Used Correa for sale (51)

Condition: like new (used), Year of construction: 2018, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, Year of manufacture: 2018 Table: 4,500 * 2,000 mm X: 4,000 mm Y: 3,000 mm Z: 1,500 mm Additional information: Heidenhain TNC 640 HSCI Main spindle ISO 50 Spindle speeds: max 6,000 rpm Hnedpez Nifdsfx Ah Sju Tool changer: 60 tools Coolant through the spindle UAD/universal head 0.002/0.002 degrees Many additional options!

Condition: like new (used), Year of construction: 2021, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, Year of manufacture: 2020 Table: 4,500 * 2,000 mm X: 4,000 mm Y: 3,000 mm Z: 1,500 mm Additional information: Heidenhain TNC 640 HSCI Main spindle ISO 50 Spindle speeds: max. 6,000 rpm Tool changer: 60 tools Coolant through the spindle UAD/universal head 0.002/0.002 degrees Hedpfx Ajz Nihfjh Senu Many additional options!

Condition: used, Year of construction: 1998, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, overall weight: 9,000 kg, input voltage: 380 V, power: 29 kW (39.43 HP), We are offering this used Correa CF22/20 bed milling machine, manufactured in 1998, for sale. Model: CF22/20 Serial number: 9671801 Year of manufacture: 1998 Power: 29 kW Voltage: 380 V Air pressure: bar Weight: 9000 kg If you have any questions or would like more information, please feel free to send us a message or call us. Hsdpoz Sr Uaefx Ah Sjnu

Condition: used, Year of construction: 1995, functionality: fully functional, machine/vehicle number: 9690706, Control system: Heidenhain TNC 407 Table size: X 1800, Y 700, Z 700 Hedpfx Ahoz D D S He Ssnu Tools included, as shown in the picture. Price: 80,000 SEK, excluding VAT, or best offer. Free loading is included.

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 1,300 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, feed rate X-axis: 8,000 m/min, feed rate Y-axis: 8,000 m/min, feed rate Z-axis: 8,000 m/min, spindle speed (max.): 3,150 rpm, table width: 630 mm, table load: 3,000 kg, table length: 1,700 mm, mount diameter: 50 mm, total height: 2,300 mm, total width: 2,300 mm, total length: 4,700 mm, rotational speed (max.): 3,150 rpm, overall weight: 6,000 kg, 2013 Overhauled by REIDEN SWISS New regrinded New iTNC530 New Hr410 Handwheel New CE-Safety  New Milling head gears and bearing New LS186C Glas scales New Blum TC60 3D taster Geomtrical DIN 8615 ! Hnodpfx Ahjzvfiae Ssu Overhauling cost CHF 250k X-Axis: 1300mm Y-Axis: 630mm Z-Axis: 630mm Table Length: 1700mm Table Width: 630mm Table load: 3000 Power on spindle:16kW Spindle speeds: 3150Rpm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis:8000mm/min. Feed rate Y-Axis:8000mm/min. Feed rate Z-Axis:8000mm/min. Length: 4700mm Width: 2300mm Height: 2300mm Weight: 6000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2014, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-530 Technical features Dimensions Table dimensions: 3800 x 1000 mmNumber of T slots: 7T slots dimensions: 22 mm Traverses of axis X axis traverse: 3500 mmY axis traverse: 1250 mmZ axis traverse: 1500 mmVertical capacity (VC): 80 / 1580 mm Milling head Head type: Auto-indexing Universal UDG (2.5º)Tool clamping system: HydraulicTaper nose: ISO-50 (DIN 69871)   /   Pull stud: DIN 69872Speed range: 3000 rpmSpindle power: 24 kW Feedrates Rapid feedrate (X,Y,Z): 20000 mm/min Weight and dimensions Maximum weight on table: 9000 kgMachine weight approximate: 26500 kgMachine dimensions approximate: 11100 x 5900 x 3700 mm Accessories Guarding: PerimetralAutomatic tool changer: ATC-40Chip conveyor: 1 front longitudinal and 1 rear longitudinalElectronic handwheel: HR-410Coolant: External internal high-pressure through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features Hodszqhg Rjpfx Ah Senu

Condition: like new (used), Year of construction: 2010, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 8500 x 2500 mmNumber of T slots: 17T slots dimensions: 22 mm Traverses of axis X axis traverse: 8000 mmY axis traverse: 3800 mmZ axis traverse: 1500 mmVertical capacity (VC): 168 / 1668 mmDistance between columns: 3100 mm Milling head Auto-indexing differential head (UAD - 0,02º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871) / Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 35000 kgMachine weight approximate: 79000 KgMachine dimensions approximate: 22700 x 7660 x 6800 mm Accessories Guarding: 2 sliding doors with a new perimetral wire-mesh fenceAutomatic tool changer: ATC-60Chip conveyor: 2longitudinal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sale conditions Warranty: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features Hedpfx Ahjz Alwqj Sonu

