Condition: ready for operation (used), Year of construction: 2002, bar diameter (max.): 32 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, number of axes: 12, This 12-axis Index MS32-P multi-spindle turning machine was manufactured in 2002. It features a Sinumerik 840D control system and includes a SIR MS32 face loader for efficient bar loading. The machine is equipped with a robust coolant system, including high-pressure pumps and a fire suppression system. If you are looking to get high-quality turning capabilities, consider the Index MS32-P machine we have for sale. Contact us for further details. - Control System: Sinumerik 840D (Index C200-4D) Dual NCU- Bar Loader: SIR MS32 Face Loader- Coolant System: Knoll System- 1x High-pressure pump: 80 bar (24 liters/min at 80 bar)- 1x High-pressure pump: 40 bar (55 liters/min at 55 bar)- 1x Low-pressure pump: 250 liters/min at 3 bar- Fire Suppression System: Included- Coolant Mist Extraction & Filtration System: SH 2000-PEV-T/TR (two-stage design)- Process Monitoring System: Integrated ARTIS process monitoring system (DEFECTIVE)- Synchronization Device: For quill spindle position 6 (counter spindle)- Tooling Components: WTO driven tool holders visible in machining area Hsdpfxsz E Inhe Abgou Technical Specification Counter Spindle Yes

Condition: ready for operation (used), Year of construction: 2011, operating hours: 27,865 h, bar diameter (max.): 24 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, number of axes: 6, This 6-axis Index MS 22 multi-spindle turning machine was manufactured in 2011. It features a Siemens Sinumerik 840D control system and includes a bar loader system with a maximum pressure of 6 bar. The machine is equipped with a Knoll coolant/filter system and various tooling attachments for enhanced versatility. If you are looking to get high-quality turning capabilities, consider the Index MS 22 machine we have for sale. Contact us for further details. Hjdpfxjz Ahy Is Abgou - Nominal Voltage: 400 V- Rated Current (In): 99 A- Short Circuit Current (Icu): 50 kA- Peak Current (I2): 3.6 kA- Maximum Backup Fuse: 100 A- Rated Power: 64 kW- Connected Load: 67 kVA- Frequency: 50 Hz- Control Voltage: 24 VDC- Operating Hours: 124,075 h- Hydraulic Operation Hours: 61,189 h- Operating Time: 37,971 h- Production Time: 27,865 h- Control System: Siemens Sinumerik 840D powerline (Index C200-4D) with Dual NCU- Bar Loader System: IEMCA / SIR MS22 P flat loader, Type 33 (YOM: 2011, Pressure: 6 bar, Mass: 100 kg, Voltage: 400 V / 50 Hz, Current: 7 A)- Material Feeders: 1 set Ø12 with reducer tubes, 1 set Ø18 with reducer tubes, 1 set Ø24- Clamping Heads: Ø9, Ø10, Ø12 – Ø18, Ø20 – Ø22- Knoll Coolant/Filter System (YOM: 2011): 1x high-pressure pump (80 bar, 24 l/min), 1x high-pressure pump (40 bar, 55 l/min), 1x low-pressure pump (300 l/min at 4 bar)- Tooling Drive Connections: 2x electrical connections on NCU 1, 3x electrical connections on NCU 2- Tooling Attachments: 1x polygon turning device, 3x powered tool holders ER11 (i = 1:2, max speed 12,000 rpm), 1x powered tool holder VDI25 (i = 1:1, max speed 6,000 rpm)- Back-machining Unit: on slide 6.3 (with 2x powered tool holders, 1x fixed holder, i = 1:2, max speed 12,000 rpm)- Optional Equipment: Fire suppression system, Coolant mist extraction and filtration system (SH 2000-PEV-T/TR, two-stage design), Integrated ARTIS process monitoring system Technical Specification Counter Spindle Yes

