Used Grinding machines centerless for sale (88)

Centerless cylindrical grinding machine

JUNKER BBE 15 CNC

Call

Condition: used, Year of construction: 2001, machine/vehicle number: 5012, grinding diameter max.:3-220 mm regulating wheel width:500 mm max. width of grinding wheel:500 mm grinding motor:55 kW peripheral speed:max. 63 m/sec workpiece length:500 mm regulating wheel dimensions:350 x 500 x 203 mm dimensions of grinding wheel:CBN 500 x 500 x 305 mm grinding wheel size:KORUND 610 x 500 x 305 mm total power requirement:138 kVA weight of the machine ca.:16 t. dimensions of the machine ca.:4,47 x 2,77 x 2,49 m. Centerless Grindign Machine JUNKER JUPITER 500 CNC SIEMENS in good condition. Including: · 2 robots Kuka KR 16 Year 2007 · CNC loading and unloading device Promot EPL60NC Year 2007 The machine was lately used for grinding of guide bushes (through grinding). Plunge is possible. JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Cii7ysepi9 Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls.

more

Listing

Butzbach

7,816 km

Mikrosa Kronos LX

Call

grinding wheel width: 660 mm, grinding wheel diameter: 600 mm, Condition: excellent (used), Year of construction: 2002, Functionality: fully functional, Mikrosa Kronos XL Year of construction 2002 Wd7egf8ne

more

Listing

Portugal

7,326 km

centerless grinding machine

Mikrosa Kronos S 250

Call

Condition: excellent (used), Year of construction: 2014, Min/Max Grinding Ø1.5/35mm. Maximum Grinding Length While Plunge Grinding 245mm. Grinding Wheel Dimension Ø450 x 250mm Wide. Wheel Bore Ø203.2mm. Regulating Wheel Dimension Ø250 x 250mm Wide. Maximum Wheel Speed 7,200rpm. Dittel Dynamic Balancing Unit. S/No. 15005008 (2014). Lvoeqiluvv

more

Listing

Hattingen

7,668 km

LIDKOEPING CL 520

Call

Condition: used, Year of construction: 1987, grinding diameter max. 75 mm grinding diameter - min. 2,5 mm grinding wheel diameter 508 mm max. width of grinding wheel 254 mm regulating wheel width 254 mm regulating wheel diameter 280 mm weight 8,6 t C9yzmfu Centerless Grinding Machine | Lidkoping 520 Equipped with: - 1 Electrobalance system - 1 CNC plunge on the working wheel - 1 CNC drive motor on the control grinding wheel - Automatic pass on the workung wheel diamond cutter - 2 hydraulic diamond cutters - 1 Ruler holder for working in a row The machine is in a well contained condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: CL520 | CL-520

more

Listing

Leipzig

7,966 km

ESTARTA 312

Call

Condition: used, Year of construction: 1996, grinding diameter: 1,5 - 75 mm grinding wheel diameter: 400 mm grinding wheel width: 160 mm work stroke: 0 - 1 mm working feed: stufenlos/ continous mm/min grinding wheel speeds: 1300 U/min control for program: Num 1020 GC total power requirement: 14 kW weight of the machine ca.: 3,8 t dimensions of machine: 3,0x2,2x2,2 m dimensions electric cabinet LxWxH: 1,5x0,4x2,0 m CIRCULAR GRINDING MACHINE - alloyed round steels as well as (grooving process) throughfeed process. - In the plunge process, the plunge-cut length is max. 160mm. - Workpiece removal automatically via rail (its function or operation is not known to WMW AG) - grinding wheel with reshaping device, speed = 1300 rpm. - regulating grinding wheel with reshaping device, infeed angle right 0-6° and left 0-2°; wheel size 280x160mm - automatic grinding wheel balancing system accessories: various grinding and regulating wheels on request Bevgtt9bqd The machine is operating in manual mode! The control is in the Catalan language and none of our employees can control the machine or understand the language.

more

Listing

Warren

1,240 km

ESTARTA 310

Call

Condition: used, ESTARTA CENTERLESS GRINDER Model 310 S/N Stock 6738 STANDARD SPECIFICATIONS CAPACITY Maximum grinding diameter……………... 2mm to 51mm Maximum infeed grinding length……………... 127mm Grinding wheel (dia. x width x bore)…mm x 178mm W x 127mm B Spindle speed…………….…...……….. 1,900 RPM Grinding wheel motor…………….……………. 10 H.P. Regulating wheel (dia. x width x bore)…03mm x 127mm x 127mm Regulating wheel speeds (4 speeds)…...…………. 22 to 335 RPM Approximate machine weight………...………….. 1542 kg Approximate machine dimensions...………..…… 1575mm L x 1041mm W x 1245mm H Eqe3ne2 EQUIPPED WITH 152mm Infeed work rest. Hydraulic grinding wheel dresser. Hydraulic regulating wheel dresser. 10 H.P. grinding wheel motor. Hydraulic pump motor.

