Used Centers (universal) 800-999mm (x-travel) for sale (81)

Condition: excellent (used), Year of construction: 2019, Hermle C42U 5 Axis Machining Centre HS Flex 18 pallet system Traverses XYZ: 800 x 800 x 550mm, 440mm rotary table, A axis +91°, -139°, C axis 360 degrees, spindle power 31kW, 15000rpm, HSK A 63, 88 station tool changer, swarf conveyor, through spindle coolant 80 bar, Heidenhain TNC640 control, Renishaw probe, 6 off 400 x 400 pallets Crgwly9Mbk

Condition: used, Year of construction: 2002, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain Main spindle: turning speed range - main spindle 20 - 10.000 min/-1 power capacity - main spindel 13 kW Torque 130 Nm tool taper BT 40 DIN 69872 work table: table surface area 1.250 x 700 mm max. table load ca. 500 kg table diameter 700 mm T-slots 11x 14 x 63 mm max. table speed 15 min/-1 tool magazin: number of toolpositions 32 (2x 16) pos. tool taper BT 40 max. tool diameter 80 / 130 mm max. tool-dia with free toolbox 160 mm max. tool length 315 mm max. tool weight 8,0 kg feeds: feed speeds 20 - 15.000 mm/min rapid traverse 12 m/min total power requirement 30 kVA weight of the machine ca. 9,0 t dimensions of the machine ca. 4,0 x 3,0 x 2,5 m Dqqktd CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 T - 5-Axis - Rotary table in Fixed-Table - Retrofitting to SK 40 optionally possible!

Condition: used, Year of construction: 2007, x-travel 880 mm y-travel 630 mm z-travel 630 mm control MillPlus iT Heidenhain number of spindle speeds 20 - 12000 1/min spindle taper SK 40 DIN 69871 max. torque at 40% / 100% load 28 / 19 kW tool change unit 2 x 16 Pos. table-size 1250 x 700 mm table load capacity 650 kp total power requirement 44 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 3,50 x 3,20 x 2,60 m NC rotary table Ø 800mm 5th axis B (-30°/+90°) Infrared probe Renishaw OMP 60 Dqq7It 4. Operating mode Rotoclear Coolant system basic volume 250 Liter flush gun high pressure pump chip conveyor air filter system

Year of construction: 2017, Condition: excellent (used), With B + C axis Working travels 800 x 900 x 620 mm Table diameter 800 mm Cxx3G0Vab9 Spindle taper HSK63 Spindle speeds -15'000 rpm Tool changer 64 Pos. Control HEIDENHAIN iTNC 640 Coolant through spindle Misc.accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2001, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller manufacturer: HEIDENHAIN, controller model: TNC430, workpiece weight (max.): 500 kg, total height: 2,410 mm, total length: 3,500 mm, total width: 2,200 mm, table width: 700 mm, table length: 1,250 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 32, tool length: 315 mm, tool diameter: 130 mm, tool weight: 8,000 g, CNC controller: HEIDENHAIN TNC430 Axes X-axis travel mm: 880 Y-axis travel mm: 630 Z-axis travel mm: 630 C-axis degrees: 360º B-axis degrees: NC swivel millin head Worktable Table dimensions mm: 1.250 x 700 Max. workpiece weight kg: 500 T-Slot version: 1xT-Slot 14 H7 ; 10xT-Slot 14 H12 Spindle Cqjeet2Wd0 Spindle speed rpm: 12.000 Milling/turning table nc Table dimensions mm: Ø700 Max. workpiece weight kg: 350 Table rotation speed rpm: 15 max. torque Nm: 4.377 (at 25%) Drive power kW: 15/10 (40%/100% DC) Tool system Tool holder: SK40 Tool magazine slots: 32 (2x16) Max. Tool Diameter: 130 mm (Magazine 1)/ 80 mm (Magazine 2) Max. Tool Length mm: 315 Max tool weight kg: 8 Equipment Electronic Handwheel Chip conveyor Rigid table with integrated rotary table Infrared probe Rinsing gun Infrared Probe Heidenhain TS631 Machine running times Under power: 74.352 Spindle Working: 30.187 Rated power kVA: 30 Basic machine dimensions / weight Length mm: 3.500 Width mm: 2.200 Height mm: 2.410 Weight kg: 9.000 Powered by

Year of construction: 1999, Condition: excellent (used), DMU80E Bvgjzrx7Lx with hard disk storage Control Heidenhain 426M Year 1999 2014 axes and spindle revised Speed 18000 Since the revision approx. 1200 hours run Accuracy according to a new machine Chip conveyor available Accessories would be available at extra cost.

