Used Vertical turning lathes for sale (193)

Condition: used, Year of construction: 2006, A VL 5 oLT, built in 2006, is for sale ex-works. The machine can be inspected under power. Bsb Ha Rsup Tizs Eyswl

Condition: good (used), Year of construction: 2010, Functionality: fully functional, GENERAL Project No: 905696 Quantity: 1 pc. Manufacturer: EMAG Type: VL 3 Control: Fanuc 18i TB Year of Manufacture: 2010 Condition: Used Machine Programme run approx. [h]: 49.479 DESCRIPTION TURNING Max. turning diameter 210 mm Max. turning length 100 mm Max. Swing diameter over bed cover 210 mm Max. speed main spindle 7500 1/min Max. power main spindle at 10-40/100% duty ratio 25/16 kW Max. torque main spindle at 10-40/100% duty ratio 200 Nm Spindle diameter in front bearing main spindle 80 mm Spindle flange size main spindle Gr. 5 (DIN 55026) Axis at main spindle unit X/Z Travel in X/Y/Z main spindle unit 400/-/200 mm Max. rapid traverse in X/Y/Z main spindle unit 60/-/30 m/min Feed force X/Y/Z main spindle unit 5000/-/5000 N Linear glass scales main spindle unit X/Z Solid clamping cylinder at main spindle Lower turret No. of stations/driven 12/12 Tool reception in turret VDI 40 FURTHER EQUIPMENT Fully enclosed work area Light in working area Oil-/emulsion mist extraction unit Slat band chain chip conveyor Discharge hight chip conveyor 1250 mm Coolant unit 80 l/min at 7 bar Loop-type part storage conveyor Max. workpiece diameter (27 workpieces with 30-85 mm or 18 workpieces with 30-130 mm) mm Max. workpiece length 100 mm Automatic central oil lubrication GENERAL TECHNICAL DATA Operating voltage 400/50 V/Hz Mains fuse 80 A Total power requirement 36 kVA Machine dimensions (LxWxH) approx. 2500x1900x2300 mm Bwobevfmdus Ha R Eyol Space requirement of the whole equipement (LxWxH) approx. 3600x1900x2300 mm Machine weight approx. 6000 kg REMARKS We described the specified product with the upmost attention. As this product is not manufactured by us, the mentioned data and description can deviate. Herewith, we point out that they are non-binding and ask you to check them during your inspection.

Condition: ready for operation (used), Year of construction: 1984, CNC numerical 1600mm platen, maximum diameter 3200mm Beb Haov Nqics R Eyjwl 1600mm clearance height 20 tons permissible weight 160 rpm maximum rotation speed

Condition: good (used), CHARACTERISTICS Plate diameter ⌀; 3200 mm Maximum turning/turning diameter ⌀; 3300 mm - With upright forward; 3300 mm - With upright set back; 5600 mm Min. turning/turning diameter ⌀ - With advanced upright; 800 mm - With upright set back; 3100 mm Max turning height; 750 mm Control; FAGOR 8025 Spindle RPM (2 ranges); - 0,5 - 10 rpm - 10 - 40 rpm Motor Power; 80 hp Bwjb Ha R Esr I Aykeyjl Maximum table load; 30.000 kg

Condition: ready for operation (used), chuck outer diameter: 6,000 mm, controller model: Siemens/Heidenhain, net weight: 180,000 kg, Type: SD 600/6500 4 assen gerichte, kogelomloopspindels tussen kolommen: 6500 mm maximaal hoogte onder dwarsbalk: 4270 mm verticale beweging van de dwarsbalk: 2500 mm maximaal gewicht op tafel: 160 ton koppel van de tafel: 30.000 MKP, 200 PK Verticale beweging van Z1 Z2: 1750 mm Twee onafhankelijke schaarliften aan elke kant van de draaibank, met bedieningseenheid Bjb Haswaiuqo R Eyowl Max turningdia -- passage: 6500 mm Power on the spindle: 200 HP Max hight of workpiece Z-axis: 4270 mm Number of speeds: 1 > 40 rev/min Long: 20 500 mm Wide: 8500 mm Height: 6290 mm (above ground-level)

Condition: good (used), Year of construction: 2013, operating hours: 44,500 h, EMAG VL5i vertical turning machine (2013) Manufacturer: EMAG Type: VL5i Year of manufacture: 2013 Operating hours: 44.500 Condition: good, used, in production Control SIEMENS 840 D SL Bwob Haowbqnuo R Eyel Emulsion mist extraction chip conveyor Further information will follow

