Vertical machining centers offers
+++ This auction is held in cooperation with a long-time Maschinensucher dealer. +++
General:
Control: Siemens 810 D
Control type: CNC
Machine weight: approx. 4.5 t
Camm2yad79
Space requirement: approx. 3,000 × 2,000 × 2,000 mm (L × W × H)
Total power requirement: 22 kW
Working area:
Travel X / Y / Z: 630 / 500 / 500 mm
table size: 800 × 500 mm
workpiece weight: max. 500 kg
spindle speed: 0 - 10.000 rpm
feeds: 1 - 30.000 mm/min
rapid traverse: 30 m/min
tool holder: SK40
Tool positions: 24 posi...
12
+++ This auction is held in cooperation with a long-time Maschinensucher dealer. +++
General:
Control: Brother CNC-B00
Year of manufacture: 2007
Cavv3jka
Dimensions: 1,890 × 3,669 × 2,260 mm (L × W × H)
Weight: Approx. 4.6 t
Working range:
Travel X / Y / Z: 550 / 400 / 415 mm
Rotational speed: 12,000 rpm
spindle distance: 645 mm
tool holder: HSK 40
tool places: 40
table dimension: 600 × 425 mm
table load: 200kg
+++ Machine can be inspected. +++
+++ This auction is held in cooperation with a long-time Maschinensucher dealer. +++
General:
Control: FANUC 21iMB
Year of manufacture: 2007
Dimensions: Approx. 2,700 × 4,300 × 3,071 mm (L × W × H)
Weight: Approx. 11,600 kg
Total power requirement: 60 kVA
Working range:
Travel (X / Y / Z): 800 / 560 / 560 mm
spindle speed: max. 10.000 rpm
Spindle drive power: 15 kW
Distance table to spindle nose: 150 - 710 mm
Type of spindle: NT 40
Table dimensions: 900 × 610 mm
Number of tables: 2× rotopalle...
14
Hurco VMX 42i Vertical Machining Center
Cai9u0tmdq
Mfd. 2014
SN: M443-16001B4GF0AH
Equipped as pictured
10
41"X 35"Y 23"Z travels, Heidenhain TNC 640 control, 56hp, 18k rpm, HSK-A63 taper, ATC 42, rotary table, 80 bar internal coolant supply, scraper belt conveyor with ICS, external air blast, air blast through spindle center, Renishaw probe Blum tool break, swarf flushing nozzle, mist extraction system
Cljnnd0u
1
Category: VERTICAL MACHINING CENTER
Brand: HAAS
Model/Type: VCE 1600
Year: 1995
Control: HAAS
Travel axes XYZ: 1600 x 800 x 650 mm
Max. Spindle rotation speed: 10,000 rpm
Spindle Nose: ISO 40
Machine Dimensions (LxWxH): 5000 x 3200 x 3000 mm
Total weight of the machine: 16,000 kg
Gv7rh8
OPTIONS INCLUDED:
- GEAR BOX
- 10.000 RPM
- 4TH AXIS DRIVE
- TROUGH SPINDLE COOLANT 21 BAR
Photos Soon
8
CNC Vertical Machining Centre
B9knah932x
Table size 1150 x 510 mm.
Movement x-Axis 1000 mm.
Movement y-Axis 510 mm.
Movement z-Axis 630 mm.
Max table load 700 kg
Number of tools in magazine 24 pieces.
Maximum spindle speed 10.000 R/pm.
Tool taper MAS BT-40.
CNC control Fanuc 21i-MB
If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.
Feel free to view our other advertisements for a complete overview of our stock.
1
Machine comes from the AXA factory in Schöppingen and was delivered in August
2017 to our customer in completely overhauled condition.
Since the general overhauling our customer only used it for approx. 400 hours
Control: Siemens 840 D Powerline
Control On: Approx. 12121 hours
Travel X: 1200mm
Travel Y: 520mm
Travel Z: 600mm
Distance table - spindle nose: 180-780mm
Clamping area: 1,350x500
max. table load: 800kg/m²
Tool holder: SK40
Tool slots: 22
Spindle power: 30kW at 40% ED
Spindle speed...
9
Pallet size 650 x 350 mm
Spindle speeds 12000 rpm
C0s3u80bc
Max. spindle speeds for thread cutting 4000 rpm
No. of stations in ATC 24 (HSK 63A)
Control:
Fanuc 0IM
Equipped with:
Remote handwheel
Coolant
14
- 28 kva Isolation Transformer
- APS (ADVANCE PROCESSING SYSTEM)
- Band Filter System 600L
- Calibration ball HH KKH 100mm tall for Kinematics
- Complete Machine Enclosure
- Compressed Air through Spindle
- Compressed Air Through Spindle & TSC Prep.
