Used Gear shaping machines for sale (46)

Condition: excellent (used), Year of construction: 2002, Functionality: fully functional, feed length X-axis: 230 mm, feed length Y-axis: 25 mm, feed length Z-axis: 150 mm, workpiece diameter (max.): 300 mm, nominal diameter: 130 mm, TECHNICAL DETAILS Control: Siemens 840 D Nominal module in steel with approx. 600 N/mm² tensile strength: 4 Largest tooth width: 25 mm Largest nominal diameter: 130 mm Largest helix angle when using 125 mm diameter cutting wheels: ± 45° Workpiece with internal gearing Nominal module in steel with approx. 600 N/mm² tensile strength: 4 mm Largest tooth width: 25 mm Largest swing diameter: 300 mm Largest inner diameter: 130 mm Tool Largest permissible cutting wheel diameter: 175 mm Cutting wheel holder – diameter: 1.5 inches Cutting wheel holder – taper in the shaping spindle: PKP 45 hollow steep taper – Bauer Travel paths Radial (X-axis): 230 mm Manual transverse column adjustment (Y-axis): ± 25 mm Adjustment range of the axial slide (Z-axis): 150 mm Workpiece table Outer diameter: 168.14 mm Bore: 65.532 mm Spindle spindle Largest stroke length (V-axis): 30 mm Spindle axis adjustment range: ± 0.25° Bwjliowc Tg Njktrzol MACHINE DETAILS Length: 6,435 mm Width: 4,560 mm Height: 4,400 mm Weight: approx. 11,000 kg

Condition: good (used), Year of construction: 1973, FELLOWS 70-15 GEAR SHAPER - Model 70-15 Fellows heavy duty vertical gear shaping machine , suitable for the manufacture of external straight spur gears up to 70" pitch diameter, as well as internal spur gears and splines within a range of 0" to 88" pitch diameter, regardless of shaper-cutter radius. This unique feature, combined with the machines 15" face-width capacity and 1.7DP cutting capability in steel, provide a formidable platform for producing a wide range of larger geared part members. Equipped with: * Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction * Machine with "Saddle Backoff" Method of Cutter Relieving * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide * Cutter Positioning via Stroke Jog-Button * Rapid Rotation of Work Spindle for Trueing Work-Piece * Rapid Saddle Traverse for Traversing Saddle Relative to Work * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor Providing Speed Change on Finishing Cut * Assorted Work and Feed Change Gears * Assorted Stroke Change Gears * 2" Riser Plate * Main Drive Motor 15HP, 650/220 rpm, 240 Volt 60Hz w/Westinghouse Rectifier Unit for AC * Power Forced Lubrication to Working Elements with "Lubriquip Lub Controller" * Coolant Tank, Pump, and Piping, With Chip Pan * Full Complement of Electrics * Assorted Guards, Covers * 84" T-Slotted Table * Hydraulic System * Work Lamp * Work Platform * Cutter Adaptor * Manuals Specifications: Max. Diameter External Gear Cut (Nominal): 70" Max. Diameter Internal Gear Cut (Nominal): 88" Max. Diameter Workpiece Accommodated: 104" Worktable Diameter: 84" Max. Permissible Weight of Workpiece & Fixture: 36,000 Lbs. Max. Distance Workspindle Centerline to Centerline of Cutter Spindle: 35" Min. Distance Workspindle Centerline to Centerline of Cutter Spindle: 0" Max. Work & Fixture Clearance Height w/Cutter Spindle in Upper Position: 28" Belikjrtrxijtrzowl Max. Diametral Pitch (full length teeth): 2 DP Max. Diametral Pitch (stub teeth): .75 DP Max. Diameter Pitch (30P.A. splines): 2-5/5 DP Diameter of Cutter Spindle: 6.25" Max. Stroke Length: 19.118" Max. Face-Width (nominal): 15" Stroking Speeds (infinitely variable): 5 to 122 S.P.M. Max. Infeed of Cutter Ram: .0020 inch/min. Min. Infeed of Cutter Ram: .0005 inch/min. Max. Rotary Feed Per Stroke (per 1" of cutter diameter): .0068"/Min. Min. Rotary Feed Per Stroke (per 1" of cutter diameter): .0006"/Min. Approximate Machine Dimensions: 192"L x 144"W x 150"H Approximate Machine Weight: 95,000 Lbs.

