Used Cylindrical grinding machines from 2100mm grinding length for sale (23)

Condition: good (used), Year of construction: 2015, Functionality: fully functional, Machine Name - Churchill Machine Model - BX /Servo cylindrical grinder S.N 10625 Ojvjyokc Retrofitted 2015 Description - 3048mm between centers Table size 4500mm x 400mm 400mm swing Fixed head Filtration system Machine weight 9000Kg

Condition: ready for operation (used), Year of construction: 2006, Functionality: fully functional, Precision surface-, profile and cylindrical grinding machine with internal grinding device Brand: GEIBEL & HOTZ / Type: RS 5000 CP / Year of manufacture: November 2006 This machine is characterised by its robustness, long service life, extreme low vibration and high precision. Suitable for individual parts and series production. The following grinding cycles are available: - Plunge-cut grinding in X-direction, optionally with short-stroke oscillation - Grooving grinding in Z-direction - Longitudinal grinding, with infeed at the turning points (also for crowned workpieces) - Multiple plunge-cut grinding in X-direction with plunge-cut overlap - Oblique oscillation (grinding at an angle, with obliquely dressed disc) - Angled plunge-cut grinding at any angle - Pendulum grinding in Z-direction Previous use: max. 1-shift operation. Udps8J29Ir The machine can be inspected by appointment under power. TECHNICAL DATA: Working area: - Centre distance/grinding length: 5.000 mm - Centre height: 650 mm - Swing diameter max.: 1.290 mm - Grinding diameter max.: 750 mm - Workpiece weight between the centres: 3.200 kg Machine weight: approx. 21 tonnes Machine dimensions (L/W/H): 13.6 x 3.6 x 2.1 m EQUIPMENT: - CNC control: SIEMENS SINUMERIK 840D with integrated PC and digital SIMODRIVE 611D drive system - CE labelling - Documentation (German) - Further extensive equipment Without guarantee of completeness and correctness of the technical information and the equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: new, Year of construction: 2024, Workpiece weight (max.): 3,000 kg, Grinding wheel diameter: 750 mm, Distance between centers: 4,000 mm, Grinding wheel width: 100 mm, New machine Control system: Siemens 828D sl Swing diameter: 630 mm Distance between centers: 4 000 mm Max. weight of workpiece: 3 000 kg Dptrqd Grinding wheel peripheral speed: 10-50 m/s Grinding wheel dimensions (dia. x width x bore): 750 x 100 x 305 mm

Condition: good (used), Year of construction: 1980, Cylindrical grinding machine KOLB R8/7000 YOM ab. 1980 Main technical data: Centre height: 400 mm
 Table speeds:: 30 ¬ 4500 mm/min
Grinding motor: 30 kW
Swing diameter: 800 mm
 Grinding length: 7000 mm Workpiece drive: 3,3 kW
 Peripheral speed: 30 m/sec
Rapid adjustment: 50 mm
 Workpiece weight: 6000 kg
 Grinding diameter: 800 mm
 Grinding wheel speeds: 720 & 900 U/min Tailstock quill stroke: 100 mm
 Cwo9Iy9K8G Total power requirement: 45 kW
Workpiece turning speeds: 6 ¬ 60 U/min
 Weight of the machine ca.: 30 t
 For more information please contact us.

Condition: excellent (used), centre height 315mm centre distance 4000 mm CNC MONOASSE SIDAC Crngfcb . The data are indicative and not binding, translation errors are possible.