Condition: ready for operation (used), Year of construction: 2016, operating hours: 18,071 h, General Data Machine weight 6000 kg Main Drive Bwjb Hewbk U Ioa R Eyel Number of axis 3 Media Main electronic connection 40 kVA This 3-axis DMG MORI Gildemeister CTV 250 2nd was manufactured in 2016. Ideal for precision vertical turning, this machine maintains robust construction and reliability. If you are looking to get high-quality turning capabilities, consider the DMG MORI Gildemeister CTV 250 2nd machine we have for sale. Contact us for more information. Application Types Turning

Condition: good (used), Year of construction: 2018, operating hours: 28,500 h, Functionality: fully functional, GENERAL Project No: 905623 Quantity: 1 pc. Manufacturer: EMAG Type: VL 3 Control: Siemens 840 D solutionline Year of Manufacture: 2018 Condition: Used Machine Programme run approx. [h]: 28.500 DESCRIPTION TURNING Max. turning diameter 210 mm Max. turning length 100 mm Max. Swing diameter over bed cover 210 mm Max. speed main spindle 7500 1/min Max. power main spindle at 10-40/100% duty ratio 25/16 kW Max. torque main spindle at 10-40/100% duty ratio 200 Nm Spindle diameter in front bearing main spindle 80 mm Spindle flange size main spindle Gr. 5 (DIN 55026) Axis at main spindle unit X/Z Travel in X/Y/Z main spindle unit 400/-/200 mm Max. rapid traverse in X/Y/Z main spindle unit 60/-/30 m/min Feed force X/Y/Z main spindle unit 5000/-/5000 N Linear glass scales main spindle unit X/Z Solid clamping cylinder at main spindle Lower turret No. of stations/driven 12/12 Tool reception in turret VDI 40 FURTHER EQUIPMENT Fully enclosed work area Light in working area Oil-/emulsion mist extraction unit Slat band chain chip conveyor Discharge hight chip conveyor 1250 mm Beb Hsry Uhwja R Eyswl Coolant unit with paperband filter Loop-type part storage conveyor Max. workpiece diameter (27 workpieces with 30-85 mm or 18 workpieces with 30-130 mm) mm Max. workpiece length 100 mm Automatic central oil lubrication GENERAL TECHNICAL DATA Operating voltage 400/50 V/Hz Mains fuse 80 A Total power requirement 36 kVA Machine dimensions (LxWxH) approx. 2500x1900x2300 mm Space requirement of the whole equipement (LxWxH) approx. 3600x1900x2300 mm Machine weight approx. 6000 kg REMARKS We described the specified product with the upmost attention. As this product is not manufactured by us, the mentioned data and description can deviate. Herewith, we point out that they are non-binding and ask you to check them during your inspection.

Condition: excellent (used), Year of construction: 2005, turning diameter 140 mm swing diameter 200 mm turning height 630 mm Bjbovvcibj Ha R Eyewl Control Siemens 840 S centre distance 832,5 mm turning length 380 mm spindle head Grösse 6 spindle diameter in front bearing 110 mm bed slide 2 number of cross-slides 2 turret head VDI 40 number of tools 11 total power requirement 70 kW weight of the machine ca. 22 t dimensions of the machine ca. 5,8 x 8,6 x 3,8 m

Condition: excellent (used), Year of construction: 2007, Functionality: fully functional, machine/vehicle number: 3141 & 3151, Used CTV250s for sale, built in 2007. ---- Please state your offer price for 1 or 2 used CTV250s, built in 2007. Serial No. ... 3141 & 3151 Sale only within the European Union (EU), including Switzerland, Turkey, and Great Britain ----- Our line, consisting of four identical CTV250s from 2004 and 2007, is for sale. The machines can operate individually. Bids can be placed for 1-2 units of this model year. The machines are connected to a central lubricating oil supply. The machines are delivered without the robot. The machines are currently in series production and will be shut down approximately in the third quarter of 2025. A visit is possible at any time by appointment. Scope of delivery: Machine, clamping tools, chip conveyor. Not included in delivery: Kuka robot ----- Without packaging; any warranty claims are excluded. If you wish to disassemble the system yourself, please provide appropriate information in your bid. We assume no liability for the accuracy of the technical data, the completeness of accessories and tooling, Bob Haovft I Ts R Eyewl or compliance with all safety and environmental protection requirements specified in accident prevention regulations.

