Used multi-spindle boring machines for sale (86)

Condition: ready for operation (used), Year of construction: 2012, product length (max.): 2,250 mm, This Hüttenhölscher Line multi-spindle drilling machine was manufactured in 2012. It features a PC-controlled function sequence under Windows 7 with TwinCAT, a 6-station loading gantry, and a 2-axis gantry robot. The machine includes a vacuum generation by ejector and multiple conveyor lines for efficient material handling. Ideal for high precision drilling with its advanced control system. Contact us for more information about this machine. • Control: PC-controlled function sequence under Windows 7, TwinCAT • Part dimensions: • Length: 300–2250 mm • Width: 350–710 mm • Thickness: 16–25 mm • 2-station drilling station: • Base frame as welded construction with machined screw-on surfaces • 2x toothed belt conveyors V = 1.5 m/sec • 2x pneumatic lift for toothed belt conveyors • 2x stoppers for cabinet parts, dampened by shock absorbers • 2x pneumatic double clamping cylinders, controlled by ball screw and servo motor, moved to side height (measuring the side height) • 2x pneumatic cross alignment ruler (plausibility check) • 2x vacuum clamping units in the drilling machine table • 2x 0-line controllable Bjdpfxeyctaus Ac Njcu • Support: • Support can be moved in the X direction by means of a servomotor • 2x drilling gear (support 1): • Support equipped with 2 units (machining from above) • Individually movable in Y direction by servomotor • Individually movable in Z direction by servomotor • Drilling gear a = 32 mm, adjustable with frequency converter, drill chuck Ø 10h7 with grub screw • Callable spindles, 8000 rpm • Two 16-spindle drilling gears • Groove saw (support 1): • Sawing units for cutting special rear wall grooves • Sawing unit with tool holder, speed control via frequency converter • Pneumatically pilot-controlled working position • 2x milling spindles right/left at the front edge (support 1): • Pneumatically pilot-controlled working position Additional equipment (automation, handling, guarding, conveyors) • Loading/handling: • 6-station loading gantry • 2-axis gantry robot; Y/Z axes with servo motors; travel distances: Y-axis 8500 mm, Z-axis 1500 mm • Suction crossbeam with four-circuit vacuum supply; vacuum generation by ejector • Double part detection • Portal supports • 4 stacking stations • 1 hand rest station (automatic/manual feeding) • 1 removal station (automatic/manual removal) • Side feed range: • Stack height: max. 1000 mm (60 parts) incl. protective plate • Protective plate sizes: • 1380 mm x 780 mm • 1220 mm x 720 mm • 1120 mm x 620 mm • 2290 mm x 620 mm • Thickness: 25 mm • Thickness: max. 28 kg • Floor roller conveyor / stack feed: • 4 roller conveyor lines, 930 mm wide x 3600 mm long, AH 300 mm • Feeding/removal: manual cross transfer carriage • Support stations / automatic feeding: • Transport section 950 mm wide x 4100 mm long; integrated side stop • Manual feeding: • Toothed belt section 900 mm wide x 2500 mm long • Transfer shuttle: • Toothed belt section 900 mm wide x 2500 mm long; horizontal stroke approx. 2500 mm by three-phase motor • Return: • Transport section 950 mm wide x 4000 mm long; pneumatic stopper • 90° rotary unit: • Vacuum suction cup; pneumatic stroke; rotation by three-phase motor by +/- 90° • Discharge stations / automatic removal: • Transport 950 mm wide x 3000 mm long; positioning of cabinet parts by encoder • Manual removal: • Toothed belt section 900 mm wide x 3000 mm long • Protective system for feeding: • 45 m protective fence with 3 access doors

Condition: ready for operation (used), Year of construction: 2010, This Biesse Techno Kernell was manufactured in 2010. A used multi-spindle drilling line with stacking system, it features infeed and automatic stacking units by Wamhoff. Ideal for efficient, high-volume drilling operations, this machine includes multiple drilling supports both from above and below. If you are looking to get high quality drilling capabilities consider the Biesse Techno Kernell machine we have for tact us for more information. Machine Benefits Technical Machine Benefits Bsdpfx Asyap Uvsc Nscu • Used drilling line with stacking system • Consisting of: infeed unit / throughfeed drilling machine / automatic stacking unit • Throughfeed drilling machine / 6 drilling supports from below / 4 drilling supports from above / throughfeed drilling machine / 5 drilling supports from below / 4 drilling supports from above • Note: the technical data and descriptions are taken from the order confirmation at the time. Data is for information purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 2010, This Hüttenhölscher Drilling rig was manufactured in 2010. It features a PC-controlled function sequence under Windows 7, TwinCAT, and a used drilling system with a 6-station loading gantry. The rig includes a 2-axis gantry robot, Y/Z axes with servo motors, and a travel distance of Y-axis 8500 mm, Z-axis 1500 mm. It also has a suction crossbeam with a four-circuit vacuum supply. Contact us for more information about this machine. Application Types Boring & Drilling (Wood) Bodsx Tkauspfx Ac Nocu

