Condition: used, Year of construction: 2016, x-travel 450 mm
y-travel 400 mm
z-travel 420 mm
Control Sinumerik 840 D SL Siemens
Main spindle:
number of spindles 2
turning speed range - main spindle max. 8.000 min/-1
tool taper HSK-A100
power capacity - main spindel 31 kW
Torque (40%) 200 Nm
max. Torque 295 Nm
spindle distance 450 mm
swivable table:
A-Axis 270 °
swivle time 0-180°: 4 s
Swivel diameter max. 765 mm
max. table load 500 kg
b - axis 0,001 °
pallet changer:
Number of pallet-stations 2x 2 pos.
pallet diameter 420 mm
tool magazin:
number of toolpositions 2x 60 pos.
tool taper HSK-A100
max. tool diameter 110 mm
max. tool-dia with free toolbox 200 mm
max. tool length 250 mm
max. tool weight 15 kg
feeds:
rapid traverse X/Y: 60 m/min
rapid traverse Z: 90 m/min
Accelaration X/Y: 6 m/s²
Accelaration Z: 9 m/s²
feed power X/Y: 15.000 N
feed power Z1/Z2: 10.000 N
total power requirement 90 kW
weight of the machine ca. 17 t
dimensions of the machine ca. 7,0 x 3,8 x 4,5 m
Documents
Chip conveyor
Coolantsystem
high pressure coolant 70 bar
paper band filter
autom. Frontdoor
test probe Renishaw OMP 60
triple signal light
5-Axis-CNC-Doublespindle-Machiningcenter
LICON - LiFLEX II 444 i PC B2
Ba3z8leeq9c
-incl. zero-point clamping system
Condition: excellent (used), Year of construction: 2016, Operating hours: 1,500 h, 2-spindle manufacturing cell with enlarged working area. The machine has a pendulum table with four mounted NC rotary dividing tables with 500 mm. Each work spindle can be corrected individually in the three main axes. Knoll KF 400/1700 cooling lubricant filter system included.
Manufacturer: Schmid
Type: SE 363
Year of manufacture: 2000 (general overhaul / retrofit in 2016).
Weight: 21 t
Control: Sinumerik 840 D Powerline
Tool holder: HSK 63
Traversing range X axis: 800 mm
Traversing range Y axis: 800 mm
traversing range Z axis: 520 mm
three-phase main drive (2 pcs.): max. 26 kW at S1
speed range: 50 - 8000 rpm
tool storage each 2 pcs: 30 tools
tool length: max. 420 mm
workpiece clamping: 4 rotary dividing tables
Floor space requirement: 5 x 6 m
Included: Knoll KF 400/1700 filter system for cleaning cooling lubricants (year of construction 2016)
Operating hours: since retrofit (2016) approx. 1500 hours
The general overhaul (retrofit) included the following items:
- Renewal of all guide rails
- Renewal of all ball screws incl. bearings and toothed belts
- Renewal of all electrical cables
- Renewal of measuring systems
- Inspection of the rotary tables
- Renewal of all valves
- General overhauled spindles Fa. Schmid installed
Gw9hmmu
- Tool changer completely overhauled and checked
- New painting
- Renewal of the covers
We will be pleased to send you further information on request.
Condition: ready for operation (used), Year of construction: 2004, Schmid SE 365
- Machine control Siemens Sinumerik 840D with Simatic S7
- travel range X/Y/Z: 800/800/520 mm
- 2 synchronous main drives 0,4-26 kW
- machine swivel table/rotary table (B-axis) 360x0,001 degrees
- with hydraulic clamping 2x2 arranged side by side
- spindle modules SPI1/SPI2 with three-phase motor spindles
- speed range: 50 - 16.000 rpm.
- Torque: 16,5 - 75 Nm
- Tool holder clamping via disk springs, release hydraulically
- Coolant supply through the work spindle - IKZ
- axis modules X1, X2, Y1, Y2, Z1, Z2, A1, A2, C1, C2
- 2 tool round magazines stationary mounted a 30 tool places
- Hydraulic system with power unit and various controls for all clamping and auxiliary functions
- chip conveyor
- Coolant return pump
- Automatic central lubrication
- Coolant pressure boost 6,5 bar, 80 l/min.
- Tool holders HSK 63 A
- Year of manufacture: 2004
Bc93ea9u3lp
The machine is currently still under power and can be inspected by appointment.
Condition: used, Year of construction: 2015, diameter / mm
Cutting (quantity) /
weight 15000 kg
Control Siemens 840D
Production line - Modular Special Machine (MSM) with clamping device
1 double spindle machining centre
Bel2gy2vah8
Make: GROB
Type: Special machine GM4650
Year: 2015
Control: Siemens, type 840D sl
CO2 fire extinguishing system, air filter LTA,
oil treatment, make: Ruez, type MBF-1000 AS, year 2015 -
Operating hours 43,774, spindle hours 1,598
Technical data
Machine length: 8400mm
Machine width: 2500mm
Machine height incl. LIP: 2150mm
Machine weight: 15.000kg
