Condition: used, Year of construction: 1969, weight 10 t ja facing slide ja milling head ja Celqjwg Hu Ij Nrq Tegt ja spindle diameter 90 mm diameter Tisch 2000 mm

Condition: new, BRAND NEW MACHINE HEIDENHAIN TNC 640 Digital Contouring Control HEIDENHAIN package (motors, encoders, and handwheel) X-axis: 3,000 mm Y-axis: 1,300 mm Z-axis: 1,500 mm Rotary table: 1,600 x 1,200 mm Maximum workpiece weight: 6,000 kg Automatic universal swivel head 1° x 1° (optional with fixed spindle Ø 210 mm) Spindle mount: SK50 DIN 69871/A Max. spindle speed: 6,000 rpm (oil-cooled) Max. spindle motor power: 53 kW Internal coolant supply - 36 bar Rapid traverse X, Y & Z: 30 m/min Positioning accuracy: 0.015 mm Cgolq Nrqjq I Ncqj Tst Repeatability: 0.010 mm 40-station tool changer 2 x longitudinal hinged chip conveyors Perimetric cover Only inquiries from Germany will receive a response /// Only inquiries from Germany will be processed

Condition: used, bore capacity in steel (diameter) 40 mm throat 360 mm bore stroke 240 mm Cgslq Novtgv Horq Tet total power requirement 2,5 kW weight of the machine ca. 1100 kg dimensions of the machine ca. 1100 x 800 x 2300 mm

Condition: excellent (used), Year of construction: 1955, Drilling capacity in steel St 37 Ø 65 mm Drilling capacity in cast iron Ø 75 mm Spindle mount MT 5 Throat 1250 mm Spindle stroke 400 mm Spindle speeds 22.4 – 1800 rpm Feed range 0.056 – 0.56 mm/rev Column diameter Ø 300 mm Motor power, 2-stage: 3.6 / 4.8 kW Clamping surface, base plate 1320 x 1000 mm Dimensions L x W x H (with motor!) 2250 x 1000 x 3100 mm Transport dimensions L x W x H (without motor!) 2250 x 1000 x 2800 mm Weight 5100 kg Accessories / Special features: • Cube table L x W x H 650 x 500 x 500 mm • Central clamping • Feed • Right-to-left travel • Motorized up and down travel • High speed range up to 1800 rpm • Coolant system • Lighting Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel Cjlq Nrqotwzk De Tjgt

Condition: used, Year of construction: 1986, spindle diameter 225 mm x-travel 21900 mm y-travel 6000 mm z-travel 1900 mm table dimension - longitudinal 4500 mm table dimension - cross 4500 mm table load 140 t floor-plate length 6000 mm floor-plate width 2000 mm floor-plate height 400 mm no. of tables 9 V-axis 2450 mm ram head dimension 800 x 400 mm z-axis 1500 mm Control SIEMENS 840D spindle turning speed range 800 U/min spindle taper ISO 60 / 50 table rotating 360 ° total power requirement 100 kW dimensions of the machine ca. 25 x 12 x 7 m This SCHIESS FB225 panel boring machine has: - 9 plate fields each with LxWxH: 6000 x 2000 x 400mm Cgjlq Nrewgwnrsq Tet - 1 turntable with 4500 x 4500mm and 140ton table load The machine can be inspected under power by arrangement with the seller.

