Condition: good (used), Year of construction: 2003, NAGEL MODEL TBT M320-6 6 SPINDLE CNC HORIZONTAL GUN DRILL, 2003 Equipped with: Panel Mate Power Pro Control Counter Rotation Gedjrtrztepfx Achoud Cross Drilling High Pressure Coolant System Auto Loader Magnetic Chip Separator Hydraulic System Chiller Specifications: Maximum Drill Depth (Approx): 16" Maximum Drill Length: 36" Number of Drill Spindles: 6 Spindle Motors (3): 7.5HP HP Per Spindle: 3.75 Drill Head Slide Stroke: 16.9" Maximum Diameter Mild Steel: 0.750"

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Gsdertrx Repfx Acheud Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW Gjdpfx Acodkx Ansheud - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: good (used), Morse taper sleeve, tool holder, Morse taper, Morse cone, taper sleeve, adapter, extension sleeve, reducing sleeve, cone sleeve, adapter sleeve, spindle sleeve, Morse taper adapter -Morse taper sleeves: Adapter sleeves, reducing sleeve MK6/MK5 -Type: MK6-MK5 Gujdpfx Aszlf Saschjd -Dimensions/Quantity: see photos -Transport dimensions: 620/250/H63 mm -Weight: 29.8 kg

Condition: new, Year of construction: 2026, Heavy-duty design for the entire machine High running smoothness thanks to a new spindle design Industrial motor Separate emergency stop switch Drill depth stop Guodpfx Acog Uaiuehjd LED machine light integrated into the drill head Precisely machined, stable drill table with diagonally arranged T-slots and an all-around coolant channel Drill table can be tilted ± 45° and rotated 360° V-belt cover with safety switch Precision spindle bore Machine control and safety electronics in 24 V DC Guaranteed concentricity accuracy ≤ 0.02 mm measured in the drill spindle Thick-walled steel column for high force absorption and stability Massive, generously sized base plate with T-slots Dimensions and weights Column diameter 92 mm Length approx. 945 mm Width/Depth approx. 485 mm Height approx. 2040 mm Weight approx. 162 kg Drilling capacity Drilling capacity in steel (S235JR) 30 mm Continuous drilling capacity in steel (S235JR) 25 mm Drill table Working surface length 355 mm Working surface width 355 mm Type of T-slots diagonal T-slot size 14 mm Number of T-slots 2 Rotation 360° Tilt 45° Distance spindle - drill table max. 784 mm Speed range Speed range 120 – 1810 min⁻¹ Number of speed ranges 9 Electrical data Connection voltage 400 V Mains frequency 50 Hz Machine base Distance spindle - machine base max. 1470 mm Working surface length 230 mm Working surface width 300 mm T-slot size 16 mm Number of T-slots 2 Spindle Quill stroke 125 mm Spindle mount MK 4 Overhang 270 mm Location: In stock at warehouse 54634 Bitburg - immediately available -

Condition: excellent (used), Year of construction: 2009, Bernardo FM 45 V drilling and milling machine. The FM 45 V drilling and milling machine offers an optimal price-performance ratio thanks to the standard spindle feed. The dovetail guide of the gear head ensures maximum precision and stability. Drilling capacity in steel 32 mm Drilling capacity in cast iron 40 mm Throat 260 mm Spindle speed (12) 50 - 2520 rpm Spindle mount MK 4 Quill stroke 120 mm Quill feed (3) 0.12 / 0.19 / 0.26 mm/rev Table size 820 x 240 mm Distance spindle / table 40 - 485 mm Travel path (x / y) 550 / 190 mm Height adjustment of milling head 400 mm T-slot size 14 mm T-slot distance 55 mm Motor output power S1 100% 0.85 / 1.1 kW (400 V) Motor input power S6 40% 1.1 / 1.5 kW (400 V) Machine dimensions (W x D x H) 1150 x 850 x 1450 mm Weight approx. 285 kg Standard with automatic spindle feed and thread cutting device Large speed range 50 - 2520 rpm (12 levels) Dovetail guide for x, y and z axes, adjustable via wedge strips Versatile application options, slot milling, face milling, boring,.... Solid large cross table, precisely surface-machined Milling: spindle feed via handwheel Gusdevutw Hspfx Achsd Drilling: spindle feed via handwheel High-quality aluminum motor, designed for continuous operation Stable and vibration-free cast design Simple and quick speed change using a gear lever Pivoting milling head for angle drilling, milling bevels, etc. Location: from stock 54634 Bitburg - available at short notice -