Condition: excellent (used), Year of construction: 2006, Control Heidenhain iTNC 530 Travel X/Y/Z: 980 x 630 x 630 mm Speed 12,000 min-1 Tool magazine for 32 tools, SK 40 NC rotary table Dqk9Lx NC swivel milling head (B-axis) -120° /+ 30° IKZ 40 bar Electronic handwheel Chip conveyor

Condition: new, Year of construction: 2024, Functionality: fully functional, machine/vehicle number: N2495255010011, travel distance X-axis: 800 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,020 mm, GROB G550 access-SERIE - FACTORY | NEW MACHINE Highlights: - powerful motor spindle - pallet clamping system - 90 tools in the system Basic machine G550 access-SERIE Travel path of the X-axis 800 mm Travel path of the Y'-axis 950 mm Travel path of the Z-axis 1020 mm Power supply 400 V, 50 Hz, TN-S Decentralized work area mist collector Stainless-steel internal work area enclosure Fluid cabinet doors SIEMENS SINUMERIK 840D sl with the machine control panel GROB⁴Pilot Generation 2 Tilting table unit (A'-axis) Rotary table with pallet clamping system (B‘- axis) Motorized spindle HSK-A 63, 16,000 rpm, 159/206 Nm, 25/32 kW, oil-air lubrication Dqqyrv Compact double disk-type magazine HSK-A 63 with 90 tool pockets Tool cleaning device Electromechanical tool breakage detection device Palette 630 x 630 mm, grid holes, without pallet changer hook Scraper conveyor , discharge height 1,100 mm High-pressure cutting fluid system (5-40 bar, IKZ) Compressed air feed through spindle center Air gun at the work area Flush gun at the work area Flushing unit (Z- axis) Compressed air cleaner bar for safety screen in work area door Remote machine diagnostics with access control switch 12 month warranty

Condition: used, Year of construction: 2012, x-travel 800 mm y-travel 950 mm z-travel 1020 mm Control SIN840D sl B - axis 360 x 0,001 ° A - axis -185 / +45 x 0,001 ° feed x-axis 1 - 65.000 mm/min C0O3Oatb7U feed y- axis 1 - 50.000 mm/min Feed z- axis 1 - 80.000 mm / min. rapid traverse X/Y/Z 60 / 50 / 80 m/min spindle turning speed - stepless 1 - 18.000 U/min power capacity at 100 % load 29,00 kW power capacity at 40 % load 38,00 KW max. torque at 40% / 100% load 46,00 / 34,00 Nm spindle diameter in front bearing 70 mm tool taper HSK-A63 tool magazin: 2x 60 tool length - max. 360 / 400 mm tool diameter 68 mm tool diameter with 2 vacant positions 160 mm tool total weight 8,00 kg Chip to chip time 4,2 sec. size of pallet 2x 630x630 mm workpiece weight 700 kg interference diameter 900 mm total power requirement 50,00 kW weight of the machine ca. 25,00 t dimensions of the machine ca. 7,00 x 4,00 x H3,50 m 5-axis machining center with SIEMENS Sinumerik 840D SL control, integrated KNOLL coolant system KF150, coolant high-pressure 80bar, coolant through the spindle, chip conveyor, pallet changer, RENISHAW OMP60 measuring probe, electromechanical tool length check, HT8 manual operating device, BLUM-Laser, GROB Spindle-diagnosis (GSD) workpiece pallets with ROEMHELD Speedy classic4 zero-point clamping system, integrated workpiece clamping, kinematics-set. The machine can be inspected under power.

