Used other measuring equipment for sale (107)

Year of construction: 2018, condition: used, 4-axis CNC measuring machine, additional CNC axis and laser sensor for measuring the outer contour and for generating 3D point clouds. Contactless full measurement of precision tools, microtools, grinding wheels, rotationally symmetric parts and flat parts. Microtools with diameter from 0.1 mm can be measured with high precision. Certified accuracy E1 = (1.8 + L/300) μm and repeatability ≤ 1.5 μm. Accessories: Full enclosure, ISO 50 adapter spindle, Automatically actuated hydrodew-spannfutter, Machine software: 3D tool analysis, 3D matcher, Helitronic Toolstudio, Viascan, DXF generator, Viafit, Control panel with stand, 22" touchscreen, keyboard and mouse. Traverse X-axis: 270 mm X axis travel: 270 mm Z-axis travel: 325 mm Y axis travel: 455 mm Y-axis travel: 455 mm Bjdpfx Aeygl Avsaqslc A-axis: 360° Length measuring accuracy E1 value E1: (1.8 + L/300) μm A axis: 360 ° Measurement resolution: 0.25 µm Length measurement accuracy E1 value E1: (1.8 + L/300) µm Position resolution for all linear axes Y, Z: 0,02 µm reading resolution: 0.25µm max. workpiece length: 420 mm mass: 1200 kg max. workpiece weight: 25 kg Magnification transmitted light camera: 1:50 gear Connected load approx.: approx. 1.5 kVA (230 V / 50 Hz) Dimensions W x D x H approx.: 1117 x 1390 x 2012 mm Weight: approx. 1200 kg colour: gray RAL 9003, gray RAL 7011

Year of construction: 2019, condition: ready for operation (used), This Nikon V-12BDC was manufactured in 2019. It features a 305 mm screen diameter, a measuring stage of 250 × 150 mm, and integrated XY and angle digital displays for precise measurements. The machine includes a 3-position objective turret for quick magnification changes and high-quality halogen illumination for clear imaging. Ideal for production control and precision mechanics. Contact us for more information about this machine. • Laterally correct image (no reflection) for easy evaluation • 3-position objective turret for quick magnification selection • Magnifications: 10×, 20×, 50×, 100× • Screen diameter: 305 mm • Measuring stage travel: 250 × 150 mm (8" × 6"); rotary stage type 2 • Maximum workpiece height: 100 mm • Integrated XY and angle digital display for precise readings • Illumination: combination of contour (transmitted) and vertical (incident) light Bedsx D I Etopfx Aaqelc • Light source: 24 V / 150 W halogen for high-quality projection • 4-fold condenser in transmitted light with automatic illumination adjustment to magnification • Optics: semi-transparent mirror for clear incident-light image; telecentric lenses for distortion-free imaging across the full field • Focusing via movable optical head (stage remains stable to avoid measurement deviations) • Measurement accuracy: contour illumination ±0.1%; inclination/area illumination ±0.15% • Solid construction with precision-engineered guides; workshop-ready and easy to operate • Proven Nikon quality, made in Japan • Large projection area suitable for medium-sized and complex workpieces • Quick magnification changes via turret • Ideal for production control, toolmaking, precision mechanics, and sample inspection • Flexibly upgradeable with digital interfaces or SPC connectivity

Year of construction: 2016, condition: ready for operation (used), This KEYENCE IM-6025 optical measurement machine was manufactured in 2016. It features a comprehensive set of components including a measuring head, control unit, glass plates, software, clamping device, glass scale, barcode scanner, lighting, and styli. Consider the opportunity to buy this KEYENCE IM-6025 optical measurement machine. Contact us for more information about this machine. Additional information • Measuring head with 200 × 200 mm measuring field • Multi-angle illumination with photoelectric sensor • Digital measuring projector • Control unit • AC power cable • Mouse and keyboard • Rotary unit (for IM-8000) • Glass plates • Clamping device • Glass scale • Barcode scanner • Lighting Bljdpfx Aasyf Du Ueqjc • StyliOptional Accessories: • Test probe sets: 80 pcs, range 0.3–0.99 mm • Test probe sets with handles: 350 pcs, range 0.4–4 mm • Gauge sets: 800 pcs, range 4–12 mm • Limit plug gauges: 265 pcs, range 1–43 mm • Setting rings: 50 pcs, range 0.6–47 mm • Thread plug gauges: 170 pcs, range M1–M24 and various inch threads • Thread ring gauges: 265 pcs, range M1–M63 and various inch threads • Micrometers: 70 pcs, range 0–150 mm (analog and digital)Availability: • 2 units availableOptional: Comprehensive package of measuring instruments

