Condition: good (used), Year of construction: 1973, FELLOWS 70-15 GEAR SHAPER - Model 70-15 Fellows heavy duty vertical gear shaping machine , suitable for the manufacture of external straight spur gears up to 70" pitch diameter, as well as internal spur gears and splines within a range of 0" to 88" pitch diameter, regardless of shaper-cutter radius. This unique feature, combined with the machines 15" face-width capacity and 1.7DP cutting capability in steel, provide a formidable platform for producing a wide range of larger geared part members. Equipped with: * Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction * Machine with "Saddle Backoff" Method of Cutter Relieving * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide * Cutter Positioning via Stroke Jog-Button * Rapid Rotation of Work Spindle for Trueing Work-Piece * Rapid Saddle Traverse for Traversing Saddle Relative to Work * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor Providing Speed Change on Finishing Cut * Assorted Work and Feed Change Gears * Assorted Stroke Change Gears * 2" Riser Plate * Main Drive Motor 15HP, 650/220 rpm, 240 Volt 60Hz w/Westinghouse Rectifier Unit for AC * Power Forced Lubrication to Working Elements with "Lubriquip Lub Controller" * Coolant Tank, Pump, and Piping, With Chip Pan * Full Complement of Electrics * Assorted Guards, Covers * 84" T-Slotted Table * Hydraulic System * Work Lamp * Work Platform * Cutter Adaptor * Manuals Specifications: Max. Diameter External Gear Cut (Nominal): 70" Max. Diameter Internal Gear Cut (Nominal): 88" Nwjdpfx Aportrxiohel Max. Diameter Workpiece Accommodated: 104" Worktable Diameter: 84" Max. Permissible Weight of Workpiece & Fixture: 36,000 Lbs. Max. Distance Workspindle Centerline to Centerline of Cutter Spindle: 35" Min. Distance Workspindle Centerline to Centerline of Cutter Spindle: 0" Max. Work & Fixture Clearance Height w/Cutter Spindle in Upper Position: 28" Max. Diametral Pitch (full length teeth): 2 DP Max. Diametral Pitch (stub teeth): .75 DP Max. Diameter Pitch (30P.A. splines): 2-5/5 DP Diameter of Cutter Spindle: 6.25" Max. Stroke Length: 19.118" Max. Face-Width (nominal): 15" Stroking Speeds (infinitely variable): 5 to 122 S.P.M. Max. Infeed of Cutter Ram: .0020 inch/min. Min. Infeed of Cutter Ram: .0005 inch/min. Max. Rotary Feed Per Stroke (per 1" of cutter diameter): .0068"/Min. Min. Rotary Feed Per Stroke (per 1" of cutter diameter): .0006"/Min. Approximate Machine Dimensions: 192"L x 144"W x 150"H Approximate Machine Weight: 95,000 Lbs.

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Equipped with: Hydraulic Workholding Pendant Control Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Nwedpjrtrykjfx Aphel Specifications: Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Nsdortrzdepfx Aphewl Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), Year of construction: 1993, Equipped with: 9" Cutter Head Power Stocks Crowning Auto Loader Heidenhein Scales Variable Feed/Speed Cutter Head RS232 Serial Port Trabon Lube Coolant W/Magnetic Chip Separator AC Servo Motors Full Splash Guards Stack Light Manuals Specifications: Nodpfx Aoruahwephowl Work Gear Pitch Diameter 9" & 12" Cutter Head: 1-12", 1-8" Work Gear Max. O.D. 9" & 12" Cutter Head: 12 1/2", 8 1/2" Diameter Pitch Range: 4-20 Distance Between Centers: 23" Cutter RPM 9" & 12" Cutter Head" 50-500, 50-400 Max. Table Travel Conventional, Tangential, Diagonal: 5", 2" 5"-2" Diagonal Traverse Angle Straight Shaving: 0 Deg. - 90 Deg. Traverse Angle Crown Shaving: 45 Deg. Max. Approx. Max. Table Angle Crowning: 5 Deg. Max. Table Angle Taper: 1 Deg 30' Max. Cutter Head Crossed Axes Angle Left & Right: 25 Deg. Table Cross Feed Inches Per Minute: .5-35 Table Up-Down Feed Inches Per Minute: .004-12.5 Table Up-Down Travel: 8 1/8" Approx. Weight: 9600 lbs

