Used Radial drilling machines 1000-1299mm arm length for sale (61)

Condition: new, Technical data: Drilling capacity steel Ø: 50 mm Drilling capacity cast iron Ø: 60 mm Tapping steel Ø: 40 mm Tapping capacity cast iron Ø: 50 mm Diameter of the column: 300 mm projection (min/max): 305 - 1275 mm travel of the spindle head (horizontal): 970 mm distance spindle nose - base plate (min/max): 438 - 1330 mm Traverse height of the cantilever: 625 mm Clamping surface of cube table : 635 x 520 x 420 mm size base plate : 1830 x 785 x 185 mm spindle mounting: MK 5 spindle stroke: 270 mm Speeds: (12) 44 - 1206 min-1 2L0Qa8Hm feeds: (3) 0.06 / 0.10 / 0.20 mm/rev. Motor power, approx.: 3,7 kW Total height, max.: 2795 mm Weight, approx.: 2300 kg Features: - Simple one-button operation with integrated circuit for automatic release of swing arm movement, automatic stop and automatic clamping. - Boom arm and drill head with independent hydraulic clamping. - A special lift safety device prevents the arm from falling off abruptly or moving on its own, even after a long period of use and corresponding wear. This safety device protects the operator from injury even if the threaded nut is excessively worn. - The column, arm and gearbox can be clamped simultaneously by pressing a button. Standard Equipment: - Threading device - Coolant device incl. pump - machine light - cube table 635 x 520 x 420 mm - Operating tools in box - Operating instructions and spare parts list - protection device for spindle - CE

Condition: excellent (used), Year of construction: 1988, Alzmetall AB 30/R-1000 radial drilling machine with 3,0 kW motor Manufacturer: Alzmetall Type: AB 30/R-1000 Condition: used, very good Year of manufacture: 1988 Drilling capacity steel E335 (St 60) 40 mm Drilling capacity cast iron EN-GJL-200 50 mm Thread cutting (St60)* M 30 Thread cutting in cast iron (EN-GJL-200)* M 42 Short spindle MK 4 / MT 4 Stroke motor 0.75 kW 4 feeds 0.15-0.2-0.3-0.36 mm/rev Spindle stroke 160 mm* throat 1000 mm Drive Manual gearbox Motor: n = 1500 min-1 3.0 kw kW 12 Spindle speeds 56 / 80 / 112 / 160 / 224 315 / 450 / 630 / 900 / 1250 / 1800 / 2500 Standard equipment Dpsnq2 - Electromagnetic feed clutch with overload protection and electric handle cross switching - Clockwise rotation through contactor control - incl. motor protection switch for drive and lift motor - Base plate with T-slots - Protection class IP 54 Special equipment. - Machine light - Thread cutting device - Coolant system - Electrically controlled free-cutting device - Drilling depth fine adjustment and fixed stop - 2 x cube table 630 x 800 x 500 - Central clamping for drilling slide and boom mechanical and for column pneumatic

Condition: new, Year of construction: 2023, 50 mm Dprldt 1275 mm 1330 - MK 5 bore depth 270 mm spindle turning speed range 44-1206 U/min

Condition: excellent (used), Year of construction: 1955, Drilling capacity in steel St 37 65 mm Drilling capacity in cast iron 75 mm Spindle holder MK 5 throat depth 1250 mm Spindle stroke 400 mm Spindle speeds 22.4 - 1800 rpm Feed range 0.05 - ... mm/rev Dimensions L x W x H (with motor!) 2250 x 1000 x 3100 mm Transport dimensions L x W x H (without motor!) 2250 x 1000 x 2800 mm Weight 5100 kg Accessories / special features: - Cube table L x W x H 650 x 500 x 500 mm - R-L run - feed - Central clamping Saurq98Dax - Coolant device Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2017, gebraucht 2017 3901 China 8490 € 6800 € 1 32 mm MK 4 300 - 1.000 mm 32 - 2.500 (16) U/min 1760 mm 800 mm 2080 mm 1600 kg 530 - 1.000 mm 2.2 kW 240 mm 250 mm 0,75 kW 0,10 - 1,25 (8) mm/U box table 600 x 455 x 455 mm coolant equipment Cy3H78Kcl3 machine lamp mechanical clamping for height adjustment and spindle stock electr. clamping for arm rotation machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: used, Year of construction: 1988, bore capacity in steel (diameter): 45 mm arm length:: 300 - 1250 workpiece height max.: mm drill capacity in cast iron: 60 mm cantilever arm length from center column: 1700 mm distance table - lower edge spindle: min./max.: 280 bis1380 mm spindle taper MT: MK5 bore spindle stroke: max. 355 mm swivel range of the arm: 360 mm drill head horizontal traverse: 950 mm cantilever adjustment vertical: 800 mm range of revolutions per minute - continous: 20 - 1200 / 6 step U/min feed: 0,063 ... 0,,63 / 6 step mm/U Height adjustment of the: 745 mm column diameter: Ø 300 mm base plate surface area: 1450 x 920 mm max. torque on the spindle: ca. 250 Nm total power requirement: 5,0 kW weight of the machine ca.: 3,8 (+ 350kg Würfel) t dimension machine xH: 2,1 x 1,0 x 2,8 (3,05) m Machine is currently in the technical department with friction gearbox Heavy, torsion-resistant base plate overload clutch Metric thread in steel / cast iron : 36 / 45mm, inch thread up to 1 1/2? to 2? Boejtdnsj3Z incl. drilling cube Coolant system with pump

