Used planer-type milling M/C - double column for sale (129)

Condition: ready for operation (used), Year of construction: 2004, operating hours: 42,832 h, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 760 mm, controller model: FANUC SERIES 18i MB, clearance between the columns: 2,300 mm, TECHNICAL DETAILS Travel X-axis: 3,000 mm Travel Y-axis: 2,100 mm Travel Z-axis: 760 mm Ffedpfjymxi Ajx Afusw Distance between columns: 2,300 mm Table size: 3,020 mm × 2,010 mm Maximum table load: 10,000 kg Spindle taper: ISO-50 Standard spindle speed: 6,000 rpm Max. tool diameter / with empty magazine slot: 127 mm / 215 mm Max. tool length: 350 mm Max. tool weight: 20 kg Tool changer capacity: 32 tools Rapid traverse (X-axis): 20,000 mm/min Rapid traverse (Y-axis): 15,000 mm/min Rapid traverse (Z-axis): 15,000 mm/min Feed rate: approx. 1 – 10,000 mm/min MACHINE DETAILS CNC control: FANUC SERIES 18i MB Spindle motor power (continuous / 30 min): approx. 22 / 26 kW Operating hours, feed time: 42,832 h Operating hours, automatic mode: 53,246 h EQUIPMENT Automatic head changer (with angular milling head) RENISHAW probe

Condition: good (used), travel distance X-axis: 12,000 mm, travel distance Y-axis: 7,300 mm, travel distance Z-axis: 3,000 mm, total length: 30,000 mm, table length: 12,000 mm, table width: 4,730 mm, total width: 12,000 mm, total height: 10,475 mm, table load: 250,000 kg, overall weight: 400,000 kg, Make : Waldrich - Siegen - Typ : PF-F-150(1)-530/400 - No. : 11.093/0 - Age : Overhault 2004 ( Euro 2.2 Mil) X Travel : 12.000 - Y Travel : 7.300 - Z Travel : 3.000 - W Travel : 4.000 - Between column : 5.000 - Table width : 4.730 - Table length : 12.000 - Table load : 19 t / mtr. Ca. 250 ton - Table feed : 10.000 mm/min. - W axis : 3.000 mm/min. - T axis : 6.000 mm/min. - Cross adj. milling head : - Vert. adj. cross rail : - Horizontal hydrostatic spindle ram - Milling spindle Ø : 560 - Milling tool taper : iso 60 - C axis feed : 5.000 mm/min. - Milling motor : 90 kW - Spindle speed : 2.500 R/pm - Z axis stroke : 3.000 - Z axis feed : 2.000 mm/min. - Milling Küma Angle head WF2 90 kw- 450 - Milling Küma Uni. UB1D 60 kw - 2400 - Milling Küma Fixed GB1D 90 kw- 2400 - Milling Küma Angle head WF1? - Electric requirement : 3 x 400 V / 50 Hz - Power requirement : 600 kVA / 630 Amp - Capacity 4.000 L coolant true spindle 20/40 Bar Machine is rebuild in 2004 by Schiess Bed – Table assembly group: * Renewal of sliding lining * Grinding of guideway * Renewal of table drive * Direct linear measuring syst. * Hydrostatic Portal and cross rail: * Modification of adjusting spindle trape Zoidal spindle was recplaced with ball screw * Direct linear measuring syst. * New drive motors for relization of higer speed on feed axes of milling support. Ffodpoytrxksfx Afusw * New milling support with hydrostatic guideways Electric system: * Complet elctric cabinet switchgear * Complet new wire * Siemens Sinumrik 840 D in 6 axis !! Equipment / parts : * Complet new raumag janich covers * Complet new double chip conveyor * Complet with big tooling packet * Complet with big mounting equipment - Under power in Europe - Free directly - Controlled axis X / Y / Z / W / C / B axis - Over all height : 10.475 mm - Over all width : 11.934 mm - Over all length : 30.000 mm - Total weight : ca. 400.000 Kg Rebuild in 2004 for EUR 2.200.000 !This CNC Waldrich Portal milling machines was used in the Energie Field for steam turbien case machining. Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 10,000 rpm, table load: 4,000 kg, overall weight: 13,000 kg, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 3, This 3-axis Nicolas Correa Euro 2000 was manufactured in 1997. It features a Siemens 840 D control system and a Ganfior electro-spindle capable of reaching 10,000 rpm. The working envelope is 2000 × 1250 × 700 mm with a spindle taper of SK40. It supports a maximum table load of 4,000 kg and weighs 13,000 kg. If you are looking to get high quality milling capabilities consider the Nicolas Correa Euro 2000 machine we have for tact us for more information. • Spindle: Ganfior electro-spindle Technical Specification Ffjdpoyctpijfx Afujw Taper Size SK 40

