Surface grinding machine LGB R 16090 SM
Surface grinding machine with gantry Manufacturer LGB France
Type R 16090 SM
Year 1998
Control SM
Diamond age
Cylindical / Surface / Other portal surface
Electro magnetic table 1600 x 800 mm
Grinding wheel size 400 x 60 x 127 mm
kW power on the spindle 15 kW
Cniaqrvw
X - Stroke 1730 mm
Y - Travel 930 mm
Z - travel 550 mm
Workpiece weight 2000 kg
Speed / spindle range Vario 1350 Rpm
Length 4160 mm
Width 2215 mm
Height 2500 mm
6
x-travel 400 mm
y-travel 280 mm
w-axis 350 mm
Feed X / Y- axis 6000 mm / min.
feed rate w-axis 4000 mm/min.
table surface area 620x315 mm
table load 0,3 t
T-slot - width 12 mm
T-slots 5 Stk.
spindle speeds (infinitely variable) 10-80.000 U/min
planetary speed 300 U/min
spindle stroke 100 mm
total power requirement 15 KVA
weight of the machine ca. 3,5 t
dimensions of the machine ca. 2,45x2,03x2,6 m
Y99cj3m
cnc control Fanuc 15 M - 8 axis
10 milling heads
3 measuring feeler
1 cabinet with acces...
9
Coordinate grinding machine Hauser 3 SM with digital display
Usable table area 550 x 320 mm
Adjustment range of the table 400 x 250 mm
Stroke of the vertical slide approx. 500 mm
Max. clearance between grinding motor and table approx. 500 mm
Speed range of grinding motors (stepless) 9'000-80'000 rpm
Speed range of the grinding turbine up to 250'000 rpm
Fully equipped with original tool cabinet
Centering microscope
Carc0hd2ze
10
x-travel 400 mm
y-travel 250 mm
workpiece height 500 mm
table surface area 600 x 320 mm
B9qgtryu8q
total power requirement 7 kVA
weight of the machine ca. 2 t
1
x-travel:400 mm
y-travel:250 mm
workpiece height:500 mm
grinding diameter:220 mm
Dyo8y2u
table surface area:600 x 320 mm
throat:310 mm
range of angles:12 °
grinding wheel stroke - vertical:110 mm
stroke speeds:0 - 6 m/min
grinding spindle speed:bis 50000 U/min
peripheral speed:max. 35 m/sec
capacity:ca. 7 kVA
power capacity:6 kW
weight of the machine ca.:2 t
dimensions of the machine ca.:3 x 3 x 3 m
rotary table d = 300 mm
frequency changer
10
Technical data:
Uuiqewyp
travels x/ y-axis 400/ 250 mm
Work table 600 x 380 mm
Spindle speed range 30- 4000 1/min
Tool holder SK 30
Max. grinding diameter 220 mm
Total weight approx. 3000 kg
- Grinding head
- Miscellaneous accessories
-----
CNC control Poselesta II
POSELEST II is a position-regulated 4-axis path control (2 1/2 D). It allows interpolations 3 D linear or 2 1/2 D circular.
With the 6 G functions G17, G18, G19, G45, G46 and G47, any two of the axes X, Y, Z, 0 can be defined as inter...
13
Equipment:
ELESTA digital measuring device, 2 axes
Standard accessories
DITTEL MARPOSS Sensitron 6 - gating device
Groove grinding attachment
Attachment rotary table D:300 mm incl.
adapter plate 250x400 mm
div. grinding motors
Caepjfrd2d
div. mounted points and grinding wheels
Documentation
condition: good, functional
5
x-travel 400 mm
y-travel 250 mm
workpiece height 485 mm
Control ELESTA CNC 314
total power requirement 10 kW
weight of the machine ca. 4000 kg
dimensions of the machine ca. m
H A U S E R
CNC - Controlled Vertical Precision Coordinate Grinding Machine
Model S 3 CNC 314
Year 1987 / 1998 partially reconditioned by Swiss-HTT # 0463
_____
Table size, approx. 600 x 380 mm
Max. load on table, approx. 300 kg
Table travel, longitudinal, max. (X Axis) 400 mm
Table travel, cross, max. (Y Axis) 25...
