5
Tool setting device, tool presetting device, milling cutter setting device
Ptmleu
-Presetting device for: milling tools
-maximum hob diameter: 500 mm
-maximum height of the milling cutter: 500 mm
-Dimensions: 800/400/H1600 mm
-Weight: 242 kg
7
x-travel 700 mm
B7q2bgx2hd
y-travel 590 mm
z-travel 480 mm
Control HEIDENHAIN ITNC 530
a-axis +-110,0. 001º °
c-axis 360, 0.001 °
rapid travel x/y/z 32.000 mm/min
Tools changer 30 pos.
max. workpiece length 280 mm
max. workpiece weight 7 kg
chip conveyor Inkl. kW
Internal cooling system 20 bar
handwheel HEIDENHAIN HR 310
Machine on 13.975 h
Spindle hours 6.258 h
total power requirement 30 KVA
weight of the machine ca. 8,2 t
dimensions of the machine ca. 2.220 x 2.650 x 2.855 mm
-pallets 3 W...
2
x-travel 600 mm
y-travel 650 mm
z-travel 550 mm
Control HEIDENHAIN 426
total power requirement 35 kW
weight of the machine ca. 8500 kg
dimensions of the machine ca. m
D E C K E L M A H O (Germany)
Universal CNC- 4 + 1 Axis Machining Center
Model DMU 60 P with HEIDENHAIN-CNC-Control 426
Year 1998 # 662834
_____
Working range: X Axis (Cross Stroke of Milling slide) 600 mm
Z Axis (Vertical Stroke of Milling head) 550 mm
Y Axis (Tablestroke lengthwise) 650 mm
Table Ø, max Wp-Load in kg 6...
5
Serial no° 503
Operating hours 58.780
Bokoloumi
Chip conveyor
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
15
CNC machining center
Manufacturer: IBARMIA
Type: ZV 45 L3000
Year of manufacture: 1997
Machine number: 272
travels:
X-axis, longitudinal: probably 3000 mm
Y-axis, cross: 800 mm
Z-axis, vertical: probably 600 mm
Work table:
Number of T-slots: 7
size of the T-slots: 18 mm
distance between T-slots: 125 mm
distance min./max. spindle nose/table: 200/800
dimensions of working table: approx. 3600 x 850 mm
Main spindle:
Tool holder: SK40 DIN 69871
Standard speed: 6000 rpm.
Main spindle moros power at 10...
Longitudinal travel X-axe 3340 mm
Cross travel Y -axe 300 mm
Travel Z-axe (Height) 350 mm
Power on spindle 5,5 Kw
Max speed range 500 - 18 000 rpm
Clamps N° 4
Tool magazine position N. 3+1
Included in the price:
-Software cam plus
-5 Cones iso 30
-1 Aggregate double side
Cbmxsxlff7
15
Length stop, length stop, saw stop, material stop, motorized length stop, controlled length stop
-Length stop: for various processing options
-Max. Stop length: 2970 mm
-Individual components: see photos
-Dimensions: 3530/700 / H1170 mm
Hjrivvp
-Weight: 346 kg
6
x-travel 600 mm
y-travel 450 mm
z-travel 450 mm
Control HEIDENHAIN iTNC 530
Uocksms
number of spindle speeds 20.000 U/min/rpm
tool change unit 75 pos.
table-size 350 x 350 mm
table weight 200 Kg
Internal cooling system 20 bar
handwheel HR C410
weight of the machine ca. 7,7 t
dimensions of the machine ca. m
HEIDENHAIN iTNC 530
- taster
- Paper filter installation
- Linear regulator : MQL suction
- chip conveyor
11
Universal BAZ cover Maho DMU 50V with 4th +5th axis and 40bar IKZ
Year of manufacture: 2010
Control: Heidenhain 530 iTNC
Program running hours: 11.500h
Technical data:
Spindle speed: 10.000min
tool holders: SK 40
Number of magazine places: 16
travels:
X-axis: 560mm
Y-axis: 400mm
Caw7ajwwj3
Z-axis: 500mm
A-axis: endless
B-axis: +/- 105 degrees
accessories:
- Chip conveyor
- Coolant tank: 800l
Available at short notice!
