Floor type boring and milling over 161mm spindle diameter for sale
Control: HEIDENHAIN TNC 426 M
spindle diameter: 180 mm
x-travel: 8,000 mm
y-travel: 3.500 mm
Z-axis travel (beam): 1,400 mm
traverse path - W-axis (drilling spindle): 1,000 mm
travel - V axis (table adjustment): 2,800 mm
headstock cross section: 400 x 600 mm
Clamping surface of the table: 2.500 x 2.500 mm
Max. table load: 30 t
Speed range: 5 - 1.000 min -1
Feeds X,Y: 1 - 6,000 mm/min.
Feeds Z, W: 1 - 3,000 mm/min.
Drive power: 55 kw
Erlrvzlea
Equipment:
- ISO 60 tool holder (ISO 50 with adapter...
7
Catalog No. : 5506
Type: W 200 HA
Producer: ŠKODA
Made in: 1984
Plvk7
Characteristic:
Speed: 0.8-630 1/min
X-Axis travels: 15000 mm
Y-Axis travels: 3150 mm
Z-Axis travels: 1600 mm
Taper: M120
Spindle diameter: 200 mm
Maximum boring depth: 2000 mm
Power input: 77 kW
Equipment:
Rotary table (2x2m)
Floor plate (6400x5100mm)
6
Spindle diameter 200mm
X stroke 120,000mm
Y stroke 5,500mm
Z stroke 1,200mm
W stroke 1,100mm
Spindle taper NT50
Spindle speed 600rpm
Main Motor 75kw
X and Y axis is organized ball screw and Linear scale on Hydro static
Rotary table 70tons
Clamping plate 3000 x 3000mm
V stroke 1000mm
B axis 0.001 degree
Ps7hh
Floor Plate
Angular Milling head, x 1
High speed Head (1500rpm)
Multi drilling Attachment
4
Juraristi 205 M panel boring machine,
Year of manufacture 1993,
Control Heidenhain TNC 355,
Travel X/Y/Z/W 10,000/2,500/1,250/500 mm,
Spindle Ø 205 mm,
Shooting ISO 50,
Spindle speed up to 700 rpm
Milling power 37 KW,
optionally with panel fields 5000 x 2000 mm,
and 6400 x 1875 mm,
Beyzwat
13
SCHIESS FRORIEP - 1FB180
CNC Horizontal borer 18500 x 4500 x 950 x 900 mm iTNC530
MACH - ID 6675
Make: SCHIESS FRORIEP
Type: 1FB180
Control: HeidenHain iTNC530
YOP: 2006
Hydrostatic guideways
Hydrostatic spindle bearing
Pick place head change station
1 = Facing head with U-Axis
2 = Universal milling head
3 = Boring Spindel support
4 = Vertical milling head
Specifications
US Standard Metric
X – Travel
18.500 mm
Y – Travel
4.500 mm
Z – Travel
Byivgz8vyw
950 mm
W – Travel
900 mm
Table Length
20...
5
Year of manufacture Construction year 1983
Drive power Drive power 83 kW
Clamping table Clamping table 2500 x 2500 mm
Bjyhlt29u
Max. workpiece mass on table Workpiece mass 20 t
Processing width on table Processing width on table 5770 mm
Processing height on table Processing height on table 2800 mm
Max. machining depth Processing depth 1985 mm
Spindle diameter Spindle diameter 200 mm
Slide cross-section Slide cross-section 530 x 550 mm
Additional equipment Additional equipment Angle head large
...
4
Spindle diameter: 200 mm
Spindle extension: 400 mm
x-way: 8000 mm
y-way: 3150 mm
z-way: 1600 mm
Support sleeve dimensions: 520 x 540 mm
Recording: ISO60
Bjgtfapdho
Torque d. Spindle: 34,300 Nm
Bed guide width: 2000mm
Spindle drilling depth: 2000 mm
Catalog No. : 5481
Type: W 250 HA
Producer: ŠKODA
Made in: 1985
Characteristic:
Control system: MEFI
Power of the spindle drive: 77 kW
Minimum rotary speed of the spindle: 0.8 1/min
Maximum rotary speed of the spindle: 630 1/min
X-Axis travels: 8000 mm
Y-Axis travels: 6000 mm
Z-Axis travels: 1600 mm
Maximum feed rate in X-axis: 4000 mm/min
Maximum feed rate in Y-axis: 4000 mm/min
Maximum feed rate in Z-axis: 4000 mm/min
Taper: M 140
Spindle diameter: 250 mm
Maximum boring depth: 200...
15
Borer horizontal, H-floor type W 200 H CNC
Producer: Škoda machine tool
YP 1980/ overhauled 2013
Control Heidenhain ... TNC 530
Spindle diameter ... 200mm
Axis X ... 8150mm
Y axis ... 3300mm
Spindle speed ... 1-630 / min.
Axis W ... 2000mm
Spindle mount ... Metric 120.
Axis V ... 1600mm
Main Moro power ... 75kW
Machine weight ... 93800kg
3faobapj
L x W x H ... 10000 x 4000 x 8320mm
In 2013 there was a complete general overhaul.
The machine is in good condition and can be tested under power.
