Used machining centers (horizontal) X-axis travel 1000-1199mm for sale (58)

Condition: ready for operation (used), Year of construction: 2019, General Data Measurements height 3280 mm Machine weight 24000 kg Main Drive Spindle speed range 12000 Tool taper HSK 100 Number of axis 4 Movement X-Axis Movement 1000 mm X-Axis Rapid Traverse 60 m/min Y-Axis Movement 900 mm Y-Axis Rapid Traverse 60 m/min Z-Axis Movement 1000 mm Dcodex D Rttspfx Adusr Z-Axis Rapid Traverse 60 m/min Table Table load 1200 kg This 4-axis Okuma MA 600H II was manufactured in 2019, featuring a robust 630 × 630 mm table, capable of handling loads up to 1,200 kg. It boasts rapid traverse rates of 60 m/min and a high-speed spindle up to 12,000 rpm, ensuring efficient machining. The machine includes a large tool magazine with 171 stations and advanced features like spindle cooling and a chip conveyor system. If you are looking to get high-quality milling capabilities consider the Okuma MA 600H II machine we have for sale. Contact us for more information. Application Types Milling

Condition: excellent (used), Year of construction: 2018, Heller H6000 CNC Twin Pallet Horizontal Machining Centre With Siemens 840D sl Control Pallet Dimension 630 x 630mm. Maximum Pallet Mass 1,000kg. Maximum Workpiece Height 1,200mm. Axis Travel 'X'=1,000mm, 'Y'=1,000mm, 'Z'=1,000mm, 'B'=360° (0.001° Increments). Rapid Traverses 'X'=50,000mm/min, 'Y'=50,000mm/min, 'Z'=75,000mm/min, 'B'=25rpm. Feed Thrusts 'X' And 'Y'-axis With Duty Cycle = 40% 15,000N, 'Z' Axis With Duty Cycle = 40 % 20,000N. Spindle Speed Range 5-6,000rpm. Drive Power At Duty Cycle S6 40% 60kW, Maximum Torque At Duty Cycle S6-40% 2,292Nm. 50 Position ATC. Spindle Taper HSK 100A. Maximum Tool Ø280mm, Maximum Tool Length 600mm, Maximum Tool Mass 25kg. S/No. MA56338 (2018). Dodpfx Adsx Aia Aoujcr With Absolute Measuring Scales 'X', 'Y' & 'Z', Baluff Tool Chip Reader, Renishaw Spindle Probe Interface, Knoll Through Spindle Coolant System, Knoll Chip Conveyor, LTA Industrial Cleaning Mist Extraction Unit, Signal Tower, Foot Switches, Handwheel & Manuals. Overall Dimensions L7,650 x W3,500 x H4,300mm. Weight 13,500kg.

Condition: used, Year of construction: 2010, x-travel 1000 mm y-travel 1000 mm z-travel 1000 mm Control Heidenhain iTNC 530 tool taper SK 50 number of tool places 120 Pos. On-time hours ca. 66737 h spindle hours ca. 36316 h In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features & Accessories: - Fully protective cabin with sliding doors and interior lighting - Setup room - Tool measurement in the work area with BLUM laser Dcsdoxylqxepfx Adusr - 3D measuring probe - Operating modes 3 bar internal coolant supply with 600 l tank and paper belt filter - Chip flushing gun with 1 bar/ l pump - Chip conveyor - Brankamp monitoring system - 3-color signal light - Coolant ring nozzle - Blow-air cooling system - Coolant system - Oil/emulsion mist separation system - Control cabinet cooling unit - Operating manuals Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: as good as new (ex-display), Year of construction: 2022, Control : Heidenhain TNC 640 Working area Travels X : 1,020 mm Travels Y : 700 mm Travels Z : 500 mm Clamping surface (L x B) : 1,050 x 700 mm Table load max. : 800 kg Spindle Speed : 15,000 rpm Tool holder : SK 40 In general Tool changer : 30 stations Dsdet A Ucpspfx Aduecr Machine bed : Meehanite cast Rapid traverse (X/Y/Z) : 32 / 32 / 32 m/min Equipment / Accessories Chip management : Chip conveyor Coolant : high pressure coolant 30bar Handwheel : electr. Handwheel Additional parts : flushing gun Linear scale : direct