Condition: like new (used), Year of construction: 1996, Retrofitted: 2023 Numerical control: HEIDENHAIN TNC-426 Hjdpez Iuk Uofx Ah Senu Technical features Dimensions Table dimensions: 3000 x 1250 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mmY axis traverse: 1800 mmDistance between columns: 1680 mmZ axis traverse: 800 mm Milling head Head type: Standard vertical spindleTool clamping system: HydraulicTaper nose: ISO 50Speed range: 20 - 2000 r.p.m.Spindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Max Weight on table: 10000 kgMachine weight: 21500 kgMachine dimensions: 7300 x 2690 x 3400 mm Accessories Guarding: YesCoolant: ExternalElectronic handwheel: HR-330 Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: used, Year of construction: 2002, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 20 rpm, table length: 4,500 mm, total height: 3,400 mm, total width: 5,390 mm, total length: 11,100 mm, workpiece weight (max.): 9,000 kg, overall weight: 22,500 kg, spindle motor power: 22,000 W, spindle nose: ISO 50, Fixed-bed milling machine built by Nicolás Correa in 2002, fitted with a Heidenhain TNC 426 CNC control and electronic handwheel. Working table measuring 4,500 × 1,100 mm with eight T-slots, 22 mm wide and spaced approximately 125 mm apart. Maximum permissible table load of 9,000 kg. Axis travels of 4,000 mm in X, 1,250 mm in Y and 1,500 mm in Z. Hjdpfjzw Hgvjx Ah Sjnu Universal milling head with manual positioning, hydraulic tool clamping and ISO 50 spindle taper. Main spindle rated at 22 kW with infinitely variable speed control across a range of 20 to 3,000 rpm. Cutting feed from 2 to 5,000 mm/min; rapid traverse of 15,000 mm/min on the X axis and 10,000 mm/min on the Y and Z axes. Compensation on the Y and Z axes, through-spindle coolant supply and provision for a fourth axis. The machine is supplied with a shared fourth axis, 400 mm in diameter. CE marked. Condition: axis movement is correct, with no unusual noise or vibration. Measured deviation of approximately 0.15 mm. The milling head is functional and shows slight play. The machine has been kept under basic maintenance and is in working industrial condition. Approximate weight between 22,500 and 24,000 kg. Approximate overall dimensions of 11,100 × 5,390 × 3,400 mm.

Condition: ready for operation (used), Year of construction: 1996, travel distance X-axis: 2,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 2,500 rpm, Heidenhain TNC 407 control unit Table: 2000 x 700 mm Travel: 2000 x 800 x 800 mm Spindle: SA 50 Hsdpszbrkpsfx Ah Sonu Maximum spindle speed: 2500 rpm Weight: 10000 kg

Condition: reconditioned (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,000 mm, feed rate Z-axis: 7 m/min, total length: 11,000 mm, table length: 4,500 mm, table width: 1,250 mm, total width: 4,170 mm, spindle speed (max.): 3,000 rpm, total height: 4,645 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 12 m/min, distance between stands: 2,040 mm, type of input current: three-phase, table load: 1,000 kg, position of the milling head: Universal automático, indexable cada 2,5°, workpiece weight (max.): 10,000 kg, rotational speed (max.): 5,000 rpm, overall weight: 30,500 kg, spindle motor power: 3,000 W, Equipment: rotational speed infinitely variable, Gantry milling machine, Nicolás Correa FP-40/40S, built in 2000 and retrofitted in 2016. Fitted with a Heidenhain TNC-426 CNC control and a Heidenhain HR-410 portable handwheel. Working table measuring 4,500 × 1,250 mm with eight 22 mm T-slots. Maximum permissible table load of 10,000 kg. Axis travels of 4,000 mm in X, 2,500 mm in Y and 1,000 mm in Z. Distance between columns of 2,040 mm. Hnodpfeul S Syox Ah Ssu Automatic UAG universal milling head with 2.5° indexing steps and hydraulic tool clamping, ISO 50 spindle taper to DIN 69871. Spindle rated at 30 kW, reaching 5,000 rpm. Cutting feed from 2 to 7,500 mm/min; rapid traverse of 15,000 mm/min on the X and Y axes and 12,000 mm/min on the Z axis. Automatic tool changer with 30 stations. Renishaw tool measuring probe installed, plus provision for a Renishaw workpiece touch probe. Two chip conveyors. External coolant system together with internal coolant supply through the milling head. Enclosed splash guarding, CE marked. Machine weight 30,500 kg. Overall dimensions 10,975 × 4,170 × 4,645 mm.