Year of construction: 2007, Condition: excellent (used), HEIDENHAIN iTNC530 with B + C axis Working travels 885 x 800 x 520 mm Table size 600 x 500 mm Table swivelling +30°/-120° Table rotating 360° Spindle taper SK40 Big Plus Spindle speeds -15'000 rpm tool changer 60 pos. Coolant through spindle 3D tracer Renishaw Sv9Cko MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2007, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, table width: 630 mm, table length: 800 mm, spindle speed (max.): 12,000 rpm, CNC controller: Heindenhain MillPlus iT Axes X-axis travel mm: 800 Y-axis travel mm: 800 Gxczpvi Z-axis travel mm: 800 C-axis degrees: 360º (0.001º) B-axis degrees: Swivel head Spindle Spindle speed rpm: 12.000 Spindle drive power kW: 28/19 (40/100% ED) Milling/turning table nc Number of pallets: 2 Table dimensions mm: 800 x 630 T-Slot: 14 mm Tool system Tool holder: SK 40 Tool magazine slots: 180 Equipment Chip conveyor Rotating inspection windows Rinsing gun Operating mode 4 Infrared Probe Heidenhain TS640 Cooling Cooling through the Spindle Center bar: yes Tank capacity: 980 High-pressure bar: 40/80 Machine running times Under power: 123.482 Spindle Working: 52.719 Basic machine dimensions / weight Length mm: 4.558 Width mm: 3.116 Height mm: 2.791 Weight kg: 20.000

Condition: good (used), Year of construction: 1998, Functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 15,000 rpm, Equipment: documentation/manual, Machine details Stock-No. 1105-03955 Type of machine Machining Center - Universal Make HERMLE Type C 800 U Year of manufacture 1998 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time CALL ME Freight basis EX WORK Technical details x-travel 800 mm y-travel 600 mm z-travel 500 mm control TNC 426 HEIDENHAIN turning speeds 15000 1/min taper ISO ISO 40 tool change unit 98 Ch8Lrgy spindle 15 kW Additional information 5-axis machine with round-swivelling table, NC-swivelling table dia. 290mm,A-axis from -110° - +110°, B-axis 360°, Laser tool measuring system Ethernet interface, EXTRA MAGASIN 96 TOOLS flush gun, lots of accessories,

Condition: used, Year of construction: 2005, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain Main spindle: turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 / 82 Nm tool taper HSK-A 63 swivellable B: +30° / -120 ° NC-Rotary table: table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg rotatable C: 360 ° max. workpiecediameter 850 mm max. workpiece height 550 mm tool magazin: number of toolpositions 32 pos. tool taper HSK-A 63 max. tool diameter 80 mm Dqkarp max. tool-dia with free toolbox 160 mm max. tool weight 8,0 kg change-time chip to chip 10 sec feeds: feed speeds max. 30.000 mm/min rapid traverse 30 m/min Accelaration 5 m/s² total power requirement 48 kVA weight of the machine ca. 14,0 t dimensions of the machine ca. 6,5 x 5,0 x 2,9 m 5 Axis CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 monoBLOCK - NC-Rotary Table (C-Achse) integrated in rigid-table - Swivel-Milling-Head (B-Axis) - only 6.100h Power-On Hours

Condition: excellent (used), Year of construction: 2016, operating hours: 27,010 h, Functionality: fully functional, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, operating hours of spindle: 11,140 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, - Year of manufacture 2016, Heidenhain TNC640, - Machine ON: 27010 h Spindle ON: 11140 h - HSK-A 63 18000 min-1 - SRT650 worm drive - 38 tool positions - IKZ 40 bar - Scraper belt conveyor - Renishaw measuring probe - handwheel - Blum Laser A2 - KinematicOpt hardware - Oil mist extraction - Blowing air outside Dqpkel very well-kept condition - few spindle hours We guarantee perfect operation and will be happy to commission the machine on site.

