Used center grinding machines for sale (23)

Condition: excellent (used), workpiece diameter 60 mm grinding depth 30 mm clamping length 1000 mm Ppodpfsunt Egjx Amger weight of the machine ca. 0,6 t dimensions of the machine ca. 0,5 x 0,5 x 2,1 m

Condition: excellent (used), Year of construction: 1987, workpiece diameter 0,5 - 160 mm grinding depth 30 mm clamping length 1000 mm taper angle 0 - 90 Grad turning speeds U/min weight of the machine ca. 0,9 t dimensions of the machine ca. 1,2 x 1,4 x 2,0 m driven lynette, many accessories. Ppodpfx Ameykb I Nsgor

Condition: used, Henninger high-speed milling spindle SK40 Type 801 M391 For Deckel milling machines Podpfx Amsvygxnegjpr Ratio: 1:6 Max. speed: 12,000 rpm Continuous speed: 10,000 rpm Temperature: approx. 60°C with tools over: ø 12 mm With 14 collets Clamping range 2 - 15 mm

Condition: used, Technical Data Manufacturer: Technica Model: 5100 Design: Centre grinding machine with vertical construction Workpiece holding: Between centres with tailstock and guide Grinding spindle: High-speed grinding spindle Equipment: Various grinding wheels and live centres included Maximum workpiece length: 1100 mm Minimum workpiece length: 50 mm Maximum workpiece diameter: 125 mm Minimum workpiece diameter: 8 mm Centre height above guide: 145 mm Centre height above carriage: 65 mm Centre hole taper angle: 60° Maximum centre hole diameter: 50 mm Minimum core hole diameter: 2 mm Weight: 460 kg Ppsdpfoyw Rr Esx Amgor Dimensions: 850 x 750 x 1850 mm Condition: Used, good No guarantee is given for the correctness, completeness, and up-to-dateness of the information provided.

Condition: used, Number of working hours 1717 h Ppodpfsywnuqsx Amgjr

Condition: good (used), functionality: fully functional, total length: 1,300 mm, total height: 1,800 mm, total width: 800 mm, center height: 150 mm, overall weight: 700 kg, HENNINGER ZS 160 centre grinding machine Podpfsyvtmijx Amgspr - Centre distance: approx. 800 mm Note: The item must be collected on a binding basis between 12.05. and 22.05.2026, on a date yet to be coordinated. FCA D-74821 Mosbach – loaded onto truck

Condition: excellent (used), Year of construction: 2000, Description to follow! Pedpfsyrtwxjx Amgspr

Condition: excellent (used), Year of construction: 1981, Description to follow! Ppedsynmn Aspfx Amgsr

Condition: used, Year of construction: 1977, Machine type: center‑hole grinding machine Model: AG 5100 Year of manufacture: approx. 1975–2000 (various serials) Center distance (grinding stroke): 50 mm to 2,000 mm Workpiece spindle capacity: 8 mm to 125 mm diameter Workpiece swing over tailstock guide: approx. 290 mm Swing over grinding‑head column: approx. 300 mm Maximum workpiece weight: approx. 250 kg Center‑hole taper range: 2 mm to 50 mm diameter Ppsdpfx Amjwwrdisger Center‑hole taper angle: approx. 60° Chuck capacity: approx. 4 mm to 150 mm Grinding‑head vertical stroke (coarse adjustment): approx. 130 mm Fine feed range of grinding pin: 0.01 mm to 1 mm per revolution Grinding‑pin diameter: 20 mm to 60 mm Grinding‑spindle speeds: 13,000 rpm to 45,000 rpm Spindle drive: approx. 0.5 kW Machine power supply: 400 V, 50 Hz Machine weight: approx. 1,000 kg Dimensions (L × W × H): approx. 1,900 mm × 600 mm × 1,800 mm Lubrication/cooling: pneumatic oil‑mist lubrication of grinding spindle Orifice for long workpieces in machine base, tailstock height adjustable with carbide inlays and live center Manual dressing device mounted laterally on grind spindle, approx. 40 mm stroke with pendulum swing for accurate taper Fold‑down pre-centering device for workpiece No workpiece drive via tailstock (passive center)