more

Listing

Ried im Oberinntal

8,153 km

Centerless grindingmachine

JUNKER Jupiter 500

Call

Condition: used, Year of construction: 2008, machine/vehicle number: 5207, grinding diameter max.:3-220 mm regulating wheel width:500 mm max. width of grinding wheel:500 mm weight of the machine ca.:16 t. dimensions of the machine ca.:4,12x 2,052 x 2,49 m. grinding wheel diam. min/max.:420-610 grinding wheel diameter - width-internal grin:304,8 x 500 mm Regulatin wheel diameter min/max.:300-350 mm JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Kl77ms7m Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls.

more

Listing

Schijndel

7,556 km

KOEBAU Multimat 250

€80,000

centerless cylindrical grinding machine

Call

Condition: like new (used), Year of construction: 1990, Multimat 250 in excellent condition. Sharpening stone spindle made for 40M/s with 600mm stone Automatic dressing. Control disc 300mm continuously adjustable Max Ø100mm /Min Ø2mm main engine 22Kw ll original papers are included Svalx Electronics work perfectly The machine is powered and can be seen working

more

Listing

Staufenberg

7,810 km

NOMOCO VSR 3-120 (Drm. 50 mm)

Call

Condition: good (used), Year of construction: 1990, centerless cylindrical grinding machine make NOMOCO type VSR 3-120 machine no. 449 year of construction 1990 Technical data: WORKING RANGE: max. grinding length (for plunge grinding) 120 mm grinding diameter min/max. 1-50 mm grinding spindle tool holder taper 1:10 workpiece spindle swiveling +- 5° max. grinding wheel dimension 300x120x127 mm max. control wheel dimension 250x120x127 mm Spindle speed in 1/min VS 20 m/sec drive power 380 V 50 Hz 5,5 kW speed 1500 rpm. 9wvdkwm Outer dimensions 2,0x2,0x1,5 m weight approx. 2500 kg used, in good condition SPECIAL PRICE ex stock!!!

more

Listing

Böhmenkirch

7,999 km

Centerless cylindrical grinding machine

PALMARY GC 1810-NC Neue Maschine

Call

Condition: new, Year of construction: 2023, Grinding wheel DxB 455 x 255 mm workpiece diameter 1-60 mm, control disc DxB 255 x 255 mm, disc speed 10-100 rpm, power SS 11 kW, weight approx. to 3.7, size approx. 2,700 x 1,700 mm Machine is suitable to the pass and feed grinding, hardened and ground Guide pave grinding and control spindle with hydrodynamsicher three-point bearing, lubrication for carriage and delivery spindles, rule discs powered by DS engine, frequency controlled, hydraulic dressing equipment for grinding and rule disc. Equipment of electrical, predominantly with Siemens components, electrical cabinet in Germany built up, 9k9j0kxz9 GC 1810-NC stepper motor with Siemens S7 control for grooving and extra movement. Very economic price / performance ratio

more

Listing

Sondermaschinenbau Ernst Born CNC-Schleifmaschine

Biebertal

7,799 km

centerless grinding machine

Sondermaschinenbau Ernst Born CNC-Schleifmaschine

€12,000

Call

grinding wheel width: 25 mm, workpiece weight (max.): 5 kg, grinding wheel diameter: 160 mm, motor power: 2 W, total height: 160 cm, total width: 120 cm, total length: 140 cm, grinding diameter: 5 mm, input power: 2 kW (2.72 PS), grinding length: 300 mm, type of input current: AC, rotational speed (max.): 2,800 rpm, feed length X-axis: 500 mm, feed length Y-axis: 300 mm, travel distance Z-axis: 300 mm, Condition: ready for operation (used), Year of construction: 2005, Operating hours: 500 h, machine/vehicle number: CNC B1, CNC grinding machine for centering optical lenses, metal and ceramic parts can also be machined by converting chucks. ceramic parts can also be machined. Bgrthvtwg8f

more

Listing

Warren

1,240 km

centerless grinding machine

Landis 14R

Call

Condition: used, machine/vehicle number: 863-56, 14R LANDIS CENTERLESS GRINDER S/N 863-56 STANDARD SPECIFICATIONS WORK CAPACITY (DIAMETER) Regular thru feed and infeed work rests..... 12.7mm to 101mm B9kuo87xiy Heavy duty thru feed and infeed work rests..... 50mm to 152mm Bar grinding work rests..... 203mm max. WHEELS Grinding wheel, 304mm hole..... 25mm to 355mm widths 508mm max. dia. 355mm min. dia. Regulating wheel, 127mm hole..... 25mm to 355mm widths 355mm max. dia. 228mm min. dia. MOTORS Grinding wheel drive motor, totally enclosed..... 20 HP, 1800 RPM (40 HP available) Regulating wheel drive motor, totally enclosed..... 2 HP, 1800 RPM Wheel spindle lubrication pump motor, totally enclosed..... . . . . 1/4 HP, 1800 RPM Coolant pump motor, totally enclosed..... 1/3 HP, 1800 RPM Hydraulic oil pump motor, totally enclosed, for machine with hydraulic grinding wheel feed..... 3/4 HP, 1800 RPM REGULATING WHEELHEAD Maximum angle of tilt for thru feed grinding..... 7 Maximum swivel for taper grinding (including angle..... 7 Maximum angle of reverse tilt for thru feed grinding from rear to front..... 5 Spindle speeds when grinding..... 10 to 72 RPM Spindle speed for dressing..... 300 RPM HYDRAULIC GRINDING WHEELFEED Hydraulic rapid infeed..... 1.587mm to 25mm Hydraulic grinding feed..... 2.286mm COOLANT Reservoir capacity..... 100 gallons Pump capacity..... 30 GPM MACHINE WEIGHTS Net weight including electrical equipment..... 14,500 lbs. ADDITIONAL FEATURES Hydraulic truing on both sides Set up as thru feed grinder Free standing panel From Service Push button control station