Year of construction: 2008, Condition: good (used), CNC control Heidenhain iTNC530 NC swivel head (B-axis) NC-rotary table (C-axis) automatic tool changer for 60 tools chip conveyor coolant through spindle device New milling spindle mounted (0 hours) Technische Daten / technical details: X-Weg / X-travel 885 mm Y-Weg / Y-travel 600 mm Z-Weg / Z-travel 600 mm B-Achse / B-axis -10 - +110 ° C-Achse / C-axis 360 ° Spindelaufnahme / spindle taper SK40 Drehzahlbereich Spindel / spindle speed 18000 Upm /rpm Vorschub / infeed 90 m/min NC-Rundtischdurchmesser / NC-rotary table diameter 750 mm Dkm3Bf Antriebsleistung / drive capacity spindle 73 kW Gewicht der Maschine ca. / weight 12000 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: like new (used), Year of construction: 2019, operating hours: 1,500 h, Functionality: fully functional, DMG MORI (as good as new) DMU 85monoBLOCK X-935 mm Y- 850 mm Z-650 mm NC swivel rotary table Table top C-axis: d 858 x 758 mm, integrated in fixed table 1,000 mm x 758 mm Control system: CELOS with Siemens 840D sl Operate including 21.5 ERGOline® Control with multi-touch screen Motor spindle: SK 50 Spindle speed 20 - 10,000 min-1 Power 44 kW / 32 kW Torque 288 Nm / 187 Nm (40 / 100 % duty cycle) Tool magazine Vertical chain magazine basic 0L7Wngd with 60 magazine slots SK 50 Production package: Scraper belt chip conveyor with 600 liter coolant system, paper belt filter Discharge height: 950 mm, width: 970 mm IKZ 40 bar / 23 l/min through spindle center (AD) External coolant supply 4 bar (data as theor. pump capacity) Chip flushing in work area door (chip conveyor suitable for short-breaking chips) Coolant ring nozzle for vertical headstock, 16 water nozzles, 7 air nozzles Oil and emulsion mist separator Mechanical filter Throughput volume 600 m'/h Infrared measuring probe Heidenhain TS 649 MPC - Machine Protection Control Machine protection through quick shutdown Electronic handwheel Siemens 840D

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 550 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530 HSCI, workpiece length (max.): 800 mm, workpiece width (max.): 700 mm, workpiece height (max.): 600 mm, workpiece diameter (max.): 950 mm, workpiece weight (max.): 600 kg, rotational speed (max.): 900 rpm, spindle speed (max.): 10,000 rpm, coolant supply: 40 bar, number of slots in tool magazine: 60, CNC controller: HEIDENHAIN iTNC 530 HSCI Axes X-axis travel mm: 800 Y-axis travel mm: 650 Z-axis travel mm: 550 C-axis degrees: 360º (0.001) A-axis degrees: -5º/110º (0.001) Distance spindle nose - table surface mm: 150 - 700 Feed rates m/min: 80 Rapid traverse m/min: 80 Acceleration in the axes m/s2: 10 Spindle Spindle speed rpm: 10.000 Milling/turning table nc Table dimensions mm: 800 x 700 Maximum workpiece size (D x H) mm: 950 x 600 Max. workpiece weight kg: 600 Table rotation speed rpm: 900 Tool system Tool holder: SK40 Tool magazine slots: 60 Equipment Electronic Handwheel Chip conveyor Rinsing gun Blowing air through spindle center selectable via M-function Signal lamp C2Sc2R39 High pressure pump NC swivel rotary table Preparation for the use of the 3D quickSET Laser tool measurement for measuring tool length and diameter Direct measuring system XYZ Internal coolant supply Electrical cabinet active cooling unit Paper band filter RENISHAW OMP60 Cooling Tank capacity: 980 High-pressure bar: 40/80 Machine running times Under power: 50.739 Spindle Working: 0 (retrofitted) Basic machine dimensions / weight Length mm: 2.440 Width mm: 3.350 Height mm: 3.050 Weight kg: 10.000

Condition: good (used), Year of construction: 2011, 5-axis CNC machining center Manufacturer: Hermle Machine model: C42 U Control: Heidenhain iTNC 530 Year of manufacture: 2011 TECHNICAL DATA Travels - X-axis: (mm) 800 - Y-axis: (mm) 800 - Z-axis: (mm) 550 Number of controlled axes: 5 Spindle - Spindle speed max.: (rpm) 18,000 IKZ: (bar) 80 - Blowing air through spindle Tool magazine - Tool holder: HSK 63 - Tool positions: 42 Rotary table - Swivel rotary table diam.: (mm) 440 - Swivel rotary table with torque drive in the C-axis Bslr3Mcjdpo - Swivel rotary table with 6-fold rotary feed-through - A-axis with spur gear tandem drive EQUIPMENT FEATURES + Electric iTNC manual operating module + Electrical heat compensation iTNC + Scraper belt chip conveyor + Paper belt filter + Chip flushing gun + Blow-off device + Sealing air for glass scales Bed rinsing + Internal cooling (IKZ) 80 bar + Automatic cabin door + Automatic cabin roof + Blum tool breakage monitoring system + Measuring probe incl. preparation + Comfort control panel + Laminated glass safety window Technical data and specifications are subject to change without notice.

