Used gear grinding machines for sale (29)

Condition: used, Year of construction: 1997, Technical details: max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm Ppsdpex Aq Egjfx Aczou max. workpiece weight: 60 kg without filter *

Condition: used, Year of construction: 1998, Technical details: max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 Podpfxozgw I Nj Aczopu max. top circle diameter: 360 mm max. workpiece weight: 60 kg with Turbo Separator, loading unit, latest-generation balancing and dressing unit and various accessories *

Condition: excellent (used), Year of construction: 1991, max. wheel diameter 10 - 330 mm gear width 180 mm max. module 7 min. module 0,5 clamping length 420 mm number of teeth 10 - 600 ical angle +/- 45 ° Ppodpfszd Hgiox Aczsu turning speeds 1100 - 1900 U/min grinding wheel diameter 280 - 350 mm grinding wheel width 84 - 104 weight of the machine ca. 5,1 t dimensions of the machine ca. 4,5 x 6,0 x 2,3 m

Condition: excellent (used), Year of construction: 2024, operating hours: 12,675 h, functionality: fully functional, A total of four identical KAPP gear grinding machines are for sale. KAPP NILES KX 260 TWIN Machine type: CNC gear grinding center / hobbing and profile grinding machine Manufacturer: KAPP NILES GmbH & Co. KG Number of machines for sale: 4 Podpfezdv Shox Aczjpu Address according to nameplate: Callenberger Straße 52, 96450 Coburg, Germany Model: KX 260 TWIN OEM machine number: XXX Year of manufacture: 2024 Inventory No. PPS: XXX Control: Siemens SINUMERIK Machine concept: TWIN / dual-spindle concept with rotary table Machining process: continuous hobbing grinding, optional profile grinding Automation concept: automatic loading, robot cell / FANUC loader visible Robot: FANUC Robot M-710iC/45M visible Condition: machine is powered on / screen is active / very modern, clean overall impression Manufacturer's specifications KX 260 TWIN Max. face diameter: 260 mm Max. workpiece length: 770 mm Module range: 0.5 – 6 mm Max. gear width: 320 mm, with corresponding design up to 520 mm Max. helix angle: ±45° These values correspond to the KAPP-NILES-KX-TWIN series; KAPP NILES describes the KX 260 TWIN as a machine for continuous hobbing grinding with dressable and undressable tools and specifies exactly these limit values for the KX 260 TWIN. Technical machine concept According to KAPP NILES, the KX TWIN series is designed for high production volumes in the medium and large series production of gears and shafts. The concept includes two identical workpiece spindles, which are arranged opposite each other on a rotary table. While one workpiece is being machined, the second workpiece spindle can be loaded and unloaded in parallel and aligned. Equipment / visible features Siemens SINUMERIK CNC control KAPP NILES operating interface TWIN spindle concept / two workpiece spindles Rotary table / indexing table Automatic loading cell FANUC M-710iC/45M robot Robot gripper / handling gripper visible Protective housing / safety cell Grinding wheel mounting / grinding spindle area visible Profile / hobbing grinding area visible Coolant / grinding oil area Work area lighting Full protection cabin Manual control unit / electronic handwheel on the control panel Signal light / traffic light CE marking visible on the machine housing Documentation holder / machine documents visible on the machine Electrical data according to nameplate Normal supply: 400 V AC Frequency: 50 Hz Normal power supply voltage: 400 V AC Control voltage: 24 V DC Lighting: 22 W / 230 V Installed power: 110 kVA Rated current: 79 A cos φ: 0.64 Fuse: 100 A gL Control cabinet weight: 1,000 kg Operating hours according to the counter in the photo T1 Total operating time: approx. 12,675 h T2 Net operating time: approx. 5,538 h Additional photos and videos available upon request.

Condition: used, Year of construction: 1988, functionality: fully functional, Gear Grinding Machine VEB ZSTZ 630 C 3 P – 1988, Ready to Operate Description: For sale: gear grinding machine from the German manufacturer VEB Werkzeugmaschinenkombinat, model ZSTZ 630 C 3 P, year of manufacture 1988. The machine is in good technical condition, available immediately, and ready for inspection. Currently connected to power, allowing immediate testing of its operation. Ideal for workshops specializing in precise gear machining and industrial machine repair. Specifications: Manufacturer: VEB Werkzeugmaschinenkombinat Model: ZSTZ 630 C 3 P Year of manufacture: 1988 Condition: good technical condition Availability: immediate Psdpfeyfq E Hsx Aczspu Ready for inspection, connected to power Contact: Please contact us for inspection arrangements or further information.