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, spindle motor power: 26 W, number of spindles: 2, spindle speed (max.): 5,000 rpm, spindle bore: 77 mm, Equipment: documentation/manual, MAZAK QTN-250 II MSY turning center + Fanuc robot with Meccano automation for flanges Year 2015 Control unit: MATRIX II Maximum swing (capacity): 640 Workable diameter / standard workable diameter (capacity): 380 Maximum workable length*1 (capacity): 500 Bar capacity (capacity): 77 Hodpfjzz Rh Esx Abgsu Chuck size (main spindle): 250/210 Spindle speed (main spindle): 4500/5000 Spindle nose (main spindle): ASA 8 / ASA 5 Spindle speed (powered tool spindle): 5000 Rapid traverse rate axis X (feed): 36,000 Rapid traverse rate axis Z (feed): 36,000 Rapid traverse rate axis C (feed): 550 Travel (tailstock): 500 Main spindle motor (continuous / 40% duty) (motors): 26 kW Coolant tank (coolant): 300 l Sub-spindle chuck diameter: 210 Sub-spindle speed: 5000 Travel axes X, Z, Y: 230mm, 575mm, 100mm

Condition: used, Year of construction: 2011, Micro 8 automatic lathes and LNS Tryton bar feeders. Hjdszz Nl Nopfx Abgju

Condition: ready for operation (used), Year of construction: 2013, operating hours: 22,100 h, bar diameter (max.): 104 mm, overall weight: 13,000 kg, controller manufacturer: SIEMENS, controller model: Sinumerik, number of axes: 4, This 4-axis DMG CTX beta 800 4A was manufactured in 2013. It features a maximum turning diameter of 340 mm and a turning length of 735 mm. The machine is equipped with two 12-station tool turrets and an integrated spindle motor with a maximum speed of 4000 rpm. If you are looking to get high-quality turning capabilities, consider the DMG CTX beta 800 4A multi-spindle turning machine we have for sale. Contact us for further details. - Control: Siemens 840D Solutionline with ERGOline Control and ShopTurn 3G- Max Turning Diameter: 340 mm- Max Turning Length: 735 mm- Main Spindle (HS): Integrated spindle motor ISM 102, 40/48 kW (100/40% ED), 0-4000 rpm, 570/680 Nm- Counter Spindle (GS): Integrated spindle motor ISM 76, 25/32 kW (100/40% ED), 0-5000 rpm- Draw Tube Inner Diameter: 104 mm- Tool Turrets: 2x 12-station Sauter star turrets (VDI 40 with Trifix interface, DIN 69880-40)- Driven Tool Drive: 2x Direct Drive, 40-10,000 rpm, 14.2 kW, 34 Nm- Axis Configuration: 4 Main Motion Axes (X1, Z1, X2, Z2), 2 C-Axes with hydraulic spindle brake (HS + GS), Y-Axis for Slide 1 and Slide 2 (stroke 40 mm), NC cross-stroke X3 axis for counter-spindle slide (180 mm)- Counter Spindle Slide: Includes NC cross-stroke X3 (180 mm) with linear scale, and integrated tailstock- Tailstock: Automatic quill stroke 300 mm, tailstock force 1.5 - 6.3 kN, revolving center MT5- Measuring Systems: Direct measuring systems (Glass scales) in X1, X2, and X3 axes- Coolant System: 980 Liter tank with band filter, cooler, 8/20/80 bar pressure options, and expansion for Turret 2- Additional Equipment: Chip conveyor, automatic electric sliding hood, workpiece in-process measurement system (Renishaw), Brankamp CMS collision monitoring system, mechanical oil mist separator (1,100 m³/h) Hodpfx Abjzzpxpogju Technical Specification Counter Spindle Yes

Condition: used, Year of construction: 2004, Tornos MultiDeco 20/8 Number of spindles: 8 Maximum bar diameter: 20 mm Spindle speed: 5000 rpm Main spindle power: 15 kW / 18.5 kW Maximum part length: 100 mm without backworking; 75 - 80 mm with backworking Number of backworking spindles: 1 Hodpfx Aezy Spujbgeu Backworking spindle axial travel: 160 mm Backworking spindle motor power: 1.1 kW CNC control unit: Fanuc Programming system: TB-DECO software platform IEMCA integrated automatic bar feeder High-pressure coolant pump and fine filtration system Automatic chip conveyor The machine is in working condition and can be inspected upon request.