more

Listing

Ulm

8,022 km

WMW MIKROSA SASL 125

Call

Condition: good (used), machine/vehicle number: 16.52 28 33, a well preserved centerless grinding machine Fab.MWM MIKROSA TYPE:SASL 125 Ba3numxr

more

Listing

Schijndel

7,556 km

Koebau multimat 130

KOEBAU multimat 130

€30,000

Centerless grinding machine

Call

Condition: excellent (used), Year of construction: 1988, needle diameter max. 85mm min0.85mm Grinding wheel width max. 150 mm Working range mm Speed m/min45m/sec Total power requirement 22.5 kW Machine weight approx. 4,500 t Space requirement approx. m k O E N I G & B A U E R centerless cylindrical grinding machine for plunge grinding Type M 150 - Year of construction approx. 1988 700907 _____ max. workpiece length for plunge cutting approx. 200 mm Grinding wheel size: Diameter x width max. 400 x 150 mm Control wheel dimensions: diam. x width max. 300 x 200 mm Grinding wheel speeds max. rpm resp. 45 m/sec Steer wheel speeds infinitely variable 10 140 / 230 rpm Inclination of the control wheel +3 / -5 degrees Cxaygqblg7 Battle of the two hydr. dressing slides approx. 200 mm Grinding wheel drive approx. 22 kW Total drive approx. 22.5 kW - 400 V 50 Hz Weight approx. 4,500 kg Accessories / special equipment The machine is a centerless grinding machine specially equipped for plunge grinding of cylindrical workpieces by hand See also our other advertisement multimat 250 transit machine

more

Listing

Beringen

7,986 km

DANOBAT-ESTRADA 301 MV

Call

Condition: excellent (used), Grinding diameter 1.5 - 50 mm Grinding wheel 300 x 125 x 175 mm Speed 10-250 rpm Idfpwrb0k GE FANUC QuickPanel control Misc. accessories MARCELS MASCHINEN AG

more

Listing

Gussago

8,221 km

Mikrosa SASL 5 CNC retrofit 5 axis - ms

Call

Condition: used, Year of construction: 2023, Grinding wheel width: 500 Fh8qdyl Grinding wheel diameter: 610 CNC: 5 axis (new) (3) Mikrosa SASL 5 CNC (size similar to Kronos M, MX, L) CNC overhaul and retrofit in progress full overhaul and CNC retrofit (pending) komplett Ueberholung + CNC retrofit Grinding wheel 500mm wide x 610mm dia. CNC 5 axis / 5 axis Mikrosa SASL 5 CNC complete overhaul and retrofit Grinding wheel 500 x 610 mm Regulating wheel 400 x 650mm Fixed center Complete mechanical overhaul Complete electrical overhaul Elimination of hydraulic movements Application CNC Siemens 840D 5 axes controlled in position with digital brushless motors: - Operating wheel axis motor with optical scale - 4 dressing axes: 2 on the grinding wheel, 2 on the regulating wheel - rotating axis with adjustable speed motor on regulating wheel - rotating axis with 55kW AC motor with inverter on grinding wheel to adjust RPM / peripheral speed (m/sec) Set-up for through-feed grinding and still customizable according to customer needs. Machine refurbished, grinding test in our warehouse is possible, CE certification, manuals, 12 months warranty also available Machines can be inspected in our warehouse in Gussago BS Google Map HERE INFO? . Machine Tools - Machine Tools Gussago (BS) - Italy Tel: +39 030 3733780 Centerless grinding is a procedure for grinding cylindrical bodies and is used for the mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, tips, etc. During centerless plunge grinding (plunge grinding), the workpiece is ground in one pass thanks to the translation of the wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the workpiece to work which is given to them with the aid of a tool. Through-feed grinding or also through grinding and longitudinal grinding: parts to be machined proceed uninterruptedly with axial advancement through the grinding gap.

