Condition: excellent (used), Year of construction: 2013, 5-axis machining center (BAZ) Control: Heidenhain Travel paths: X 2000 mm, Y 600 mm, Z = H 800 mm, V 700 mm. Max. clamping weight (rotary table): 1200 kg Nedpfsyaba Djx Aahjkt Max. spindle speed: 18,000 rpm

Condition: excellent (used), Year of construction: 2016, 5-axis simultaneous machining center Year of manufacture: 2016 Röders proprietary control 1.) Working area: 1000 x 1050 x 600 mm Nkedsyaa T Njpfx Aahet 2.) Max. workpiece weight: 800 kg 3.) Milling spindle: 32,000 rpm 3.) Tool changer: 30 positions 4.) Guideway system: Hydrostatic on all axes 5.) Drive: Linear motors 6.) 5-axis machine, swivel range A-axis ±115°, rotary C-axis 360° 7.) Control: Röders RMS6 5.52 8.) Machine weight approx. 21,000 kg 9.) Space requirement: 3500 x 5500 x 3600 mm with dust extraction

Condition: used, Year of construction: 2006, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 Nm Nedpfoyackdex Aahokt tool taper HSK-A 63 swivellable B: +30° / -120 ° table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg rotatable C: 360 ° number of toolpositions 2x16 pos. tool taper HSK-A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool weight 8,0 kg max. tool length 315 mm feed speeds max. 30.000 mm/min rapid traverse 30 m/min total power requirement 48 kVA weight of the machine ca. 14,0 t dimensions of the machine ca. 4,5 x 4,0 x 2,6 m 5 Axis CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 monoBLOCK - NC-Rotary Table (C-Achse) integrated in rigid-table - Swivel-Milling-Head (B-Achse)

Condition: used, Year of construction: 2007, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 Nm tool taper HSK-A 63 swivellable B: +30° / -120 ° table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg rotatable C: 360 ° number of toolpositions 2x16 pos. tool taper HSK-A 63 Nodpfx Aeyaci Toahokt max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool weight 8,0 kg max. tool length 315 mm feed speeds max. 30.000 mm/min rapid traverse 30 m/min total power requirement 48 kVA weight of the machine ca. 14,0 t dimensions of the machine ca. 4,5 x 4,0 x 2,6 m 5 Axis CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 monoBLOCK - NC-Rotary Table (C-Achse) integrated in rigid-table - Swivel-Milling-Head (B-Achse)

Condition: used, Year of construction: 2004, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, total height: 4,375 mm, total length: 12,300 mm, total width: 11,200 mm, table width: 1,400 mm, table length: 1,600 mm, table load: 3,500 kg, Equipment: documentation/manual, 5-axis CNC Universal Machining centre, simultaneous Control: Heidenhain iTNC 530 Table size: 1600x1400 mm Table load: 3500 kg Number of pallets: 2 x Maximum workpiece diameterxheight: 1950x1100 mm Movement X-axis: 1800 mm Movement Y-axis: 2000 mm Movement Z-axis: 1100 mm C-Axis table rotation: 360 ° B-Axis travel: -7 / 187 ° Spindle Speed: 18000 1/min Spindle taper: HSK-A63 Spindle motor: 28/19 kW Nkedpfx Aox Tulnjahjt Magazin capacity: 120 Required floor space: 11200x12300 mm Height: 4375 mm Weight: 58000 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, Year of construction: 2005, x-travel 500 mm y-travel 450 mm z-travel 400 mm control Heidenhain iTNC 530 c-axis 360 b-axis -5/+110 ° turning speeds 20- 10000 U/min power capacity - milling spindle 13 kW tool taper SK 40 no. of workpieces in the magazine 16 Stück rapid traverse 24 m/min table surface area 630 x 500 mm table load 200 kg weight of the machine ca. 4,0 t dimensions 2,3x 3,2 x 2,75 m Nodpfx Aajw Eyg Ijhekt 3 + 2 axis Milling Center - Turn-/swiveling table full programmable - electr. hand wheel - new spindel in 2015

Condition: used, Year of construction: 1996, x-travel 850 mm y-travel 630 mm z-travel 500 mm Nedpfx Aouxfz Aoahekt Control Heidenhain total power requirement 16 kW dimensions of the machine ca. 5 x 4,2 m