9
x-travel 700 mm
y-travel 500 mm
workpiece height 675 mm
table surface area 900 x 770 mm
column daylight 840 mm
turning speed range - grinding spindle 9 - 45.000 U/min
total power requirement 6,5 kW
weight of the machine ca. 5 t
Bec9yvrlq
dimensions of the machine ca. 3,6 x 5 m
control Digitalanzeige
8
x-travel 420 mm
y-travel 270 mm
workpiece height - mm
table-size 254 x 482 mm
throat 254 / 318 mm
grinding spindle speeds 12. - 60.000 U/min.
spindle stroke 92 mm
spindle turning speed range 90, 136, 184, 280 U/min
number of strokes adjustable 2 - 120 Hübe bei 51 mm
0 1,25 µm bei 30 mm
Required air-pressure 7 bar
weight of the machine ca. 1430 kg
dimensions of the machine ca. 1,45 x 1,2 x 2,4 m
Electric 380 Volt
Tool cupboard 2
Rotary table Moore 254 mm
Grinding head with air turbine 4 x
...
4
x-travel:400 mm
y-travel:250 mm
workpiece height:500 mm
grinding diameter:220 mm
table surface area:600 x 320 mm
throat:310 mm
range of angles:12 °
grinding wheel stroke - vertical:110 mm
stroke speeds:0 - 6 m/min
grinding spindle speed:max 50.000 U/min
peripheral speed:max 35 m/sec
workpiece weight:80 kg
Y7lxh8yys
weight of the machine ca.:2 t
dimensions of the machine ca.:1,2 x 1,3 x 2,3 m
6
Control Hauser Elesta Digital
Caj2bauipm
Technical data
table LxW 700 x 500 mm
grinding diameter max. 300 mm
grinding stroke Z 150 mm
Rotary table diameter 600 mm
grinding motor 45S 9.000-45.000 rpm
grinding motor 45ST 9.000-45.000 rpm
Grinding motor 80 S 40,000-80,000 rpm
Operating hours 19.184
Last technical inspection 2020
Many accessories
Use in toolmaking
Connected load
dimensions LBH ca. 400x250x270 cm
Cargo dimensions LBH ca. 300x200x270 cm
Weight approx. 6 tons
Plane Grinding Machine MONOPRECIS 114 S
Travel X: 450 mm
Travel Y: 200 mm
Travel Z: 300 mm
Grinding wheel: Max Ø 180 mm
Motor: 1,1 kW - 2820 RPM
X - Y - Z movements manual
Delivered with:
1 manual magnetic chuck 300 x 150 mm
1 vacuum cleaner
Voltage: 380 V
Width: 1500 mm
Depth: 1300 mm
Itjeoqt
Total height: 1600 mm
Weight: approx 1 T
5
x-travel 650 mm
y-travel 450 mm
workpiece height 585 mm
Control ADCOS CNC 400
total power requirement 15 kW
weight of the machine ca. 5000 kg
dimensions of the machine ca. m
H A U S E R (Switzerland)
CNC Controlled Hi Precision Double Column Jig Grinder
Model S 40 CNC 311 / ADCOS 400 CNC
Year 1981 / CNC modernized in 2008 # 0126
_____
Table size approx. 630 x 770 mm
Table load capacity approx. 500 kg
Table travel longitudinal max. (X) 650 mm
Grinding head slide cross max. (Y) 450 mm
V...
4
Grinding spindle attachment for coordinate grinding machine
Make MIKROMAT
Shank diameter 14 mm
Qdymv
Thread : M 14
Ca.19.shots .