Condition: ready for operation (used), Year of construction: 1998, total height: 4,900 mm, overall weight: 51,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D, This 4-axis MIKROMAT 20V gantry milling machine was manufactured in 1998. Ideal for precision milling, it offers robust construction and reliable performance. Consider the opportunity to buy this MIKROMAT 20V gantry milling machine. Contact us for more information. Additional equipment • Automatic Tool Changer: Included / Number of Places in the Magazine: 90 / Max. Tool Diameter: 125 mm (300 mm with free secondary positions) / Max. Tool Length: 450 mm/ Max. Tool Weight: 30 kg /Tool Change Time: Approx. 5 sec • Compressed Air Connection / Air Volume: 6 bar - 5 m³/h / Nominal Voltage: 3 AC 400 V / Control Voltage: DC 24 V / Connected Load: Basic machine 65 kW • Cooling Lubricant Supply and Filter System: Included / Tank Capacity: 1500 l / Pump for External Cooling: Q= 20/40/60 l/min switchable / Pump for Internal Cooling: Q= 35 l/min at 50 bar Work Area Guard with Lighting: Included / Set of Chip Conveyors: Included, with scraper belt type, discharge height 1000 mm Machine Benefits Technical Machine Benefits • Traverse path: x (table): 5200 mm/ y (slide): 3400 mm /z (spindle): 1250 mm • Traverse path: x (table): 5200 mm y (slide): 3400 mm /z (spindle): 1250 mm • Max. Feed force (x, y, z): 15 kn • Clamping surface: 2000 x 5000 mm / max. Table load: 100 kn / width / spacing of table grooves: 22 / 160 mm / passage width: 2400 mm / distance between spindle nose and table surface: 500 to 1750 mm • Spindle speeds: 10 to 5000 rpm / max. Power of the spindle motor: 37/46 kw / max. Spindle torque: 1000/1250 nm / spindle head for tool shank: sk 50 • Control type: microprocessor control siemens sinumerik 840d / screen: colour screen 10. 4 inch tft display / number of axes: 3 (x, y, z) • Control system: integrated with various functionalities including spindle orientation, interpolation, and an electronic handwheel • Programming and data transfer: includes comprehensive programming capabilities and data transfer options via the universal interface v24/rs-232 • Accessories: multiple accessories and additional device functionalities included, focusing on enhanced efficiency and safety Dimensions Machine Depth 10500 mm Ffedpfxsx D Hcwe Afuow

Condition: new, Portal machine - the space miracle! CNC portal milling machine for large traverse paths with small space requirements! ADVANTAGES: -optimized space utilization, completely free table clamping area -best possible chip protection due to overhead axes -particularly suitable for high and bulky components -PILZ safety technology -Windows 10 Ffjdpohqhlvofx Afuew APPLICATIONS: -chipping -measuring and testing -dosing applications FOR MACHINING: -Aluminum / light metals -Milled plastics -Ceramics -Non-ferrous metals (brass, bronze, etc...) -Plastics -Wood Maximum functionality with minimum space requirements is the motto of the OverHead Gantry M. The basic machine can be optimally configured for many sectors and work areas using a variety of variable equipment features and additional options. The possible applications of the OverHead Gantry M include measuring, testing and metering applications in addition to machining. The power of the milling motor of up to 2.2 kW and 20,000 rpm and a traverse speed up to 250 mm/sec make it suitable for processing wood and plastic as well as light and non-ferrous metals. The free processing area and its excellent price/performance ratio off er decisive benefits compared to similar products. The OverHead® Gantry M is available in five different sizes for different process areas from M20 to M50. Do you require the control cabinet on the right-hand side or would you prefer the control panel to be on the left? No problem – we will be happy to accommodate your requirements. And of course we will take care of maintenance and support for your OverHead® Gantry M. Our service technicians can be reached by telephone and can attend to you quickly on-site as needed. In addition, we also off er our in-house isy-CAM 2.8 software and can advise you on your specific application. BENEFITS: -Optimal use of space -Free machining area -Fixed table, mobil portal -Variable clearance of 340- 590 mm -Also suitable for a large chip volumes SET UP: Portal: mobil, Table: Fixed