Condition: used, Year of construction: 1993, max. wheel diameter 330 mm gear width 180 mm Psdpfst Hwyfex Aczspu total power requirement 12 kW weight of the machine ca. 7500 kg

Condition: excellent (used), Year of construction: 2011, operating hours: 72,728 h, TECHNICAL DATA WILL ONLY BE SENT BY EMAIL. Ppsdpfxezav Nme Aczsu

Condition: excellent (used), Year of construction: 2011, operating hours: 79,920 h, Technical data will be sent by email. Ppodpfxozav Ips Aczsu

Condition: used, Year of construction: 2008, control Siemens 840D Ppjdpfswzypnex Aczsu

Condition: ready for operation (used), Year of construction: 1982, functionality: fully functional, A used Reishauer RZ300E II gear grinding machine with a dressing device from Fässler is available. The machine is connected to the control cabinet. The balancing device is fully functional. The oil pan is also included. The change gears are included. The buyer is responsible for dismantling and loading the machine. Podjy R Nqaopfx Aczspu

Condition: used, Year of construction: 2012, Technical details: max. wheel diameter: 260 mm gear width: 320 mm max. module: 5 weight of the machine ca.: 21 t Podpfxjy Amlls Aczepu dimensions of the machine ca.: 8,71 x 5,97 x 3,49 m no. of teeth: 1...999 max. helix angle: +45/-45 ° pitch min.: 0,1 mm pitch max.: 1000 mm X-axis: 345 mm y-axis: 250 mm Z-axis: 320 mm b-axis: 360 ° c-axis: 360 °

Condition: good (used), Year of construction: 1972, max. wheel diameter 80 mm gear width 60 mm max. module 3 Ppedpfxew N S D Ss Aczsu min. module 0,1 total power requirement 0,4 kW weight of the machine ca. 120 kg dimensions of the machine ca. 0,6x0,6x0,75 m

Condition: used, Year of construction: 2003, Control BWO tip circle diameter max. 700 mm root circle diameter min. 50 mm height of profile max. 35 mm number of spindle speeds 0 - 5400 min-1 table load capacity max. 500 kg Overall size 370x220x300 cm Total weight, approx. 15000 kg Number of working hours 94082 h Equipment: BWO control system All axes CNC controlled Oil mist extraction Coolant cleaning system with cooling unit Dittel balancing unit Accessories: Grinding wheels Ø400mm incl. Grinding wheel flanges Ppsdpfx Aext Ur Seczeu 1 diamond dressing roller, manufacturer Dr. Kaiser, Ø160mm Counterholder tip Control cabinet: Width 70 cm x length 280 cm x height 220 cm Machine: Width 220 cm x length 370 cm x height 300 cm Coolant system: Width 170 cm x length 240 cm x height 250 cm