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Nedpfx Aeruakgophswl Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm Nwsdportrvyjfx Aphsl -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Stock Divider Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Index Plate Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Nwodsxdfa Ujpfx Aphol Overall Height: 70" Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25667, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System Nedpfx Apjy Tybnohswl SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Workpiece Spindle: -Speed: 0-7000 l/min -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: -Positioning Accurace: 9" Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Nwsdpjrualpofx Aphol Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: used, Year of construction: 1977, machine/vehicle number: 19909, Equipped with: Index Plate Geneva Cam Cutter Body Hydraulic Work Clamping Coolant Pump & Tank Chip Conveyor Additional Cutter Bodies, Index Plates & Geneva Cams Available Specifications: Nwedpfexdfazsx Aphol Minimum Outside Cone Distance: 2.75" Maximum Cone Distance: 10" Maximum Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 Deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 15.6 to 87.7 RPM Feeds (seconds/tooth): 5 to 34.3 Main Motor: 10hp, 1800 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approximate Floor Space: 118" x 86.5" Needed Overall Height: 70" Approximate Net Weight: 18,820 lbs Shipping Weight Boxed for Export: 20,500 lbs

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Nwjdpfxezn Aymo Aphsl Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 25734, wheel diameter: 700 mm, gear diameter: 1,000 mm, wheel width: 152 mm, workpiece spindle speed (max.): 67 rpm, feed length X-axis: 610 mm, feed length Y-axis: 610 mm, feed length Z-axis: 725 mm, pivoting range: 95 °, spindle bore: 203 mm, travel distance X-axis: 610 mm, travel distance Z-axis: 725 mm, Equipment: rotational speed infinitely variable, Equipped with: Fanuc 150MB Control Hydraulic Chucking Work Spindle Large Bore Work Spindle #80 Taper Stock Divider Helical Motion Modified Roll Hansen Coolant Chiller & Filtration Coolant Tank & Pumps Chip Conveyor Nwjdpfxsxaqa So Aphsl Chip Hopper Reven Mist Collector Hydraulic System Transformer Cutter Bolt Work Light Operator Platform Hand Tools Documentation Specifications: Extreme Ratio: Face Milling: 10:1, Face Hobbing: 10:1 Full Depth: Maximum: Face Milling:1.25" (31.75mm), Face Hobbing: 0.93" (23.50mm) Face Width: Maximum: Face Milling:6.00" (152.00mm),Face Hobbing: 3.00" (76.20mm) Range of Tooth Numbers: 1-300 Inclusive Gear Pitch Diameter, Maximum: 1000 mm (39.37") Cutter Size, Maximum: 18" (diameter) Face Milling Cutter Size, Maximum: 350 mm (radius) Face Hobbing Root Angle Range (B-Axis) 5 deg.to 90 deg., Face Hobbing:5 deg. to 90 deg. Machine Center to Work Spindle Face:9.00"Fixed, 229mm (Fixed) A-Work Spindle: 0 to 67 RPM, 0 to 333 RPM B-Swinging Base: 0 to 30 deg./sec, N/A C-Cutter: 0 to 500 deg., Same X-Horizontal: +/-305mm (+/-12") Y-Vertical: +/-305 mm (+/-12") Z-Sliding Base: -25/+700mm (-1/+28") B-Root Angle: -5 Degree/+90 Degree Diameter of Taper Hole at Large End: 8" (#80 Taper) to 6" (#60 Taper) Taper Per Foot:3/4", Same Depth of Taper Front:6", 152.40 mm Depth of Bore: 678 mm (26.7") Diameter of Taper Bore: 140 mm (5.5") Diameter Through Spindle of Hole:7.125", 180.98 mm MACHINE DIMENSIONS: Length x Width:233"x 209", 5920 mm x 5310 mm Height: 129", 3280 mm Weight: 65,000 lbs., 29,484 kg