Condition: good (used), Year of construction: 2003, max. ram stroke 100 mm max. module 8 table diameter 400 mm workpiece diameter 600 mm strokes per minute 80-1200 Hübe/min Feed radial axis from - to 1 - 3750 mm/min angle adjustable from - to - 0,5 / + 0,5 Grad Accessories: - Various tool holders - Various clamping devices Bsliktovfwuqerzewl - Documentation

Condition: good (used), Year of construction: 2005, Functionality: unexamined, machine/vehicle number: 29406, Lot consists of: (1)CNC Gear Shaping Machine Position consists of: (1) CNC gear shaping machine Technical Details/Technical Details: English: Bwolisv R Tmtoktrzjl max dia 130mm, max face width 25mm, min/max module 0.5-4, strokes 500 - 2,500 1/min, spindle dia 85mm, CNC Siemens Sinumerik 840D, 400V 50Hz 49kW, LxWxH 6.4x4.5x4.4m, weight 12to Parts Gantry System and/or Cranes are not included in the scope. German: max. diameter 130mm, max. face width 25mm, min./max. Module 0.5-4, strokes 500-2,500 rpm, spindle diameter 85 mm, CNC Siemens Sinumerik 840D, 400 V 50 Hz 49 kW, LxWxH 6.4 x 4.5 x 4.4 m, weight 12 tons Parts gantry system and/or cranes are not included in the scope of delivery.

Condition: used, Year of construction: 2002, max. wheel diameter 130 mm gear width 25 mm max. module 3 min. module 0,5 work-spindle diameter 85 mm strokes - infinitely variable 500 - 2500 Hub/min stroke 30 mm The machine is incomplete and is being sold as a spare parts carrier. The following parts are not included in delivery: - Counter-holder unit - Siemens PCU50 - Hydraulic unit - Workpiece clamping - Chuck See photos for scope of delivery. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as Bjlikjv N Ra Istrzewl subject to prior sale!

Condition: excellent (used), max. wheel diameter 630 mm gear width 180 mm max. module 8 min. module 1 table bore diameter 160 mm no. of strokes 47 - 300 Hub/min dia. of shaper cutter 125 mm dayligth 100 - 330 mm Bwoliktrjwgizkozel workpiece diameter 0 - 750 mm stroke length max. 200 mm total power requirement 12 kW weight of the machine ca. 5,8 t dimensions of the machine ca. 2,5 x 2,1 x 3,1 m The design of the LORENZ S8 represents a further development of model S7/500, which was successful over many years. A considerable increase in driving power, reinforced cast iron bodies and gearing units, easy service by push button-control, automatic change of stroke speed as well as circulation system lubrication for all moving parts correspond to the demands of a modern gear cutting machine. The machine is suitable for internal- and external gears. The capacity has been adapted to experience and has been extended to the following maximum values. Raizor block 150 mm, table clamping, tailstock, chip conveyor, change gears, manuals,toolholders, ....

Condition: used, Year of construction: 2007, max. dia. of teeth cutting 2000 mm workpiece dia. 2700 mm Diameter of the table 1500 mm max. module 22 Control 840D turning speeds 3,5 U/min table load capacity 20000 KG Distance of shafts 70...1220 mm Stroke length 30...330 mm no. of strokes 10...200 Hub/min total power requirement 138 kW weight of the machine ca. 38 t dimensions of the machine ca. 11x5 m machine: Full CNC machine with electronic rolling coupling for C- and D-axes and digital INDRAMAT drive technology. Stiff machine bed in welded construction. Radial axis (X-axis) with hardened guideways, sliding guide with wraparound, longitudinal guide with roller recirculating shoes. Ground preloaded ball screw with play-free preloaded nut. Digital AC drive technology with play-free gearbox. Linear measurement system for radial positioning. Freestanding machine table with electrohydraulically play-free preloaded double worm gear, part wheel diameter 1365 mm, hydrostatic axial and radial bearings, automatic compensation of the workpiece weight. Table hole with a diameter of 500 mm through and open at the bottom. Water-cooled digital AC servo motors. The machine is to be installed on a foundation. Machine stand: as a highly rigid cast construction for axial travel of 1200 mm. Axial axis (Z-axis) with hardened guideways, slide-guided, longitudinal guide and wraparound with roller recirculating shoes. Ground ball screw with play-free preloaded nut. Digital AC drive technology. Encoder for axial positioning. Shapping head: SK 4.1 with hydraulic NC servo drive for impact spindle movement and cutting wheel lifting, stroke length 330 mm, impact spindle diameter 160 mm. Hydrostatically supported impact spindle, linear guide and lateral guide for the lifting mechanism. Maximum tool diameter 300 mm. Drive motor power 30 kW. Bwelov E R Eisiktrzel Stroke rates from 10 - 200 DH/min, stroke speed from 5 - 45 m/min. Impact spindle speed for working and return stroke independently programmable. In the cutting area, the spindle speed remains constant. Maximum cutting wheel speed 10 rpm, digital AC drive technology. Cutting wheel lifting correction for internal and external gearing manually reversible. Lateral offset of the impact spindle axis up to 50 mm from the machine center to prevent return stroke collision of the cutting wheel, manually adjustable.