Condition: new, Solberga SE2035 - Geared drilling machine - Drill head can be swiveled 360° around the column and is height-adjustable - Gearbox built with traditional and tested technology for the highest possible torque - helical gears made of steel reinforced with fiber material offer high efficiency, a low noise level, long service life and a virtually maintenance-free gearbox - Spindle made of steel - ensures optimum concentricity of the tool thanks to its adjustable tapered rollers (ball bearings) - Adjustable spindle return spring - the return force can be adapted to the weight of the tool - automatic feed (model M) - when the preset drilling depth is reached, the spindle returns to its starting position (the feed gear is equipped with automatic overload protection and can also be interrupted manually) - Electromagnetic feed and automatic tapping device (ME model) - high-quality cast-iron rectangular table (500 x 400 mm) with T-slots and oil channel - height-adjustable and can be swiveled 360° around the column - Steel drilling column - guarantees lasting stability of the machine and high precision and angular accuracy between drill and table - Base plate with T-slots and oil channel - Equipped with thermal overload protection, power failure protection and emergency switch Optional equipment - LED work lighting - Tool set for MK4 - Machine vice 150 mm jaws - 2 x T-slot stones - Drill chuck 1 - 13 mm B16 Metabo, arbor MK4 - Reducing sleeve MK4 / MK3 - Reducing sleeve MK4 / MK2 - Reducing sleeve MK4 / MK1 - Automatic tapping device - Complete coolant unit - Foot-operated tapping device - Foot-operated on/off switch for spindle motor - Spindle nose with thread for tool holder - Cross table FB102 584x242 mm, longitudinal movement 415 mm, transverse movement 155 mm - Drill chuck 0 - 13 mm with arbor MK4 - Drill chuck 3 - 16 mm with mandrel MK4 - Special finish Technical specifications - Drilling capacity: 35 mm - Quill stroke: 150 mm - Tapping capacity (steel / cast iron): M 18 / M 22 - Spindle holder: MK4 - Spindle speed: 85 - 3160 rpm - Gear stages: 8 - max. distance spindle/table: 820 mm - max. distance spindle/base plate: 1150 mm - throat depth: 320 mm - Drill table size: 500 x 400 mm - Column diameter: 127 mm - Motor power: 1.6 kW Cgjlq Nrjuzhx Aeq Tet - Voltage: 400 V - Dimensions WxHxD: 500 x 1785 x 700 mm - Weight: 290 kg

Condition: used, Year of construction: 1988, control Heidenhain 355 tool adaptor SK50 weight of the machine ca. 8 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. Cgslef Tdvboq Nrq Tjt +++++

Condition: new, BRAND NEW MACHINE HEIDENHAIN TNC 640 Digital Contouring Control HEIDENHAIN package (motors, encoders, and handwheel) X-axis: 4,000 mm Z-axis: 2,000 mm Y-axis / Cross-arm: 1,500 mm V-axis / Cross-column: 1,000 mm Rotary table (C-axis): 2,195 x 2,195 mm Max. load capacity up to 20,000 kg Automatic universal swivel head 1° x 1° (optional with fixed spindle Ø 210 mm) Spindle mount: SK50 DIN 69871/A Cgoleq I Nlyeq Nrq Tot Spindle speed: 6,000 rpm (oil-cooled) Max. spindle motor power: 53 kW Internal coolant supply - 36 bar Rapid traverse speeds X, Y, V & Z: 30 m/min Positioning accuracy: 0.020 mm Repeatability: 0.010 mm Tool changer: 60-station Double-hinge chip conveyor (longitudinal) Perimetric enclosure Only inquiries from Germany will receive a response /// Only inquiries from Germany will be processed

Condition: used, Functionality: not functional, Pictures show : 2-spindle drilling head , pneumatic clamping device , hydraulic feed device . Technical data : Continuous drilling capacity 50 mm Normal drilling capacity 65 mm Spindle motor , pole-switchable 3 / 5 kW Cgjlq Nrqewg A Rxe Tst 4 infinitely variable speed ranges Gear stage 1 50 - 375 and 100 - 750 rpm Gear stage 2 100 - 750 and 200 - 1500 rpm Distance from spindle nose to table approx. 800 mm Spindle stroke 200 mm Column diameter 160 mm Projection 325 mm Entire table 650 x 500 mm Height approx. 2.1 m Normal weight approx. 0.7 to . Equipment and scope of delivery : - Table clamping from the front - Coolant device - Electric cabinet - without table height adjustment - Hydraulic feed device - the hydraulic unit is missing ! (drill feed can be operated manually via a cross lever)

