Centers (universal) 0-599mm (x-travel) for sale
15
Universal machining center, CNC tool milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine
Bgrhjrzb32
-function tested
-Clamping table: 800 x 445 mm
-Travel: X/Y/Z 500/500/385 mm
-Spindle holder: SK40
-quill stroke: 90 mm
-Speeds from: 31.5 to 3150 rpm
-Coolant device
-Dimensions: 1475/1770/H2000 mm
-Weight: 1966 kg
10
x-travel 500 mm
y-travel 400 mm
z-travel 400 mm
Control TNC 426 Heidenhain
Main spindle:
turning speed range - main spindle 20 - 9.000 min/-1
power capacity - main spindel 9 / 13 kW
max. Torque 57 / 82 Nm
tool taper SK 40 DIN69871
swiveling-rotary-table:
table diameter 700 x 500 mm
swivellable man. B: 105° (-10°/+95) °
rotatable man. 360 °
max. table load 200 kg
number of T-slots 7
T-slot - distance 63 mm
T-slot - width 14H7 mm
center hole 30H6 mm
Tool-Presetter:
number of toolpositions...
8
x-travel 2000 mm
y-travel 400 mm
z-travel 630 mm
control Siemens 840D
main spindle:
max. turning speeds 10000 min/-1
B00brxrqhn
tool changer:
tool taper SK 40
number of tool places 12 Pos.
In our estimation, the machine is in very good condition
and can be viewed live by appointment.
technical features:
- 2 spindles
- Spindle distance 320 mm
- 2 x 12-fold tool changer (basket)
Equipment:
- coolant system
- IKZ
- chip conveyor
- Drill breakage control
*** There are two identical machi...
5
CONTROLS
.. CNC controls HEIDENHAIN ITNC 530
WORKING RANGE -CUBIC-
.. number of processing axes (excl parallel axes): 5
.. .. among of them simultaneous CNC axes: 5
.. X-axis travel: 400 mm
.. Y-axis travel: 240 mm
.. Z-axis travel: 350 mm
.. rotating range B-axis from: 110 °
.. rotating range B-axis up to: -110 °
.. rotating range C-axis from: 0 °
.. rotating range C-axis up to: 360 °
MILLING SPINDLE / HEAD
.. spindle revolutions (max): 42000 /min
.. tool fixture: HSK E40
.. drive power...
5
x-travel 200 mm
y-travel 200 mm
z-travel 280 mm
Control HEIDENHAIN iTNC 530
total power requirement 80 kW
weight of the machine ca. 5000 kg
dimensions of the machine ca. m
D M G - SAUER (Germany)
Universal CNC 5-Axis HSC - Machining Centre with high speed linear
drives and workpiece Magazin Model SAUER PH 10/100
Model HSC 20 Linear / High Speed Cutting Year 2009
_____
Working range: Longitudinal stroke X Axis 200 mm
Vertical stroke Z Axis 280 mm
Cross stroke Y Axis 200 mm
Positioning ...
8
High performance machining center Mikron HEM 500U
Year of manufacture 2015, commissioning 2016
axes RTT 3+2, rotary swivel table
travels: X= 500 Y=450 Z=400 mm
Control Heidenhain iTNC 530
spindle 12000 min-/ISO-B40
tool magazine DT30/DT40
T-slot table 500D parallel
ascending chip conveyor
Production package IKZ20 bar
Full protection cabin
Preliminary IKZ & air through spindle 12k
Operating status light
Mobile handwheel Heidenhain
Tool touch probe (TS27R)
Glass scales
Encoder for B and C axis
Tou...
8
5-Axis Vertical machining centre.
Makino D500
New in 2014
Fanuc 310iS + Pro 5 control.
2-Axis NC rotary swivelling table.
Table diameter 500 mm.
Table load max. 500 kg.
C-Axis rotation 360° / 0.0001°.
A-Axis swivelling axis +30°/-120° - 0.001°.
Work diameter max. 650 mm.
Work height max. 500 mm.
X 550 mm.
Y 1000 mm
Z 500 mm.
Feeds X 1 - 32000 mm/min.
Feeds Y,Z 1 - 40000 mm/min.
Feeds A/C 18000 °/min.
Rapids X 48000 mm/min.