4
Serial no° 512
Operating hours 50.071
Cbds2r8hdw
Chip conveyor
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
5
X-travel: 450mm, y-travel: 500mm, z-travel: 450mm, max. rotational speed: 16.000/min, spindle distance: 450mm, connected load: 72kVA, controls: SIEMENS Sinumerik 840D, length: 5100mm, width: 3050mm, height: 2800mm, weight: 20t.
Cbggbgtmwz
15
HERMLE UWF 700 CNC
Universal milling and drilling machine
I9eu0vt
Machine no .: 6851
Heidenhain contouring control TNC 150 (HS 189)
Year of construction: approx. 1985
Spindle motor: 2.2 kW
Number of spindle speeds: 18
Speed range normal: 40-2000 rpm 1
Speed range high: 56-2800 rpm 1
Geometric increment: 1.25
Ratio of lowest to highest speed: 1:50
Horizontal and vertical tool holder: ISO 40 DIN 2079
Quill stroke vertical: 63mm
Feed drive
Single DC motor for each axis
Feed range: X, Y, Z: m...
15
Length stop, length stop, saw stop, material stop, motorized length stop, controlled length stop
Bzhn9ggvja
-Length stop: for various processing options
-Max. Stop length: 2970 mm
-Individual components: see photos
-Accessories: incl. Haubold stapling device
-Dimensions: 3550/760 / H1200 mm
-Weight: 396 kg
10
x-travel 600 mm
y-travel 700 mm
z-travel 600 mm
spindle turning speed range 24.000 U/min
control Heidenhein iTNC 530
tool taper HSK 63
Internal cooling system 40 bar
tool magazin: 120 pos.
table-size 630 x 500 mm
Machine on 71581 h
Spindle hours 31755 h
total power requirement kW
weight of the machine ca. t
dimensions of the machine ca. m
Nqf9mhbf
15
3-axis machine
Dialog 12 control
Table size 800x400mm
working range:
Jfflacp
x-axis movement 500 MM
y-axis movement 400 MM
z-axis movement 400 MM
spindle speed up to 5,000 rpm
Electr. handwheel
5
Serial no° 511
Operating hours 51.725
Chip conveyor
Pwxt2q
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
3
X-travel: 300mm, y-travel: 500mm, z-travel: 450mm, max. rotational speed: 16,000/min, spindle distance: 300mm, connected load: 82kVA, controls: SIEMENS Sinumerik 840D, length: 5100mm, width: 3050mm, height: 2800mm, weight: 20t.
2ug7s3
2
Heidenhain iTNC530 programming station
2 pieces in stock
600,-€ per piece
B8u8iaprll
5
Tool setting device, tool presetting device, milling cutter setting device
-Measuring range X-axis radius: 310 mm
Jfaktip
-Z-axis: 500 mm
-Display accuracy: 0.001 mm
-Viewing unit
-Projector: Ø 150 mm
-Magnification: 20 times
-crosshairs
-360 degree protractor
-Nonius: 10min
-Dimensions: 1600/900/H2100 mm
-Weight: approx. 800 kg
4
The machine is not currently in use. Before the sale, a complete service of pneumatics and electronics will be done.
B3cgy8hq97
15
Very well maintained machining center PBX 7200 AL with many new parts and accessories.
Kbb3vz
Machine can be demonstrated on site.
Test run possible.
Self-collection preferred.
Spindle is renewed a year ago 15.000 €
4
Serial no° 511
Operating hours 43.506
Bokfnlltk
Chip conveyor
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
2
Controls: emcotronic TM02, length: 2400mm, width: 2300mm, height: 2450mm.
Btywfjn
3
GARNET 5X 5-axis machining centre
The 5-axis CNC machining centre, GARNET, has the capacity to machine aluminium profiles of different sizes, thanks to a spindle that allows machining at any angle between 0/180 on the A axis and 0/360 on the C axis, providing solutions for a wide range of operations.
The machine has been developed for all-in-one milling:
Open a channel, punch, mark and finish milling on profiles and perform special custom operations on different profiles.
Automatic terminal posi...
