Used Schaerer 660 X 2000 Mm for sale (6)

Condition: good (used), spindle bore 80 mm distance between centers 2500 mm weight approx. 4500 kg swing diameter 880 mm Dodsw Rcgmopfx Abwjcf 4.5/900 rpm length 490 cm height 145 cm width 150 cm digital readout on X and Z axes rapid traverse sold with 3-jaw chuck, 4-jaw chuck, and steady rest

Condition: good (used), Year of construction: 1975, Offer 24204 Technical data: - Maximum swing diameter over bed: 420 mm Dedpfx Ajx Tqg Iebwjcf - Centre distance: 1000 mm - Spindle bore: mm - Tailstock quill taper: MT 4 - Tailstock quill travel: 200 mm - Spindle speeds: 40 - 2000 rpm - Longitudinal & facing feeds - Metric thread pitches - Imperial threads - Module threads - Drive: 400 V - Includes: 3-jaw chuck - SWS steel toolholder with 3 inserts - Space required: approx. W 2800 x H 1250 x D 950 mm - Weight: approx. 2200 kg

Condition: good (used), Year of construction: 1970, LZ-Lathe Fabr.SCHAERER Type:UD500 Year 1970 overhauled 1991 With Forkadt chuck 315mm tool holder Multifix size C. Center height : 250 mm Center width : 1500 mm Dcedpsu Rdurofx Abwof spindle bore: 65 mm Spindle speed : 18 - 900 rpm. Machine in good condition .

Condition: used, Year of construction: 1970, digital readout ja weight 4,4 t Dodpfsyacnpsx Abwscf rapid traverse ja m/min

Condition: used, Year of construction: 1982, Lathe Schaerer, model UD632 Specifications: - Working height above floor: 1120 mm - Centre height above flat bed: 320 mm - Swing over bed: 660 mm - Swing over cross slide (short): 450 mm - Swing over cross slide (long): 420 mm - Swing in gap: 710 mm - Drive power: 15 / 22 kW - Spindle torque: 3000 Nm - Max. workpiece weight between centres without steadies: 1500 kg - Max. workpiece weight between centres with one steady rest: 2200 kg - Bed width: 460 mm Main spindle: - Spindle head with centring cone: 55022, size 8 - Front spindle bearing diameter: 120 mm - Through spindle bore: 72 mm - In front, taper 1:20: 80 mm - Internal taper: Morse 5 - Speeds: 1.8 – 2240 rpm Carriage feeds (number): 3x32 - Longitudinal feed A, 1:1: 0.07 – 1.12 mm/rev - Longitudinal feed B, 4:1: 0.31 – 4.5 mm/rev - Longitudinal feed C, 24:1: 1.8 – 28 mm/rev - Cross feed A, 1:1: 0.035 – 0.56 mm/rev - Cross feed B, 4:1: 0.16 – 2.24 mm/rev - Cross feed C, 24:1: 0.9 – 14 mm/rev - Rapid traverse longitudinal: 5000 mm/min - Rapid traverse cross: 2500 mm/min Leadscrew: - Pitch: 12 mm - Diameter: 50 mm Thread cutting: - Metric threads (number): 3x32 - Metric thread range A: 1 – 12 mm - Range B: 3.25 – 48 mm - Range C: 21 – 288 mm - Inch threads range A: 24 – 15/8 TPI - Range B: 6 – TPI - Range C: 1 – 1/12 TPI - Module threads A: 0.5 – 6 Mod - B: 2 – 24 Mod - C: 10.5 – 144 Mod - DP threads A: 48 – 3 DP - B: 12 – 1 DP - C: 1 – DP Cross slide: - Width: 310 mm - Cross slide short: 465 mm - Cross slide long: 1000 mm Top slide travel (manual): 150 mm Top slide travel (automatic): 180 mm Tailstock: - Quill diameter: 90 mm - Quill travel: 200 mm Weight (standard version): 3460 kg Year of manufacture: 1982 Special features: - Machine is in very clean condition - Double prism under-bed for high precision - Digital read-out HEIDENHAIN, model ND 780 - Infinitely variable spindle speed! - 3-jaw chuck FORKARDT - Automatic lubrication system - Automatic tool post - Rapid traverse on all three axes - Chip guard - Machine lighting Dcjdpegbd E Dsfx Abwjf Delivery conditions: - Delivery time: ex-stock, subject to prior sale - Delivery: ex Baarle-Nassau - Payment: prior to collection - Prices: net, excl. VAT Disclaimer: Machinehandel De Leeuw BV cannot be held liable for any discrepancies in the technical data in this offer and the actual machine. Machinehandel De Leeuw BV specializes in used machines and accessories for the metalworking industry and used paternoster systems from brands such as Kardex, Hanel/Haenel, Electrolux, Bertello, Megamat, Lista, Denocard and automated storage systems like the Kardex Shuttle XP, XPlus and NT systems. Warehouse: Oordeelsestraat 7b, NL-5111 PA Mail address: Postbus 294, NL-5110 AG Baarle-Nassau / The Netherlands Phone: Mobile Antoine: VAT no.: NL800103026B01 CoC Tilburg: 18034279

Condition: ready for operation (used), Year of construction: 1965, functionality: fully functional, spindle bore: 62 mm, turning diameter: 580 mm, center height: 275 mm, center width: 2,000 mm, total length: 4,000 mm, total width: 1,250 mm, total height: 1,300 mm, overall weight: 3,400 kg, Ladies and Gentlemen, We are selling a fully functional lathe of the type Schaerer UDA560 with lynette, some steel holders and technical documentation. Dcedpfxou St Rrj Abwef Availability: immediately Year of manufacture: 1965 Center height: 275mm Center distance: 2000mm Spindle bore: 62mm Max. turning diameter: 580mm Max. Max. turning diameter in the recess: 630mm Space requirement: 4.00x1.25x1.30m (LxWxH) Weight: approx. 3400kg Accessories: various steel holders, lynette, machine card