Condition: used, Year of construction: 1999, Technical details: x-axis: 800 mm y-axis: 500 mm z-axis: 510 mm control: Siemens 840D number of spindle speeds: 36 - 10000 U/min. tool changer with: 42 tools tool clamping: 12000 N tool taper: SK40 max. torque on the spindle: 102 Nm feed continuous: X/Y/Z: min./max.: 1/10000 / 1/10000 / 1-10000 mm rapid traverse: X/Y/Z: 40/40/40 m/min voltage: 400 / 50 V / Hz Oiqbceb total power requirement: 70 kW HIGH PERFORMANCE DRIVING COLUMN - MACHINING CENTER Coolant system with paper band conveyor chip conveyor make Flender MC535/x=800 hydraulic aggregate make HAWE Loading system Promo cutting values: max. milling capacity=400mm max. drilling Ø 50mm max. thread Ø M30 1 motor each for main spindle 1 + 2: make Kessler; 21 kW; speed 15.000 rpm. 1 motor each for X / Y / and Z-axis: Make Siemens; for X/Y axis 14.0 Nm and Z axis 17.6 Nm torque; speed 3000 rpm. *

Condition: used, Hermle C 600 U 5-axis CNC universal machining center Milling machine X-axis: 600mm Y-axis: 450mm Bei0Dm3 Z-axis: 450mm Spindle holder: HSK A 63 Feed range: 1-30000mm/min Speed: 35m/min rotational speed: Ø turntable: 280mm Rotation range: A-axis: +20 / - 90° Rotation range C-axis: 360 Control: Heidenhain iTNC 530 Year of manufacture: 2002 Weight: approx. 6500 kg You are welcome to come by for a viewing. We will be happy to arrange a cost-effective forwarding agent for you. organize! You will receive a proper invoice. A net invoice can also be issued for foreign customers. Prerequisite is a valid VAT number. Subject to prior sale. Visit our store and have a look at our other offers. Company names and trademarks are the property of their owners and are used only to identify and describe the products. Deviations from technical data and errors in the description of the article may occur and are reserved.

Condition: reconditioned (used), Year of construction: 2010, • Traveling distances X=3100 mm, Y=1950 mm, Z=1390 mm • Heidenhain iTNC 530 with handwheel HR 410 • Machine table for multi side working 3000 mm x 1600 mm • 2-axis NC-universal milling head, for simultaneous and positioning working • Spindel 10.000 U/min HSK 100, 130 Nm Spindle torque • Tool change system HSK 100 / 40 places for 750 mm long tools • Chip conveyor (screw type) in X-axis, for transport into • Chip conveyor scraper belt type (traverse conveyor), Fabr. Knoll • Coolant container 900 l, Fabr. Knoll • Outside air at spindle • IKZ 60 bar for deep hole drilling function • Covering with safety glass pane, open at the top for loading by crane Ccnn2U9R • 2 part sliding doors at the operator side • 2 part sliding doors at the front side, for easy loading • Radio-controlled measuring probe RMP 60 • incl. washing gun • incl. podiums at the front side and operator side • complete factory overhauled and painted new • short time delivery after arrangement • used machine • Y-axis ball screw in September 2021 incl. bearings renewed • X-axis new linear guiding system, July 2023 changed, renewed • Spindle overhauled at Mai 2023 (clamping system new, clamping cartridge new, rotation unit new, general tests) (at 23105 spindle hours)) • can be visited under power at 72793 Pfullingen • optional fixators • optional installation at customers plant • optional transport • 23122 spindle hours in total • 53991 machine hours in total • Year of construction 2010 Subject to prior sale

