Used diecasting machines for sale (23)

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, clearance between the columns: 640 mm, closing stroke: 640 mm, total height: 2,500 mm, total width: 2,400 mm, stroke length: 480 mm, total length: 7,500 mm, column diameter: 120 mm, ejector force: 240,000 N, ejector stroke: 145 mm, mold height (min.): 250 mm, type of input current: three-phase, input voltage: 400 V, overall weight: 16,600 kg, clamping force: 4,600 kN, power: 31.5 kW (42.83 HP), workpiece weight (max.): 8 kg, pressure: 160 bar, Equipment: documentation/manual, BÜHLER GDM H-400B Version 6.0 – 460T Complete die casting cell for aluminum with automatic mold spraying and automatic pouring ladle Manufacturer BÜHLER Model GDM H-400B Version 6.0 Year of manufacture 1996 Condition The machine is complete, in good working order, and has been regularly operated. It can be inspected while running after prior arrangement of a viewing date. Description We offer for sale a complete aluminum die casting cell based on the renowned BÜHLER GDM H-400B Version 6.0 injection molding machine with a clamping force of 460 tons. BÜHLER has been recognized for many years as one of the most reputable manufacturers of die casting machines in the world. The GDM H-400B model is a proven design, known for its high durability, precision, and low operating costs. The machine offered is sold as a complete production cell including an injection molding machine, an automatic mold spraying system, and an automatic pouring ladle. This configuration allows for efficient and repeatable production of aluminum castings. The offer includes: Die casting machine BÜHLER GDM H-400B Version 6.0 Year of manufacture: 1996 Clamping force: 4600 kN (460 tons) DATACESS control Complete control cabinet Technical documentation Automatic mold spraying system ACHESON Dog1000FCT.1S-A Year of manufacture: 2000 Automatic lubrication and mold cooling Rjdjzg E Rfopfx Ah Decf Power supply: 3 × 400 V Control: 24 V DC The system ensures uniform application of the release agent, improves the surface quality of the castings, and reduces the production cycle time. Automatic pouring ladle Equipped with: Siemens SIMATIC HMI Touch control The unit automatically picks up molten metal from the furnace and dispenses the appropriate amount of aluminum into the injection chamber, ensuring high process repeatability and reducing material losses. Technical data of the injection molding machine Clamping unit Clamping force: 4600 kN Second-stage clamping force: 180–420 kN Moving platen stroke: 640 mm Ejector force: 240 kN Ejector stroke: 145 mm Mounting plates Fixed platen: 990 × 1165 mm Moving platen: 990 × 990 mm Distance between columns: 640 × 640 mm Column diameter: 120 mm Molds Minimum mold height: 250 mm Maximum mold height: 780 mm Injection unit Piston stroke: 480 mm Effective piston stroke: 455 mm Available piston diameters: 60–110 mm Maximum aluminum casting weight: up to 8.5 kg Maximum injection pressure: up to 1485 bar Hydraulic system Maximum working pressure: 160 bar Oil tank capacity: 850 liters Electrical parameters Connected power: 31.5 kW Protection class: IP55 Dimensions Footprint: 7.5 × 2.4 m Height: 2.5 m Weight: 16,600 kg Key advantages ✔ Renowned BÜHLER brand ✔ Clamping force of 460 tons ✔ Complete production cell ✔ Automatic ACHESON mold spraying ✔ Automatic pouring ladle ✔ Siemens SIMATIC HMI control ✔ Complete technical documentation ✔ High production efficiency and repeatability ✔ Possibility of producing medium and large aluminum castings Application The machine was operated in a production facility and is offered as a complete workstation. It can be inspected and its technical condition verified after prior arrangement of a viewing date. Availability The machine is available immediately. Loading and transportation arrangements can be made within Poland and throughout Europe.

