Universal tool milling machine

DECKEL FP 1

Condition: good (used), functionality: fully functional, DECKEL FP1 Active milling machine Manufacturer: Deckel Type: FP1 Active Condition: very good Control type conventional Control active HEIDENHAIN TNC X-path 300 mm Y-path 160 mm Z-path 340 mm Tool holder SK40 Gsdpexnniaefx Abrskc Speed 40-2000 rpm. Control Active HEIDENHAIN TNC Total power requirement 2 kW Machine weight approx. 0.73 t Space requirement approx. TBH 1200x1100x1600 mm

Condition: good (used), Year of construction: 1992, functionality: fully functional, Technical details x-travel 300 mm Gjdoxl Tcgjpfx Abrekc y-travel 160 mm z-travel 290 mm table surface area 210 x 600 mm table load max. 200 kg tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 730 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a research centre. Equipment: 3-axis active digital readout made by Heidenhain TNC 113 Fixed angle table Coolant equipment Kelch mounting block Machine vise Counterholding device for the horizontal spindle

Condition: excellent (used), Year of construction: 1986, travel distance X-axis: 300 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 290 mm, Year of manufacture: 1986 Travel paths: X = 300 mm Y = 160 mm Z = 290 mm Equipment: Standard accessories Vertical milling head, SK 40/20x2 Fixed angle table 210 x 600 mm, NEW! Retrofitted safety device for milling spindle, electrically protected, NEW! Active digital display (TNC113), 3 axes Gksdpjwgafysfx Abrjc Coolant system Machine light Machine feet Documentation Condition: Good, mechanics and control system workshop-tested

Condition: ready for operation (used), Working travels 300x150x340mm Universal table 600x260mm Spindle taper 40 Spindle speeds 40-2000 rpm Gsdodr E Apopfx Abrekc Digital read-out Misc.accessories MARCELS MASCHINEN CH

Condition: good (used), Year of construction: 1980, machine/vehicle number: 4038, travel distance X-axis: 290 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 330 mm, mount diameter: 40 mm, table length: 600 mm, table width: 210 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, overall weight: 700 kg, CONDITION & NOTES: Gkodpfx Abewxpxmsrjc - This is an active, path-controlled tool milling machine

Condition: good (used), Offered for sale is a partially overhauled DECKEL FP1 Aktiv universal milling machine, equipped with a 3-axis Heidenhain digital readout TNC 113 and a dividing rotary table with a three-jaw chuck. Gedpfjxmgguox Abrjkc Thanks to its compact design, this machine is ideal for smaller hobby workshops or garages. Manufacturer: DECKEL Model: FP1 Machine no.: 2102-3314 - Travel X/Y/Z 300 x 160 x 340 mm - Spindle speed range 40–2000 rpm - Stepless feed in all three axes - Rapid traverse in all three axes - Vertical milling head - 100 mm adjustable vertically - Horizontal milling attachment - 3-axis Heidenhain digital readout TNC 113 - Coolant system - Dividing rotary table with a three-jaw chuck Total power requirement: 1.9 kW Machine dimensions (L x W x H): 1.30 x 1.10 x 1.60 m Weight: approx. 850 kg Price is quoted net, ex-works, loaded. Condition: Used.

Condition: reconditioned (used), Year of construction: 1994, Universal Tool Milling Machine DECKEL FP 1 With 3-axis active digital readout Heidenhain TNC 123 Year of manufacture: 1994 Travel: X 300 mm, Y 160 mm, Z 340 mm Spindle speed range: 40 – 2000 rpm Comes with the following accessories: Fixed angle table, 600 mm x 250 mm clamping surface Movable vertical milling head Extendable quill Infinitely variable feed via potentiometer 1 machine vice 1 tailstock with counter bearing 1 long milling arbor Ø 22 mm, Ø 16 mm, Ø 27 mm Various tool holders S 22 x 2 Z axis bellows 1 chip guard Machine lamp Automatic central lubrication pump Gkjdpfx Aow Agxrsbrec Coolant system Operating manual THE MACHINE IS IN EXCELLENT CONDITION! THE MACHINE COMES FROM A TRAINING WORKSHOP!

Condition: good (used), functionality: fully functional, DECKEL FP1 tool milling machine + tool cabinet with contents (tool holders and tools, see photos) Gksdpfx Absw Hnx Isrjc Ready for use. Price €9,700 (+ VAT) Disassembly on site and transport are the responsibility of the buyer.

Condition: ready for operation (used), Cover FP 1 Milling machine Traverse path X-axis: 300mm Y-axis travel: 160mm Z-axis travel: 340mm Mounting: SK 40 with tightening thread Feed X-axis: 290mm Weight: approx. 940 kg (with pallet) Space requirement: 1300mm x 1200mm x 1800mm ( L x W x H ) Dimensions with pallet: 1400mm x 1400mm x 2000mm ( L x W x H ) You are welcome to come by for a viewing. We are happy to arrange a cost-effective forwarding agent for you. organize! You will receive a proper invoice. A net invoice can also be issued for foreign customers. Prerequisite is a valid VAT number. Gsdpfxjuvih He Abrokc Subject to prior sale. Visit our store and have a look at our other offers. Company names and trademarks are the property of their owners and are used only to identify and describe the products. Deviations from technical data and errors in the description of the article may occur and are reserved.

Condition: good (used), Year of construction: 1995, Universal tool milling machine cover FP 1 several machines see pictures Type : FP 1 Godjtdcfhopfx Abrjkc 3-axis digital readout Heidenhain Price : from 9.500€ excl. VAT Technical data: x-path: 300 mm y-path: 150 mm z-path: 340 mm Clamping surface: 600 x 210 mm T-slots: 5 T - slot width: 12 mm Speed range - vertical: 250 - 2000 rpm Speed range - horizontal: 40 - 315 rpm Speed steps work spindle: 8 Feed range: 10 - 500 mm/min Feed steps: 8 Quill stroke: 60 mm Spindle holder: SK 40 ... Dimensions/weight: 1235x1160x1800 / approx. 800kg
