Condition: used, Year of construction: 2001, max. wheel diameter 400/500 mm CNC-Control GE FANUC Series 160i-M pinion diameter - max. 400 mm Cgebovxwxce Ed Ulvjt crown gear diamter max. 500 mm x-axis +/- 70 mm y-axis 200 mm z-axis 200 mm axis angle 90 Grad speeds: R T min rated current 30 kVA weight of the machine ca. 6,2 t dimensions of the machine ca. 3,2 x 2,5 x 2,3 m

Condition: ready for operation (used), Specifications Manufacturer NILES Model ZSTZ 08 CNC Csb Ed Uswgnmfolvsgt Condition Used Stock Number in fabbrica Max diameter 800 mm Max module 14 Min-max number of teeth 5-315 Machine weight 14500 kg Machine dimensions 6000x3500x2800 mm min-max grinding wheel revolution 100-1250 rpm Description Equipped with New electrical system

Condition: excellent (used), Year of construction: 2005, Functionality: fully functional, wheel width: 275 mm, helix angle: 45 °, table diameter: 245 mm, Make : GLEASON Model: 245 TWG YEAR OF MANUFACTURING: 2004 CNC: SIEMENS 840D PowerLine Max. Gear diameter: 275 TWG Cgsb Edowca Hvs Ulvot Max. Module : 5 Grindable Profile Depth Max. Max. Swivel angle: 45 deg max. Table load: 500 kg GRINDING WHEEL DIAMETER: 160 - 220 mm Other Info THE MACHINE IS IN EXCELLENT CONDITIONS AND COMPLETE IN ALL ITS PARTS and ACCESSORIES.

Condition: ready for operation (used), Year of construction: 2002, Functionality: fully functional, Klingelnberg ZW 301 Gear Measuring Machine with Evaluation Computer Double-flank gear measuring machine with 4-position indexing table - Spur gear - Internal gear - Gear shaft - Computer (evaluation via industrial PC with fully automatic parameter calculation, quality determination, and classification) Cgeb Ed Ulov Ic R Aevjt Workpiece data: Table load including fixture, max. 100 kg Load on support plate/vertical slide including fixture, max. 80 kg Workpiece knife with counterholder on measuring and feed slide, max. 300 mm Workpiece knife with counterholder on machine bed, max. 300 mm Device data: Heidenhain LIF 101 position measuring system Center distance min./max. 45/300 mm Table diameter 150 mm Table height above floor 950 mm Measuring pressure min./max. 5/30 daN Total connected load of the test device: 0.75 kVA Total space requirement: LxWxH 1900 x 1200 x 2200 mm Net weight: 750 kg PC, as well as some master wheels with common modules. Weight: 750 kg

Condition: good (used), LIEBHERR - LORENZ L301 / Gear Hobbing Machine - Complete technical specifications / See images - Largest millable module - 6 - Maximum workpiece diameter 300 mm - Travel of the gear head slide 225 mm - Worktable diameter 315 mm - Milling spindle centerline above machine table 165 mm - Maximum workpiece length 680 mm - Continuously adjustable radial feed - Rapid traverse of the gear head slide 900 mm/min - Maximum gear head displacement / tangential travel 150 mm - Change gears Cgob Ed Uev Htkwjlvot - Belt filter - Various accessories - Documentation Dimensions: LxWxH 2.6 x 2 x 2.6 meters / Weight 6500 kg Errors / input errors excepted

Condition: used, Year of construction: 2006, Functionality: fully functional, workpiece weight (max.): 25,000 kg, wheel width: 3,000 mm, feed length X-axis: 1,000 mm, LIEBHERR L3002 CNC Internal and External Gear Hobber Cgjb Ed Ulswdmy Ejvst Built 1982, Modernized 2006 CNC SIEMENS 840 D. Max Wheel diameter 3,000 mm. Max helical angle 45° Internal and external Head. 44/50 kW.