Condition: used, Year of construction: 1991, pressure: 140 bar, We offer this used Italpresse IP/500 press, manufactured in 1991. Rcjdpfezdi Ezjx Ah Def Manufacturing date: 4/1991 Machine type: IP/500 Serial number: 1856 The machine is equipped with a STOTEK DTE 716 dosing furnace (spare parts for the furnace are included), an Achceson Dag 1000 sprayer, and an Italpresse transfer device. The control system has been replaced with a new S7 system, and the batteries have been replaced. The machine is in working order and is currently in continuous production. If you have any questions or require further information, please send a message or contact us by phone.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 10380840, clearance between the columns: 640 mm, column diameter: 125 mm, ejector force: 150,000 N, ejector stroke: 145 mm, mold height (min.): 300 mm, type of input current: three-phase, input voltage: 400 V, clamping force: 4,200 kN, Horizontal die casting machine Make: Bühler, Model: Evolution B42D, Year: 2004, Serial number: 10380940 Mould height: 300 - 700 mm Mould opening stroke: 640 mm Max. surface pressure: 100 N/mm² Min. clamping plate dimensions: 500 x 500 mm Clear tie bar spacing: 640 x 640 mm Tie bar diameter: 125 mm Ejector stroke: 145 mm Ejector force: 150 kN Rcedsyngv Tspfx Ah Dof Max. closing force: 4200 kN Cycle time: 30 s Casting piston speed: 5.0 m/s Incl. die spraying system Gerlieva GS 1200/1400Z Incl. holding furnace Westomat ProDos DPC 900kg Incl. extraction robot ABB IRB 4600 M2004

Condition: used, Year of construction: 2004, machine/vehicle number: 257253, Clamping force: 13,000 kN, total weight: 69,000 kg, including spraying unit WOLLIN, deburring press REIS TKP3, serial number: 181013, year of manufacture: 2004, weight: 680 kg, industrial robot REIS V60, serial number: 541010, year of manufacture: 2004, machine weight: 1,950 kg, melting and holding furnace STRIKO WESTOFEN W1200SL Pro, year of manufacture: 2004, serial number: 7961, furnace chamber volume: 970 dm³, empty weight: 3,100 kg, heating capacity: 22 kW, machine out of service, not ready for operation. Rjdpfx Ahszhaydj Docf

Condition: used, Year of construction: 2008, machine/vehicle number: 311504, equipped with melting and holding furnace STRIKO WESTOFEN W900SL Prodos XP, year of manufacture: 2008, serial number: 10406, furnace chamber volume: 8290 dm³, unladen weight: 3,200 kg, heating capacity: 22 kW, handling robot SPESIMA Gripmat 2, year of manufacture: 2008, serial number: 210430, machine weight: 1,400 kg, casting automation, spray unit, articulated chain conveyor, length: approx. 350 cm, conveyor width: approx. 100 cm, protective enclosure, control system, machine platform, injection unit defective. Rcjdpfx Ahezhax He Def

Condition: used, Year of construction: 1996, machine/vehicle number: 7037, equipped with an ABB IRB6400F removal robot, year of manufacture: 1997, serial number: 1318, inventory number: 073005700, WOLLIN spray unit, casting automation, control system, touch panel, cooling tank, machine platform, belt conveyor, 1 ABB industrial robot as a spare parts dispenser. Rodpfx Aozhax Toh Dscf

Condition: used, Year of construction: 1992, machine/vehicle number: 6597, Revision status: 2005, clamping force: 320 tons, melting and holding furnace DOGUS MACHINE EMHF-300/45, year of manufacture: 2020, heating capacity: 45 kW, diameter: 1,320 mm, height: 1,500 mm, casting automation, spray device WOLLIN LSC1, year of manufacture: 2014, serial number: 1009. Redpezhaykjfx Ah Djcf

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 10306675, type of input current: three-phase, input voltage: 400 V, clamping force: 8,400 kN, input frequency: 50 Hz, Horizontal die casting machine Manufacturer: Bühler, Model: SC D/84, Year: 1999 Serial number: 10306675 Max. locking force: 8,400 kN Cycle time: 30 s Casting piston speed: 5.0 m/s Including Gerlieva GS 1200/1400Z mould spraying unit Including Westomat W900SLDG 900kg holding furnace Including ABB IRS5 45kg extraction robot Rcedpfxeynh Dle Ah Def