Condition: used, Machine type: CNC Horizontal Machining Center Model: FH6800 Manufacturer: MAZAK Control: Mazatrol 640M Year of initial operation: 2010 Dedpfexxzlvsx Aduocr Location: Germany Options: - Number of tool magazine pockets: 80 pcs - MAZAK Monitoring B (Renishaw probe) - Software options package “Performance” - NC rotary table (C-axis) 0.001 degree - Chip conveyor Mayfran Consep 2000 - Through-spindle coolant (IKZ) pressure: 20 bar Travel X-axis: 1,050 mm Travel Y-axis: 800 mm Travel Z-axis: 880 mm Rapid traverse X/Y/Z-axis: 40 m/min Pallet size: 630 x 630 mm Max. spindle speed: 7,000 rpm Coolant supply: 20 bar

Condition: used, Overall dimensions (machine and tool magazine) : 7000 x 4400 x 3850 mm Shipping dimensions (machine) : 7000 x 3500 x 3850 mm Tool magazine dimensions : 6000 x 2100 2850 mm Dcedpfx Aexzdr Roduor TECHNICAL DETAILS x-travel: 1000 mm y-travel: 800 mm z-travel: 1100 mm Control name: Siemens Feed force X-axis: at ED S3 -40% 15000 N Feed force Y-axis: at ED S3 -40% 15000 N Feed force Z-axis: at ED S3 -40% 20000 N Feed rate in X, Y and Z axes: 1 - 30000 mm/min Rapid traverse speed: 30000 mm/min Acceleration in X-, Y- and Z-axes: 3.0 m/s² Rotary indexing table: 20 l/min Tool holder: SK50 Spindle diameter in the front bearing: 100 mm Speed range: 45 - 4,500 rpm Pallet size: 630 x 800 mm Pallet change time: 21 s

Condition: ready for operation (used), Year of construction: 2019, General Data Measurements height 3280 mm Machine weight 24000 kg Main Drive Spindle speed range 12000 Number of axis 4 Movement X-Axis Movement 1000 mm X-Axis Rapid Traverse 60 m/min Y-Axis Movement 900 mm Y-Axis Rapid Traverse 60 m/min Z-Axis Movement 1000 mm Z-Axis Rapid Traverse 60 m/min Table Table load 1200 kg Tools Number of station 171 Dcedpox D Rtmsfx Aduer Type of tool holder HSK 100 This 4-axis Okuma MA 600H II was manufactured in 2019. It features a 630 × 630 mm table, capable of handling loads up to 1,200 kg, and a high-speed spindle up to 12,000 rpm. The machine offers rapid traverse rates of 60 m/min and a comprehensive tool magazine with 171 stations. If you are looking to get high-quality milling capabilities consider the Okuma MA 600H II machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 2007, operating hours: 40,933 h, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: Siemens, controller model: 840D PL, table width: 630 mm, table length: 630 mm, spindle speed (max.): 8,000 rpm, number of spindles: 1, Machine name / type: HELLER / MCH 280 C Operating hours: 40.933h Year of construction: 2007 Control unit: Siemens 840D PL Spindle: 8.000 rpm (43 kW/ 822 Nm) Tool clamping system: HSK 100 Tool magazine / places (Options): Rack / 234 (Operating panel at the tool loading station with terminal) Dsdpfx Aoxwpmxjduecr Rotary table: 360.000° X 0,001° Coolant unit: KNOLL, VRF 250, IKZ 70 bar, (work area flushing) Positioning range XYZ (mm): 100 / 1000 / 1000 Pallet size (mm): 630 X 630 Workpiece clamping: mechanical Additonal options: Receiver for measuring probe (RENISHAW); interface exhaust system; additional weight for pallets; drill fracture sensing; status lamp; interface exhaust system; integrated tool and collision monitoring; toolshaft cleaning; tool codechip; Interface handheld;

