Used panel saws with a cutting length from 0 to 999mm for sale (11)

Condition: ready for operation (used), Year of construction: 2022, This BIESSE Selco WNT 630 panel saw was manufactured in 2022. It features a maximum cutting length of 3800 mm, saw blade projection of 108 mm, and a lift table capacity of 5 tons. Ideal for handling large panels up to 3660 x 2200 mm. If you are looking to get high-quality cutting capabilities, consider the BIESSE Selco WNT 630 machine we have for sale. Contact us for more information. • Working size: 3800 x 2200 mm • Max cutting length: 3800 mm • Saw blade projection: 108 mm • Max gripper opening: 100 mm • Min panel size: 1830 x 915 mm • Max panel size: 3660 x 2200 mm • Max packet height: 630 mm • Condition: Almost new, used only a few months Hsdeyf I U Sspfx Afzjh Additional equipment • Back lift table: • Minimum panel thickness on lift table: 10 mm • Maximum lift: 985 mm • Lift table capacity: 5 t

Condition: ready for operation (used), Year of construction: 2001, operating hours: 5,466 h, This HOLZMA HPP 82/43 panel saw was manufactured in 2001. It features a main saw motor of 13.5 kW and a scoring saw motor of 2.2 kW, ensuring robust performance. The machine boasts a cutting length of 4300 mm and a cutting width of 4250 mm, with a saw blade diameter of 380 mm. It has been operational for only 5,466 hours. Consider the opportunity to buy this HOLZMA HPP 82/43 panel saw. Contact us for more information. Additional equipment • 7 Collets: First three are two-fingered, all others are single-fingered Hsdpfx Afex E Echjzeh • 2 Additional Two-Fingered Collets Possible • 1 Additional Single-Fingered Collet Possible Machine Benefits Technical Machine Benefits • Ce-tested // gs-tested fph // dust-tested • Collet opening max. : 100 mm • Cutting length: 4300 mm • Cutting width: 4250 mm • Air cushion table: 1 table 2160 x 650 mm and 3 tables 1760 x 650 mm with blower • Saw carriage feed forward speed: 5 - 125 m/min // saw carriage feed reverse speed: 125 m/min • Program slide speed forward/reverse max. : 80 m/min • Saw blade diameter: 380 mm // saw blade projection: 95 mm • Main saw blade: hm 380 x 48 x 60 • Scoring saw blade: hm 180 x 48 - 58 x 45 Extra Information Media Compressed Air: 6 bar Operating Voltage: 400 V / 50 Hz Operating Temperature Min.: +5 °C Operating Temperature Max.: +35 °C Minimum Extraction Speed at Extraction Nozzle: Approx. 26 m/s Extraction Connection for Chip Channel: 1 x 200 mm Extraction Connection for Pressure Beam: 1 x 150 mm

Condition: ready for operation (used), Year of construction: 2006, operating hours: 27,750 h, overall weight: 8,100 kg, This 3-axis PANHANS POLYPAN 47 was manufactured in 2006. It features 4200 mm cutting length and width, maximum cutting heights of 72 mm at 0° and 40 mm at 47°, and a saw carriage speed up to 100 m/min. Main motor power is 13.5 kW, with a scoring unit. Weighs 8100 kg. If you are looking to get high quality sawing capabilities consider the PANHANS POLYPAN 47 machine we have for sale. Contact us for further details. • Configuration: Machine including control cabinet • Cutting length (SL): 4200 mm • Cutting width (SB): 4200 mm • Max cutting height (saw blade vertical 0°): 72 mm • Max cutting height (saw blade swiveled 47°): 40 mm • Cutting accuracy (saw blade vertical 0°): +/- 0.1 mm • Cutting accuracy (saw blade swiveled): +/- 0.2 mm • Angle accuracy (feed speed < 10 m/min): +/- 1 mm • Angle accuracy (feed speed > 10 m/min): +/- 2.5 mm Hjdpfsx D Rtyjx Afzsh • Feed speed (saw carriage forward/reverse): 0–100 m/min • Feed speed (width stop forward): 25 m/min • Feed speed (width stop reverse): 100 mm • Axis travels (minimum plate size): X = 300 mm, Y = 100 mm • Axis travels (maximum plate size): X = 2800 mm, Y = 750 mm • Max drilling diameter: 13 mm • Max total length: 115 mm • Number of tools: 1 drilling spindle • Tool holder: Quick-release chuck DM 1-13 • Connection values • Total connection value: 21.0 kVA • Nominal current: 3x 32 A • Pneumatic connection: 8 bar (minimum 6 bar) • Air consumption: 3 liters/min per clamp • Sound pressure level (Lpa) at operator position: 86 dB(A) • Sound power level (LWA): 103 dB(A)

