Coordinate measuring machines for sale
2
Control UCC lite-2
Muo2t8
Measuring range 700 x 450 x 350 mm
Measuring heads (MH20i, PH1, PH6)
Various touch probes
table length 1200 mm
Bnp72ugzzu
table width 1000 mm
daylight mm
measuring range X-axis 900 mm
measuring range Y-axis 1200 mm
measuring range Z-axis 600 mm
total power requirement kW
weight of the machine ca. 4,00 t
dimensions of the machine ca. 3,50 x 2,50 x H3,80 m
3
table length 0 mm
table width 0 mm
daylight mm
H9jq0x3wm
total power requirement kW
weight of the machine ca. t
This mobile system is based on two CCD cameras with high resolution, which record the manual probing of an object, and on the basis of the known geometry of the lightpen (a measuring probe equipped with light emitting diodes) 3D nodes are automatically assessed and evaluated.
Typical uses are for the geometrical examination of devices, adjustment of pressing and stamping tools, ...
1
table length 6000 mm
table width 3000 mm
daylight / mm
Bjsa8ywuk3
TECHNICAL SPECIFICATION
- x-Axis 6000 mm
- y-Axis 1600 mm
- z-Axis 2400 mm
- table surface (left-right) 7000 mm
- .. width 3000 mm
8
table length 900 mm
table width 750 mm
Control CMMC-5
complete with pc and button
Control: CMMC-5
O9qr9
Table LxW: 900x750 mm
DIMENSION
Length: approx. 1100mm
Width: approx 850mm
Height: approx. 2100mm
15
Coordinate Measuring Machine
Manufacturer: ZEISS
Type: PRISMO 9/12/7MPS
Year of manufacture: 2000
Technical data (estimated values):
Y-travel: approx. 1000 mm
X-travel: approx. 1500 mm
measuring plate dimensions: 1520 x 1025 mm
Operating hours: 32674,8
With EDP, various measuring probes and accessories
With technical documentation
Total dimensions: 2000 x 1700 x 3060 mm
B0vcf8zaqv
Total weight: 2500 kg
4
Measuring range and pushbutton, see pictures
Bfiy7wamnv
2
x-travel 250 mm
y-travel 200 mm
z-travel 200 mm
Control VMA AutoMeasure Software
workpiece weight max. 15 kg
Gvtjzxix
total power requirement kW
weight of the machine ca. 0,123 t
dimensions of the machine ca. 1,31 x 1,79 x 1,96 m
Included:
VMA 3CCD Color Progressive Scan Camera
VMA zoom head
VMA Ring LED ring lighting
VMA projection lens
VMA calibration standard
POWER CORD E for 220-240V
VMA vibration damper with AI plates
VMA underframe on castors
iNEXIV VMA Profiler & CAD Reader
NEXIV EDF...
4
table length 1160 mm
table width 710 mm
Hpomhdl
daylight 650 mm
Control WENZEL ME 5007
total power requirement kW
weight of the machine ca. 800 kg
dimensions of the machine ca. m
3-D-coordinate measuring machine with METROLOG II-Software
8
x-travel 457 mm
y-travel 508 mm
Dkts2vytm
z-travel 406 mm
total power requirement kW
weight of the machine ca. t
dimensions of the machine ca. m
9
Little used measuring machine.
Rarely used since last calibration. As good as new condition.
X:600mm
Y:700mm
Z:500mm
Bwqaxtsntb
Measuring accuracy: 1.5um +L/500
Measuring software: Arco CAD
LxWxH: 1424x2105x2970
2400Kg
excl. Erowa UPC chuck
LEITZ REFERENCE XE 7.5.5
Coordinate measuring machine and gear measuring center
Year of manufacture: 2014
Machine number: 495
Measuring range (X/Y/Z): 700 mm x 500 mm x 500 mm
Equipment:
Controller B5, Reference Line
Desk stand
Control desk with potentiometer
Leitz LSP-X3c, Reference 7.5.5
Stylus changing device, LSP-X3
Stylus rest, LSP-X3
Stylus holder, LSP-X3
Standard stylus set, LSP-X3
Calibration ball, Ø 30 mm, ceramic, with stand
Dell Desktop Precision T3610 High
Preconfiguration Computer S...
4
CONTROLS
.. CNC controls
TECHNICAL SPECIFICATION
.. x-Axis: 1200 mm
.. y-Axis: 2000 mm
.. z-Axis: 1000 mm
ELECTRICAL SPECIFICATIONS
.. mains voltage: 400 V
.. mains frequency: 50 Hz
Measuring system: Motorized rotary/swivel head PH10H with probe system TP200 and SP600M, probe rack Reck for CNC probe change, 13 probe modules of which 4 are new.