Condition: good (used), Year of construction: 2017, Ref. -No.: 10596 Manufacturer: HELLER Type: H - 2000 Year of construction: 2017 Type of control: CNC Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine-No.: 56XXX X-Travel: 630 mm Y-Travel: 630 mm Z-Travel: 630 mm B-Axis: 0,001 ° Table Load: 500 kg Max. Tool Length: 350 mm Max. Tool Diameter: 160 mm Tool Taper: HSK 63 Numbers Of Tools In Magazin: 80 Turning Speeds: 16000 RPM Tool changer: Doppelgreifer Max. Workpiece height: 850 mm Max. Torque: 95 Nm Rapid Travel X/Y/Z: 60 mm / min Rapid Traverse X-Axis: 80 m / min Rapid Travel Y-Axis: 80 m / min Rapid Traverse Z-Axis: 90 m / min Drive Capacity - Spindle Motor: 40 kW Internal cooling: 50 bar Numbers Of Pallets: 2 Size Of Pallet: 400 x 500 mm spindle running time: 1000 H Operating hours: 3000 H Workpiece interference circuit max.: 720 mm Dodpfx Adoxvw Rijuecr Media interface: 5 - fach Further information: - Equipped with NC rotary table. - State-of-the-art spindle technology. - Ideal for precise machining tasks. - Spindle hours: 1000. - Pallet can be rotated manually 4 x 90 - Hydraulic pressure 200 bar - Quick drill breakage check Machine can be viewed under power by arrangement

Condition: used, Year of construction: 2002, Technical details: Dcjdpfjw T Tntsx Aduor x-travel: 1000 mm y-travel: 800 mm z-travel: 1100 mm weight of the machine ca.: 20 t dimensions of the machine ca.: 6,80 x 3,0 x 3,20 m Tool bore: SK50 Tool taper: HSK-A 100 turning speed range: 45-6.000 U/min size of pallet: 630x800 mm change time of pallets: 21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to *

Condition: like new (used), Year of construction: 2023, operating hours: 200 h, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, feed length X-axis: 1,000 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,000 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, controller manufacturer: Siemens, controller model: Siemens 840d solution line SL, workpiece length (max.): 900 mm, workpiece width (max.): 900 mm, workpiece height (max.): 900 mm, workpiece diameter (max.): 900 mm, table width: 630 mm, table length: 630 mm, table load: 850 kg, overall weight: 16,000 kg, spindle speed (min.): 5,000 rpm, spindle speed (max.): 8,000 rpm, operating hours of spindle: 960 h, coolant supply: 70 bar, spindle motor power: 43,000 W, spindle nose: HSK100, number of spindles: 1, input voltage: 400 V, type of input current: AC, Equipment: chip conveyor, rotational speed infinitely variable, List price new: €749,000 HSK100, the machine is in like-new condition and has not yet produced any series parts. Dedpfx Adexzh Ebsuscr So far, only one component has been sampled.

Condition: excellent (used), Kitamura HX630i Horizontal Machining Center Dedpfx Adjxx Drxjuscr Year of manufacture: 2010 Control: Fanuc 16i-MB Travel paths: X: 1000 mm Y: 800 mm Z: 820 mm B axis: 0.001° Table size: 630 mm x 630 mm Spindle: 12,000 rpm Tool changer: 50 positions Tool holder: BT50 The machine is in very well-maintained condition.

Condition: ready for operation (used), Year of construction: 2011, General Data Measurements width 6110 mm Measurements depth 3380 mm Measurements height 3280 mm Machine weight 24000 kg Main Drive Spindle speed range 12000 Number of axis 4 Movement X-Axis Movement 1000 mm X-Axis Rapid Traverse 60 m/min Y-Axis Movement 900 mm Y-Axis Rapid Traverse 60 m/min Z-Axis Movement 1000 mm Z-Axis Rapid Traverse 60 m/min Tools Number of station 150 Max weight 25 kg Max tool diameter 140 mm Max tool length 450 mm Type of tool holder HSK 100 This 4-axis Okuma MA 600 HB was manufactured in 2011, featuring a robust horizontal machining center design. It boasts X, Y, and Z axis travels of 1,000 mm, 900 mm, and 1,000 mm respectively, and a maximum spindle speed of 12,000 rpm. The machine includes a high-capacity 150-tool chain magazine with rapid tool change times. Consider the opportunity to buy this Okuma MA 600 HB horizontal machining center. Contact us for more information about this machine. Dcjdpfx Adex D Hzyjujr Application Types Milling