Condition: used, Year of construction: 2019, functionality: fully functional, feed length X-axis: 318 mm, feed length Y-axis: 51 mm, feed length Z-axis: 584 mm, number of spindles: 2, spindle speed (max.): 4,500 rpm, spindle bore: 51 mm, Equipment: cooling unit, documentation/manual, The DS-30Y Y-axis turning center combines turning with two spindles, a Y-axis, a C-axis, and powered tooling to create a powerful “one-hit” solution for any workshop. Milling, drilling, and off-center threading can be enhanced for increased machining capabilities. It comes standard with a 12-station BMT65 turret and a synchronized C-axis for versatile 4-axis capabilities. Counter spindles support fully synchronized rotation and enable workpiece transfer during operation to reduce cycle times. Hedszvy D Eepfx Abgju Spindle | CHUCK-10"-A2-6 4.8K-20HP-A2-5-DS | CHUCK-8.3"-A2-5 LT-BMT65-12 Live Tooling 4000 rpm CONVEYOR ATP Automatic Tool Presetter PCAT Part Catcher HPC High-Pressure Coolant CABCOOL NGC | 1GB, ETHERNET, WIFI, EPFDM SO, MACRO, RTAP, 8M

Condition: ready for operation (used), Year of construction: 2006, spindle motor power: 22,000 W, spindle speed (max.): 3,500 rpm, bar diameter (max.): 76 mm, travel distance X-axis: 250 mm, travel distance Y-axis: 50 mm, controller manufacturer: FANUC, controller model: 18i-TB, number of axes: 6, This 6-axis DOOSAN Puma TT 2500 SY was manufactured in 2006. It is a multi-spindle turning machine featuring twin spindles and twin turrets, equipped with a Fanuc 18i-TB control. Key specifications include a maximum turning diameter of 330 mm, turning length up to 500 mm, and bar capacity of 76 mm. Main spindle speed reaches 3500 RPM, while the sub-spindle can go up to 6000 RPM. If you are looking to get high quality turning capabilities consider the DOOSAN Puma TT 2500 SY machine we have for sale. Contact us for more information. • Max turning diameter: 330 mm (12.99 in); upper turret: 390 mm Hsdpfxezvu Ufj Abgou • Max turning length: 500 mm (19.6 in) • Bar capacity (main spindle): 76 mm (2.99 in) • Travels: X 250 mm (9.84 in), Y ±50 mm (±1.97 in), Z 580 mm (22.8 in) • Sub spindle speed: 6000 rpm • Sub spindle motor power: 7.5 / 11 kW • Notes: Series introduced mid-2000s Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2000, No. of axis 10 No. of spindles 2 Max. spindle bore 10 mm Spindle speeds 100-16000 rpm Control: Fanuc Equipped with: Hjdpszvcduefx Abgsu Magazine barfeeder FMB Minimag Chip conveyor

Condition: used, Year of construction: 2003, No. of axis 10 No. of spindles 2 Max. spindle bore 16 mm Spindle speeds 100-10000 rpm Hsdpszvb Ryefx Abgou Live toolings on S2, S3, S5 & S6 Control: Fanuc PNC 16i Equipped with: Magazine barfeeder FMB Turbo 2-16

Condition: good (used), Year of construction: 2014, functionality: fully functional, using Stäubli robots Hjdpfx Abezuc T Togju Specifications, information, price, images, etc. can be found in the PDF documents attached.

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter Hodezubyrjpfx Abgeu delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or *