Condition: good (used), Year of construction: 1959, Functionality: fully functional, Cantilever drilling machine High performance radial drilling machine ALZMETALL FROM 3R year of construction 1959 Clamping surface: 1015 x 520mm Column can be swiveled 350 Stroke drilling depth 150mm Drilling capacity steel (St 60) 28, 32 [mm] Spindle MK 3 Power 1.5 [KW] Spindle speed 56 - 1,500 [rpm-1] Space requirement 1700 x 700 x 2400 mm Cseynrtmce Weight 1500 kg

Condition: used, Manufacturer: Breda Type: R1200L 30-40 Technical data: Projection: 1200 mm Spindle holder: MK4 Quill stroke: 180 mm Spindle speed: 2 - 2000 rpm. Clamping cube: 460 x 550 x 500 mm (LxWxH) Bk909R28Va Flat floor plate: 1100 x 500 mm (LxWxH) Main switch and 2 emergency stop foot switches Long connection cable with 16A plug Country of origin: Italy Space requirement: 1750 x 640 x 2100 mm (LxWxH) Machine weight: approx. 1450 kg The machine can be demonstrated under power on site. All data without guarantee Subject to errors and prior sale

Condition: excellent (used), Year of construction: 2001, Functionality: fully functional, Grinding length: 2,500 mm, Grinding width: 800 mm, Total height: 800 mm, the machine is in very good condition Dprioj

Condition: excellent (used), Year of construction: 2007, Functionality: fully functional, Technical details : rotary table diameter 900 mm grinding height 650 mm grinding head - power requirement 11 kW Control Siemens 840 D swing dia. 1100 mm table turning speeds 1 - 100 U/min table load 800 kg Dimensions (LxWxH) 4,7 x 2,5 x 3,2 m total power requirement 55 kW weight of the machine ca. 13 t Additional information : Universal rotary table grinding machine with movable rotary table and 2 spindles for internal and external cylindrical grinding Very good condition, operating hours according to counter only 7141 ! - Control Siemens Sinumerik 840 D powerline - Axis drives Digital AC servo motors - electron. handwheel - Electro permanent magnet 900 mm with star pole pitch - Working height above rotary table max. 650 mm - Rotatable column by hand ± 180 deg. - Hydraulic weight compensation - Coolant device with paper band filter - Hydrostatic for rotary table with cooler Spindle no.: 1 - External grinding - Grinding wheel diameter 400 x 40 (70) x 127 mm - Motor 11 kW - Speed 1000 - 2250 rpm Spindle no.: 2 - Internal grinding - Spindle diameter 100 x 400 mm - Speed 10.000 rpm - Grinding wheel diameter 150 x 32 x 51 mm - Grinding motor 5.5 kW - Grinding motor speed 1375 - 6000 rpm. Table drive The rotary table is equipped with a large-diameter hydrostatic table bearing. This ensures maximum accuracy. Dressing: 1 permanently installed dresser with MK1 holder enables automatic operation up to a diameter of 1100 mm. Ca0Ms7Bobu The full enclosure of the machine consists of: Cover hood attached to the machine bed with two telescoping tunnel hoods to the left Swing diameter of the workpiece inside the hood 1300 mm