more

Listing

Kirchheim unter Teck

7,977 km

TSCHUDIN Ecoline 400

Call

Condition: used, Year of construction: 2005, Working areas throughfeed-grinding: workpiece dia 1,5-50 mm Z08tcaw working area plunge grinding: workpiece dia 1,5-100 mm working area plunge grinding: greatest length 250 mm grinding wheel - outer dia max 400 mm grinding wheel inner dia 203,2 mm grinding wheel wide max 250 mm grinding wheel peripheral speed 50 m/s Grinding wheel Drive power with balancer 11 kW control wheel outer dia max 225 mm 127 mm control wheel width max 250 mm control wheel tilt angle max +5/-5 ° control wheel driving power 3,7 kW temperature 15-40 °C compressed air max 6 bar total power requirement kW weight of the machine ca. 4,5 t dimensions of the machine ca. 1880x2370x1950 mm

more

Listing

Warren

1,240 km

CNC centerless cylindrical grinding machine

Micron MD450-RDT-CNC

Call

Condition: used, machine/vehicle number: 4819, MICRON MD450-RDT-CNC CENTERLESS GRINDER Dzbylu S/N 4819 Year: 1999 STANDARD SPECIFICATIONS EQUIPMENT & FEATURES Fanuc 180-T controller. GWD – Servo w/ Diamond roll. RWD – Manual Comp w/ AC traverse. Servo transmission. Dual servo infeed. Loader assembly. Bunsi filtration unit w/ 211 GPM chiller. Hydraulic tank.

more

Listing

United Kingdom

6,838 km

CNC Centreless Grinder

Microrex- Dinatec ATN

Call

Condition: good (used), Year of construction: 1999, Dinatec Microrex ATN 1002 18" x 4" Grinding Wheel C3pyfowb 8" x 4" Control Wheel

more

Listing

Sauldorf

7,996 km

Nomoco VSR 4-180 CNC

€30,500

EXW ONO plus VAT

Call

Condition: excellent (used), Year of construction: 2011, Year of manufacture: 2011 (Revision + CNC) Machine - No.: 2493 Control: Siemens Sinumerik 840D Working range Ø: 2 - 80 mm grinding wheel: diameter: 406 mm wheel width max.: 180 mm Djq0mf Drive motor: 15 kW regulating wheel: Diameter: 350 mm disc width max.: 180 mm Drive motor: 20 Nm Dimension: 2.800 x 1.800 x 3.100 mm (L x W x H) Weight: 4.600 kg Voltage: 400V Fuse protection: 50A Accessories: - Vibratory feeder - belt filter - Oil mist extraction - feeding automation - Documentation in paper form Available immediately Without warranty

more

Listing

Neuss

7,653 km

Centerless cylindrical grinding machines

Call

Condition: as good as new (ex-display), Dear Sir or Madam, we would like to introduce our program of centerless cylindrical grinding machines. As new machine or retrofit we offer machines for plunge and through grinding. Dscnsjes3

more

Listing

Gussago

8,221 km

Cylindrical grinding machine (centerless)

Ghiringhelli M100 CNC 1A

Call

Condition: used, Wheel width: 100 Wheel diameter: 400 Centerless grinding machine - centerless Ghiringhelli M100 CNC 1A 400x100mm wheel CN 1 axis plunge + through feed grinding The machine can be seen working in our warehouse in Gussago BS. Mimu(dot)com machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass Qjad2 thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification gap.

more

Auction

LIDKOEPING CL 520

Condition: excellent (used), Functionality: fully functional, TECHNICAL DETAILS grinding diameter: 2,5 - 75 mm Bar grinding diameter: 2.5 - 50 mm grinding wheel diameter: 508 mm grinding wheel width: max. 254 mm Drill diameter: 203 / 229 mm Peripheral speed: 33 / 45 / 60 m/s regulating wheel diameter: 280 mm regulating wheel width: 254 mm drilling diameter: 165 mm speed worm gear: 10 - 200 rpm Speed bevel gear screw drive: 25 - 600 rpm MACHINE DETAILS motor power: 35 kW Dqhyazwpg footprint: 1500 x 4450 mm net weight: 7200 kg total weight: 8,6 t Transport volume: 17 cbm EQUIPMENT - 1 balancing device - 1 CNC drive motor on the regulating wheel - Automatic dresser - 2 hydraulic dressers - 1 through-grinding device

more

Listing

Warren

1,240 km

Centerless cylindrical grinding machine

Micron MD-600III4W

Call

Condition: used, machine/vehicle number: 4484, MICRON MD-600III4W CENTERLESS GRINDER S/N 4488 Year: 1997 EQUIPMENT & FEATURES Fanuc Powermate controller. GWD – Servo w/ Diamond roll. RWD – Manual Comp w/ AC traverse. Kjryivoz Servo transmission. Dual servo infeed. Bunsi filtration unit w/ 211 GPM chiller. Hydraulic tank.

