Used furnaces for metalworking for sale (239)

Condition: like new (used), Year of construction: 2012, operating hours: 75 h, This Vötsch Hephaistos Industrial Microwave Chamber has had extremely low hours usage during its life so far, on 75 hours .. having been installed and minimally utilized from time to time for a single research project at the University of Sheffield AMRC research department known as the “Factory of the Future”. Sold new for a price of approx 250,000.00Euro. Contact us now for an exceptional offer for this high tech unit in as new condition. VHM Hephaistos Industrial Microwave Chamber For Aerospace and Automotive Engineering The Research Project The VHM Hephaistos Industrial Microwave Chamber for component testing was developed in cooperation with the Karlsruhe Institute of Technology (KIT). It is the result of a joint development project sponsored by the German Federal Ministry of Education and Research (BMBF). Alongside KIT, the Composite Research Center of EADS in Munich, the Institute for Aircraft Design (IFB) at the University of Stuttgart, GNK Aerospace in Munich and Vötsch Industrietechnik were involved in the project. Microwave system The VHM Hephaistos Industrial Microwave Chamber from Vötschtechnik is an internationally patented system. Fast and energy-efficient production processes are possible by using microwaves. The microwave chamber is characterized by its hexagonal geometry with a very high field homogeneity. This is a major advantage when thermoforming fibre composites (CFRPs) in the aerospace and automotive industries. Bdedpfx Ajtvz Rfjguoc During the targeted volumetric heating of the products, the microwaves directly enter the material so that energy is delivered directly and the chamber does not require heating. This increases the heating rate and throughput, saving energy and time in addition. Reduced production costs This industrial microwave chamber guarantees you reduced costs due to shorter heating, process and cooling times required for curing CFRP components. Its material processing technology means the microwave can produce energy input into the component to be heated while the oven itself remains cold. In comparison to the process in autoclaves, the processing times are reduced by up to 50 %. Energy consumptions is reduced by up to 70%. Advantages: Possibility to use metal parts, such as conventional metal tools and feed systems, in the microwave field High degree of product quality thanks to the maximum homogeneity of the microwave fields provided by the hexagonal chamber structure. By using microwave absorbing materials, additional positive effects can be achieved Sizes from laboratory scale to large systems, e.g. as are required in the aerospace industry, can be achieved The modular design allows a flexible adjustment to your product Volumetric and selective heating for energy-efficient processes Precise heating of the products Hybrid systems, e.g. in combination with hot air

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: 830397, functionality: fully functional, power: 85 kW (115.57 HP), temperature: 1,000 °C, inner dimension length: 1,600 mm, inner dimension width: 700 mm, inner dimension height: 950 mm, The item is offered as a "Premium Listing" – the sale is qualified and curated by Maschinensucher. Used in a large German corporation, adhering to applicable guidelines and maintenance recommendations. ACQUISITION COSTS Original purchase price in 2008: €490,000 plus VAT Retrofit in 2022: €254,000 plus VAT TECHNICAL DETAILS Dimensions of the heat treatment unit Housing width, including control cabinet: 3,600 mm Overall length with attachments: 7,000 mm Height above furnace floor: 4,900 mm Loading height above furnace floor: 1,200 mm Pit depth: 630 mm Internal height of the furnace chamber: 950 mm Internal depth of the furnace chamber: 1,600 mm Internal width of the furnace chamber: 700 mm Temperatures Rated furnace temperature: 1,000 °C Operating furnace temperature: 850 °C Oil bath temperature: 60 °C Dimensions of the furnace control cabinet Width: 2,000 mm Depth: 600 mm Height with 100 mm base: 2,100 mm Weights and Volumes Weight of multi-purpose chamber furnace: 22,000 kg Oil bath volume: 7.5 m³ Weight of switchgear: 600 kg Total weight of furnace with oil and charge: 30,000 kg Energy Data Total connected load: 85 kVA Supply voltage: 400 V Supply frequency: 50 Hz Number of phases: 3 Oil bath heating: 2 x 21.6 kW Motor power, heating chamber circulation fan: 5.5 kW Motor power, pre-chamber circulation fan: 2.2 kW Motor power, oil bath air cooler: 3.0 kW Motor power, lifting table: 11 kW Motor power, loading machine: max. 38 kW Current draw, pre-chamber door: max. 17.2 A Bdsdpjy Uxt Esfx Agusc Current draw, heating chamber door: max. 13.2 A Motor power, combustion air fan: 1.5 kW Motor power, oil bath pump for oil bath: 2.2 kW Motor power, cooling air blower: 0.75 kW Motor power, oil bath circulation fan: 2 x max. 11 kW Motor power, oil bath pump for cooling plates: 1.1 kW Motor power, batch oil circulation pump: 3 kW Batch dimensions with base grate Height: 950 mm Width: 700 mm Length: 1,600 mm Weight: 1,000 kg Note: The dismantling and loading of the furnace must be organized by the buyer.