Condition: ready for operation (used), Year of construction: 1999, This MAYER PS9Z was manufactured in 1999. A robust horizontal panel saw, it features a powerful 12 kW motor and a cutting length of 4200 mm. Equipped with a scoring unit and pneumatic lowering, it ensures precise cuts. The saw includes air cushion tables and a material pusher with a 4200 mm travel distance. Consider the opportunity to buy this MAYER PS9Z panel saw. Contact us for more information about this machine. • Saw blade diameter: 355 mm • Cutting height: 80 mm • Saw blade projection: 105 mm • Cutting length: 4200 mm • Scoring unit: Pneumatic lowering during return stroke; 1.1 kW scoring motor; for 127 mm Ø conical scoring blade • Left angle table: 2000 x 600 mm, air cushion • Side table: 2000 x 600 mm, air cushion Hjdpfx Afex D Nyfozjh • Material pusher: Travel distance 4200 mm • Package clamps: 7 pcs, opening height 80 mm, double-finger design • Trimming stops: For panels with protruding veneers; 3-finger design for bundle cuts • Automatic pressure device: 20–1200 (range as provided) • Automatic cutting height adjustment: Yes • Optimization software: EASY optimizer; Cutting optimizer (professional optimization system for horizontal panel saws)

Condition: ready for operation (used), Year of construction: 2007, controller model: CADmatic 4 - Professional, This HOLZMA HPP 380 panel saw was manufactured in 2007. It features a robust steel saw carriage, main and pre-cut saws, and a patented Central Angle Return Device that reduces cycle time by up to 25%. The machine is equipped with a Power Control CADmatic 4 system, ensuring precise and efficient operation. The saw blade projection is 95 mm, and it operates with a main saw motor of 18.0 kW. For more information about this panel saw, please reach out to us. Additional equipment • Air cushion table with roller element 2160 x 650 mm: 4 pieces • Central blower: 1 piece Machine Benefits Qualitative Machine Benefits Hsdpfx Asyaiiyofzsh • Ce-certified, gs-certified, fph wood dust certified • Division: 75/275/475/1050/1850/2650/3450 mm measured from the angle rule to the center of the clamping collet • 2 additional two-fingered clamping collets possible • 4 manual trimming rakes at clamping collets • 1 additional one-fingered clamping collet possible • Jet spacing of air cushion tables: 70 x 70 mm Technical Machine Benefits • Pre-cut saw motor: 2. 2 kw • Operating voltage: 400 v / 50 hz • Electrical connection value at hs motor: 18. 0 kw = 24 kw, 21. 0 kw = 27 kw • Positioning accuracy: +/- 0. 1 mm/m • Surface-friendly material transport, lifetime positioning accuracy, no lubrication required, high program slider speed, maintenance-free, full stability of the steel table maintained, easy, cost-effective replacement of phenolic resin plates, minimal wear of the cylinders, uniform pressure application, minimal cutting = scratch cut, significant cycle time savings, top cutting quality, minimal setup times, reduction of cycle time, pressure strength electrically adjustable • Cutting length: 4300 mm • Cutting width (program slider travel): 4250 mm • Roller track (element 10-track): 1 piece • Roller track (element 2-track): 5 pieces • Clamping collets: 7 pieces (first 3 pieces two-fingered, all others one-fingered) Extra Information Machine still under power

Condition: ready for operation (used), Year of construction: 2019, This SCM Class SI 400EP panel saw was manufactured in 2019. It features a maximum saw blade diameter of 400 mm and a cutting width on rip fence up to 1500 mm. The sliding table saw offers a squaring stroke of up to 3800 mm. Ideal for precise wood panel cutting. Contact us for more information. • Machine Condition: Very good • Maximum Saw Blade Diameter (with Mounted Scorer): 400 mm Hodpfx Aeyabkvefzjh • Maximum Saw Blade Projection from Table at 90° / 45°: 140 / 97 mm • Cutting Width on Rip Fence (Rip Capacity): 1000 – 1500 mm • Maximum Squaring Stroke of Sliding Table Saw: 3200 – 3800 × 3200 mm • Three-Phase Motor Starting From: 7 kW (8 kW) / 50 Hz (60 Hz)

