Used CNC lathes 250-299mm turning diameter for sale (72)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 0040000281C, turning length: 500 mm, spindle speed (max.): 6,000 rpm, overall weight: 4,300 kg, controller model: Heidenhain Plus IT DinPlus/TurnPlus V7, TECHNICAL DETAILS Turning length: 500 mm Y-axis travel for cross slide: ±40 mm Spindle type: Integrated spindle motor ISM 52 Plus Drive power: 20/27 kW at 100/40 % duty cycle Spindle speed: 6,000 rpm Turret: 12-position disc turret Sauter Tool holder: VDI 30, DIN 69880-30 Tool drive: Connection/drive according to DIN 5480 MACHINE DETAILS Control system: Heidenhain Plus IT DinPlus/TurnPlus V7 Clamping system: Hydraulic collet chuck Draw tube inner diameter: 52 mm Measuring system: Direct measuring system Glass scale: X-axis Connected power: 25 kVA Rated current: max. 40 A Fuse rating: 44 A Mains voltage: 400 V Mains frequency: 50/60 Hz Holjztb Adshccqmjnr Input voltage: 230 V Output voltage: 24 V Weight: 4,300 kg EQUIPMENT C-axis Hydraulic spindle brake Tailstock Chip conveyor with coolant system Connection for oil mist separator including electrical connection Coolant spray gun Separate speed limiting device for the main spindle for power chucks with predefined speeds below the maximum machine speed Documentation Tool case for disc turret Ø 30

Condition: used, Year of construction: 2001, turning diameter 280 mm turning length 400 mm control Fanuc 18 T spindle bore diameter 51 mm number of controlled axis 2 turning speed range 0 - 4000 U/min rapid speed 30 m/min number of tapers in turret head 12 VDI 40 tail stock Ja dimensions 3,9 x 1,6 x 2,1 m Hjlhccqoyxr Hgomsnr weight of the machine ca. 3,9 t power requirement 15 kW Used CNC- Lahte with box way, 2 axis - 3 jaw chuck Ø 200 mm - chip conveyor - oil dust collector

Condition: used, Year of construction: 2014, Hardinge GS200 CNC Lathe 2010 Hardinge GS200 CNC slant bed lathe equipped with Fanuc Series Oi-TD control. ----- Control Fanuc Series Oi-TD CNC Control ----- Capacity Chuck Size: 3 Jaw Bar Capacity: 52mm Maximum Swing: 457mm Maximum Cutting Diameter: 284mm Maximum Cutting Length: 406mm Distance Between Centres: Not specified ----- Main Spindle Maximum Spindle Speed: 5,000 RPM ----- Turret Number of Stations: 12 ----- Axis Travels X Axis Travel: 218mm Z Axis Travel: 406mm ----- Accessories Hydrafeed Multifeed 65 Barfeed Holhccqoylchtemsnr Swarf Conveyor Control: Fanuc Spec: Spindle bore 52 mm | Max Swing 457 mm | Travel X 218 Z 406 mm Accessories: Tailstock, parts catcher & 8" Power Chuck, Swarf conveyor, Collet chuck

Condition: used, Year of construction: 2006, Technical details: turning diameter over bed: 284 mm turning dia. over face-slide: 380 mm turning length: 381 mm x-axis: 153 mm longitudinal traverse (z-axis): 406 mm control: Siemens 810D revolution per minute: 5000 U/min spindle bore: 52 mm tool turret - number of stations: 12 Stationen / Stations operating hours - idle run: 78000 h Hnjlhezrlvlsccqmsr electrics - voltage/frequency: 400/50 V/Hz total power requirement: 11 kVA Weight approx.: 2,8 t dimension machine approx.LxWxH: 3,0 x 1,6 x 1,8 m