Condition: excellent (used), Year of construction: 2003, 2003 Mitsubishi CNC Shaving Gear cutter grinder Model ZA30CNC, Year 2003, With Fanuc Series 16i-M HMI, Includes FN-0013 Dust Collector, Power 200/220 Volts / 3 Phase , Weight 15000 Lbs. Nsdpfx Aoywftkjphowl

Condition: good (used), Year of construction: 1976, max. wheel diameter 1250 mm gear width 1000 mm Njdpfx Apjzr Rpkshjwl max. module 16 shifting 250 mm milling spindle speeds (infinitely variable) 32 - 200 U/min min. number of teeth 12 table hole 255 mm total power requirement 32 kW weight of the machine ca. 20 t dimensions of the machine ca. 5,1 x 3,2 x 3,7 m Top condition! 2 cut cycle, change gears, arbors, chip conveyor. Following hob arbors are with the machine: Diameter: 32 , 40 , 50 , 60 mm

Condition: good (used), Year of construction: 1976, max. wheel diameter 2300 mm gear width 1000 mm max. module 22 min. module 1 total power requirement 45 kW Nedpfx Apszr Rpdehswl weight of the machine ca. 22 t dimensions of the machine ca. 5x3x4 m

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h total power requirement 45 kW weight of the machine ca. 7,8 t dimensions of the machine ca. 4,40x3,95x3,01 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nodpfx Apev Ehbbehjwl Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: good (used), Year of construction: 2007, max. wheel diameter 500 mm gear width 200-400 mm module 12 turning speeds 0-3250 U/min bracke pressure bis max. 95 Nm inner taper Konus #39 Control Fanuc 16 total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid Nodpfx Apsvr Hf Eshewl gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Nm.

Condition: used, Year of construction: 1971, hobbing length 1750 mm milling width 260 mm max. module 10 table size incl. water gutter 460 x 2100 mm table clamping surface: 250 x 1850 mm cutter width - max. 100 mm feed of the milling slide, stepless 0 - 500 mm/min. rapid traverse feeds 3000 mm/min milling head -swivable +/- 30 ° Rotation speed range of milling head, in 9 steps 29 - 178 rpm Milling head swivable 2 sides helical gearcutting 30 ° total power requirement 4 kW weight of the machine ca. 4 t dimensions of the machine ca. 4 x 1,85 x 1,85 m Milling length 1750 mm Milling width 260 mm Nwjdpfxsy Ayrre Aphjl Module - max. 10 Table dimensions incl. water channel 460 x 2100 mm Table clamping surface: 250 x 1850 mm Milling cutter width - max. 100 mm Feed of the milling carriage, infinitely variable 0 - 500 mm/min. Rapid traverse 3000 mm/min Milling head - tiltable + / - 30 ° Speed range of the milling spindle, in 9 steps 29 - 178 rpm Milling head swivels on both sides for helical gearing 30 ° Machine weight approx. 4 t Space requirement approx. 4 x 1.85 x 1.85 m Equipment/accessories - 7 vices - change wheels - Clamping devices - documentation

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) Nwjdpfxsxh Rqtj Aphol TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: used, Year of construction: 2012, grinding diameter 200 mm profile depth 30 mm workpiece length - max. 2790 mm grinding length 2310 mm Maximum pitch of the screw -/+ 50 ° Maximum number of gears 1-999 workpiece weight max. 250 kg Njdoza Hqzjpfx Aphewl z-travel 3000 mm x-travel 185 mm max. dia. of grinding wheel 450-330 mm Grinding wheel thickness (with recess) 20-70 mm roll diameter 120 mm Speed of the grinding wheel spindle 1500 - 6000 U/min Workpiece spindle speed 0 - 600 U/min Speed of the pitch axis 0-4 1/min Speed of the dressing spindle 1500-16000 1/min feed speed z-axis 0-10000 mm/min feed speed x-axis 0-10000 mm/min total power requirement 150 kVA control Siemens Sinumerik 840D SL weight of the machine ca. 30 t dimensions of the machine ca. 10,65 x 5,37 x 2,75 m Features/Accessories: - Filtration system: KNOLL VL1500/5000 - many accessories—list to follow - documentation