Condition: excellent (used), Max. operating temperature: 300°C Internal dimensions (W x H x D): 400 x 380 x 370 mm Internal volume: 57 liters Power consumption: 1.4 kW Bdjdoy Uwr Hopfx Aguoc Electrical connection: 230 V Footprint: 750 x 610 x 550 mm Approximate weight: 50 kg

Condition: excellent (used), Rated temperature: 1100°C Usable chamber dimensions (W x D x H): 200 x 300 x 150 mm Electrical connection: 230 V, 1.4 kW Heating-up time: 100 min. Bdjdsy Uwqvopfx Aguoc Footprint: 752 x 576 x 700 mm Weight: 78 kg

Condition: used, Technical details: temperature max.: 800-900 ° muffle size (length): 700 muffle size (width): 300 Bdodpew Rkuljfx Agusc muffle size (depth): 300 mm total power requirement: 90 kW weight of the machine ca.: 0,13 t Small chamber forging furnace. In 2017, the refractory bricks inside were renewed for €5,000. *

Year of construction: 1981, condition: used, Technical details: height over floor: 850 mm total power requirement: 2,5 kw temperature: 200 °C voltage: 220/50 V / Hz weight of the machine approx.: 80 kg space requirement of the machine approx.: L:0,85xB:0,6xH:1,15 m Application area: drying device internal dimensions: W: 0,50 x T:0,42 x H:0,60m Bsdpfsu N Agkox Aguedc door opening : W:500 x H:600mm The internal room does have 3 shelves ( depth 370 x W: 490mm) upper shelf inlet has been taken out, because the thermometer gets deep into the room ( see picture / comparable) Oven has been tested up to 160°, with limitation on sale, 2 heating rods up are OK and 2 heating rods down are not working! *

Condition: excellent (used), Year of construction: 1995, Year of manufacture 1995, vacuum hardening furnace, model BMI B83T. Bsdpfxezarvpj Agusdc

Condition: used, Year of construction: 2015, 1 unit hardening furnace, RHODE ME65/13 Maximum operating temperature: 1300°C, power: 20kW, current: 29A Color: as shown in the pictures, in accordance with the images and inspection Year of manufacture: 2015 Bedpfxsy Tkcis Agujdc Condition: used

Year of construction: 1992, condition: good (used), degree 220 total power requirement 50 kW weight of the machine ca. 1500 kg Bedpsx Ti Dxjfx Agujdc dimensions of the machine ca. 2600 x 1600 x 1600 mm

