Used Machining centers (horizontal) X-axis travel 400-599mm for sale (74)

Condition: ready for operation (used), Year of construction: 2000, Functionality: fully functional, Travel distance X-axis: 560 mm, Travel distance Y-axis: 560 mm, Travel distance Z-axis: 560 mm, Workpiece weight (max.): 400 kg, Spindle speed (max.): 14,000 rpm, Number of slots in tool magazine: 60, TECHNICAL DETAILS Control unit: Makino A55 Professional 3 X-path: 560 mm Y-path: 560 mm Z-path: 560 mm Speed range: 50 - 14000 rpm Pallet clamping surface: 400 x 400 mm Dpqmgr Workpiece weight: 400 kg Clamping surface: 400 x 400 mm Tool magazine: 60 places Spindle taper: SK 40 MACHINE DETAILS Total power requirement: 22 kW Machine weight: approx. 9.5 t Coolant tank: 1300 l

Condition: used, Year of construction: 2005, travel -x axis 560 mm travel -y axis 560 mm travel -z axis 560 mm control FANUC 16i-M b-axis 360 x 0,001 ° turning speeds 12.000 U/min tool taper BT 40 numbers of positions in the tool changer 210 Milling machining centers - horizontal | MITSUI SEIKI - HU40A equipped with ITC & tool changer. The machine has only approx. 12.000 H spindle hours. Equipment: - Direct scales in all axes, - FANUC 16i-M with HPCC look-ahead, Boswdk0Wg - Renishaw tool length measurement and tool breakage monitoring, - 2 compartment plate changer, - 2 pallets: 400mm x 400mm, - Spindle oil cooler, - Knoll paper belt filter system, - Coolant cooler, - 70 bar internal coolant supply through the spindle - CO2 extinguishing unit - Air filter unit - extensive documentation available The machine is in a well-maintained condition and can be inspected at any time under power. A machine video from the production plant will be shared on request. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HU 40A | HU40 | HU-40A | HU 40 A

Condition: excellent (used), Model: HMC 700 Control: Fanuc 18i – MB Year: October 2003 Pallet Size: 500 x 500mm X Travel: 710mm Y Travel: 610mm Z Travel: 610mm B Axis: 360 Degrees (0.001 Degrees Increments) Max Pallet Loading: 500 KGS Spindle Taper: ISO 40 (Large Face Spindle) Spindle Speed: 10,000 RPM 60 Station Tool Changer Machine Dimensions: 3675 x 4510 x 3100mm high Dpn7Ap Weight: 13,000 Kgs

Condition: ready for operation (used), Year of construction: 2019, General Data Machine weight 21000 kg Control Unit Brand Siemens Model Sinumerik 840 D SL Main Drive Number of spindles 2 Spindle speed range 50 - 24000 rpm Tool taper HSK-A63 Movement X-Axis Movement 400 mm X-Axis Rapid Traverse 75 m/min Y-Axis Movement 450 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 550 mm Z-Axis Rapid Traverse 90 m/min Tools Max tool diameter 75 mm Additional Equipment Double spindle Shuttle table 2x 2 NC rotary swivelling units Switch cabinet system Chip conveyor Knoll 600K-1 2019 Hydraulic unit Filter system Recooling system Lahntechnik KOF1803-100 2020 Number of tool magazine positions: 2x 30 Rotary table (NC / hydraulic clamping) : n x 360o, vertical axis, This 5-axis SCHMID SE 368 horizontal machining centre was manufactured in 2019. It features a Siemens Sinumerik 840 D SL control, rapid traverse rates of 75/40/90 m/min in X/Y/Z, and a shuttle table. Equipped with dual NC rotary swivelling units, a 30-fold tool changer, and HSK-A63 tool holder. Max speed is 10,000 rpm. Includes a chip conveyor and recooling system. A great opportunity to buy this SCHMID SE 368 horizontal machining centre. Contact us for further details regarding this horizontal machining centre. Cvxjfwcp90 Application Types Milling

Condition: good (used), Year of construction: 2014, Catalog No. : 7686 Type: EC 400 Producer: HAAS Made in: 2014 Characteristic: Maximum table load (evenly distributed): 400 kg Bg373Wyfxm Power of the spindle drive: 22.4 kW Maximum spindle speed: 8100 1/min X-Axis travels: 559 mm Y-Axis travels: 635 mm Z-Axis travels: 559 mm Pallet size: 400x400 mm