Condition: used, Year of construction: 2004, max. wheel diameter 300 mm max. module 8 min. module 0,7 Control SINUMERIK 840 D min/max. pitch cone angle - 90 / + 90 ° workpiece spindle - bore 127 mm grinding wheel diameter 50 - 230 mm spindle speeds (infinitely variable) 7.500 U/min total power requirement 146 kW work piece spindle speed 700 U/min weight of the machine ca. 21 t dimensions of the machine ca. 9,5 x 3,6 x 3,1 m Measuring probe (integrated on the grinding head) External grinding spindle cooling system ELBARON oil mist extraction (integrated in the machine) Cgjb Edjvxww Ej Ulvjt Hoffmann coolant filter system Was used for the serial production of spiral-toothed ring gears No clamping devices No grinding wheels / grinding wheel flanges No dressing wheels

Condition: excellent (used), Year of construction: 1968, Functionality: fully functional, Max diameter 630 mm Cutting height 375 mm Max module 10 WorkTable diameter 550 mm Table Bore 125 mm Speed 62 to 390 rpm. Min number of teeth 8 Cutter diameter D192/215 mm Shifting 200 mm Motor power 7,5 kW Cob Edewbtk Ej Ulvegt Power required 21 kVA Machine weight 8.200 kgs Accessories, features - the machine is equipped with optic - many many accessories (shafts, gears, milling cutters, etc.)

Condition: good (used), Year of construction: 2002, workpiece dia. 40 mm Cgsb Ed Uljv Ucdvjvot max. module 2 min. module 0,1 workpiece length - max. 665 mm weight 4,5 t spindle bore diameter 82,5 mm Control Siemens total power requirement 5,5 kW

Condition: ready for operation (used), thread length: 3,000 mm, Thread milling and hobbing machine Wanderer 31 NU-3000 Machining length 3000 mm With accessories: change gears, steady rest Ceb Ed Uljv Huihovogt For further technical data, see PDF file.

Condition: good (used), Liebherr / Lorenz S800 gear hobbing machine -Max. Workpiece length with counter holder 600mm -Max. Workpiece length with retracted counter holder 800mm -Max. Travel of the milling slide 360mm -Largest pitch that can be milled with the largest workpiece 5 Pi / in the normal performance range 8 Pi -Receiving cone - Milling spindle MK 5 -Milling arbor 22/27/32/40mm -Max. Milling cutter diameter 186mm -Max. cutter length 170mm -Max. cutter displacement 80mm -Milling cutter speeds 40-220 rpm -Feed rates infinitely variable / horizontal -Infinitely variable feeds / Vertical -feeds infinitely variable / tangential -Clamping table without water edge 550mm -clamping table bore 100mm -clamping mandrel cone MK5 Accessories: 1x pallet of change gears 1x pallet of hobbing cutters 1x pallet of arbors Cgjb Ed Ulsvadv Devet documentation Machine feet Dimensions: LxWxH 3.6x1.8x1.9 meters /Weight 5000Kg Errors / input errors excepted -

Condition: used, Year of construction: 2004, max. wheel diameter 425 mm max. module 8,5 min. module 1,5 Control SINUMERIK 840 D tooth width 65 mm spiral angle min. 0 / max. 60 ° max. number of teeth 6-180 min. number of teeth 6 transmission ratio min. 1:1 transmission ratio max. 1:10 Cgeb Ed Ulovxwvbovjt blade cutter head diameter 62 - 160 mm blade head turning speeds 750 U/min work piece spindle speed 400 U/min total power requirement 60 kVA weight of the machine ca. 16 t dimensions of the machine ca. 5,5 x 2,5 x 2,5 m

Condition: used, max. wheel diameter 215 mm gear width 150 mm max. module 10 min. module 1 total power requirement 6 kW weight of the machine ca. 5 t dimensions of the machine ca. 2,00x1,52x1,63 m Specification: BASIC TECHNICAL PARAMETERS Max. length of dividing cone: 107 mm Min. length of dividing cone: 0 mm Max. adjusting angle: 90 degrees Min. adjusting angle: 8 degrees Transmissive ratio: 6:1 Max. diametral pitch: 6,35 Diapason of division: 9-120 Width of tooth: 35 mm MAIN SPINDLE Diameter of cone opening on tip: 58,34 mm Obliquity on 304,8 mm length: 12,7 mm Obliquity: 15,87 mm Cjb Ed Uev Ehbnslvsgt ELECTRICAL PART Main motor: 50 Hz, 1500 r/min Stepless adjustable motor: 1500 r/min Motor of hydraulic pump: 1500 r/min Motor of frigorific pump: 3000 r/min DIMENSIONS Length: 2032 mm Width: 1524 mm Height: 1626 mm Weight: 5000 kg