Condition: used, Year of construction: 2021, gebraucht Dpr2Gj 2021 3965 prompt, Zwischenverkauf v Taiwan 15600 € 1 42 mm MK 4 280 - 1.100 mm 44 - 1.500 (12) U/min Stahl: M 25; Guss: M 38 1880 mm 870 mm 2210 mm 1800 kg 470 - 1.270 mm 0,05 - 0,15 (3) mm/min 2.2 kW 260 mm 280 mm 1.725 x 715 x 180 mm 0,75 kW 635 x 520 x 415 mm 2530 mm DEMO MACHINE left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: good (used), Year of construction: 1975, Meuser horizontal boring and milling machine model M 76 BF 5.5 kw Drilling depth 76 mm Spindle holder MK 5 Table 1000 x 1000 Dpkuqd

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW weight of the machine ca. 3.700 kg dimensions of the machine ca. m Bur07Fxsku

Condition: not inspected (used), Maintained radial drilling machine drilling capacity in steel: 40,0 mm throat: 1300 mm tool holder: MK4 max. swivel angle: +/- 180 degrees quill stroke: 280 mm Min. distance column - drilling spindle (X) 593 mm Max distance column - drilling spindle (X) Chbchtgpfa 1473 mm Speed: 52 - 2000 rpm (12 steps) Feed rate: 0,05-0,1-0,2-0,3 mm/rev (4 steps) column diameter: 250 mm spindle diameter: 68 mm clamping area: approx. 1445 x 810 mm operating voltage: 400 V Total power requirement: 5.5 kW Machine weight: approx. 2815 kg. Space requirement (L x W x H): 2010 x 820 x 2495 mm Equipment: - electric height adjustment - hydraulic clamping of the drilling slide and the column - cube clamping table with T-slots - automatic spindle feed - R/L run of the drilling spindle - electric height adjustment from boom - speed adjustment manual - feed adjustment manual - handwheel for drill carriage adjustment We will be pleased to demonstrate the machine under power on site. All data without guarantee. Subject to prior sale. The object of purchase is sold under exclusion of any warranty. The exclusion does not apply to claims for damages arising from grossly negligent or intentional breach of obligations of the seller and for any injury to life, limb and health.

Condition: used, Year of construction: 1985, bore capacity in steel (diameter): 44 mm arm length:: workpiece height max.: mm Bh0Iuntt drill capacity in cast iron: 55 mm distance table - lower edge spindle: min./max.: 208 / 1380 mm spindle taper MT: MK5 bore spindle stroke: 360 mm range of revolutions per minute - continous: 20 - 1200 / 6 step U/min feed: 0,063 ... 0,,63 / 6 step mm/U swivel range of the arm: 360 mm cantilever adjustment vertical: 800 mm cantilever arm length from center column: 1700 mm column diameter: Ø 300 mm base plate surface area: 1300 x 750 mm total power requirement: 5,0 kW weight of the machine ca.: 3,05 (+ 350kg Würfel) t dimension machine xH: 2,1 x 1,0 x 2,8 (3,05) m Travel of drill head on extension arm (horizontal) 950mm Projection of drill spindle min./max.: 280 / 1200mm Drill spindle right/left rotation (thread cutting) Machine lighting pre-equipped Drill cube: L: 700 x W: 500 x H: 520mm; (weight approx. 350kg) Coolant device with pump i.D.

Condition: used, Year of construction: 1973, bore capacity in steel diameter 55 mm arm length 1600 mm workpiece height max 1600 mm WORKING RANGE -BORING- Bvrxuqzrbe - drilling capacity full bore (steel) 55 mm - throat (max) 1600 mm - workpiece height (max) 1600 mm MILLING SPINDLE / HEAD - tool fixture: MK 5 - sleeve stroke 350 mm DIMENSIONS / WEIGHTS - space requirements -left/right- 2700 mm - space requirements -front/back- 1100 mm - total height 3400 mm - total weight approx. 4500 kg

Condition: used, Year of construction: 2011, gebraucht 2011 3960 prompt, Zwischenverkauf v Taiwan Dpr2C2 12200 € 1 42 mm MK 4 280 - 1100 mm 44 - 1.500 (12) U/min M 25 / M 28 1880 mm 870 mm 2210 mm 2600 kg 470 - 1.270 mm 0,05 - 0,15 (3) mm/min 2.2 kW 280 mm 1725 x 715 x 180 mm 0,75 kW 635 x 520 x 415 mm 2530 mm coolant equipment machine lamp mechanical clamping box table new Repar2 spindle protection HYDRAULIC CLAMPING OF THE COLUMN AND THE ARM User Manual in English COMPLIES WITH GERMAN UVV & AUSTRIAN AMVO