Condition: excellent (used), Year of construction: 2019, operating hours: 29,081 h, functionality: fully functional, FPT Industrie S.p.A. – Travelling Column / Gantry Milling Machine Model: DINOSPIN Year of manufacture: 2019 Serial number: DP0419015 Origin: Italy (FPT Industrie S.p.A., Made in Italy) Machine weight: 44,280 kg Control: Heidenhain TNC640 (15") RAM: 4 GB Hard drive: 32 GB (min. 21 GB program storage) Resolution: Linear axes up to 0.1 µm / Rotary axes up to 0.0001° Interfaces: 2x Ethernet 1000BaseT, 1x USB 2.0 (front), 4x USB 3.0 (rear) Block processing time: 0.5 ms Handwheel: Heidenhain HR510 (remote handwheel) Universal milling head (5-axis machining, continuous movement on 2 axes) Max. spindle speed: 18,000 rpm Swivel range C: ±270° Swivel range A: ±185° Max. rotation speed A/C: 30 rpm Working torque A/C: 450 Nm Clamping torque axes: 1,400 Nm Positioning uncertainty: 8 arcsec / scatter: 4 arcsec (VDI/DGQ 3441) Spindle power (S1/S6): 22/33 kW Spindle torque (S1/S6): 84/128 Nm Continuous operation, constant power: 2,500–18,000 rpm Continuous operation, constant torque: 10–2,500 rpm Tool holder: HSK-A63 DIN 69893 Rigid tapping: yes Dynamic RTCP: yes AUTOCAL (automatic calibration): yes Tool changer (overlapped-wheel system with tool-change arm) Magazine capacity: 80 tools Max. tool diameter: 75 mm Max. tool diameter with adjacent pocket free: 125 mm Max. tool weight: 10 kg Max. tool length: 600 mm (for 40 tools) Ffsdpfx Aeyrndmsfusw Max. tool length: 250 mm (for 40 tools) Tool type: HSK-A63 DIN 69893 Measuring systems Laser tool setter: tool length/radius + tool breakage control (software included) Probe for workpiece measurement/alignment: wireless transmission, probing cycles included in CNC Monitoring Sensor for vibration/collision detection: response time approx. 1 ms Coolant system external/internal (LEU/LEIUHP) Tank capacity: 3,500 l Filtration: Filter A 60 µm / Filter B 40 µm External cooling: max. 30 l/min, max. 10 bar Through-spindle coolant (IKZ): max. 30 l/min, max. 70 bar Additional options/functions External tool spray mist Compressed air through spindle (high speed) up to 24,000 rpm

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 7,000 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 2,000 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 18,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 30 m/min, torque: 38 Nm, overall weight: 65,000 kg, Initial commissioning: 2012 Control system: Heidenhain iTNC 530 X-axis: approx. 7,000 mm Y-axis: approx. 3,500 mm Z-axis: approx. 2,000 mm A-axis: ± 100° C-axis: ± 360° Clamping table: 6,000 x 3,000 x 160 mm (sunken) with 18H12 T-slots / 250 mm spacing 2-axis milling head VH 12 Spindle power: 24 kW Spindle speed: max. 18,000 rpm Torque: max. 38 Nm Tool holder: HSK 63A Linear axis drives Feed rate X, Y, Z axes: up to 50 m/min / 30 m/min Axis acceleration X, Y, Z axes: up to 2.5 m/s² Connection data Voltage: 400 V Frequency: 50 Hz Main fuse: 200 A Power consumption: 85 kVA Dimensions, weights Machine footprint without peripherals: approx. 10,000 x 6,650 x 5,900 mm Total weight: approx. 65,000 kg Additional equipment - Double-sided access doors - 10-position tool changer Optional at extra cost: - Wireless probe Fodoyrdc Eopfx Afusfw - Heidenhain remote diagnostics Machine condition Fully functional, very good condition. Can be inspected under power. !!! The machine was completely mechanically overhauled in 2022 !!!