more

Listing

Iserlohn

7,695 km

KOEBAU MULTIMAT 150-6

€18,500

Factory build NEW Centreless Grinder

Call

Condition: good (used), Year of construction: 1987, Centerless cylindrical grinding machine Make Koenig&Bauer Type:Multimat 150-6 Year.1987. Grinding diameter : 2 - 100 mm Largest workpiece length for plunge grinding : 250 mm More data See data sheet Machine in stock . Good general condition machine documentation available. Chpoptr7jl

more

Listing

7 Fraser Rd, Erith DA8 1PP, UK

7,247 km

JAINNHER JHC-12S

Call

Condition: new, With a capacity from 1 to 25mm with a standard workrest or 25 to 40mm with a special workrest, and a servo controlled regulating wheel, the JHC 12S is the most compact centreless grinder in the range. A precision ground, the hydrostatic bearing assembly provides minimal friction and lateral displacement, along with extended wheel life under heavy grinding loads. The grinding wheel spindle runs on the hydrostatic bearings with an ultra-thin oil film between all touching surfaces. This provides a substantial reduction in wear and prolongs spindle trueness and longevity. The regulating wheel uses a Variable Speed Motor, controls the speed of the regulating wheel. Specification Europa Jainnher JHC 12S Standard work rest diameter 1 - 25mm Optional work rest diameter 25 - 40mm Grinding wheel size : diameter x width x hole 305 x 150 x 120mm Regulating wheel size : diameter x width x hole 205 x 150 x 90mm Grinding wheel speed 1900 rpm Regulating wheel speed 10 - 300 rpm (variable speed) Grinding wheel motor 7.5 hp Regulating wheel motor 2 HP Hydraulic pump motor 1 HP Coolant pump motor 1 / 8 hp Regulating wheel feed on handwheel 4mm (rev) 0.02mm(Gra) Table feed on handwheel 7mm (rev) Bcyhpkvitit 0.05mm(Gra) Table micro feed on handwheel 0.2mm(rev) 0.001mm(Gra) Dressing handwheel 1.25mm (rev) 0.01mm (Gra) Regulating wheel tilt angle + 5 Deg -3 Deg Regulating wheel swivel angle +/- 5 Deg Floor space (approx) 1750 x 1350 x 1400 mm Net weight (approx) 1600 kgs Europa Jainnher JHC 12S Centreless Grinding Machine Standard Equipment Grinding wheel and grinding wheel flange Regulating wheel and regulating wheel flange Flange extractor Diamond tool Thrufeed standard workrest and blade Infeed standard workrest and blade Levelling screw and plate Tool box and tools Thrufeed process gauge Thrufeed safety device Work lamp

more

Listing

Böhmenkirch

7,999 km

Centreless cylindrical grinding machine

PALMARY PC 12-SPS

Call

Condition: new, Year of construction: 2023, Grinding wheel diam. 305x150 mm, workpiece diameter 1-40 mm, Bmmpqmy72m machine for plunge-cut and through-feed grinding, PLC-control, coolant system, hardened and ground guideways, grinding and regulating spindle with plain bearing over three-point bearing, hydraulic adjustable dresser for grinding and regulating wheel, regulating wheel drive adjustable over DS-motor, electrical cabinet German design with Siemens components,

more

Listing

Gussago

8,221 km

Centerless grinding machine

Ghiringhelli M300 SP600

Call

Condition: used, Grinding wheel width: 350 Grinding wheel diameter: 600 Ghiringhelli M300 SP600 (M12, M212) centerless grinding wheel 350x600mm plunge and though-feed grinding oscillating spindle fixed + rotary dresser we can overhaul and make cnc retrofit The machine is in our warehouse in Gussago BS. Mimu Machine Tools Italy Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. H8m8g2r9ax The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification gap.

more

Listing

Cestona

7,546 km

K-YUANG M10100

Call

Condition: good (used), Brand: K-YUANG Model: M10100 Grinding parts diameter: 10-100 mm Continuos Grinding (Standard frame): 210 mm Plunge feed: 195 mm Abrasion wheel specification P500 x 200 x305 mm Guide wheel specification: PSA 350 x 200 x 127 mm Abrasion wheel rotate speed: 1250 r/min Guide wheel rotate speed:(Infinite) 10-200 r/min Guide Wheel rotation Angel: In vertical plane: -2º- +5º In horizontal plane: 0º- +3º Feed hand wheel scale: 0.002 mm Plunge-cut-Grinding Stroke: Total Stroke Volume: 3.5 mm Quick Stroke Volume: 2-3.5 mm Slow Stroke Volume: 0-1.5 mm Length from Abrasion Wheel and the centre of Grinding Wheel to the underside of Bed: 255 mm Machine gross power: 22.46 kw B8g9j3ekxv Machine size (exclude electricity box, lubrication tank and water tank : 2675 mm x 1505 mm x 1615 mm Machine weight 5000 kg