Condition: good (used), Year of construction: 2015, turning diameter over cross slide: 660 mm, turning length: 3,000 mm, spindle bore: 82 mm, spindle speed (max.): 1,500 rpm, spindle motor power: 11,000 W, total height: 1,500 mm, total length: 4,700 mm, total width: 625 mm, Centre lathe CONTUR SAEILO - SJ-600L MACH-ID 9759 Make: CONTUR SAEILO Type: SJ-600L Year: 2015 3 chuck schunk 315 mm 4 chuck schunk 400 mm Multi fix tool system with inserts Digital reafdout system Steady rest  DBC Turning Length: 3000mm Swing over bed Ø: 660mm Swing over cross slide Ø:438mm Spindle bore: 82mm Spindle power: 11kW Bed width: 400mm Tailstock spindle Ø: 85Ø Hnelhccqezpwplemer Stroke pinole: 165mm Spindle taper: 5Mk Speeds / ranges: 1500Rpm Length: 4700mm Width: 625mm Height: 1500mm Weight: 3000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2017, operating hours: 5,190 h, functionality: fully functional, MAIN SPINDLE MAX. BAR DIAMETER: 70 MM MAX. TURNING DIAMETER: 290 MM MAX. TURNING LENGTH: 560 MM SPINDLE NOSE: A2-6 SPINDLE POWER: 11 KW SPINDLE SPEED: 40-4000 RPM C AXIS: 360° INCR. INDEXING 0.001° TURRET NUMBER OF POSITIONS: 12 NUMBER OF LIVE POSITIONS: 12 AXES: X=170 MM, Z=560 MM, Y=+55/-50 MM SUB-SPINDLE SPINDLE NOSE: A2-5 SPINDLE POWER: 11 KW SPINDLE SPEED: 5000 RPM C AXIS: 360° INCR. INDEXING 0.001° Hnjlhjwurdwjccqmer CONTROL FANUC 32i-B

Condition: excellent (used), SOMAB TRANSMAB 200 is a CNC turning lathe with slant bed, engineered for precision, high accuracy and reliability. Swing over bed 260 mm, spindle bore 35 mm; travels Z 300 mm, X 125 mm. Turret DUPLOMATIC with 8 positions, 8 fixed tools, 16 mm tool shank, inner cone Ø20 mm. Stepless spindle 200–5000 rpm, spindle motor 4 kW, spindle taper A2-4", tailstock Morse 3 with 80 mm stroke and 52 mm diameter, pressure 1200 N; voltage 3x400 V 50 Hz; machine weight ~2500 kg; dimensions L1900×W1400×H1980 mm. Equipment: collet device and set (F38), lamp, tool cabinet, RS232 interface, foot pedal, set of toolholders. Delivers tight tolerances; typical applications: automotive, aerospace, medical, machine tools and watchmaking. Hnelhcozqbmwjcqmjr

Condition: ready for operation (used), Year of construction: 2018, spindle speed (max.): 4,000 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 500 mm, spindle motor power: 4,000 W, total height: 1,700 mm, total width: 890 mm, overall weight: 1,050 kg, bar diameter (max.): 43 mm, product length (max.): 1,570 mm, workpiece diameter (max.): 280 mm, number of slots in tool magazine: 4, number of axes: 2, Horizontal turning machine manufactured in 2018. This Weiler PRIMUS VCD features a connected load of 7.5 kVA and operates at a nominal current of 15.5 A. With a machine weight of 1050 kg, it is designed for robust performance. If you are looking to get high-quality turning capabilities, consider the Weiler PRIMUS VCD machine we have for sale. Contact us for further details. • Machine Type: Centre Lathe • Turning Length / Distance Between Centres: 500 mm • Swing Over Bed: 280 mm • Swing Over Cross Slide: 150 mm • Spindle Nose (DIN 55027): Size 5 • Front Bearing Diameter: 70 mm • Spindle Bore: 43 mm • Main Spindle Internal Taper: ME 50 • Drive Power (100% Duty Cycle): 4 kW • Spindle Speed Range: 30 – 4,000 rpm • Number of Feed Rates: 24 • Longitudinal Feed Range: 0.02 – 0.63 mm/rev • Cross Feed Range: 0.006 – 0.20 mm/rev • Metric Thread Range: 0.25 – 8 mm • Inch Thread Range: 80 – 2 TPI • Module Thread Range: 0.25 – 4 Module • Diametral Pitch (DP) Thread Range: 200 – 5 DP • Tailstock Quill Diameter: 40 mm • Tailstock Quill Travel: 85 mm • Tailstock Taper: MT3 • Operating Voltage: 400 V • Control Voltage: DC 24 V • Connected Load: 7.5 kVA • Nominal Current: 15.5 A • Frequency: 50 Hz • Main Fuses: 25 A Hnjlhccqozpwh Uemer • Machine Weight: 1,050 kg • Machine Dimensions (L × W × H): 1,570 × 890 × 1,700 mm Additional Equipment • 4-Position Quick-Change Tool Post PARAT Size 1, incl. 1 × WD 1/12 Tool Holder • 2 × WD 1/12 Tool Holders • Lever-Operated Collet Chuck for 173 E Collets • 13 × 173 E Collets, Clamping Range: 3–15 mm (1 mm Increments) • Fixed Steady Rest with Roller Jaws, Capacity: 15–100 mm • Movable Chip Splash Guard with Viewing Window • 8 × Levelling Elements Technical Specification Counter Spindle No Driven Tools No