Condition: excellent (used), Year of construction: 2014, operating hours: 68,000 h, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 15,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 30 m/min, torque: 167 Nm, overall weight: 35,000 kg, Initial commissioning: December 2014 Control system: Fidia X-axis: approx. 2,200 mm Y-axis: approx. 3,500 mm Z-axis: approx. 1,200 mm A-axis: ± 100° C-axis: ± 275° Machine operating hours: approx. 68,000 h Total spindle hours: approx. 26,500 h Clamping table: 2,000 x 3,500 mm with T-slots 2-axis fork milling head Spindle power: 70 kW Spindle speed: max. 15,000 rpm Torque: max. 167 Nm Tool holder: HSK 100A Tool clamping: hydraulic Linear axis drives Feed rate X, Y, and Z axes: up to 50 m/min / 30 m/min Connection data Voltage: 400 V Frequency: 50 Hz Dimensions, weights Required space for machine without peripherals: approx. 8,000 x 6,000 x 5,000 mm Total weight: approx. 35,000 kg Additional equipment - Coolant system - 26-place tool changer - Work area enclosure - Chip conveyor Available at extra charge: - Wireless touch probe - BLUM laser Condition of the machine Fully operational, very good condition. Can be inspected under power. Ffjdpeyrc Akjfx Afusw

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 12 m/min, total length: 11,000 mm, table length: 4,500 mm, table width: 1,250 mm, total width: 4,645 mm, spindle speed (max.): 3,000 rpm, total height: 4,170 mm, workpiece weight (max.): 10,000 kg, rotational speed (max.): 5,000 rpm, overall weight: 30,500 kg, Nicolás Correa FP40-40S gantry milling machine, refurbished model, is a high-precision solution designed for demanding industrial applications. With a large table size of 4,500 × 1,250 mm and 8 T-slots, it allows efficient machining of large workpieces. The travels on the X, Y and Z axes are 4,000 mm, 2,500 mm and 1,000 mm respectively. Equipped with an automatic UAG head and ISO 50 (DIN 69871) spindle taper, this milling machine provides flexibility and ease of operation for complex machining tasks. The machine offers a speed range up to 5,000 mm and a rapid feed of 15,000 mm/min, significantly improving productivity. The 30 kW head power ensures robust and consistent performance during extended operations. Fedpjul S Syofx Afuefw The Nicolás Correa FP40-40S supports a maximum table load of 10,000 kg, making it suitable for large and heavy workpieces. Carefully maintained and refurbished, this machine is an excellent option for companies looking for Correa reliability and precision at a competitive cost.

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 650 mm, total length: 6,500 mm, table length: 2,000 mm, table width: 1,000 mm, total width: 3,600 mm, spindle speed (max.): 12,000 rpm, total height: 4,000 mm, overall weight: 14,000 kg, Equipment: rotational speed infinitely variable, The NICOLÁS CORREA EURO 2000 milling machine is a pre-owned machine that offers reliable performance for a wide range of industrial applications. Equipped with a HEIDENHAIN TNC 530 CNC control, this model ensures precise and efficient operation. Its working table measures 2,000 × 1,000 mm, providing a spacious and versatile working area. The machine travels are 2,000 mm on the X axis, 1,250 mm on the Y axis, and 650 mm on the Z axis, offering sufficient capacity for complex machining tasks. The distance between columns is 1,250 mm, contributing to a robust and stable structure. The HSK 63 head with electrospindle reaches speeds of up to 12,000 rpm, enabling high-precision machining across a variety of materials. Ffsdeul Txzjpfx Afuow In addition, the milling machine features full enclosure guarding, improving operator safety while reducing noise and dust during operation. This used but well-maintained machine is an excellent option for companies looking to increase their production capacity without compromising quality.