Condition: good (used), Year of construction: 1996, operating hours: 70,000 h, Functionality: fully functional, This PSA 500 gear shaper is in excellent condition at an German plant for special-purpose industrial drives. The company has it's own special products, no supplier, no automotive, no mass production. High precision single pieces work. This machine works since decades only 3-4 single shifts per week. Gear Shaping Machine – CNC SIEMENS 840C Controls Standard Technical Data Electrical System Power supply: 400 V / 50 Hz (3-phase, IEC standard) Total installed power: 45 kW CNC/PLC ready: Yes Motors & Drives Radial Axis Motor “X”: 6 Nm / 3000 rpm (AC servo, incremental encoder) Axial Axis Motor “Z”: 6 Nm / 3000 rpm (AC servo, incremental encoder) Tool Rotation Motor “B”: 20 Nm / 3000 rpm (AC servo, incremental encoder) Workpiece Rotation Motor “C”: 20 Nm / 3000 rpm (AC servo, incremental encoder) Stroke Motor “E”: 95 Nm / 2000 rpm Camshaft Motor “A”: 5 Nm / 6000 rpm (AC servo, incremental encoder) Toothed Band Travel Motor “V”: 5 Nm / 3000 rpm (AC servo, incremental encoder) Working Capacities Max external pitch diameter: 500 mm Max internal pitch diameter: 600 mm Max overall part diameter incl. fixture: 750 mm Max module: 8 Max toothed band length: 200 mm (standard) Max helix angle (with Ø125 mm tool): ± 45° Number of adjustable strokes: 30–500 strokes/min Tool–table center distance (min./max.): -50 / +400 mm Belikswb Epyetrzewl Min. distance table–tool spindle: 300 mm Max. distance table–tool spindle: 450 mm Manual offset spindle: ±25 mm Manual inclination spindle: ±0.5° Max. table load: 1000 kg Max tool rotation speed: 15 rpm Max workpiece rotation speed: 22 rpm Machine Dimensions Length: 4790 mm Width: 3320 mm Height: 3775 mm Auxiliary Unit Capacities Hydraulic/lubrication unit (recirculating): 190 L Lubrication unit (consumption type): 6 L Cooling unit – oil tank capacity: 590 L Weight Net weight (dry): 13,000 kg Paint Colors Machine, guards, units: Grey RAL 7035 Electrical cabinet doors: Blue RAL 5012

Condition: used, Year of construction: 1977, max. wheel diameter 500 mm gear width 75 mm max. module 5 min. module 0,4 total power requirement 5 kW weight of the machine ca. 4 t External gearing Largest pitch circle diameter for spur gears ..... 500 mm Largest pitch circle diameter for helical cylindrical gears ..... 450 mm Largest tooth width ..... 75 mm Internal gearing Largest pitch circle diameter for spur gears .....440 mm Largest pitch circle diameter for helical cylindrical gears ..... 420 mm Largest tooth width ..... 75 mm Largest pitch in steel for spur gears ..... Module 5 Number of adjustable tappet stroke numbers ..... 18 Range of ram stroke rates ..... per min. 45-425 Pitch circle diameter of the cutting wheel normal ..... 4" Mounting pin for cutting wheels ..... 1¾" Bore of the table spindle ..... 125 mm Power requirement ..... approx. 3 kW Bwoliswf D Nyektrzsl