Condition: used, Year of construction: 2003, max. wheel diameter 275 mm gear width 58 mm max. module 13 min. module 2 Control SINUMERIK 840 D number of teeth 5 - 200 ratio of transmission 10:1 cutter diameter max. 228 mm x-axis 25 - 350 mm y-axis +/- 175 mm z-axis 125 - 600 mm b-axis -5 / +90 ° total power requirement 75 kW Cgjb Ed Ulsvxwuksvjt weight of the machine ca. 11,7 t dimensions of the machine ca. 12,5 x 3,0 x 3,0 m Equipped for dry milling Pressure deburrer Deburring device with driven brush Integrated magnetic chip conveyor Promot Cellmaster Cartridge pulse filter system User interface control works with Gleason Summary

Condition: used, max. wheel diameter 215 mm gear width 150 mm max. module 10 min. module 1 total power requirement 6 kW weight of the machine ca. 5 t dimensions of the machine ca. 2,00x1,50x1,62 m Specification: BASIC TECHNICAL PARAMETERS Max. length of dividing cone: 107 mm Min. length of dividing cone: 0 mm Max. adjusting angle: 90 degrees Min. adjusting angle: 8 degrees Transmissive ratio: 6:1 Max. diametral pitch: 6,35 Diapason of division: 9-120 Width of tooth: 35 mm MAIN SPINDLE Diameter of cone opening on tip: 58,34 mm Obliquity on 304,8 mm length: 12,7 mm Cebsv Eha Rs Ed Ulvogt Obliquity: 15,87 mm ELECTRICAL PART Main motor: 50 Hz, 1500 r/min Stepless adjustable motor: 1500 r/min Motor of hydraulic pump: 1500 r/min Motor of frigorific pump: 3000 r/min DIMENSIONS Length: 2032 mm Width: 1524 mm Height: 1626 mm Weight: 5000 kg

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm gear width 320 mm max. module 4,5 min. module 0,5 Control SIN 840D ical angle +/- 45 ° Csb Ed Usvxwtmjlvjgt total power requirement 68 kW weight of the machine ca. 15500 Kg dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Wekal loading cell

Condition: used, Year of construction: 2004, max. wheel diameter 200 mm gear width 250 mm max. module 5 min. module 0,1 milling tool taper HSK 80 B spindle turning speed range 0 - 1000 U/min control 840 D total power requirement 15 kW weight of the machine ca. 10,2 t dimensions of the machine ca. 4.455 x 3.160 x 3.335 m Gleason-PFAIJTER CNC gear milling machine GP200 for gear cutting of shaft and wheel-shaped workpieces with all rollable profiles and shapes that regularly occur on the cylindrical workpiece circumference. Optionally for wet milling with cooling lubricants (basic version) and/or dry milling (option). Working area and technical data: Cgeb Ed Ulev Eha Devot Max. workpiece diameter that can be cut .. 200 mm Machine nominal module ..... approx. 5 mm (Guide value depending on the respective machining task and the specific machine equipment.) Smallest/largest distance between milling cutter and workpiece axis ... 15/215 mm The travel paths and angles mentioned above can be restricted if necessary depending on the workpiece and tool dimensions, the gear data and the workpiece-dependent machine equipment Accessories 1 compressed air maintenance unit (make FESTO) 1 signal light (3-color) to display machine statuses 1 work area light 1 control cabinet light 1 set of tools for machine operation and maintenance 2 operating instructions 2 programming instructions 2 maintenance instructions 1 set of electrical documents in German or English

Condition: used, Year of construction: 2012, max. wheel diameter 300 mm gear width 320 mm max. module 10 min. module 0,5 ical angle 45 ° frequency 50 Hz voltage 400 V main fuse 125 A x-axis 270 mm y-axis 250 mm Cgsb Esvxwtgod Ulvst z-axis 320 mm A - axis +/- 45 ° B - axis 360 ° C-axis 360 ° total power requirement 89 kW weight of the machine ca. 23,5 t dimensions of the machine ca. 11,2 x 5,5 x 2,9 m automated Oil slinger station EWAB workpiece storage Hoffmann coolant filter system HSF 100 SE/K Minimax fire extinguishing system W+W air filter system Promot Automation "Cellmaster" (3 cells) year 2019

Condition: used, Year of construction: 1992, max. wheel diameter 160 mm gear width 710 mm max. module 4,5 min. module 0,5 milling spindle speeds (infinitely variable) 70 - 400 U/min centre distance 800 mm total power requirement 11 kW weight of the machine ca. 4,7 t Cgjb Edevz Edrs Ulvst dimensions of the machine ca. 3,6 x 3,0 x 2,0 m 2-cut-cycle, shifting, very nice condition. Change gears, arbors.