Condition: excellent (used), Year of construction: 2007, Control unit: OSP P200M Travels: X-axis 560 mm Y-axis 610 mm Z-axis 625 mm Tool holder: SK 40 MASBT Tool magazine: 60 - compartment Spindle speed: 50 - 15,000 rpm 26 KW Distance from spindle center to pallet surface: 50 - 660 mm Distance from spindle nose to pallet center: 85 - 710 mm Pallet dimensions: 400 x 400 mm accessories - Chip conveyor - Measuring probe - IKZ high-pressure pump - NC-B axis - DNC operation W9Gkxuxw - 2-fold plate changer - Large tool package Garwels machines and service The right choice We would be happy to provide you with a quote for our additional services - transportation - Installation of the machine - Commissioning - Instruction We are exactly the right contact for - repair - maintenance - service Please also visit our website www garwels de

Condition: good (used), Year of construction: 2001, MATSUURA ES-450HII PC-5 4 axes horizontal machining center Year of construction 2001 Control FANUC 18i - M Machine number 10414639 Travel X - 450 / Y - 400 mm / Z - 400 mm 4th axis 360 x 1° Equipment: Tool magazine with 61 places Circular pallet storage with 5 pallets 300 mm x 300 mm and set-up station Spindle SK 40 Speed 50 - 15,000 rpm 4th axis 360 x 1° KNOLL coolant system Coolant system HYFRA Coolant filter system Chip conveyor Operating instructions/documentation Machine data on storage medium All other accessories shown in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery only includes the accessories that are expressly listed here, in the order confirmation and invoice. Equipment, technical data, plans and transportation - illustration, content and information without guarantee, therefore not binding - see "PDF. Ceoduyhq3 There are two more MATSUURA machining centers available. Sale preferably en bloc. PRICE net 19.900 € FCA D-77866 Rheinau including dismantling, removal and loading onto truck, excluding packaging Delivery time immediately Subject to prior sale / payment immediately on completion of purchase

Year of construction: 2013, Condition: excellent (used), Total power value: approx. 133 kVA Back up fuse: 250A Compressed air quality according to ISO 85731: purity class 4 Connection pressure: max. 9.5 bar Operating pressure: min. 7 bar Number of spindles: 2 Spindle arrangement: vertical, side by side Spindle distance: 600 mm Spindle bearing diameter: 90 mm Spindle with max 12000 rpm Ramp up time: 0 10,000 kin 1 approx. 0.8 s Travel X axis: 600 mm Travel Y axis (change position): 600 (875) mm Travel Z1-,Z2 axis: 500 mm Tool changing system: Pick up Tool spindle: HSK 80 Tool places: 70 Max. Tool diameter: 90 mm Biwhf7Wyfj Max. Tool length: 540 mm Max. Tool weight: 10 kg Max. Magazine load: 350 kg

Condition: used, Year of construction: 2014, Matsuura H Plus-300 Year of manuf. : 2014 Control : Fanuc 30iM Movement X/Y/Z : 500/560/500 mm Tool holder : BT40 _____ Description: Spindle: Speed:15.000 rpm Power:15 kW Torque:119 Nm Taper:BT40 NC-Roundtable: Dpfw3V B-Axis:0,001° Palletsize:300 x 300 mm Tableloading (max.):250 kg Workpiecesize (max.):ø530 x 760 mm In general: Toolmagazine:71 stations Rapidtravers in X/Y/Z:60 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal cooling unit with paperbeltfilter and high-pressure, 70 bar Workpiecemeasurement:Touchprobe, Renishaw OMP60 Toolbreakagecontrol:Mechanical Automation:Palletchanger, 2 stations Further Accessory:Trafo, rinsing pistol

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT40 BIG PLUS - Spindle power : 26 [kW] - Spindle speeds : 15000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 560/640/640 [mm] - Rapid traverses rates (X/Y/Z) : 60 [m/min] B ROTARY AXIS Dprzz7 - Travel : 360 [°] - Indexing precision : 0.001 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 60 PALLET CHANGER - Pallet changing device type : Rotopalette - Pallet size : 400X400 [mm] - Pallets number : 2 - Maximum weight upon pallet : 400 [kg] - Maximum workpiece diameter : 630 [mm] - Maximum workpiece height : 900 [mm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 4100X2300 [mm] - Machine height : 2720 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Number of working hours : 3700 [h] EQUIPMENT - CNC : Fanuc 31 iB Interface : Ethernet / RS232 / USB / PCMCIA - Electronic handwheel - Linear scales - Rigid tapping - 3 colors status lamp - Coolant tank * with high-pressure pump : 25 [bars] * Coolant through spindle * With cabin washing - Chips conveyor : Arrière - Spindle cooling unit - Tool probe - Workpiece probe : Renishaw OMP60