Condition: excellent (used), Year of construction: 1955, Make: RABOMA KOLB Year of manufacture: 1955 / Overhauled 1991 Horizontal travel: min. 930 mm / max. 4100 mm Cjlq Nrqsum I Sxo Tsgt Vertical travel: min. 900 mm / max. 2300 mm Spindle travel: 650 mm Spindle diameter: 120 mm / MT 6 chuck Spindle speed: 1000 rpm Machine dimensions: 5600 mm x 1800 mm x 5500 mm Total weight: approx. 33 tons.

Condition: good (used), Distance from table to nose: Max (mm) 740 Min (mm) 290 Distance from spindle axis to vertical face of upright: 400mm Spindle motor power: 4 KW Spindle : Stroke 325mm Cslq Nrqeummkme Tsgt Diameter: 70mm Cone N°: CM4 Dimensions LxWxH : 1700 x 1500 x 250mm Net weight: 1500kg

Condition: new, - Drill head can be swiveled 360° around the column and is height-adjustable - Gearbox built with traditional and tested technology for the highest possible torque - helical gears made of steel reinforced with fiber material offer high efficiency, a low noise level, long service life and a virtually maintenance-free gearbox - Spindle made of steel - ensures optimum concentricity of the tool thanks to its adjustable tapered rollers (ball bearings) - Adjustable spindle return spring - the return force can be adapted to the weight of the tool - automatic feed (model M) - when the preset drilling depth is reached, the spindle returns to its starting position (the feed gear is equipped with automatic overload protection and can also be interrupted manually) - Electromagnetic feed and automatic tapping device (ME model) - high-quality cast-iron rectangular table (500 x 400 mm) with T-slots and oil channel - height-adjustable and can be swiveled 360° around the column - Steel drilling column - guarantees lasting stability of the machine and high precision and angular accuracy between drill and table - Base plate with T-slots and oil channel - Equipped with thermal overload protection, power failure protection and emergency switch Optional equipment - LED work lighting - Tool set for MK4 - Machine vice 150 mm jaws - 2 x T-slot stones Cgslq Nrovb Hdgsq Tet - Drill chuck 1 - 13 mm B16 Metabo, arbor MK4 - Reducing sleeve MK4 / MK3 - Reducing sleeve MK4 / MK2 - Reducing sleeve MK4 / MK1 - Automatic threading device - Complete coolant unit - Turning device for table 400 x 500 mm - Foot-operated on/off switch for spindle motor - Spindle nose with thread for tool holder - Lower spindle speeds 60 - 980 rpm - Higher spindle speeds 180 - 3000 rpm - Cross handle with 3 levers - Cross table FB102 584x242 mm, longitudinal movement 415 mm, transverse movement 155 mm - Milling cutter chuck ER, MK4, 5, collets 6, 8, 10, 12 and 20 mm - Drill chuck 0 - 13 mm with arbor MK4 - Drill chuck 3 - 16 mm with mandrel MK4 - Special finish Technical data: - Drilling capacity: 40 mm - Quill stroke: 190 mm - Tapping capacity (steel / cast iron): M 24 / M 28 - Spindle holder: MK4 - Spindle speed: 90 - 1500 rpm - Gear stages: 8 - max. distance spindle/table: 830 mm - max. distance spindle/base plate: 1210 mm - throat depth: 330 mm - Drill table size: 500 x 400 mm - Column diameter: 140 mm - Motor power: 2.6 kW - Voltage: 400 V - Dimensions WxHxD: 500 x 2120 x 750 mm - Weight: 310 kg