Condition: used, x-travel 6500/13150 mm y-travel 4000 mm z-travel 1250 mm w-travel 2250 mm control Sinumerik 840 D table surface area 5500/12150 x 3000 mm distance between columns 3500 mm max. distance between table and spindle-nose 3000 mm max. workpiece weight 70000 / 105000 kg ram head dimension 480 x 510 mm spindle turning speed - stepless 6,3 - 4000 U/min milling spindle motor 63 kW max. torque on the spindle 3300 Nm tool taper DIN 39871 AD ISO 50 feed speeds X/Y/Z= 24000 mm/min total power requirement 120 kVA weight of the machine ca. 245 t dimensions of the machine ca. 29 x 7,7 x 8,1 m The Machine is in almost new condition - in 2020, it was completely retrofit and modernized for 1.6 million Euro! Equipment/accessories: - automatic tool magazine for 153 tools - automatic milling head magazine for 6 milling heads - machining modules/ milling heads: 1. machining module -straight - straight long - 2. machining module -standard angle - 4000 rpm, 144 x 2.5°, ISO 50 3. machining module -narrow angle extended -40 kW, 4000 rpm, 1800 Nm, 144 x 2.5°, ISO 50 4. machining module -universal index - 40 kW, 4000 rpm, 2100 Nm, - C-axis 144 x 2.5° , B-axis +/- 44 x 2.5°, ISO 50 - coolant unit Fjdpowa Dx Rjfx Afuofw - chip conveyor - technical documentation

Condition: new, Year of construction: 2023, functionality: fully functional, FPT INDUSTRIE GANTRY MILLING MACHINE TECHNICAL SPECIFICATIONS Brand: Fpt Industrie Model: Dinox 350 (IAT) Year: 2023 2-position PickUp Automatic millesimal head (2 segments) Tool changer Ffsdpfxeytpfnj Afujw CNC: Heidenhain PRICE AND FURTHER INFORMATION UPON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKES)

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, Control: Siemens 840 D Powerline Tool holder: HSK-A63 Max. rpm: 16,000 X-travel: 3,000 mm Y-travel: 2,500 mm Z-travel: 1,150 mm A-axis: +/- 100 mm Fedpfx Afjytfgujusfw C-axis: +/- 181.5 mm Table size: 3,000 mm x 2,500 mm Option: External blowing air Kinematics: Fork head

Condition: good (used), Year of construction: 2011, functionality: fully functional, We are selling our Datron M8, year 2011. The machine is powered and ready for immediate use! Includes tools, vacuum clamping plate, pneumatic clamps, and programming software! 10-position tool magazine (incl. various tools and holders) Ffjdpeyti I Asfx Afuow HSK25 milling spindle, 50,000 rpm Includes Primcam programming software 2x pneumatic clamps Vacuum plate including vacuum pump Horizontal clamping device Cooling with alcohol or air

Condition: like new (used), Year of construction: 2022, x-travel 2500 mm y-travel 3500 mm z-travel 1500 mm Control HEIDENHAIN TNC 640 c-axis +-360 ° milling head -swivable ° milling head swivable ca. +-360 ° table dimension - longitudinal 2500 mm table dimension - cross 3500 mm table load 6 t/m² coolant IKZ 70 bar Feed speed 60 m/min. Fsdpfovwgtyox Afusfw spindle turning speed range 24000 U/min tool taper HSK-A63 milling spindle motor S6(40%/2 min) 41 kW max. torque on the spindle S6(40%/2 min) 49 Nm milling spindle motor S1(100%/2 min) 34 kW max. torque on the spindle S1(100%/2 min) 39 kW tool change unit 60 Pos. weight of the machine ca. 74 t dimensions of the machine ca. 4 x 7.5 x 5.4 m This thermosymmetrical, ergonomic, universal ZIMMERMANN FZU32 portal milling machine is in mint condition and available immediately. DESCRIPTION: The FZU32 is a remarkably compact 5-axis portal milling machine for machining aluminium machining of aluminium, fibre composites, plastics, ureol and steel. steel. Thanks to the particularly rigid, newly developed centre-guiding gantry, we can meet the increasing requirements in model, tool and mould making. mould making. This thermo-symmetrical design makes the FZU32 less susceptible to adverse environmental conditions.