Condition: good (used), Year of construction: 2006, Catalog No. : 7008 Type: BA400-2 Bhozp892Uvw Producer: SW Made in: 2006 Characteristic: Control system: Siemens - Sinumerik 840D Number of stack positions: 120 Maximum rotary speed of the spindle: 17500 1/min X-Axis travels: 400 mm Y-Axis travels: 700 mm Z-Axis travels: 400 mm Taper: HSK63 Equipment: Internal cooling Chip convoyer High pressure pump Filtration Knoll 2x four-digit 5th axis on A and B-Side (manufactured by Peiseler)

Condition: excellent (used), Year of construction: 2016, Control unit: OSP P300MA Travels: X-axis 560 mm Y-axis 560 mm Z-axis 625 mm Hdspm3Ct Pallet size: 400 x 400 mm Max. Workpiece size: Ø600mm x 900 mm Fixture: MAS BT 40 Tool magazine: 64 - compartment Spindle speed: 15,000 rpm Accessories: - BigPlus main spindle - 2-fold plate changer - NC rotary table - Mayfran Consep 2000 II chip conveyor - Renishaw TS34 touch probe - Ball screw cooling in X- and Z-axis - Tool breakage control and length measurement - Okuma Servo Navi - High pressure IKZ Garwels machines and service The right choice We would be happy to provide you with a quote for our additional services - transportation - Installation of the machine - Commissioning - Instruction We are exactly the right contact for - repair - maintenance - service Please also visit our website www garwels de

Condition: good (used), Year of construction: 2007, MATSUURA H.PLUS-300 PC-5 4 axes horizontal machining center Year of construction 2007 Celkhxp98 Control: FANUC /MATSUURA G-Tech 30i Machine number 17232 Travel X - 500 mm / Y - 500 mm / Z - 500 mm B-axis 360.000 Spindle new November 2020 Hydraulic unit new 2021 Tool changer overhauled 2021 Oil cooler for spindle new 2023 Equipment: MATRIX tool magazine with 240 places Circular pallet storage with 5 pallets 300 mm x 300 mm and set-up station Spindle SK 40 Speed 50 - 15,000 rpm NC rotary table as B-axis rapid traverse and feed 50 rpm. RENISHAW OMP 60 measuring probe Tool breakage control Rotating viewing window Cutting force monitoring Pressure cell for tool length measurement KNOLL coolant system Tank capacity 1,400 l Scraper belt chip conveyor with lifting pump and chip removal Coolant supply through the spindle 70 bar External cooling 1.4 bar Filter system SF1000/Turbo Coolant recooler VWK 70 Coolant spray gun Air nozzle on the headstock Coolant shower Operating instructions/documentation Machine data on storage medium All other accessories shown in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery only includes the accessories that are expressly listed here, in the order confirmation and invoice. Equipment, technical data, plans and transportation - illustration, content and information without guarantee, therefore not binding - see "PDF. There are two more MATSUURA machining centers available. Sale preferably en bloc. SPECIAL PRICE net 34.900 € FCA D-77866 Rheinau including dismantling, removal and loading onto truck, excluding packaging Delivery time immediately Subject to prior sale / payment immediately on completion of purchase

Condition: used, Year of construction: 1996, travel -x axis:560 mm travel -y axis:510 mm travel -z axis:510 mm control:Fanuc 18 MC size of pallet:400 x 400 mm numbers of pallets:2 table load:0,5 t working diameter:610 mm B-axis (table):1 ° rapid travel x/y/z:32000 mm/min feeds x/y/z -stepless:16000 mm/min tool magazin::40 BT 40 tool changing time:1,5 sec max. tool diameter:80/125 mm O0Z798Bfdv max. tool weight:10 kg spindle speed::12000 1/min spindle drive:22 / 18,5 kW max. torque on the spindle:167 Nm program memory:160 m capacity:55 kVA weight of the machine ca.:8,7 t Overall size:2400 x 3900 x 2500 mm Registered programs:200 Probe for tool breakage and length measuring:Blum MINI Laser Fast horizontal machining center with twin 400 mm pallet changer, 40 tool magazine BT 40 (BT tool specification can be converted to SK), coolant through spindle interface, new Frascara high pressure coolant system can be supplied against extra cost.