Condition: ready for operation (used), Year of construction: 2025, number of axes: 3, Main Drive Number of axis 3 This 3-axis QUICK CNC KQ-63E was manufactured in 2025. It's a multi-spindle drilling machine capable of handling workpieces from 70 to 2800 mm in length and 50 to 1220 mm in width. Features include top and bottom milling spindles, a high-speed tool changer, and brushless servo motors. If you are looking to get high-quality drilling capabilities, consider the QUICK CNC KQ-63E machine we have for sale. Contact us for more information. Bcjdpfx Asx D Dnkjc Nou Application Types Boring & Drilling (Wood)

Condition: ready for operation (used), Year of construction: 2025, This QUICK CNC KQ-62 Lite multi-spindle drilling machine was manufactured in 2025. It handles workpieces from 70 to 2400 mm in length, 9 to 60 mm in thickness, and 30 to 1220 mm in width. Features include a Higerman control system, dual 3.5 kW milling spindles at 18000 rpm, and comprehensive drilling units. Consider the opportunity to buy this QUICK CNC KQ-62 Lite multi-spindle drilling machine. Contact us for more information. Application Types Bcsdpfx Ajx S Sizsc Nou Boring & Drilling (Wood)

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drill head, drilling gear -Joint multi-spindle head -Max. x drill -7x drill built-in collet: mm -min. Distance drill: mm -Weight: 11.3 kg Bodpfx Ajdym D Toc Necu Articulated multi-spindle heads are: variable tools for various machining operations such as drilling, thread cutting, countersinking, reaming, milling, turning, with which several holes can be machined at once.

Condition: good (used), Multi-spindle head, multi-spindle drilling head, drilling gearbox -Multi-spindle head -Number: max. 2x drill bits/milling cutters -largest hole pattern spacing: 42 mm -Top opening: Ø 45 mm -Built-in collets: Ø 16 mm -Multi-spindle heads are variable tools Bcedob T Ti Eepfx Ac Nou -for various machining operations such as drilling, thread cutting, countersinking, reaming, -with which multiple holes can be machined at once -Dimensions: 120/110/H220 mm -Weight: 5.6 kg

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drilling head, drilling gearbox -Multi-spindle drill head with: drive -Drive geared motor SEW Eurodrive type: RF40DT80K4B Bcodpfx Aedz A Tpjc Nou -Power: 0.55 kW -Speed: 165 rpm -max. x: drill bit -4x built-in drill bits Collet: mm -Drilling pattern can be adjusted -Dimensions: 1115/150/H300 mm -Weight: 55 kg

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drilling head, drilling gearbox Bedpfxsdz A Tre Ac Nocu -Multi-spindle drill head with: drive -Drive geared motor SEW Eurodrive type: RF40DT80K4B -Power: 0.55 kW -Speed: 165 rpm -max. x: drill bit -4x built-in drill bits Collet: mm -Drilling pattern can be adjusted -Dimensions: 1115/150/H300 mm -Weight: 55 kg

Condition: good (used), Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox -Number: max. 9 drill bits -Recording: M8 Bcsdsb A R R Tepfx Ac Nsu -right/left: rotating alternately -Drill bit spacing: 32 mm -Quantity: 2 pieces available -Price: per piece -Dimensions: 310/60/H135 mm -Weight: 8 kg

Condition: used, Multi-spindle head, drilling beam, multi-spindle drilling head, articulated multiple-spindle head, row drilling machine, dowel drilling head, dowel drilling machine, drilling gear, drilling head -Manufacturer: Grotefeld, multi-spindle head max 3 drills -Admission: M8 -Spindle drive: dimensions see photo techn. drawing -Spindles: 2x clockwise / 1x counterclockwise rotating -Distance drill: see photo Bcedehh Tk Eepfx Ac Nou -Dimensions: 132/85 / H82 mm -Weight: 3.1 kg

Condition: good (used), Multi-spindle head, multi-spindle drilling head, drilling gear -Manufacturer: Perske, multi-spindle drilling head with drive -Drilling head: 18 spindles -Drill spacing: 32 mm -Stroke: 50 mm -Drive: DSB 1306/2 1.8 kW 2800 rpm -Collets: Ø10 mm Bcodpfxsvmw H Ao Ac Nou -Number: 2x multi-spindle drilling head with drive available -Price: per piece -Dimensions total: 800/200/H575 mm -Weight: 67 kg/piece

Condition: used, multi-spindle head, multi-spindle drilling head, drilling gear -Multi-spindle head: 5 spindles -Hole: Shaft Ø 20 x 25 mm -Drill holder: Ø 6 mm -Dimensions: see photos -Total dimensions: Ø 120/165 mm -Weight: 2.0 kg Bodpfsu Tytgox Ac Nscu