Condition: used, Year of construction: 1997, x-travel 600 mm y-travel 410 mm z-travel 510 mm control Fanuc type Serie 0-MD mm Tool changer 16 Pos. spindle taper: ISO 40 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are Ppedpfxjyqut Es Amger possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1964, Technical details: shaft diameter: max. 120 mm work piece - max.: 800 mm height of profile: Tiefe: max. 90 mm grinding spindle speed: nicht bekannt U/min Table dimensions: Ø 150 mm voltage: 380 V total power requirement: 1,1 kW weight of the machine ca.: 0,675 t dimension machine xH: 0,75 x 0,70 x 2,0 m Application: vertical internal cylindrical grinding of shafts face, and center grinding with shaft grinder. Spindle head technical details: -equipment shank grinder Ø 13mm 60°; clamping element Ø 6mm shank clamping head. -travel=vertical 950mm by handwheel and transversal 80mm by crank handle -abrasive device with diamond, adjustment crosswise= 80mm. Table other specifications: -with fixed tip holder 60°. -speed 63 / 125 rpm. -adjustment vertical 600mm, in height 1.100mm, operation manual. Ppedsu Ngr Dspfx Amgsr centering block: -prismatic guide accessories: -fixed tip L=180mm -fixed tip L=300mm -div. shank grinder -div. clamping and auxiliary tools *

Condition: good (used), Centre bore 2- 50 mm Diameter of workpiece 8 - 125 mm Lenght of workpiece 50 - 1000 mm Grinding wheel speeds 13'000 - 45'000 rpm Misc.accessories Podpferivluox Amgepr MARCELS MASCHINEN AG

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Psdpowv Nq Rjfx Amgspr Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Robotic, Complete-CNC Control Panel : Beckhoff CNC Movements : Z1-Axis, Z2-Axis, Workpiece clamping Feeding : Stäubli robot arm for loading, unloading and aligning Automatic Grinding Cone Dressing : Included Automatic Compensation After Dressing: Included Indurstry 4.0 Compatibility : Available Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Podpfsu Nmi Njx Amgopr Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Non-Stop Production: Achieve continuous production with robotic arm feeding, automatic dressing, and automatic compensation features, eliminating the need for constant operator oversight. Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use Complete-CNC Control Panel: Utilize a full CNC control panel that allows you to control all axes of the machine, manage robotic feeding, and perform automatic dressing with the Beckhoff control panel. Easily save all grinding programs and monitor machine working times, efficiency, and errors. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex A-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors for mass-production. Additionally, the Zentroflex A-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. With 6-Axis robot arm and servo motors on all axes of the machine, Zentroflex A-series center hole grinding machines operate completely autonomously. All loading and unloading operations are performed by the robot arm. All axis movements of the machine are also performed autonomously with servo motors. Cone dressing and compensation are also performed automatically. All movements and measurements of the machine are performed from the CNC control panel. Contact us for more details.

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Semi-Automatic, CNC Control Panel : Beckhoff CNC Movements : Z-Axis Indurstry 4.0 Compatibility : Available Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Ppsdpswhi Srjfx Amger Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use CNC Control Panel: Benefit from very simple operation and grinding program recording with the Beckhoff control panel and Z-axis servo movement. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex SA-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex SA-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Z-Axis movement is provided by servo motor in CNC form. The part is loaded-unloaded and clamped manually. Settings are made from CNC control panel and grinding is started by pressing the start button. No other manual setting or control is made during grinding. Contact us for more details.

Condition: new, Year of construction: 2026, functionality: fully functional, Grinding cones in different sizes for center hole grinding machines. Ppodpjxyiyqofx Amgsr

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, workpiece weight (max.): 170 kg, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 220 mm, clamping length: 1,600 mm, Workpiece Clamping Diameter : ø 3 – 220 mm (Optional ø 310 mm) Workpiece Diameter: ø 3 – 400 mm Workpiece Length : 20 – 1.600 mm Centre Hole Diameter : ø 1 – 60 (Optional 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Pjdpfx Amjym At Ssgepr Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: UWID/5000/97, grinding spindle speed: 10,000 rpm, feed rate X-axis: 20 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 20 m/min, center height: 150 mm, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 250 mm Travel Z-axis: 250 mm Feed rate X-axis: 0 - 20 m/min Feed rate Y-axis: 0 - 10 m/min Feed rate Z-axis: 0 - 20 m/min Centre height: 150 mm Usable table area: 980 x 185 mm Grinding head Swivel range: 240° Rotation speed: 120°/s Spindle diameter: 170 mm Spindle speed: 2,000 – 10,000 rpm Workpiece holder A-axis Indexing accuracy: ± 15″ Cumulative indexing error (at ∅ 100 mm): 8 µm Mount: ISO 50 Max. rotational speed: 50 rpm Position measuring systems resolution: 0.0001 mm / 0.0001° Tool magazine: 70 tools MACHINE DETAILS Control: NUM 1050 M with PC; Program memory: 512 KB Drive capacities Grinding spindle motor: 10 kW Table drive X-axis: 1.5 kW Workpiece holder A-axis: 1.5 kW Cross slide Z-axis: 1.5 kW Grinding head column Y-axis: 3 kW Grinding head rotation B-axis: 3 kW Electrical connection Connected load: 23 kW Main fuse: 63 A Operating voltage: 400 V, 50 Hz Control voltage: 24 V Lighting voltage: 230 V, 50 Hz Compressed air Air consumption: 10-12 Nm³/h Pressure min/max: 5/8 bar (500/800 kPa) Compressed air quality: ISO 8573-1, class 4 Ambient temperature Operation: 15°C - 35°C Weight: 7,400 kg Ppjdpfjyh I U Iex Amgor Further documentation for the machine is available on request.

