The Model AIRKOMP case clamp allows for fast assembly of cabinets and case goods. The strong clamping beams of the AIRKOMP enable an all-over clamping of the cases to achieve the highest quality results.
A clamping pressure of up to 1700 kg (3,747 lbs.) Vertically and 1200 kg (2,645 lbs.) Horizontally can be generated in the press. The unique feature of this clamp is that the horizontal beam is moved manually and locked into any position necessary. This allows for the fastest adjustment of any ...
lacquer and veneer sanding machine + structuring brush
cross sanding belt
longbelt sanding - 1 electronic sanding pad
structuring brushing unit
cleaning brushing unit
Bagttxinrh
sanding width mm: 1300
Sanding hight mm: 3-120
Number of sanding belts: 2
Sanding belt dimensions: mm 2620 X 1320
Aggregat 1 sanding speed m/sec: 2,5-16
Aggregate 2 sanding speed m/sec: 2,5-16
Power motor cross belt kW: 11
Power motor belt 2 kW: 18
variabel feeding speed m/min: 5-18
Feeding motor kw: 2,5
...
4300mm Cutting length
72mm Max cutting depth
Max sawbalde dia 320mm
Pusher speed 0 - 70m/min
Pusher with 7 x panel grippers
Rack and pinion guidance for pusher
Main / scoring saw
Carriage speed 3 - 100m/min
Side aligning device for crosscutting
G3bbgwgj
Rear lift table x 4hp Max stack height 500mm
3 x Front sopprt tables
Serial nr 918/19
Year - 2019 CE
Total insstalled power 18kw
Overall floor area approx 5.9m wide x 7.3m deep
Overall weight 600okg
X axis working area: 6360 mm
Y axis working area: 1680 mm
H8nm8v7
Working Table: Pod and Rail
Main Electrospindle power: 12 KW
Number of controlled axes: 5 axes
Total number of tool changer positions: 48
The CNC shaping machine SPRINT-MT select.line is ideal for the complete processing of door frames with mortise and tenon connection under 45° combined in one work process.
C2823b0s
The possibility to process 2 workpieces simultaneously leads to high efficiency. Furthermore, the machine is equipped with 3 NC-axis offering you extreme flexibility in the processing of different processing patterns.
Work piece thickness 0,4 - 8 mm
Work piece height max. 51 mm
Min. work piece width 50 mm
min work piece length 180 mm
edge magazine for PVC and strips
pneumatic pressure rollers for edge magazine
edge snipping unit
cutting unit with 2 saws
milling aggregate
buffing unit
Js982fjdy
Feed speed 11 m/ min
Glue application with fin nozzle
Air pressure 6 bar
length 3750 mm
Machines a pair of strings in one operation
No setting out or marking of strings and no pitch board required
Pneumatic workpiece cramps
Automatic pneumatic movement to pitch settings
Top and bottom cutterheads are arranged to jump in and out to facilatate open plan stairs.
Max size of string board 300mm x 50mm
High rpm spindles through frequency changer
Cuts a pair of open flight strings in approximately 4 minutes
Fw7vtv7
Single-sided drilling and dowel insertion machine for batch size 1 production
Pure function, top quality and consistent high performance are combined into one in the basic version of our SPRINT drilling and dowel insertion machine.
The machine is equipped for horizontal drilling and doweling. The proven technology guarantees high-quality drilling and doweling results -consistently over long periods- and reproducible accuracy thanks to perfect precision.
ADVANTAGES
Extreme efficiency due to t...
UV tunnel with nozzle cooling zone
working width max mm: 1350
work piece height max mm: 80
UV lamps: 3
kW per lamp: 11,5
adjustable - no
power output UV lamp Watt: 80
feed speed m/min: 5-25
feeder motor kW: approx. 2,0
working height mm: 980
Advise used machines:
• Technical data without obligation, mistake and intermediate sale reserve.
• Price is considered ex-location price
• All articles or machines are bought as seen without any entitlement on warranty.
2pn8q3yix
• It is l...
Provisional specification.....
230mm x 120mm capacity
Feed speeds 6 - 12m/mnin
2m infeed table
4 spindles [ motors approx 5.5-7.5kw ]
Bottom
Right
Left
Top
All spindles 40mm dia x 6000rpm
Mechanical digital readouts for spindle setting
Rgbfr
Lift up safety /. soundproof cover
brushing machine for profiles such as windows frames or doors with fillings
feed and the rotation of brushes are completed managed from inverters
aggregates:
group of one longitudinal counter rotating brush
two lateral brushes
one horizontal brush, moveable
these aggregates allow working at the same time on three sides of the piece
feed speed variable with inverter
brush speed variable with inverter
all aggregates controlled vis touch screen panel
max work piece height 250 mm
max work piece w...
36" dia saw pulleys [ 900mm ]
3" max wide blades [ 75mm ]
Max length of saw 18' 4"
Max height of top sawguide above table 16" / 400mm
Max opening fence to sawline 9" / 225mm
15hp motor.
Adjustable tilting fence.