Condition: excellent (used), Year of construction: 2016, x-travel 950 mm y-travel 850 mm z-travel 650 mm Control HEIDENHAIN TNC 640 spindle turning speed range 20000 U/min tool taper HSK-A 63 coolant IKZ 40 bar swivable table: 850 x 750 mm c-axis 360° tool change unit 60 Pos. total power requirement kW weight of the machine ca. 14 t dimensions of the machine ca. m This DMG DMU 95 monoBLOCK is in very good condition and can be inspected under power at the seller's premises by prior arrangement. Technical data: Clamping surface table C-axis: 850 x 750 mm Clamping surface rigid table: 1,000 x 750 mm Control: 3D control HEIDENHAIN TNC 640 Spindle speed: 20,000 rpm Spindle power: 35 kW (40% ED) / 25 kW (100% ED) Tool holder: HSK-A 63 according to DIN 69893 Tool changing device: Double gripper Bsi2Edldz23 Magazine slots: 60 (chain magazine) Connected load: 50 kVA Coolant system IKZ: 40 bar / 23 l/min through spindle centre (AD) External coolant supply: 4 bar / 40 l/min EQUIPMENT and DESCRIPTION - MPC Machine Protection Control chip tray with integrated coolant tank 500 l - Scraper belt chip conveyor with coolant system 600 litres, paper belt filter - Infrared measuring probe HEIDENHAIN TS 649 - 3D quickSET extension package - Coolant ring nozzle for vertical headstock, 15 water nozzles, 5 air nozzles - Flushing gun with pump 2 bar / 40 l/min - Cooling device Blast air through spindle centre, selectable via M function - Operating mode 4 - Manual intervention with open work area doors - Documentation

Condition: as good as new (ex-display), Year of construction: 2023, Functionality: fully functional, machine/vehicle number: S2479855210219, travel distance X-axis: 800 mm, travel distance Y-axis: 1,020 mm, travel distance Z-axis: 970 mm, controller manufacturer: Siemens, controller model: ONE, workpiece height (max.): 525 mm, workpiece diameter (max.): 900 mm, workpiece weight (max.): 600 kg, rotational speed (min.): 800 rpm, spindle speed (max.): 14,500 rpm, coolant supply: 80 bar, number of slots in tool magazine: 243, tool length: 750 mm, input voltage: 400 V, Equipment: chip conveyor, rotational speed infinitely variable, Highlights: - Powerful mill- turn motorized spindle with 14.500 rpm | 58 KW | 261 NM - Palette storage systems PSS-R900 with 10 storage locations - 243 tools in the system Basic machine G550 T Generation 2 Power supply 400 V, 50 Hz, TN-S Work area door, automatic, for manual and automatic loading/unloading Decentralized work area mist collector: 800 m³ Machine control system SIEMENS SINUMERIK ONE GSC Advanced F3I7Mvh Time-controlled start of warm-up program - programmable at the HMI EES function to realize CN program on an external data carrier (SIEMENS) Tilting table unit (A'-axis) Rotary table with pallet clamping system GROB (B'-axis) Motorized spindle HSK-T 100, 14,500 rpm, 225/261 Nm, 50/58 kW, oil-air lubrication GROB spindle diagnostics GSD Double disk-type tool magazine HSK-A 100 for extra-long tools with 72 pockets in total Additional tool magazine TM180 HSK-A 100 with 180 tool pockets Tool cleaning device Tool coding, system BIS-M (BALLUFF) Electromechanical tool breakage detection device Laser measurement system LaserControl LC52-DIGILOG for mill and turn tools, A'=0° (BLUM-NOVOTEST) Rotary pallet storage system PSS-R900 with 10 storage locations Setup station PSS-R900, high-precision setup station, rotated manually Air gun at setup station Cutting fluid return of rotary pallet storage system PSS-R Lighting in the setup station of the PSS pallet storage system Support EES-Aufruf PSS-R450-1800 Tool requirement planning PSS-R450-1800 Support GSC swivel axis calibration PSS-R450-1800 4 Pallet´s 630 x 630 mm, with star-configured T-slots, without pallet changer hook Additional pallets can be selected optionally Slat band chip conveyor, discharge height 1,100 mm High-pressure cutting fluid system (10-80 bar, IKZ) Continuous cooler for cutting fluid with an air cooled cooling unit (13 kW) Compressed air feed through spindle center Changeable cutting fluid pressure increase for the motorspindle nozzles Cutting fluid recirculation on weekends Oil skimmer for cutting fluid care Air gun at the work area Flush gun at the work area Flushing unit (Z-axis) Machine accuracy package 1 Work area camera for machine control panel GROB⁴Pilot Preparations for use of radio signal receiver (RENISHAW) Radio touch probe RMP600 (RENISHAW) Remote machine diagnostics with access control switch 12-month warranty *The machine pictures contain special equipment that differs from the quotation, such as clamping devices and roller shutter