8
Table:590x320mm
Max.table load:200Kg
Travel XYZ:400x250x500mm
Distance between spindle/table:655mm
Spindle speeds:9000-80000rpm
With rotating table:300mm
Power:6.6kW
Incl tools
Machine weight:1540Kg
2hysr0pf
3
x-travel:700 mm
y-travel:400 mm
workpiece height:620 mm
table::1000x630 mm
internal grinding diameter:250 mm
:115 mm
C2p2sptq
feed speeds infinitely variable:0,5-63 mm/min
total power requirement:6 kW
weight of the machine ca.:4,5 t
dimensions of the machine ca.:2375 x 2470 x 2560 m
precision machine with high-speed spindle 30000-60000 rpm as well as second high-speed
auxiliary spindle (12000-30000 rpm), facing slide head +/- 50 mm traverse, feed display, digital RPM display, ARKURITE model VRO...
Parts shown by hand not come.
Pnhsx
12
External cylindrical grinding machine MANURHIN POLYGONE
Between points: 800 mm
Pdefi2pd
Cone: CM6
Spindle diameter: Ø 54 mm
Rotation: 1300 RPM
Grinding wheel: Ø 508 mm x Ø 127 mm x thickness 60 mm
Centre height: 175 mm
Grindstone motor: 5 KW
External cylindrical, eccentrics, ellipes, triangles, squares grinding machine
External rectifications possible
Dimensions (L x W x H): 3200 x 2100 x 1600 mm
Weight: approx 3,8 T
10
Hauser coordinate grinding machine 3 SM in very good condition
B8v3k7ws3k
-Fully equipped with original tool cabinet
-Normal grinding motor 9'000-50'000 rpm
-high speed grinding motor 50'000-80'000 rpm
-grinding turbine 150'000-250'000 rpm
-with centering device and suitable dial gauge
-centering microscope
-machine was factory overhauled
5
- Table dimensions: 1200 x 500mm
- Grinding wheel diameter: 400 mm
Brbeobdpq9
- Grinding wheel width: 50 mm
- Grinding wheel bore: 127 mm
- Strokes: X = 1030mm - Y = 500mm
- Power: 5.5 kW
Equipped with :
- 1 Magnetic plate 900 x 400mm
- 3 automatic and manual movements
- 1 Hydraulic diamond on the head wheel holders
10
Hauser S40-111
Type S40-111
Serial number S402026
Working range
X mm 650
Y mm 450
W mm 500
grinding spindle stroke mm 140
Dimensions work table
X mm 770
Z mm 630
Speed
electric 1/min 80000
pneumatic 1/min 160000
Lifting speed
hydraulic mm/min 7500
electric mm/min 50
Feeding speed
machining X/Y mm/min 1500
machining W mm/min 800
rapid traverse mm/min 3000
Workpiece weight kg 500
Control Hauser 111
Mxamws
Connection cable kW 8
Year of manufacture 1987
Install...
7
Jig grinding machine Hauser 3 SMO 14-04-011
Delivery time: immediately
Number: 14-04-011
Machine data
L x W x H: approx. 1500 x 1200 x 2800 mm
Weight: approx. 1800 kg
Year of construction: around 1969
Very good general condition
Technical specifications
Digital display: 2-axis digital display
Working area: 400 x 250 mm
Direct reading accuracy: 0.001 mm
Accuracy of the slide adjustment 0.002 mm
Grinding diameter: approx. 220 mm
Lifting speeds: 0 - 6 m / min
Grinding spindle:
Speed: approx...
6
- Usable table area: 550 x 320 mm
- with Hauser round table Ø-300 mm
- travel distances X x Y x Z strokes: 400 x 250 x 500 mm
Tuwe2y3r
- Heidenhain 2-axis digital display: X / Y axes
- Distance Spindle lids Table area max. : 485 mm
- Distance between spindle axis and Z Guide rail max: 310 mm
- Largest passage under grinding spindle: 470 mm
- Grinding spindle Vertical stroke: 3 to 110 mm
- Automatic stroke of the grinding spindle: 5 - 90 mm
- Automatic grinding spindle feed, infinitely variable: ...