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 130 mm gear width: 25 mm module max. : 3 module min. : 0,5 control: Siemens 840D work-spindle diameter: 85 mm strokes - infinitely variable: 500 - 2500 Hub/min stroke: 30 mm Bjlovi Nineiktrzswl total power requirement: 48 kVA weight of the machine ca.: 11,5 t space requirements approx. LxWxH: 4,7 x 3,0 x 3,3 m Equipment: -Counterholder with tip -chip conveyor -hydraulically operated counterholder arm and linear guides *

Condition: excellent (used), Year of construction: 1979, Functionality: fully functional, overall weight: 2,500 kg, gear diameter: 180 mm, wheel diameter: 180 mm, Machine can be inspected on site Bwolikjwbvwnjtrzol

Condition: excellent (used), max. wheel diameter 180 mm gear width 60 mm max. module 4 min. module 0,5 no. of strokes 236 - 630 Hub/min table diameter 160 mm table bore diameter 75 mm Bjliktouwwmzsrzswl total power requirement 6 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 2,1 x 1,5 x 2,3 m Hydrostatic, tailstock, Top condition!

Condition: used, - Documentation available: No - Control: Conventional Financial information Bsliktov Umkajrzowl VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: good (used), Year of construction: 1991, Functionality: fully functional, External gearing – max. outer diameter: 420 mm Internal gearing – max. inner diameter: 370 mm Workpiece outer diameter: 420 mm Maximum module: 8 Bwsliktswb Ef Isrzsl Maximum stroke length: 130 mm Stroke rate (infinitely variable): 25–800 strokes/min Table load capacity: 1150 kg Machine weight: 8,500 kg Dimensions (L x W x H): 3600 x 3300 x 3000 mm

Condition: good (used), Year of construction: 2000, Max. Pitch circle diameter External gearing 300 mm Max. Pitch circle diameter internal gearing 300 mm Max. Outer diameter of workpiece (equipment) 450 mm max. module 6 gear hobbing width -max. 100 mm Max. Helix angle (with tool Ø 125 mm) +- 45 ° strokes - infinitely variable 130 - 1300 Hub/min Minimum distance table top - tool spindle 200 mm Maximum distance table top - tool spindle 450 mm Manual Upright side shift +/- 25 mm Manual swivelling angle of the tool spindle +/- 0,5 ° Max. Tool speed 30 UpM Max. Workpiece speed 55 UpM Max. Tool diameter 7 Zoll voltage 400 V frequency 50 Hz Max. Line power 95 A 160 L coolant capacity 550 l workpiece weight 1000 kg control Siemens Simunerik 840 C weight of the machine ca. 10,5 t dimensions of the machine ca. 3,22 x 3,05 x 2,85 m Bolikevu E Nzjtrzjwl Gleason PFAUTER gear shaping machine Mod. PSA 300 The CNC modular gear shaping machine with skiving cutter for the machining of external and internal cylindrical gears, with straight or helical involute with straight or helical involute toothing, as well as any other profile splitting process. The work cycle is controlled by a CNC unit, with specific software for machining the gears, machining. Field of application --> The PSA 300 has been designed for the production of: - Gears with straight external teeth - Gears with straight internal teeth - Gears with external helical teeth - Gears with internal helical teeth

Condition: excellent (used), max. wheel diameter 300 / 400 mm gear width 76 mm max. module 6 min. module 0,5 Control BWO CNC 921 adjustment of stroke position 94 mm/Hub Bweliktrouwwlqjzsl stroke 82 mm no. of strokes 75 - 1000 Hub/min number of teeth 5 - 200 taper of shaper cutter SK 45 table diameter 400 mm total power requirement 50 kW weight of the machine ca. 7,5 t dimensions of the machine ca. 5,0 x 3,8 x 3,4 m Machine in top condition.