Condition: like new (used), Year of construction: 2007, HYUNDAI WIA KH63G - YOM 2008/ FIRST INSTALLED 2010 - SERIAL NUMBER G3641-071 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Horizontal Machining Centre. • One Piece Heavy Duty Cast Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Oil Cooled 2 Stepped Geared High Torque Spindle. • Shuttle Type Pallet Changer. • Pre-Tensioned Double Anchored Ballscrews. TABLE Table Size 630 X 630 MM Maximum Load Capacity 1,000 KGS Maximum Working Size Ø 1,120 X H 875 MM Minimum Index Angle 1° FEED X-Axis 950 MM Y-Axis 825 MM Z-Axis 760 MM Distance from Table Surface to Spindle Centre 175 ~ 935 MM Distance from Table Centre to Spindle Nose 0 ~825 MM Guide Type HARDENED & GROUND BOX GUIDEWAYS SPINDLE Spindle Taper #50,DIN 69871 Spindle rpm 4,500 RPM Spindle Motor Output (Max/Cont.) 26.0 / 22.0 KW Spindle Torque (Max/Cont.) 1,267 / 1,071 NM Type 2 STEPPED GEAR Dcjdpfx Adelrqiqouer FEED RATE Cutting Feed Rate X, Y and Z-Axis 5 M / MIN Rapid Feed Rate X, Y and Z-Axis 20 M / MIN ATC Number of Tools 60 Tool Type ISO 50, DIN69871 Maximum Tool Diameter Ø 110 MM Max. Tool Diameter without Adjacent Tools Ø 245 MM Maximum Tool Length 600 MM Maximum Tool Weight 20 KGS Tool Selection Method FIXED ADDRESS Tool Change Time – Tool to Tool 6 SEC Tool Change Time – Chip to Chip 11 SEC APC Number of Pallets 2 APC Type SHUTTLE TANK CAPACITY Coolant Tank 400 L POWER SUPPLY Electric Power Supply 36 KVA Voltage 415 V / 50 HZ / 3PH MACHINE Floor Space (L x W) 3,530 X 5,320 MM Height 3,106 MM Weight 14,000 KGS STANDARD SUPPLIED MACHINE FEATURES • Total Splash Guard • Door Interlock • APC (2 Pallets) • Remote MPG • Coolant Tank • Internal Chip Conveyor (2 Sets) • Work Light • Tapped Holes in Pallets • Levelling Pads and Bolts • Operation/Programming Manuals • Call Light • Selection of Spindle Tooling

Condition: good (used), Year of construction: 2011, Ref. -No.: 10565 Manufacturer: TOYODA Type: FH 630 SX Year of construction: 2011 Type of control: CNC Control: Fanuc 31i - A Storage location: Halberstadt Country of origin: Japan Serial no.: NS3XXXX X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 850 mm B-Axis: 360 ° Distance Spindle /Table: 200 - 1050 mm Max. Workpiece Weight: 800 kg Max. Tool Weight: 27 kg Max. Tool Length: 545 mm Max. Tool Diameter: Ø120 mm Max. Size Of Workpiece Lxwxh: Ø 1000 x 1000 mm Tool Taper: BT - 50 Tool Piece Magazine With: 60 Pcs./pcs. Spindle Speed: 6000 RPM Rapid Travel X/Y/Z: 60 mm / min Tool to tool: 2,4 sec Machine length: 7000 mm Machine width: 3500 mm Weight Of The Machine Ca.: 20,1 t Pallet height: 1200 mm Positioning (X, Y and Z axes):: + - 0,003 mm Djdpfxexvw I Io Adujcr Repeatability (X, Y and Z axes):: + - 0,0015 mm Payload pallet: 800 kg Axial: 14700 N Further information: - Cutting feed (same for X-, Y- and Z-axis): 0.001 - 30m/min - Distance between spindle center and upper edge of the area: 100mm - 900mm - Table size range: 630 mm - Positioning of the lower table: 1 ° - Positioning of the rotary table: 0.001 ° - Tools used: SK 50 - Operating oil: 53l - Slide lubricating oil / spindle head lubrication: 3.0 l - Coolant for spindle & ball screw head: 37l Machine can be inspected under power by arrangement.