Condition: ready for operation (used), Type: TVM 450/5 Uitzonderlijke freesmachine draai verticale draaibank die zeer grote werkstukken kunnen bewerken. Zowel de binnen- als buitendiameter van de werkstukken kunnen worden bewerkt!! De machine bestaat uit een vaste buitenkolom en een beweegbare binnenkolom. Draaitafel: buitendiameter: 6300 mm binnendiameter: 3000 mm grootste diameter van het werkstuk: 9800 mm kleinste diameter van het werkstuk: 2220 mm max. gewicht op tafel: 300 ton rotatiesnelheid: 0,08 27 tpm rotatiesnelheid bij draaien/frezen: ,4 t/min Vaste externe kolom: ram-afmeting: 550 x 550 mm diameter van de spindel: 304,8 mm ISO 60 - 37 kW op spindel Maximale hoogte van uitwendig draaien/vriezen: 8700 mm min. hoogte van uitwendig draaien/frezen: 700 mm verticale slak: 8000 mm horizontale slak: 2030 mm Beweegbare binnenkolom: rammaat: 280 x 280 mm maximaal diameter van inwendig draaien/frezen: 5180 mm min. diameter van inwendig draaien/frezen: 3048 mm maximaal hoogte van inwendig draaien/frezen: 5800 mm min. hoogte van inwendig draaien/frezen: 615 mm verticale slak: 5800 mm horizontale slak: 1120 mm Spiltoerentallen: 1,2 601 tpm Totaal vermogen: 250 kW 5-assige CNC-besturing Bsb Ha Rowaiu Dj Eyowl

Year of construction: 2014, Condition: used, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm travel -z axis 375 mm c-axis 360 ° Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. Bsb Haoqvd Iqe R Eyswl The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2

Condition: used, Year of construction: 2012, turning diameter 400 mm swing diameter 420 mm x-travel 850 mm z-travel 315 mm spindle head DIN 55026 - Size 11 spindle bearing diameter 140 mm turning speeds max. 4000 U/min tool turret 12 times C5 Capto rapid traverse x + z axis 45 / 30 m/min feeding force 11 kN total power requirement 58 kW weight of the machine ca. 9 t Beb Hasvxwx Ao R Eyjwl dimensions of the machine ca. 9,5 x 4,5 x 3 m Hard turning Dry machining Chip conveyor Promot Portal and Cellmaster No clamping device available No tools available no Cellmaster accessories available

Condition: good (used), Year of construction: 2002, Functionality: fully functional, USED TOSHULIN POWERTURN 1600 CM 2-APC – YOM 2002 – Serial Number 1428 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Ram Type Vertical Boring & Turning Machine With C-Axis & Driven Tools • Heavy-Duty Cast-Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Hardened & Ground Slideways to Provide Increased Stability & Rigidity. • 2 Step Automatic Gear Change. • 96 Position Tool Magazine. • Recirculating Cylindrical Roller Bearing Packs and Steel Hardened and Ground Guide Way Inserts on X and Z Axes • Pallet Changer with Set Up Station, Park Station and Transfer Station and 2 Off 4 Jaw 1600mm Pallets with Manually Operated Integral Base Jaws • High Precision Pallet Location for High Repeatability • Knoll 70 Bar Coolant System With Paper Band Filtration – with Through Spindle • Swarf Conveyor • Power Rise and Fall to the Operator’s Pendant CAPACITY Maximum Turning Diameter - Ø 2,000 MM Maximum Turning Height - 1,110 MM Maximum Height Under Crossrail - 1,300 MM Maximum Torque on Pallet - 22,918 NM Maximum Workpiece Weight - 6,000 KGS TABLE Pallet Diameter - Ø 1,600 MM Table Speed - 2.5 ~ 315 RPM Table Speed Range - Automatic 2 Step TABLE C-AXIS Minimum Index Angle - 0.001° C-Axis Cutting Feedrate - 500 MM / MIN Max. C-Axis Speed - 0.01 ~ 6.2 RPM RAM HEAD Tool Size - 40 MM² Ram Cross Section - 240 x 240 MM MILLING SPINDLE Milling Spindle Speed - 4 ~ 3,000 RPM Milling Spindle Power - 22.0 KW TRAVEL & FEEDRATE X-Axis Travel (Saddle Horizontal) - 2,470 MM Z-Axis Travel (Ram Vertical) - 900 MM Vertical Travel of Crossrail - 800 MM Maximum X / Z-Axis Cutting Feedrate - 1.0 ~ 4,000 MM / MIN X / Z-Axis Rapid Feedrate - 12,000 MM / MIN ATC Type of Tool Holder - MAS BT 50 Tool Magazine Capacity - 96 STATIONS Max. Tool Weight - 50.0 KGS MOTOR Table Motor (Cont. / 30 Min) - AC 60.0 KW Milling Spindle Motor Power - AC 22.0 KW X / Z-Axis Servo Motor - AC 7.0 KW C-Axis Motor - AC 7.0 KW Bsb Ha R Esuu R Dgsyowl POWER SOURCE Input Power Supply - 415V / 50HZ / 3PH Power Capacity - 80 KVA DIMENSIONS & WEIGHT Height 5,905 - MM External Width (With Chip Conveyor) - 9,765 MM External Depth - 11,130 MM Weight - 45,000 KGS