Year of construction: 2011, condition: ready for operation (used), This KEYENCE IM-6020 optical measurement machine was manufactured in 2011. It includes a measuring head, control unit, glass plates, software, clamping device, glass scale, barcode scanner, lighting, and styli. Consider the opportunity to buy this KEYENCE IM-6020 optical measurement machine. Contact us for more information. (Two units are available) Additional Information • Measuring head with 200 × 200 mm measuring field • Multi-angle illumination with photoelectric sensor • Digital measuring projector • Control unit • AC power cable • Mouse and keyboard • Rotary unit (for IM-8000) Optional Accessories: Bodsyfft Sepfx Aaqslc • Test probe sets (80 pcs, 0.3–0.99 mm) • Test probe sets with handles (350 pcs, 0.4–4 mm) • Gauge sets (800 pcs, 4–12 mm) • Limit plug gauges (265 pcs, 1–43 mm) • Setting rings (50 pcs, 0.6–47 mm) • Thread plug gauges (170 pcs, M1–M24 and various inch threads) • Thread ring gauges (265 pcs, M1–M63 and various inch threads) • Micrometers (70 pcs, 0–150 mm, analog and digital) Availability: • 2 units availableOptional: Comprehensive package of measuring instruments

Year of construction: 2023, condition: ready for operation (used), This KEYENCE IM-8020 optical measurement machine was manufactured in 2023. It features a comprehensive set of components including a measuring head, control unit, glass plates, software, clamping device, glass scale, barcode scanner, lighting, and styli. Consider the opportunity to buy this KEYENCE IM-8020 optical measurement machine. Contact us for more information. Additional information • Measuring head with 200 × 200 mm measuring field • Multi-angle illumination with photoelectric sensor • Digital measuring projector Bjdpfxjx D Dl Ne Aaqolc • Control unit • AC power cable • Mouse and keyboard • Rotary unit (for IM-8000) • Glass plates • Software • Clamping device • Glass scale • Barcode scanner • Lighting • StyliOptional Accessories: • Test probe sets: 80 pcs, range 0.3–0.99 mm • Test probe sets with handles: 350 pcs, range 0.4–4 mm • Gauge sets: 800 pcs, range 4–12 mm • Limit plug gauges: 265 pcs, range 1–43 mm • Setting rings: 50 pcs, range 0.6–47 mm • Thread plug gauges: 170 pcs, range M1–M24 and various inch threads • Thread ring gauges: 265 pcs, range M1–M63 and various inch threads • Micrometers: 70 pcs, range 0–150 mm (analog and digital)Optional: Comprehensive package of measuring instruments

Condition: excellent (used), For sale: precision ORION dial micrometer with a measuring range of 0–25 mm and accuracy of 0.001 mm. Mounted on a robust cast iron stand for stationary operation—an ideal set for dimensional control in a factory, toolroom, workshop, or metrology laboratory. Micrometer technical specifications: • Range: 0–25 mm • Accuracy: 0.001 mm • Dial readout – fast and unambiguous readings Blsdpfxow Rdgno Aaqsc • Precision engineered – solid head, stable micrometric scale • Brand: ORION (renowned manufacturer of measuring instruments) Measuring stand: • Stable cast iron base • Two-point adjustment • Enables repeatable measurements without handheld operation Set ready for use Very good condition – well-maintained, fully functional, smooth and precise measurements

Year of construction: 2002, condition: used, x-travel 210 mm z-travel 350 mm max. loading 25 kg Distance C/Z-axis (mm) 270 mm max. test diameter (mm) 300 mm Rotation axis C (turntable) 0° 90° 180° 270° diameter of rotary table 150 mm Measuring path R-axis 170 mm required space L2,0 x B0,8 x H0,82 m Scope of delivery: - Form measuring system F1004/350 - Work table - Rotary table (rotation axis C) - All documentation - Software TURBO FORM 8.21 + licences - Accessories (see pictures) Condition: - As good as new - Functional Maintenance: Blsdpfx Aorxxc Hoaqoc - Last inspection on 03/08/2021 - Test report from Jenoptik available

Condition: used, LB 326 - glass scale Length: 8500mm HEIDENHAIN LB 326 ID 249 942 01 Blodpjr I D Imofx Aaqsc

Year of construction: 2003, condition: used, functionality: fully functional, machine/vehicle number: SN.: 19-03-028, Granite sub-table with pneumatic level compensation, including subframe with 3 drawers, from Integrated Dynamics Engineering. Year of manufacture: 2003. Serial no.: 19-03-028. Length: 80 cm, width: 80 cm, height: 86 cm including subframe. Blodsya Dttopfx Aaqsc