Year of construction: 2010, condition: excellent (used), Chamber inside 2000 x 1250 x 1250 mm Volume inside 2344 Liter Up to 400 Gr/C (Power 33kW)   Preheating / Drying For manual, cycle and CNC processing up to interactive contour programmingCovered guidance tracks (DGP) for high long-term precisionDirect drive from motor to main spindle for high running smoothnessOil recirculating lubrication unit with filtering for the lubrication of the precision main spindle bearingCombination control unit for economically advantageous programming and machine operation, as well as optimum access to the work area Length:2500mm Width:2015mm Bdsdpsuqkwfjfx Aguoc Height:2900mm Weight:4000kg

Condition: excellent (used), Year of construction: 2020, machine/vehicle number: SN376848, functionality: fully functional, 12 months warranty, available for immediate delivery Electrically heated recirculating air chamber furnace Nabertherm NA 500/45 - T max 450 °C - Internal dimensions W x D x H 750 x 1000 x 750 mm - External dimensions W x D x H 1400 x 1910 x 1810 mm - Volume 500 liters - Nabertherm controller P470 (50 programs, each with 40 segments) - Feedthrough, e.g., for thermocouples - Alarm and control indicator light - Pneumatic lift-up door - Additional insert shelf - Loading weight 500 kg - 125 kg max. per level - Power 18 kW - Weight 800 kg - Documentation, CE declaration - Electrically tested and supplied with a current DGUV test report Bedpfx Asya D Aujgusdc This series can be operated with a fumigation box (not included). Internal dimensions 630 x 780 x 610 mm. A slot must be cut into the furnace door for this. Inspection in our warehouse is possible at any time! All devices are electrically tested and supplied with a warranty. Furnace, Industrial furnace, Burn-in oven, Heat treatment oven, Laboratory furnace, Drying oven, Tempering furnace, Chamber furnace, Annealing furnace.

Condition: used, Year of construction: 2008, power: 27 kW (36.71 HP), input voltage: 400 V, input current: 44 A, temperature: 200 °C, inner dimension length: 1,100 mm, inner dimension width: 1,600 mm, inner dimension height: 1,500 mm, overall weight: 3,500 kg, number of chambers: 1, Equipment: CE marking, documentation/manual, Chamber oven Vötsch for components containing solvents Usable dimensions: 1600 x 1100 x 1500 mm (width x depth x height) Rated temperature: 200 °C Maximum temperature: 250 °C Maximum permissible solvent quantity according to EN 1539 at rated temperature: 38 g Connected load: 30 kVA Rated power: 27 kW Usable volume: 2.78 m³ Steam space: 4.5 m³ Bdedpoy U Uzxofx Aguoc

Condition: excellent (used), functionality: fully functional, El. heated salt bath continuous furnace system, make Kohnle consisting of Magnetic feeder Hardening furnace Type: BLH 950-650/100-5000 Temperature: max. 950°C Throughput: 200 kg/h Conveyer belt width: 620 mm Effective height: 90 mm Connected load: 160 kW Heated length: 5.000 mm Bsdpfxey Uuwmj Agujdc Temperature control zones: 5 Throughput speed: 170 - 20 mm/min. Time in the heating zone: 30 - 240 minutes Gases used: nitrogen, methanol, natural gas, ammonia, propane Salt bath Salt: AS200 Washing system

Condition: excellent (used), El. heated salt bath continuous furnace system, make Kohnle consisting of Bedsy Uuu Eopfx Aguodc Magnetic feeder Hardening furnace Type: BLH 950-650/100-5000 Temperature: max. 950°C Throughput: 200 kg/h Conveyer belt width: 620 mm Effective height: 90 mm Connected load: 160 kW Heated length: 5.000 mm Temperature control zones: 5 Throughput speed: 170 - 20 mm/min. Time in the heating zone: 30 - 240 minutes Gases used: nitrogen, methanol, natural gas, ammonia, propane Salt bath Salt: AS200 Washing system

Condition: excellent (used), Year of construction: 2012, machine/vehicle number: 9349-0010, functionality: fully functional, Used: rotary hearth furnace / mandrel hardening press Manufacturer: Aichelin Model: Drehherdofen Aichelin RDGs 270 Control: Siemens S7-300/317-2 PN/DP Year of manufacture: 2012 Bjdsw Rrxfjpfx Aguedc Max. temperature: 950 °C GAS