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Controller GE FANUC 21i-TB Swing dia 533 mm Turning dia 340 mm Turning lenght 355 mm X travel 209 mm Z travel 355 mm Spindle hole D50,8 mm Spindle speed 5000 rpm Chuck size max. D200 mm Turret 12-fold Rapid speed 30 m/min Spindle power 11 kW Spindle face A2-6 Tool holder type VDI30 C axis 0,001 degree (programmable) Dimensions LxWxH = 2300 x 1700 x 1700 mm Weight ca 3000 kg Features, accessories - Hydraulic chuck - Short barfeeder EMT Super 80 - Manual Guide in FANUC Software - Drive tool turret and C axis - Tailstock - Part catcher - Manuals Hjlhccqjvw Uqajmjnr Very good condition. The lathe works accurately and run quitely. Ready to buy immediately.

Condition: ready for operation (used), CNC Lathe TAKAMAZ EX 20 / Fanuc 15 TF - Control: FANUC 15 TF - Max. turning diameter: 260 mm - Turning length: approx. 500 mm - Bar capacity: 42 mm - Spindle speeds: 40 - 4000 rpm - Spindle nose: A2-6 - Tool positions (stations): 12-fold / direct mount - Tool measurement (Tooleye) - Parts catcher - Tailstock - Collet chuck: 173 E - Spindle motor: 7.5 kW Hjlhceztycvscqmjnr Dimensions (LxWxH): 2.6 x 2 x 1.8 meters / Weight: 2,800 kg Errors and omissions excepted.

Condition: used, Spare parts donor We are dismantling the CNC turning machine GILDEMEISTER, type GDM 42/2A CNC control system Eltropilot EPL 2 Machine no. 4.5733, year of manufacture 1989 Machine not operational - electrical problems Turning diameter, normal: 185 mm Swinging diameter, max.: 400 mm Cross slide travel = planar travel: 190 mm Longitudinal slide travel = longitudinal travel: 450 mm Spindle bore in the turning spindle: 52.7 mm Hnslhsdzqm Rsccqmor Spindle passage in the draw tube: Ø 42 mm Feed rate X and Z, max.: 3000 mm/min Spindle speed: 40-6300 rpm, continuously variable Motor power, spindle drive: 22 kW Mains connection: 400 volts, 50 Hz, 45 kVA - Hydraulic 3-jaw chuck FORKARDT, Ø 200 mm - Tool turret, 12-station, VDI 40, every second station powered - Powered tool station in 6 stations - Electrical cabinet located beside the machine Footprint of the complete machine, L x W x H: 5000 x 2500 x 2100 mm Weight of the complete system: approx. 5.7 tons good condition Transport dimensions: Footprint of the base machine, L x W x H: 3000 x 2300 x 1900 mm Weight of the base machine: approx. 4.8 tons Footprint of the machine's electrical cabinet, L x W x H: 2500 x 550 x 2000 mm Weight of the machine's electrical cabinet: approx. 450 kg without chip conveyor Main motor missing Individual parts available upon request In the electrical cabinet: Siemens Siemens 6SC6101-3A-Z + the circuit boards

Condition: used, Year of construction: 1996, turning diameter 250 mm turning length 1000 mm Control Philips CNC-Steuerung weight of the machine ca. 8 t PHILIPS CNC control X-axis: 295 mm / Y-axis: 295 mm Center distance: 1000 mm Max. diameter on the bed: Ø 310 mm Helhccqjyan R Ajmjnr Max. diameter when turning: Ø 250 mm. Maximum turning speed: 4500 rpm. Spindle bore diameter: Ø 78 mm Turret with 8 tools Weight: approx. 8 tons