more

Listing

Warren

1,240 km

Centerless grinder

Cincinnati 200 Series Viking

Call

Condition: used, machine/vehicle number: 9168A0196-0033, 203mm VIKING CNC 200 CENTERLESS GRINDER S/N 9168A0196-0033 New: 1996 STANDARD SPECIFICATIONS Work Capacity Maximum work piece diameter……………. 64mm Minimum work piece diameter……………. 1.3mm 2t90h3 Grinding Wheel Maximum new wheel diameter……………. 547mm Minimum worn wheel diameter with 16” wheel…………….. 270mm Maximum wheel width……………. 205mm Wheel mounting hole diameter……………. 203mm Type of support…………….. Twin Grip, removable spindle Type of bearing…………….. Anti-friction roller Type of lubrication……………. Grease packed Type of balancing Manual balancing…………… Standard Automatic balancing……………... Optional Grinding Wheel Drive Motor Motor…………….. 30 HP Drive belts…………….. 6 high cap narrow V Regulating Wheel Maximum new wheel diameter…………….. 305mm Minimum worn wheel diameter……………. 254mm Maximum wheel width……………... 254mm Wheel mounting hole diameter……………... 178mm Maximum RPM…………….. 600 RPM Minimum RPM……………... 10 RPM Drive motor (Servo)…………… 7.3 HP Housing swivel (work feed angle)…………….. + 6˚ to -6˚ Type of support…………….. Twin Grip, removable spindle Type of bearing…………….. Anti-friction roller Type of lubrication……………. Grease packed EQUIPMENT & FEATURES 15 HP spindle motor. Stand alone electrical panel. 203mm Thru feed work rest. 2 Axis CNC grinding & regulating wheel dressers. Coolant tank & pump.

more

Listing

Metzingen

(dealership location)

7,971 km

Centerless Round & Polishing Machine

KOENIG & BAUER MULTIMAT 150-5

Call

Condition: used, Year of construction: 1978, grinding diameter max. 100 mm regulating wheel width 200 mm max. width of grinding wheel 200 mm grinding diameter 100 mm grinding length 250 mm feed in mm working area mm speed m/min Bar length mm total power requirement 25 kW weight of the machine ca. 4.500 t dimensions of the machine ca. m K O E N I G & B A U E R (Germany) Centreless Grinder with Plunge-in Grinding Device Model Multimat 150 - 5 Year approx. 1978 S/Nr. 73 918 _____ Grinding Ø regular/maximal 2 50/100 mm Max. length of workpiece for Thru-Feed-grinding 250 mm Max. length of workpiece for plunge-cut grinding 200 mm Grinding wheel size, Ø x width 600 x 200 mm Regulating wheel size, Ø x width 300 x 200 mm Grinding wheel speed, max. 1.450 rpm/35 m/sec. Regulating wheel speeds (stepless) 10 140/230 rpm Regulating wheel tilt plus/minus +3 / 5 ° Stroke of Dressing Device 200 mm Grinding wheel drive, approx. 18,5 kW Total electrical load approx.. 25 kW - 380 V - 50 Hz Weight approx.. 4.500 kg Accessories/Special Features: * Machine is suitable for a Plunge-In Grinding Process with a manual workpiece Injection device and a pneumatic driven workpiece lift-off device after grinding Process. The final removal of the finished parts is by hand. Dyvb0i * Actually mounted a workpiece rest for medium sized workpieces, (maybe 50 mm) * The Regulating wheel slide/workpiece rest carriage can be inclinate by 3 to 5 degrees to compensate cylindrical errors. * The infeed adjustment of workpiece saddle is controlled by a hydraulic plunge-in device with a cam device for quick-feed forward and backwards, also there is a fine infeed actuated by a step motor controlled by MARPOSS Unit. * The grinding spindle unit is fixed and accommodates a complex hydraulic dressing device with template and the slide can be swivelled for profiling plane shoulders, stepmotor for the infeed of diamond tool compensation, also there is mounted a hi pressure coolant nozzle to cool down the diamond tool and to rinse the grinding wheel. * Hydraulic driven Copy Dressing device mounted above the regulating wheel. * The regulating wheel speed is steplessly adjustable, higher speed during dressing poc. * The control panel contains all machine functions like Numbers of dressing cycles, number of workpieces, adjustable spark-out time, speed range, manual or automatic process, etc. * some sep. Flanges and grinding and regulating wheels, tool for changing the flanges,separate Hydraulic and sep. Switch cabinet, central lubrication, MARPOSS Unit, * ! Actually there is no Coolant device available ! Condition : Good to very good. Machine can be inspected under power. Ideal for small batch production. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

more

Listing

Staufenberg

7,810 km

LÖSER RPS 374 mit 2 Schleifstationen

Call

Condition: good (used), Year of construction: 1990, centerless cylindrical and polishing grinding machine make LÖSER type RPS 374 Year of manufacture 1990 B9u8tjn33q Technical data: Grinding range 6 - 80 mm belt dimensions 2500 x 150 mm Feed speed 0 - 10 m/min. Max workpiece weight diameter range up to 80 mm approx. 10 - 15 kg Number of grinding stations 2 drive power per grinding station 5,5 kW with - supply and exhaust - cooling device used, in good condition

more

Listing

Bonneville

7,955 km

ROSSI 1500

Call

Condition: like new (used), 1 REBUILT CENTERLESS GRINDING MACHINE ROSSI 1500 - Stock N° : 7213 - Wheel width : 250 mm - Grinding wheel diameter : 508 mm - Row work - Manual dive Equipped with : - 2 Hydraulic diamond cutters Bk0ptycnpq - 1 Ruler holder for working in a row

more

Listing

Gussago

8,221 km

Hanwha centerless grindm. HCG-150 CNC

Monzesi Rossi Monza 510 CNC 6 assi - axis

Call

Condition: used, Year of construction: 2007, Wheel width: 250 Wheel diameter: 510 CNC: Fanuc 160i T CNC centerless grinding machine Monzesi mod Monza 510 CNC 6 axes complete with piece loading and unloading system CNC Fanuc 160i-T Under power in our warehouse in Gussago BS. Caxcprkcmi machine tools Italy