Accessories: perforated plate, office table, transport locks, Bilz oscillating damper system.
Software: MCOSMOS-3 version 4.2 and CAT1000 for Widos 1...
4
Sell Garant measuring microscope MM01 X200mm Y100mm
B02cw93skw
3
table length 200 mm
table width 200 mm
Bjxz0hrklf
daylight 200 mm
Control MAHRSOFT
total power requirement kW
weight of the machine ca. 300 kg
dimensions of the machine ca. 1000 x 1000 x 1950 mm
Measuring Machine with optical-, Laser and Mechanical Feeler
3
Catalog No. : 5461
Type: PMM 12 10 6
Producer: Leitz
Made in: 1999
Characteristic:
Axis X/Y/Z: 1200/1000/600 mm
Maximum table load: 1200 kg
H3qj3rwda
Machine height: 3800 mm
Machine length: 3500 mm
Machine width: 2400 cm
Machine weight: 6 t
Equipment:
Technical books
Automatic exchange of measuring touch (7 positions - including various touches)
Ref. -No.: 10157
Brand: CARL ZEISS
Type of control: HP 9000 Serie 700
Control: Betriebsystem HP-UX.9.05
Storage location: Halberstadt
Country of origin: Deutschland
Turntable: 1000x2100 mm
Machine weight: 4.800 kg
Machine Height: 3050 mm
Table height above the floor: 850 mm
X-Axis: 850 mm
Y-Axis: 1800 mm
Z-Axis: 600 mm
Further information:
Microcomputer control
X-axis as a longitudinally movable portal
Y-axis cross slide in the portal
Z-axis as measuring head quill (vertical)
Passage bet...
10
misc. spareparts, electronic cards, motors and gear boxes, power
supplies, cables, DRO, etc.
Nllv7
More details on request!
3
table length / mm
table width 3000 mm
daylight / mm
TECHNICAL SPECIFICATION
- x-Axis 6000 mm
- y-Axis 1600 mm
- z-Axis 2100 mm
Bjsa9chz87
- table surface (left-right) 6000 mm
- .. width 3000 mm
Last Overhaul: 2017
6
x-travel 800 mm
y-travel 600 mm
z-travel 200 mm
table-size 800x400 mm
Stde7o
total power requirement kW
weight of the machine ca. 3,0 t
dimensions of the machine ca. 3,0x2,0x2,0 m
with increased accuracy
with contact and optical measuring device
only 790 hours of operation
3
table length:2000 mm
table width:1000 mm
Y7ndu79bh
weight of the machine ca.:2,9 t
Novalyth stone table with integrated T-groove, Grundig MZ 1030 measuring computer, 5 height-adjustable feet.
9
Technical data
XYZ 640x750x500 mm
Complete with dongle and 5 probes
Cls8qb7
probe Renishaw PHC 10 - 2
and software, computer WPC 2030
dimensions 1800x1200x2450
4
3 D measuring machine Zeiss Vista year 2005
Ewdeezh
Measuring range in X=400, Y=500 and Z=350 mm.
Touch probe system
Various probes, as well as PC etc.
Optically and technically the Vista is in a perfect condition, as calibration 2021.
7
table length 5.900 mm
table width 3.640 mm
Pgyi9
x-travel 2.500 mm
y-travel 5.000 mm
z-travel 1.500 mm
weight of the machine ca. 870 kg
dimensions of the machine ca. 5.900 X 3.640 X 4.555 mm
5
The machine is in good technical condition, by prior arrangement the possibility of testing. in standard version always with Y-axis extension. PH10M / TP200 sensor system. With the PH10M head the machine can be equipped with a scanning system SP25 and a laser probe. Tool changer Metrosoft Quartis GEO software CNC measurement and evaluation of geometric parts without or against a CAD model. Quartis -Q-DAS, Quartis -Offline-Quartis-SURF measurement of general surfaces and curves against the CAD mo...
1
x-travel 7200 mm
y-travel 1600 mm
z-travel 2100 mm
Control
0 240 V
total power requirement kW
weight of the machine ca. 2 t
Byj89a38
dimensions of the machine ca. 8x1,6x2,1 m
3
table length:1500 mm
table width:1000 mm
daylight:800 mm
measurement range X =:1400 mm
measurement range Y =:1000 mm
measurement range Z =:800 mm
weight of the machine ca.:1,6 t
dimensions of the machine ca.:2,0 x 1,8 x 2,1 m
2p9zcq
3-D coordinate-measuring machine, caste measuring plate with finely machined surface with
T-slots, ZETT-MESS evaluation computer system, EPSON-statistical printer, machine equipped with temperature stabilizing heating and video camera, for TV-transmission of microsc...