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, number of spindles: 2, spindle speed (max.): 4,500 rpm, turning length: 145 mm, turning diameter: 240 mm, travel distance X-axis: 130 mm, travel distance Z-axis: 145 mm, Horizontal, twin-spindle CNC lathe with 2 turrets in two working areas and 2 loading portals! Hjdpfxsztxlcj Abgou The machine underwent an overhaul in 2023! TECHNICAL DETAILS Turning diameter max.: 240 mm Turning length max.: 145 mm Travel X-axis: 130 mm Travel Z-axis: 145 mm Distance between spindles: 340 mm Rapid traverse X/Z-axis: 24 m/min Guidance X-axis: Roller linear guide Guidance Z-axis: Round guide, 145 mm Number of spindles: 2 Spindle drive power: 11 / 7.5 kW Max. spindle speed: 4,500 rpm Torque: 93 Nm Spindle nose: JIS A2-5 Chuck size: 210 mm (8 inches) Number of turrets: 2 Turret type: BT turret Tool positions per turret: 8 Shank size for external turning tools: 20 × 20 mm Max. shank diameter for boring bars: 40 mm MACHINE DETAILS Control: Fanuc 32i-B Working areas: 2 Power connection: 30 kVA Dimensions & Weight Footprint: 4,500 × 2,440 mm Overall height with loader: 2,550 mm Weight: 4,400 kg Loading portal GT Twin with two independent portals Dual gripper for raw and finished parts Turning station Control unit with cable Max. workpiece diameter: 120 mm Max. workpiece length: 80 mm Max. workpiece weight: 3 kg EQUIPMENT Stack magazine, on the left side Parts conveyor belt, on the right side Chip conveyor, on the rear side Coolant tank Coolant supply through both spindles for flushing the clamping devices Various tool holders Various clamping devices Documentation and wiring diagrams

Condition: ready for operation (used), Year of construction: 2002, operating hours: 63,040 h, functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Machine configuration Upper linear slides: 2 units Milling unit: 1 unit Transverse drilling units: 2 units Rigid front spindle: 1 unit Machining units Drum 6: Movable only in the X-axis Front position 1: Rotationally rigid spindle, movable only forwards and backwards Front positions 2 to 4: Rotationally fully controllable spindles Front position 5: Internal machining axis for processing internal contours and radii Front position 6: Driven indexing spindle with rear machining slide and two tools, movable towards the viewing side Full electronic equipment Electronically connectable auxiliary drives on the front positions and six drum slides MACHINE DETAILS Operating hours: 98,119 h Spindle hours: 63,040 h EQUIPMENT Chip conveyor Hodpfx Aezrgnpjbgeu High-pressure coolant unit Bar loader Milling unit Two transverse drilling units Collets Spare parts Electronic components for the control cabinet New rigid front spindle

Condition: good (used), Year of construction: 2014, See documents. Hsdpfx Aezqtg Asbgsu List of individual machines with operating hours, etc. – see documents.

