrufeed work rest…………….. ………….16”
Allen Bradley controls.
Stand alone electrical panel.
50 HP Spindle motor.
1
KOYO KC-300A SLANT BED CNC CENTERLESS GRINDER
STANDARD SPECIFICATIONS
Grinding capacity…………….…………… 1.6mm- 120mm / .060" – 4.72"
Grinding wheel size……………..…………… 610mm x 305mm / 24" x 12"
Grinding wheel dresser……………..……………... 2 Axis with AC Stepper Motors
Ih8hif2i0
Regulating wheel dresser……………..……………... 2 Axis with AC Stepper Motors
Regulating wheel drive……………. AC Variable Frequency Drive
Servo compensation……………. Fanuc
Work rest…………….. 305mm / 12”
Machine Features
Fanuc OM CNC Controls.
Stan...
1
KOYO MODEL KC-200 CENTERLESS GRINDER
Grinding Capacity
Outer diameter (O.D.): 1.524mm – 119mm
Infeed work length: 299mm
Grinding Wheel
O.D. x width x bore diameter 609mm x 203mm x 304mm
Min. O.D. 469mm
Height (spindle center to floor) 1092mm
Regulating Wheel
O.D. x width x bore diameter 330mm x 203mm x 203mm
Min. O.D 279mm
Tilt adjustment 5
Motors
Grinding wheel 15 kW-4P 20 HP
Regulating wheel 1.5 kW-6P
Ifdnq7wae
EQUIPPED WITH
Wheel dressers
Thru feed work rest
Coolant system with filtrat...