Condition: good (used), Year of construction: 1998, Manufacturer: Henninger Type: ZS-201 Year of manufacture: 1998 Self centerring device Double column slide ways Dressing Unit Tailstock by rack & pinion Eccentric adjustment 0 - 20 mm Large Cone-Stone tooling package Specifications Metric US Standard Minimum workpiece Ø 20 Ø Min. Maximum workpiece Ø 450 Ø Max. Max. product length 1200 mm Speed 18300 Rpm Max. grinding angle 45 - 120 ° Max. workpiece weight 190 Dimensions (estimate) Length 1250 mm Width 1250 mm Psdpfxevt Tuio Amgjpr Height 1900 mm Weight 365 kg Please note: The information on this page has been compiled to the best of our knowledge and belief by us and, where possible, by the manufacturer. The information is provided in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you review all important details.

Year of construction: 1974, condition: excellent (used), Workpiece diameter max.: 150 mm workpiece length max.: 1100 mm center hole angle : 60 ° grinding spindle speed : 15'000 rpm Weight: approx. 460 kg dimensions W x D x H: approx. 700 x 800 x 1800 mm Accessories: see picture Ppjdpfx Aef U Ev Ismgsr

Condition: used, Year of construction: 1975, workpiece diameter 125 mm grinding depth 50 mm clamping length 2000 mm total power requirement 0,5 kW weight of the machine ca. 1000 kg dimensions of the machine ca. m T E C H N I C A (Switzerland) Centre Hole Grinding Machine Model ZSM 5100 – 2.000 Year approx.. 1975 S/N 66 32 7872 – J 3278 _____ Distance between centres 50 – 2.000 mm Height of centres approx. 125 mm Workpiece Ø in clamping Vice 8 – 125 mm Swing of workpiece over tailstockguide 290 mm Swing of Workpiece max. over grinding head pillar 300 mm ght of workpiece 250 kg Max. centre hole taper Ø 2 – 50 mm Max. centre hole taper angle 60 ° Podpfx Asvanrcemgjpr Clamping range of vice approx. 5 – 160 mm Grinding head adjustable in vertical axis 160 mm Stroke of grinding tool on workpiece 0.75 – 5 mm Grinding tool Ø 15 – 60 mm Grinding spindle speeds 13,000 – 45,000 rpm Total electrical load, approx. 1 kW - 380 V - 50 Hz Weight, approx. 1.000 kg Accessories / Special Features Machine is suitable for workpiece length up to 2.000 mm with a basement extension * A cone shaped grinding wheel is employed, but it is only in line contact with the centrehole surface, in addition it is reciprocating simultaneously along this line. The workpiece remains stationary, enabling the generation of perfect centre holes. * To clamp cylindrical Workpieces one uses a height adjustable 2 jaw vice which gives three point contact and always coincides with the center of the grinding spindle. * Height-adjustable workpiece centering vice with carbide inserts. Manual adjustment of appropriate workpiece diameter with clamping screw. * Dressing device, mounted on the side of the grinding spindle, stroke approx. 40 mm, for producing a geometrically exact conical form and with oscillation of diamond tool. * Pre-centering device for Workpiece adjustment between centers. * Pneumatic Oil Lubrification of grinding spindle by oil-mist. * Manually adjustable Tailstock with handwheel but without motorized drive. Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 2,000 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 2.000 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Ppedpsxrnchofx Amgor Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Pjdpsgb Ec Hjfx Amgopr Grinding Process : Semi-Automatic, CNC Control Panel : Beckhoff CNC Movements : Z-Axis Indurstry 4.0 Compatibility : Available Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use CNC Control Panel: Benefit from very simple operation and grinding program recording with the Beckhoff control panel and Z-axis servo movement. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex SA-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex SA-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Z-Axis movement is provided by servo motor in CNC form. The part is loaded-unloaded and clamped manually. Settings are made from CNC control panel and grinding is started by pressing the start button. No other manual setting or control is made during grinding. Contact us for more details.