Rapids Y,Z 50000 mm/min.
Rapids A/C 18000 °/min.
Spindle drive motor 15...
10
x-travel 500 mm
y-travel 400 mm
z-travel 400 mm
Control iTNC 530 Heidenhain
Main spindle:
turning speed range - main spindle 20 - 9.000 min/-1
power capacity - main spindel 9 / 13 kW
max. Torque 57 / 82 Nm
tool taper SK 40
swiveling-rotary-table:
table diameter 700 x 500 mm
swivellable B: 105° (-10°/+95) °
rotatable C: 360 °
max. table load 200 kg
number of T-slots 7
T-slot - distance 63 mm
T-slot - width 14H7 mm
center hole 30H6 mm
Tool-Presetter:
number of toolpositions 16 pos.
tool ta...
5
Control Unit
Brand Heidenhain
Model 410
Main Drive
Number of spindles 1
Spindle speed range 30-4000
Number of axis 3
Hdsgkpd
Movement
X-Axis Movement 500 MM
Y-Axis Movement 400 MM
Z-Axis Movement 400 MM
A-Axis Movement 1500-4000 mm
Tools
Number of station 18
Type of tool holder SK40
Media
Chip conveyor Yes
This ALMA SWITZERLAND Alma Hbz-500 Universal Machining Center was manufactured in the year 1997. It has approximately 29000 working hours. This 3 axis machine operates with a spindle spee...
3
Technical Details
x-way 500 mm
y-way 420 mm
z-travel 380 mm
Control HEIDENHAIN Mill-Plus
Fn8dk99
Mounting Sk40
Controlled 2 AXIS NC rotary swivel table,
chip conveyor
full cabin,
Tool magazine 30-fold SK40
18000 RPM
6
CNC- control make Heidenhain, 20-fold tool changer, tool holder HSK 40, max. tool length 130 mm, max. tool diameter 16 mm, travel X- axis 485 mm, Y- axis 340 mm, Z- axis 355 mm, table size 470 mm x 400 mm, separate pallet changer make SAV, type 1600-I, with 8 clamping stations, separate cooling unit and separate control cabinet.
Ibmjwph
2
Turning capacity ST-10 Tool measuring system in the machine Chuck size (∅) 165 mm Max. Turning diameter 229 mm Max. Turning length without workpiece holder 355 mm Bar diameter (standard) 44 mm Chip conveyor Year of construction 12/2015 Commissioning 2016 Running time 7420 hours
Milling Travel X = 1270 Y = 508 Z = 635 Distance spindle axis to machine table 742 Spindle nose to table 107mm Table Length X = 1321 Width Y = 457 Width of T groove 16 Max weight payload 1588 Kg - Spindle with 8,100 rpm -...
8
5-Axis Vertical Machining Centre.
Makino D500
New in 2014
Fanuc 310iS + Pro 5 control.
2-Axis NC rotary swivelling table.
Table diameter 500 mm.
Table load max. 500 kg.
C-Axis rotation 360° / 0.0001°.
A-Axis swivelling axis +30°/-120° - 0.001°.
Work diameter max. 650 mm.
Work height max. 500 mm.
X 550 mm.
Y 1000 mm
Z 500 mm.
Feeds X 1 - 32000 mm/min.
Feeds Y,Z 1 - 40000 mm/min.
Feeds A/C 18000 °/min.
Rapids X 48000 mm/min.
Rapids Y,Z 50000 mm/min.
Rapids A/C 18000 °/min.
Spindle drive motor 15...
1
x-travel 500 mm
y-travel 400 mm
z-travel 400 mm
Control TNC 426 / 430 Heidenhain
Main spindle:
B2bw8lg9c0
turning speed range - main spindle 20 - 9.000 min/-1
power capacity - main spindel 9 / 13 kW
max. Torque 57 / 82 Nm
tool taper SK 40
swiveling-rotary-table:
table diameter 700 x 500 mm
swivellable B: 105° (-10°/+95) °
rotatable C: 360 °
max. table load 200 kg
number of T-slots 7
T-slot - distance 63 mm
T-slot - width 14H7 mm
center hole 30H6 mm
Tool-Presetter:
number of toolpositions...