Condition: ready for operation (used), Year of construction: 2008, spindle motor power: 26,000 W, spindle speed (max.): 3,500 rpm, bar diameter (max.): 76 mm, total width: 2,210 mm, total height: 2,480 mm, overall weight: 12,700 kg, controller manufacturer: FANUC, controller model: Series 31i-MODEL A, product length (max.): 4,050 mm, number of axes: 8, This 8-axis DOOSAN PUMA TT2500SY was manufactured in 2008. It features a maximum turning diameter of 390 mm on the upper turret and 300 mm on the lower turret, with a maximum turning length of 350 mm. The machine includes a robust tool turret with 24 stations and a rapid traverse speed of 20 m/min for X1 and X2 axes. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA TT2500SY multi-spindle turning machine. Contact us for further details. • Number of axes: 8 (X1, X2, Z1, Z2, Y, B, C1, C2) • Swing over bed: 800 mm • Swing over saddle: 620 mm • Max. turning diameter: Upper turret 390 mm; Lower turret 300 mm • Recommended turning diameter: 255 mm • Max. turning length: 350 mm • Main/left spindle motor power (30 min / cont): 26 / 22 kW • Main/left spindle nose: ASA A2-8 • Right/sub spindle max. speed: 3500 rpm • Right/sub spindle motor power (30 min / cont): 26 / 22 kW • Right/sub spindle nose: ASA A2-8 • C-axis indexing (C1 & C2): 360° in 0.001° increments • Upper turret travel (X1/Z1/Y): 255 / 800 / 120 mm (±60 mm Y) • Lower turret travel (X2/Z2): 190 / 900 mm • Sub-spindle B-axis travel: 810 mm • Rapid traverse (X1/X2): 20 m/min • Rapid traverse (Z1/Z2/B): 24 m/min • Rapid traverse (Y): 7.5 m/min • Turret stations: 24 total (12 upper + 12 lower) • Tooling type/interface: BMT65P • Indexing time: 0.2 s • Rotary tool spindle speed: 4000 rpm • Rotary tool motor power (15 min / cont): 5.5 / 1.5 kW • Machine electric power supply: 95.77 kVA Hjdpfx Ajznwf Djbgju Additional equipment • Chip conveyor • Various static tool holders • Rotary live tool holders • Chucks on both spindles Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, We offer you: Manufacturer: INDEX Type: MS40-6 C Year of construction: 2019 Control: Index control C200-SL, MS40C Double-NCU Technical data: Working spindles: Number: 6 pcs. Spindle bore: max. 40 mm Max. speed: 7,000 rpm Power (100% / 25%): 13 / 24 kW Torque (100% / 25%): 31 / 57 Nm Hodpfjzlutmox Abgeu Synchronous spindle: Number: 1 pc. Spindle bore: 40 mm Max. speed: 8,000 rpm Power (100% / 25%): 10 / 14 kW Torque (100% / 25%): 16 / 22 Nm Slide travel z: 150 mm Number of tools for back-end machining: 3 pcs. Swiveling range b: 144 ° Tool holder: Number: 12 pcs. Slide travel x: 73 mm Slide travel z: 120 mm Tool holder, cut-off and back-boring slide: Number: 1 pc. Slide travel x: 82 mm Number of tools for back-end machining: 3 pcs. Electrical connection data: Rated power: 85 kW Connection power: 101 kVA Rated current: 145 A Max. pre-fuse: 160 A Note: Mains voltage: 400V Note: Electrical frequency 50 Hz Technical features & accessories: - Double-NCU - Signal light 'Smartlight' with LED - Machine designed for connection to a TN network. - Coolant: Cutting oil - NC option Synchronous spindle / Multi-sided turning incl. electronic shaft - INDEX loading magazine MBL40-6/3300/Strip loader/50Hz: - Strip loader 50Hz - for bar diameter D13 - D40 - Bar length 3300 mm - with pilot drilling unit - Material storage with 700 mm support area - Profibus-DP-Master interface. - 1 set (6 pieces) reducing sleeves manufactured for bar or corner dimensions, diameter D = * mm, Inner diameter range D14 - D41 - 1 set (6 pieces) material sliders for material diameter D24mm - D32mm, consisting of: - 6 material sliders D23 - 6 rotating sleeves D23 - 1 set (6 pieces) internal clamping sleeves D23mm - for material diameter D24mm - D32mm - pilot drilling diameter D15mm - 1 set (6 pieces) external stops D23mm - for material diameter D24mm - D32mm - pre-machined - 1 set (12 pieces) reducing sleeves for material sliders. The outer diameter of the reducing sleeves corresponds to the material diameter (D13 - D40) - 1 set (6 pieces) adapter sleeves, inner diameter range D13.5 - D40.5. The inner diameter of the adapter sleeves should be bar diameter + 0.5mm. - 1 set (6 pieces) two-part guide intermediate tubes, diameter 29 mm - Assembly aid for the sleeves of the guide intermediate tubes - UNIMAG - Interface for connecting a bar loader - Part discharge via slide into spindle position 6 - Workpiece conveyor belt in spindle position 6, machine-integrated - Hainbuch TOPlus Axfix D40 for synchronous spindle - Multi-sided and thread milling device - Reduction ratio i=5:1 - Inductive encoder for reference query - Internal oil lubrication - INDEX short taper connection - without converter - Back-end machining device on slide position 6.2 for max. three boring positions for fixed tools FURTHER INFORMATION IN THE PICTURES Accessories, tools and clamping devices shown are only included in the scope of delivery if this is stated in the additional information. Changes and errors in the technical data and information, as well as prior sale, are reserved!