- Coolant system - Lift-up Chip Conveyor
- Heidenhain CNC - TNC640
- Heidenhain Linear glass scales
- ISM (Intelligent Spindle Monitoring)
- ITC (Intelligent Thermal Control)
- ITC-5X (5-Axis Intelligent Rotary Center Control)
- KinematicsOpt
- Laser...
7
Traverses X Y Z: 660mm x 406mm x 508mm,
table size 762mm x 406mm,
maximum table load 340Kgs
10000rpm spindle,
20 station ATC,
DIN40 spindle taper,
Caidwyl8fy
spindle power 11Kw,
Hurco WINMAX control, coolant,
15
Category: Vertical Machining Center
Brand: HAAS
Model: VF3
Year: 2014
Specifications:
• Travels X / Y / Z = 1016 x 508 x 635 mm
• Table 1219 x 457 mm
• Máx weight on table 1588 Kg
• Spindle Motor 22,4kW / 30CV
• Spindle BT-40
• Coolant Tank
Options included
• Chip Conveyor (AUGER)
• High speed machining (HSM)
• Tool Magazin 24+1 tools (SMTC-24)
• Spindle 10000rpm de 22kW / 30CV direct drive (10K-40T-IN)
Qjgrf
• Automatic Air gun (AAG1)
• Hand jog LCD de 3,5” (RJH-C)
• (PFDM)
• Ma...
3
x-travel 635 mm
y-travel 510 mm
z-travel 460 mm
control 840D ShopMill Siemens
Main spindle:
turning speed range - main spindle 20 - 12.000 min/-1
power capacity - main spindel 18,9 / 14 kW
tool taper SK 40 DIN 69871
max. Torque 100 / 74 Nm
tension force 8 kN
Mnx7xxw
work table:
table surface area 790 x 560 mm
number of T-slots 4 + 1
T-slot - distance 100 mm
T-slot - width 4x 14H12 / 1x 14H7 mm
max. table load 600 kg
table height over floor 720 mm
distance spindle nose and table 120 - 580 ...
4
Hartford HV-80S X: 2060 - Y: 1016 - Z: 820 mm CNC
Chsgvitu
14
For sale is a good used CNC milling machine brand Fanuc Robodrill Alpha T21iE.
The machining center is from year 2007 with Fanuc control.
Caoyel9bcr
Machine is immediately available.
Subject to prior sale and errors.
15
Control Unit
Brand FANUC- i
Main Drive
Spindle speed range 12000
Tool taper BT40
Number of axis 5
Movement
X-Axis Movement 400 mm
Y-Axis Movement 655 mm
Z-Axis Movement 500 mm
A-Axis Movement 150 (+30 ~ -120)
C-Axis Movement 360
Workpiece
Workpiece drm over bed 400 mm
Workpiece drm over support 335mm
Table
Outer length 350 mm
Table load 250 kg
Tools
Number of index 30ea
Media
Main electronic connection 220V, 60Hz
Chip conveyor Yes
Internal cooling Yes
Control Unit
Brand FANUC- i
Main Dri...
1
Traverses X Y Z ; 711 x 406 x 394mm,
Table size 864 x 381mm,
table load 113 kgs,
rapid feedrates 61m/min,
spindle power 15Hp,
Caidtf70vm
spindle speed 10,000rpm,
spindle taper BT40,
18 station ATC,
Haas control.
x-travel:1100 mm
y-travel:600 mm
z-travel:600 mm
table-size:1250x600 mm
B9h0a2tnnj
max. table load:1000 kg
distance spindle center to column:630 mm
distance spindle center to table:125-725 mm
rapid traverse in x-y-z axis:30x24x10 m
milling feed range:1-10.000 mm/min
spindle drive:7,5/11 kW
positioning accuracy:+/- 0,005 mm
repeating accuracy:+/- 0,003 mm
tool taper:SK 40
max. tool weight:8 kg
dimensions:4000x2580x2750 mm
weight of the machine ca.:6,8 t
Brand-new CNC vertical machining center w...
x-travel 1.035 mm
y-travel 560 mm
z-travel 510 mm
control Sinumerik 810D pl Siemens
Main spindle:
turning speed range - main spindle max. 10.000 min/-1
power capacity - main spindel 11 / 7 kW
max. Torque 83 / 57 Nm
tool taper SK 40
work table:
table surface area 1.200 x 560 mm
max. table load 1.000 kg
table height over floor 720 mm
T-slots 5x 14 x 100
Tool-Presetter:
number of toolpositions 30 pos.
max. tool diameter 80 mm
max. tool-dia with free toolbox 130 mm
max. tool length 300 mm
m...