Condition: as good as new (ex-display), Year of construction: 2026, OPTIdrill D 26PRO - Pillar drilling machine Bench and pillar drilling machine with V-belt drive User-friendly safety switch according to IP 54 with undervoltage release and separate emergency stop button 400-volt models with right/left rotation Drilling depth stop Precisely manufactured drilling table with diagonally running T-slots Gjdpfx Aedqzbnjchjud Height adjustment of the drilling table via rack and pinion Drilling table can be tilted ± 45° and rotated 360° V-belt cover with safety switch Aluminum die-cast quill lever in one piece with soft-grip handles Industrial motor Precision spindle bore Machine operation including safety electricals in 24 V DC Guaranteed run-out accuracy

Condition: new, Year of construction: 2025, Heavy-duty, solid cast-iron construction High running smoothness due to ground, oil-bath lubricated gears Right-hand/left-hand operation Automatic quill feed with manual fine feed Motorized positioning of the Z-axis Motorized table feed of the X-axis Coolant system Machine lamp Gear head can be swiveled ± 60° Adjustable wedge strips Solid dovetail guide for the column, hand-scraped, for maximum stability and precision Height-adjustable, large-sized protective shield with microswitch Drilling depth stop Digital position display DRO 5 Drilling/tapping function Gsdpsg U Uv Uofx Achjud Solid and large-sized cross table, precisely surface-finished with T-slots and adjustable wedge strips Solid machine base made of cast iron with chip collection groove Single-stage, high-quality industrial electric motor Large speed range of 60 - 2,760 rpm through 2 continuously adjustable speeds Dimensions and weights Length approx. 1600 mm Width/Depth approx. 930 mm Height approx. 2110 mm Weight approx. 495 kg Drilling/Milling performance Arbor size max. 63 mm Shell mill size max. 26 mm Drilling capacity steel (S235JR) 24 mm Continuous drilling capacity steel (S235JR) 20 mm Electrical data Connection voltage 230 V Mains frequency 50 Hz Electrical connection Total connected load 1.5 kW Milling table, horizontal Length 800 mm Width 240 mm Distance Vertical spindle - Milling table max. 420 mm T-slot size 14 mm Number of T-slots 3 T-slot spacing 80 mm Standards and approvals Standard DIN EN 55011 EMC class C2 Travel X-axis manual 560 mm Y-axis manual 195 mm Z-axis manual 350 mm X-axis automatic 480 mm Vertical spindle Overhang 258 mm Spindle mount MK 4 Speed range 60 – 2760 rpm Number of speed ranges 2 Speed control Steuerung der Drehzahlregelung electronic Draw bar M 16 Swivel range milling head Z - X plane ± 45 ° Quill diameter 75 mm Quill stroke 120 mm Location: In stock at 54634 Bitburg - available immediately -

Condition: refurbished (used), Year of construction: 1983, Work table 600mm x 1200mm Arm travel 600mm Tool holder MK 4 Drilling capacity 32mm in steel Thread cutting device Godpjmt Ed Refx Achsud Coolant system Electrics 24V control voltage Emergency stop 2-channel Guard on the drill Completely overhauled 2025 12 months warranty New paint RAL 7035/7031

Condition: refurbished (used), Year of construction: 1976, Work table 500mm x 1200mm Arm travel distance 600mm Tool holder MK 4 Drilling capacity 32mm in steel Thread cutting device Coolant device Electronics 24V control voltage Emergency stop 2-channel Safety device on the drill Completely overhauled in 2025 12 months warranty Guedpewnn S Refx Achjd New paint RAL 7035/7031