Condition: good (used), Year of construction: 2006, machine/vehicle number: 66078, TECHNICAL DETAILS Control: SIEMENS SINUMERIK 840 Speed: 5,500 rpm Swing diameter: 260 mm X-axis travel: 626 mm Z-axis travel: 250 mm Spindle bearing diameter: 32 mm Nominal speed: 1,200 rpm X-axis rapid traverse speed: 60 m/min Z-axis rapid traverse speed: 30 m/min Turret positions: 12 MACHINE DETAILS Machine length: 1,685 mm Machine width: 2,400 mm Machine height: 2,850 mm Machine weight: 8 t Beb Hajwfddde R Eyewl EQUIPMENT - Spindle head with short taper DIN 55026: A6 - WPS pallet conveyor - KNOLL system (2010) - SAUTER turret (12 places) - Documentation available

Condition: excellent (used), Year of construction: 2005, operating hours: 23,500 h, chuck outer diameter: 250 mm, turning diameter: 320 mm, rotational speed (max.): 4,000 rpm, swing diameter 320 mm control 840 D SIEMENS Bwsb Ha Rswhd Sgo Eysl turning speeds 5000 1/min spindle drive 20 / 27 kW chucking diameter 250 mm travel -x axis 650 mm travel -z axis 300 mm turret head 12 Pos. tool holder VDI 40 toolpiece turning speed range 4000 1/min work piece power max. 11,7 kW CNC vertical lathe, live tools, C-axis, high pressure pump 20 bar, 500l, filter, flush gun, 3-jaw chuc, EWAB loading station right, chipconveyor, approx. 23.500h "machine on", approx. 8.000h "spindle on"

Year of construction: 2014, Condition: used, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm travel -z axis 375 mm c-axis 360 ° Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. The machine is in very good condition. Please note that the technical details were added from comparable machines. Beb Hoqvd Iuoa R Eyewl - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2

Condition: used, Year of construction: 2009, turning diameter 320 mm turning height 180 mm Control SIEMENS 840 D chucking diameter 315 mm 0 4 U/min 1 mm rapid power traverse in X-and Z direction 60/30 m/min tool turret with 12 work positions VDI 50 total power requirement 65 kW weight of the machine ca. 13,5 t Bobsvxwk Se Ha R Eyowl dimensions of the machine ca. 5,5 x 3,2 x 3,3 m

Condition: new, Year of construction: 2018, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Bob Ha R Esuu Rybsyowl Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Year of construction: 2007, Condition: used, control Siemens 840-D tool taper HSK & VDI 40 - - - - - - - - - Vertical Turning Machine EMAG - VTC 250 DUO DD with ITC (7-30 bar) and driven tools Additional equipment: Bwjb Ha R Esh Nhlwjyel - Workpiece grippers on all 3 turrets - 12-position disc turret for driven tools and VDI 40 tool holders, - 12-station disc turret with cross-slot and VDI 40 tool holders, - 12-station disc turret for driven tools and VDI 40 tool holders, - NC steady rest, self-centering, - headstock below, - tailstock below, - chip conveyor - Knoll unit 1.500 l, - OP10: Three-jaw chuck Rhöm KFD-N 220/3, - OP20: Hainbuch Spanntop pull-back BZI65, - Live tool for axial and radial machining, - Tool holder with Capto 5 quick change system, - Artis as tool and process monitoring, The machine is in a well-maintained condition. A machine video from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VTC250 | VTC-250 | VTC250DUO | VTC-250 DUO

Condition: new, Year of construction: 2018, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Bwjb Hsguq Txsa R Eyol Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Year of construction: 2005, Condition: used, control Siemens 840-D tool taper HSK & VDI 40 Bweb Ha R Eeh Nhltjysl - - - - - - - - - Vertical Turning Machine | EMAG - VTC 250 DUO ED with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets, - 6-station end-processing turret with HSK tool holder, - 12-station disc turret for driven tools and VDI 40 tool holder, - 12-position disc revolver with cross slot and VDI 40 tool holder, - NC - clamping head, - NC bezel, self-centering, - EMAG hydraulic double-piston clamping cylinder, - tailstock down, - Hydraulic double-piston clamping cylinder at the top, - chip conveyor, - Knoll plant 1.500 l, - Coolant supply 7-30 bar, - OP20: shaft chuck with retractable jaws and face drivers, - Tool holder with Capto 5, - Artis quick-change system for tool and process monitoring, - Tool pack is included, The machine is in a well-maintained condition. A machine video from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VTC250 | VTC-250 | VTC250DUO | VTC-250 DUO