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 100 mm, travel distance Z-axis: 290 mm, Control: Fanuc 0-T Max. spindle speed: 6000 rpm Chuck size: 6 in Max. machining diameter: 160 mm Max. machining length: 285 mm Spindle bore: 40 mm X-axis travel: 100 mm Z-axis travel: 290 mm Axes: 2 Hnjlozr I Auohccqmjr Tool positions: 8 Turret stations: 8 Tailstock: Included Made in: South Korea Year: 2002 Swing Over Bed: 300 mm Spindle Power: 11 kW Weight: 2600 kg Length: 2000 mm Width: 1100 mm Height: 1300 mm

Condition: new, Year of construction: 2026, Swing over bed 290 mm Swing over cross slide 185 mm Distance between centers 750 mm Bed width 180 mm Spindle bore 38 mm Spindle taper MT5 Number of spindle speeds 2 Spindle speed range 75–500 / 300–2000 rpm Number of metric threads 18 Metric thread range 0.2–3.5 mm Number of inch threads 21 Inch thread range 8–56 TPI Cross feed range 0.017–0.25 mm/rev Longitudinal feed range 0.07–0.72 mm/rev Tool post type: 4-position quick-change Maximum upper carriage travel: 80 mm Maximum cross carriage travel: 150 mm Maximum longitudinal slide travel: 700 mm Tailstock quill travel: 80 mm Tailstock quill taper: MT3 Main motor power: 2.4 kW Maximum drilling diameter: 20 mm Maximum face mill diameter: 63 mm Maximum end mill diameter: 20 mm Spindle speed: 50–2250 rpm Spindle taper: MT2 Head tilt range: -90° to +90° Head height adjustment: 260 mm Milling head motor power: 750 W Lathe stand/stand included SINO DRO 2 digital position readout Axles KIFES Toolholders Set of 7 turning tools 16 x 16 mm with folding inserts MK3 live center Fixed telescope (included) Movable telescope (included) 4-jaw chuck 160 mm Set of safety guards (CE compliant) Set of change gears (included) Reduction sleeve (included) Maintenance wrenches (included) Oil can (included) Length 1500 mm Width 750 mm Height with stand 1100 mm Weight with stand 360 kg Hslhezr Iytjccqmsnr A larger 320 x 1000 VARIO model is available - price €3200 net.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: GN08201038G, spindle speed (max.): 4,500 rpm, center width: 460 mm, controller model: Fanuc 0i-Mate TO, power: 15 kW (20.39 HP), No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swing over bed: 250 mm Distance between centers: 460 mm Spindle bore: 62 mm Max. spindle speed: 4,500 rpm Swing over removable bed: 460 mm MACHINE DETAILS Control system: Fanuc 0i-Mate TO Power: 15.0 kW Dimensions & Weight Dimensions (L x W x H): 2,790 x 1,570 x 1,750 mm Net weight: 4,300 kg Transport packages: 2 EQUIPMENT Removable bed Hnelhezk D Ansccqmsr CE marking

Condition: ready for operation (used), Year of construction: 2007, operating hours: 40,767 h, spindle speed (max.): 5,000 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 570 mm, total height: 1,800 mm, total width: 1,350 mm, overall weight: 2,500 kg, bar diameter (max.): 52 mm, controller manufacturer: SIEMENS, product length (max.): 2,100 mm, workpiece diameter (max.): 280 mm, number of slots in tool magazine: 12, number of axes: 3, This 3-axis SPINNER TC 52 MC was manufactured in 2007. It features a robust design with optional equipment including a bar feeder, parts catcher, and a turret with driven tools. The machine is equipped with a collet chuck for clamping and a dust extraction system for efficient operation. If you are looking to get high-quality turning capabilities, consider the SPINNER TC 52 MC horizontal turning machine we have for sale. Contact us for further details. • Number of Live Tools: 12 • Live Tool Speed: 6,000 rpm • Live Tool Torque: 23.5 Nm • Rapid Traverse X/Z: 15 / 24 m/min • Maximum Turning Diameter: 280 mm Helhccjzlq I Toqmjnr • Maximum Swing Diameter: 400 mm • Distance Between Centers: approx. 550 mm • Main Spindle Nose: A6 • Bar Capacity: 52 mm • Main Spindle Torque: 92 Nm • Coolant Tank Capacity: approx. 85 l • Coolant Pressure: 8 bar • Supply Voltage: 3/PE ~ 400 V • Collet Chuck Used for Clamping • Dust Extraction System • Supply Voltage: 3/PE ~ 400 V • Frequency: 50 / 60 Hz • Operating Current (IB): 34 A • Rated Current (IN): 35 A • A collet chuck used for clamping • Turret with driven tools Optional equipment: • Bar feeder • Parts catcher • Chip conveyor • Tailstock Technical Specification Counter Spindle No Driven Tools Yes Taper Size VDI 30