more

Listing

Immendingen

7,978 km

HANWHA HCG-150 CNC

Call

Condition: excellent (used), Year of construction: 2019, The grinding machine is currently set up for plunge grinding, but can be converted to through-feed grinding without much effort. Di9nd9 Grinding wheel with roller bearing CNC control Fanuc grinding wheel drive 11 kW grinding wheel DxBxID: [Ø 455 x 150mm x 228,6mm] Grinding wheel: [2,600 m/min.] regulating wheel drive 1,4 kW (servo motor) regulating wheel: [10-300 1/min] Control wheel: DxBxID: [Ø 305 x 150mm x 177,8mm] Grinding diameter workpiece: [Ø 1,0mm - Ø 50mm] Max. Workpiece length [150mm] Installation dimensions LxW: [2.750 x 1.450mm] + periphery Machine weight: [4.000 kg] + periphery Tool box wheel changing unit magnetic separator Grinding wheel dressing Z1 (3) CNC axis (feed) X1 (2) CNC axis (feed) Control wheel dressing Z2 (4) CNC axis option (infeed) X2 (5) CNC axis (feed) Underslide regulating wheel Y1 (1) CNC axis Top slide control wheel Y2 (6) CNC axis option Standard 4 CNC axes Z1, X1, X2, Y1 NC axis control wheel Y2 NC axis control wheel Z2 Coolant cooling unit Coolant cleaning with paper filter Change from standard. Machine cooling coolant oil.

more

Listing

Warren

1,240 km

KC-400 Centerless Grinder

KOYO KC400

Call

Condition: used, Year of construction: 1985, machine/vehicle number: 8511-0044, STANDARD SPECIFICATIONS B80ftpy3e7 Grinding capacity…………….…………… 3.0mm- 120mm Grinding wheel size……………..…………… 610mm x 405mm Grinding wheel dresser Profile. AC motor on traverse. Manual diamond advance. Regulating wheel dresser Profile. AC motor on traverse. Manual diamond advance. Equipment Regulating wheel drive……………. AC Variable Frequency Drive Servo compensation……………. Fanuc Thrufeed work rest…………….. ………….16” Allen Bradley controls. Stand alone electrical panel. 50 HP Spindle motor.

more

Listing

Metzingen

7,973 km

Centerless (centerless) cylindrical grinding masc

BRYANT 45 M / Serial No. B 16049

Call

Condition: used, Year of construction: 1973, grinding diameter max. 30 mm Buyhxaxq regulating wheel width 12 mm max. width of grinding wheel mm total power requirement kW weight of the machine ca. t dimensions of the machine ca. m

more

Listing

Mörsdorf

7,965 km

MAGNAGHI Milano Schleiflänge 130 mm

Call

Condition: used, Year of construction: 1969, Centerless (centerless) cylindrical grinding machine make MAGNAGHI Milano make # 20600, year of construction 11/1969 technical data: grinding length 130 mm grinding wheel dia. 340 mm grinding wheel width 120 mm max. grinding diameter 85 mm 4 speeds 18, 24, 34, 250 rpm, infeed via hand lever outside dimensions 1600 x 1200 x 1200 mm high with - hydraulics in the machine Zdkus used

more

Listing

Bonneville

7,955 km

LIDKOPING 46

Call

Condition: good (used), Grinding wheel : - Ø Ext : 508 mm Chgmg9i3 - Width : 610 mm Regulating wheel : - Ø Ext : 330 mm - Width: 610 mm - Working in-feed - Plunge work advance CNC motor 0.001 Equipped with : - 1 Electrical cabinet with SIEMENS PLC - 1 CNC plunge on the working wheel - 1 CNC motor on the control wheel - 1 External lubrication pump tank - 2 Hydraulic diamond cutters - 1 Ruler holder for working in a row

more

Listing

Gussago

8,221 km

Centerless Slant Bed Grinder

Monzesi Rossi Monza 500

Call

Condition: used, Monzesi Rossi Monza 500 centerless grinding Grinding wheel 250 * 500 auto plunge also available Electric/Electronic retrofit possible The machine is in our warehouse in Gussago BS, under power Mimu machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass Gyigq38gb thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification axial advancement through the grinding gap.

more

Listing

Warren

1,240 km

Koyo KC-300A

Call

Condition: used, Year of construction: 1991, machine/vehicle number: 9103.0355, KOYO KC-300A SLANT BED CNC CENTERLESS GRINDER Ih8hif2i0 STANDARD SPECIFICATIONS Grinding capacity…………….…………… 1.6mm- 120mm / .060" – 4.72" Grinding wheel size……………..…………… 610mm x 305mm / 24" x 12" Grinding wheel dresser……………..……………... 2 Axis with AC Stepper Motors Regulating wheel dresser……………..……………... 2 Axis with AC Stepper Motors Regulating wheel drive……………. AC Variable Frequency Drive Servo compensation……………. Fanuc Work rest…………….. 305mm / 12” Machine Features Fanuc OM CNC Controls. Stand alone electrical panel. Parts conveyor. Coolant tank & pump with paper unit. Twin grip grinder. Slant bed. Stepper compensation.