4
- control Heidenhain
- electric handwheel
- 3 axis
- fix angle table: 700 x 400 mm
- travel range: X= 500, Y= 420 mm, Z= 380 mm
- tool changing system: 32
- tool holder: ISO 40
- hydraulic clamb
- measurement tool
B0xatkbj0d
- weight: ca. 6.000 kg
14
5 assige Micron HSM 600 U
laser meting
3d taster
erowa opname
pallets
gereedschappen
heidenhain i TNC 530
Cj3wkn98
wisselaar 30 gereedschappen
nevel afzuiging
erowa robot PX
x 600 mm
y 600 mm
z 500 mm
spindel 42000 omw.
koeling door de spindel
spindel koeler
HSK E 40 opname
ijlgang 40 mtr
8
aschinen-Details
Lagernummer 1105-02961
Maschinenart Bearbeitungszentrum - Universal
Fabrikat DECKEL MAHO DMG
Typ DMU 50 EVO linear 5-Achsen
Baujahr 2005
Steuerungsart CNC
Steuerung HEIDENHAIN 530
Lagerort FRANKREICH
Bg3eqvu8
Ursprungsland Deutschland
Lieferzeit AUF ANFRAGE
Frachtbasis EX WORK
Technische Details
x-Weg 500 mm
y-Weg 420 mm
z-Weg 380 mm
Steuerung HEIDENHAIN 530
Aufnahme HSK 63
Zusatzinformationen
Gesteuerter 2 AXIS NC-Rund-Schwenktisch,
Kühlmitteleinrichtung,
Vollkabine,
magazin 3...
2
Manufacturer: DMG
Machine model: DMU 50 eVo linear
Control: Siemens 840 D
Year of manufacture: 2005
Number of controlled axes: 5 - simultaneous
TECHNICAL DATA
Travels
Pv902
- X-axis: (mm) 500
- Y axis: (mm) 450
- Z axis: (mm) 400
- B axis 0 - 161.955
- C axis n x 360º
Spindle
- Spindle speed max.: (rpm) 18,000
Tool magazine
- Tool holder: HSK 63
- tool places: 30
Machine table
- swivel rotary table dia.: (mm) 500 x 380
- max. table load: (kg) approx. 200
EQUIPMENT FEATURES
- Drive cooling of...
15
- Number of axes : 5
MILLING SPINDLE
- Tool holder type : HSK40
- Spindle power : 7,3 [kW]
- Spindle speeds : 16.000 [rpm]
LINEAR AXES
- Travels on X/Y/Z axes : 550 x 400 x 415 [mm]
- Rapid traverses rates (X/Y/Z) : 70 [m/min]
- Cutting feed rates (X/Y/Z) : 1 - 20.000 [mm/min]
TOOL CHANGER
- Auto. Tool Changer type : Arm type
- Tool magazine capacity : 26
Pojx2
- Tool exchange time : 1,1 [sec]
PALLET CHANGER
- Pallet size : 600 x 425 [mm]
- Pallets number : 2
- Pallet exchange time : 3,4 [sec]
-...
x-travel 500 mm
y-travel 450 mm
z-travel 400 mm
control iTNC 530 Heidenhain
Main spindle:
turning speed range - main spindle 20 - 18.000 min/-1
power capacity - main spindel 35 / 25 kW
max. Torque 130 Nm
tool taper HSK-A63
swiveling-rotary-table:
table surface area 500 x 380 mm
max. table load 200 kg
Swivel range B: 0 - 108 °
rotation range C: 360 x 0,001 °
T-slots 5x 14 x 63 mm
tool magazin:
number of toolpositions 60 pos.
max. tool weight 6 kg
max. tool diameter 80 mm
max. tool-dia wit...