DC braking
G2yddnnl
Net weight 1850kg
motor power S1 (100%) 3.0 kW / 4.0HP
motor specification, 400V/3P/50Hz
Motor rotation speed 2850 rpm
oscillation motor power S1, 0,25 kW
oscillation stroke 20 mm
sanding belt speed 20 m/sec.
sanding belt width 150 mm
sanding belt length 2600 mm
sanding unit tilt range 90-45°
working table vertical stroke 190 mm
working table dimensions 750 x 300 mm
Ø drive roller 135 mm
Ø round sanding roller 100 mm
Ø dust collecting plugs 120 mm
weight 253 kg
• Sanding unit steplessly tiltable from 90 to 45°
...
700mm dia saw pulleys
325mm max depth under saw guide
230mm fence opening
385mm feed opening
78mm max sawblade width
Tilting table
11kw main motor
Ci9fqdglvf
0.75kw feed motor
Feed speeds variable 5 - 25m/min
double end profiling machine for the door and windows production
working width 4000 mm
3 aggregates on each side
1 x saw
2 x vertical miling aggregate - spindle stroke 800 mm!
long side profiling machine with 16 spindles
machine comes with a lot of spare parts!
further technical data on demand
79sh8ptbc
Advise used machines:
• Technical data without obligation, mistake and intermediate sale reserve.
• Price is considered ex-location price
• All articles or machines are bought as seen...
A twin blade saw that has been specifically designed for cutting glazing beads accurately to length, with either a straight or mitred cut. The machine has two work-levels one set above the other, allowing two lengths of beading to be cut simultaneously. The two lengths of bead are held secure during the cutting operation by the front pneumatic clamps. Setting the correct length is achieved by means of handwheel moving the left head in relationship to the fixed right head, the length is easily...
max. edge thickness coils 0.2 - 3 mm
Wau7an3
max. edge thickness solid strips15 mm
feed speed 12/ 18 m/min
glue plot heating time approx. 6 min
autom. strip magazine
coil magazine
granulate heating pot
flush trimming unit
radius trimming unit
operating panel
extendable work piece support
noice cancelation hood
machine length 3800 mm
Advise used machines:
• Technical data without obligation, mistake and intermediate sale reserve.
• Price is considered ex-location price
• All article...
Vertical heavy-duty hydraulic frame clamp for window frames and doors Clamping of windows/doors Hydraulic Simple set up
Ci9fhfdc3h
Specification
3m x 2m capacity
With one fixed and one moveable longitudinal pressure beam.
3 x Vertical beams each with hydraulic cylinder with 150mm stroke. Each with spring balance unit.
2 x Horizontal hydraulic pressure cylinders with 120mm stroke, positioned on moveable longitudinal pressure beam.
3 x vertical beams fitted with adjustable lower support plates
...
edge thickness 0,4 - 12 mm
work piece thickness 10 - 55 mm
work piece length min 160 mm
work piece width min 65 mm
feed speed 13 m/ min
compressed air 7 bar
3dt30mwyf
machine length 5420 mm
weight 1950 kg
glue pot with quick melt system
glue application roller wit left and right turning
edge magazine for PVC and strips
motor height adjustment for pressure beam
pneumatic pressure rollers for edge magazine
control panel, rotatable
all aggregates in-line controlled
cutting
milling...
220 x 120mm capacity
2000mm long infeed table
4 Spindles
Bottom x 5.5kw
Right x 5.5kw
Left x 5.5kw
Top x 7.5kw
Variable feed speeds 5 - 30m/min
G2mpfsae
Pneumatic pressure to feed rollers
40mm dia spindles x 6000rpm
Mechanical digital readouts for spindle setting
Lift up safety hood
X axis working area: 3100 mm
Y axis working area: 2250 mm
Working Table: Flat table
Bgek9pd8
Main Electrospindle power: 9 KW
Number of controlled axes: 3 axes
Total number of tool changer positions: 22
X axis working area: 3000 mm
Y axis working area: 1250 mm
Working Table: Pod and Rail
Main Electrospindle power: 9 KW
Number of controlled axes: 4 axes
Total number of drilling spindles: 18
Cicg7foqab
Total number of tool changer positions: 16
Max. panel width: 4100 mm
Max. panel length: 2200 mm
Main saw blade projection: 135 mm
No of Grippers: 12
Second flexible pusher: yes
Panel Rotation Station: yes
Jrngbeq
X axis working area: 3130 mm
Y axis working area: 1550 mm
Working Table: Pod and Rail
Bcketaoe
Main Electrospindle power: 9 KW
Number of controlled axes: 3 axes
Total number of drilling spindles: 18
Total number of tool changer positions: 8
X axis working area: 3200 mm
Y axis working area: 920 mm
Main Electrospindle power: 6.5 KW
Number of controlled axes: 3 axes
Total number of drilling spindles: 15
Qynfv
Total number of tool changer positions: 6
X axis working area: 3050 mm
Y axis working area: 850 mm
Number of controlled axes: 3 axes
Kb8bcj
Total number of drilling spindles: 19
Total number of tool changer positions: 4
X axis working area: 3700 mm
Y axis working area: 1550 mm
B8vdgip3x8
Main Electrospindle power: 9 KW
Number of controlled axes: 3 axes
Total number of drilling spindles: 10
Total number of tool changer positions: 8
X axis working area: 3680 mm
Y axis working area: 2040 mm
Dplkyz7
Main Electrospindle power: 13 KW
Number of controlled axes: 3 axes
Total number of drilling spindles: 9
Total number of tool changer positions: 32