Condition: used, Year of construction: 1959, total height: 1,900 mm, total width: 2,200 mm, total length: 1,500 mm, Empty weight: 2.500 kg Price: On request - Year: 1959 - Documentation available: Yes - Serial number: 80 - Control: Conventional - Motor power: 5.0kW - Transport dimensions: 1500mm x 2200mm x 1900mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren Bolikjv Umiijtrzewl

Condition: good (used), max. wheel diameter 1000 mm gear width 160 mm max. module 7 min. module 0,4 total power requirement 8 kW weight of the machine ca. 5,6 t This machine is set up for shaping and drawing spur and helical gears using the hobbing process. By means of a special device, gears can also be produced using the hand-piece method. Cutting wheels with a pitch circle diameter of approx. 4" = 100 m/m are normally used. As the machine works according to the hobbing method, all numbers of teeth can be cut with just one cutting wheel of a particular module. Dimensions for external gearing: - largest wheel diameter for pinions: 1000 mm - Largest wheel diameter for helical gears: 750 mm - largest tooth width: 160 mm Bwjloudn E Seiktrzsl Dimensions for internal gearing: - Largest wheel diameter for pinions: 750 mm - Largest wheel diameter for helical gears: 750 mm - Largest tooth width: 130 mm - largest pitch to be planed in steel: 8.5/8.6 module - Bore of the table spindle: 160 mm - Number of ram strokes: 6 - Number of cutting wheel feeds: 8 Additional information + accessories: - Column extension 50 mm - Max. Max. installation height 2540 mm - Year of construction unknown - including change wheels

Condition: used, Year of construction: 1954, Price: On request Chuck: 700mm  Workpiece maximum height: 550mm  X axis displacement: 450mm - Year: 1954 - Documentation available: No Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Beliktov Umd Hjrzowl Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: good (used), max. wheel diameter 180 mm gear width 58 mm max. module 4 min. module 0,5 strokes per minute 200 - 710 total power requirement 3 kW weight of the machine ca. 3 t Very good condition, change gears,... Year of construction: Approx. 1964 Bwsleuayw Sjiktrzel

Condition: used, total height: 1,900 mm, total width: 1,500 mm, total length: 2,700 mm, Empty weight: 5.200 kg Bwslisv Spu Aektrzsl Price: On request Up till module 5 Maximum diameter: 250mm Maximum width: 275mm Speed: 50-400 rpm Maximum diameter mill-cutter: 145mm - Documentation available: Yes - Serial number: 5743 - Control: Conventional - Motor power: 15.0kW - Transport dimensions: 2700mm x 1500mm x 1900mm (l x w x h) - Transport weight [kg]: 5200kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: good (used), Year of construction: 1998, Max. Pitch circle diameter External gearing 300 mm Max. Pitch circle diameter internal gearing 300 mm Max. Outer diameter of workpiece (equipment) 450 mm max. module 6 gear hobbing width -max. 100 mm Max. Helix angle (with tool Ø 125 mm) +/- 45 ° strokes - infinitely variable 130 - 1300 Hub/min workpiece weight 1000 kg Bsliktsvu E Nuerzswl Minimum distance table top - tool spindle -55 / +300 mm Maximum distance table top - tool spindle 200 mm Maximum distance table top - tool spindle 350 mm Manual Upright side shift +/- 25 mm Manual swivelling angle of the tool spindle +/- 0,5 ° Max. Tool speed 15 UpM Max. Workpiece speed 27 UpM Max. Tool diameter 7 Zoll voltage 400 V frequency 50 Hz Max. Line power 70 A total power requirement 48 kW weight of the machine ca. 11 t dimensions of the machine ca. 4,27 x 3,11 x 2,87 m control Siemens Sinumerik 840 C table hole 40 mm taper in main spindle SK 45 Gleason PFAUTER gear shaping machine Mod. PSA 300 The CNC modular gear shaping machine with skiving cutter for the machining of external and internal cylindrical gears, with straight or helical involute with straight or helical involute toothing, as well as any other profile splitting process. The work cycle is controlled by a CNC unit, with specific software for machining the gears, machining. Field of application --> The PSA 300 has been designed for the production of: - Gears with straight external teeth - Gears with straight internal teeth - Gears with external helical teeth - Gears with internal helical teeth

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 stroke length max. 0 - 52 mm Boliktrsu Uu S Tszowl spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg Year of construction: Approx. 1970

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 Bweliev Ehbbsktrzol min. module 0,1 Control Siemens 840 D SL total power requirement 45 kW weight of the machine ca. 7 t dimensions of the machine ca. 4x3x2,5 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 Bwsliktotycg Sorzsl stroke length max. mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes Hub/min feed range mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg With rack and pinion unit Change gear set Year of construction: Approx. 1981