Condition: like new (used), Year of construction: 2003, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-530 Technical features Dimensions Table dimensions: 20000 x 2500 mmNumber of T slots: 10T slots dimensions: 22 mm Traverses of axis X axis traverse: 20000 mmY axis traverse: 3800 mmZ axis traverse: 1250 mmVertical capacity: 100 / 1350 mmDistance between columns: 3200 mm Milling head Head type: Auto-indexing BC universal UAD milling head (0,1º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871)   /   Pull stud: DIN 69872Speed range: 6000 rpmSpindle power: 27 kW Feedrates Rapid feedrates (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 15000 kgMachine weight approximate: 150000 kgMachine dimensions approximate: 30190 x 8865 x 6200 mm Accessories Guarding: Door with platform access and new perimetral wire-mesh fenceAutomatic tool changer:ATC-120Chip conveyor:2 longitudinal hinge typeControl panel: 2 switched panels on each side of the tableElectronic handwheel: HR-510Coolant: External and internal high pressure through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features Hnedpfxsy Nfz Ej Ah Ssu

Condition: like new (used), Year of construction: 2013, Retrofitted: 2026 Hnodpfjyf Rraex Ah Sou Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 12500 x 2250 mmNumber of T slots: 9T slots dimensions: 22 mm Traverses of axis X axis traverse: 11500 mmY axis traverse: 1500 mmZ axis traverse: 2000 mmVertical capacity (VC): 150 / 2150 mm (adjustable) Milling head Head type: Universal Auto-indexing UDG (2.5º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 3000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 30000 mm/min Weight and dimensions Maximum weight on table: 15 Tn/m2Machine weight approximate: 62000 kgMachine dimensions approximate: 18494 x 8412 x 5290 mm Accessories Guarding: front doors and new perimetral wire-mesh fenceAutomatic tool changer: ATC40Chip conveyor: 1 longitudinal rear hinge typeElectronic handwheel: HR-410Coolant: external internal high-pressure through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2011, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 10000 x 2250 mmNumber of T slots: 9T slots dimensions: 22 mm Traverses of axis X axis traverse: 10000 mmY axis traverse: 1500 mmZ axis traverse: 2500 mmVertical capacity (VC): 150 - 2650 mm  (adjustable) Milling head Head type: Universal Auto-indexing UDG (2.5º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 3000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 30000 mm/min Weight and dimensions Maximum weight on table: 15 Tn/m2Machine weight approximate: 56000 kgMachine dimensions approximate: 16520 x 8575 x 5290 mm Accessories Guarding: front sliding doors and new perimetral wire-mesh fenceAutomatic tool changer: ATC40Chip conveyor: 1 longitudinal rear hinge typeElectronic handwheel: HR-410Coolant: external internal high-pressure coolant through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features Hnedpfx Aozcz Srjh Sju

Condition: used, Year of construction: 1990, Fixed Bed Milling Machine CORREA A25/25 Travel X: 2500 mm Travel Y: 1200 mm Hodpjz Nxx Tsfx Ah Senu Travel Z: 1000 mm CNC HEIDENHAIN TNC 355 Spindle: SA 50 Spindle motor: 30 CV Spindle speed: from 2 to 3000 RPM Table size: 3000 x 1000 mm Year of construction: 1990 Maxi eligible load on table: 7 T Manual Swivel Head Voltage: 380 V Dimensions (L x W x H): 5000 x 3000 x 3000 mm Weight: 16,5 T