4
Machine is in good condition
Iqjlygj
4
Serial no. 510
Operating hours 41.464
Chip conveyor
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
Cbdswgjb2e
2
X-travel: 800mm, y-travel: 600mm, z-travel: 600mm, tool holder: ISO SK 50, rotational speed spindle: 20-6300/min, feed rate: 1-10,000mm/min, rapid traverse: 30,000mm/min, tool diameter: 130-230mm, max. tool length: 400mm, max. tool weight: 25kg, compressed air supply: 5.5-8bar, length: 5114mm, width: 4468mm, height: 3070mm, weight: 14t.
Baqabvc77k
5
Serial no. 501
Boj3pic0m
Operating hours 49.288
Chip conveyor
Automatic pallet and tool changer Fa. Fibro
Control Siemens Sinumerik
5
X-travel: 650mm, y-travel: 600mm, z-travel: 500mm, controls: HEIDENHAIN iTNC 530 (2P), spindle/ operational hours counter: 33,019/ 77,905h, including pallet automation.
Yuvpp0
4
X-travel: 560mm, y-travel: 560mm, z-travel: 510mm, pallet clamping surface: 400x400mm, tool cone: SK40, rotational speed: 18,000/min, controls: SIEMENS 840D, weight: 8.2t, spindle/ operational hours counter: 15,237/ 65,909h, without accessories, with documentation.
B80c9onjud
3
X-travel: 420mm, y-travel: 330mm, z-travel: 240mm, controls: emcotronic TM02, without accessories, machine needs overhauling.
Bqzd2cl
3
Controls: TOSNUC 500.
B8dhlunbzg
6
Number of axes: 4, x-travel: 1000mm, y-travel: 600mm, z-travel: 800mm, tool mount: ISO 50, rotational speed: 20-4000/min, spindle drive: 15kW, feed rate: 4000mm/min max., rapid traverse: 10,000mm/min, tool slots: 36, connected load: 43.5kVA, control: Phillips CNC 432, operational hours counter: 63.000h, including splash guard cabin and chip conveyor.
Vlxpnbbh
6
There are one BOSTOMATIC BD12 and one BOSTOMATIC BD12G available, controls: 2x BDC 3200, including documentation, without accessories, one touchscreen is defective, one of the machines is not functional and serves as a source for spare parts.
C0vfd8sw
3
Number of tool slots: 40, controls: MAZATROL CAM M-2.
Beyz23d
2
X-travel: 3660mm, y-travel: 1250mm, z-travel: 180mm, length: 5300mm, width: 2200mm, height: 2500mm, weight: 4.3t.
Cy3o30xi
6
X-travel: 600mm, y-travel: 560mm, z-travel: 560mm, rapid traverse: 36m/min, number of tools plate/ changer/ chain: 40/ 60/ 90, max. tool length: 350mm, number of pallets: 2, pallet dimensions: 400x500mm, controls: SIEMENS SINUMERIK 840D, operational hours: ca. 70,000h.
Fufmtnbr
4
X-travel: 2350mm, y-travel: 375mm, z-travel: 500mm, table dimensions: 2730x500mm, spindle cone: SK40, max. rotational speed: 4000/min, controls: HEIDENHAIN TNC 355.
Bqjl0yydu0
3
Controls: SIEMENS Sinumerik 3M, documentation available.
Bvkbohhm
2
X-travel: 2000mm, y-travel: 520mm, z-travel: 630mm, max. workpiece dimensions: 650x320mm, number of tool slots: 40, controls: SIEMENS 840D.
Brtnnfrmx0
6
X-travel: 500mm, y-travel: 250mm, z-travel: 145mm, table dimensions: 885x320mm, max. load: 250kg, rotational speed: 50-10,000/min, controls: HEIDENHAIN TNC 407, weight: 2.4t, operational hours counter: ca. 39,900h.
Bz90tqdgum
4
The machine is functional, one drive belt needs to be replaced.
Mciwsdmd
1
X-travel: 3600mm, y-travel: 900mm, z-travel: 820mm, controls: SIEMENS SINUMERIK 840D, with accessories, machine needs overhauling, swivelling head and magazine sensor are defective.
E08kseszm
1
Controls: FANUC Series 16-M.
Jcxth3sdw
1
X-travel: 1100mm, y-travel: 600mm, z-travel: 510mm, table spindle distance: 120-630mm, table dimensions: 1300x600mm, max. load: 1t, controls: HEIDENHAIN iTNX 530, weight: 8.5t.