Condition: used, Year of construction: 1979, taper MK MK5 Cgolsf Ek Risq Nrq Tot round table ja weight of the machine ca. 1.200 kg +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: new, Technical data: Drilling capacity in steel: 50 mm Tapping capacity: M33 face milling cutter: 100 mm end mill: 25 mm spindle: MK 4 throat depth: 340 mm Speeds: (6) 50 - 1510 1/min quill stroke: 200 mm quill feed: 0,1 / 0,2 / 0,3 / 0,4 mm/rev table size: 820 x 240 mm Colq Nrqepxmlqs Tegt traverse path X: 460 mm traverse path Y: 280 mm column diameter: 180 mm Number of T-slots: 4 T-slot size: 16 x 26 mm motor power: 3 kW Weight, approx.: 750 kg Equipment: - Cross table - thread tightening spindle - Thread cutting device - Automatic spindle feed - LED machine light - Rotatable table - Manual fine feed - Coolant device - Height adjustable protective cover - Limit switch protected spindle

Condition: used, Price: On request Celq Nrqjwfpbbe Tegt - Documentation available: No - Control: Conventional - Drilling depth: 150mm - Model: ördinatenboor - Digital readout: Yes - Table width: 1500mm - Table length: 2200mm - Travel X: 2500mm - Travel Y: 1400mm - Spindle diameter: 100mm - Travel Z: 1000mm - Number of axes: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: new, bore capacity in steel (diameter) 28 mm throat 250 mm bore stroke 130 mm morse taper 3 MK table: 380 x 380 mm Cgjlq Nrqjprfbue Tst turning speeds 75 - 3200 U/min thread M16 ST60 column diameter 98 mm engine output 1,1 kW dimensions 800 x 500 x 2000 mm weight 210 kg - automatic drill feeds (magnetic clutch) - Height adjustable and angle adjustable table - Movable work table - Integrated cooling system - Powerful engine - 3 hand levers for drilling feed - Safety shield with limit switch - Separate emergency stop - Built-in working lights - Incl. drill chuck 16mm - B16 - Built-in automatic thread cutting.

Condition: excellent (used), GSP M 743 mortising machine Stroke (mm): X450 Y500 Slide travel (mm): 300 Max. table tool distance (mm): 450 Cgelqsulfuze Nrq Tjt Gooseneck (mm) : 590 Slot width 25 30 mn Table diameter (mm): 700 Feed speed (mm/mm): 0.1-2.5mm/Cp Main motor power (HP): 6 Machine equipped with : Automatic feeds/Slide tilting Dimensions WxDxH (mm) : 2300x1700x2600 Machine weight (T) : 3.5 Overall dimensions 2500x 2200 height 2400

Condition: new, Special price €2,800 instead of €3,340 excl. VAT - Precise drilling depth adjustment - Suitable for drilling and tapping (optional) - The drilling table is height-adjustable and can be rotated around the column - Made in Sweden Specifications - Drilling capacity: 25 / 28 mm - Spindle stroke: 130 mm - Tapping capacity (steel / cast iron): M 16 / M 20 Cslq Nrqou Tq Ste Togt - Spindle mount: MT3 - Spindle speed: 129 - 1498 rpm - Gear ratios: 4 - Max. spindle/table distance: 730 mm - Throat depth: 255 mm - Drilling table size: 500 x 400 mm - Column diameter: 100 mm - Motor power: 0.65 kW - Voltage: 400 V - Dimensions W x H x D: 500 x 1720 x 500 mm - Weight: 185 kg

Condition: used, Year of construction: 1980, table length 550 mm table width 550 mm table swivelabel +/- 90 ° no. of flutes 4 weight of the machine ca. 600 kg +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. Cjlqegvi I Aj Nrq Tsgt +++++