Condition: used, Year of construction: 1987, total width: 800 mm, total length: 1,200 mm, total height: 2,600 mm, Colour: Green Empty weight: 700 kg - Year: 1987 - Documentation available: No - CE certificate present: No - Serial number: 14441 - Drive system: Conventional - Drive system: Gear drive - Power [kW]: 2.2 - Table type: Fixed table - Table length [mm]: 500 - Table width [mm]: 500 - Drilling depth [mm]: 250 - Drilling capacity [mm]: 32 - Reach [mm]: 320 - Tool holder: MK4 - Main spindle power [kW]: 1.5 - Min. spindle speed [rpm]: 85 - Max. spindle speed [rpm]: 1500 - Options: Drill unit feed - Transport dimensions: 1200mm x 800mm x 2600mm (l x w x h) - Transport weight [kg]: 700kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Gjdozkq Auepfx Achoud Lukas van Rossum

Condition: ready for operation (used), Year of construction: 1991, functionality: limited functionality, travel distance X-axis: 5,020 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 2,000 mm, spindle diameter: 100 mm, controller model: Heidenhain 415 B, TECHNICAL DETAILS Spindle diameter: 100 mm Travel in X-axis: 5,020 mm Travel in Y-axis: 1,000 mm Travel in Z-axis: 2,000 mm Tool holder: SK 50 MACHINE DETAILS Control system: Heidenhain 415 B Rotary table dimensions: 2,500 x 2,000 mm EQUIPMENT Indexable milling head 2.5 60-position tool changer Rotary table manufacturer: Scharmann Gujdpjzlryqofx Achjd Note: The rotary function of the rotary table is defective. The machine is sold without pallet changers.

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, CNC Table Type Boring and Milling Machine - Horizontal | Brand: UNION Type: BFT 105 | Year of construction: 1990 Machining operations: Boring, reaming, deep boring, precision boring, reaming, countersinking, tapping, milling, circular milling, thread milling. The machine can be inspected under power by prior appointment. Condition: Very well-maintained, second-hand / operating condition. TECHNICAL SPECIFICATIONS: - Travels: - X-axis (table transverse movement): 1.750 mm - Y-axis (headstock vertical movement): 1.250 mm - Z-axis (table longitudinal movement): 1.175 mm - B-axis (table positioning): 360° - W-axis (boring spindle axial adjustment): 450 mm Clamping table: - Clamping surface: 1.250 x 1.400 mm - Maximum workpiece weight with centric clamping: 4 tons - T-slot spacing: 125 mm - T-slot width: 22H7 mm - Centring bore: 250 mm Boring spindle: - Diameter: 105 mm - Axial adjustment: NC-controlled - Tool holder: * with tapered shank: A 50 TGL 7837 * with steep taper: A 50 DIN 2080 * with clamping bolts: UNION 95-2805 (A 50 TGL 42620) DIN 69872-28 Speed ranges: - 3 continuously variable ranges: 4 – 2.500 rpm - Drive power: 23,7 kW - Max. spindle torque: 2.500 Nm Feed rates: Continuously variable feed range - X, Y, Z axes: 1 – 5.000 mm/min - Rapid traverse, X, Y, Z-axes: 10.000 mm/min Gujdezlal Ispfx Achod W-axis: 5.000 mm/min B-axis: 3,2 rpm - Max. feed force: X and Y-axes: 16.000 N Z-axis: 25.000 N Specifications: - Total connected load: 50 kW/130 A - Voltage/frequency: 380 V/50 Hz - Machine weight (approx.): 17 tons - Dimensions: 6.560 x 4.370 x 3.450 mm EQUIPMENT: - 5-axis path control: Heidenhain TNC 355 - Swivelling control panel with central control station - Electronic handwheel - Other comprehensive ranges of accessories, such as tool holders, drill bits, milling cutters, and tool trolleys and cabinets ... - Comprehensive documentation available (foundation plan, circuit diagrams, hydraulic documentation, operating instructions and spare parts lists, programming lists) No guarantee is given for the completeness and accuracy of the technical information and equipment. - Subject to prior sale -