12
DMU 50 EVOLUTION
WORKING HOURS
POWER ON: 23730
Ehhopddeq
SPINDEL HOURS: 15972
18000 RPM
HSK63
HEIDENHEIN Itnc 530
Normal cooling, not trough spindle
5 axis
Documentation
WE ORGANIZE TRANSPORT AS WELL FOR OUR CUSTOMERS TO THE DESTINATION OF THEIR WORKSHOP OR WAREHOUSE
10
3 assig cnc en 2 assig manueel
bouwjaar 1998
Yirkg
x,y,z 500 x 400 x 400 mm
motor 7 kw
20- 4500 omwentelingen
heidenhain tnc 310 besturing
eventueel met een EZ-CAM mill licentie ( 1495 euro meerkosten)
voor extern programmeren
zie : ww.ezcam.eu
incl. machineklem en gereedschappen
kan onder stroom worden bezichtigd
9
x-travel 500 mm
y-travel 600 mm
z-travel 460 mm
Control Heidenhein iTNC 530
main spindle:
max. turning speeds 10000 min/-1
Gzhsvd37
rotary table:
table diameter 400 mm
max. table load 600 kg
Number of T-slots 8 Stk.
width of T-slots 12 mm
T-slot spacing 45 °
tool changer:
tool taper BT 40
number of tool places 24 Pos.
max. tool diameter 80 mm
max. tool length 300 mm
max. tool weight 7 kg
change-time tool to tool 2,8 sec
feeds:
rapid traverse ( x / y / z ) 40 / 40 / 40 m/min
Overall siz...
4
x-travel 1000 mm
y-travel 550 mm
z-travel 500 mm
control Siemens828D
rapid speed 36/36/30 m/min
feed speeds 24000 mm/min
table surface area 1100 x 502 mm
turning speed range 12000 U/min
no. of tools in the magazine 24 Stück
tool taper SK 40
total power requirement 18,5 kW
weight of the machine ca. 6,5 t
dimensions of the machine ca. m
- Commissioning: January 2017!
- with Siemens828D including Shopmill
- Flat top chip conveyor
Ihkpup2
- Spindle with 12,000 rpm, SK 40
- Internal coolant sup...
4
DMU 50 eVolution
Heidenhain TNC 426
Renishaw TSA measuring arm
30.000 rpm
HSK 50
Numerous tool holders are additionally available for the machine
Pxmvh
10
x-travel 160 mm
y-travel 200 mm
z-travel 90 mm
Control HSC 6000
A-axis +- 25 °
b-axis +- 180 °
tool change unit 14-fach
turning speeds 5000-50000 U/min
tool taper HSK 25 E
Bnzfaoz
total power requirement kW
weight of the machine ca. 550 kg
dimensions of the machine ca. 1,9x1,5x1,8 m
WISSNER Gamma 202 Dental 5D Economic
Portal stand construction
5D path control HSC 6000
1 milling spindle HFS 301 quick change
(5,000 - 50,000 rpm; 3000 watts; HSK 25 E)
Tool length scanning
large control pane...
1
NEW MACHINE // NEW MACHINE
control: HEIDENHAIN TNC 640
X-axis: 450mm
Y-axis: 460mm
U927z78
Z-axis: 500mm
table size: Ø 320mm (A-axis: +30°/-120° / C-axis: 360°)
Spindle speed: 12.000 rpm (oil cooled - MQL) - SK 40
IKZ - cooling through the spindle (20bar)
Max. Spindle motor power: 14kW
Rapid traverse: 30m/min
Tool changer: 30 tools
Hinged belt - chip conveyor
2
SHORT DELIVERY TIME
Viewing exclusively in our showroom in Neunburg v. Wald.
The DMG DMU 50 eVo linear
5-axis simultaneous machining centre
HIGHLIGHTS:
CONTROL: Siemens 840D
TECHNICAL DATA
- YEAR: 2005
- HSK 63
- 18.000 rpm
- NC-swivel rotary table Ø 500 x 380 mm / approx. 200 kg
- 30-fold tool changer
Bxsotbj3qi
- Heidenhain probe TS649
- handwheel
- 5 axes
- drive cooling of B- and C-axis
- Cooling unit for spindle and drives
- Optional minimum quantity lubrication
- Chip conveyor
- Hydraulic...
5
x-travel:500 mm
y-travel:350 mm
z-travel:510 mm
control:Mori Seiki MSX 711 (Fanuc 31i) MAPPS IV
Spindle power:22/11 kW
Spindle RPM:20000 1/min
Feed x/y/z:50 / 50 / 40 m/min
rapid travel x/y/z:50 / 50 / 40 m/min
c-axis:360.000 x 0,001°
b-axis:+160.000/ -180.000x0,001°
RPM B-axis:150 1/min
table diameter:350 mm
workpiece height max.:300 mm
max. workpiece diameter:350 mm
workpiece weight:100 kg
tool magazin::61 HSK-A 63
total power requirement:41 kW
weight of the machine ca.:9,4 t
dimensions o...