Condition: used, Year of construction: 1992, total height: 2,700 mm, total width: 3,000 mm, total length: 5,300 mm, Colour: White Empty weight: 11.000 kg Price: On request - Year: 1992 - Documentation available: No - CE certificate present: No - Serial number: 9220212 - Drive system: Conventional - Bed milling machine model: Movable table - Number of axes [pcs]: 3 - X-axis travel [mm]: 3200 Hodszwn Egspfx Ah Senu - Y-axis travel [mm]: 1000 - Z-axis travel [mm]: 1000 - B-axis rotation [°]: 360 - C-axis rotation [°]: 360 - Table length [mm]: 3500 - Table width [mm]: 800 - Tool holder: ISO50 - Main spindle power [kW]: 15 - Min. spindle speed [rpm]: 40 - Max. spindle speed [rpm]: 2000 - Max. workpiece weight [kg]: 4000 - Options: Digital readout - └ Type of digital readout: Sony 3-A - Transport dimensions: 5300mm x 3000mm x 2700mm (l x w x h) - Transport weight [kg]: 11000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: like new (used), Year of construction: 2001, Retrofitted: 2026 Numerical control: NUEVO/NEW HEIDENHAIN TNC-320 Hsdpfx Aezq H Ugsh Sonu Technical features Dimensions Table dimensions: 2500 x 700 mmNumber of T slots: 5T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mmY axis traverse: 800 mmZ axis traverse: 800 mmVertical capacity (VC): 22 / 822 mm Milling head Head type: Manual universal long nose head (Option: new automatic milling head UDG 2,5º)Tool clamping system: HydraulicTaper nose: ISO-50 (DIN 2080)   /   Pull stud: DIN 69872Speed range: 4000 rpmSpindle power: 22 kW Feedrates Working feedrate: 5 - 5000 mm/minRapid feedrate (X,Y,Z): 12000 mm/min Weight and dimensions Maximum weight on table: 4000 kgMachine weight approximate: 9500 kgMachine dimensions approximate: 6605 x 3315 x 2730 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceElectronic handwheel: New HR-510Coolant: External Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2002, Retrofitted: 2026 Hsdpfx Ahszlu Scs Senu Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 2000 x 1000 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 2000 mmY axis traverse: 1250 mmZ axis traverse: 650 mmVertical capacity (VC): 150 / 800 mmDistance between columns: 1250 mm Milling head Kessler electrospindleTool clamping system: HydraulicTaper nose: HSK-63Speed range: 20 - 12000 rpmSpindle power: 25 kW Feedrates Rapid feedrate (X,Y,Z): 20000 mm/min Weight and dimensions Maximum weight on table: 5000 kgMachine weight approximate: 14000 KgMachine dimensions approximate: 6500 x 3934 x 4000 mm Accessories Guarding: PerimetralAutomatic tool changer: ATC-24Chip conveyor:2 longitudinal and 1 hinge type transversalElectronic handwheel: HR-410Coolant: External internal high pressure through spindle Sale conditions Warranty: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2008, Retrofitted: 2025 Hnsdpsy D Uzwofx Ah Sju Numerical control: HEIDENHAIN TNC-530 Technical features Dimensions Table dimensions: 2800 x 1000 mmNumber of T slots: 5T slots dimensions: 22 mm Traverses of axis X axis traverse: 2500 mmY axis traverse: 1000 mmZ axis traverse: 1500 mmVertical capacity (VC): 96 / 1596 mm Milling head Head type: Universal manual (U22) (Option: new auto-indexing UDG head, every 2,5º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871)   /   Pull stud: DIN 69872Speed range: 20-3000 rpmSpindle power: 22 kW Feedrates Feedrates: 5000 mm/minRapid feedrates (X,Y,Z): 20000 mm/min Weight and dimensions Maximum weight on table: 6000 kgMachine weight approximate: 23000 kgMachine dimensions approximate: 7750 x 4400 x 3500 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceAutomatic tool changer: New ATC-30Chip conveyor: 1 Rear longitudinalElectronic handwheel: HR-410Coolant: External and internal high pressure through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2000, Retrofitted: 2026 Hnedpfx Ahsznpczj Sou Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Technical features Dimensions Table dimensions: 5600 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 5000 mmY axis traverse: 3250 mmZ axis traverse: 1000 mmVertical capacity (VC): 500 / 1500 mmDistance between columns: 2700 mm Milling head Milling head model 1: UAGA orthogonal auto-indexing BC (2,5º)Tool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 3000 rpmSpindle power: 30 kW Milling head model 2: FA large vertical spindleTool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 3000 rpmSpindle power: 30 kW Milling head model 3: Direct spindleTool clamping system: HydraulicTaper nose: ISO-50 (DIN69871)   /   Pull stud: (DIN69872)Speed range: 5000 rpmSpindle power: 37 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 25000 KgMachine weight approximate: 56000 KgMachine dimensions approximate: 13200 x 5738 x 5850 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceMilling head changer: Semi-automatic with hinges on columnAutomatic tool changer: OptionalChip conveyor: 1 transversal hinge typeElectronic handwheel: New HR-510Coolant: External internal high-pressure through spindle (only in direct spindle) Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: like new (used), Year of construction: 2007, Retrofitted: 2026 Hodpsy Nfz Sefx Ah Sjnu Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 4500 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): -50 / 950 mmDistance between columns: 2500 mm Milling head Milling head: 2 axis continuous head C5ETool clamping system: HydraulicTaper nose: ISO-50 (DIN 69871)   /   Pull stud: (DIN69872)Speed range: 4000 rpmSpindle power: 37 kW Feedrates Feedrate: 7000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 35500 KgMachine dimensions approximate: 10923 x 6170 x 5250 mm Accessories Guarding: 2 sliding doors and new perimetral wire-mesh fenceElectronic handwheel: HR-410Coolant: external Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: used, Year of construction: 1988, Bed milling machine Manufacturer: Correa Type: A16 Year of manufacture: 1988 Control system: HEIDENHAIN TNC415 Travel distances X/Y/Z: 1,800 x 800 x 800 mm Clamping surface: 2,000 x 630 mm Hjdpfjzt U T Aex Ah Sonu Workpiece weight: 3,000 kg Operating hours: 12,103 Power: 19 kW Spindle type: ISO 50 Dimensions L/W/H: 4,886 × 2,720 × 2,500 mm Machine weight: 7,500 kg 121026