Condition: ready for operation (used), Year of construction: 1996, Clamping force: 3150kN, opening force: 10,000daN, closing stroke: 500mm, ejector force/retraction force: 159/82kN, ejector stroke: 120mm, mould height: 300-700mm, platen dimensions: 900x900mm, tie bar spacing: 550x550mm, tie bar diameter: 110mm, injection position: mm, max. injection force: 350kN, injection stroke: 430mm, injection plunger diameter: 50/60/70/80mm, shot volume: 563/811/1103/1441cm³, specific injection pressure: 1783/1238/909/696daN/cm², corresponding projected area: 177/254/347/453cm², max. projected area: 1050cm² at 300daN/cm², operating pressure: 140bar, dry cycle time (DIN 24480): 500, drive motor: 22kW, control: Datacontrol, length: 6900mm, width: 2000mm, height: 2800mm, weight: 14t, operating hours: 77,185h, shot count: at least 1,147,108, however not guaranteed due to a hardware replacement, adjustable opening stroke, with Striko Westofen W455 holding furnace, ABB IRB 2400 (M96/F10) industrial robot, and documentation. An on-site inspection is possible. Rjdpfsza E Rmjx Ah Docf

Condition: used, STUDER S41 is a CNC cylindrical grinder engineered for precision, high accuracy and reliability. Capacities: centre height 275 mm, distance between centres 1000 mm, max workpiece Ø 550 mm, workpiece height 1000 mm, Z 1150 mm, X 350 mm, workpiece weight 250 kg. Specs: grinding wheel Ø500×100 mm, peripheral speed 50/80 m/s, spindle speeds 0–4500 rpm, wheel head swivel -45/+225°, workpiece spindle motor 15 kW, 3x400 V 50 Hz, air 5 bar, tailstock stroke 60 mm (Ø 60 mm), machine weight ≈9000 kg. Accessories: high‑res C‑axis, B1+B2 axes, coolant system, internal grinding attachment, 2 spindles, lamp, status light, PC system, electronic handheld control, foot pedal. Achieves tight tolerances; typical in automotive, aerospace, toolmaking, medical and watchmaking. Rcsdpjzv I Irefx Ah Dsf

Condition: used, Year of construction: 1994, functionality: limited functionality, Used Oskar Frech DAW 125 with control cabinet and crucible Rodpfjwywn Eex Ah Dscf

Condition: ready for operation (used), Year of construction: 1989, An aluminum die casting system is available. Clamping force: 2200kN, opening force: 71kN, max. opening stroke: 430mm, mold closure: double toggle lever, pressure chamber: cold chamber, position: horizontal. Filling piston diameter min./max.: 40mm/70mm, pressure chamber filling volume min./max.: 293cm³/898cm³, casting pressure: 1990bar, blast area min./max.: 110cm²/338cm², output: 780 cycles/h. Clamping plate dimensions X/Y: 755mm/755mm, column spacing: 500mm/500mm, mold height min./max.: 250mm/600mm, min. mold dimensions X/Y: 296mm/296mm. Including crucible furnace, blow-out device, automatic dosing unit and 4x control cabinets. Documentation available. Rsdoucfwpjpfx Ah Decf

Condition: used, Year of construction: 2017, workpiece weight max. 2000 g used weightcontrol WC2000 for die casting machines up to a unit weight of 2000 grams. Rcjdpfx Aoy Diaush Def The device has been checked and repaired by the manufacturer