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, DECKEL MAHO DMU 70 VL – Technical Specifications General Machine type: Vertical CNC machining center Year of manufacture: approx. 1999 Control: Heidenhain MillPlus Axes: 3 axes (X / Y / Z), optional expansions Machine weight: approx. 13,000 kg Travel distances X-axis: 2,050 mm Y-axis: 520 mm Z-axis: 520 mm Spindle Tool holder: SK 40 Max. spindle speed: 12,000 rpm Spindle power: approx. 30 – 36 kW Spindle drive: Motor spindle Nksdoyazd Nspfx Aahst Table Table size: approx. 700 × 500 mm Max. table load: approx. 350 kg T-slots: approx. 7 × 14 mm Feeds Working feed: up to 10,000 mm/min Rapid traverse X / Y / Z: approx. 30 – 40 m/min Tool magazine Magazine capacity: 32 tools Max. tool diameter: approx. 105 mm Max. tool length: approx. 315 mm Max. tool weight: approx. 6 kg Power / Installation Total connected load: approx. 30 – 40 kVA Machine dimensions (L × W × H): approx. 5,600 × 3,300 × 2,800 mm ICS (internal coolant supply) and chip conveyor

Condition: ready for operation (used), Year of construction: 1999, Machine Model: DMU 50 eVolution (5-Axis Machining Center) Nksdpfoyay Rzex Aahot Control: Heidenhain MillPlus (MillPlus Control) Axes: 5 (X, Y, Z, B, C) Machine Weight: approx. 5,000 – 5,100 kg Installation Dimensions (L × W × H): approx. 2,683 × 5,353 × 2,470 mm Total Power Requirement: ~ 38 – 40 kVA Working Area & Axes X-Axis Travel: 500 mm Y-Axis Travel: 420 mm Z-Axis Travel: 380 mm B-Axis (Swivel Range): ±180° C-Axis (Rotary Range): 360° Spindle Data Max. Speed: 20 – 18,000 rpm (infinitely variable) Spindle Drive: approx. 35 kW (40% duty cycle) / 25 kW (100% duty cycle) Torque: approx. 130 Nm (40% duty cycle) / 87 Nm (100% duty cycle) Tool Interface: SK 40 (standard) – HSK optionally available for certain models Table & Workpiece Table Size: ø 500 × 380 mm Max. Table Load: 200 kg T-Slots: 7 × 14 mm (H7) ⚙️ Tool Magazine Magazine Capacity: 32 tools Max. Tool Length: ~ 200 mm (depending on magazine configuration) Max. Tool Weight: ~ 6 kg Feeds / Rapid Traverse Working Feedrate: up to 20,000 mm/min Rapid Traverse X/Y/Z: up to 50 m/min

Condition: good (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, DMG MORI DMU 75 monoBLOCK Year of manufacture: 2014 Nodpeyay Iyefx Aahskt Control system Siemens SINUMERIK 840D sl ShopMill Working area / Axes Travel X / Y / Z: 750 / 650 / 560 mm 5-axis simultaneous machining NC swivel rotary table Table / Workpiece Table size: Ø 650 mm Max. table load: 600 kg Max. workpiece dimensions: Ø 840 mm, height 500 mm Spindle Tool holder: SK40 Max. speed: 18,000 rpm Feeds / Dynamics Rapid traverse X/Y/Z: 40 m/min Feed rate: up to 40,000 mm/min Acceleration: 6 m/s² Tool changer Chain magazine: 60 tool positions Max. tool weight: 8 kg Max. tool length: 315 mm Max. tool diameter: Ø 80 mm (adjacent positions occupied) Ø 160 mm (adjacent positions free) Tool change time (chip-to-chip): approx. 4.9 s Chip removal Chip conveyor The machine comes with a newly packaged window. 3D Quickset included.

Condition: good (used), Year of construction: 2019, functionality: fully functional, travel distance X-axis: 720 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, controller model: Siemens 840D, 5-Axis Center WEMAS VZG 72 - 5A *Full simultaneous 5-axis version* Working area: X axis: 720 mm Y axis: 600 mm Z axis: 520 mm Table rotation C axis: 360° Table tilting B axis: -50° / +110° Distance Spindle nose - table: 150 - 670 mm Njdpfxoyazkve Aahekt Table plate pitch circle diameter: Ø 720 mm Clamping area of the table: Ø 720 x 540 mm Table load (dynamic): 300 kg Table load (positioning): 500 kg Table T-slots: 5 x 14 x 100 mm Centering bore: Ø 50 mm Machine accuracy VDI / DGQ 3441* Positioning accuracy: 0.006 mm ± Axis resolution: 0.001 mm *measured at 20°C +/-1°C constant ambient temperature Main spindle I: Main drive: AC motor direct drive Drive power Control: Siemens 840D Year of manufacture: 2019 Further information can be found in the attachment. NOTE: We offer flexible financing solutions for all machines as well as a professional relocation service. Dismantling, transport, and qualified installation – all from a single source. Billing according to individual terms and duration. Contact us for your personal offer.