Condition: used, Year of construction: 1988, Bed milling machine Manufacturer: Correa Type: A10 Year of manufacture: 1988 Control system: HEIDENHAIN TNC 355 Travel distances X/Y/Z: 1,300 x 630 x 630 mm Hnsdpfx Ahezt U R Ij Seu Clamping area: 1,700 x 630 mm Workpiece weight: 3,000 kg Operating hours: 25,845 Power: 19 kW Spindle type: ISO 40 Dimensions L/W/H: 3,870 x 2,630 x 2,200 mm Machine weight: 6,800 kg 121026

Condition: like new (used), Year of construction: 2008, Retrofitted: 2026 Numerical control: SIEMENS 840D Technical features Dimensions Table dimensions: OptionalNumber of T slots: UndefinedT slots dimensions: Undefined Traverses of axis X axis traverse: 10000 mmY axis traverse: 1500 mmZ axis traverse: 2500 mmVertical capacity (VC): 0 / 2500 mm (adjustable) Milling head Head type: Universal Auto-indexing UAD (0,1º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 20 - 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 30000 mm/min Weight and dimensions Maximum weight on table (kg/m2): OptionalMachine weight approximate: 70000 kgMachine dimensions approximate: 17560 x 12800 x 4270 mm Accessories Guarding: pendular with automatic front door and perimetral wire-mesh fenceAutomatic tool changer: ATC80 with electrical motorsChip conveyor: 1 front longitudinal and 1 transversalElectronic handwheel: 6FX2007-1AE14 SiemensCoolant: external internal high-pressure through spindleOperator’s cabinet: adjustable in vertical traverse Other technical features 2 ROTARY TABLES:Model:   DEMMELER DRLTS1800Table surface: 2400 x 1800 mmMaximum load on table: 40 TT slots number: 9T slots dimensions: 22 mmRotary axis: HydrostaticMaximun speed (S1/S6): 3.4 / 5.4 rpmClamped tangencial torque: 175000 NmW axis: 1500 mm.Maximum feedrate: 20000 mm/min.Quantity of guideway (W axis): 4 Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features Hnodpfx Ahoyvwche Ssu

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, table width: 1,100 mm, table length: 3,500 mm, total height: 4,164 mm, total width: 5,875 mm, total length: 9,120 mm, rotational speed (max.): 6,000 rpm, workpiece weight (max.): 8,000 kg, overall weight: 29,000 kg, torque: 760 Nm, Fixed-bed milling machine, Nicolás Correa BRAVA-30, built in 2005. Working table measuring 3,500 × 1,100 mm with six 22 mm T-slots and a maximum permissible load of 8,000 kg. Axis travels of 3,000 mm in X, 1,250 mm in Y and 1,500 mm in Z. Automatic UAD milling head with 0.1° indexing on both swivel axes and hydraulic tool clamping, ISO 50 spindle taper to DIN 69871. Front bearing diameter of 85 mm. Constant torque of 760 Nm between 20 and 375 rpm. Main spindle rated at 30 kW with constant power from 375 to 6,000 rpm and a speed range of 20 to 6,000 rpm. Cutting feed of 30 m/min and maximum acceleration of 12 m/s². Ball screws measuring 80×30 mm on the X axis, 50×20 mm on the Y axis and 63×25 mm on the Z axis. Hnsdpfxsulwy Aj Ah Sju Heidenhain workpiece touch probe fitted, plus provision for a Renishaw measuring probe. Portable handwheel. External coolant system together with internal coolant supply through the spindle. Chip removal by two screw-type augers and one lateral hinged-belt conveyor. Fully enclosed guarding. Approximate overall dimensions of 9,120 × 5,875 × 4,164 mm.
