Used Tos Bph20 for sale (674)

Condition: good (used), Year of construction: 2005, functionality: fully functional, Control system: Siemens 840-D Spindle diameter: 130 mm Spindle speed: 3500 RPM Spindle mount: ISO 50 Torque: 1320 Nm Main motor power: 37 kW Travel in X-axis: 4000 mm Travel in Y-axis: 2500 mm Travel in Z-axis: 2000 mm Travel in W-axis: 800 mm Working feed rates: 15 m/min Rapid traverse rates: 20 m/min Rotary table: 1800 x 1800 mm Table load capacity: 20,000 kg Tool magazine: 60 positions Bdodpfx Aboz Ii Tdeasi Machine weight: approx. 36 tons Universal milling head - manual

Condition: good (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, space requirement width: 1,975 mm, space requirement length: 1,800 mm, space requirement height: 1,900 mm, Equipment: documentation/manual, Machine is in very good condition - used as a training machine until 2018; since then, the machine has hardly been in operation. Operating voltage 400 V Spindle mount ISO 40 Quill stroke 100 mm Spindle speeds 63 – 3150 rpm Fixed table Bedpfxsw U Aahj Abajdi

Condition: used, Year of construction: 1992, functionality: fully functional, machine/vehicle number: 2202, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, total height: 1,740 mm, total width: 1,740 mm, total length: 2,090 mm, overall weight: 1,725 kg, Equipment: documentation/manual, The machine is in very good condition – it was used as a training machine until 2018; since then, it has rarely been in operation. Operating voltage: 380 V. Spindle mount: ISO 40. Quill stroke: 100 mm. Spindle speeds: 40 - 2000 rpm. Rotary table. Bdjdpfsw Urirex Abasi

Condition: good (used), Year of construction: 2013, Ref. -No.: 10636 Manufacturer: TOS VARNSDORF Type: WHN 13 CNC Year of construction: 2013 Type of control: CNC-Steuerung Control: Heidenhain 530 Storage location: Halberstadt Country of origin: Czech Republic X-Travel: 3500 mm Y-Travel: 2000 mm Z-Travel: 1250 mm W-Axis: 800 mm B-Axis: 360 ° Table Load: 15.000 kg Tool Taper: SK 50 Turning Speeds: 1400 RPM Spindle Speed: 2000 RPM Table size: 1800 x 2200 mm Further information: - The control system was converted to a HEIDENHAIN 530i in 2013. - All drives were upgraded to digital. Thrust bearing replacement on the tower also renewed in 2013. - Accessories: - 3D probe - Heidenhain, large spindle support - 1x Heidenhain axis module (completely overhauled), - 1 new axis module is installed in the machine. - Newly packaged spare parts, covers from the machine. - All bearings have been replaced on the machine in recent years. Bdodpfxo Ahkx Ij Abaji - Tools and milling cutter heads are available. The machine is first-hand. The machine is still powered up and in production. The machine can be viewed by appointment.

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, center width: 2,000 mm, rotational speed (max.): 450 rpm, workpiece weight (max.): 5,000 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swinging diameter over bed: 1,050 mm Distance between centers: 2,000 mm Spindle bore: 105 mm Spindle speed: 2.24–450 rpm Workpiece weight: max. 5,000 kg MACHINE DETAILS Control: Conventional Motor power: 22 kW Dimensions & Weight Dimensions (L x W x H): 4,900 x 1,900 x 1,700 mm Machine weight: 8,000 kg Bdodpfx Ae Af Hdusbaoi EQUIPMENT Four-jaw chuck Fixed steady rest

Condition: good (used), Year of construction: 1998, Ref. -No.: 10671 Manufacturer: TOS VARNSDORF Bodj Ahky Nspfx Abaedi Type: WH 105 CNC Year of construction: 1998 Type of control: CNC Control: Heidenhain TNC 426 PB Storage location: Halberstadt Country of origin: Czech Republic Further information: The machine is currently in active production and can be inspected under power and in operation by prior arrangement

