Used Radial drilling machines 1000-1299mm arm length for sale (53)

Condition: used, Year of construction: 2021, gebraucht 2021 3965 prompt, Zwischenverkauf v Taiwan 15600 € 1 12480 € 42 mm MK 4 280 - 1.100 mm 44 - 1.500 (12) U/min Stahl: M 25; Guss: M 38 1880 mm 870 mm 2210 mm 1800 kg 470 - 1.270 mm 0,05 - 0,15 (3) mm/min 2.2 kW 260 mm Cgelq Egoupmggo Tqjt 280 mm 1.725 x 715 x 180 mm 0,75 kW 635 x 520 x 415 mm 2530 mm DEMO MACHINE left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: used, Year of construction: 1988, Technical details: bore capacity in steel (diameter): 45 mm arm length:: 1250 drill capacity in cast iron: 60 mm distance table - lower edge spindle: min./max.: 280 / 1380 mm spindle taper MT: MK5 bore spindle stroke: 355 mm range of revolutions per minute - continous: 20 - 1200 / 6 step U/min feed: 0,063 ... step mm/U swivel range of the arm: 360° cantilever adjustment vertical: Bohrkopf: 950 mm cantilever arm length from center column: 1700 mm Cgslqsvc Anqe Eg Tqjt vertical adjustment of the arm: Höhe: 800mm (manuell+motorisch) mm column diameter: Ø 300 mm base plate surface area: 1450 x 920 mm total power requirement: 5,0 kW weight of the machine ca.: 3kg Würfel) t dimension machine xH: 2,1 x 1,0 x 2,8 (3) m metric thread cutting in steel / GG: 36 / 45mm Drilling cube pump for supply with cooling water i.D. *

Condition: like new (used), Year of construction: 1990, Drilling capacity in steel: 50mm Drilling capacity in cast iron: 63mm Spindle: MK4 Celq Egog I I Eks Tqogt Spindle Speeds: (12) 45-2000 RPM Drill head displacement: 350-1250mm Distance spindle base plate: 350-1420mm

Condition: good (used), Year of construction: 1991, machine/vehicle number: 1435, Offer 25056 Technical data: - Drilling capacity in steel ST 60 32 mm - Drilling capacity for reaming 40 mm Celov E Iwieq Eg Tqegt - Drill spindle mount MK 4 - Drill spindle stroke 250 mm - Throat min. / max. 250 / 1000 mm - Stroke of the boom 750 mm - Min. / max. – Distance: - Spindle – base plate approx. 270 - 1040 mm - Machined base plate clamping surface W 1150 - 800 mm - Spindle speeds 50 - 2800 rpm - 6 feeds 0.05 - 0.31 m/rev - Drill spindle drive 400 V / 3.5 kW - Cube table tiltable - Coolant device - Space requirement approx. W 1050 x H 2610 / 340 x 1700 mm - Weight approx. 1800 kg

Condition: good (used), Year of construction: 1973, bore capacity in steel diameter 55 mm arm length 1600 mm workpiece height max 1600 mm - drilling capacity full bore (steel) 55 mm - throat (max) 1600 mm - workpiece height (max) 1600 mm - sleeve stroke 350 mm - space requirements -left/right- 2700 mm Cslq Eg Tsvwgnkeqogt - space requirements -front/back- 1100 mm - total height 3400 mm - total weight approx. 4500 kg feed for quill 1: 0,056 - 2,5 mm/min. turning speeds 20 - 2000 U/min tool taper MK 5

Condition: excellent (used), Caser radial drill mod. F50-1250 complete with cube Cgelqjv Hngmo Eg Tqot