7
TABLE
- Table dimensions : 1350 x 600 mm
- Weight allowed on the table: 1200 kg
SPINDLE
- Spindle speed : 15 000 RPM
- Spindle power: 30/18,5 kW
- Spindle taper : BT40
AXIS
- Axis strokes : X = 1050 - Y = 530 - Z = 510 mm
- Rapid travers rates : X - Y - Z = 30 000 mm / min
TOOL CHANGER
- Tool changer : 30 tools
- Tool-to-tool change time : 2,34 seconds
- Max tools diameter : 80 mm
- Maximum tool length : 300 mm
- Maximum tool weight : 8 Kg
OVERALL DIMENSIONS
- Machine dimension s: 3294 x 2971 ...
9
CNC Double Column Vertical Machining Centre
CNC Control Heidenhain iTNC 530
Table size 4200 x 2040 mm
Table load 15.000 kg
Number of pallets: 1
Movement X-Y-Z-axis: 4050 / 2600 / 1070 mm
Spindle taper DIN 69871a- SK 50
Spindle speed 6.000 RPM
Number of tools in magazin: 60 pieces
B8xjtkjbeg
If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.
Feel free to view our other advertisements for a complete overview of our stock.
4
Control Unit
Brand HEIDENHAIN
Model iTNC530
Main Drive
Spindle speed range 100 - 18000
Spindle motor power 25 kW
Tool taper HSK 63 A
Number of axis 3
Movement
X-Axis Movement 1000 mm
Zrajrwxn
X-Axis Rapid Traverse 30000 mm/min
Y-Axis Movement 700 mm
Y-Axis Rapid Traverse 30000 mm/min
Z-Axis Movement 550 mm
Z-Axis Rapid Traverse 18000 mm/min
Table
Outer length 1250 mm
Outer width 700 mm
Media
Main electronic connection 400 V / 50 Hz
Chip conveyor Yes
Internal cooling Yes
This Huron kx10 Vert...
3
Traverses X Y Z: 355 x 305 x 455mm,
Table 457 x 381mm,
Spindle speed 50 – 6000 rpm,
Spindle taper BT30,
Qiycb
Spindle Motor 3Hp,
Prototrak TMX Control,
8 Station ATC, coolant, Low Volt light.
10
x-axis 1250 mm
y-axis 840 mm
z-axis 550 mm
control Siemens 840D
turning speed range - main spindle 12000 min/-1
drive capacity - main spindle 22,5 kW
Torque max. 140 Nm
Number of tools 24 St.
max. tool length 320 mm
spindle taper HSK 63
Number of working hours 56000 h
spindle hours 17500 h
weight of the machine ca. 9,7 t
This machine can be viewed under power by appointment and
is in our estimation in very good condition.
Furnishing:
- IKZ
- chip conveyor
- Glass measuring rods in all axes...
x-travel 630 mm
y-travel 560 mm
z-travel 560 mm
control TNC 530 Heidenhain
Main spindle:
turning speed range - main spindle 20 - 12.000 min/-1
power capacity - main spindel 15 / 10 kW
max. Torque 130 Nm
tool taper SK 40
feed:
feed speeds 20 - 10.000 mm/min
rapid traverse X-axis 26 m/min
rapid traverse Y-axis 26 m/min
rapid traverse Z-axis 20 m/min
Resolution 0,001 mm
input unit 0,001 mm
work table:
surface area 1.000 x 600 mm
number of T-slots 9
T-slot - width 14 H7
T-slot - distance 63...
x-travel: 762 mm
y-travel: 510 mm
z-travel: 560 mm
control: Heidenhain TNC 415 BR
tool piece magazine with: 21 place
table surface area: 865x510 mm
table load capacity: 455 kg
tool taper: SK40
O2d0e0uh
spindle turning speed range: 60-8000 U/min
feed: x/y/z:15000 mm/min
compressed air: Bedarf: 5,5 bar
total power requirement: 30 kW
weight of the machine ca.: 4,3 t
dimension machine xH: 4,0 x 2,8 x 2,4 m
Machining Center with ATC (automatic tool changer)
coolant through spindle (CTS)
swarf- and co...