Condition: excellent (used), El. heated continuous furnace system, make Safed consisting of: Bdedoy Ur Aaopfx Agujc Magnetic feeder Hardening furnace Type: T 80/54 Ti Throughput: 540 kg/h Temperature: max. 950°C Conveyor belt: effective width 600 mm Effective height: 100 mm Heating power: 229 kW Heating length: 7.200 mm Temperature control zones: 9 Processing time: 15 - 150 minutes Gases used: nitrogen, methanol, ammonia, propane Oil quenching bath Liquid capacity: 4000 l Bath temperature: max. 80°C Washing system Annealing furnace

Condition: reconditioned (used), Year of construction: 2009, machine/vehicle number: SN FX036084, functionality: fully functional, 12 months warranty, in stock, immediately available, in TOP condition. Resistance-heated system with a gas-tight furnace chamber. -Tmax 800°C -Max. temperature approx. 900°C (under protective gas) -Rod program controller SE-402 -3-zone heating -Gas supply system: 2 different protective gases, as well as fuel gases -Gas circulation -Vacuum system -No safety package installed! -Internal chamber dimensions WxDxH 580x830x1500 mm (special length) -Chamber volume approx. 722 liters -Max. load weight approx. 1000 kg -Two-stage rapid cooling with frequency converter -Flare device with flame monitoring -Automatic shutdown / emergency purge in case of flame failure, not in case of power failure! -Sight glass DN150 -Max. gas operating pressure 7 mbar -Power supply 400V, 3 phases, N, PE -Heating power 70 kVA -Rated current 3x97A Bsdpeyxlwrjfx Aguedc -Weight 1900 kg -External furnace dimensions WxHxD 1700x1950x2750 mm -Control cabinet dimensions WxDxH 510x1360x500 mm -Operating manual, circuit diagrams, CE declaration The furnace is offered as refurbished. Electrically tested, including test reports. Inspection in our warehouse by appointment! Not suitable for gas nitriding with NH2/ammonia! Furnace, furnaces, industrial furnace, melting furnace, annealing furnace, heat treatment furnace, sintering furnace, protective gas furnace, annealing furnace, tempering furnace, hardening furnace, chamber furnace, brazing furnace, debinding furnace, dewaxing furnace, stress-relieving furnace.

Condition: used, Year of construction: 2012, Make: ROSENBERGER, Model: RB20-LR, Year of manufacture: 2012, Serial no.: M1057, 2 CNC bending heads, Bending capacity Ø 30 x 2 mm (steel), Bending planes selectable within a total tool height of 138 mm, Travel range X/Y/Z 1,416 x 260 x 1,170 mm, Collet head with feed slide, PLC control Siemens S7-300, Touch display, Loading magazine, 2 robots, make: Motoman, Robot control unit, make: Yasnac, Model: K10, Teach-in terminal MRC, Spray cleaning system, Chamber size 500 x 300 x 1,000 mm, PLC control with operator panel, make: Siemens, Model: SIMATIC Panel, Thermostat, 3 washing chambers, Tube cutting station, make: FZH, year: 2012, serial no.: M99964, Control system, Display make: Siemens, Model: SIMATIC Panel touch. Bdjdpfoyx Erijx Aguoc

Condition: used, Year of construction: 2010, Manufacturer: ROSENBERGER, Model: RB 20-2 Twister, Year of manufacture: 2010, Serial no. A89, tube diameter 12 mm and tube length 1,700 mm, mainly consisting of: 2 CNC bending heads, bending capacity Ø 20 x 2.0 mm (steel), bending planes freely selectable within 78 mm total tool height, robot, make KUKA, type KR16-2, serial no. 10009498, robot controller KRC2, teach-in terminal, 2x indexing conveyor belts, robot by Motoman, Teach-In Terminal K6, controller by Yasnac, type MRC, safety fence system, electrical/control cabinets, peripheral units, accessories. Bedpfx Agsyx Ewreuedc