Condition: ready for operation (used), Year of construction: 2011, EXCELLENT CONDITION TOS SVITAVY FWP 225 FOUR-SIDED PLANER AND PROFILING MACHINE FOR SALE Perfect choice for industrial woodworking production and professional window manufacturing! For sale is an exceptionally well-maintained, robustly constructed, Czech-made TOS Svitavy FWP 225 four-sided planer and profiling machine. The machine is an ideal choice for larger-capacity carpentry workshops, lumber processing facilities, and specifically for the serial production of wooden joinery (windows, doors). 📌 KEY FEATURES AND TECHNICAL SPECIFICATIONS: Bsdpfsz Tdhzox Abaedi • Year of manufacture: 2011 (Young, modern and precise design) • Total power: 35 kW (High-performance, efficient motors) • Supply voltage: 3~ 400 / 230 V (50 Hz) • Machine weight: 2900 kg (Nearly 3 tons, massive cast iron frame, which guarantees completely vibration-free and highly accurate machining) • Pneumatic requirements: 0.4 – 0.6 MPa (4 – 6 bar) operating air pressure for the clamping devices • Protection rating: IP 54 (Protection against dust and splashing water) • The machine features a robust cast iron frame, excellent vibration damping, and high-performance motors, which guarantee warp-free and perfect surface quality. • Key technical parameters and features: • Maximum working width: 225 mm • Maximum working height: 120–130 mm • Spindle diameter: Standard 40 mm (easy tooling) • Feed speed: Continuously adjustable (between 5 – 25 m/min) for optimal material processing. • Removable/replaceable groove bed: Modular table design that allows for the easy removal of the groove bed for quick adjustment between precise guidance of short, uneven pieces and smooth surface planing. Used in a single shift!

Condition: good (used), TOS fnk 25 – milling machine Table dimensions: 1250 × 290 mm, 800 mm X-axis travel 370 mm Y-axis travel 450 mm Z-axis travel Automatic feed on the drill quill, 3 settings: 0.035 / 0.070 / 0.140 Automatic feed and rapid traverse on the X and Y axes Electric traverse (rapid traverse) on the Z-axis Spindle ISO 40 with a speed of 56–4500 rpm, Table load capacity up to 200–500 kg, Machine dimensions: 1.90 m (length) × 1.70 m (depth) × approx. 2.3 m (height) Machine weight: approx. 1.7 tons. Bdeds Ahfd Sspfx Abasi Year of manufacture: 1986

Condition: reconditioned (used), Year of construction: 2003, functionality: fully functional, TRACKED SINGLE-SHAFT MULTIBLADE SAWMILL TOS SVITAVY PWR 401 450/160, 75 kW MOTOR Note: Fitted with new guides and a new chain (the replacement cost was quite significant – 36,000 PLN) TECHNICAL DATA - Track width: 450 mm - Shaft width: 420 mm - Mounted blade: 400 mm - Maximum blade diameter: 450 mm - Blade bore diameter: 80 mm - Maximum cutting height with 450 mm blade: 160 mm - Table dimensions: 2230 x 860 mm Top side: - Anti-kickback pawls - Slipper shaft - Anti-kickback pawls - Smooth slip roller - Hold-down - Shaft with bushing and nut - Hold-down - 2 slip/hold-down shafts Bottom side: - Roller before the table - Guide rail - Pawls - Track chain - Central track chain lubrication Bedpfoy Nxdyox Abaodi - Electric rise and fall for sawshaft - Electric body lift: 0.75 kW - Infinitely variable feed speed – new 2.2 kW inverter installed - Extraction port diameter: 280 mm - Main motor: 75 kW - Overall dimensions (L/W/H): 2360 x 2000 x 1960 mm - Weight: 3250 kg ADVANTAGES - Czech manufacture - Used multiblade saw - Overhead operator’s control panel - Full technical documentation (DTR) - Very good condition - We can provide a warranty for the equipment

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, We offer for sale a CNC vertical lathe (carousel) TOS HULÍN SKJ 12 A CNC, equipped with a Siemens SINUMERIK 840Di control system. The machine underwent a complete overhaul and modernization in 2009, including the installation of CNC control and machine geometry adjustment. The carousel is fully functional, in operational condition, and can be demonstrated to interested parties upon prior arrangement. Technical specifications: Parameter | Value Manufacturer | TOS HULÍN Type | SKJ 12 A CNC Manufacturing number | 2212 046 Year of overhaul | 2009 Control system | Siemens SINUMERIK 840Di Diameter of clamping plate | 1,250 mm Maximum workpiece diameter | 1,400 mm Maximum workpiece height | 1,070 mm Maximum workpiece weight | 6,000 kg Cross slide stroke | 710 mm Working stroke of the ram | 720 mm Transverse travel of the tool post from the center of the clamping plate left/right | 60 / 915 mm Machine condition and equipment: * Complete overhaul and modernization in 2009 * CNC control system Siemens SINUMERIK 840Di * Turret tool head * Complete technical documentation in electronic format, including documentation before and after the overhaul Bedpfx Ajz Tzyuebaodi * Machine geometry adjustment performed * Fully functional condition with the possibility of demonstration The machine is suitable for machining larger-sized rotary parts, flanges, fittings, and other components in mechanical engineering production. Inspection and demonstration of the machine are possible upon prior arrangement.