Condition: used, Year of construction: 2004, x-travel 500 mm y-travel 560 mm z-travel 500 mm Control Matsuura G-Tech 840DI main spindle: max. turning speeds 15.000 min/-1 total power requirement 45 kW In our opinion, the machine is in good used condition and can be viewed under power by appointment. Accessories, tools and clamping devices shown are only included in the scope Ciutfphgqg of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well Subject to prior sale!

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 22 [kW] - Spindle speeds : 12.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 560 x 560 x 560 [mm] - Rapid traverses rates (X/Y/Z) : 40.000 [mm/min] - Cutting feed rates (X/Y/Z) : 1 - 20.000 [mm/min] B ROTARY AXIS - Travel : 360 [°] - Indexing precision : 1 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 60 - Tool exchange time : 1,2 [sec] PALLET CHANGER - Pallet changing device type : Rotopalette - Pallet size : 400 x 400 [mm] - Pallets number : 2 - Maximum weight upon pallet : 400 [kg] - Distance table / spindle axis (min./max.) : 80 - 640 [mm] - Distance table center / spindle nose (min./max.) : 150 - 710 [mm] - Maximum workpiece diameter : 600 [mm] - Maximum workpiece height : 700 [mm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 3.600 x 3.750 [mm] - Machine height : 2.828 [mm] - Machine weight : 9.500 [kg] MACHINE HOURS - Number of hours under power : 9.893 [h] - Number of working hours : 2.138 [h] Cyw0Ww3Pry EQUIPMENT - CNC : Fanuc 18-iM - Electronic handwheel - Rigid tapping - Coolant tank * Coolant through spindle * With cabin washing - Chips conveyor - Spindle cooling unit

Condition: good (used), Year of construction: 2020, DMG Mori NHX 4000 horizontal machining center, Year of construction 2020, Celos Ergoline Touch control, Travel X/Y/Z 560/560/660 mm, Dpriej B axis 0.001°, Tool changer 60 times, Spindle speed up to 20,000 rpm, IKZ 70 bar, 3D measuring probe Renishaw,

Condition: good (used), Year of construction: 2010, Functionality: fully functional, Controller WINMAX DSM V09 Palette size 500 x 500 mm (not accessories) Max wpcs weight 500 kgs X travel 760 mm Y travel 610 mm Z travel 610 mm Dppbxp Spindle speed 12000 rpm Tool holder type SK40 Rapid speed 32 m/min Feedrate 15,4 m/min ATC magazin 60-fold Spindle power 15/18 kW Weight ca 13000 kgs Dimensions LxWxH = 4300 x 2500 x 2800 mm Accessories, features - Chip conveyor - MPG - Software options: 3D, DXF, pocket/islands, rigid tapping, realistic graphics, NCPP, ISNC herical/ramp, tool and material databank, tool optimalisation, etc. - CTS 20 bar - Machine mounts The machine is in good working order and technically checked.

Condition: good (used), Year of construction: 2008, MATSUURA H.PLUS-300 PC-5 4 axes horizontal machining center Year of construction: 2008 Control: FANUC /MATSUURA G-Tech 30i Machine number 17758 Travel X - 500 mm / Y - 500 mm / Z - 500 mm B-axis 360.000 Spindle new April 2023 Cehtbbf8W Equipment: MATRIX tool magazine with 240 places Circular pallet storage with 5 pallets 300 mm x 300 mm and set-up station SK 40 spindle speed 50 - 15,000 rpm. NC rotary table as B-axis rapid traverse and feed 50 rpm. RENISHAW OMP 60 measuring probe Tool breakage control Rotating viewing window Cutting force monitoring Pressure cell for tool length measurement KNOLL coolant system Tank capacity 1,400 l Scraper belt chip conveyor with lifting pump and chip removal Coolant supply through the spindle 70 bar External cooling 1.4 bar Filter system SF1000/Turbo Coolant recooler VWK 70 Coolant spray gun Air nozzle on the headstock Coolant shower Operating instructions/documentation Machine data on storage medium All other accessories shown in the photos and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery only includes the accessories that are expressly listed here, in the order confirmation and invoice. Equipment, technical data, plans and transportation - illustration, content and information without guarantee, therefore not binding - see "PDF. There are two more MATSUURA machining centers available. Sale preferably en bloc. SPECIAL PRICE net 39.900 € FCA D-77866 Rheinau including dismantling, removal and loading onto truck, excluding packaging Delivery time immediately Subject to prior sale / payment immediately on completion of purchase

Condition: good (used), Year of construction: 2014, Operating hours: 5,566 h, Travel distance X-axis: 508 mm, Travel distance Y-axis: 508 mm, Travel distance Z-axis: 508 mm, The machine is in good technical condition. X-axis: 508 mm Y axis: 508 mm Z axis: 508 mm Length x width x height 3405 × 3655 × 2630mm Czsw7K3T7E Weight 9075 kg Centre cooling. By prior arrangement, inspection in operation is possible. The machine is in good technical condition. X axis: 508 mm Y axis: 508 mm Z axis: 508 mm Length x width x height 3405 × 3655 × 2630mm Weight 9075 kg Central cooling.