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 20800 € 426.4 € 42 mm MK 4 280 - 1.100 mm 44 - 1.500 (12) U/min Stahl: M 25; Guss: M 38 1880 mm Colq Esvv H S Hog Tqsgt 870 mm 2210 mm 1800 kg 470 - 1.270 mm 0,05 - 0,15 (3) mm/min 2.2 kW 260 mm 280 mm 1.725 x 715 x 180 mm 635 x 520 x 415 mm 2530 mm left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 horizontal adjustment of the boring slide: 700 mm vertical adjustment of arm: 600 (motorisch) mm swivel range of the arm: 90° rechts/links Grad distance table - lower edge spindle: min./max.: 200 / 1120 mm spindle taper MT: 4 bore spindle stroke: 420 (manuell-automatisch) mm range of revolutions per minute - continous: 20 - 2000 / 3 step U/min feed: 01, / 0,2 / 0,3 / 0,4 / 0,8 / 1,2 mm/U column diameter: 250 mm base plate surface area: 1100 x 600 mm Cslevhbpqjq Eg Tqsgt total power requirement: 4,6 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,8 x 0,8 x 2,5 m Tool ejection via expulsion wedge Equipment: Coolant system with pump (without feed) Drill cube L: 760 x W: 500 x H: 510mm / horizontal surface 760 x 500mm and vertical surface 760 x 510mm Machine ilumination *

Condition: good (used), Radial Drill WMW HECKERT Reach mm 1300 Drilling mm 50 Spindle speed : Rpm 20 - 1200 Cube supplied with vice Cgolq Egjk S Tpgs Tqet

Condition: used, Year of construction: 1985, Bohrleistung in Stahl (-Ø 45 mm throat 1250 mm workpiece height max. 1100 mm swival range +/- 360 ° height adjustment 745 mm base plate surface area 1450 x 920 mm Bohrspindel-Ø/ Aufnahme 90 mm / MK 5 bore spindle stroke 355 mm max. torque on the spindle 250 Nm Celq Egjvcrmps Tqjgt feed power 14000 N turning speed range 20 - 1200 U/min feed range 0,063 - 0,63 mm/U drilling capacity steel/cast iron mm power capacity 3,7 kW weight of the machine ca. 3,0 t dimensions of the machine ca. 2,1 x 0,9 x 3,3 m • cube table 650 x 650 x 500 mm, • coolant device

Condition: repair required (used), bore capacity in steel diameter / mm arm length 1000 mm workpiece height max / mm ----- WORKING RANGE -BORING- - throat (max) 1000 mm - sleeve stroke 250 mm MILLING SPINDLE / HEAD / - spindle revolutions (min) 47.5 /min - spindle revolutions (max) 2120 /min - spindle diameter 60 mm - tool fixture: MK 4 DIMENSIONS / WEIGHTS - space requirements -left/right- 2000 mm - space requirements -front/back- 750 mm - total height 2160 mm - total weight approx. 2500 kg Celq Eg Tjvmtlhjqjgt Machine is not 100% OK, and needs an overhaul. - Height adjustment and cross adjustment must be repaired

Condition: used, bore capacity in steel (diameter) 40 mm arm length 350 - 1000 mm workpiece height max. 1300 mm Cjletw Haqeq Eg Tqegt turning speeds 30 - 1850 U/min feed range 0,06 - 1,0 mm/min spindle taper MT 4 column diameter 320 mm total power requirement 3,0 / 3,3 kW dimensions 2000 x 1000 x 2850 mm Weight 3500 kg

Condition: new, bore capacity in steel (diameter) 50,0 mm arm length 320 - 1.220 mm workpiece height max. 330 - 1.170 mm turning speeds 25 - 2000 U/min spindle taper MT 5 MK base plate 1300 x 980 mm threading 42 M quill stroke 335 mm total power requirement 4,0 kW weight of the machine ca. 3000 kg. range L-W-H 2035 x 1000 x 2830 mm Furnishing: - Large-sized base plate, ideal for processing large workpieces - Thick-walled, polished column for increased sliding properties of the boom - Extension arm and drill head with independent hydraulic clamping - Simple height adjustment of the extension arm using a lifting motor - Ideal for drilling, countersinking, reaming and thread cutting - Hardened and ground gears, running in an oil bath Cgjlq Eeixmlfsg Tqjt - Good gliding ability of the drill head on the boom - sanded surface Scope of delivery: - Cube table - Drill chuck arbor MK 5 / B 16 - Reducing sleeves MK 5/4, MK 4/3, MK3 / 2 - LED machine light - First filling with Shell Tellus 46 - coolant device - lifting motor - hydraulic motor - operating tool - Height-adjustable protective cover

Condition: good (used), Manufacturer : MAS Cgolq Egsh Eigbo Tqjt Type : VR 4 throat : 1000mm without table!