Condition: used, Year of construction: 2015, The machine will be delivered as shown in the photos, including the visible tool holders, etc. Hsdpfxozlqavo Abgju

Condition: used, Pick-up truck Hjdpezi U H Ijfx Abgju pick-up control unit Pietro Cucchi full-body loader

Condition: good (used), functionality: fully functional, 2 Index MS 25 E machines in very good condition and fully functional – also available individually – for sale. Hjdpfxozicxlo Abgsu Inspection while the machines are powered on is possible.

Condition: used, TECHNICAL DETAILS - Number of axes : 23 - Number of spindles : 8 - Number of counter-spindles : 1 - Max. part length : 100 [mm] SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 11.2 [kW] COUNTER-SPINDLE - Y stroke : 280 [mm] - Z stroke : 450 [mm] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 6: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 7: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 8: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5.300 x 2.200 [mm] Hsdjzhph Depfx Abgsu - Machine height : 2.600 [mm] - Machine weight : 12.000 [kg] MACHINE HOURS - Number of hours under power : 75000 [h] EQUIPMENT - CNC : Fanuc 30i-TB - Hirth teeth - 1 counter-spindle in position 7 - Counter-spindle with counter-operation device - 2 x 4 counter-operation tools - 8 spindles with independent spindle speeds - C-axis on all 8 spindles and the counter-spindle : 0.001 [°] - Chips conveyor : MAYFRAN - Coolant tank * with high-pressure pump : 35 + 80 [bars] - Bar loader : ROBOBAR MSF-522/8 - Oil mist extractor

Condition: used, TECHNICAL DETAILS - Number of axes : 23 Hodpfx Abozhphwogju - Number of spindles : 8 - Number of counter-spindles : 1 - Max. part length : 100 [mm] SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 11.2 [kW] COUNTER-SPINDLE - Y stroke : 280 [mm] - Z stroke : 450 [mm] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 6: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 7: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 8: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5.300 x 2.200 [mm] - Machine height : 2.600 [mm] - Machine weight : 12.000 [kg] MACHINE HOURS - Number of hours under power : 73500 [h] EQUIPMENT - CNC : Fanuc 30i-TB - Hirth teeth - 1 counter-spindle in position 7 - Counter-spindle with counter-operation device - 2 x 4 counter-operation tools - 8 spindles with independent spindle speeds - C-axis on all 8 spindles and the counter-spindle : 0.001 [°] - Chips conveyor : MAYFRAN - Coolant tank * with high-pressure pump : 35 + 80 [bars] - Bar loader : ROBOBAR MSF-522/8 - Oil mist extractor

Condition: used, TECHNICAL DETAILS - Number of axes : 18 - Number of spindles : 6 - Max. part length : 120 [mm] SPINDLES - Max. bar diameter : 8 - 25.4 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 18 [kW] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 6: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 71 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.500 x 1.600 [mm] - Machine height : 1.950 [mm] - Machine weight : 8500 [kg] MACHINE HOURS - Number of hours under power : 72000 [h] EQUIPMENT - CNC : Fanuc 16i-TB - Hirth teeth - Counter spindle with counter-operation device - Goltenbolt turning tool holders in all positions - 5 fixed drills - 1 cutting tool holder - Chips conveyor - Coolant tank * with high-pressure pump Hodpfxozhphqj Abgju - Bar loader : ROBOBAR MSF-522/6 - Oil mist extractor

Condition: used, TECHNICAL DETAILS - Number of axes : 18 - Number of spindles : 6 - Max. part length : 120 [mm] SPINDLES - Max. bar diameter : 8 - 25.4 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 18 [kW] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 6: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 71 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.500 x 1.600 [mm] - Machine height : 1.950 [mm] - Machine weight : 8500 [kg] MACHINE HOURS - Number of hours under power : 65000 [h] EQUIPMENT - CNC : Fanuc 16i-TB - Hirth teeth - Counter spindle with counter-operation device - Goltenbolt turning tool holders in all positions - 5 fixed drills - 1 cutting tool holder - Chips conveyor - Coolant tank * with high-pressure pump - Bar loader : ROBOBAR MSF-522/6 - Oil mist extractor Hjdpfx Ajzhphkebgou