more

Listing

Mörsdorf

7,965 km

Centerless grinding machine

KOEBAU KOENIG & BAUER Multimat

Call

Condition: repair required (used), centerless cylindrical grinding machine make KÖBAU KÖNIG & BAUER type Multimat Make # 491889, WA3480 Technical data: Grinding wheel size 400 x 100 mm regulating wheel diameter x width 300 x 100 mm 11 speeds of the regulating wheel 10 - 90 rpm Drive power 15,5 kW dimensions L x W x H 2000 x 1700 x 1670 mm weight 2950 kg used, in good condition special price ex stock Mörsdorf because in need of repair a chain is missing in the machine the gears guiding the chain are defective Cziekpv2

more

Listing

Bonneville

7,955 km

Grinding machines - centerless - CNC

LIDKOPING 46

Call

Condition: good (used), Grinding wheel : - Ø Ext : 508 mm - Width : 610 mm Regulating wheel : - Ø Ext : 330 mm - Width: 610 mm - Working in-feed - Plunge work advance CNC motor 0.001 Equipped with : - 1 Electrical cabinet with SIEMENS PLC - 1 CNC plunge on the working wheel - 1 CNC motor on the control wheel - 1 External lubrication pump tank Czgmygafqw - 2 Hydraulic diamond cutters - 1 Ruler holder for working in a row

more

Listing

Gussago

(dealership location)

8,223 km

Ghiringhelli M2150 SP610 CNC 4 axis - ms

Call

Condition: used, Year of construction: 2021, Grinding wheel width: 200 Grinding wheel diameter: 610 CNC: 4 axes Centreless grinding machine GHIRINGHELLI M2150 CNC 4 axes grinding wheel 200x610 CNC 4 axes Variable speed drive on grinding wheel complete overhaul with electric / electronic retrofit Machine in our warehouse in Gussago BS Mimu machine tools (Italy) Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers Fhqmgn2uo cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification gap.

more

Listing

Warren

1,240 km

Centerless grinder

Koyo KC-200

Call

Condition: used, Year of construction: 1990, machine/vehicle number: 9001-267, KOYO MODEL KC-200 CENTERLESS GRINDER Grinding Capacity Outer diameter (O.D.): 1.524mm – 119mm Infeed work length: 299mm Grinding Wheel O.D. x width x bore diameter 609mm x 203mm x 304mm Min. O.D. 469mm Height (spindle center to floor) 1092mm Ifdnq7wae Regulating Wheel O.D. x width x bore diameter 330mm x 203mm x 203mm Min. O.D 279mm Tilt adjustment 5 Motors Grinding wheel 15 kW-4P 20 HP Regulating wheel 1.5 kW-6P EQUIPPED WITH Wheel dressers Thru feed work rest Coolant system with filtration Automatic size compensator (upper slide) Fine size compensator (lower slide) A/B PLC 2/16 Controls Omron power supply

more

Listing

Bonneville

7,955 km

CENTERLESS GRINDING MACHINE

ROSSI 300

Call

Condition: good (used), - Grinding wheel width: 100 mm - Working wheel diameter: 300 mm Equipped with : - 2 hydraulic diamond cutters - 1 Ruler holder for working in a row Voia33yv - 1 Manual dive

more

Listing

Gussago

8,221 km

MIKROSA KRONOS M CNC 6 axis

Call

Condition: used, Grinding wheel width: 250 Cguead3w9c Grinding wheel diameter: 610 CNC: Siemens 840D CNC centerless grinding machine Mikrosa Kronos M 6 axis Grinding wheel 250x610 mm complete with workpiece loader Siemens 840D CNC The machine is in our warehouse in Gussago BS Italy Mimu machine tools Centerless grinding is a procedure for grinding cylindrical bodies and is used for the mass production of rollers cylinders, tapered rollers, jet needles, pump pistons, hydraulic sliders, crosses, tips, etc. During centerless plunge grinding (plunge grinding), the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, grinding wheels and setting discs have a negative workpiece profile to work which is given to them with the aid of a tool. Centerless through-feed grinding or through-feed grinding and longitudinal grinding: workpieces to be machined proceed continuously with axial feed through the grinding gap.

more

Listing

Bonneville

7,955 km

VOUMARD 5A-

Call

Condition: like new (used), - Spindle diameter : 90 mm - Spindle speed : 3600 Tr/min - Grinding spindle power : 3,7 kW - Inter grinding diameter : 5 - 200 mm - Grinding depth : 250 mm - Max length of workparts to be ground : 500 mm Suy920 - Center height : 180 mm - Number of turns of spindle part holders : 6 - Speed headstock part holders : 500- 800 - 1000 Tr/min - Tilting headstock : 90° - Table travel : 3 - 600 mm - Table speed : 0,01 - 10 m/min - Weight of machine : about 2700 KG

more

Listing

Gussago

8,221 km
