Used Anayak for sale (33)

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 1,500 mm, controller model: Heidenhain 530, Equipment: chip conveyor, TECHNICAL DETAILS X-axis travel: 3,000 mm Y-axis travel: 1,270 mm Z-axis travel: 1,500 mm Spindle speed: up to 4,000 rpm Tool holder: SK50 Cslhcsymcu Ascqnsgp MACHINE DETAILS Control: Heidenhain 530 Internal cooling: 22 bar EQUIPMENT Diagonal milling head with 2.5 x 2.5 indexing Longitudinal chip conveyor

Condition: used, CNC Gantry-Type Boring and Milling Machine ANAYAK Type HVM-3800-P Bed type milling machine, structure similar to a plate-type boring mill with fixed table Machine No.: M-20021203 Year of manufacture: 2002 ("Refurbished 2025") The machine will be completely workshop overhauled in 2025 and can then be inspected in storage at 37235 Hessisch Lichtenau. Travel distances: X: 3,200 mm, Y: 1,200 mm, Z: 1,500 mm Table size: 3,800 x 1,200 mm T-slots: 8 pieces, 22 mm, spacing 130 mm Table load: max. 25 tons (stationary table – virtually unlimited load capacity) Spindle taper: ISO 50 (DIN69871-A) (drawbar: DIN 69872-B) Spindle speed: 60 – 4,000 rpm, stepless Feed rate: up to 10,000 mm/min, stepless Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Electrical connection: 400 Volt, 50 Hz, 50 kVA - Automatic tool changer for 30 tools - Spindle drive with 2 speed ranges - With automatic tool changer and tool magazine - Orthogonal milling head with hydro-mechanical tool clamping - Orthogonal milling head fully automatic swiveling in two 45° planes – B+C axis - HEIDENHAIN iTNC 530 control, with electronic handwheel - Prepared for wireless touch probe (probe and receiver not included) - Additional HF-spindle, 18,000 rpm – for attachment - Free-standing control cabinet - Chip conveyor positioned between the gantry bed and the machine table - 32,078 operating hours recorded - Coolant system - Free-standing hydraulic unit - Operating manual with circuit diagrams Installation area (L x W): approx. 1,000 x 700 cm Cjlhccsxcgtgeqnegp Installation height: approx. 410 cm Weight (total): approx. 33 tons Good condition

Condition: good (used), Year of construction: 2002, Ref. -No.: 10633 Manufacturer: ANAYAK Type: VH Plus 2000-MG Year of construction: 2002 Type of control: CNC Control: Heidenhain Storage location: Halberstadt Country of origin: Germany serial number: M200XXX X-Travel: 2000 mm Y-Travel: 1500 mm Cgslhjyn Emdjccqnsp Z-Travel: 1500 mm No. Of Working Stations: 90 Control: 106.253 H machine: 93.170 H Program run: 41.859 H Kopf- und Drehtisch: 1600 x 1450 mm

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, CNC controller: HEIDENHAIN iTNC530 Axes X-axis travel mm: 3.000 Y-axis travel mm: 1.700 Z-axis travel mm: 1.500 Feed rates m/min: 10 Rapid traverse m/min: X, Y: 20; Z: 10 Worktable Table dimensions mm: 3.200x1.200 Maximum weight on table kg: 8.000 T-Slots: 7xT22 - 150 mm Spindle Celsrw Arzjhccqnogp Spindle speed rpm: 30 - 5.000 Spindle drive power kW: 28/38 Gear box steps: 2 Cooling Cooling through the Spindle Center bar: 22 Tool system Tool holder: ISO-50 DIN 69871A Equipment Electronic Handwheel Chip conveyor 4th axis ready

Year of construction: 2001, condition: like new (used), Retrofitted: 2024 Cgslougbrqohccqnep Numerical control: HEIDENHAIN TNC426 Technical features Dimensions Table dimensions: 6000 x 1000 mmNumber of T slots: 7T slots dimensions: 22 mm Traverses of axis Longitudinal traverse X: 5040 mmVertical traverse Y: 1000 mmTransversal traverse Z: 1500 mm Milling head Head type: Fixed frontalTool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871)   /   Pull stud: DIN 69872-BSpeed range: 60 - 3000 rpmSpindle power: 22/30 kW Feedrates Feedrate: 5000 mm/minRapid feedrate (X / Y,Z): 10000 mm/min Weight and dimensions Maximum weight on table: No restrictionsMachine weight approx.: 43000 kgMachine dimensions approx.: 11560 x 6150 x 3538 mm Accesories Guarding (Option: pendular guarding)Automatic tool changer: AH40Chip conveyor: 2 longitudinalElectronic handwheel: HR-410External coolant Sales conditions Warranty: 6 months mechanical partsSale price (Ex Work): On request View all technical features