Condition: new, Year of construction: 2025, A large and stable radial drilling machine with a large range of revolutions which ensures precise and fast machining. Machine features Large weight and sturdy design ensure stability and vibration-free operation Cube table provides adjustability and easy fixture of workpiece Control panel located at the front of the machine for improved convenience Ground column surface provides easy, precise arm travel Cjlqsi D Daqe Eg Tqegt Machine equipped with manual head and column arm limiter Large speed range for accurate and quick machining Technical data Maximum drilling diameter 32 mm Distance from spindle to base 340–1125 mm Distance from spindle axis to column surface 330–890 mm Spindle extension 215 mm Spindle taper MK4 Spindle speed 75–1200 rpm Spindle speed ranges (6): 75, 130, 240, 380, 660, 1200 rpm Spindle feed (3) 0.10; 0.16; 0.25mm/turn Horizontal plane rotation angle 180° Main motor power 2.2 kW Worktable dimensions 500×330×294 mm Machine dimensions 1400×660×2100 mm Weight 950 kg The price is a net price. Price does not include shipping costs. For more information, please contact us by phone or e-mail. We invite you to familiarize yourself with the offer on our website.

Condition: used, Year of construction: 1974, Bohrleistung in Stahl (-Ø 35 mm throat 1000 mm Cjlq Egjtv Igto Tqsgt workpiece height max. 200 - 1400 mm height adjustment 745 mm base plate surface area 1200 x 930 mm Bohrspindel-Ø/ Aufnahme 90 mm / MK 4 bore spindle stroke 350 mm turning speed range 60 - 1850 U/min feed range 0,09 - 1 mm/U power capacity 3,7 kW weight of the machine ca. 3,7 t dimensions of the machine ca. 2,1 x 0,9 x 3,3 m Cube table 800 x 800 x 650 mm Coolant device

Condition: repair required (used), Witzig & Frank high-speed radial drilling machine LEO 32 AS Cgolq Egetrnr Te Tqst Defects: (Clamping no longer works, running noises present)

Condition: used, Radial drilling machine WEBO type R4bR No. 15 / E195 Year of manufacture approx. 1965 Drilling capacity 40 mm Colju T Ty Hsq Eg Tqjgt throat depth: approx. 1250 mm Spindle holder: MK 4 Spindle speed: 30 - 1325 rpm. 9 steps Feed rate from 0.12 - 2 mm/rev. 9 steps

Condition: good (used), Collet / Gamesa - Radial drilling machine / Can be used mobile using a crane -Boom approx. 1200mm -Universal angle head with multiple angle adjustments -Spindle speed 95 - 750 rpm -Automatic feeds -Morse taper MK4 -Boom height adjustable approx. 1400mm -Retrofit control cabinet Cslqevucbhe Eg Tqsgt Dimensions: LxWxH 2x1x2.1 meters / Weight 1500Kg Errors / input errors reserved

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW weight of the machine ca. 3.700 kg Cslq Eet H Smysg Tqogt dimensions of the machine ca. m