Condition: excellent (used), Year of construction: 2018, x-travel 950 mm y-travel 850 mm z-travel 650 mm Control HEIDENHAIN TNC 640 spindle turning speed range 20000 U/min tool taper HSK-A 63 coolant IKZ 40 bar swivable table: 850 x 750 mm c-axis 360° tool change unit 60 Pos. total power requirement kW weight of the machine ca. 14 t dimensions of the machine ca. m This DMG DMU 95 monoBLOCK is in very good condition and can be inspected under power at the seller's premises by prior arrangement. Technical data: Clamping surface table C-axis: 850 x 750 mm Clamping surface rigid table: 1,000 x 750 mm Control: 3D control HEIDENHAIN TNC 640 Spindle speed: 20,000 rpm Spindle power: 35 kW (40% ED) / 25 kW (100% ED) Tool holder: HSK-A 63 according to DIN 69893 Tool changing device: Double gripper Bsi2Dfrohls Magazine slots: 60 (chain magazine) Connected load: 50 kVA Coolant system IKZ: 40 bar / 23 l/min through spindle centre (AD) External coolant supply: 4 bar / 40 l/min EQUIPMENT and DESCRIPTION - MPC Machine Protection Control chip tray with integrated coolant tank 500 l - Scraper belt chip conveyor with coolant system 600 litres, paper belt filter - Infrared measuring probe HEIDENHAIN TS 649 - 3D quickSET extension package - Coolant ring nozzle for vertical headstock, 15 water nozzles, 5 air nozzles - Flushing gun with pump 2 bar / 40 l/min - Cooling device Blast air through spindle centre, selectable via M function - Operating mode 4 - Manual intervention with open work area doors - Documentation

Condition: as good as new (ex-display), Year of construction: 2017, Functionality: fully functional, machine/vehicle number: S253105521883, travel distance X-axis: 800 mm, travel distance Y-axis: 1,020 mm, travel distance Z-axis: 970 mm, controller manufacturer: Siemens, controller model: 840D sl, spindle speed (max.): 30,000 rpm, coolant supply: 40 bar, number of slots in tool magazine: 311, tool mount: 63 mm, tool length: 700 mm, tool weight: 8,000 g, input voltage: 400 V, Equipment: chip conveyor, rotational speed infinitely variable, Highlights: - Powerful motorized spindle with 30.000 rpm - 311 | HSK 63-A tools in the system - PSS-R900 with 13 storage locations Basic machine G550 AB generation 2 Power supply 400 V, 50 Hz, TN-S Work area door, automatic, for manual and automatic loading/unloading Decentralized work area mist collector SIEMENS SINUMERIK 840D sl control system Swivel axis calibration GSC Classic Tilting table unit (A'-axis) Rotary table with pallet clamping system GROB (B'-axis) Motorized spindle HSK-A 63 30,000 rpm, 48/63 Nm, 40/53 kW, oil-air lubrication GROB spindle diagnostics GSD Double disk-type tool magazine HSK-A 63 for extra-long tools with 126 pockets in total Additional tool magazine TM200 HSK-A 63 Tool cleaning device Tool coding, system BIS-M (BALLUFF) Electromechanical tool breakage detection device Laser measurement LaserControl Micro Compact NT for milling tools, A'=-180° (BLUM) Pallet storage system PSS-R900 with 13 storage locations Air gun at setup station GROB⁴Automation Tool requirement planning 13 Palette`s 630 x 630 mm, grid holes Crdp7Qzx88 High-pressure cutting fluid system (5-40 bar, IKZ) Continuous cooler for cutting fluid with an air cooled cooling unit (13 kW) Compressed air feed through spindle center Changeable cutting fluid pressure increase for the motorspindle nozzles Cutting fluid recirculation on weekends Oil skimmer for cutting fluid care Air gun at the work area Flush gun at the work area Part clamping system in work area - KP1: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP2: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP3: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP4: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) Part clamping system in setup station of pallet storage system PSS - KP1: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP2: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP3: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP4: Pressure oil, proportional valve technology and volume counter 30-190 bar (H3.1) - KP5: Compressed air, manual pressure regulation, 0.5-5 bar (P1.1) - KP6: Compressed air, manual pressure regulation, 0.5-5 bar (P1.1) Machine status light, 3-colored Machine accuracy package 1 Radio touch probe RMP600 (RENISHAW) Remote machine diagnostics with access control switch 12-month warranty