Condition: ready for operation (used), Year of construction: 2009, This HOLZHER CUT 70 6110 panel saw was manufactured in 2009. It features a cutting size up to 3900 × 3900 mm, a maximum cutting height of 70 mm, and saw blade projection of 82 mm. The main sawing unit has a motor power of 11 kW and a blade diameter of 350 mm. It supports a saw carriage and pusher speed of 0–70 m/min. Consider the opportunity to buy this HOLZHER CUT 70 6110 panel saw. Contact us for more information. • Workpiece • Cutting size: 3900 × 3100 mm or 3900 × 3900 mm • Max. cutting height: 70 mm • Max. saw blade projection: 82 mm • Sawing Unit • Motor power: 11 kW • Saw blade Ø: 350 mm • Rotational speed: 4070 rpm Scoring Unit • Motor power: 1.1 kW • Saw blade Ø: 180 mm • Rotational speed: 6070 rpm Feed / Carriage • Saw carriage & pusher speed: 0–70 m/min (continuous) Hedpfox Ut Ikjx Afzjh • Return speed: 70 m/min • EU feed speed: 0–25 m/min Media • Compressed air: 6 bar, 32 NL per cutting cycle • Dust extraction: • Connections: 1×120 mm (base machine), 3×120 mm (pressure beam) • Capacity: 4500 m³/h • Air speed: 30 m/s Additional Equipment • Number of tables: 3

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 0-341-07-8150, cutting length (max.): 4,300 mm, saw blade diameter: 380 mm, cutting width (max.): 3,800 mm, throat depth: 75 mm, Equipment: scorer, TECHNICAL DETAILS Blade extension: 75 mm Cutting length: 4,300 mm Cutting width: 3,800 mm Main saw blade, max. diameter: 380 mm Main saw blade, power: 9.2 kW Scoring saw blade, max. diameter: 180 mm Scoring saw blade, power: 2.2 kW Pusher carriage speed: up to 80 m/min Saw carriage speed: 1–120 m/min MACHINE DETAILS Numerical control: POWER CONTROL Software: Cad Matic 4.0 Electrical Data Voltage: 400 V Current: 31 A Frequency: 50 Hz Secondary current: 40 A Control voltage: 24 V DC Hedpfx Asxx Svrefzsh EQUIPMENT Front panel loading Front-side unloading Automatic side aligner Fixed front table made of Bakelite with air cushion system 3 mobile front tables made of Bakelite with air cushion system Pusher carriage with 6 clamps

Condition: new, Code: N0004 Brand: SICAR Model: SEGA 315 - CE Standard Professional panel saw SEGA 315 with carriage 3200 mm , blade 315 and scoring unit with separate motor - CE Standard Three-phase main motor 7,5 hp. Parallel guide on round bar with cast iron support and micrometric adjustment, blade lifting and tilting by handwheels, tilting blade unit with integrated scoring unit, aluminium carriage sliding on ball bearings, fence on extendable frame with two reversible stops. TECHNICAL DATA: Main worktable mm 910x550 Hjdpfx Afohktiuezjh Additional worktable mm 910x760 Additional lateral worktable mm 500x550 Main blade speed rpm 4000 Scoringunit speed rpm 8000 Blade diameter mm 300x30 Scoring diameter mm 120x20 Cutting height at 45° mm 75 Cutting height at 90° mm 100 Max cutting distance between blade and scale mm 1250 Carriage dimensions mm 3200 Three-phase motor power HP 5,5 Scoring unit motor power kW-HP 1,0-0,75 Overall dimensions for transport mm 3450 x 2000 x 1000 h Weight kg 570 MACHINE READY FOR DELIVERY

Condition: new, Universal complete solutionfor cut optimization and label printingIncluding office software, W-LAN box, tablet PCwith machine holder and label printer- Easiest handling and suitable for all machines- Cut optimization at the desk or directly on the tablet PC- Immediate availability of the cutting plan on the sawW-LAN transmission- Parts lists can be used from all common (CAD) programs- Label printing by simply pressing the pieces in the cutting plan(Touch screen)- Labels with dimensions etc. on the cut edge ensure goodOverview in the panel store Hedpfx Ajvwf Ipefzjh

Condition: used, Radial saw Hjdoqqu Auopfx Afzsh