Condition: excellent (used), Year of construction: 1969, Functionality: fully functional, Machine/vehicle number: lom0303, Center height: 550 mm, Workpiece weight (max.): 15,000 kg, Grinding length: 5,000 mm, Grinding wheel diameter: 760 mm, Grinding diameter: 1,050 mm, Quill stroke: 120 mm, Quill diameter: 200 mm, Distance between centers: 5,100 mm, Type of input current: three-phase, Workpiece diameter between centers: 1,050 mm, Grinding wheel width: 120 mm, Spindle speed (max.): 1,000 rpm, Spindle speed (min.): 400 rpm, Feed length X-axis: 630 mm, Feed length Z-axis: 5,100 mm, Feed rate X-axis: 1,000 mm/min, Grinding spindle motor power: 1,100 W, Grinding spindle speed: 250 rpm, Pivoting range: 1 °, Rotational speed (min.): 1 rpm, Rotational speed (max.): 250 rpm, Year of last overhaul: 2023, Rapid traverse X-axis: 1,000 mm/min, Rapid traverse Z-axis: 3,080 mm/min, Equipment: Rotational Speed Infinitely Variable, Naxos Union cnc grinding in 4.0 certified ,fully retrofitted moving head ,electrical cabinet 2023,cnc 2023,fully programmed in parametric + iso for : straight rolls , convex rolls ,concave and convex rolls, program 15 different diameters, possibility of program implementation. Radius of cambering practically infinite. The grinding machine is fully functional ,(we are working) and visible in our company. Optical millesimal x-axis ruler. Magnetic ruler millesimal z-axis. Metric 100 tailstocks. N 3 bezels. N 5 wheel holders. Losma fume suction. Losma coolant tank (230 liters/minute). Possibility of mounting plateau on workpiece holder. Possibility to see the machine in operation ,(grinding has been completely redone, ground grinding wheel holder bench and scraped , electrical panel with new diagrams , new motors, ball screws , new pumps , new control units , flow switches , etc .etc .etc ). Ivuwuqv Price negotiable.

Condition: ready for operation (used), TOS Grinder BE 370x4000 Max grinding diameter - 400 mm Max length -4.000 mm Dprxhd Many accesories

Condition: new, Experience unparalleled precision and performance with ROBBI's range of cylindrical grinding machines. Our machines offer grinding lengths starting from 2000mm and are available in semi-automatic and CNC versions. With a grinding diameter range of 300-1000mm, the possibilities are endless. Partly available from stock! Discover our extensive range of optional accessories that make our cylindrical grinding machines even more versatile. Whether it's for complex workpieces or demanding tasks, our machines always deliver the best results. With ROBBI's years of experience, trust us to optimize your machining processes. Invest in quality and precision - contact us today! MAIN TECHNICAL DATA: Model: Omicron CNC 80 Grinding diameter: 795/895/955 mm Grinding length: 3000-6000 mm Center height: 400/450/500 mm Center distance: 3000-6000 mm Swing over bed: 795/895/955 mm Max. workpiece weight between centers: 4 t Additional technical data in the appendix MAIN TECHNICAL DATA: Model: Omicron CNC 60 Grinding diameter: 595/695 mm Grinding length: 1000-3000 mm Center height: 300/350 mm Center distance: 1150-3150 mm Swing over bed: 600/700 mm Max. workpiece weight between centers: 1200 kg Additional technical data available on request or in the appendix MAIN TECHNICAL DATA: Model: Omicron CNC 36 Grinding diameter: 355/455 mm Grinding length: 630-2030 mm Center height: 180/230 mm Swing over bed: 355/455 mm Max. workpiece weight: 250 (300 opt.) kg Additional technical data available on request or in the appendix ACCESSORIES (EXAMPLE FOR OMICRON CNC 80) CNC control: Siemens 840D Glass scales: in the X-axis Coolant system: with coolant collection tray Grinding wheel dresser: mounted on the tailstock (without diamond) Telescopic cover: for the table made of fabric Machine oil: 5l for the spindle Frequency converter: for spindle motor and workpiece drive (stepless) Hydraulic unit: for controlling the tailstock quill Ball screw in the axes: X and Z Optimized cycle with geometric and process parameters - The CNC grinding machines meet the production requirements for medium-sized workpieces. - The machines are equipped with the latest generation SIEMENS 840Di sl system. - The machine can be equipped with automatic measuring systems. - It is possible to design the grinding wheel for geometries specifically created for the required type of production. - High-precision machining can be performed when the grinding machines are equipped with a third interpolated axis and specially designed software. EASY PROGRAMMING Complex programs can be created without the need for ISO programming knowledge. The input of parameters is facilitated by a series of messages and characters that explain the meaning of the various parameters step by step. The programming of work cycles is done by entering the same parameters of the cycle. The sequence of execution of the various cycles can be quickly and intuitively changed. By the way, in addition to affordable new machines and tested used machines, you can expect even more from us: • Consultation and problem-solving at your location • Organization of machine transport to your facility • Installation, commissioning, and turnkey delivery, and more. Scklrpytsr