10
travel -x axis 1.020 mm
travel -y axis 600 mm
travel -z axis 560 mm
table dimension (L x W) 1.200 x 635 mm
table load 1.000 kg
control HEIDENHAIN
number of spindle speeds 10.000 U/min
tool taper MAS BT 40
numbers of tools in magazin 24
Dimensions (L x W x H) 2.650 x 2.200 x 2.825 mm
weight of the machine 7.500 kg
Vertical - milling machining centers | QUASER - MV204 II
C2hblnoc
Additional equipment:
+ ICZ
+ 4.axis (dividing head)
+ Chip conveyor
Scope of delivery:
- package of tools
The...
13
Main Drive
2t7xom
Spindle speed range 10000
Movement
X-Axis Movement 1000 mm
X-Axis Feed Force 6000 N
X-Axis Rapid Traverse 30 m/min
Y-Axis Movement 600 mm
Y-Axis Feed Force 6000 N
Y-Axis Rapid Traverse 30 m/min
Z-Axis Movement 600 mm
Z-Axis Feed Force 6000 N
Z-Axis Rapid Traverse 30 m/min
Table
Outer length 1200 mm
Outer width 600 mm
Height adjustment 340 mm
Table load 800 kg
This DECKEL MAHO DMC 103 V Vertical Machining Center was made in 2004 in Germany. It has been on for 24172 hours, of ...
4
Traverses X Y Z: 2134 x 1016 x 762mm,
2udx7y
Table 2134 x 914mm,
Spindle Speed 8,100 rpm,
Spindle taper BT40,
Spindle Motor 30Hp,
HAAS Control,
30 Station ATC,
through spindle coolant, low volt light, swarf auger, WIPS, 4th axis interface.
3
x-travel:2360 mm
y-travel:600 mm
z-travel:1000 mm
table surface area:2500 x 640 mm
control:TNC 430 A HEIDENHAIN
spindle turning speed range:8000 1/min
spindle motor:35 kW
spindle taper:SK 40
tool change unit:76 ( 2x 38 ) Pos.
:69 kW
dimensions:5,5 x 2,4 x 2,9 m
weight of the machine ca.:14 t
traveling column m/c (two table machining possible)
incl. 2 pcs. NC-dividing devices (left / right side), dia. 300mm,
chipconveyor
el. handwheel
coolant box and paper filter
new monitor
Cri23gkhc
approx....
7
x-travel 600 mm
y-travel 525 mm
z-travel 500 mm
control MillPlus M Heidenhain
Main spindle:
turning speed range - main spindle max. 12.000 min/-1
power capacity - main spindel 10 / 15 kW
tool taper SK 40
work table:
table surface area 900 x 543 mm
max. table load ca. 350 kg
Cxp0rxuc
number of T-slots 8
T-slot - distance 63 mm
Tool-Presetter:
tool taper SK 40
number of toolpositions 25 pos.
total power requirement 22 kW
weight of the machine ca. 5,0 t
dimensions of the machine ca. 4,5 x...
6
Vertical machining center YANG Cabinet HEIDENHAIN 410 Travel: 1020 x 550 x 610 mm Table dimensions: 1250 x 560 mm Table weight: 600 kg Spindle power 15 kW Random log 24 sets BT 40 Electronic flywheel Dimensions: 2800 x 2400 x 2980 Weight: 6500 kg
Bzzd7pcm
5
x-travel 600 mm
y-travel 450 mm
z-travel 450 mm
CNC-control TNC 426 HEIDENHAIN
table-size 850 x 530 mm
max. table load 400 kg
spindle taper HSK 63-A
spindle turning speed range 20.000 U/min
feed stepless 15.000 mm/min
rapid traverse 22 m/min
drive capacity - spindle motor 12 kW
tool change unit 30 Pos.
coolant
B3u8mnt
voltage 400 V
total power requirement 40 kW
weight of the machine ca. 6,5 t
dimensions of the machine ca. 1,65 x 3,35 x 2,65 m
- .: 107.30.98.040
- control: TNC426
- 3D mea...
15
General Data
Measurements width 3200 mm
Measurements depth 2800 mm
Measurements height 2750 mm
Machine weight 4500 kg
Control Unit
Brand HEIDENHAIN
Model TNC 426
Main Drive
Number of spindles 1
Spindle speed range 50 - 16000
Spindle motor power 11 kW
Number of axis 3
Movement
X-Axis Movement 685 mm
X-Axis Feed Force 6000 N
X-Axis Rapid Traverse 12 m/min
Y-Axis Movement 315 mm
Y-Axis Feed Force 6000 N
Y-Axis Rapid Traverse 12 m/min
Z-Axis Movement 540 mm
Z-Axis Feed Force 12000 N
Z-Axis Rapid ...