Condition: ready for operation (used), Year of construction: 2007, operating hours: 14,900 h, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: HEIDENHAIN, controller model: TNC530, table load: 6,000 kg, number of axes: 3, This 3-axis ANAYAK Performer 2500 was manufactured in 2007. It features a Heidenhain TNC530 control unit, a versatile EMENA-VAR-3 milling head, and a robust table size of 2700 x 850 mm. Capable of handling a table load up to 6 tons, with traverse paths of 2500 mm in X, 1000 mm in Y, and 1100 mm in Z. If you are looking to get high-quality milling capabilities consider the ANAYAK Performer 2500 machine we have for sale. Contact us for more information. Machine Benefits Technical Machine Benefits Cjlhccqjx D Id Nonogp • Table size: 2700 x 850 mm Extra Information Machine still under power

Condition: used, Year of construction: 1997, x-travel 2550 mm y-travel 900 mm z-travel 1200 mm Control Heidenhain type 355 table surface area 2900x800 mm Center of spindle to wall or column 1000 mm spindle taper ISO 50 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Cjlhccqoyqumxenjgp About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1994, functionality: limited functionality, travel distance X-axis: 1,600 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 900 mm, table width: 700 mm, table length: 1,800 mm, Anayak VH 1800 bed milling machine Heidenhain TNC 415 B control Tool holder SK 50 Machine runs, further condition unknown Machine is still connected to power Colhsypxtajccqnjgp Overhead crane available for loading

Condition: used, X axis (longitudinal) 800 mm Y axis (transversal) 400 mm Z axis (vertical) 300 mm Table length 1340 mm Table width 300 mm Max. spindle speed 2500 rpm Spindle motor power 3 kW Dimensions (L x W x H) 1800.0 × 2000.0 × 2080.0 mm Cgsljw Tyyijhccqnop Weight 2050 kg

Condition: excellent (used), Year of construction: 2001, overall weight: 10,000 kg, total length: 5,000 mm, total width: 900 mm, total height: 900 mm, Cast iron box table Weight 10 Ton Colhceyg Hpwocqnegp 2 matching pieces availebel Nice surface Number of T slots: 7 Jump from T to T: 130mm T size: 22mm Number of T-slotted sides:1 Length: 5000mm Width: 900mm Height: 900mm Weight: 10000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2008, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, spindle speed (min.): 6,000 rpm, table width: 1,100 mm, table length: 4,200 mm, rotational speed (max.): 6,000 rpm, Heidenhain iTNC 530 control Tool changer for 60 tools Automatic universal head, 0.02 degree in both axes Cgslhccqew Ngd Tjnsp Machine will be refurbished in 2025

Year of construction: 2018, condition: excellent (used), Spindle ISO 50 (DIN-69871-B) Pull studs DIN-69872-B Clamping force 1900 daN Automatic B Axis 1.0 Degrees Automatic C Axis 2.5 Degrees Power 60/100 % 22/30 kW Coleyf Dp Eshccqnogp Speeds 60 - 3000 2 Speed Range Automatic lubrication (Air-Oil) Gear; ZykloPalloid, Klingelnberg-System, HPG-5 Qulaity-6 with DIN3965 Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1996, total height: 3,200 mm, total width: 3,200 mm, total length: 8,000 mm, Empty weight: 26.000 kg Price: On request Bed Milling machine Bed Miller Model: CNC Manufacturer: Anayak Type: FBZ-HV-4000 CNC: Heidenhain Year: 1996 Bed-dimensions: 4500x800mm X-travel: 4000mm Y-travel: 935mm Z-travel: 1000mm Rotatable Fräsekopf Spindle-speed: 3000rpm Spindle-take: ISO 50 Incl. peripherals and documents Dismantled for transport Video available! Machine-dimensions: 8000x3200x3000mm Machine-weight: 26000kg - Year: 1996 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 11676-FBZ - Number of axes: 3 - Travel X [mm]: 4000 - Travel Y [mm]: 935 - Travel Z [mm]: 1000 - Spindle speed max. [rpm]: 3000 - Tool holder: ISO50 Cgslhcownhnfecqnsp - Table size length [mm]: 4500 - Table size width [mm]: 800 - Control type: Heidenhain - Control: CNC - Transport dimensions: 8000mm x 3200mm x 3200mm (l x w x h) - Transport weight [kg]: 26000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Bram van Summeren

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,100 mm, Rotary table 1,250 x 1,400 mm (interference circle 1,700 mm) Heidenhain 530 Diagonal milling head with 1° x 1° indexing Speed up to 5,000 rpm Tool holder SK50 Tool changer with 40 positions Internal coolant supply with 19 bar Chip conveyor in longitudinal direction Colox Iuccshccqnjgp