Year of construction: 2006, condition: good (used), Kiln Superturbo, Pulsar model, 180 mc, intermittent type with a firing temperature till 1150°C, and a maximum temperature of 1200°C, equipped with 24 high-speed burners, n° 1 wagon inside the chamber, n° 1 vertical door, reverse induction chimneys, cowl for the expulsion of the smokes, automatic control panel with ATR 313, lining in ceramic fibre, high density, 1260°C type; 4 Heat exchangers for hot combustion air. Thermal Power 3,2 MW Dimensions 7x7x4 meters, capacity of wagoon 80 tons. Bdsdehgkdqepfx Aguoc

Condition: ready for operation (used), Manufacturer: Beck -external sizes: 1700x1010x1400mm -Permeable cross section: 540x240mm -The temperature range: 0-400 °C Bjdpfxou Nuyis Aguodc

Condition: good (used), Year of construction: 2011, Heated surfacefinishing machine for Zink-magnesium coating Bodpfxsfndpne Aguedc Tank capacity : 150 l Heating power: 20 kW Weight: 1230 kg

Condition: like new (used), Chanber size: 280x180x500mm upper 280x130x450mm lower Bdsdpfx Aged Sm Diouoc Max temperature: 700 C °

Condition: used, Vötsch Type: NTUD 125/130/125 Pass-through oven Last maintenance: 3.12.25 Temperature control in 3 zones: Control of the internal temperature via an electronic temperature control system, divided into 3 separate temperature zones and controlled by semiconductor switching devices. This ensures good temperature uniformity whether operating in fresh or recirculated air mode. Temperature program control: The CTC control system is operated via a dialog PC with TSI software for the heating control of each temperature zone, as well as the activation of the recirculation fans and damper control. Horizontal airflow with reversal: By switching the electronically or pneumatically actuated dampers, the airflow direction can be set from left to right or right to left. The airflow direction for each of the 3 zones can be independently adjusted. Vertical airflow: By shifting a cover plate in the oven ceiling. Useful floor area: Bjdpfx Ajy H Akrsguedc The floor area can be driven on using customer-provided loading trolleys. Recirculation fans: Each zone is equipped with a radial fan. Usable space dimensions: 1300 mm height / 1250 mm width / 1250 mm depth External dimensions: 2490 mm height / 1770 mm width / 1810 mm depth Volume: 2000 liters Connection rating: 400V(N)PE AC 50/60 Hz 22 kVA Rated current: 32 A Power: 18 kW Nominal temperature: 50 to 150°C Weight: 1000 kg Condition: used Scope of delivery: (See photo) (Specifications and data subject to change and errors excepted!) We are happy to answer any further questions by phone.

Condition: good (used), HEESS Hardening Press with IPSEN Rotary Hearth Furnace. Technical Key Data (Furnace): Process: Carbonitriding Workpieces: Gear components, up to Ø 260 mm, 4.7 kg Throughput: approx. 96 parts/hour Dwell time: approx. 56 min Temperature range: 820–960 °C Max. temperature: 1000 °C Bedpfx Agey Dd Adeusdc Uniformity: ±5 K Atmosphere: Endogas with propane/ammonia C-potential: approx. 0.9 %C Furnace: Ø 3000 mm, usable height 750 mm Energy: electric: 33 kVA natural gas: approx. 19 m³/h HEESS Hardening Press: Pressing force: 300 kN Workpieces: Ø 60–250 mm, height 10–98 mm Cycle/process parameters: Pressing time: 0.1–10 min Pre-cooling time: 0–100 s Quenching medium: up to 300 l/min Handling: Manipulator + gantry robot (Siemens servo drives)