Condition: ready for operation (used), Year of construction: 2015, operating hours: 42,222 h, spindle speed (max.): 5,000 rpm, bar diameter (max.): 65 mm, total width: 1,990 mm, total height: 2,300 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, overall weight: 9,500 kg, controller manufacturer: FANUC, controller model: 310, product length (max.): 4,500 mm, number of axes: 8, This 8-axis DMG MORI Sprint 65 linear was manufactured in 2015. It features a maximum workpiece diameter of 175 mm and a maximum bar diameter of 65 mm. The machine is equipped with two turrets, each with 12 driven tool positions, and offers a maximum spindle speed of 5000 rpm. If you are looking to get high-quality turning capabilities, consider the DMG MORI Sprint 65 linear multi-spindle turning machine we have for sale. The machine comes with a large and valuable set of spare parts and components. Contact us for further details. Control system: CNC 310 isTotal hours: 61295 hOperating hours: 42222 hMain spindle power 20/25 kWCounter spindle power 17 kWMax. main spindle speed: 5000 rpmMax. counter spindle speed: 5000 rpmMax. main spindle bar diameter: 65 mmMax. counter spindle bar diameter: 45 (65) mmCNC CONTROLLED AXESStroke X1 165 mmRapid speed X1 30 m/minAcceleration X1 5 m/s2Stroke Z1 678 mmRapid speed Z1 30 m/minAcceleration Z1 5 m/s2Stroke Y1 80 (+50/-30) mmRapid speed Y1 30 m/minAcceleration Y1 5 m/s2Stroke X2 165 mmRapid speed X2 30 m/minAcceleration X2 5 m/s2Stroke Z2 640 mmRapid speed Z2 30 m/minAcceleration Z2 5 m/s2Stroke W2 690 mmRapid speed W2 30 m/minAcceleration W2 5 m/s2Number of turrets 2Number of rotating tools each station 12 all driven positionsTool system VDI 30Max driven tool speed 4.000 rpmApprox. coolant tank capacity 650 lCoolant pump max.capacity (per each turret) 20 l/minPump pressure 7 barPower supply 91 kVALxWxH of the machine 4.500x1.990x2.300 mmApprox. machine weight 9.500 kgThe machine comes with a large and valuable set of spare parts and components.IEMCA MASTER 865 MP 43 L (4m) bar feederBase machine configuration:- Drive for slide 1 and 2 (all 12 pos.)- C-axis for main and counter spindle- Y-axis for slide 1- Swarf conveyor belt type- Counterspindle collet cleaning with coolant- Workpiece unloading including belt- Mechanical preparation for oil mist filter- Electrical and software interface for bar loader- Angular synchronism between main and counter spindle- Automatic machine shut down- 2 additional on/off outputs (4 M-functions)- Rigid tapping- Piece and time counter- Software for polygonal turning for slide 1 and 2- Constant cutting speed- Helical interpolation for slide 1- Spindle speed control- Quadruple warning light- Cooling device for electrical cabinetAdded options:I-V50011 Collet chuck Type "MPF 65/140" without axial feed for main spindle max. diameter: 65mm.Clamping elements and other equipment:I-V50025 Manual collet changer type "SACO MPT65/140 and MPF65/140"I-V50092 Differential pressure for counterspindle, possibility of setting two different clamping pressures.I-V50083 1 set of soft jaws for chuck type "SMW 175-BBD"I-V50080 Chuck type "SMW 175-BBD" For counter spindle, including adapter for adapting the spindleI-V60050 Tool holder for drilling tools with internal cooling and cylindrical shank Ø 32mm,with clamping shank according to DIN 69880 (VDI 30) - 4pcsI-V60010 Radial tool holder for external machining type C1 with clamping shank according to DIN 69880 (VDI 30) - 5pcsControl system options:I-V12060 Tool wear monitoring system Monitor for CNC FANUCI-V12070 Sister tool selection system for Tool Monitor for CNC FANUCHydraulic and filtration equipment:I-V40045 External flushing of jaws/collets with coolant on main spindle and counter spindleSpecial optionsSK001 Special clamping device with mandrel for counter spindle product HAINBUCH AXFIX 811 including 2 collets Hjdpezhklwofx Abgsu