Condition: good (used), Year of construction: 1981, Functionality: fully functional, Workpiece weight (max.): 10,000 kg, Grinding length: 4,000 mm, Grinding wheel diameter: 750 mm, Total width: 4,180 mm, Total length: 13,440 mm, Total height: 2,455 mm, Grinding diameter: 800 mm, Overall weight: 38,700 kg, STANKO 3M196 roller grinder. Year of manufacture 1981. Max. grinding diameter 800 mm, Max. length of ground workpiece 4000 mm, Range of grinding diameters 80 - 800 mm, Max. grinding diameter without support 800 mm, Max. grinding diameter in support 450 mm, Elevation of the tusk above the table 410 mm, Max. weight of ground workpiece in the tusk 10000 kg, Grinding wheel dimensions ⌀750 x 100 mm, Grinding speed 50 m/s, Main motor power 30 kW, Product speed 5 - 80 rpm, Max. travel of tailstock tusk pins 100 mm, Overall dimensions of the grinder (Length x Width x Height ): 13440 × 4180 × 2455 mm, Bw9Pvy00Mm Weight of the grinder 38700 kg,

Condition: excellent (used), Year of construction: 2018, Control system: Siemens 840D Technical data: Center height: 315mm Sanding diameter Ø: 630mm Sanding length: 4000mm Grinding stone dimensions: 710 x 80 x 305mm Table rotation: -5 to + 5° Tailstock: 6Mk 4 axes controlled X, U, Z and C-axis Sxzsjs Further equipment features - Coolant system - Filter system - Large steady rest package 6 pieces - Concave loops - Covex grinding - Dressing system - Overhaul by Primoteq

Condition: good (used), Year of construction: 1997, AP 315 DP 2000 WITH SINGLE AXIS CN SIEMENS SIMATIC KAVALIR, WATER FILTER TANK, ACCESSORIZED Bkf8Kc8Zr8M

Condition: refurbished (used), Schmaltz R6 3500 grinding length: 3.500 mm Center height: 300 mm (optionally more possible) Workpiece weight: 2,000 kg (optionally more possible) Other freely selectable options: - Upgrade to CNC grinding machine possible Qab07 - CE-marking in combination with partial or full enclosed splash water housing - "Workpiece memory" SPS PRO for 10/15/30/50 workpieces - Mini handheld control unit for SPS-PRO - Balancing device - Grinding sensor system - Peak increase - Frequency converter external grinding spindle - B-axis freely positionable - Glass scale in X- & Z-axis - remote maintenance - suitable coolant / exhaust system - grinding wheel flange & change arm - and much more We can also overhaul your existing bearing machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella uvm.

Year of construction: 1984, Condition: good (used), Used TOS KAMENICEK model BUC63A x 3000 Universal cylindrical grinding machine. YEAR OF MANUFACTURE: 1984. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. SPECIFICATION Max Swing 630 mm Distance between centres 3000 mm Workhead swivel – towards wheelhead only 90 deg. mm Work spindle bored taper No. 6 M.T. Length of stroke of tailstock barrel 70 mm Tailstock barrel taper No. 6 M.T. Spindle nose clamping Din 55021 Swivelling of wheelhead + 30 deg – 10 deg Length of adjustment by re-circulating ball screw 290 mm Additional length of adjustment 250 mm Length of rapid feed 90 mm Length of infeed setting per each rev. of handwheel, measured on work diameter 0.5 mm Grinding wheel dia. X width X bore 750 x 80 x 305 mm Min. dia. of worn grinding wheel 570 mm Max. face width of grinding wheel 125 mm Rate of table traverse – steplessly variable 0.5-0.6 m/min Ccxhtcc8Rl Table traverse per 1 rev of handwheel 8 mm Swivelling of table +/- 5 deg. Max. permissible weight of work between centres 2500 kg Max. permissible weight of workpiece in chuck with overhang. (including weight of chuck) 150 kg Wheel spindle speeds (2) 840,970 rpm Grinding wheel surface speed 33 m/sec Work spindle speeds – int. var. in 2 ranges 8-50, 50-315 rpm Drive – total power required rated 31 kva Output of workhead motor 3 kw Output of wheelhead motor Electrics 15 kw 415V ,3Ph,50Hz Equipped with:- Additional wheel flanges, coolant system with clarifier and splash guards. FEATURES AND EQUIPMENT – Swivel Round Internal Grinding Attachment

