Jig boring machine

Oerlikon KB3

Condition: used, Year of construction: 1999, operating hours: 65,090 h, functionality: fully functional, ET365 GS with bar feeder and chip conveyor The machine is fully equipped - Collection tray - High-pressure pump - Control cabinet air-conditioning unit Podpeycvaqjfx Abgerb - Kupa loader - The machine was purchased from a running production operation and has been technically inspected - Geometry measured and all settings adjusted - Wearing parts replaced - All functions checked and adjusted as required The machine is fully operational and ready for immediate production The machine is available immediately

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 3,750 mm, travel distance Y-axis: 1,870 mm, travel distance Z-axis: 700 mm, total length: 9,000 mm, table length: 4,000 mm, table width: 1,650 mm, total width: 3,500 mm, spindle speed (max.): 6,000 rpm, total height: 3,500 mm, distance between stands: 2,300 mm, rotational speed (max.): 6,000 rpm, overall weight: 30,000 kg, Equipment: rotational speed infinitely variable, X-axis: 3.750 mm Podeyac T Eopfx Abgsrb Y-axis: 1.870 mm Z-axis: 700 mm CNC Controller: Heidenhain iTNC 530 Spindle nose: ISO 50 Spindle speed: 6.000 Rpm Toolchanger: 30 pockets Table size: 4.000 x 1.650 mm Distance between columns: 2.100 mm Featured with: - Vertical milling head attachement - Touch probe - Cooling throught spindle - Double chip conveyor - Cooling unit - Machine manuals Country of origin: Taiwan Machine LxWxH: 9000 x 3500 x 4000 mm +/- Machine weight: 30.000 kg

Condition: repair required (used), Year of construction: 2016, operating hours: 90 h, functionality: limited functionality, fuel type: diesel, power: 44 kW (59.82 HP), nominal power: 44 kW (59.82 HP), continuous power: 44 kW (59.82 HP), continuous power (apparent): 55 kVA, Diesel Generator ETT-55E (55 kVA) for Sale Condition: Used. The cooling pump is not working and oil is entering the engine; the oil pump needs replacement. Otherwise in technically good condition. We can start the unit for demonstration. A brand new fuel pump is included in the offer. Manufacturer: ETT – Electrotech Dış Ticaret ve Tekstil Ltd., Turkey. Reliable three-phase diesel generator with automatic control panel and soundproof enclosure. Suitable for both backup power supply and continuous industrial or construction site use. Technical specifications: Model: ETT-55E Predpfoxlngaox Abgsb Operating hours: 90 h Output (Standby): 55 kVA / 44 kW Output (Prime): 50 kVA / 40 kW Engine: Ricardo K4100ZDS (diesel, 4 cylinders, water-cooled) Alternator: WHI224D, brushless, with Automatic Voltage Regulator (AVR) Voltage / Frequency: 400 / 230 V – 50 Hz Current: 79 A Power factor (cosφ): 0.8 RPM: 1500 rpm Cooling: Water Fuel consumption: ~10 L/h (at 100% load) Fuel tank capacity: 260 L (up to 8 hours continuous operation) Dimensions (LxWxH): 2250 × 1000 × 1500 mm Weight: 1100 kg Year of manufacture: 2016 Country of origin: Turkey Controls and features: Automatic DATKOM DKG309 control module Emergency stop button Fuel level, oil pressure, temperature, and voltage sensors Battery charging system Automatic transfer switch (ATS) for mains/generator control Overvoltage, overload, and low oil pressure protection Soundproof enclosure – reduced noise levels Manual or automatic operating mode Typical applications: Suitable for: - Industrial facilities, warehouses, production plants - Construction sites and mobile workplaces - Backup power for hotels, hospitals, office buildings, or farms A reliable solution for stable and uninterrupted power supply. Feel free to contact us if you have any further questions.

Condition: used, Technical details: honing diameter: Ø 400 mm stroke: 600 mm throat: 390 mm table-size: 1.550 x 780 mm table surface area: 1.400 x 480 mm table:: fest total power requirement: 4,1 kW Weight approx.: 2,8 t dimension machine xH: 2,0 x 1,2 x 4,35 m Further technical details: - longitudinal travel of machine table approximately 500mm - cross travel of machine table approximately 200mm - working height 350mm (non-adjustable) - distance column / table 0 - 200mm Equipment: - oil tank Ø 300 x 600mm - control panel i.D. * Pjdsu Ngybepfx Abgsrb

Condition: good (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 81362, travel distance X-axis: 305 mm, travel distance Y-axis: 305 mm, travel distance Z-axis: 330 mm, rapid traverse X-axis: 48 m/min, rapid traverse Y-axis: 48 m/min, rapid traverse Z-axis: 48 m/min, controller model: Fanuc 18i-MB, total height: 2,200 mm, total length: 3,300 mm, total width: 2,000 mm, table width: 250 mm, table length: 250 mm, overall weight: 4,600 kg, spindle speed (max.): 15,000 rpm, number of spindles: 1, number of slots in tool magazine: 40, Equipment: chip conveyor, documentation/manual, Kitamura Mycenter HX250iF, year 2011 Serial number: 81362 *Main spindle bearings replaced 07/2026 - CNC control unit: Fanuc 18i-MB - Spindle power: 11.2 [kW] - Spindle speed: 15000 [rpm] - Travels in X/Y/Z axes: 305 / 305 / 330 [mm] - Rapid traverse (X/Y/Z): 48 [m/min] - Number of tool positions: 40 - Tool holder type: BT30 - Tool change time: 1.2 [s] - Pallet size: 250 x 250 [mm] - Number of pallets: 2 - Maximum weight per pallet: 110 [kg] - Distance center of table/top of spindle: 380 [mm] - Machine dimensions: 3,300 x 2,030 × 2,300 [mm] - Machine weight: 4,600 [kg] Equipment - Manual command - 3-color status light - Coolant tank with high-pressure pump - Oil mist extractor - Chip conveyor - Spindle cooling unit - Renishaw 3D probe - Renishaw tool measurement - Transformer - Approx. 150 tool holders Psdpfx Aoxur E Sobgsrb