1
Horizontal Traverse 11.000 mm
Vertical Traverse 4.500 mm
Main axis diameter 180 mm
Head speed (NEW CONDITION) 1.500 rpm
RAM 400 x 400 mm
RAM Exit 900 mm
Salida de caña 1.200 mm
2lim29tyt
Mesa giratoria 3.000 x 3.000 mm
Recorrido transversal mesa giratoria 2.000 mm
Swing table carrying load 60 Tn
Head power 80 kW
Equiped With
Universal head 1º x 1º
CNC FAGOR 8055 M
Electronic handwheel
2 sets of 6.000 x 4.000 mm plates
4
Travels:
X-axis 9.500 mm
Y-axis 4.100 mm
Z-axis 950 mm
W-axis 900 mm
Main spindle speeds (infinitely variable) 3,15 to 1000 rpm
Spindle motor power 58 kW
Feed range (infinitely variable):
X-axis 0,1 - 9600 mm/min
Y-axis 0,1 - 5600 mm/min
Z-axis 0,1 - 5600 mm/min
W-axis 0,1 - 5600 mm/min
D83wbr0z
Accessories
- Floor plate 6 x 4 m (CNC controlled B- and V-axis)
- Table 2 x 2 m
14
Spindle size: dia 200 / ISO 60
X travel: 9.000 - 22.000 mm
Y travel: 4.000 - 5.000 mm
Z travel: 1200 mm
W travel: 1500 mm
Bxiuasgo
Spindle speed: 700 RPM
Rotary table:
- Surface: 3500 x 3500 mm
- Travel: 2900 mm
8
Twin column floor borer INNSE yom 1979 retrofitted and upgraded with Siemens 840D in 2012
Boring spindle diameter 221 mm
Milling spindle diameter 280mm
X-way 18000 mm
Y-way 5000 mm
Z-way 1500 mm
W-axis 1500 (RAM) mm
ISO 60 Spindle
Main motor power 130KW
Total Power 270KW
Br8s2ah3df
Equipped with :
- Rotary table 5000x4000mm travel 3000mm with hydraulik sustentation max. load on table 150ton
- 16pcs floor plates 6000x2000x400mm
- 3 milling heads
- Faceplate
For more information please contact ...
9
Catalog No. : 5550
Type: W 200 HB NC
Producer: ŠKODA
Made in: 1986
Characteristic:
Control system: Siemens Sinumerik 840 D
Maximum lenght of the workpiece: 16000 mm
Max. workpiece width: 5445 mm
Max. workpiece weight: 140000 kg
Power of the spindle drive: 150 kW
Speed: 0.8-630 1/min
X-Axis travels: 8000 mm
Y-Axis travels: 2000 mm
Z-Axis travels: 4990 mm
Dgeag72v
Maximum feed rate in X-axis: 6000 mm/min
Maximum feed rate in Y-axis: 3000 mm/min
Maximum feed rate in Z-axis: 6000 mm/min ...
15
ITEM : CNC Horizontal Boring Machine
MAKE : INGERSOLL
YEAR : 1979 / 2017 RETROFITTED
SPECIFICATION :
CNC Control : Fanuc 15MA
Spindle dia. : 200 mm
X-Axis : 12,000 mm
Y-Axis : 5,500 mm
Z-Axis : 1,200 mm
W-Axis : 1,100 mm
B-Axis : 2,000 mm x 2,500 mm
V-Axis Travel : 2,000 mm
Taper of boring spindle : 7/24 taper NT 50
Spindle speed : 1 - 600 (min-1)
Ram size : 800mm x 800mm
Max. workpiece weight (Floor) : 100 ton
Main drive motor : 75 KW
ATC : Manual / Draw Bolt
Equipment :
Chip conveyor, Angl...
4
spindle diameter 203,2 mm
x-travel 9.000 mm
y-travel 4.000 mm
grinding spindle dia. 335 mm
spindle taper ISO 60
spindle turning speed range 1-350 / 5-1.200 U/min
w-axis 800 mm
z-axis 1.200 mm
rapid travel X-axis 8.000 m/min
rapid travel Y-axis 6.000 m/min
RAM dimensions 530 x 600 mm
Main drive 75 kW
total power requirement 165 kW
weight of the machine ca. 130 t
dimensions of ...
6
Horizontal boring machine SHIBAURA BSF34/23A spindle dia. 230mm X=13M Y-5M with rotary table 4000x5000 mm 60ton and floor plates retrofitted and upgraded with Siemens CNC in 2018.
Gfmyoeal
For more information please contact us.
Catalog No. : 5479
Type: PC W 200 HA
Producer: ŠKODA
Made in: 1987
Characteristic:
Power of the spindle drive: 77 kW
Minimum rotary speed of the spindle: 0.8 1/min
Maximum rotary speed of the spindle: 630 1/min
Travel length X-axis (mechanical feed): 5000 mm
Travel length Y-axis (mechanical feed): 4000 mm
Travel length Z-axis (mechanical feed): 1600 mm
Maximum feed rate in X-axis: 4000 mm/min
Maximum feed rate in Y-axis: 4000 mm/min
Maximum feed rate in Z-axis: 4000 mm/min
Taper: ISO 6...