Condition: excellent (used), Year of construction: 1995, x-travel 14000 mm y-travel 5000 mm z-travel 1500 mm w-axis 3000 mm column daylight 4000 mm column: max. dist. table - spindle nose 4500 mm workpiece weight 100 t table dimension - longitudinal 9000 mm table dimension - cross 3000 mm spindle taper ISO SK 50 spindle turning speed range 2-2500 U/min spindle motor 113 kW spindle diameter 200 mm max. torque on the spindle 9500 Nm feed in x - axis 1-10000 mm/min feed in y - axis 1-10000 mm/min feed range Z-direction 1-10000 mm/min rapid traverse 20000 mm/min height over floor 8600 mm control SIEMENS 840C weight of the machine ca. 360 t ATTACHMENTS angular milling head yes autom. tool clamping yes ball spindles yes guideway covers yes coolant unit yes high pressure cooling syst. (through spindle) yes closed cabin yes chip conveyor yes TECHNICAL DESCRIPTION 2 portal milling centres, each with 3 table pallets 9000 x 3000 mm: - Tool changer with 420 tools - Head pick-up system - Video monitoring via camera - High pressure lubrication unit for inner cooling 70bar AVAILABLE HEAD UNITS: - Fixed angle head HS800C600 105 Kw 600 long - Fixed angle head HSD350C850 50 Kw 850 long - Fixed angle head HSD 40C880 12 Kw 880 long Ffsdpfx Afevwgm Hjuow - Fixed angle head HSD 190C1000 30 Kw 1000 long - Vertical spindle unit VS800C 105 Kw 900 long - Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time - Angle spindle unit SO800C905 - 22,5° fix - Angle spindle unit HSE1200CS -25° fix - Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth --> 1.350 1/min , B-Achse 0,5 Grad Hirth One additional drilling extension SE 350C plus 1 SE500C. DESCRIPTION OF CONDITION In 2011/2012 these 2 identical machines were retrofitted The milling length was extended to 14meters and an automatic changing system for table pallets was installed. Both machines can be seen under power by prior appointment.

Condition: excellent (used), Year of construction: 2002, x-axis 4000 mm y-axis 3500 mm z-axis 1500 mm Control SIEMENS 840 D w-axis 1500 mm column daylight 2500 mm surface area 3000 x 2000 mm workpiece weight 10000 kg spindle turning speed range 5-6000 U/min transmission ratio 2 power capacity - milling spindle 45 kW dist. cutter spindle - workpiece spindle 3500 mm max. torque on the spindle 1250 Nm tool change unit 200 -fach tool diameter 135 / 250 mm weight of tools max. 50 kg tool length - max. 400 mm tool taper ISO SK-50 the portal milling machine is in very good condition. ADDITIONAL EQUIPMENT DRILLING/MILLING Angle milling head yes automatic tool clamping yes Tool clamping yes Ball screws yes Guideway cover yes Coolant system yes High-pressure cooling system (internal cooling) yes Full work area panelling yes Fodpfjvwgmmsx Afuefw Portal machining centre with tool changing system and second table top.

Condition: new, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 800 mm, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 30,000 m/min, feed rate Z-axis: 30,000 m/min, table length: 1,900 mm, table width: 1,100 mm, spindle speed (max.): 6,000 rpm, table load: 4,000 kg, position of the milling head: Vertikal, torque: 1,356 Nm, spindle nose: SK 50 - DIN 69871A, Equipment: rotational speed infinitely variable, BRAND NEW GANTRY MILLING MACHINE Control and Motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN 19" TFT display HEIDENHAIN package (motors, measuring systems, electronic handwheel) Spindle Power: Maximum spindle motor power: 30 kW ICS: Internal coolant supply, 70 bar Additional Equipment: Tool changer with double gripper, 60 positions Double screw conveyor (longitudinal) Hinged belt chip conveyor (transverse) Preparation for 4th axis (rotary table) Full enclosure, closed at the top Accuracies: Positioning accuracy: ± 0.025 mm Ffjdpfjq Ixc Tjx Afuew Repeatability: ± 0.020 mm Only inquiries from Germany will be answered.