Condition: used, Year of construction: 2000, closing pressure 900 kN clamping plate 540x540 mm distance between columns 350x350 mm weight of the machine ca. 5,5 t lock stroke 280 mm capacity of ejector 60 kN ejector stroke 70 mm height of form 160-400 mm column diameter 65 mm casting capacity 75 kN casting plunger stroke 130 m/m injection plunger diameter 50,55,60 mm casting volume (DIN 24480) 119, 163, 214 cm 2 volume cast pressure 380, 315, 265 kp/cm² casting area 236, 285, 340 cm 2 Traverse Stroke 150 m/m General overhauled Die Casting machine DAW 80 GO with DataLogic control for the use of zinc alloys. Excerpt from the overhaul: · Upgrade of the machine with new control cabinet and operator panel including new electric machine installation · Renewal of the hydraulic system (blocks and valves) · locking unit overhaul Details available upon request The machine is equipped with the following options: Front door motorized, rear door manual handling Cover for drop through area at the subframe Hanging operating desk with monitor 1.0.2 Cover for drop through area at the subframe with scale / chute 3.2.4 Multi-chamber furnace with pump TOC 3.2.1 furnace control cabinet 4.0.1 Hydraulic system for water glycol 6.1.3.1 Wired signal interface for extraction device (DISPO 010) 6.5.2 Equipment package, Remote Service Dialog (RSD) with switch 7.2.2.2 Spraymotion 611 E with servo drive Rcjdeyzt D Eopfx Ah Def 7.3.1 Lubricant container TD 20 7.4.0.3 Spray rail CR 275 Other options can be offered upon request

Condition: like new (used), Year of construction: 1995, machine/vehicle number: 10262342, Automated high pressure die casting machine Bühler. 9800 kN clamping force. Machine is DISMANTLED Rodpfx Ahofbl Ene Djcf

Condition: like new (used), Year of construction: 2000, machine/vehicle number: 32577, Automated high-pressure die casting machine Bühler. 7900 kN clamping force. 500 mm plunger stroke Rcsdjfbl E Sjpfx Ah Dsf Air conditioning KMA / Bentleon type Ultravent / AFS 6000 (2000) The machine is DISMANTLED. Has been repainted recently.

Condition: used, 6166 000, TiMix 5, microtiter plate shaker Model: 6166 000 Type: TiMix 5 Rcsdpfx Asuz Ebhoh Def Condition: Used

Condition: used, Year of construction: 1997, functionality: fully functional, clearance between the columns: 579 mm, casting force: 350 N, stroke length: 420 mm, column diameter: 125 mm, overall weight: 12,000 kg, power: 22 kW (29.91 HP), Locking Force: 350 metric tons Rcsdpfxev D Dwpo Ah Dsf Tie Bar Diameter: 125 mm Clearance Between Tie Bars: 579 x 579 mm Die Thickness (Minimum - Maximum): 300 - 700 mm Die Stroke: 420 mm Moving Platen Size: 940 x 940 mm Injection Position: -125 mm Power Requirement: 22 kW Machine Weight: 11,974 kg (26,400 pounds) Sold with trimming press and manipulator.

Condition: repair required (used), Year of construction: 2001, functionality: not functional, FRECH DAK 720-71 RC Die-Casting Machine, used Machine number 440403, clamping force 8,000 kN, clamping stroke 825 mm, ejection force 364 kN, ejection stroke 180 mm, mould height 350 to 1,000 mm, clamping platens 1,300 x 1,300 mm, tie bar spacing 825 mm, tie bar diameter 180 mm, maximum casting force 713 kN, casting stroke 600 mm, casting piston diameter 70 to 120 mm, casting volume 1,539 to 4,523 cm³, operating pressure 160 bar, drive motor 45 kW, equipped with MELTEC AVDF 1200/5000 dosing furnace, year 2017, serial number System sold as a donor for spare parts Technical details: Dimensions (L x W x H): approx. 8,000 x 7,500 x 3,500 mm Rcedpfxewc Tdzs Ah Djf Weight: approx. 36,000 kg Year of manufacture: 2001

Condition: new, Year of construction: 2022, Electric furnace MELTEC Typ ZC20/120F ECO V2 incl. iron steel crucible, isolated coverand substructure. Without control cabinet (can be ordered aditionally) The EcoMelTec furnace combines the advantages of the proven multi chamber furnace with many new functions for double savings. New functions help to optimize the handling of the casting process just as: - Good accessibility for cleaning purposes via flexibly mountable flap cover - New pump design enables longer cleaning intervals - Storage for slag container - facilitates cleaning the melt bath - Symmetrical furnace design - no right-hand/left-hand version required Crucible content: 420,0 kg/Zn Melting capacity: 120,0 kg/Zn/h Electrical connection: 21,5 kW Type: ZC 20/120 F ECO V2 Redjy E Tybspfx Ah Docf suitable for DAW 20F and W20Zn

