Used roll forming lines for sale (64)

Condition: used, Year of construction: 1980, outer diameter: 38 mm, pipe diameter (max.): 38 mm, PRODUCT (PROFILE, TUBE) .. external diameter min.: 11 mm .. external diameter max.: 38 mm .. wall thickness min.: 0.8 mm .. wall thickness max.: 2 mm LINE CHARACTERISTICS .. welding process: HF inductive .. sawing process: travelling .. speed max.: 120 m/min ELECTRICAL SPECIFICATIONS .. mains power supply: 440 kVA For sale is a fully serviced and excellently maintained tube welding line . The line was previously used for the production of USM Haller furniture tubes, but it is designed for a wide range of tube diameters, making it highly versatile for different manufacturing requirements. Welding is carried out with an induction HF system from EFD Induction, built in 2018, ensuring a modern and efficient welding process. Total line length: approx. 100 m Operation: handled by 7 operators Condition: well-maintained, fully operational Scope of delivery: complete package Hedpjx Hd Thefx Af Sopa An excellent opportunity for companies looking for a reliable and high-performance tube welding line.

Condition: used, Year of construction: 2013, functionality: fully functional, Gantry machining center; tool changer Hpjdpjx Hk Dgjfx Af Soa

Condition: used, Stainless steel welding line MOD.70/120, made OLIMPIA 80 with tricathode welder & Seam bead roller & Orbital polishing Hpodpfsvtn H Tex Af Soa Specifications: - Diameter : 35 – 120 mm - Thickness : 0.7 – 3.5 mm - Length : 3 – 6 m Tube diameter: 35 – 120 mm Thickness: 0,7 – 3,5 mm Tube length: 3 – 6 m

Condition: excellent (used), Schlebach Mini Prof Plus profiling machine The machine is equipped with: Hpodpfx Afex A S Ame Sea - Hand roller shear RS for cross cutting - Roller shear LS for longitudinal cutting before profiling - Electromechanical length measurement - 400V connection

Condition: excellent (used), Year of construction: 2015, operating hours: 50 h, functionality: fully functional, machine/vehicle number: P1.2014.86242, The subject of the report is a Dreistern laser-welded profile production line. The machine has been tested but was not put into production. It has operated for 50 hours. It is designed for the forming of cold-rolled sections, either open or closed, which are laser-welded. The input material for profile production consists of coils made of black or galvanized steel. Component parts (serial numbers in accordance with technical documentation): 1 - Soprem H1250/D/1700ZR decoiler, serial no.: 20140388/1, year of manufacture: 2014 2 - Soprem CH-2540 strip end welder, serial no.: 20140388/2, year of manufacture: 2014 3 - Dreistern RS616 multi-roll forming machine, serial no.: 15773, year of manufacture: 2015 - base frame, serial no.: N/A, year of manufacture: N/A - P60/80/90 gearbox unit, serial no.: N/A, year of manufacture: N/A - servo drive, serial no.: N/A, year of manufacture: N/A - Dreistern P60 forming, embossing, and perforating stands, serial no.: N/A, year of manufacture: N/A 3 x Dreistern RC1500, RC1501, RC1502 roll forming tools, serial no.: N/A, year of manufacture: N/A Hsdpfx Afoxz Tuus Sepa 4 - Trumpf TruLaser Cell 1100 laser, serial no.: S1200C0090, year of manufacture: 2014 5 - Dreistern TS214.10 cut-off machine, serial no.: 15122, year of manufacture: 2015 - Dreistern S 200.10 circular saw, serial no.: 15094, year of manufacture: 2014 6 - Electrical cabinets 7 - Laser safety system

Condition: good (used), Year of construction: 1975, 13 stations shaft Ø: 50,4 mm strip width: 500 mm strip thickness: 1,5 mm Hpedpfx Afobif E Eo Ssa

Condition: good (used), Year of construction: 1996, Offer 25468 Sheet – Profiling Line for Shelf Panels Hodoxxvq Tepfx Af Sjpa Technical Data: - Shelf panel width approx. 250 mm - Material thickness 1.25 mm - Profiling unit with 16 roll forming stations - Hydraulic punching unit - Straightening unit, make DREHER - Motorized decoiler CAMU, load capacity approx. 1.5 t - Control panel - Space requirement / footprint: 14 x 1.5 m - Weight approx. 10 t