Condition: good (used), Year of construction: 2004, Ref. -No.: 10612 Manufacturer: LIEBHERR Type: LC 3002 Year of construction: 2004 Type of control: CNC-Steuerung Control: LIEBHERR Storage location: Halberstadt Country of origin: Germany Serial no.: 30XX Max. Module: 30 mm Min. Module: 4 mm Max. Workpiece Diameter: 3000 mm ambient temperature: +15...+38 ° cutting speed: 25 - 250 m / min Milling head swivel angle: 0,001 ° Resolution accuracy: 0,1 Degree Workpiece table load: 300 kN Njdpfx Apjzx Nyhjhowl Operating voltage: 400 V control voltage: 24 V frequency: 50 Hz Max. rated current: 230 A Fuse in the supply line: 250 A Max. milling diameter spur gears/helical gears: 3.000 mm Further information: Suitable for internal and external gear cutting. The machine can be viewed by appointment.

Year of construction: 2019, condition: as good as new (ex-display), Involute gear cutting tool Manufacturer: Gleason - Hurth Nwodpsfgwt Eefx Aphol Type: CH7M5R - 7B340-B1A 200 mm diameter unused delivered in a wooden crate Weight: 9.5 kg

Condition: refurbished (used), Year of construction: 2005, operating hours: 49,331 h, functionality: fully functional, We are selling this KLINGELNBERG OERLIKON tool grinding machine for a Swiss-based Italian group. Additional photos available upon request! Type: B24 Machine type: CNC tool grinding machine Year of manufacture: 2005 Machine No.: AVAILABLE UPON REQUEST CNC control: GE FANUC Series 160i-M Machining process: Wet grinding Automation: Automatic handling station with HIRATA robot Automation accessories: 6 different types of automation pallets / workpiece carriers Total weight: approx. 8,800 kg APPLICATION AREA Precision grinding of cutting tools Profiling of cutting tools Re-sharpening of cutting tools Machining of tools for bevel gear manufacturing Machining of main relief faces Machining of secondary relief faces Machining of chip faces Machining of facets Automated series machining MACHINABLE TOOL FACES A: Main relief face B: Secondary relief face C: Chip face K: Tool head / head face Facets possible on A, B and C faces Facet angle: approx. 1° GRINDING PROCESSES Deep grinding Oscillating grinding Spark-out grinding Rough grinding Finish grinding Straight grinding Angle grinding Form grinding Profile grinding Automatic intermediate dressing Automatic re-profiling of the grinding wheel Individual machining of single tool faces Programmable grinding cycles CNC AXES X-axis: Table longitudinal movement Y-axis: Vertical movement of the grinding wheel spindle Z-axis: Headstock transverse movement A-axis: NC rotary / swivel axis dividing head C-axis: NC rotary axis dividing head Dividing head: NC-controlled 2-axis dividing head A1-axis: Robot axis B1-axis: Robot axis W1-axis: Robot axis Z1-axis: Robot axis Z2-axis: Vertical magazine movement GRINDING SPINDLE Pre-loaded precision ball bearings Automatic grinding wheel diameter compensation Automatic grinding wheel speed compensation Automatic electromechanical balancing system Grinding wheel breakage detection Automatic coolant supply GRINDING WHEELS Grinding material: Diamond / CBN Grinding wheel diameter: Ø 300 mm / Ø 400 mm Grinding wheel width: 40 mm with spacer ring Grinding wheel width: 50 mm without spacer ring Grinding wheel Ø 400 mm at 25 m/s: 1,192 rpm Grinding wheel Ø 400 mm at 30 m/s: 1,431 rpm Grinding wheel Ø 400 mm at 35 m/s: 1,670 rpm Grinding wheel Ø 300 mm at 25 m/s: 1,591 rpm Grinding wheel Ø 300 mm at 30 m/s: 1,909 rpm Grinding wheel Ø 300 mm at 35 m/s: 2,228 rpm Max. documented grinding wheel speed: 2,228 rpm DRESSING SYSTEM Integrated automatic dressing system Automatic dressing Intermediate dressing during the grinding process Automatic re-profiling Profile correction Programmable dressing parameters Compensation for grinding wheel wear MEASUREMENT AND TEMPERATURE COMPENSATION Measuring system: MARPOSS Automatic temperature compensation Measurement relative to the radial reference surface Nedpfx Aoz Ermnsphowl Measurement relative to the axial reference surface Automatic correction of the Y-axis Automatic correction of the Z-axis Temperature compensation during form grinding via the dressing process AUTOMATION Robot manufacturer: HIRATA 4-axis Automatic swivel module 2-finger parallel gripper Inductive proximity switches Pneumatic gripper components Automatic workpiece handling VERTICAL MAGAZINE Magazine positions: 20 Automation pallets: 6 different types Additional workpiece carriers / pallets available