Condition: good (used), Year of construction: 1990, Functionality: fully functional, Rotary drill VO 32 Dpmbgx

Condition: good (used), Throat depth: 1,250 mm, Manufacturer: MAS Kovosvit Type: VO 50 / 1250 Year of construction: 1999 Specifications: Metric Metric US Standard Arm length 1250 mm Max. Drill Ø iron 60 mm Max. Tap diameter M50 x 1.5 M Quill stroke 310 mm Max. Distance spindle - table 1380 mm Min. distance spindle - table 320 mm Table / footprint 1470 x 986 mm Spindle speed 2500 rpm Tool holder 5 ISO/Bt/Mk Quill Ø 75 mm Power output 4 kW Max. Drill Ø steel 50 mm Dimensions (estimate) length 2900 mm width 1120 mm Height 3400 mm D7Vawzs weight 4200 kg Please note: The information on this page is given in good faith and to the best of our knowledge, and where possible, has been obtained from the manufacturer, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details.

Condition: used, bore capacity in steel (diameter) 35 mm arm length 1000 mm workpiece height max. 500 - 1300 mm turning speeds 5 - 1500 U/min spindle taper MT 4 total power requirement 3 kW Weight 3000 kg Isvmqa3 dimensions 2200 x 1000 x 2850 mm

Condition: used, Year of construction: 1988, bore capacity in steel (diameter): 45 mm arm length:: 1250 9Fm3Nahfi9 workpiece height max.: mm drill capacity in cast iron: 60 mm distance table - lower edge spindle: min./max.: 280 / 1380 mm spindle taper MT: MK5 bore spindle stroke: 355 mm range of revolutions per minute - continous: 20 - 1200 / 6 step U/min feed: 0,063 ... 0,,63 / 6 step mm/U swivel range of the arm: 360° cantilever adjustment vertical: Bohrkopf: 950 mm cantilever arm length from center column: 1700 mm vertical adjustment of the arm: Höhe: 800mm (manuell+motorisch) mm column diameter: Ø 300 mm base plate surface area: 1450 x 920 mm total power requirement: 5,0 kW weight of the machine ca.: 3,05 (+ 350kg Würfel) t dimension machine xH: 2,1 x 1,0 x 2,8 (3,05) m metric thread cutting in steel / GG: 36 / 45mm Drilling cube pump for supply with cooling water

Condition: used, bore capacity in steel diameter / mm arm length 1000 mm workpiece height max / mm ----- WORKING RANGE -BORING- - throat (max) 1000 mm - sleeve stroke 250 mm Dpgahn MILLING SPINDLE / HEAD / - spindle revolutions (min) 47.5 /min - spindle revolutions (max) 2120 /min - spindle diameter 60 mm - tool fixture: MK 4 DIMENSIONS / WEIGHTS - space requirements -left/right- 2000 mm - space requirements -front/back- 750 mm - total height 2160 mm - total weight approx. 2500 kg Machine is not 100% OK, and needs an overhaul. - Height adjustment and cross adjustment must be repaired

Condition: defective spare-parts repository (used), Year of construction: 1978, bore capacity in steel (diameter) 40 mm arm length 1000 mm workpiece height max. - mm total power requirement 5 kW weight of the machine ca. 3 t Gs2Xkyby dimensions of the machine ca. 2,4 x 1,2 x 3 m No. 4656 Radial drilling machine MK 4 make OOYA, type RE 2 - 1300 A Year of manufacture 1978 with cube table 800 x 600 / 950 x500 Working area: MK 4 x 1000 x 660 mm Spindle holder MK 4 Speed range 32 - 1655 min-1 ( 50 Hz ) Space requirement approx. 1.2 x 2.4 m Weight approx. 3 tons

Condition: used, bore capacity in steel (diameter) 40 mm arm length 350 - 1000 mm workpiece height max. 1300 mm turning speeds 30 - 1850 U/min Sa9Whjguin feed range 0,06 - 1,0 mm/min spindle taper MT 4 column diameter 320 mm total power requirement 3,0 / 3,3 kW dimensions 2000 x 1000 x 2850 mm Weight 3500 kg

Condition: used, bore capacity in steel (diameter) 40 mm arm length 1250 mm workpiece height max. -- mm Gxcblai turning speeds 30 - 2100 U/min