Condition: used, Year of construction: 1979, outer diameter: 76 mm, pipe diameter (max.): 76 mm, PRODUCT (PROFILE, TUBE) .. external diameter min.: 25 mm .. external diameter max.: 76 mm .. wall thickness min.: 0.7 mm .. wall thickness max.: 3.25 mm LINE CHARACTERISTICS .. welding process: HF inductive .. sawing process: travelling .. speed max.: 100 m/min ELECTRICAL SPECIFICATIONS .. mains power supply: 680 kVA For sale is a high-quality pipe welding line from the renowned manufacturer DREISTERN. Technical Data & Highlights: Line length: approx. 130 m Staff required: 6 operators Welding process: High-frequency welding up to 400 kHz Induction welding power: up to 250 kW Advantages: Robust and reliable design – suitable for continuous industrial operation Precise weld quality through state-of-the-art high-frequency technology Ideal for the production of pipes in various dimensions Hpodjxrklxspfx Af Ssa Ready for immediate operation

Condition: excellent (used), functionality: fully functional, sheet thickness steel (max.): 3 mm, sheet thickness (max.): 3 mm, outer diameter: 80 mm, HEAVY-DUTY HIGH-PERFORMANCE TUBE MILL OTO 80.3 QTC With complete Quick Tool Change System Made by OTO MILLS PRODUCTION RANGE • Diameter range 19mm – 80mm • Thickness 0.8mm to 3.2mm • Speed Max. 150 m/min • Working direction Left - Right Scope of supply: 1. Entry Line made OTO MILLS with: • Double Uncoiler OTOAD256 -PA • Double strip peeler for opening from top/bottom • Automatic strip joiner OTO GG254 • Floop vertical accumulator 2. OTO 80.3 QTC tube mill made OTO MILLS with: • Casted Iron stand • Bottom shaft height adjustable • Reinforced motor and gearboxes 2-speed transmission • Hydraulic nuts • Double length cooling tunnel • Motorised turk-head for fast adjustment 3. Quick change rafted system OTO QTC - 2nd set of cassettes off-line including : • 1 complete cassette for forming • 1 complete cassette for fin-pass • 1 complete cassette for sizing • Quick – plug automatic cardan connections 4. 150 m/min Flying saw – High Speed cold saw OTO TCCG160 with : • Carriage motion with 70kW motor • Cutting head motion with hydraulic control • AC Rotation of the blade 5. Automatic packer MAIR SQ.HEX.90.D.5.SL with emulsion draining and bundle weighting system • Possibility to make hexagonal and square/rectangular bundles • 5 modules for production of tubes 4-10m (12m for thickness >1.8mm) • Including emulsion draining, and weighting unit • 3 chains for finished bundle storage • Test tube zone, with cutting saw for the test tube 6. Automatic strapping unit SIGNODE M400 7. Zinc spraying METALISATION 250 • 1 metallisation cabin • 1 zinc spraying unit METALLISATION ENERGIZER 250 • 1 Zinc spraying gun ARCSRPAY 528E 8. Fume exhaust system • Fume exhaust conducts and exhaust covers on the required points a • Filter for fumes 9. Complete set of rolls (*See details) NEW PARTS SUPPLIED IN 2023/2024: Hjdpfovr Tntsx Af Sspa 10. Thermatool CFI 350-VF Solid state welder with : • Automatch • Selectable frequency 250-400kHz • Thermaview control panel 11. Cooler PARKER, Model hyprechill Maxi 12. Inner scarfing hydraulical Blissenbach, with all the toolding for ID 30-50m 13. OPTRONIC CNC control unit for driving flying saw (Switzerland) 14. New Emulsion plant with : • Pump and heat exchanger • Fillters • Electrical controls and monitoring 15. New motor and electritical cabinet for accumulator 16. New motor and control for sizing section

Condition: excellent (used), Schlebach SPA RS LS Profiling machine for continuous production of angled standing seam with 25 mm seam height. The machine is equipped with: - a hydraulic cutting unit for precise right-angled cut-off of strips after profiling, Hedpox A Sz Nefx Af Sepa - millimeter-accurate length measurement, - RS rotary shears for cross cutting, - LS rotary shears for longitudinal cutting.