Condition: new, Year of construction: 2020, Electric furnace MELTEC Typ ZC50/180 TOC incl. iron steel crucible, isolated coverand substructure. Without control cabinet (can be ordered aditionally) Electric heating with heating elements. Transfer of melt below bath level from melting to casting chamber by pump to provide constant bath level together with shot to shot Rodpfxjy E Tynj Ah Decf consistency. Crucible content: 820,0 kg/Zn Melting capacity: 180,0 kg/Zn/h Electrical connection: 27,0 kW Type: ZC 50/180 TOC suitable for DAW 50F and W50Zn

Condition: new, Year of construction: 2023, Electric furnace MELTEC Typ ZC80/180F ECO V2 incl. iron steel crucible, isolated coverand substructure. Without control cabinet (can be ordered aditionally) Rcodpfxey E Tyhs Ah Dsf The EcoMelTec furnace combines the advantages of the proven multi chamber furnace with many new functions for double savings. New functions help to optimize the handling of the casting process just as: - Good accessibility for cleaning purposes via flexibly mountable flap cover - New pump design enables longer cleaning intervals - Storage for slag container - facilitates cleaning the melt bath - Symmetrical furnace design - no right-hand/left-hand version required Crucible content: 820,0 kg/Zn Melting capacity: 180,0 kg/Zn/h Electrical connection: 27,0 kW Type: ZC 80/180 F ECO V2 suitable for DAW 80F and W80Zn

Condition: new, Year of construction: 2025, closing pressure 240 kN clamping plate 380x380 mm distance between columns 250x250 mm weight of the machine ca. 3,0 t lock stroke 180 mm capacity of ejector 28 kN ejector stroke 50 mm height of form 120-300 mm column diameter 45 mm casting capacity 43 kN casting plunger stroke 85 m/m injection plunger diameter 36,40,45 mm casting volume (DIN 24480) 47,63,87 cm ³ volume cast pressure 420,340,270 da/cm² casting area 56,70,88 cm 2 Traverse Stroke 150 m/m Equipment of the machine 1.0.2 Cover for drop through area at the subframe with scale/chute 1.0.3 Cover for small parts in the subframe 1.1.0 Motorized guard in casting direction left 1.4.0 Machine positioning mounting pads 1.5.4 Machine interior illumination 1.11.0 Convenience package energy efficiency 2.0.1.2 Ejector function package "Technology" including SensiEject 2.6.4 Machine assistance system SensiLock 2.8.0 Hydraulic adjustment of locking unit for shot positioning 3.0.1.2 Casting assistance package Technology including SensiInject 3.2.9 EcoMelTec multi-chamber furnace with pump (surcharge) 3.4.4 Prefilling process 3.4.5 Simplified piston removal 3.4.6 Piston stop during return stroke Rcsdpjx Hp E Asfx Ah Def 3.5.2 Electric nozzle and gooseneck heating (extended version) 3.5.3 Plug-in connections for electric nozzle and gooseneck heating 4.5.0 Shut-off facility for hydraulic locking and injection unit 4.6.1.2 Integrated water circuit 2+4 circuits 5.1.0 Machine control DATADIALOG - Realtime Control (RC) 5.1.5 Maintenance plus package 5.6.0 Special cable lengths 6.1.3.1 Wired signal interface for extraction device (DISPO 010) 6.1.4 Serial interface for 4 heating-cooling circuits ROBAMAT 3.1 6.1.5 Interface for Vacuum unit 6.3.1.1 Hanging operating desk with monitor 6.5.2 Service Package RSD with Switch for each additional machine 7.2.1.2 Spraymotion 411 E with servo drive 7.2.10 Extended spraying program for spraymotion 7.3.1 Lubricant container TD 20 7.4.0.1 Spray rail CR 155