Condition: used, Year of construction: 2008, x-travel 1000 mm y-travel 1000 mm z-travel 1000 mm Control Siemens 840D powerline spindle tunring speed 8.000 U/min drive capacity - main spindle 100/40% ED 32/44 kW tool taper HSK-A 100 number of tool places 354 Pos. rapid traverse ( x / y / z ) 60 m/min size of pallet 800 x 800 mm In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features: - NC rotary table with pallet carrier Dcodpexcp R Ujfx Aduor - Rotary pallet changer - 40 bar internal coolant supply - Rotating viewing window - Wall-mounted magazine with 300 magazine positions - Rotating wall tool lock, 30 positions (inactive) and 54 positions (active) - Infrared measuring probe - SK 50 mechanical tool breakage detector - Tool identification - 4-color signal lamp Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: ready for operation (used), Year of construction: 2009, General Data Machine weight 21000 kg Dodpfx Adsx D I Rvjuocr Control Unit Model 31i–Mod.A Brand FANUC Main Drive Number of spindles 1 Spindle speed range 600 Spindle motor power 30 Kw Tool taper ISO 50 Din 69871 Number of axis 4 Movement X-Axis Movement 1000 mm X-Axis Rapid Traverse 48 m/min Y-Axis Movement 800 mm Y-Axis Rapid Traverse 48 m/min Z-Axis Movement 850 mm Z-Axis Rapid Traverse 48 m/min Tools Number of index 60 Media Chip conveyor Yes Additional Equipment 2 Pallets (dimensions 630 x 630 mm, indexing: 1°, change type: 180° rotary, weight allowed on the pallet: 1,200 kg) Renishaw predisposition Remote electronic handwheel The DOOSAN HM 6300 is a 4-axis horizontal machining centre from 2009 with a CNC FANUC 31i-Mod.A control unit. It offers expansive axis movement: 1000 mm on X, 800 mm on Y, and 850 mm on Z, with rapid 48 m/min travel. The two 630 x 630 mm pallets, with a 1° indexing and 180° rotary change, support 1,200 kg each. The spindle, powered by a 30 kW motor, reaches 6000 rpm, and the 60-position tool chain accommodates various tool sizes. Accessories include a chip conveyor, Renishaw predisposition, and a high-pressure coolant system. Contact us for more details. Application Types Milling

Condition: excellent (used), Year of construction: 2004, Used Kia Model Kia Centre H63 Twin Pallet Horizontal Machining Centre with 60 Station ATC and Fanuc 18M Control. Serial Number KH630216. Year of Manufacture 2004. MACHINE CONSTRUCTION & FEATURES • One Piece Heavy Duty Cast Iron Bed Construction for High Accuracy & Rigidity • Heavy Duty Oil Cooled 2 Stepped Geared High Torque Spindle • Shuttle Type Pallet Changer • Pre-Tensioned Double Anchored Ballscrews • Fanuc 18M Control with 15 Inch Colour Screen • 20 Bar ‘Cool-Jet’ Through Spindle Coolant • Set of BT50 Toolholders • Filtermist FX5002 Mist Filtration • Frontal and Side Operators Platforms TABLE Table Size 630 X 630 MM Maximum Load Capacity 1,000 KGS Maximum Working Size Ø 1,120 X H 875 MM 0bwkk Minimum Index Angle 1° Dcodpfxju A Ut Ns Adujr FEED X-Axis 950 MM Y-Axis 825 MM Z-Axis 760 MM Distance from Table Surface to Spindle Centre 175 ~ 935 MM Distance from Table Centre to Spindle Nose 0 ~825 MM Guide Type HARDENED & GROUND BOX GUIDEWAYS SPINDLE Spindle Taper NT #50 Spindle rpm 4,500 RPM Spindle Motor Output (Max/Cont.) 26.0 / 22.0 KW Spindle Torque (Max/Cont.) 1,267 / 1,071 NM Type 2 STEPPED GEARED HEADSTOCK FEED RATE Cutting Feed Rate X, Y and Z-Axis 5 M / MIN Rapid Feed Rate X, Y and Z-Axis 20 M / MIN ATC Number of Tools 60 Tool Type BT #50 Maximum Tool Diameter Ø 110 MM Max. Tool Diameter without Adjacent Tools Ø 245 MM Maximum Tool Length 600 MM Maximum Tool Weight 20 KGS Tool Selection Method FIXED ADDRESS Tool Change Time – Tool to Tool 6 SEC Tool Change Time – Chip to Chip 11 SEC APC Number of Pallets 2 APC Type SHUTTLE TANK CAPACITY Coolant Tank 400 L POWER SUPPLY Electric Power Supply 36 KVA Voltage 415V / 3PH / 50HZ MACHINE Floor Space (L x W) 3,610 X 5,320 MM Height 3,140 MM Weight 14,000 KGS