Condition: good (used), Year of construction: 1970, Ref. -No.: 10575 Manufacturer: VDF BOEHRINGER Type: T 11 Year of construction: 1970 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Germany Machine-No.: 40XXX Turning Diameter: Ø 700 mm Pedpfoxmd Uvjx Abgorb Turning Length: 3000 mm Spindle Diameter: Ø 750 mm Spindle Bore: 70 mm Swing diameter over cross slide: Ø 450 mm

Condition: ready for operation (used), Year of construction: 1983, functionality: fully functional, machine/vehicle number: 8151, rotary table diameter: 800 mm, grinding height: 750 mm, workpiece weight (max.): 800 kg, total height: 4,100 mm, total width: 26,650 mm, total length: 44,000 mm, feed length Y-axis: 750 mm, feed length Z-axis: 550 mm, overall weight: 13,000 kg, grinding wheel diameter: 400 mm, disc diameter: 400 mm, grinding spindle speed: 1,460 rpm, grinding diameter: 800 mm, control cabinet width: 650 mm, type of input current: DC, control cabinet height: 1,900 mm, control cabinet length: 1,800 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 1,460 rpm, table load: 900 kg, workpiece diameter (max.): 850 mm, grinding wheel width: 60 mm, table width: 1,240 mm, power: 35 kW (47.59 HP), rapid traverse X-axis: 2 m/min, rapid traverse Y-axis: 100 m/min, rapid traverse Z-axis: 2 m/min, space requirement height: 4,100 mm, space requirement length: 5,100 mm, space requirement width: 2,655 mm, Good day, For sale is a well-preserved and completely functional Sielemann cylindrical grinding machine for the following applications: surface grinding, internal grinding and external grinding. The machine has a swivel stand with 3 different sanding heads for the respective area of application. Complete machine documentation is available and can be presented upon inspection. The Sielemann offered here has always been serviced and maintained, most recently the components listed below were replaced: - 3x New weight compensation cylinders - 1x new hydraulic unit (complete) - New guideway covers - Revised rotary table group Technical data Machine length: 4.400mm Machine width: 2,655mm Machine height: 4.100mm Machine weight: 13.000Kg Control cabinet width: 650mm Control cabinet height: 1.900mm Control cabinet length: 1.800mm Grinding table diameter: 800mm Grinding table load capacity: 800kg Grinding table drive power: 0.21 - 14.5KW Grinding table speed: 100 1/min (both directions) Grinding table workpiece clamping: Magnetic clamping plate incl. T-slots Z-axis travel (grinding table): 550mm Maximum grinding height (Y): 750mm Lubrication pump Masch. Bed: 0,18KW Lubrication pump Masch. Column: 0,1KW Leak oil pump: 0,065KW Podpfx Abjrntirogerb Hydraulic pump: 1.5KW 1) External round grinding head Spindle drive power: 11KW Spindle speed: 1,450 1/min Grinding wheel: 400x50mm Cone grinding spindle mount: D=65mm Taper pitch: 1:5 Feed speed (Y): 100 mm/min 2) Internal round grinding head Spindle drive power: 5.5KW Grinding wheel: Variable Feed speed (Y): 100 mm/min 3) Flat-round sanding head Spindle drive power: 11KW Spindle speed: 1,800 1/min Grinding wheel: 400x50mm Cone grinding spindle mount: D=65mm Taper pitch: 1:5 Feed speed (Y): 100 mm/min Viewing appointments possible at short notice by arrangement !!! With kind regards R.Suckow / Managing Director UNITTOOL Werkzeugmaschinen GmbH 33758 Schloß Holte Stukenbrock Görlitzerstraße 9

Condition: good (used), Year of construction: 1983, Machine number: 316204/22 Type / Model: FSS 315/E Travel ranges x-y-z: 850 – 280 – 355 mm Table: 1,200 x 370 mm Clamping area: 1,060 x 260 mm Speed range: 28 to 1,400 rpm Spindle mount: SK 50 Quill stroke: 80 mm Feeds for x and y axes: 16 to 800 mm/min Feed for z axis: 5 to 250 mm/min Power: 8 kW Psdefli Afepfx Abgjrb Accessories/Equipment: Head swivels Condition: good Weight: 4 t Dimensions: 2,000 x 2,000 x 2,400 mm

Condition: good (used), Year of construction: 1954, Ref. -No.: 10576 Manufacturer: VDF WOHLENBERG Type: VDF Year of construction: 1954 Type of control: Konventionell Control: n/a Pjdpfx Aexmd U Ajbgsrb Storage location: Halberstadt Country of origin: Germany Machine-No.: 27XXX Turning Length: 4000 mm Spindle Diameter: Ø 80 mm Faceplate Speeds I: 355 RPM Turning diameter over cross slide: Ø 1000 mm Max. Turning diameter: Ø 1250 mm

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, Swing over bed 1,300mm, over cross slide 1.000mm, swing in gap 2,100mm, center distansen 1,500mm, 2,350mm with open bed. Spindle bore 128mm, 450 Rpm, 50 Kw, Chuck 800mm, 4-jaw plate 900mm. Fagor CNC, weight ca 12.000kg Pedpfoxqp I Njx Abgjrb