Condition: used, Year of construction: 1982, Machine/vehicle number: 14552, grinding diameter:600 mm grinding length:3000 mm centre height:315 mm workpiece weight max.:3000 kg work piece spindle speed:8 - 120 U/min grinding wheel motor:25 kW grinding wheel speed:45 m/sec grinding wheel width x diameter:750 x 80 mm table speeds:30 - 4500 mm/min feeds of grinding head:0 - 5 mm/min table swivelabel +/-:7,5 ° total power requirement:55 kVA weight of the machine ca.:18 t dimensions of the machine ca.:11,5 x 4 x 2,2 m - Internal grinding device - taper grinding up to 10,1° based on diameter - automatic grinding cycle - grinding wheels and flanges - dressing device - coolant attachment Fhc8W7Oc - dust exhauster, various steady rests

Condition: excellent (used), Center height 300 mm Distance between centers 3500 mm Vlbqd82G Grinding wheel 760 x 305 x 100 mm With DRO With measuring control MARPOSS Misc.accessories MARCELS MASCHINEN AG

Year of construction: 2018, Condition: good (used), Make: WMW Meuselwitz Type: SAXW 630 / 4000 Control: SIEMENS 840D Year: 2018 4 Axis controlled X, U, Z and C Axis Large steady rest package 6 units Concave grinding Covex grinding Dressing system Rebuild by Primoteq Specifications Metric US Standard Centre height 400 mm Grinding Ø 630 mm Grinding length 4000 mm Grinding stone dimensions 710 x 80 x 305 mm Table inclasement -5 to + 5 ° Tailstock 6 Mk Coolant system Kosyautv Yes Filtration Yes Dimensions (Estimate) Length 12000 mm Width 4500 mm Height 2800 mm Weight 24000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), centre height 315mm centre distance 2500mm grinding diameter 630mm grinding wheel diameter 800mm power 24kw weight ca. 10000kg. Lunettes, hydraulic tailstock, water filter paper. Bcs37Vas The data are indicative and not binding. Translation errors are possible.

Condition: refurbished (used), Year of construction: 2023, Schaudt PF61 1000 - 4000 grinding length: 1.000 / 2.000 / 3.000 / 4.000 mm Center height: 260 mm Other freely selectable options: - completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus control system - fast set-up via GSN user interface - Diatronic measuring device - B-axis freely positionable - second external grinding wheel - internal grinding unit - center elevation - dressing spindle for diamond form roll - balancing and grinding sensors Cg0Asglmdz - Tailstock hydraulic clamping / unclamping - Autom. Siemens door drive - 19" / 22" screen - remote maintenance - conversion to needle nozzles - suitable coolant / exhaust system - automation preparation - and much more We can also overhaul your existing stock machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella uvm.

Condition: used, Year of construction: 1977, grinding diameter 350 mm grinding length 1000 mm centre height 100 mm grinding wheel diameter 360 mm total power requirement kW weight of the machine ca. 3,8 t dimensions of the machine ca. 3,5 x 1,3 x 1,5 m Cinccf98 Machine in very nice condition, external + internal spindle, many accessories.