4
The machine is in a good technical condition, after prior consultation possibility of testing. 640 spindle operating hours, Heidenhain iTNC 530, 12000 rpm, ISO40, 48-fold magazine, Heidenhain measuring probe
Pxdrv
10
x-travel 850 mm
y-travel 700 mm
B0xik9cnac
z-travel 500 mm
control Siemens
weight of the machine ca. 9500 t
dimensions of the machine ca. L 3,15 x B 2,4 x H 2,9 m
In our estimation, the machine is in very good condition
and can be viewed live by appointment.
Equipment:
- Chip conveyor Knoll 850 K-1
- Knoll AE 1058 coolant system
- Fastems FPC-750 pallet automation
*** Accessories, tools and clamping devices shown are only included in the
scope of delivery
if this is noted in the additiona...
8
Used 5-axis machining center from DMG
DMG DMU 50 eco (3+2)
Control SIEMENS
year of construction 2011
traverse paths:
X 500 mm
Y 450 mm
Z 400 mm
2tsdyu
B -5/+110°
C 360°
spindle speed - 8.000 rpm.
CNC - swivel rotary table 630 mm x 500 mm
Tool changer 16 pockets
SK 40 interface
Chip conveyor
Machine was completely measured and is in
in a very good condition.
1
Year of manufacture 2019
Operating hours: 4100
B0l9xgzzsb
Control: Siemens
HSK-A63 tool holders
2x 48 places tools
2 spindle
automatic loader
X1 400
Y1 200
Z1 360
X2 900
Y2 200
Z2 360
Machine still in use
5
Heidenhain control iTNC 530
TRAVELS X500 Y450 Z400
NC Swivel rotary table
Ocd3x
Tool changer with 60 positions
HSK63
SPINDLE 18000 RPM
Through spindle coolant
Tool measuring
Chip conveyor
x-travel 530 mm
Oskx2
y-travel 450 mm
z-travel 450 mm
control iTNC 530 HEIDENHAIN
Table dimensions Ø 280 mm
max. table load 200 kg
spindle taper SK 40
spindle turning speed range 12.000 U/min
feed range 15.000 mm/min
rapid traverse 22 m/min
tool change unit 30 Pos.
voltage 400 V
total power requirement 44 kVA
weight of the machine ca. 6,5 t
dimensions of the machine ca. 1,65 x 3,30 x 1,65 m
coolant 1,80 x 0,90 x 1,35 m
chip conveyor 2,70 x 0,60 x 1,20 m
- Factory No.: 107.32.99.204
- Program...
9
x-way: 550 mm
y-way: 400 mm
z-way: 425 mm
table surface: 660 x 400 mm
dimensions: 3000 x 2000 x 2500 mm
Bxojkkqazc
11
1 piece CNC-machining center 5 axes simultaneous
Type DMU 50 eVo linear
with Heidenhain control iTNC 530
Make: DMG
Year of manufacture: 2010
Technical data
Working range:
- Travels
X-axis 500 mm
Y-axis 450 mm
Z-axis 400 mm
- Speed range 20 - 18,000 rpm
- motor spindle (40/100% ED) 35/25 kW
- NC-round table diameter 500x380 mm
- tilt rotary table max. load 200 kg
- spindle cone SK 40
tool changer:
Pwahb
- magazine positions 30
space requirement LxWxH approx. 3,9 x 5,5 x 2,70 m
Machin...
11
Universal milling machine
Manufacturer Hermle
Type UWF 721
year of manufacture 1988
Control Heidenhain TNC 155
travel X/Y/Z 500/360/400mm
clamping area 800 x 390mm
Pivoting of the head 360
quill stroke 80mm
4 gear steps
20 - 270, 271 - 640, 641 - 1685, 1686 - 4000rpm
Machine comes from a public institution, was almost never really used, 12.093 switch-on hours.