Condition: good (used), Year of construction: 2002, Functionality: fully functional, USED TOSHULIN POWERTURN 1600 CM 2-APC – YOM 2002 – Serial Number 1428 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Ram Type Vertical Boring & Turning Machine With C-Axis & Driven Tools • Heavy-Duty Cast-Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Hardened & Ground Slideways to Provide Increased Stability & Rigidity. • 2 Step Automatic Gear Change. • 96 Position Tool Magazine. • Recirculating Cylindrical Roller Bearing Packs and Steel Hardened and Ground Guide Way Inserts on X and Z Axes • Pallet Changer with Set Up Station, Park Station and Transfer Station and 2 Off 4 Jaw 1600mm Pallets with Manually Operated Integral Base Jaws • High Precision Pallet Location for High Repeatability • Knoll 70 Bar Coolant System With Paper Band Filtration – with Through Spindle • Swarf Conveyor • Power Rise and Fall to the Operator’s Pendant CAPACITY Maximum Turning Diameter - Ø 2,000 MM Maximum Turning Height - 1,110 MM Maximum Height Under Crossrail - 1,300 MM Maximum Torque on Pallet - 22,918 NM Maximum Workpiece Weight - 6,000 KGS TABLE Pallet Diameter - Ø 1,600 MM Table Speed - 2.5 ~ 315 RPM Table Speed Range - Automatic 2 Step TABLE C-AXIS Minimum Index Angle - 0.001° C-Axis Cutting Feedrate - 500 MM / MIN Max. C-Axis Speed - 0.01 ~ 6.2 RPM RAM HEAD Tool Size - 40 MM² Ram Cross Section - 240 x 240 MM MILLING SPINDLE Milling Spindle Speed - 4 ~ 3,000 RPM Milling Spindle Power - 22.0 KW TRAVEL & FEEDRATE Bjb Hajrrzchj R Eyowl X-Axis Travel (Saddle Horizontal) - 2,470 MM Z-Axis Travel (Ram Vertical) - 900 MM Vertical Travel of Crossrail - 800 MM Maximum X / Z-Axis Cutting Feedrate - 1.0 ~ 4,000 MM / MIN X / Z-Axis Rapid Feedrate - 12,000 MM / MIN ATC Type of Tool Holder - MAS BT 50 Tool Magazine Capacity - 96 STATIONS Max. Tool Weight - 50.0 KGS MOTOR Table Motor (Cont. / 30 Min) - AC 60.0 KW Milling Spindle Motor Power - AC 22.0 KW X / Z-Axis Servo Motor - AC 7.0 KW C-Axis Motor - AC 7.0 KW POWER SOURCE Input Power Supply - 415V / 50HZ / 3PH Power Capacity - 80 KVA DIMENSIONS & WEIGHT Height 5,905 - MM External Width (With Chip Conveyor) - 9,765 MM External Depth - 11,130 MM Weight - 45,000 KGS

Condition: used, Year of construction: 2006, spindle passage 65 mm spindle diameter in front bearing 110 mm number of spindle speeds 5.000 U/min Power 20/27 KW Control INDEX C 200-4 travel -x axis 850 mm travel -z axis 260 mm number of tapers in turret head 12 driven tools turning speeds 6.000 U/min CNC turning and milling center vertical | INDEX - V160C equipped with turret, milling spindle and pallet conveyor system. The machine only has 17.000 hours of Power-On. The machine is in good condition. Bwob Ha Rjvzcnzs Eyjl For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: V-160C | V-160 C | V 160 C | V 160C

Condition: used, Year of construction: 2001, workpice diameter max. 90 mm forward bearing diameter 140 mm Bwjb Hsvzcnbea R Eyjl Turning speeds mainspindle 4.200 U/min Power 35,5 KW Control INDEX C 200-4 travel -x axis 1.500 mm travel -z axis 340 mm travel -y axis 180 mm b-axis 360 ° CNC turning and milling center vertical | INDEX - V300 equipped with a turret for driven tools as well as y- + B- axis. Further information: - direct measuring system on X + Z The machine is in good condition. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: V-300 | V 300