Condition: used, Year of construction: 2007, control Siemens Sinumerik 840 D weight 57.000 kg voltage 400 V Gleason PFAUTER CNC gear hobbing machine P 2400/2800 for gear cutting of cylindrical and worm gears as well as all other regularly occurring rollable profiles and shapes on the cylindrical workpiece circumference. Large gear hobbing machines from Gleason offer maximum productivity for roughing and finishing cylindrical gears for many industries: wind turbines, industrial gearboxes, mining and shipbuilding, gear machining and many more. The power range of the drive takes future tool developments into account. Of course, the gear hobbing head drive is also backlash-free. These machines are particularly well suited for use with state-of-the-art, cutting materials, regardless of whether dry or wet machining is preferred. The machine can be used for dry or wet machining and is also equipped with the appropriate chip conveyor for both machining methods. The machine is equipped with an internal profile milling head as a motorised Ppjdpfx Aswzyp Ijczsu milling head. --> Working range and technical data Nominal workpiece diameter: 2.400 mm --> Largest millable diameter approx.: 2.800 mm --> Smallest/largest distance between cutter and workpiece axis: 100/1.200 mm --> Largest axial slide travel (special design): 1.300 mm --> Largest clampable cutter (internal milling head): --> Diameter max: 440 mm --> Max. cutter width: 90 mm --> Swivel range of the internal profile milling head/vertical axis: +/- 15° --> Milling mandrel taper: HSK-B160 --> Maximum milling cutter travel: 300 mm --> Table diameter: 2.500 mm --> Part wheel diameter: 2.200 mm --> Table bore --> Diameter: 800 mm --> Depth: 875 mm --> Maximum table load approx.: 40.000 kg --> Max. feed and rapid traverse speeds: --> axial (Z-axis): 4.000 mm/min --> radial (X-axis): 3.000 mm/min --> tangential (Y-axis): 3.000 mm/min --> Milling cutter cooling lubrication device/electric centrifugal pump: approx. 150 l/min --> Increased drop height of magnetic chip conveyor: 1,600 mm --> Increased main stand: 1,300 mm axial slide travel --> Internal profile milling head as motor milling head instead of standard motor milling head --> Max. millable profile depth in steel with approx. 600 N/mm² strength: approx. 65 mm --> Infinitely variable milling speed: 50 - 150 min?¹ --> Max. milling cutter diameter: 440 mm --> Min. milling cutter base circle diameter: 310 mm --> Max. milling cutter width: 90 mm --> Min. internal diameter at 0° bevel angle: 800 mm+) --> Max. workpiece height at 0° bevel angle: 600 mm --> Max. workpiece ring thickness (including clamping device): 500 mm

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens 840D max. workpiece dia. 1600 mm max. module 20 mm Ppodpfjwzypuox Aczeu tip circle diameter 350 mm weight of the machine ca. 33500 kg dimensions of the machine ca. 10,53 x 6,38 x 4,68 m Technical details: - x-travel: 900 mm - y-travel: 300 mm - z-travel: 1000 mm - Control system: Siemens Sinumerik 840D - Workpiece diameter - max.: 1600 mm - Module - max.: 20 mm - Head circle diameter: 350 mm - Milling spindle diameter: 375 mm - Total power consumption: 80 kVa - Machine weight approx.: 33500 kg - Space requirement approx.: 10.530 x 6.375 x 4.680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in 1/min: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - Motor milling head M 2 - Milling mandrels - Oil cooler - Technical documentation

Condition: used, Year of construction: 2006, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm spindle speeds (infinitely variable) 6000 U/min work piece spindle speed 1200 U/min diameter of tools max. 230 mm diameter of tools min 69,85 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm b-axis + 90,1 / - 1 ° work piece table - Ø 212,71 mm Podpfx Acjvxwr Aszspu Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m coolant filtering unit Hoffmann HSF 100 V

Condition: used, Year of construction: 1972, Technical details: grinding wheel diameter: 400 mm total power requirement: 3 kW weight of the machine ca.: 1,5 t dimensions of the machine ca.: 1,5 x 1,4 x 1,3 m Dressing Grinder for gears REISHAUER AM max. width of grinding wheel 104 mm max. dia. of grinding wheel 400 mm max. module 7 min. module 0,5 pressure angle 10 - 30 ° grinding worm dia. 270 - 400 mm width of grinding worm 62/84/104 mm grinding worm turning speeds: at profiling 18/35/70 U/min Ppjdpjwi Ni Tefx Aczju electrics - voltage/frequency 380 / 50 V/Hz long. movement of crowning device 156 mm *

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 73866, workpiece weight (max.): 60 kg, rotational speed (max.): 2,300 rpm, overall weight: 5,000 kg, TECHNICAL DETAILS Module, max.: 7 Grinding worm diameter: 280–350 mm Grinding worm width: 84–104 mm Grinding worm speed (grinding): 1,100–2,300 rpm Grinding worm speed (profiling): 50–95 rpm Number of teeth, min.: 6 Number of teeth, max.: 600 Maximum permissible outside diameter: 360 mm Maximum workpiece weight: 60 kg Maximum grinding stroke: 175 mm Workpiece speed (grinding): max. 250 rpm MACHINE DETAILS Podpoxvrziofx Aczjpu Machine weight approx.: 5 t Electrical Data Mains connection: 3 × 400 V 50 Hz Machine voltage: 3 × 400 V 50 Hz Control voltage: 1 × 230 V 50 Hz / 1 × 24 V DC Contactor voltage: 1 × 24 V DC Solenoid valve voltage: 1 × 24 V DC