Condition: used, Year of construction: 2006, ratio of transmission 10:1 min. number of teeth 3 Cgjb Ed Ujvxwr Aelvet max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm spindle speeds (infinitely variable) 6000 U/min work piece spindle speed 1200 U/min diameter of tools max. 230 mm diameter of tools min 69,85 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm b-axis + 90,1 / - 1 ° work piece table - Ø 212,71 mm Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m coolant filtering unit Hoffmann HSF 100 V

Condition: used, Year of construction: 1969, max. wheel diameter 160 mm gear width 355 mm max. module 4,5 min. module 0,5 centre distance 450 mm total power requirement 11 kW weight of the machine ca. 3,8 t dimensions of the machine ca. 2x17,1,6 m Wheel diameter - max. 160.175 mm Wheel width 355 mm Module - max. 4.5 Spindle bore 75 mm Center distance 410 mm Number of teeth - min. 2, 3 Cutter diameter max. 115 mm Cutter length max. 105 mm Center distance between milling cutter and workpiece - max. 138 mm Center distance between milling cutter and workpiece - min. 30 mm Milling head - swivels 120 ° Milling cutter speeds 70 - 400 rpm Axial feeds 0.25 - 4.0 mm/rev Radial feeds 0.09 - 1.5 mm/rev Total power requirement approx. 9.5 kW Csb Eevz Ec Iod Ulvegt Machine weight approx. 3.5 t Space requirement approx. 1730x1400x1440 mm Equipment/accessories: - Changing wheels - milling arbors - Clamping device Dra8M7 - documentation

Condition: used, Year of construction: 2007, max. dia. of teeth cutting 2000 mm workpiece dia. 2700 mm Diameter of the table 1500 mm max. module 22 Control 840D turning speeds 3,5 U/min table load capacity 20000 KG Distance of shafts 70...1220 mm Stroke length 30...330 mm no. of strokes 10...200 Hub/min total power requirement 138 kW weight of the machine ca. 38 t dimensions of the machine ca. 11x5 m machine: Full CNC machine with electronic rolling coupling for C- and D-axes and digital INDRAMAT drive technology. Stiff machine bed in welded construction. Radial axis (X-axis) with hardened guideways, sliding guide with wraparound, longitudinal guide with roller recirculating shoes. Ground preloaded ball screw with play-free preloaded nut. Digital AC drive technology with play-free gearbox. Linear measurement system for radial positioning. Freestanding machine table with electrohydraulically play-free preloaded double worm gear, part wheel diameter 1365 mm, hydrostatic axial and radial bearings, automatic compensation of the workpiece weight. Table hole with a diameter of 500 mm through and open at the bottom. Water-cooled digital AC servo motors. The machine is to be installed on a foundation. Cgeb Esv E R Eiod Ulvet Machine stand: as a highly rigid cast construction for axial travel of 1200 mm. Axial axis (Z-axis) with hardened guideways, slide-guided, longitudinal guide and wraparound with roller recirculating shoes. Ground ball screw with play-free preloaded nut. Digital AC drive technology. Encoder for axial positioning. Shapping head: SK 4.1 with hydraulic NC servo drive for impact spindle movement and cutting wheel lifting, stroke length 330 mm, impact spindle diameter 160 mm. Hydrostatically supported impact spindle, linear guide and lateral guide for the lifting mechanism. Maximum tool diameter 300 mm. Drive motor power 30 kW. Stroke rates from 10 - 200 DH/min, stroke speed from 5 - 45 m/min. Impact spindle speed for working and return stroke independently programmable. In the cutting area, the spindle speed remains constant. Maximum cutting wheel speed 10 rpm, digital AC drive technology. Cutting wheel lifting correction for internal and external gearing manually reversible. Lateral offset of the impact spindle axis up to 50 mm from the machine center to prevent return stroke collision of the cutting wheel, manually adjustable.