Condition: good (used), Year of construction: 2015, total width: 1,800 mm, total length: 3,700 mm, total height: 4,300 mm, overall weight: 14,000 kg, Maximum drilling capacity in steel: 75 mm Gsdpfozi S Snsx Achoud Length:3700mm Width:1800mm Height:4300mm Weight:14000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 2014, condition: ready for operation (used), travel distance X-axis: 1,600 mm, total width: 1,250 mm, total height: 3,437 mm, spindle motor power: 5,500 W, product length (max.): 3,080 mm, spindle speed (max.): 1,600 rpm, number of axes: 3, This 3-axis M+A RB 63/20 W drilling machine was manufactured in 2014. It features a maximum drilling diameter of 63 mm in steel and 80 mm in cast iron, with a maximum reach from the column of 2000 mm. The machine includes a robust cube table measuring 800 x 630 x 500 mm. If you are looking to get high-quality drilling capabilities, consider the M+A RB 63/20 W machine we have for sale. Contact us for further details. Guodpfx Aezk Ivxsched - Maximum drilling diameter in steel (600 MPa): 63 mm- Maximum drilling diameter in cast iron (250 MPa): 80 mm- Maximum reach from column: 2000 mm- Minimum reach from column: 450 mm- Column diameter: 450 mm- Minimum distance between spindle nose and baseplate: 400 mm- Maximum distance between spindle nose and baseplate: 1600 mm- Spindle inner taper: MT 5- Maximum spindle stroke: 400 mm- Vertical adjustment of drill head: 800 mm- Horizontal adjustment of drill head: 1550 mm- Baseplate length: 2900 mm- Baseplate width: 1250 mm- Baseplate height: 260 mm- Number of spindle speeds: 16 (hydraulically set)- Spindle speed range: 20 to 1600 rpm (20, 32, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 1000, 1600 rpm)- Number of spindle feeds: 16- Spindle feed sizes range: 0.04 to 3.2 mm/rev- Maximum permissible torque at spindle: 980 Nm- Main drive motor power: 5.5 kW (1500 rpm)- Arm elevating motor power: 2.2 kW (1500 rpm)- Clamping motor power: 0.75 kW (1500 rpm)- Coolant pump power: 90 W / 0.09 kW (3000 rpm, Flow rate: 25 l/min, Head: 4 m)- Machine total power: 8.45 kW- Operating voltage: 400 V / 50 Hz- Required connection current: 16 A- Maximum load capacity/weight: Approx. 7000 kg- Machine overall dimensions: 3080 x 1250 x 3290 mm (Max height up to 3437 mm)- Noise emission level: ≤ 85 dB (A)

Condition: used, y-axis 1.000 mm table dimensions 1.000 x 600 mm bore depth 150 mm bore diameter 32 mm spindle tunring speed 30 - 2.650 U/min output 6 kw In our assessment, the machine is in good used condition and can be inspected under power by appointment. Gsdpoy A Tc Dsfx Achsud Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Year of construction: 1990, taper MK 3 serial number 4131 throat 1000 mm documentation ja clamping hydraulisch kW Gusdpfx Aezkbqvjchsd weight of the machine ca. 2,6 t

Condition: good (used), Year of construction: 2004, Ref. -No.: 10604 Manufacturer: UNION Type: TC 110 Year of construction: 2004 Type of control: CNC-Steuerung Gujdpfx Aozkpv Hechod Control: SINUMERIK 840 D Powerline Storage location: Halberstadt Country of origin: Germany X-Travel: 2000 mm Y-Travel: 1250 mm Z-Travel: 1000 mm W-Axis: 550 mm Table Height: 1050 mm Spindle Diameter: 110 mm Table Dimensions (Lengthxwidth): 1600 x 1250 mm Number of T-slots: 10 Max. Workpiece Weight: 6000 kg Clamping Area: 1250 mm T - groove width: 22 mm T - slot spacing: 125 mm Tool Taper: ISO 50 Max. Torque: 1639 Nm Feed Speeds X/Y/Z Axis: 6000 mm / min Rapid Traverse X-Axis: 15000 m / min Rapid Travel Y-Axis: 15000 m / min Rapid Traverse Z-Axis: 15000 m / min Feed Capacities X/Y/Z: 16000 x 16000 x 20000 N swivel angle: 360 ° Further information: Includes angle head 0,001° The machine can be viewed under power.