3
Plane Grinding Machine MAGERLE F10 N482
Travel X: 1000 mm
Travel Y: 250 mm
Travel Z: 350 mm
Rotation: 3300 RPM
Automatic pass X - Y - Z
Lubricant tank
B9wmeudt7k
Diamond grinding
Voltage: 380 V
3
2-axis digital display
Travel X / Y / Z: 400/250/500 mm
Rodoxyqw
Optical rotary table D 300 mm + adapter plate D 400 mm
Swivel rotary table D 200 mm
a lot of accessories
5
1 USED PLANE GRINDING MACHINE JONES & SHIPMAN 540 H
- Serial N° : 95120
- Table dimensions : 457 x 152 mm
Jvj0jy
- Wheel speed : 3000 rpm
- Power of the headstock wheel holder : 1.5 kW
- Vertical advance of the wheel holder head : max. 405 mm
- Low friction transverse displacement
- Machine dimensions : 1168 x 597 x H1651 mm
- Machine weight : 1016 kg
Equipped with :
- 1 Motorized device for raising and lowering the wheel holder head
- 1 Automatic sweep of the carriage
- 1 Dust extractor
- 1 Op...
12
House 3 SMO
Type 3 SMO
Serial number 201
Working range
X mm 400
Y mm 250
W mm 500
grinding spindle stroke mm 110
Dimensions work table
X mm 595
Z mm 320
Speed
electric 1/min 45000
pneumatic 1/min 80000
Lifting speed
hydraulic mm/min 6000
electric mm/min
Feed speed
machining X/Y mm/min
machining W mm/min
rapid traverse mm/min
Workpiece weight kg 200
Control Hauser 111
Spindle hours h N/A
Connection line kW 6,6
year of manufacture 1974
Installation area (with...
9
Code 9602
Bujyczkgn0
DESCRIPTION Vertical JIG Grinder
Make HAUSER
Modell 3 SMO
Serial No. 257
Machine No. 1519-2564
Table surface 600 x 320 mm
Table movement longitude (X) 400 mm
Table movement cross (Y) 250 mm
Max. grinding diameter Ø 190 mm
Column-Spindle 300 mm
Max. height under spindle 500 mm
Vertical movement spindle 90 mm
Vertical movement grindinghead 500 mm
Max. speeds grindingspindle up to 80.000 omw./min
Weight 2000 kg
Total power 6,6 kW – 380 Volts
Acce...
12
Hauser 3 SMO jig grinding machine
The HAUSER brand is a leader in jig grinding technology. Coordinate grinding machines are used when milled workpieces have to be ground to the highest precision. They are used when even the precision that can be achieved on CNC milling machines does not meet the requirements.
Manufacturer: Hauser
Model: 3 SMO
Dimensions: approx. 1.5 metres long, 1.3 metres wide and 2.2 metres high
Table dimensions: 595x320 mm
Travel: 400 mm lengthwise and 250 mm crosswise
...
Plane grinding machine LIP type PLTH 450 Série A
Travel X: 450 mm
Travel Y: 250 mm
Travel Z: 200 mm
Axes X and Y auto - Axe Z manual
Manual magnetic chuck
Magnetic chuck dimensions: Length 405 mm x Width 200 mm
Grinding wheel dimensions: Ø 220 mm x 25 mm
Machine rebuilt and in compliance in 1997
Working hours since 1997: 70 h
Delivered with protective fairing (not mounted)
With one independant hydraulic unit
With one independant lubricant tank
Bwg3gwofvp
Voltage: 380 V
Width: 1800 mm
Depth: 1700...
2
Travel for the x-axis - 400 mm
Travel for the y-axis 250 mm
Bdvmtaahug
Travel for the z -axis 340 mm
Table Surface area - 600 x 300 mm
Turning speed range 40 - 3150 rpm
Planetary grinding heads included.