Condition: excellent (used), Year of construction: 1967, Multi-spindle head, multi-spindle drill head, drilling gear -Multi-spindle head recording drive: MK4 -Max. Number of drill heads: 9 pieces -Number of cardan shafts: 4 pieces with MK1 mount -Take drill: MK1 Bjdpfxsd E Hlaj Ac Nscu -Largest drilling pattern Dimensions of the drill: 280 x 280 mm -Multi-spindle heads: are variable tools -for various processing: such as drilling, tapping, countersinking, reaming, -with which several holes: can be machined at once -Dimensions: 330/330/H515 mm -Weight: 36 kg

Condition: used, Multi-spindle head, multi-spindle drill head, drilling gear -Multispindle head -Spindles: 7 -Socket: Ø 20 x 30 mm -Number: 2x built-in drill Bedpfxod Nkrwj Ac Necu -Dimensions: Ø 120/290 mm -Weight: 2.2 kg

Condition: used, Multi-spindle head, multi-spindle drill head, drilling gear Bsdpfx Asd Nzg Doc Necu -Piece multi-spindle head: 3 -Spindles: 2, 3 4 -Socket: Ø 20 x 28 mm -Price: complete -Dimension: see pictures -Weight: 7 kg

Condition: used, Multi-spindle head, drilling beam, multi-spindle drilling head, articulated multi-spindle head, row drilling machine, dowel drilling head, dowel drilling machine, drilling gear -comes from an Alberti drilling rig -max.: 18x drill -Admission: -alternately turning right/left -Distance drill: 50 mm -Distance drill: 25 mm -Number: 2x drilling heads available (1x left/1x right) Bcodpfx Ascp Txpec Nju -Price: per piece -Dimensions: 1090/380/H580 mm -Weight: 210 kg/piece

Condition: used, Quills, processing unit, automatic drilling machine, drilling machine, standing drill, multi-spindle drilling machine -2x: quill machining units -1x: Horizontal -1x: vertical -Max. Feed: stroke mm Bcedjchnx Uopfx Ac Nsu -Speed: rpm -Built-in drill chucks: 1.5-13 mm -Dimensions: 1050/1205/H1550 mm -Weight: 222 kg

Condition: used, Multi-spindle head, drilling beam, multi-spindle drilling head, articulated multi-spindle head, row drilling machine, dowel drilling head, dowel drilling machine, drilling gear -Number: max. 3x drill -Admission: M8 -right/left: rotating alternately Bsdpsf S T Iwofx Ac Necu -Distance drill: 25 mm, offset (see photo) -Number: 3 drill heads available -Price: per piece -Dimensions: 90/85/H70 mm -Weight: 1.6 kg/piece

Year of construction: 1984, condition: used, Multi-spindle head, multi-spindle drill head, drilling gear - Joint multi-spindle head -max.: x drill Bcjdpedym D Usfx Ac Nsu -3x built-in drill collet: mm -min. Distance drill: mm -Weight: 11.3 kg -Articulated multi-spindle heads are variable tools: for various machining operations such as drilling, thread cutting, ountersinking, reaming, milling, turning, with which several holes can be machined at once.

Condition: used, Multi-spindle head, multi-spindle drill head, drilling gear -Multispindle head Bodpfxod Nkrxo Ac Njcu -Spindles: 4 -Socket: Ø 20 x 30 mm -Dimensions: Ø 120/165 mm -Weight: 2.2 kg

Condition: good (used), Multi-spindle head, multi-spindle drilling head, drilling gear -Manufacturer: Romai, multi-spindle head 2 spindles Bodpfswyuu Njx Ac Nocu -Type SMSK 2/23 -Drilling tool holder: MK3 -min. distance drill bit: mm -Dimensions: Ø 220 x 455 mm -Weight: 27 kg

Condition: good (used), Spindles, machining unit, automatic drilling machine, drilling machine, pillar drilling machine Multi-spindle drilling machine -System without control -1x Spindle machining units Bodjb A I Dxjpfx Ac Nocu -2x sleds -Max. feed stroke: 110 mm -Speed: 1400 rpm -Built-in collet: 6 mm -Weight: 350 kg

Condition: good (used), Year of construction: 1987, Multi-spindle head, multi-spindle drilling head, drilling gearbox -Multi-spindle head -Number of drill spindles: 5 (adjustable spacing) -Drill bit diameter: max. 11 mm Bodsb A Ifkopfx Ac Nscu -Cardan shafts: 5 pieces -Largest drilling pattern; Drill dimensions: 100 x 230 mm -Weight: 27 kg -Multi-spindle heads are: variable tools -for various machining operations such as: drilling, thread cutting, countersinking, reaming, -with which multiple holes can be machined at once -Dimensions: 450/190/H660 mm -Weight: 27 kg

Condition: good (used), Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox -Number: max. 5x drill bits -Recording: M8 Leuco Type 010 Li -Center: clockwise rotation Outer: counterclockwise rotation -Drill bit spacing: 32 mm -Dimensions: 95/160/H105 mm -Weight: 4 kg Bcjdpeb A R Hcefx Ac Nsu