Year of construction: 2009, operating hours: 3,093 h, condition: ready for operation (used), travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,800 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 320, overall weight: 8,900 kg, total width: 3,400 mm, total height: 3,160 mm, product length (max.): 5,800 mm, spindle speed (max.): 1,600 rpm, table load: 2,500 kg, number of axes: 5, This 5-axis MSC Chemnitz BFT90/5 MSC boring machine was manufactured in 2009. It features a substantial table size of 1000 x 1120 mm with a maximum table load of 2.5 t. The machine offers impressive feed rates of 4000 mm/min and a spindle speed range of 4 – 1600 rpm. If you are looking to get high-quality boring capabilities, consider the MSC Chemnitz BFT90/5 MSC machine we have for sale. Contact us for further details. • Table size: 1000 x 1120 mm • B axis (table rotation): 360° Gjdpfx Ajy Hvgtechjud • Feed rate (X/Y/Z): 4000 mm/min • Spindle diameter: 90 mm • W axis travel: 710 mm • Control cabinet dimensions (L x W x H): 2.0 x 0.75 x 2.0 m • Temperature range: 15–40 °C • Electrical: 3-phase/50 Hz; 380 V rated voltage; 24 V control voltage • Connected load: 40 kW • Fuse rated current: 100 A • Typical power consumption: approx. 7.5 kW • Spindle running time: 3069 h • Power-on hours: 10402 h • General overhaul: 2009 General Information Retrofit Retrofit includes: • Control system: TNC 320 • New drives in all axes • New table • New clamping system • New media units • New hand control unit • New coolant system • New hydraulic unit • 30 measuring scales (linear measurement systems) • Control manufacturer: SK 40 • CNC control: TNC 320 • Complete electrical retrofit • New wiring throughout the machine • Integration of CNC system (TNC 320) • New inputs and outputs (I/O) • New sensors and measuring systems • Updated control circuits and safety circuits • Modern CNC control system • Improved accuracy due to new measuring systems • Higher reliability • Better performance due to new drives • Reduced downtime due to new auxiliary units • New electrical documentation • Updated schematics • Includes systems for power supply, control, machine interface, operator panel, and drivesMachine base remains:MSC Chemnitz table boring machineType: BFT 90/5 MSC – 5 axes Technical Specification Taper Size SK 40

Year of construction: 1985, condition: used, spindle diameter 110 mm x-travel 900 mm y-travel 600 mm z-axis 200 mm table length 1020 mm table width 860 mm taper MK 40 Table size, approx. 1,020 x 860 mm Max. weight of workpiece 800 kg Table travel, longitudinal, max. (X) 900 mm Boring head travel, cross, max. (Y) 600 mm Boring spindle stroke (Z) 200 mm Vertical travel of cross beam (W) 635 mm Vertical distance between table and boring spindle 15 - 850 mm Distance between columns 950 mm Spindle Ø 110 mm Spindle taper internal/external ISO 40 Guedpfxst Hwyxs Achsd 18 spindle speeds 10 - 2,500 rpm Milling feeds of table, infinitely variable 1 - 6,000 mm/min 4 milling feeds of boring head 30 - 180 mm/min 6 boring feeds 0.01 - 0.39 rpm Accuracy of all 3 axes when the machine was new 0.003 mm Quick feeds for table, boring head slide, and boring spindle, max. 6,000 mm/min Spindle drive 6.2 kW Weight, approx. 9,000 kg Total electrical load 15 kW - 380 V - 50 Hz Accessories / Special Features - BOSCH CNC Control, Model MICRO 8, in 3 axes, with monitor. Program input is either manual or via cassette, or via interface entry. - Digital display for Z Axis. - Separate switch cabinet. - Various tools. - Oil cooler for spindle lubrication.

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW weight of the machine ca. 3.700 kg Gsdpfx Acst H Smyohjud dimensions of the machine ca. m

Year of construction: 1980, condition: used, table length 2000 mm table width 1800 mm table load 12,5 t total power requirement 10 kW weight of the machine ca. 7,5 t dimensions of the machine ca. m Table size approx. 2,000 x 1,800 mm Max. weight of workpiece, approx. 12,500 kg Gusdpfx Acjt Hwq Rjhsd Table travel, longitudinal 1,250 mm Table height above floor 920 mm Longitudinal feed 0.63 - 2,000 mm/min Turning feed, with Ø 1,000 mm 1 - 3,150 mm/min Longitudinal quick feed 2,000 mm/min Turning quick feed, with Ø 1,000 mm 3,150 mm/min Weight of machine 7,500 kg External dimensions of machine 3,700 x 2,100 x 920 mm Total electrical load 10 KW - 180 V - 50 Hz Accessories / Special Features * Telescopic covers for the guides. * Infinitely variable table feed. * Optical display for setting and reading the longitudinal adjustment. * Optical display for setting and reading the angle. Condition : Satisfactory to good. Machine can be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest.