Condition: good (used), Year of construction: 2008, Ref. -No.: 10564 Manufacturer: TOYODA Type: FH 630 SX Year of construction: 2008 Type of control: CNC Control: Fanuc 31i - A Storage location: Halberstadt Country of origin: Japan Serial no.: NS2XXX X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 850 mm B-Axis: 360 ° Max. Workpiece Weight: 800 kg Max. Tool Weight: 27 kg Max. Tool Length: 545 mm Max. Tool Diameter: Ø 120 mm Max. Size Of Workpiece Lxwxh: Ø 1000 x 1000 mm Tool Taper: BT - 50 Tool Piece Magazine With: 60 Pcs./pcs. Spindle Speed: 6000 RPM Dcodpfxjxvw Izo Aduor Machine length: 7000 mm Machine width: 3500 mm Weight Of The Machine Ca.: 20,1 t Further information: - Equipped with IKZ and chip conveyor - NC rotary table 360,000 * 0.001° Machine can be inspected under power by arrangement.

Condition: ready for operation (used), Year of construction: 2007, General Data Measurements width 3400 MM Measurements depth 8000 MM Measurements height 3300 MM Machine weight 24000 KG Main Drive Spindle speed range 6000 RPM Number of axis 4 Movement X-Axis Movement 1000 Y-Axis Movement 800 Z-Axis Movement 810 Table Outer length 630 MM Outer width 630 MM Additional Equipment Number of tools (atc warehouse) 160 This 4-axis OKUMA SPACE CENTER MA-600HB horizontal machining center was manufactured in 2007. It boasts a robust 160-tool ATC warehouse, continuous 4th axis table, and high-pressure cooling system at 30 BAR. With X/Y/Z strokes of 1000/800/810 mm and a maximum spindle speed of 6000 RPM, this machine ensures precision and flexibility for various machining tasks. The OKUMA MA-600HB machine we have for sale is designed for heavy-duty machining, accommodating pieces up to 1500 kg. For further details, please contact us. Application Types Milling Djdex D R Evjpfx Aduscr

Condition: like new (used), Year of construction: 2007, HYUNDAI WIA KH63G - YOM 2008/ FIRST INSTALLED 2010 - SERIAL NUMBER G3641-071 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Horizontal Machining Centre. • One Piece Heavy Duty Cast Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Oil Cooled 2 Stepped Geared High Torque Spindle. • Shuttle Type Pallet Changer. • Pre-Tensioned Double Anchored Ballscrews. TABLE Table Size 630 X 630 MM Maximum Load Capacity 1,000 KGS Maximum Working Size Ø 1,120 X H 875 MM Minimum Index Angle 1° FEED X-Axis 950 MM Y-Axis 825 MM Z-Axis 760 MM Distance from Table Surface to Spindle Centre 175 ~ 935 MM Distance from Table Centre to Spindle Nose 0 ~825 MM Guide Type HARDENED & GROUND BOX GUIDEWAYS SPINDLE Spindle Taper #50,DIN 69871 Spindle rpm 4,500 RPM Spindle Motor Output (Max/Cont.) 26.0 / 22.0 KW Spindle Torque (Max/Cont.) 1,267 / 1,071 NM Type 2 STEPPED GEAR FEED RATE Cutting Feed Rate X, Y and Z-Axis 5 M / MIN Rapid Feed Rate X, Y and Z-Axis 20 M / MIN ATC Number of Tools 60 Tool Type ISO 50, DIN69871 Maximum Tool Diameter Ø 110 MM Max. Tool Diameter without Adjacent Tools Ø 245 MM Maximum Tool Length 600 MM Maximum Tool Weight 20 KGS Tool Selection Method FIXED ADDRESS Dcjdpju A Td Tefx Adujr Tool Change Time – Tool to Tool 6 SEC Tool Change Time – Chip to Chip 11 SEC APC Number of Pallets 2 APC Type SHUTTLE TANK CAPACITY Coolant Tank 400 L POWER SUPPLY Electric Power Supply 36 KVA Voltage 415 V / 50 HZ / 3PH MACHINE Floor Space (L x W) 3,530 X 5,320 MM Height 3,106 MM Weight 14,000 KGS STANDARD SUPPLIED MACHINE FEATURES • Total Splash Guard • Door Interlock • APC (2 Pallets) • Remote MPG • Coolant Tank • Internal Chip Conveyor (2 Sets) • Work Light • Tapped Holes in Pallets • Levelling Pads and Bolts • Operation/Programming Manuals • Call Light • Selection of Spindle Tooling