Condition: good (used), Year of construction: 2003, functionality: fully functional, turning length: 650 mm, turning diameter: 250 mm, spindle bore: 65 mm, spindle speed (max.): 5,000 rpm, CNC lathe Gildemeister Twin 65Y RG2 Year of manufacture: 2003 Control system: Siemens 840D Type: CNC twin-spindle turning center Main/counter spindle: Yes Turret: 2 × 12 stations Tool holder: VDI 30 Driven tools: Yes Y-axis: Yes (upper turret) C-axes: Main and counter spindle Working area Characteristic Value Max. turning diameter: 250 mm Max. turning length: 650 mm Max. turning diameter over the bed: approx. 340 mm Bar passage: 65 mm Main spindle Characteristic Value Speed: 20–5,000 min⁻¹ Power: 35 kW Torque: 370 Nm C-axis: 0.001° Counter spindle Characteristic Value Speed: 20–5,000 min⁻¹ Power: 35 kW Torque: up to 370 Nm Bar passage: 65 mm C-axis: 0.001° Travel paths Axis Value X1: 300 mm Z1: 650 mm Y: 80 mm (±40 mm) X2: 180 mm Z2: 650 mm Tool turret Number of stations: 12 + 12 Hnslhccqozl Dy Nomor Tool holder: VDI 30 Driven tools: 4,000 min⁻¹ Power of tool drive: 11 kW Torque of tool drive: 28 Nm Chip conveyor High-pressure pump Bar loader magazine, manufacturer IRCO, type SiMag 42

Condition: used, Year of construction: 2022, controller manufacturer: Siemens, controller model: SINUMERIK 828D, _____ Description: Year of manuf. : 2022 Control : Siemens SINUMERIK 828D Turning diam. : 288 mm Turning length : 243 mm Work area max. turning diameter:288mm max. machining length:243mm X-axis:175mm Z-axis:350mm Main spindle Chuck diameter:210mm Max. bar diameter:67mm Spindle bore diameter:76mm Drive power:10.5/20 kW max. torque:213 NM max. speed:4,500 rpm Tailstock Quill diameter:65mm Quill stroke:80mm Axial force:4,312 N Center point adapter:MT4 Hneleyavz Aohccqmer Tool turret Number of tool stations:12 Tool holder:BMT45 Powered tools:Yes Max. speed:5,000 rpm

Condition: used, Year of construction: 1990, turning diameter 250 mm turning length 450 mm control TX8D bore 80 mm Hjlhccqst Hwq Demjnr spindle speed: 3150 U/min. CNC Lathe with Bar Feed and 3 Turrets Very large spindle bore, with bar loading device Please ask for further details.