Year of construction: 2023, operating hours: 2 h, condition: used, machine/vehicle number: 5767/78631, Axle distance: approx. 40-175 mm, max. test piece diameter: approx. 200 mm, net weight: approx. 110 kg, adjustable measuring force: approx. 1-11 N, power consumption: approx. 0.2 kW, control/switch FRENCO, serial number: 30020-000147, various measuring accessories, 1 operating panel, single-track/single-door, 1 DELL flat screen, approx. 22 inches, year of manufacture: 2022 Bodsx Aklmepfx Aaqelc

Year of construction: 2021, condition: used, machine/vehicle number: 2150801, max. clamping length: approx. 60 cm, with darkening cabin Bledpex Akkcjfx Aaqoc

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 430 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 400 mm, number of axes: 3, This 3-axis ZEISS ScanMax was manufactured in 2008. It features a travel range of 430 x 850 x 400 mm and can handle a workpiece weight up to 50 kg on its standard base frame or 20 kg on the rotary tilt table. The machine's overall dimensions are 640x1057x2080 mm. If you are looking to get high quality measuring capabilities consider the ZEISS ScanMax machine we have for sale. Contact us for more information. • Permissible workpiece weight with standard base frame: 50kg • Permissible workpiece weight with rotary tilt table: 20kg Bljdpfx Aasyab Aroqsc • Max. probe length: 300mm • Weight of components: • Appliance: 60kg • Underframe: 315kg • Electronic unit: 25kg • Rotary tilt table: 12kg • Overall dimensions (LxWxH): 640 x 1057 x 2080 mm

Condition: good (used), Year of construction: 2021, functionality: fully functional, Fischerscope X-RAY XDL 230 coating thickness gauge, year of manufacture 2021, X-ray fluorescence measuring device for determining thin coatings and for bath analysis, top-down measurement direction, tungsten tube, manual XY-table 95x150 mm, support surface 420x450 mm, electrically adjustable Z-axis 140 mm, laser pointer for positioning assistance, all documents available: test certificates, manual Bodpfxeygirno Aaqslc

Condition: good (used), Angle bracket, locksmithsquare, flat angle -Flat angle: Leg length 1000 x 660 mm -Number: 2x flat angles available -Price: per piece -Dimensions: 1000/660/H12 mm Bjdjx Tpdlopfx Aaqelc -Weight: 10 kg/pc.

Condition: good (used), Stop square, locksmithsquare, hair square, precision hair square, control square -Manufacturer: Horex, stop square DIN 875/2 -Type: 1000 x 500 mm -Accuracy level: 2 -Quantity: 5x angle brackets available -Price: per piece -Dimensions: 1010/500/H50 mm Bedpex Tn U Nefx Aaqelc -Weight: 7 kg/pc.

Condition: excellent (used), Microscope Magnifying glass Make Hartmann ACCU type Lux 20 times magnification in wooden box with instruction manual Bsded Iacwepfx Aaqslc

Condition: used, 8 Multi wedge profile plug gauges in wooden boxes Blodoctiwiopfx Aaqec L 4734-44

Condition: used, Bar fine pointer Passover meters Make Zeiss Jena 0-25 mm Bledpfxjda Abaj Aaqjc in the wooden box

Year of construction: 2018, condition: like new (used), Thermal sensor Transmitter Make Jumo Bledpfefgwmbsx Aaqjc unused Type PT 100 Number : 902102/10 00055514 0128409001008450005 Immersion tube stainless steel Weight 1 kg Total length 570 mm Immersion length 470 mm with mounting CH 512032 Age estimated

Condition: used, Tool measuring instrument Make Mitutoyo Bedpoddtuysfx Aaqolc Type quick set R

Year of construction: 2010, condition: excellent (used), Measuring column in suitable transport box Height 500 mm diameter 120 mm Weight 37 kg Bodpfefdzvasx Aaqjlc

Condition: excellent (used), Shrinkage Caliper gauge Bsdpfefhkdtox Aaqelc Make Preisser Measuring length 300 mm Shrinkage : 1,75% , 2% , 2,5

Condition: like new (used), Outside micrometer Bodpfxegt U Tpe Aaqslc Make Steinmeyer 400 - 425 mm in wooden case

Condition: used, Micrometer hanger Mass 475 - 500 mm Bljdpoby Rggsfx Aaqec in wooden case

Condition: used, Optics Bljdpjcifpmefx Aaqoc Make Heidenhain Type OZA II 02 - 6 Device number 2739 Mounting distance 14,30