Condition: used, Functionality: fully functional, General overhaul 2007 Cgjlq Nrjwf Dv Hoq Tot Operating hours since overhaul: 1,001 hours Control: Siemens touch panel with TIBO drilling program (simple version - Siemens TP 177 A with Siemens S7-200 PLC) Drilling method: Single-lip drilling Number of spindles: 1 Solid drilling: Ø 4.0 - Ø 35.0 (Max. !!!) Nominal drill depth: 500 mm Maximum drill depth: 737 mm Maximum drill length: 1,100 mm Drill diameter: Rotationally symmetrical parts: Ø 10 - Ø 136 mm Maximum workpiece length: 650 mm Spindle drive: 7.5 kW Speed range: 100 - 4,000 rpm Working feed: 35 - 320 mm /min Rapid traverse: 3500 mm /min Coolant system: Capacity: 1000 liters. High-pressure pump: 5 - 91 liters /min Paper belt filter Chip conveyor - permanent magnetic Air cooler (unused because only aluminum was processed)

Condition: used, Year of construction: 1988, Drilling capacity in steel St 60 28 mm Drilling capacity in cast iron GG 20 35 mm Drilling capacity in St 60 35 mm Spindle mount MT 3 Throat 290 mm Quill stroke 160 mm Table stroke 592 mm Celqjwgkyuj Nrq Togt Column diameter 115 mm Clamping area 510 x 300 mm Spindle speed 130-1750 rpm Machine weight approx. 400 kg

Condition: new, bore capacity in steel (diameter) 32 mm throat 300 mm bore stroke 160 mm morse taper 4 MK table: 460 x 460 mm turning speeds 75 - 3200 U/min engine output 1,5 kW column diameter 125 mm thread M16 ST60 feed 0,10/0,18/0,26 mm/U dimensions 800 x 500 x 2200 mm weight 350 kg - automatic drill feeds (magnetic clutch) - Height adjustable and angle adjustable table - Movable work table - Integrated cooling system - Powerful engine - 3 hand levers for drilling feed - Safety shield with limit switch Cslekahu Roq Nrq Togt - Separate emergency stop - Built-in working lights - Incl. drill chuck 16mm - B16 - Built-in automatic thread cutting.

Condition: ready for operation (used), travel distance X-axis: 7,000 mm, Conventional borer with ballscrews, Skoda license production Slides are in excellent condition (flower texture still visible = very little wear) ram size: 380 x 380 mm Weight of column: 20 ton Weight of bed: 22 ton Weight of head: 10 ton Weight of turntable: 12 ton Optional equipment: - 3 milling heads - 3 cabinets with tooling - lengthening piece for spindle Cgslq Nrqewdy R Rj Tot - turntable - 2 floorplates 5000 x 2000 x 400 mm Cross traverse Y-axis (table/column): 1200 mm Vertical traverse Z-axis: 3000 mm Spindle traverse W-axis: 500 mm Milling spindle taper (ISO): ISO 50 Spindle power: 30 kW Dia spindle -- Spindle bore: 150 mm Spindle speed range: 1470 rpm Digital read-out (1) CNC(2): Newall dig readout Rotary table dimensions: 2500 x 2000 mm Weight: yes

Condition: good (used), Year of construction: 2002, bore capacity in steel (diameter) 24 mm throat 260 mm bore stroke 120 mm spindle turning speed range 80 - 1400 U/min table-size 500 x 365 mm morse taper 3 total power requirement 1,5 kW Cgslq Nswgi E Asrq Tjt weight of the machine ca. 250 Kg dimensions of the machine ca. HTB 1,85 x 0,8 x 0,5 m

Condition: good (used), Year of construction: 2004, bore capacity in steel (diameter) 28 mm throat 300 mm bore stroke 150 mm distance spindle /table 60-765 mm distance spindle/base plate 1.200 mm taper MK 3 threading M20/M24 column diameter 115 mm table-size 510 X 425 mm spindle turning speed - stepless 60 - 1:400 U/min total power requirement 1,4 kW weight of the machine ca. 350 Kg. Cjlq Nowgi Evjrq Togt dimensions of the machine ca. 1,9 x 0,6 x 0,9 m - Digital spindle speed display - Foot switch - Thread cutting device - Left-right rotation - 2-speed motor