Condition: used, TOS W100A - Horizontal Boring and Milling Machine The W100A is one of the most successful models from TOS Varnsdorf and represents the latest version of the classic series (H100, H100A, W100, W100A). It is robustly built, technologically versatile, and easy to operate and maintain. Ideal for single and small batch production with high reliability and comparatively low costs. - Classic design with a fixed column - Extendable spindle - Cross-traveling, rotatable work table - Integrated faceplate support in the spindle head - Option to use long drill rods with support from the drill support - Hardened and ground guide rails - Central lubrication - Position indicator The machine is suitable for drilling, milling, facing, and threading, as well as general machining operations on large workpieces. Technical data Spindle head: - Spindle diameter: 100 mm - Spindle connection: ISO 50 - Spindle travel (Z): 900 mm - Spindle center height above the table (Y): 0 - 1120 mm Bdeds Ahg Dtjpfx Abaei - Distance between faceplate and support bearing: 2800 mm - Faceplate diameter: 600 mm - Centering hole diameter in the table plate: 280 H6 mm - Centering hole depth: 8 mm - Max. facing diameter: 900 mm T-slots: - Faceplate, number/size/pitch: 2 / 20 H12 / 335 mm - Slide, number/size/pitch: 2 / 16 H12 / 150 mm Table: - Table cross travel (X): 1600 mm - Table longitudinal travel (W): 1250 mm - Clamping area: 1250 × 1250 mm - T-slots, number/size/pitch: 9 / 22 mm / 160/80 mm - Centering hole diameter in the table: 180 H6 mm - Centering hole depth in the table: 6 mm - Max. workpiece weight: 3000 kg - Tailstock slide travel: 1000 mm Speed: - Number of spindle speed steps: 23 - Spindle speed range: 7.1 – 1120 rpm - Number of faceplate speed steps: 16 - Faceplate speed range: 7.1 - 224 rpm - Max. torque of the spindle at speed: 3350 / 7.1 - 78.5 / 1120 Nm/rpm Feeds: - Drilling feeds, number/range: 32 / 0.02 - 12 mm/rev - Drilling feeds, number/range: 18 / 18 - 900 mm/min - Drilling feeds, number/range: 32 / 0.02 - 12 mm/rev - Drilling feeds, number/range: 18 / 25 - 1400 mm/min Rapid traverses: - Spindle, spindle head, table & tool slide: 2800 mm/min - Table rotation: 1 rpm - Tailstock bearing: 696 mm/min Threads: - Metric threads, number/range: 18 / 0.25 – 12 mm - Inch threads, number/range: 18 / 120 - 2.5 threads/1" Electrical data: - Main motor power: 11 kW - Total power consumption: 15 kW - Operating voltage: 3x 400 V / 50 Hz Dimensions & weights: - Machine dimensions WxHxD: approx. 6020 × 3000 x 3500 mm - Machine weight: approx. 14000 kg

Condition: used, Year of construction: 2010, Faceplate LD 650 for TOS WHQ 13 For sale: a used faceplate LD 650, manufactured in 2010, suitable for TOS WHQ 13. Suitable for facing, turning, and machining large diameters. Slide stroke: 170 mm, maximum machining diameter: approx. 1,000 mm. The faceplate is intended for use on a TOS WHQ 13. Technical data: Type: LD 650 Bedpez I Dvmsfx Abajdi Diameter: 650 mm Slide stroke: 170 mm Machining diameter: 300 - 1,000 mm Speed: up to 150 rpm including turning tool holder Price: 9,100.00 Euro net (new price: 21,500.00 €)

Condition: good (used), functionality: fully functional, Universal lathe SU63A/3000, accessories. Bdodpfx Abo Af Ah Noaei