Condition: good (used), Year of construction: 2000, Max. Pitch circle diameter External gearing 300 mm Max. Pitch circle diameter internal gearing 300 mm Max. Outer diameter of workpiece (equipment) 450 mm Cgobjvu E Nzj Ed Ulvet max. module 6 gear hobbing width -max. 100 mm Max. Helix angle (with tool Ø 125 mm) +- 45 ° strokes - infinitely variable 130 - 1300 Hub/min Minimum distance table top - tool spindle 200 mm Maximum distance table top - tool spindle 450 mm Manual Upright side shift +/- 25 mm Manual swivelling angle of the tool spindle +/- 0,5 ° Max. Tool speed 30 UpM Max. Workpiece speed 55 UpM Max. Tool diameter 7 Zoll voltage 400 V frequency 50 Hz Max. Line power 95 A 160 L coolant capacity 550 l workpiece weight 1000 kg control Siemens Simunerik 840 C weight of the machine ca. 10,5 t dimensions of the machine ca. 3,22 x 3,05 x 2,85 m Gleason PFAUTER gear shaping machine Mod. PSA 300 The CNC modular gear shaping machine with skiving cutter for the machining of external and internal cylindrical gears, with straight or helical involute with straight or helical involute toothing, as well as any other profile splitting process. The work cycle is controlled by a CNC unit, with specific software for machining the gears, machining. Field of application --> The PSA 300 has been designed for the production of: - Gears with straight external teeth - Gears with straight internal teeth - Gears with external helical teeth - Gears with internal helical teeth

Condition: used, Year of construction: 2006, max. wheel diameter 150 mm gear width 100 mm max. module 3 min. module 1 x-travel 190 mm y-travel 160 mm Cebjub Amre Ed Ulvjgt z-travel 100 mm turning speeds 5200 U/min swivel angle for work spindle +/- 40 ° weight 8,5 t with KUKA robot loading system TWIN-SPINDLE TECHNOLOGY The twin-spindle concept significantly shortens the cycle time and guarantees the high production output of the Reishauer generating grinding machine. During the grinding of a gear, the previously ground workpiece is unloaded on the second workpiece spindle workpiece is unloaded, the next gear to be ground is loaded and centred. REISHAUER GEAR HOBBING MODULE The generating module coordinates the complex axis movements of the generating grinding process and generates the exact geometry of the workpiece. Reishauer relies exclusively on the hobbing module developed in-house. This makes us more precise and continue to set the technological standards. REVOLUTIONARY PROCESSES Thanks to the targeted further development of the grinding process, Reishauer has been the technology leadership in the hard fine machining of gears for decades gears. One example of this is grinding with a cutting speed of 100 metres per second, polishing grinding and topological grinding. Equipment/accessories: - Turret with 2 workpiece spindles and dressing unit - Counter holder - 3 workpiece clamping devices - Centre unit with sensor - Hoffmann filter unit - 1 flange with grinding disc - Kuka robot - Safety devices for transport - documentation

Condition: good (used), max. wheel diameter 1000 mm gear width 160 mm max. module 7 min. module 0,4 total power requirement 8 kW weight of the machine ca. 5,6 t This machine is set up for shaping and drawing spur and helical gears using the hobbing process. By means of a special device, gears can also be produced using the hand-piece method. Cutting wheels with a pitch circle diameter of approx. 4" = 100 m/m are normally used. As the machine works according to the hobbing method, all numbers of teeth can be cut with just one cutting wheel of a particular module. Dimensions for external gearing: - largest wheel diameter for pinions: 1000 mm - Largest wheel diameter for helical gears: 750 mm - largest tooth width: 160 mm Dimensions for internal gearing: - Largest wheel diameter for pinions: 750 mm - Largest wheel diameter for helical gears: 750 mm - Largest tooth width: 130 mm - largest pitch to be planed in steel: 8.5/8.6 module - Bore of the table spindle: 160 mm Cgjbjudn E So Ed Ulvst - Number of ram strokes: 6 - Number of cutting wheel feeds: 8 Additional information + accessories: - Column extension 50 mm - Max. Max. installation height 2540 mm - Year of construction unknown - including change wheels