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, Heidenhain 530 Diagonal milling head with 2.5° x 2.5° indexing Spindle speed up to 6,000 rpm Tool holder SK50 Internal cooling with 36 bar Cgjlhox I A Hvoccqnop Longitudinal chip conveyor + cross conveyor

Condition: used, Year of construction: 2001, x-travel 2000 mm y-travel 920 mm z-travel 900 mm table surface area 2200 x 750 mm table load 3 t number of T-slots 6 T - slots - width 18 mm T - slots distance 120 mm spindle taper ISO 50 DIN 69871-B spindle speed max. 3000 U/min transmission ratio 1 speeds infinitely variable range 1 60 - 3000 U/min weight of the machine ca. 21,6 t Cgelhsg E Utxjccqnsp feeds longditudinal/cross/vertical 0 - 5000 mm/min rapid traverse 15000 mm/min total power requirement 38 kw weight of the machine ca. 11 t Pull studs DIN69872-B | IKZ Hours: Control on: 43036 h Machine on: 41311 h Program run 13894 h The machine is already dismantled

Condition: used, Year of construction: 1999, Technical details: x-travel: 2000 mm y-travel: 1500 mm z-travel: 1460 mm milling spindle motor: 35/30 kW spindle taper ISO: 50 spindle turning speed range: 24 - 3000 U/min table surface area: 1350 x 1550 mm table load: 6 t feed speeds: 10 - 3000 mm/min rapid speed: 10 m/min total power requirement: 48 kW weight of the machine ca.: 24 t CNC HEIDENHAIN TNC 426 B-axis table round Cgjlhccqev Rdzbenop Horiz. and Vertikal automatic positioning Milling Head *

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 3000 x 1300 x 2000mm, Table 2000 x 1600mm, table load 13,000 kgs, B axis 360 degrees, Celovz A Rishccqnegp Heidenhain iTNC530, ISO SK50 spindle taper, 5,000rpm Spindle Speed, 60 station toolchanger, coolant, Interlocked guards.

Condition: used, Year of construction: 1999, functionality: unexamined, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,050 mm, rapid traverse X-axis: 20,000 m/min, rapid traverse Y-axis: 20,000 m/min, rapid traverse Z-axis: 20,000 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 60 rpm, table width: 1,100 mm, table load: 8,000 kg, table length: 2,300 mm, Bed-type milling machine Anayak VHPlus 2000 Celhjx Ndcueccqnegp Travel paths: X: 2,000 mm Y: 1,200 mm Z: 1,050 mm Diagonal milling head 45° Spindle: SK50 Power: 30/35 kW Spindle speed: 4,000 rpm Coolant system Tool changer: 30 positions, chain magazine Control: Heidenhain TNC426 Handwheel Documentation and export available at extra cost. Machine inspection under power possible. We are happy to send you further details or arrange an on-site viewing.

Condition: ready for operation (used), Year of construction: 2001, General Data Machine weight 5500 kg Measurements height 2634 mm Control Unit Brand FANUC Model 18-M Main Drive Spindle Speed 10000 RPM Spindle motor power 9 kW Tool taper BT 40 Number of axis 4 Movement X-Axis Movement 800 mm Z-Axis Movement 505 mm Y-Axis Movement 500 mm Tools Max weight 6 kg Dimensions Machine Length 2530 mm Table Table load 500 kg This 4-axis ANAYAK 8-HS was manufactured in 2001. It features a Fanuc 18-M CNC, with travels of 800 x 500 x 505 mm, and a table that can support up to 500 kg. The spindle operates at 10,000 rpm with a BT 40 taper and has a power of 9 kW. It includes a 24-position tool changer and additional equipment like a 4th axis, spindle cooler, and chip conveyor. Consider the opportunity to buy this ANAYAK 8-HS vertical machining center. Contact us for more information. Application Types Milling Csljx E Ed Sjhccqnsgp