3
Traverses X Y Z: 2134 x 1016 x 762mm,
Table 2134 x 914mm,
Spindle Speed 8,100 rpm,
Spindle taper BT40,
Spindle Motor 30Hp,
St7qzdvs
HAAS Control,
24 Station ATC,
through spindle coolant, low volt light, swarf auger,
6
x-travel: 400 mm
y-travel: 300 mm
z-travel: 400 mm
spindle revolutions per minute : 8000 U/min
control: Fanuc OM
clamping table: 500x300 mm
magazine slots: 16 Stück
tool taper: SK40
Ytyu8h9k
distance work spindle /surface of the table max.: 50-450 mm
numbers of pallets: 2 Stück/part
total power requirement: 10 kW
weight of the machine ca.: 2,5 t
dimension machine xH: 2,4x1,8x2,5 m
transport measurements machine: 2,45x1,8x2,5 m
- electric cabinet
- coolant device
- swarf conveyor
4
x-travel 1000 mm
y-travel 800 mm
z-travel 700 mm
Control HEIDENHAIN iTNC 530
total power requirement 50 kW
weight of the machine ca. 16 t
dimensions of the machine ca. m
83aukjrp0
6
installed 2013
Fanuc 31i Model B control
c/w High speed machining software AICC
Movements:
X-axis: 1.020 mm
Y-axis: 610 mm
Ibl2zfh
Z-axis: 610 mm
Table size; 1.200 mm x 600 mm
Spindle motor 22/15 kW
Max. spindle speed 15.000 rpm
BT-40
Tool magazine for 30 tools
Renishaw NC4 Laser (tool laser)
Renishaw spindle probe interface (no probe body)
Coolant through spindle, 20 bar
Swarf conveyor
CE-mark
7
Crs : 730 x 850 x 560 mm Table Diam 800 x 630 mm Spindle 18000 rpm HSK 63, magazine 40 tools, pack 5 axes simultaneous, High pressure center spraying, RENISHAW RMP 600 probe, conveyor belt.
Biuzcwjm
CNC SMOOTHX.86 machining hours available immediately
8
General Data
Measurements width 2788 mm
Measurements depth 3040 mm
Measurements height 2603 mm
Machine weight 6350 kg
Control Unit
Brand Mori Seiki
Model MSG-501
B8nu8rbour
Main Drive
Number of spindles 1
Spindle speed range 14000
Number of axis 4
Movement
X-Axis Movement 787 mm
Y-Axis Movement 508 mm
Z-Axis Movement 508 mm
Workpiece
Workpiece weight 300 kg
Table
Outer length 1100 mm
Outer width 600 mm
Tools
Slots in storage 30
Type of tool holder BT40
Media
Main electronic connection 400...
8
Table size 1600 x 650 mm
X/Y/Z - 1200/650/860 mm
No. of stations in tool changer 30 pcs.
Dawghodkm
Spindle speeds 6000 rpm
Motor power 15 Kw
Control:
Enac I (Yasnac i80MB)
14
X travel 700 mm
Caoidfwjex
5
x-travel 450 mm
y-travel 400 mm
z-travel 400 mm
control Heidenhain TNC 310
distance spindle nose and table min. 100 mm
table height over floor 810 mm
table surface area 400 x 900 mm
no. of flutes 5 je 14 mm
work piece dimensions max. 450 x 400 x 300 mm
workpiece weight max. 350 kg
turning speeds: 9000 U/min
power requirement 7,5 / 8,2 kW
spindle cone ISO 40 DIN 69871
spindle diameter in front bearing 60 mm
tool numbers 12
diameter of tools max. 80 mm
tool length - max. 200 mm
weight of tools...
9
x-travel 550 mm
y-travel 300 mm
z-travel 425 mm
Control Siemens840D solution line
main spindle:
max. turning speeds 10000 min/-1
tool changer:
tool taper SK 40
number of tool places 20 Pos.
weight of the machine ca. 4,2 t
dimensions of the machine ca. L 3,8 x B 3,65 x H 2,85 m
In our estimation, the machine is in very good condition
and can be viewed live by appointment.
Technical features:
- complete retrofit in 2014
Accesories:
B9cunwyj7u
- 4th axis, manufacturer: Peisler
- Coolan...