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 14,000 mm, feed length X-axis: 5,000 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 14,000 mm, feed rate X-axis: 5,000 m/min, feed rate Y-axis: 1,000 m/min, feed rate Z-axis: 1,400 m/min, nominal power (apparent): 22 kVA, controller manufacturer: Heidenhain, workpiece length (max.): 5,000 mm, workpiece width (max.): 1,000 mm, workpiece height (max.): 1,400 mm, workpiece diameter (max.): 1,000 mm, workpiece weight (max.): 10,500 kg, table width: 1,000 mm, table length: 5,000 mm, table load: 10,500 kg, rotational speed (min.): 2,500 rpm, rotational speed (max.): 2,500 rpm, spindle speed (min.): 2,500 rpm, spindle speed (max.): 2,500 rpm, spindle nose: ISO 50, number of spindles: 1, number of slots in tool magazine: 40, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, Technical specifications Table clamping width 1000 mm Table clamping length 5000 mm Bedpfx Abj Aazqfjaedi Working feed range 1 - 5000 mm/min Speed range 11 - 2500 rpm Spindle taper ISO 50 X-axis 5000 mm Y-axis 1000 mm Z-axis 1,400 mm Main motor power 22 kW Max. workpiece weight 10,500 kg

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 250 mm, stroke length: 250 mm, throat depth: 365 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 560 mm Y-axis travel: 450 mm Z-axis travel: 250 mm Stroke: max. 250 mm Overhang: max. 365 mm Bsdpfx Ae Af Hdbsbasdi Table diameter: 500 mm Table length: 500 mm Table width: 500 mm Table depth: 500 mm MACHINE DETAILS Control system: Conventional Model: Vertical Number of axes: 3 Power: 5.5 kW Dimensions & Weight Dimensions (L x W x H): 2,000 x 1,600 x 2,350 mm Net weight: 3,000 kg Number of transport packages: 1

Condition: used, Year of construction: 1971, For sale is a TOS WH 80 drilling machine, manufactured in 1971, in working condition. The machine is equipped with a retrofitted digital display and has an MK5 spindle. Equipment / Condition: * TOS WH 80 * Year of manufacture: 1971 * Functional * Retrofitted digital display * MK5 spindle * Large clamping table with T-slots * A large amount of additional equipment and accessories is available * Maintenance / Repairs: In 2024, the gearbox was opened and overhauled. Various gears were renewed or replaced during this process. The machine can be inspected on-site and, by arrangement, demonstrated. Due to its size and weight, the buyer is responsible for organizing the collection or transport. Bedpfx Aozwv Dkjbasdi Further photos and information on the available additional equipment are available upon request. VAT can be shown separately.

Condition: excellent (used), CATALOGUE NUMBER: 7480 Bjdpfe Agur Nex Abajdi Technical data: - track width: 360mm - shaft width: 350mm - max. disc diameter: 350mm - disc bore diameter: 80mm - max. cutting height: 120mm - table dimensions: 2040x1220mm From above: - pawls - toothed feed shaft - pawls - saw shaft - sliding, pressure shaft From below: - rollers in front of the table, 2 pcs - guide - pawls - track - central track lubrication - electric saw shaft lifting - electric body lifting - stepless feed speed adjustment - dust extraction nozzle diameter: 140mm, 160mm - main motor: 30kW - overall dimensions (L/W/H): 2600x2300x1850mm - weight: approx. 4000kg ADVANTAGES – Czech production – used multi-blade saw – very good condition Net price: 30900 PLN Net price: 7190 EUR, depending on the exchange rate of 4.30 EUR (Prices are subject to change due to significant fluctuations)

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,250 mm, spindle diameter: 130 mm, spindle speed (min.): 10 rpm, spindle speed (max.): 2,500 rpm, table length: 2,200 mm, table width: 1,800 mm, TOS Varnsdorf WHQ 13.8 CNC table type horizontal boring mill, year of construction 2000, made in the Czech Republic. The machine is controlled by an original Heidenhain TNC 430 CNC with the Heidenhain operating panel and runs programs produced with CAM software. The control cabinet air conditioning unit was replaced one year ago. The machine is well maintained and in full working order. Technical data: - Control: Heidenhain TNC 430 - Spindle diameter: 130 mm - Spindle speed: 10 - 2,500 rpm - Tool taper: ISO SK 50 - X travel: 3,500 mm - Y travel (vertical axis): 2,500 mm - Z travel: 1,250 mm Bdjdpfx Ajz Ap Awjbaei - Table size: 2,200 x 1,800 mm - Operator platform with 250 kg load capacity - Air conditioning unit fitted one year ago - Programmable via CAM software The machine can be inspected under power in our workshop.