Condition: used, Year of construction: 2004, turning diameter 250 mm turning length 100 mm control SIEMENS 840 D total power requirement 35 kW weight of the machine ca. 7500 kg dimensions of the machine ca. m E M A G (Germany) Vertical CNC Controlled Hard Turning and Grinding machine with tool turret and workpiece handling System Model VSC 250 DS Year 2004 # M7 28.69324 _____ Turning Ø, max. 250 mm Turning length internal / external 100 mm Workpiece length min./max. 29 – 100 mm 6-positon tool turret Ø / swing-Ø 480/790 mm Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm Feed rate / Quick feed X/Z 45/30 m/min. Feed force X/Z 5,5/11 kN Spindle speed 4.300 / 6.000 rpm Spindle drive 28 kW Hnelhccjt Hxa Tjqmer Total electrical load, approx. 35 kW - 400 V - 50 Hz Weight, approx. 7,500 kg Accessories / Special Features: * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor, graphics, menu-supervised dialogue programming, and all the usual options, cycles and subprograms, etc. * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without motorized tools posts, two positions T 3 u. T 6 equipped with grinding spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp. regular grinding tools * Workpiece handling device with WP transportation frames and circulation system and pick-up and unloading of finished parts directly through the motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW Autobloc with membrane clamping and clamping control system. * MARPOSS MIDA Measuring Probe for measuring blank parts a. the finished parts * NORGREN air measuring system, hydraulic weight compensation of spindle, * Main elements of machine are temperature stabilized by a coolant system made by HYFRA * Recooler for the grinding coolant sitting on a large Coolant device consisting of SEITZ Paper Band filter and a mobile Chipconveyor, Magnetic separator, Centrallubrication, etc. Vertical CNC lathes offer a thermo-resistant construction (chips do not fall onto the machine bed),fast workpiece change times (pick-up system through the main spindle) and a ridged tool arrangement,which also allows unrelated machining work, like hard turning or grinding process on the same machine. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2007, controller manufacturer: Siemens, controller model: 840 D, _____ Description: Year of manuf. : 2007 Control : Siemens 840 D Turning diam. : 250 mm Turning length : 650 mm In General: Year of construction:2007 Control:Siemens 840 D Bar capacity:65 mm Turning diameter:350 mm Turning length:650 mm Main spindle: Technology:Motor spindle Speed:5,000 rpm Power max.:35 kW Torque max.:370 Nm C-axis:0.001 Bar capacity:65 mm Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Hollow clamping cylinder Sub spindle: Technology:Motor spindle Speed:5,000 rpm Power:26 kW Torque:290 Nm C-axis:0.001 Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Partial hollow clamping cylinder Z-axis:670 mm X-axis:175 mm Tool carrier i (X/Y/Z): Technology:Tool turret, 12 stations Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:300 Y-axis:80 mm ( +/- 40 mm) Z-axis:650 mm Tool carrier II (X/Z): Technology:Tool turret, 12 stations Hnolhsyamflsccqmsr Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:180 Z-axis:650 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system Measuring systems:Direct in all X-axes (glass scales) Bar loader:IRCO Breuning Part removal:Finished part gripper + indexing belt Emulsion mist separator:Mechanical Set-up mode:Electronic handwheel

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, turning length: 610 mm, turning diameter: 300 mm, travel distance X-axis: 215 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 680 mm, bar passage: 81 mm, C-AXIS + Y-AXIS Holhccqjx Hpnksmenr 2 + 2 motorized tools QUICK LOAD SERVO LNS III tool changer RECONDITIONED SPINDLE LINE

Condition: used, Year of construction: 2005, Technical details: turning diameter: 275 mm turning length: 900 mm spindle passage: 65 mm power capacity at 100 % load: 25/20 kW spindle turning speed range: 1 - 5000 U/min spindle diameter in front bearing: 110 mm c-axis: 1 - 500 U/min. number of workpiece supports: 4 tool turret: 1 x-axis: 290 mm y-axis: 165 mm z-axis: 360 mm b-axis: 360 ° rapid speed: 18/30 m/min number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8000 / 2000 U/min power capacity: 25% ED 5,8 kW tool taper: TRAUB 60 tool turret: 2/3/4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid speed: 18/15/30 m/min number of driven tools: 10 mm toolpiece turning speed range: 1 - 6000 U/min power capacity: 25% ED 5,8 kW tool taper: DIN 69880 40 x 63 total power requirement: 95 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 10,0 x 3,5 x 3,0 m Hnelewp D Nbjhccqmjr with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and Sub spindle with C-axis 1 support with B-axis 3 turret supports dust exhauster, coolant attachment with coalescence-seperator and chip conveyor 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package *

Condition: used, Year of construction: 2007, spindle speed (max.): 6,000 rpm, overall weight: 2,500 kg, Fanuc 21T Hnolhoznlaisccqmer Spindle bore: 42 mm 12-position turret X: 130 mm, Z: 280 mm Weight: 2500 kg

Condition: used, Year of construction: 2001, spindle speed (max.): 5,000 rpm, overall weight: 4,500 kg, Fanuc 18IT control system 6 axes Rotary tools 12-position turret C-axis Main spindle speed: 5000 rpm, 7.5 kW Hsleznk Tnohccqmonr Tailstock spindle speed: 4500 rpm, 3.7 kW X: 160 mm, Z: 260 mm Chip conveyor
