Cnc lathe

Doosan Puma 4100A

Year of construction: 2001, condition: used, Max. pressure: 500t, max. operational temperature: 370°C, oil heated, oil cooled, with a secondary cycle for recirculation of heating output, was overhauled in 2014. Ksdpfx Afodwf Dbo Senf

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, turning diameter: 500 mm, DMG CTX Beta 1250 TC 2009 Kodsv N Hc Sspfx Af Senf

Condition: excellent (used), Year of construction: 2014, operating hours: 14,500 h, functionality: fully functional, machine/vehicle number: 11779, turning length: 700 mm, turning diameter: 250 mm, spindle motor power: 26,000 W, spindle speed (min.): 3,200 rpm, spindle speed (max.): 3,200 rpm, spindle bore: 65 mm, overall weight: 8,500 kg, incl. 2x Hainbuch/Ortlieb chucks, conveyor belt, swiveling measuring probe with 2 heads, MANUAL GUIDE_dialog programming, high-pressure pump 18 bar/20 l/min, SBS tool breakage monitoring and wear control. Machine year 2013 – Commissioned 05/2014 Good & well-maintained condition Knodpferdy Uqox Af Sof Original price approx. €300,000 !!! ATTENTION -> Sale without loader!!!

Condition: used, Year of construction: 2004, pressure 80 t stroke 16 - 63 mm no. of strokes 100 - 750 /min distance between columns 970 mm dayligth (stroke and adjustment up) 380 mm column travel -side 380 mm table surface area 940 x 910 mm hole in the table 770 x 190 mm table height over floor 1180 mm ram surface 940 x 510 mm ram adjustment 76 mm material width 203 mm material thickness - 6,0 mm feed length 0 - 120 mm power requirement 37,0 kW Weight 14,50 t dimensions of the machine ca. 2,7 x 1,7 x 3,6 m permitted for automatic mode according to the CE-Norm with infinitely variable drive, pneumatic clutch/brake combination, semi-automatic stroke adjustment, motoric ram adjustment, fix table, circular oil lubrication Knjdpfevuua Njx Af Sof mechanical roll feed Bruderer BBV 205/120 with drive via main shaft / pivot shaft of the press consoles Guethle CK A noise enclosure can be offered optionally - price on request

Condition: good (used), Year of construction: 1995, 551 kW Year of construction 1995 incl. concrete garage with silencer and additional oil cooler Engine condition: good (approx. 64,000h) Complete engine overhaul in 2017 at 48,500h Turbocharger overhauled at 60,000h Ksdpfovcm Nfox Af Ssnf Concrete garage/container: 9x3x4m (LxWxH) Offer is without guarantee of availability

Condition: ready for operation (used), Year of construction: 2018, 4-Axis CNC Vertical Lathe Brand: UMARO Model: SC27 Year: 2001 / 2018 (retrofitted) CNC: FANUC 0i Specifications: Turning capacities: Max. swing diameter: 2650 mm Max. turning diameter: 2600 mm Max. turning height: 1900 mm Table: Diameter: 2500 mm Max. load: 15 t Rotational speed (2 ranges): 1 to 112 rpm Main motor power: 75 / 60 kW Kodew Add Eopfx Af Sjnf Cross rail carriages: Vertical travel right carriage: 760 mm Vertical travel left carriage: 1200 mm Cross rail: Vertical travel: 1600 mm Dimensions (width x depth x height fully extended): 5 x 4.8 x 4.8 m Equipped with: Grinding spindle on left carriage Set of 4 jaws

Year of construction: 2006, condition: ready for operation (used), A DMG Mori 3-axis precision milling machine is available. Travel X/Y/Z: 200mm/200mm/190mm, speed: 40000rpm, feed: 30m/min, accuracy: 0.001mm. Machine dimensions X/Y/Z: approx. 1800mm/1550mm/1850mm, weight: approx. 2200kg, control: Siemens 840D, operating hours: 4979h, spindle hours: 1041h. The spindle was completely overhauled in 2023. An on-site inspection is possible. Knjdpfx Ajvi N D Sjf Ssf

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Ksdpexddvnofx Af Ssnf Faceplate diameter (removable): 1650 mm Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Special equipment Copying device for first support Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. 125 kg auxiliary crane on spindle box.

Condition: used, Year of construction: 1961, ram hammer weight 750 kg ram hammer stroke 660 mm Kedpfovuulljx Af Sjnf no. of strokes 100 /min impact energy 2040 kJ distance lower die block / ram gudeway 6600 mm Throat 750 mm steel forging - rectangular up to 240 mm steel forging - diameter up to 270 mm power requirement 75,0 kW weight of hammer 16,5 t weight of anvil 15,5 t weight 32,0 t dimensions (WxDxH) 3,2 x 1,45 x 3,45 m Forging hammer with pneumatic drive can only be offered without putting into operation in our warehouse video at seller's site before dismantling available

Condition: good (used), Year of construction: 1998, table diameter 1800 mm turning diameter 2060 mm swing diameter 2000 mm work height max. 1557 mm Knedpfxjw H Dkms Af Sof power capacity - milling spindle 30 kW workpiece weight 12 t table drive 100 kW gear box 2 Stufen grinding spindle drive 30 kW milling spindle SK50 with Grinding device