Condition: used, Year of construction: 1995, TOS W100A horizontal table boring machine Bdsdpfx Abjz Sff Hjaji X spindle is worn Digital read out is partially functional lot of tools included Table Dimensions 1200 x 1200 mm X-Axis Travel (Longitudinal) 1250 mm Y-Axis Travel (Vertical) 1120 mm Z-Axis Travel (Cross) 1600 mm W-Axis (Spindle) 900 mm Spindle Motor 11mkW Spindle Speed 7-1120rpm Spindle Taper ISO 50 Spindle Diamete 100 mm Facing Chuck 600 mm Floor Space 6020 x 3500 x 3000 mm Machine Weight 14.000 kg Price ex VAT Delivery ex works, as is

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, We can provide this machine, connected and ready for testing. A video of the machine can be sent via the WhatsApp application. General overhaul in 2008. Heideihaim positip 855 X 6,400 mm Y 2,200 mm W 1,120 mm Bodezak A Iopfx Abajdi ISO 50 Weight: 32,500 kg Two plates, dimensions 602x2000x400 mm, are included with the machine. A head is also included with the machine.

Condition: used, Year of construction: 1982, functionality: fully functional, total length: 2,575 mm, total width: 1,110 mm, total height: 1,450 mm, type of input current: three-phase, overall weight: 1,550 kg, Accessories: 200 mm chuck, rotating center for the tailstock, micrometer stop for longitudinal feed, chip and coolant emulsion tray including pump, lighting, technical documentation. Basic technical parameters: Swing over bed 400 mm, Swing over carriage 220 mm, Swing in gap 600 mm, Gap width 230 mm, Turning length 1000 mm, Spindle bore 50.5 mm, Spindle taper Morse 6, Tailstock center taper Morse 5, Spindle speeds: Number of steps 12, Range 1st range 45-2000 rpm, 2nd range 22-1000 rpm, Maximum tool section 30 x 20 mm, Max. workpiece weight clamped in centers 300 kg, Main motor power 5.5 kW, Machine dimensions L x W x H: 2575 x 1110 x 1450 mm, Machine weight 1550 kg. The machine can be viewed and fully tested in our warehouse in Přerov by prior arrangement. Bdodpfxsz Tdcfj Abaoi

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 14,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,000 mm, Travel ranges: - X-axis: 14,000 mm - Y-axis: 4,000 mm - Z-axis: 1,000 mm - W-axis travel: 800 mm Equipped with automatic tool changer Model WRD 150 Q - 60 tools Manipulator for horizontal and vertical tool changes Milling head - HUI 50 - automatically positionable, with pick-up station + 1 storage location Band filter system with 2 cooling circuits - internal cooling through the spindle with approximately 20 bar (30 l/min), external cooling with 3 bar (40 l/min) - RAPID 3.1, manufacturer AME EQUIPMENT: Bjdpjzzwhlsfx Abasdi - Chip conveyor for X = 14,000 mm - 3D probe with wireless transmission, manufacturer M & H, wireless handwheel PETEC - 6 clamping plates AND 4, 4020 x 1885 mm

Condition: ready for operation (used), Year of construction: 1982, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, spindle diameter: 130 mm, spindle speed (max.): 1,500 rpm, table length: 1,800 mm, table width: 1,600 mm, feed length W-axis: 600 mm, TOS Varnsdorf WHN 13 A table type horizontal boring mill (borer), year of construction 1982. The machine has been retrofitted with a FANUC CNC control; maximum spindle speed 1,500 rpm. Well maintained and in working condition. Technical data: - Table size: 1,600 x 1,800 mm - X travel: 3,500 mm - Y travel: 2,000 mm - Z travel: 1,000 mm - W travel (boring spindle / quill): 600 mm - Spindle diameter: 130 mm - Max. spindle speed: 1,500 rpm Bsdpfoz An Ufox Abasdi - Control: FANUC (retrofit) Available for inspection in our workshop and ready for immediate delivery.

Condition: ready for operation (used), Year of construction: 1987, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 1,100 mm, spindle diameter: 100 mm, table length: 1,100 mm, table width: 1,000 mm, TOS Varnsdorf WH 10 NC table type horizontal boring mill (borer), year of construction 1987. The machine has been converted to an HSP control and its electrical/electronic system has been overhauled. Well maintained and in working condition. Bsdpfx Aez Apa Nobaedi Technical data: - Table size: 1,100 x 1,000 mm - X travel: 1,200 mm - Y travel: 1,100 mm - Spindle diameter: 100 mm - Control: HSP (retrofit), electrics overhauled Available for inspection in our workshop and ready for immediate delivery.

Condition: good (used), functionality: fully functional, universal grinder BHU 32/1000 Bdode Aaybiopfx Abaji