Condition: good (used), Year of construction: 1981, Center height in crank: 450 mm, Center height: 410 mm, Workpiece weight (max.): 10,000 kg, Grinding length: 3,600 mm, Grinding wheel diameter: 750 mm, Total width: 4,180 mm, Total length: 13,440 mm, Total height: 2,460 mm, Grinding diameter: 800 mm, Workpiece weight between centers: 10,000,000 g, Distance between centers: 4,000 mm, Type of input current: three-phase, Workpiece diameter between centers: 800 mm, Workpiece length between centers: 4,000 mm, Grinding wheel width: 100 mm, Spindle speed (max.): 1,180 rpm, Spindle speed (min.): 545 rpm, Overall weight: 38,700 kg, Input frequency: 60 Hz, Input voltage: 400 V, Workpiece spindle speed (max.): 80 rpm, Power: 30 kW (40.79 HP), Equipment: Rotational Speed Infinitely Variable, Manufacturer: Kosior Machine Tool Plant, Kharkov, Ukraine. Shaft grinding machine model 3M196,is designed for grinding in canine cylindrical and conical surfaces in unit, batch and mass production. The product is processed by longitudinal or plunge grinding in manual or semi-automatic cycle. Heavy roller grinding machine, designed for external grinding of cylindrical and flat conical surfaces with the following parameters. Brief technical specifications: -Largest grinding diameter: 800 mm, -Maximum length of the workpiece to be ground: 4000 mm, -Range of grinding diameters: 80 ÷ 800 mm, -Maximum grinding diameter without support: 800 mm, -Maximum grinding diameter in support: 450 mm, -Maximum grinding length: 3600 mm, -Tusk height above table: 410 mm, -Maximum weight of the ground workpiece mounted in the tusk: 10000 kG, -Maximum table turning angle: --clockwise: 0.30°, --clockwise: 3,0°, --Distance from the base of the grinder to the axis of the workpiece to be ground: 1285 mm, -Maximum table travel length: 4300 mm, -Dimensions of grinding wheel: ⌀750 x 100 mm, Bkrvaeazzfs -Grinding speed: 50 m/s, -Motor power of main drive: 30 kW -Product speed (infinitely adjustable): 5 ÷ 80 rpm, -Maximum travel of tailstock tusk pins: 100 mm, -Size dimensions of the assembled grinder (L x B x H ): 13440×4180×2455 mm, -Grinder weight: 38700 kg,

Year of construction: 2023, Condition: new, Main technical data : Swing diameter mm 630-850 Distance between centres mm 3000,4000,500 Standard wheel size (diameter x width x bore) mm750/570 x 100 x 305 Maximum wheel width mm 100 Peripheral wheel speed m/sec 45 Wheelhead swivel (°)+10/- 30 Workhead swivel (°)90 Tabel swivel (°)+6/-4 Ftnez9Ccn Workhead spindle speed, infinitely variable RPM 8 – 156 Workhead sleeve taper bore Morse 6 Tailstock sleeve taper bore Morse 6 Minimum programmable increment : in axis X /related to diameter./ (grinding wheelhead) mm 0,001 in axis Z (table) mm 0,005 Maximum weight of workpiece Workhead motor kW 7,5 Wheelhead motor kW 22 Total power demand of machine kW 45 - between centres kg2 500 Weight of machine with standard accessories kg approx 17 500 Dimensions of machine approx. mm 12 000 x 2 980 x 2 200

Condition: excellent (used), Year of construction: 1987, Centre height 315 mm Centre distance 2500 mm Grinding diam. 630 mm Grinding wheel diam. 750 mm Power requirement 36,2 KVA WIEGHT KG 9000 Cyqokt2Q WITH LUNETTEN DRESSER EXTERNAL RAGGIATORE BATH FILTER WATER VISUALIZED THE data are indicative and not binding. Translation errors are possible.

Condition: refurbished (used), Schaudt PF5 UB 1000-2500 mm grinding length: 1.000 / 1.500 / 2.000 / 2.500mm Center height: 180 / 225 mm (optionally more possible) Workpiece weight: 350 / 500 / 800 kg (optionally more possible) Other freely selectable options: - completely new control cabinet with Siemens Sinumerik One or Fanuc 0iTF-Plus control system - Fast set-up via GSN user interface - Diatronic measuring device - B-axis freely positionable - second external grinding wheel - internal grinding unit - center elevation - dressing spindle for diamond form roll - balancing and grinding sensor system - Tailstock hydraulic clamping / unclamping - Autom. Siemens door drive Z2Z7Tiev - 19" / 22" screen - remote maintenance - conversion to needle nozzles - suitable coolant / exhaust system - automation preparation - and much more We can also overhaul your existing stock machine! Schaudt / Studer / Kellenberger / Bahmüller / Voumard / Overbeck / Fortuna / Tacchella uvm.