Condition: used, Year of construction: 2008, x-travel 500 mm y-travel 560 mm z-travel 500 mm Control Matsuura G-Tech 30i main spindle: max. turning speeds 15.000 min/-1 number of tool places 210 Pos. total power requirement 52 kW In our opinion, the machine is in good used condition and can be viewed under power by appointment. Technical features: -5-fold pallet changer Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Ciupoiq3O8 Changes and errors in the technical data and information as well Subject to prior sale!

Condition: ready for operation (used), Year of construction: 1997, Functionality: fully functional, Type of machine Machining Center - Horizontal Make MORI SEIKI Type SH 400 Year of manufacture 1997 Type of control CNC MCS 518 Country of origin Japan Delivery time immediately Freight basis EX WORK Technical details x-travel 560 mm y-travel 510 mm z-travel 510 mm 4th axis control Fanuc MSC 518 / Fanuc spindle speeds 12000 rpm spindle drive 22/18.5 kW rapid travel x/y/z 32 mm/min Number of tool station 60 SK40 Pallet dimension 2 x 400x400 mm working diameter max. 610 mm B-axis 0.001 ° total power requirement 55 kVA weight of the machine approx. 8,7 t dimensions of the machine approx. 2,9x4,1 m Accessories Chip conveyor Coolant PUMP Coolant shower Interface for coolant through the spindle Additional information Dpmebb Control Fanuc MSC 518 MB, 60 tool stations, prepared for trough spindle coolant, chip conveyor, 2 pallet changers Knoll SF 500/turbo filter COOLING THROUGH THE SPINDLE 40 BARS Price 12.000,00 EURO net ,free load your truck.

Year of construction: 2000, Condition: good (used), Maschinen-Details Lagernummer 1105-03446 Maschinenart Bearbeitungszentrum - Horizontal Fabrikat HAAS Typ HCE 400 P Baujahr 2000 Steuerungsart CNC Steuerung HAAS Lagerort FRANKREICH Ursprungsland Japan Lieferzeit Nach Absprache Frachtbasis EXW (Incoterms 2000) frei verl Technische Details x-Weg 560 mm y-Weg 635 mm z-Weg 560 mm Steuerung HAAS Palettengröße 400x400 mm Tischbelastung 400 kg Spindelmotor 22 kW Spindeldrehzahl 8100 1/min Eilgang 36 m/min Palettenwechsler-Typ 2-fach rotation Tisch Indexierung 360000° ° Werkzeugmagazin: 30 x BT 40 Gesamtleistungsbedarf 54 kVA Maschinengewicht ca. 8 t Raumbedarf ca. 2,8 x 5,5 m Zubehör Späneförderer Zusatzinformationen H8M9Igv Immer noch sehr präzises Horizontalzentum volle B AXIS 30 FACH BT 40 WERKZEUGWECHSLER CNC HAAS 2 PALETTES 400 X 400 MM