6
Catalog No. : 5522
Type: CRT-Plus 544
Producer: Mitutoyo
Made in: 2007
Characteristic:
Software: MCOSMOS 3.5
Axis X: 505 mm
Axis Y: 405 mm
Axis Z: 405 mm
Width: 1200 mm
Depth: 1200 mm
Height: 2300 mm
Weight: 450 kg
Bxcwdw8qtq
Equipment:
Touch set
Measuring head PH6M
Probe (TP20)
Calibration in 2017
9
For sale is a used, fully functional multi-sensor coordinate measuring machine / machine from Werth Type: ScopeCheck 400
Technical data:
Measuring range:
X-axis: 400 mm
Y-axis: 200 mm
Z-axis: 200 mm
measuring systems:
for all axes incremental scales, resolution 0.1 µm
Space requirement: 1600 x 1020 x 1930 mm
Weight: approx. 200 kg
Manual and data sheets are available.
Accessories:
- control console
- Monitors I give free of charge. Measuring computer is however for data protection none with it.
...
2
Zeiss -coordinate measuring machine
Type UMM 550
measuring paths: X: 550mm
Y: 1200mm
z: 450mm
measuring system - photoelectric ,single stage
resolution - 2ym
machine with extensive accessories, complete documentation
Machine is already packed and disassembled ready for transport by authorized
Be2epsl
packed and disassembled.
If interest exists please around inspection locally.
1
The machine is in good technical condition, by prior arrangement the possibility of testing. Measuring range: - External dimensions of the machine: X 1200 mm Y 1800 mm Z 1000 mm X 2197 mm Y 2850 mm Z 3596 mm - - Machine weights: Dynamic machine characteristics: Total machine weight: Maximum machine load: Vector speed: Vector acceleration : 4300 kg 1200 kg 465 mm / s 1.85 m / s2
Gx8sgs
4
Measuring machine make MORA type 0190
make # 16079/0888 year of construction 02/88 for measuring of rotating parts
(as previously used for measuring propellers)
in 2 planes, in connection with a pivot point with encoder
technical data:
Measuring height 1500 mm
Jil9rqi
Measuring width 1200 mm
Distance of the pivot point from the measuring stand 1400 mm
Installation height from chuck to highest position of
measuring probe 1260 mm
Chuck with inner jaws 240 mm dia.
Space requirement with inner jaws ...
8
Multisensor-Coordinate Measuring Machine with 4-axis CNC-control
WinWerth on Windows PC
Wbn8m89b
Measuring range:
- Length 500 mm
- up to diameter 160 mm
- Weight max. 15 kg
Kind of measuring:
- Optical, Laser, Faser-probe
Accessories:
- Hydrodehn-clamping chuck with holders from diameter 3-16 mm
Excellent condition, low working hours.
7
The machine was overhauled by Trimess in 2017.
Software PC-Demis
Previously we had an identical machine. There are still a lot of spare parts available (control, etc.)
Several styli and many touch balls
Pud3x
14
1. SCOPE OF SERVICES
- WERTH Video-Check-IP 250 x 125 3D CNC multi-sensor coordinate measuring machine (year: 2011)
- WERTH Image processing sensor
- WERTH 3D-Patch
- WERTH Laser Sensor
- WERTH Fiber Probe
- WERTH Contour Probe
- WERTH control panel
- Computer incl. screen and keyboard
- Cleaning accessories
2. DOCUMENTATION
- Comprehensive documentation available
3. TECHNICAL DATA
MEASUREMENT AREAS
X-axis: 250 mm
Y-axis: 125 mm
Z-axis: 250 mm
WORKPIECE PROPERTIES
Max. workpiece height: 250 mm
M...
5
Granite frame, drive system and linear stranspoders provide 800x1000x600 mm operating dimesions.
Bysb2ab3jo
Equipped with Renishaw controllers + jog.
Only Renishaw head, probe + sylus needs to be added.
We used it until certification expired in Sep 2021, when a new machine replaced it.
9
x-travel 2000 mm
y-travel 1500 mm
z-travel 2500 mm
Control Quadra Check 1000
plate size 2000x1500 mm
total power requirement kW
weight of the machine ca. 4,5 t
dimensions of the machine ca. 2,1x1,7x3,2 m
Kvlpnuz
Measuring and marking machine
10
TECHNICAL DATA
Measuring range 900 x 1500 x 1000 mm
measuring plate 1400 x 2700 mm
working height 800 mm
machine dimensions L x W x H 2,7 x 1,7 x 3,8 m
Machine weight 3100 kg
EQUIPMENT/ACCESSORIES
Rotary swivel head RENISHAW PH 10 T
Station for 6 probes
Automatic change of probes
6 different probes
Calibration ball
RENISHAW clamping plate 880 x 600 mm
Nup020y
Clamping magnet 300 x 160 mm
Various clamping devices
Complete workstation
DELL Precision workstation
Manual control panel with joystick
D...