With full technical documentation
There is no possible drilling and milling - no tooling
Transport dimensions: 1.5 x 1.7 x 1.8 m,
Weight ; 1300 kg.
4
1 USED PLANE GRINDING MACHINE BLOHM SIMPLEX 5
- Serial number : 8836
- Stock number : 7162
- Table dimensions : 900 X 300 mm
- Dimensions of the electric magnetic plate : 500 X 300 mm
- Maximum grinding length : 500 mm
Cvihvkic
- Maximum grinding width : 350 mm
- Grinding wheel width : 50 mm
- Grinding bore : 76 mm
- Minimum wheel diameter : 165 mm
- Maximum wheel diameter : 400 mm
- Spindle speed : 1400 - 2800 rpm
- Spindle power : 4 kW
- Machine weight : about 2600 Kg
Equipped with :
- 1 Elect...
14
Table length: 590 mm
table width: 320 mm
longitudinal travel (X-axis): 400 mm
cross travel (Y-axis): 250 mm
path of the vertical slide: 500 mm
Clearance between grinding motor and table: 480 mm
Distance between spindle center and vertical slide: 310 mm
Largest grinding diameter: 180 mm
With extension plate: 220 mm
up to: 12.0 °
stepless from: 3 mm
up to: 110 mm
up to: 6.0 m/min
Speed of the : planetary movement: C-axis
from: 5 rpm
up to: 330 rpm
from: 9000 rpm
up to: 80000 rpm
Vc3leni
With air t...
8
coordinates grinding machine
Manufacturer: DECKEL
TYPE : LKD
Accessories:
* Clamping rotary table (dividing head)
* 2-axis digital display Heidenhain
Travels
x-axis 400 mm
y-axis 250 mm
z-axis 340 mm
table surface 600 x 300 mm
Rotation speed range 40 - 3150 rpm
Pk7st
Dimensions approx.: 1.500 x 1.700 x 1.800 mm
Weight 1300 kg
9
Used Jig Gringing Machine LKS DECKEL witch additional milling head. 2018 reconditioned. Complete rebuilded from machine body as you can see on photos. Excellent condition. Tested under power. Ready to delivery, installation and work. Complete offer on request.
Bdkoe9mzmk
13
Jig grinding machine HAUSER 3SM
Travel X: 400 mm
Travel Y: 250 mm
Maxi grinding diameter: 200 mm
Taper grinding angle: 12°
Vertical stroke of grinding spindle: 110 mm
Spindle speed: from 9000 to 225000 RPM
Speed of planetary motion: 330 RPM
Advance speed: 6 m/min. max
Slide Vertical travel: 500 mm
Spindle/table distance: 490 mm
Bvrrjrtnwa
Grinding motor: 40 à 80 000 t/min.
Scale 2 axes HEIDENHAIN
Separate electrical panel
Separate hydraulic tank
Equipped with Hoover
Voltage: 380 V
Width: 1500 m...
5
- Dimensions of the electric magnetic plate: 700 X 500 mm
Psfp2
Equipped with :
- 3 Manual and automatic movements
Plane grinding machine MAGERLE type FP 10R S1
Zm0e29fl
Travel X: 1000 mm
Travel Y: 300 mm
Travel Z: 265 mm (maxi height under plate)
Magnetic chuck: BRAILLON type BUR 10 - Year 2012
Magnetic chuck dimensions: 1000 x 300 x thickness 70 mm
Grinding wheel: Ø 360 mm x thickness 50 mm
Scale HEIDENHAIN - 2 axes: X and Y
Automatic pass X - Y - Z
Diamonding
Separate electrical panel (on connector)
Lubricant tank
Voltage: 380 V
Electrical panel dimensions: Length 1400 x Depth 2000 x Heigth 500 mm
Length:...