Condition: reconditioned (used), Year of construction: 2015, Functionality: fully functional, Machine/vehicle number: 530208-M1, Travel distance X-axis: 450 mm, Travel distance Y-axis: 500 mm, Travel distance Z-axis: 450 mm, Rapid traverse X-axis: 70,000 mm/min, Rapid traverse Y-axis: 70,000 mm/min, Rapid traverse Z-axis: 80,000 mm/min, Nominal power (apparent): 28,000 VA, Torque: 63 Nm, Controller manufacturer: SIEMENS, Controller model: 840D Solution Line, Workpiece height (max.): 300 mm, Workpiece diameter (max.): 295 mm, Workpiece weight (max.): 30 kg, Total height: 2,825 mm, Total length: 5,885 mm, Total width: 3,000 mm, Overall weight: 20,000 kg, Spindle speed (min.): 50 rpm, Spindle speed (max.): 16,000 rpm, Operating hours of spindle: 100 h, Distance between spindles: 450 mm, Spindle motor power: 28,000 W, Spindle nose: 65mm, Number of spindles: 2, Number of slots in tool magazine: 100, Tool mount: 63 mm, Tool length: 320 mm, Tool diameter: 160 mm, Tool weight: 6,000 g, Input voltage: 400 V, Type of input current: AC, Equipment: Chip Conveyor, Documentation/Manual, Rotational Speed Infinitely Variable, Product name MFZ4-2 used, 2-spindle, horizontal 5-axis machining center with independent Z-spindle units Year of manufacture: 2015 Control SINUMERIK 840D Powerline Machine dimensions without coolant system and chip conveyor L x W x H approx. 5.10m x 3.05m x 2.8m Weight approx. 20000Kg (machine without coolant system and accessories) X-axis travel: 450 mm Y-axis travel: 500 mm Z-axis travel: 450 mm Spindle distance: 450 mm Rapid traverse X Y Z-axis 70000mm/min, 70000mm/min, 80000mm/min 2 x motor milling spindle GMN, version with HSK63 tool holder Drive power (S1/S6) 28 KW (constant) Torque (S1/S6) 63/83 Nm Max. speed 16,000 rpm Chip conveyor Knoll (scraper belt conveyor in the setting variant lengthways to the machine) Optional hinged belt conveyor for long winding chips (in the setting variant across the machine) Flushing gun Internal tool cooling 70 bar (2 x 20 l/min) 2 table supports each with 2 NC dividing tables (B-axes, 5th axes) Speed ​​control for high-pressure pump for internal tool cooling with frequency converter Vario valve for internal tool cooling for stepless coolant pressure programming from 10 bar Multifunctional light (3-stage) Loading area light Electro-mechanical suction unit (volume flow 2,050 m³/h) Tool and process monitoring CTM (ARTIS) Oil pans available Retrofit 2024: Replacement of the guideways and guide carriages X-Y-Z axes Replacement of the ball screws, couplings and bearings of the Z1 and Z2 axes Replacement of the motor spindles S1 and S2 with new motor spindles. Measurement and adjustment of the machine geometry and the motor spindles Replacement of the piston distributor central lubrication Replacement of the lubrication hoses between the piston distributor and the lubrication point Replacement of the toothed belts of the hydraulic weight compensation of the Y-axis Replacement of all tool clamps on the tool magazine Installation of the missing support plates of the plastic clamps on the tool magazine Cwpynof8Wu Measurement and adjustment of the tool magazine Replacement of the control door viewing window Replacement of the plexiglass panes tool handling and maintenance doors tool magazine Replacement of the stripping frame Z-axes Replacement of the cover plates Z1 and Z2 axes top and bottom Replacement of the cover X-axis (X-blind) Replacement of all hydraulic and coolant hoses Oil change of the rotary axes (A, B axes and W axes) as well as checking for leaks and checking the positioning accuracy and adjusting the backlash Oil change hydraulic oil and cleaning of the hydraulic unit Paint stripping and repainting of the cover plates A-axes and W-axis in RAL 7035 (light grey) Repair of the colour on the W-beam and in the work area in RAL 7035 (light grey) Testing, maintenance and documentation (test book) of the “Schimpke” system cooling system by a specialist company, issuing a test sticker for the “Schimpke” system cooling system

Year of construction: 1997, Condition: excellent (used), Machine-Details Stock-No. 1105-03918 Type of machine Machining Center - Horizontal Make MORI SEIKI Type SH 400 Year of manufacture 1997 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis EX WORK Technical details x-travel 560 mm y-travel 510 mm z-travel 510 mm control Fanuc MSC 502 (Fanuc 16i) spindle speeds 10000 U/min spindle drive 22 kW rapid travel x/y/z 32 mm/min Number of tool station 60 SK40 Clm7Xm9Vmu Pallet dimension 2 x 400x400 mm table load 0,5 t working diameter max. 580 mm table index total power requirement 56 kVA weight of the machine ca. 8,7 t dimensions of the machine ca. 2,9x4,1 m Accessories Chip conveyor Coolant PUMP Coolant shower No. of tool offset pairs 200 Probe for tool breakage and length measuring Tool life management offsets for parts 56 High speed countour control M-Functions 5 Warm up cycle Macro B Interface for coolant through the spindle Additional information Control Fanuc MSC 516 MB, 40 tool stations, prepared for trough spindle coolant, 4th axis, Chip conveyor, 2 Palett changer COOLING THROUGH THE SPINDEL 40 BARS