Condition: like new (used), Year of construction: 2022, Infeed height 900 mm Infeed width 300 – 800 mm Non-ferrous metals: Either 0.6 – 0.8 mm or 0.8 – 1.0 mm (has to be set before ordering) Non-ferrous metals: 1.0 – 1.2 mm (only with façade profiles) Steel (320 N/mm²): 0.55 – 0.70 mm Stainless steel: Max. 0.5 mm 3,830 mm x 2,045 mm x 1,275 mm Hjdexwxdgspfx Af Sepa 1,770 kg

Condition: excellent (used), Year of construction: 2005, 19 stations design: cassette shaft Ø: 30 mm strip width: 200 mm Hedpjh Tm Rajfx Af Sepa strip thickness: 1 mm

Condition: good (used), Year of construction: 1996, Offer 25467 Sheet Metal Profiling Line for Rack Uprights Technical data: - Profile dimensions: W 35 / 20 x 35 mm - Material thickness: 1.25 mm - Profiling unit with 12 roller stations and subsequent cut-to-length unit - Hydraulic punching unit, W 125 mm - Motorized decoiler CAMU, load capacity approx. 1T - Control panel - Required space / footprint: 14 x 1.5 m - Weight approx. Hodpfxexxu Dfs Af Sspa

Condition: excellent (used), Year of construction: 2015, Profila PIEMME mod. PM90 Decoiler Plate Bending Machine Welder Shear Heads No. 24 Width 500mm Thickness 2.5 Hodpfx Afjxa H Eqe Sspa

Condition: used, DALLAN Rollforming machine | Omega profiles 60mm & 80 mm With 11 forming stations, fully equipped and currently set up for Omega 60 mm, the line includes additional tooling for Omega 80 mm profiles. This machine is complete, in excellent condition. DALLAN rollforming line with 11 forming stations: · Maximum sheet width: 300 - 350 mm · Controls: Dual console · Shaft diameter: 60 mm · End unit: Integrated cutting station Hpedpfx Afsxugf Hj Ssa · Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm · Idle decoiler · Tooling box (approx. 1,000 kg) for producing other profile types · Dimensions: 10,000 x 1,400 x 1,600 mm (L x W x H) · Weight: 10 tons Maximum sheet width: 300 - 350 mm Controls: Dual console Shaft diameter: 60 mm End unit: Integrated cutting station Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm

Condition: used, Roll Forming Line for Drywall and Zinc-Coated Door Frame Profiles General Description: Complete roll forming line designed for the production of zinc-coated steel profiles used in drywall structures and door frame systems. The machine processes galvanized steel strips with thicknesses typically ranging from 0.6 mm to 1.0 mm, featuring quick roller adjustment depending on the required profile type. Profiles Produced - Drywall Profiles: • Galvanized Tracks: width 57 mm and 77 mm, height 35 mm, sheet thickness 0.6 mm • Galvanized Studs: 39×55 mm and 39×75 mm, sheet thickness 0.6 mm • U-Shaped Profiles for False Ceilings: 27×60×27 mm, sheet thickness 0.6 mm • Offset Profiles for False Ceilings: 20×29×28 mm, sheet thickness 0.6 mm - Zinc-Coated Door Frame Profiles (10/10 mm): Hpodpfx Afjxnmyqj Soa • Complete range from ART. 201 to ART. 217, including L, U, Z and special shapes • Variable dimensions: widths from 20 to 46 mm, heights from 15 to 31 mm, customizable configurations available Technical Features • Material thickness: 0.6 – 1.2 mm • Strip width: variable, depending on profile • Number of forming stations: 19 • Rollers: hardened and ground steel rollers • Drive system: independent motorization for each roller group • Feeding speed: adjustable • Cutting unit: automatic flying shear or saw • Optional units: punching, slotting, or quick-change tooling systems

Condition: used, Tube forming mill OME 320x8mm (A3782) Tube forming mill OME 320x8mm (A3782) for tube production of 323mm maximum diameter and 8mm maximum wall thickness Make: Ome (Italy) Material: HR, CR, Galv Condition: New Tube Diameter: 168mm – 323mm Wall Thickness: 2mm – 8mm Direction: L-R Speed: 35 meters per minute FORMING MILL Pass N. 1 Driven Forming # 1 Pass N. 2 Driven Forming # 2 Pass N. 3 Driven Forming # 3 Pass N. 4 Driven Forming # 4 Pass N. 5 Driven Forming # 5 Pass N. 6 Driven Forming # 6 Pass N. 7 Side Idle Forming Pass N. 9 Driven Forming # 7 Pass N. 10 Side Idle Forming FIN-PASS SECTION, SINGLE POINT ADJUSTMENT Hpsdpfjq Ul Rvox Af Sea Pass N. 11 Driven Fin Pass # 1 Pass N. 12 Side Idle Fin Pass Pass N. 13 Driven Fin Pass # 2 Pass N. 14 Side Idle Fin Pass Pass N. 15 Driven Fin Pass # 3 Pass N. 16 Driven Fin Pass # 4 SIZING SECTION Pass N. 26 Driven Sizing # 1 Pass N. 27 Driven Sizing # 2 Pass N. 28 Driven Sizing # 3 NDT Prueftechnik Pass N. 29 Driven Sizing # 4 Pass N. 30 Driven Sizing # 5 STRAIGHTENING AND SQUARING SECTION Pass N. 31 Idle Turkshead #1 Roll holder plates NOT available Pass N. 32 Idle Turkshead #2 Roll holder plates NOT available Pass N. 33 Idle Turkshead #3 Roll holder plates NOT available Pass N. 34 Idle Turkshead #4 Roll holder plates NOT available Tables and tools for rolls change ABB Motors Costamasnaga Reducers Centralized lubrication system Hydraulic Power Unit Complete Mill Portion Automation with diagrams (OTO MILLS/Elletre 2013) Complete hydralic system Fume and Vapors exhaust system with extraction hoods (EUROFILTER) Complete Zinc exhaust system (DONALDSON)