Condition: new, travel distance X-axis: 3,200 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, table length: 3,000 mm, table width: 1,700 mm, spindle speed (max.): 6,000 rpm, rapid traverse X-axis: 24,000 m/min, rapid traverse Y-axis: 24,000 m/min, rapid traverse Z-axis: 24,000 m/min, table load: 10,000 kg, position of the milling head: Vertikal, workpiece weight (max.): 10,000 kg, torque: 1,392 Nm, overall weight: 30,000 kg, spindle nose: SK 50 - DIN 69871/A, spindle motor power: 53 W, Equipment: rotational speed infinitely variable, Brand new gantry milling machine Control and motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN TFT 19" screen HEIDENHAIN package: motors, measuring systems, handwheel IKZ: Internal coolant supply, 70 bar Additional equipment: 60-position chain-type tool changer with double gripper Double auger conveyor (longitudinal) Hinged belt chip conveyor (transverse) Preparation for 4th axis (rotary table) Fully enclosed, top closed Ffjdpehy Avpofx Afujw Accuracies: Positioning accuracy: ±0.035 mm Repeatability: ±0.028 mm Only inquiries from Germany will be answered // Nur Anfragen aus Deutschland werden bearbeitet

Condition: new, travel distance X-axis: 6,200 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 20,000 m/min, feed rate Z-axis: 15,000 m/min, table length: 6,000 mm, table width: 2,400 mm, spindle speed (max.): 6,000 rpm, table load: 19,000 kg, position of the milling head: vertikal, torque: 1,350 Nm, spindle nose: SK 50, spindle motor power: 53 W, warranty duration: 12 months, Equipment: rotational speed infinitely variable, Control and Motors: HEIDENHAIN TNC 640 digital contouring control HEIDENHAIN package (motors, measuring systems, handwheel) Fodshy Avtepfx Afuofw IKZ: Internal coolant supply, 70 bar Additional equipment: Carousel tool changer with double gripper, 60 positions Double screw conveyor (longitudinal) Hinged belt chip conveyor (crosswise) Preparation for 4th axis (rotary table) Fully enclosed, closed at the top Accuracies: Positioning accuracy: 0.045 mm Repeatability: 0.030 mm Only inquiries from Germany will be answered

Condition: good (used), Machine is in good working condition. Parts shown by hand not come. Ffsdpfsylxg Esx Afujw

Condition: used, Year of construction: 1974, x-travel 9700 mm y-travel 3500 mm z-travel 640 mm w-axis 3000 mm Control Siemens type 840D PL spindle diameter 200 mm Spindle capacity 85 Kw surface area 9000x2800 mm Table load 40000 kg column daylight 3400 mm high speed spindle taper ISO 50 weight of the machine ca. 193,8 t dimensions of the machine ca. 22,4x10,2x8,2 m Retrofit 2009 Steep taper ISO 60 DIN 2079 Speed ??12-450 rpm Milling heads: 1x WF 680/450 1x WFU 180/350 1x WFU 70/300 1x 550 mm extension for WFKs The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Fedpeyq Sxljfx Afujfw Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1991, x-travel 5300 mm y-travel 2500 mm z-travel 1200 mm Table load 60000 kg column daylight 2700 mm workpiece height max. 1700 mm Table dimensions 5000x2250 mm Fedpfsyq Swhsx Afusfw control Heidenhain type 430 Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2004, x-travel 3000 mm y-travel 3400 mm z-travel 950 mm surface area 2500x1600 mm no. of tables 2 control NUM Tool changer 12 Pos turning speeds 4,5-40.000 U/min spindle taper: HSK 40 spindle drive 6 kW Table load 850 kg Machine No.: 2259 B +/- 110° C 360° Table size: 6000 mm x 2500 mm (hole pattern 22H7 / M16) Spindle: Manufacturer Fischer, 2 pieces (type MFWS 1709/30 Serial number: 10015020 / 133227) Milling head: Forest Line type: fork head / B-axis +/- 110° swivel / C-axis 360° (infinite) rotation / Station for milling head storage (2 pieces) Chip conveyor: Scraper conveyor / Manufacturer: Richter Tool measurement: Blum Feed: X + Y 30,000 m/min / Z 28,000 m/min Rapid traverse: equals feed rate The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Fsdpfx Asyqv Eiefujfw Your Markus Hirsch Team

Condition: used, Year of construction: 1971, x-travel 13000 mm y-travel 2750 mm z-travel 3000 mm turning speeds 600 U/min spindle taper ISO 50 milling head 4 No. 11137 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team Ffodpfx Afeyqvl Ajujw