Condition: good (used), Year of construction: 2001, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,460 mm, table length: 3,800 mm, table width: 1,000 mm, table load: 30,000 kg, Chip conveyor Double doors front side Chain Tool chnager 30 positions Central lubrication IKZ 16 Bar and 2,2 kW Flow 16L/Min Tool blocking power 1968 daN Full set books and 1e owner machine X-Axis: 3200mm Y-Axis: 1200mm Z-Axis: 1460mm Table Length: 3800mm Table Width: 1000mm Table load: 30000 Power on spindle: 41kW Spindle speeds: 3000Rpm Spindle Taper: 50ISO/Bt/Mk Celhcjxc Hh Dscqnjgp Feed rate X-Axis: 10000mm/min. Feed rate Y-Axis: 10000mm/min. Feed rate Z-Axis: 10000mm/min. Millinghead auto-index:2.5 x 2.5° Working hours: 10659H Length: 8820mm Width: 6250mm Height: 3910mm Weight: 33000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: M-970504, travel distance X-axis: 2,500 mm, travel distance Y-axis: 935 mm, travel distance Z-axis: 900 mm, spindle speed (max.): 3,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS CNC control: Heidenhain (2x control units) Travel X: 2,500 mm Travel Y: 935 mm Travel Z: 900 mm Machine Table Table size: 2,900 × 800 mm Cgslhjwpiuvjccqnsp Rotary table size: 800 × 800 mm Spindle Spindle speed: 3,000 rpm Tool holder: ISO 50 Tool magazine: 30 slots Milling head: pivotable Machine dimensions and weight Machine dimensions (L × W × H): 6,500 × 3,200 × 3,500 mm Machine weight: 18,500 kg EQUIPMENT - Dual CNC control with Heidenhain control systems - Large bed table with separate 800 × 800 mm rotary table - Swivel milling head for flexible machining - Spindle with 3,000 rpm and ISO 50 tool holder - Automatic tool magazine for 30 tools - Includes all peripheral devices and documentation - Machine is already dismantled for transport

Condition: good (used), total length: 6,000 mm, total width: 1,650 mm, plate height: 300 mm, Manufacturer: STOLLE Type: CAST IRON... Year of construction: 2004 Specifications Metric US Standard Length 6000 mm Width 1650 mm Height 300 mm Number of T-slots 6 Distance between T-slots / spacing Cslhjwpva Eoccqnsgp 250 mm T-slot size 27 mm Weight per plate approx. 7200 ton Number of matching pieces 4 Dimensions (estimated) Length 6000 mm Width 1650 mm Height 300 mm Weight 7200 kg Please note: The information on this page has been obtained to the best of our knowledge and, where possible, from the manufacturer. The information is provided in good faith, but the accuracy cannot be guaranteed. Accordingly, you will not be given any representation or contract terms. We recommend that you verify all important details.

Condition: like new (used), Year of construction: 2000, operating hours: 25,000 h, functionality: fully functional, travel distance X-axis: 10,300 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,800 mm, position of the milling head: 2.5 x 2.5 °, mount diameter: 50 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 60 rpm, total width: 50,000 mm, total height: 48,750 mm, total length: 212,400 mm, table length: 12,000 mm, table width: 1,650 mm, power: 0.03 kW (0.04 HP), overall weight: 50,000 kg, X-axis: 10300mm Y-axis: 2000mm Z-Axis: 1800mm Table Length: 12000mm Table Width: 1650mm Table load: 50000 Power on spindle: 22/30kW Spindle speeds: 60-3000Rpm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis: 10000mm/min. Feed rate Y-Axis: 10000mm/min. Feed rate Z-Axis: 10000mm/min. Millinghead auto-index:2.5 x 2.5° Working hours: 25000H Cjlhccerx Rtroqnsgp Length: 21240mm Width: 5000mm Height: 4875mm Weight: 50000kg

Condition: like new (used), Year of construction: 2000, operating hours: 25,000 h, travel distance X-axis: 10,300 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,800 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, position of the milling head: 2.5 x 2.5 °, spindle speed (max.): 3,000 rpm, spindle speed (min.): 60 rpm, table width: 3,300 mm, table length: 12,000 mm, mount diameter: 50 mm, total height: 48,750 mm, total width: 100,000 mm, total length: 212,000 mm, overall weight: 100,000 kg, Duplex milling are two machines located one opposite the other which can work seperately or as single machine, workpiece can be machined with 2 simultaneous spindles. Production increase of up to 50% in relation to conventional solutions, i.e. individual milling machines Improvements in part precision, by managing to do the machining of the part in one single setup, in most of the cases Cgsljrx Rxtohccqnsp One sole operator can control the DUPLEX milling machines Reduced space and investment requirement comparing with two single machines Fast investment amortization due to the high productivity Duplex solution admits different configurations: single working area, pendulum working areas For machining excavator arms / boom like, CAT, Caterpillar, Komatsu, Hitachi, Hyundai, Doosan, Case, Bobcat, JCB, Kobelco, Liebherr, Kubota, Takeuchi, Volvo X-Axis: 10300mm Y-Axis: 2000mm Z-Axis: 1800mm Table Length: 12000mm Table Width: 3300mm Table load: 100000 Power on spindle: 22/30kW Spindle speeds: 60 - 3000Rpm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis: 10000mm/min. Feed rate Y-Axis: 10000mm/min. Feed rate Z-Axis: 10000mm/min. Millinghead auto-index:2.5 x 2.5° Working hours: 25000H Length: 21200mm Width: 10000mm Height: 4875mm Weight: 100000kg