Bwtzqx3y
Machine is in a TOP condition !!!
x-travel:400 mm
y-travel:510 mm
z-travel:510 mm
Bkse9ftc3k
rotary table tiltable:A-Achse +30 ~ -120°, C-Achse: 360°, Min. Index-Inkrement 0.001°
table-size:350 mm
table load:200 kg
spindle speeds:15000 1/min.
spindle drive:10/17 kw
spindle taper:40 BBT
rapid traverse in x-y-z axis:36/36/30 m/min
Tool changer:30 fach
weight of the machine ca.:7 t
Machine size (LxWxH):2,150×3,104×3,121 mm
high speed directl spindle motor:15000 1/min
CNC controller:HEIDENHAIN TNC640 (15" LCD) (5-X simultan)
chip ...
3
CTV 400 VERTICHAL LATHE
Msmi8faf
1
control: RMS6
Axes
X-axis travel mm: 500
Y-axis travel mm: 455
Z-axis travel mm: 240
Spindle HSK-40
spindle speed rpm: 42.000
G7ztsg9h
tool changer places: 21 // against surcharge :42
Equipment
Thermal package
Linear path measuring system
3D probe
Remote maintenance Team Viewer
Compressed air through the spindle
Handheld control unit
Spindle compensation
Tool measurement laser
Milling tool cleaning
Minimum quantity lubrication
Space requirement machine:
Length mm: 2710
width mm: 2350
hei...
9
x-way: 550 mm
y-way: 300 mm
z-travel: 425 mm
Dyifa3
speed: 20 - 6000 rpm
throat: 427 mm
table area: 950 x 660 mm
weight: 7500 kg
6
Nr. 4100:
1 gebr. Universal Stangen - Bearbeitungszentrum 5 - Achsen
Fabr. DECKEL MAHO
Typ DMC 60 S (Typ 1136)
Bauj. 2003
Steuerung Sinumerik 840 D - Powerline Shopmill
Arb.-Ber.: 760 x 460 x 560 mm
Antriebsleistung: 19/28 kW
Zubehoer:
U7xwc7zq0
NC Schwenkfraeskopf (B-Achse) -120/+30°
60-fach Werkzeugmagazin mit Kegelreinigung
NC Rundachse (A-Achse) mit Spannzangenfutter Spanntop 65
Reitstock, hydraulisch absenkbar
NC Stangenlader 1100 mm
Werkstueckabholeinrichtung mit Austragsband
Produkt...
5
Universal tool milling machine Hermle UWF 721H
Year of manufacture: 1994
Control: Heidenhain TNC 425
Technical data:
- spindle
speed: 20-4.500min
drive power: 6 KW
tool holder: SK 40
number of magazine places: 32
traverse paths:
Dakoxesta
X-axis: 500mm
Y-axis: 360mm
Z-axis: 400mm
table size: 800x390mm
accessories:
- 3D - Probe TS 120
6
Dear Sir or Madam,
we are pleased to be able to offer you our Okuma MacTurn 350W. The machine is in our warehouse.
0ym7g9lt
In the further course you will find technical details about the machine.
We look forward to your inquiry.
Datasheet / Datasheet:
Max. Turning length: [mm] 1,500
Turning diameter: [mm] 380
Max. Turning Ø over bed: [mm] 530
Travels:
X-axis: [mm] 505
Y-axis: [+/- mm]: 190 (+ / - 95 mm)
Z-axis: [mm]: 1,655
W-axis: [mm]: 1,575 C-axis: 360,000 °
CNC spindle swiveling for mil...
7
CNC machining center make LEADWELL type TDC 450
Machine # LISIE0304 Year of construction 1995
technical data:
X-axis 450 mm
Y-axis 350 mm
Z-axis 250 mm
table clamping surface 660 x 350 mm
Speed range milling 10000 rpm.
tool holder BT 30
feed range 1 - 12000 mm/min.
rapid traverse longitudinal/cross/vertical 36 m/min.
Total power requirement 10 kW
dimensions approx. 1650 x 2250 x 2400 mm
weight approx. 2,0 t
with
Vuop2e
- Fanuc control Series O-M
used
SPECIAL PRICE !
6
Technical data:
Travels
X - path 500 mm
Y - travel 500 mm
Z - distance 380 mm
Psmxn
Table size 350 x 800 mm
Speed 50 - 2240 rpm
Machine dimensions approx. 1.8 x 1.8 x 1.7 m
10
Burgoberbach
8004 km