Condition: ready for operation (used), functionality: fully functional, One used CNC gear grinding machine OERLIKON Opal 800 Max. tip diameter: 1000 mm Min. root diameter: 40 mm Ppjdpfxoyucd Hj Aczju Min. module: 1 Max. module: 16 Number of teeth: 999 Max. gear width: 630 mm Opal grinding wheel and diamond disk Only single profile grinding possible, see photo.

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm gear width 320 mm max. module 4,5 min. module 0,5 Control SIN 840D ical angle +/- 45 ° total power requirement 68 kW weight of the machine ca. 15,50 t Ppodpfx Acox R U Hgezju dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Wekal loading cell

Condition: used, Year of construction: 2012, max. wheel diameter 300 mm gear width 320 mm max. module 10 min. module 0,5 Pedox R U Hajpfx Aczjpu ical angle 45 ° frequency 50 Hz voltage 400 V main fuse 125 A x-axis 270 mm y-axis 250 mm z-axis 320 mm A - axis +/- 45 ° B - axis 360 ° C-axis 360 ° total power requirement 89 kW weight of the machine ca. 23,5 t dimensions of the machine ca. 11,2 x 5,5 x 2,9 m automated Oil slinger station EWAB workpiece storage Hoffmann coolant filter system HSF 100 SE/K Minimax fire extinguishing system W+W air filter system Promot Automation "Cellmaster" (3 cells) year 2019

Condition: used, Year of construction: 1983, max. wheel diameter 1500 mm gear width 550 mm max. module 25 min. module 2 workpiece weight max. 6000 kg Ppedpfx Acsyq Szajzju max. number of teeth 432 min. number of teeth 12 table diameter 990 mm grinding wheel size 400 mm total power requirement 75 kW weight of the machine ca. 20,5 t With tailstock max. wheel dia. 1250mm, without tailstock 1500mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2008, max. wheel diameter 700 mm max. module 10 (18) min. module 1 table diameter 530 mm Table speed max. 350 1/min Distance of shafts 50 - 680 0 workpiece weight 4.000 kg Axial travel 1.000 mm tangential adjustment 300 mm pivoting angle + / - 45 Grad Pjdpfxeyv Ipfe Aczjpu power capacity 32 kW spindle turning speed range 3.500 - 12.000 U/min tool diameter 320 mm total power requirement 80 kW weight of the machine ca. 25,00 t

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, Grinding worm dimensions: Min./Max. outer diameter: 280/350 mm Width: 84/104 mm Max. pitch with limitations: MOD 8.0 (DP 3.2) Number of threads: up to 3 with limitations Max. usable width (shift distance): 90 mm Ppsdjyfnlkspfx Aczju For detailed technical information, please refer to the attached PDF file. Accessories: Several Fässler diamond wheels Dressing device Grinding stones Turbo separator

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, workpiece weight (max.): 500 kg, The HAAS Multigrind CB is a universal multifunctional grinding machine designed for grinding gear cutting tools, involute profiles, and spline shaft profiles. Thanks to its large axis travels of 700 x 410 x 500 millimeters, its robust stability, a spindle power of 30 kW, and a high feed rate of 30 meters per minute, it is optimally equipped for custom grinding applications. Technical Data Diameter: 500 mm Axis travels: X 700, Y 410, Z 500 mm Pjdpfx Aox Uwqpsczepu Dimensions: 3.0 x 2.65 x 3.65 m Machine weight: approx. 8,500 kg *All information and data is non-binding, subject to prior sale. Key Features: Software: For grinding straight and helical flute hobbing cutters with dressable and non-dressable grinding wheels, grinding involute profiles and spline shaft profiles by importing .dxf files Accessories: Various grinding arbors: Ø 27, Ø 32, Ø 40, Ø 50, Ø 60, Ø 80, grinding wheel adapters and Hainbuch collet chucks.