Condition: new, Technical data: Drilling capacity steel Ø: 50 mm Drilling capacity cast iron Ø: 60 mm Tapping steel Ø: 40 mm Tapping capacity cast iron Ø: 50 mm Cgolq Eop Atipsg Tqot Diameter of the column: 300 mm projection (min/max): 305 - 1275 mm travel of the spindle head (horizontal): 970 mm distance spindle nose - base plate (min/max): 438 - 1330 mm Traverse height of the cantilever: 625 mm Clamping surface of cube table : 635 x 520 x 420 mm size base plate : 1830 x 785 x 185 mm spindle mounting: MK 5 spindle stroke: 270 mm Speeds: (12) 44 - 1206 min-1 feeds: (3) 0.06 / 0.10 / 0.20 mm/rev. Motor power, approx.: 3,7 kW Total height, max.: 2795 mm Weight, approx.: 2300 kg Features: - Simple one-button operation with integrated circuit for automatic release of swing arm movement, automatic stop and automatic clamping. - Boom arm and drill head with independent hydraulic clamping. - A special lift safety device prevents the arm from falling off abruptly or moving on its own, even after a long period of use and corresponding wear. This safety device protects the operator from injury even if the threaded nut is excessively worn. - The column, arm and gearbox can be clamped simultaneously by pressing a button. Standard Equipment: - Threading device - Coolant device incl. pump - machine light - cube table 635 x 520 x 420 mm - Operating tools in box - Operating instructions and spare parts list - protection device for spindle - CE

Condition: used, Year of construction: 1983, Bohrleistung in Stahl (-Ø 50 mm throat 1500 mm workpiece height max. 1380 mm Bohrleistung in Guß (-Ø 60 mm Cgolq Egstv Iklo Tqet Abstand Spindelmitte bis Säule 320 - 1250 mm swival range +/- 180 ° base plate surface area 2640 x 1000 mm max. torque on the spindle 310 Nm Bohrspindel-Ø/ Aufnahme 75 mm /MK 5 bore spindle stroke 310 mm spindle turning speed range 28 - 2500 U/min feed: 0,05 - 2 mm/U power capacity 4 kW weight of the machine ca. 4,3 t cube table 500 x 500 x 500 mm

Year of construction: 1986, Condition: good (used), Radial drilling machine WMW Heckert from liquidation Model BR 40/2x1250 Year of manufacture 1986 MK 5 recording Pinol stroke 355mm Throat 300-1250mm Speeds from 20-1200 rpm infinitely variable 3 gears-- pole-changing engine-- Rev counter Cgolefnh T Tjq Eg Tqet Thread cutting function automatic feed 0,063---0,1--0,16--0,25--0,4--0,63 Coolant pump Work light distance spindle - base plate 280-1380mm motor-driven height-adjustment electrical clamping with clamping cube 3,5 Kw Engine power Weight 3to. Space requirement approx. 2760x2030x900

Condition: used, Manufacturer: Breda Type: R1200L 30-40 Technical data: Projection: 1200 mm Spindle holder: MK4 Quill stroke: 180 mm Spindle speed: 2 - 2000 rpm. Clamping cube: 460 x 550 x 500 mm (LxWxH) Flat floor plate: 1100 x 500 mm (LxWxH) Colqet A Azaj Eg Tqegt Main switch and 2 emergency stop foot switches Long connection cable with 16A plug Country of origin: Italy Space requirement: 1750 x 640 x 2100 mm (LxWxH) Machine weight: approx. 1450 kg The machine can be demonstrated under power on site. All data without guarantee Subject to errors and prior sale

Condition: used, Year of construction: 1983, bore capacity in steel (diameter) 60 mm arm length 2000 mm workpiece height max. 1790 mm bore capacity in cast iron 70 mm spindle turning speed range 28 - 1250 U/min spindle taper MT 9 spindle stroke 330 mm feed range - spindle 0,1 - 1,12 mm/U horiz. adjustment of drilling head 1540 mm base plate 1840 x 1000 mm spindle drive 7,5 kW stroke drive 3 kW voltage 500 V / 50 Hz total power requirement 11,2 kW Celq Eg Tstv Immeqegt weight of the machine ca. 5,5 t dimensions of the machine ca. 3,3 x 1,1 x 3,1 m electr./hydraulic column clamping, cube table 500 x 600 x 500 mm, coolant device