Condition: good (used), Year of construction: 2007, Ref. -No.: 10357 Manufacturer: STARRAG HECKERT Type: HEC 630 Athletic Year of construction: 2007 Type of control: CNC Steuerung Control: Sinumerik 840D Storage location: Halberstadt Country of origin: Schweiz X-Travel: 1200 mm Y-Travel: 950 mm Z-Travel: 1200 mm Work spindle drive power (25% ED): 67 kW Work spindle torque (25% ED): 1508 Nm Tool Taper: HSK-A100 Workpiece interference circle diameter: 1250 mm Tool Piece Magazine With: 80 Pcs./pcs. Tool changer: Werkzeugkettenmagazin Max. Workpiece height: 1200 mm Feed Speeds X/Y/Z Axis: 60000 mm / min Feed Capacities X/Y/Z: 22/18/22 N Speed range - main spindle: 20 - 6000 RPM Numbers Of Pallets: 2 Djdpfx Adsxvw Eyjuocr Max pallet load: 1500 kg Size Of Pallet: 800 x 630 mm pallet change time: 14 s Pallet clamping area (lxw): 800 x 630 mm Weight Of The Machine Ca.: 25 t

Condition: ready for operation (used), Year of construction: 2002, operating hours: 400 h, General Data Machine weight 15000 kg Measurements height 3950 mm Dimensions Machine Length 9500 mm Dcsdpfx Aox D D I Deduer Table Table load 1000 kg Control Unit Brand FANUC Model 16iMA Main Drive Spindle Speed 10000 RPM Number of axis 3 Spindle motor power 30 kW Movement Z-Axis Movement 1000 mm Y-Axis Movement 1200 mm X-Axis Movement 1080 mm This 5-axis MORI SEIKI SH8000/5AX was manufactured in 2002. Fully overhauled in 2016, it features a Fanuc 16iMA control, a spindle speed of 10,000 rpm, and a tool magazine with a capacity of 150 tools. The machine has a pallet size of 630 × 630 mm and a loading capacity of 1000 kg. If you are looking to get high quality milling capabilities consider the MORI SEIKI SH8000/5AX machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2008, Ref. -No.: 10335 Manufacturer: HüLLER HILLE Type: NBH 170 Year of construction: 2008 Type of control: CNC Control: Sinumerik 840D pl Storage location: Halberstadt Country of origin: Germany X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 800 mm B-Axis: 360 ° Distance spindle center - table: 150 mm Table Dimensions (Lengthxwidth): 500 x 630 mm Table Load: 800 kg Max. Workpiece Weight: 40 kg Max. Tool Length: 650 mm Max. Tool Diameter: 325 mm Workpiece Diameter At Full Load: 100 mm Tool Taper: HSK - 100 Spindle Speed: RPM Rapid Traverse: 60 m / min Machine length: 9500 mm Machine width: 4500 mm Machine Height: 3500 mm Further information: Coolant system = 1250 l Djdpfsxvw Etjx Aduecr

Condition: ready for operation (used), Year of construction: 2016, General Data Measurements width 3415 mm Measurements depth 6015 mm Measurements height 3500 mm Movement X-Axis Movement 1050 Y-Axis Movement 920 Z-Axis Movement 960 A-Axis Movement +30°～-120° B-Axis Movement ±360° Table Outer length 630 mm Outer width 630 mm Media Chip conveyor Yes Additional Equipment Tool Magazin: ATC 240 positions Air Cleaner: AR Filtrazioni Equipment: Chip conveyor, Laser tool presetting This 5-axis Matsuura MAM 72-100H was manufactured in 2016, offering advanced capabilities for efficient and precise machining. Ideal for complex parts, this horizontal machining centre is a robust addition to any production line. Consider the opportunity to buy this Matsuura MAM 72-100H horizontal machining centre. Contact us for more information. Dcodpfx Adsx D Svvousr Application Types Milling