Condition: used, Year of construction: 1965, core drilling diameter max. 50 mm bore depth 2000 mm swing diameter mm drilling capacity diameter max. 110 mm total power requirement 30 kW weight of the machine ca. 10 t Drilling Ø, approx. 2 - 50 mm Boring Ø, approx. 100 mm Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm Stroke of drilling slide, approx. 4,000 mm Distance between the two spindle heads 5,000 mm Gedet Hwucopfx Achjud Height of centres above guideways 350 / 450 mm Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min Quick feed of drilling slide 2,500 mm/min Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm Workspindle drive 24 kW Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW Total electrical load, approx. 60 kW - 380 V - 50 Hz Total length of machine / guideways 7,500 / 5,000 mm Weight, approx. 10,000 kg Accessories / Special Features * Machine consists of the following elements: Main spindle on the left-hand side, followed by the coolant oil supply device. Table group, driven by ball screw spindle. Coolant oil supply device with elevated height of centres. At the end is a headstock, Type B 16, with drive motor approx. 7.5 kW, n = 900/2400 and 2400/6000. Large coolant device with filter unit. Large selection of accessories and drilling tools with Ø up to 100 mm. * Machine is suitable for working with a rotating workpiece together with a fixed drilling tool (ELB and BTA Process), as well as for a fixed workpiece and a rotating drilling tool. It can work with internal oil feed (Elb) or with external oil feed (BTA). * Complete oil coolant unit with tank and filter and two SIG high pressure pumps. Number of litres can be set: 17 / 40 / 120 or 220 / 500 litres per minute. Capacity approx. 2,500 l. * Feed of main slide is via ball screw spindle and infinitely variable DC motor. Mounted on the main slide is at present a table, approx. 800 x 800 mm, cross-adjustable approx. 500 mm, and suitable for holding cubic and cylindrical workpieces. Electric control via cam rail, approx. 2,500 mm long. End switch for quick feed, feed and return. * 2 closed 3-point steady rests. * FORKHARDT 3-Jaw Chuck, manually operated, Ø approx. 315 mm. * Modernized control panel with speed display, feed setting and display, display for kW, switch for feed, quick feed, right/left, etc. * 2 separate switch cabinets, separate coolant oil display device, bushes, reducers, clamping helps and lots of other accessories. This is a very valuable machine because of all the accessories!

Condition: used, Year of construction: 1985, core drilling diameter max. 18 mm bore depth 320 mm swing diameter mm Gsdpot Hwvaefx Achsud total power requirement 33 kW weight of the machine ca. 6 t dimensions of the machine ca. m

Condition: used, Year of construction: 1984, cycle time 0 sec total power requirement 2,5 kW weight of the machine ca. 1 t dimensions of the machine ca. m P O S A L U X (Switzerland) Horizontal 3-Spindle Fine Boring Machines Model MICROFOR PNC 3 Year 1984 Serial Nos. 6.8230/9 Boring Æ 0.15 - 2 mm Spindle stroke 0 - 18 mm Working stroke, max. 0 - 12 mm Quick feed 60 mm/sec Boring feed 0 - 5 mm/sec Spindle speeds 3,500 - 11,500 rpm Distance between spindles, vertical, approx. 80 mm Table speeds (for deburring) approx. 100 rpm Table Æ, approx. 100 mm Table bore, approx. 70 mm Table slide swivelling device, approx. 60 °/sec Swivelling range 0 - 100 ° Total drive, approx. 2.5 kW Weight 1,000 kg Guodet Hwvgspfx Achjd Accessories / Special Features Serial No. 6.8230/9 Machine is equipped with a modern POSALUX SELECTRON Control with keyboard and LED for direct programming on the machine (in principle the same as with a punchboard control). With setting microscope and machine lamp.