Condition: excellent (used), Year of construction: 2005, dual track rollforming line Hpjdpfsh Tm Rlsx Af Sja 2 x 18 stations design: cassette shaft Ø: 30 mm strip width: 200 mm strip thickness: 1 mm

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: LU0183, Roll forming line for solar profiles, both for trackers and fixed structures. High processing speed, with mechanical press and 10 CNC-controlled punching tools. Working speed up to 30 m/min. Working thickness from 0.8 to 3.0 mm and maximum strip width 450 mm. Hodpewxfbwofx Af Sopa

Condition: used, Guard Rail Roll Forming Line: • The production line for road safety barriers consists of: • Accessories and rollers for the production of 2- and 3-wave guard rails • Bending machine for 2- and 3-wave profiles • 19-station roll forming machine, complete with rollers and motorization Hpsdpfx Afoxnmmqj Sea • No. 3 punching stations • No. 1 cutting station • No. 7 hydraulic power units • No. 1 station with feeding rollers

Year of construction: 2008, condition: used, Guzzetti tube mill 76-200mm with a lot of tools and automatic stacker can be perfect solution for your tube production business. This line will allow you to produce huge range of round and rectangular pipes in very easy and automatic way. Line is equipped with important machines to make manufacturing process maximum convenient and productive. You can purchase machine as is where is or we can offer to make repair. Also we can provide shipping and installation service. If you start business with us you will never regret! Make: Guzzetti (Italy) Year: 2008 Automatic stacker: MAIR / Italy Tube range: D76- D200 Material’s thickness is 2-6mm (incl and SS) Hpjdei D D Efepfx Af Sea PLC – Siemens and all inverters and servo drives Welding aggregate is Thermomachine / Italy This line is also equipped and with the following machines: – Double dec.machine – Strips ends manually welding machine – Horizontal accumulator – 10 stations forming machine Material thickness is adjusting not manually – it is done by el.motors depend of el.indicators e. Welding aggregate is Thermomachine / Italy f. Cooling system g. System for automatic control of tubes sections dimensions h. 4 calibration stations + 4 TH The TH are with mechanical movements depend of necessary calibration. i. Fly cut-off unit is with two geared motors : one for hot cut off and another for cold cut off j. Automatic stacker is MAIR . Max tubes length is 12m. Packets for round tubes are hexagonal or octagonal types and for square tubes square or rectangular depend of tube’s dimensions. Tools available with machine: – Round Tube Ø76,1 – 1 set Ø88,9 – 1 set Ø95 – 1 set Ø101,6 -1set Ø108-1set Ø114,3-1set Ø125 – 1 set Ø133-1set Ø150-1set Ø159-1set Ø188-1set – Rectangular tube 60×60 70×70 75×75 80×80 85×85 90×90 100×100 105×105 120×129 125×125 150×150

Year of construction: 1988, condition: good (used), 18 stations shaft Ø: 89 mm Hedjbh H T Iopfx Af Sspa strip width: 600 mm strip thickness: 3 mm

Condition: used, Double-head cutting-off machine – Tekna TK 154 Technical specifications: Blade: Ø 500 mm Maximum cutting length: 4000 mm Blade tilt: outward Tilt angle: 90°/22.5 kW Voltage: 380 V Power: 7 HP Hpsdpsxbr Itofx Af Sea Dimensions: 5200 x 1650 x H 1700 mm (max 2100 mm) Weight: 1260 kg

Year of construction: 1968, condition: good (used), 15 stations shaft Ø: 120 mm strip width: 180 - 830 mm Hedpfxebif Evs Af Sspa strip thickness: 10 mm

Year of construction: 2005, condition: excellent (used), 16 stations Hpedpfxoh I Nizs Af Ssa design: cassette shaft Ø: 45 mm strip width: 300 mm strip thickness: 2 mm