13
X- 1200 Y- 1000 Z- 600 mm
Table size : 1250X1050 mm
Max. Loading : 1200 kg
Yr77xs
12
x-travel 850 mm
Cmtax3rmi
y-travel 1200 mm
z-travel 600 mm
control 87er 8bit Firmware OO6
2
Mitutoyo Crysta 9166
900x1600x600
Renishaw PH10T Swivelling probe head
Active air suspension
Last calibration 2020 - Very well rated
By2vlei0zi
Very less traces of use
Year of manufacture 2003
PC with original active software
3
Mitutoyo QV E 202 P1L - C measuring machine,
Year of manufacture 2010,
Pvkjcq
CNC control,
travel X/Y/Z 250/200/200 mm,
programmable ring light,
magnification changer,
Auto Focus,
triangular pattern focus,
Temperature compensation
6
- measuring machine -second hand-
- LEITZ - PMM 12 10 6 B2
Bxtuzhp3un
- yom 1997
- working range: 1200 x 1000 x 600mm
- control B2
- QUINTOS 6 user terminal, PC Dell, 24" Widescren TFT-flat screen, laserprinter HP-LaserJet 2300N
- machine outside dimension: L x W x H = 320 x 10 x 370cm
5
1) Last maintenance / calibration from 03/2021 in the appendix (Calibration_2021).
2.) The machine is in a secured state so that it can be transported.
3.) Measurement software: software version Calypso 6.8, option Calypso Basis, Calypso PCM, Calypso Curve and Calypso QS-STAT out.
4.) The PC has to be set up again
Ppemb
5.) Stylus material: reference stylus only
1
Measuring ragne
Og7b9
Length max. 300 mm
Diameter max. 80 mm
Basic configuration
-LED ring episcopic light
-16 sectors, separatly switchable and dimmable
-active rotation axis with SK40-holder (at the bottom: dead centre SK40, on the top MK2 revolving tailtype centre)
-4 axis CNC control with servomotors with joystick, 2 moving speeds slow/quick
-high-resolution camera for image analysis
Software/Hardware
-3D measurement and analysis software SAPHIR 7: lern programming, grafical view, readin...
4
3-D measuring machine make MITUTOYO (self-made)
Technical data:
Table size 420 x 235 mm
table length = X 500 mm
table cross travel = Y 400 mm
headstock vertical adjustment = Z 300 mm
Spindle collet mounting
dimensions L x W x H 700 x 600 x 700 mm
with
- swivelling vertical milling head
- Digital display Mitutoyo 3-axis
- Mini process computer Mitutoyo DP 7
Elopvdy9u
- 3-D probe
used, from an operating solution, in good condition
3
3 Measuring machines Mitutoyo for sale
Mitutoyo Crysta Apex S 9206 BJ 2015
Mitutoyo Euro Apex C776 Year 2005
Ppiv2
Mitutoyo Euro Apex C776 Premier BJ 2002
2
Manual measuring joint arm
ZettMess AMPG - P 18 articulated,
O3bumxfl
Year of manufacture 2012,
Measuring range up to 1800 mm,
single point accuracy at the ball ± 0,012 mm, single point accuracy at the cone ± 0,018 mm,
length accuracy 0,027 mm,
Measuring probe,
probe tip,
accessories,
quick-release clamp for tribrach or mounting plate,
laptop and software,
10
Werth Scope-Check V - multi-sensor coordinate measuring device, new in year 2010
Multi-sensor coordinate measuring device for 3D CNC operation with vertical workpiece clamping.
The device is particularly suitable for measuring rotationally symmetrical tools / turned parts / etc. and
comparable rotationally symmetrical parts, such as: shafts excellently suited.
Advantage:
The multi-sensor concept supports combined measurements with several sensors.
very good condition, few hours of operation, on...
4
1 used roughness tester
Make: HOMMEL,
type: Wavelift T 8000,
feed unit,
Waveline 60,
measuring column Wavelift 400,
contour unit Wavecontur digital,
probe arm TA60,
cross table, 160 x 160 mm,
calibration set Wavecontur,
probe set TKU300 5 µm,
granite plate,
Bxxgj022vk
work table, PC,
TFT monitor, measuring software CORD8win
Technical data errors excepted