Condition: used, Year of construction: 2018, max. wheel diameter 450 mm max. module 4 mm Control Siemens 840 D sl internal diameter 100-300 mm weight of the machine ca. 11 t dimensions of the machine ca. 5,85 x 8,30 x 3,80 m GLEASON-PFAUTER 300 PS Gear Skiving Machine – Year 2018 For sale is a high-performance CNC gear skiving machine type GLEASON-PFAUTER 300 PS, built in 2018. The machine is ideally suited for the precise machining of internal gears and offers excellent dynamics, advanced CNC technology, and a robust machine design. Equipped with a powerful Siemens 840D sl CNC control, this machine provides optimal conditions for efficient and repeatable gear manufacturing processes. Technical Specifications - Max. gear diameter: 450 mm - Max. module: 4 mm - Internal diameter range: 100 – 300 mm - Max. allowable skiving cutter diameter: 175 mm - Mounting surface diameter: 125 mm - Axis Travels: X-axis travel: 350 mm Y-axis travel: 300 mm Z-axis travel: 440 mm - Max. skiving head swivel angle: ±25° - Workpiece table outer diameter: 570 mm - Max. table load capacity: 5 kN - Feed Rates and Speeds X-axis feed rate: 12,000 mm/min Y-axis feed rate: 5,000 mm/min Z-axis feed rate: 8,570 mm/min - Tool speed: 0 – 3,000 rpm Nwodozupl Nopfx Aphol - Workpiece table speed: 0 – 1,500 rpm Additional Equipment / Information - CNC Siemens 840D sl - Swivel gripper slide travel: 180° - Operating voltage: 400 V - Machine weight: approx. 11 t - Space requirement: approx. 5.85 × 8.3 × 3.8 m - Hydraulic oil capacity: 150 l - Coolant capacity: 850 l - Motor and hydraulic cooling: 100 l The machine is in very good condition and is ideally suited for demanding series production and high-precision gear manufacturing applications. Inspection by appointment possible.

Condition: good (used), Year of construction: 1998, Max. Pitch circle diameter External gearing 300 mm Max. Pitch circle diameter internal gearing 300 mm Max. Outer diameter of workpiece (equipment) 450 mm max. module 6 gear hobbing width -max. 100 mm Max. Helix angle (with tool Ø 125 mm) +/- 45 ° strokes - infinitely variable 130 - 1300 Hub/min workpiece weight 1000 kg Minimum distance table top - tool spindle -55 / +300 mm Maximum distance table top - tool spindle 200 mm Maximum distance table top - tool spindle 350 mm Manual Upright side shift +/- 25 mm Manual swivelling angle of the tool spindle +/- 0,5 ° Max. Tool speed 15 UpM Max. Workpiece speed 27 UpM Max. Tool diameter 7 Zoll voltage 400 V frequency 50 Hz Max. Line power 70 A total power requirement 48 kW weight of the machine ca. 11 t dimensions of the machine ca. 4,27 x 3,11 x 2,87 m table hole 40 mm control Siemens Sinumerik 840 C taper in main spindle SK 45 Gleason PFAUTER gear shaping machine Mod. PSA 300 The CNC modular gear shaping machine with skiving cutter for the machining of Nwsdpfx Apevu E Nujhjl external and internal cylindrical gears, with straight or helical involute with straight or helical involute toothing, as well as any other profile splitting process. The work cycle is controlled by a CNC unit, with specific software for machining the gears, machining. Field of application --> The PSA 300 has been designed for the production of: - Gears with straight external teeth - Gears with straight internal teeth - Gears with external helical teeth - Gears with internal helical teeth