Year of construction: 2004, condition: excellent (used), TECHNICAL DATA Travel X 760 mm travel Y 510 mm travel Z 610 mm table clamping surface 1020 x 510 mm T-slots / table 5 x 18 mm x 100 mm distance spindle to table min./max. 150/762 mm Spindle mounting steep taper DIN 69871 ISO 40 spindle speeds 10 - 10'000 rpm Drive power (30 min/const. ED) 11 kW Torque max. 236 Nm Power constant from 500 rpm Coolant tank 190 l Ball bearing linear guide in X,Y,Z axes Eilang X / Y / Z 30 / 30 / 20 feeds programmable 3,0 - 7600 mm/min positioning accuracy +/- 0,01 mm repeatability +/- 0,005 mm milling feed rate 3,0 - 11400 mm/min table load 1000 kg Automatic tool changer (double arm) 24 stations Max. Tool diameter 80 mm Max. tool length Tool length 300 mm Max. Tool weight 7 kg Machine weight 4700 kg Space requirement L x W x H (footprint) 3870 x 4170 x 2775 mmINCL. - Coolant system - Coolant spray gun - Chip splash guard cabin - Flushing system to support chip disposal - Machine light - set of machine shoes - rigid thread cutting - spiral conveyor in the chip room - Pocket milling with islands - Electronic handwheel - ULTIMAX 4 control Nkedpfx Aol Tpmdoahet - 2 VGA color screens (text + graphics) - 2 software units (1 x plain text dialog programming + 1 x for ISO code programming) via interface RS-232 C / V24 access for CAD / CAM or external programming station - Pentium technology, 1.6 GB hard disk, 64 MB RAM, parallel and serial data interfaces, DOS compatible 3.5 '' 1.44 MB drive. System internal self-diagnosis, DOS directory structure, software version 2.xx Servo technology DUAL DSP 40MHz

Condition: good (used), Year of construction: 2008, Ref. -No.: 10621 Manufacturer: PAMA Type: Speedmat 3/TR16 Year of construction: 2008 Type of control: CNC Control: SIEMENS SINUMERIK 840 D PL Storage location: Halberstadt Country of origin: Italy X-Travel: 3500 mm Y-Travel: 2500 mm Z-Travel: 2200 mm W-Axis: 800 mm Bore Spindle Diameter: 160 mm Table Load: 12000 kg Table surface: 1600 x 2000 mm Tool Taper: ISO 50 BIG PLUS Turning Speeds: 3500 RPM Max. Torque: 2.765 Nm Rapid Travel X/Y/Z: 25000 mm / min Drive Capacity - Spindle Motor: 46 kW Internal cooling: 15 / 45 bar External cooling: 50 / 4 bar Spindle speed gear stage 1: 2.120 1 / min Spindle speed gear stage 2: 2.765 1 / min Further information: Automatic tool changer SK50 DIN 69871, 80 positions. Automatic angle milling head TS 35 with 360 positions, speed 2,000 rpm and torque 2,000 Nm. Automatic universal milling head TU25C (2-axis), speed 3,000 rpm and torque 800 Nm. Automatic accessory changer, 2+1 units. Touch probe (Renishaw). The machine can be inspected under power. Nodpfx Aajyagikshskt

Condition: excellent (used), Year of construction: 2019, Delivery at the beginning of June 2026!!! Control: CELOS with Heidenhain TNC 640 Milling head: Universal milling head with controlled A-axis HSK63A Spindle options: Spindle tool holder HSK-A 63 Tool magazine: Tool magazine, wheel type, 63 positions HSK63A Coolant / Chip removal: Through-spindle coolant system, 80 bar, frequency controlled; oil/emulsion mist extraction unit; cooling device with air blast Measuring / Monitoring: Heidenhain infrared probe SK 40, 3D quickSET; MPC Machine Protection Control Further options: Operating mode 4 Options for HEIDENHAIN control: Electronic handwheel Documentation: 1 set documentation in German; electrical schematic in German Nkodpfxex Uqyko Aahst Display language: German

Condition: good (used), Year of construction: 2003, functionality: fully functional, 1 CNC Universal Machining Center DECKEL MAHO - DMU 50 T Year of manufacture: 2003 X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 mm Control: Siemens 810 D Spindle speed range: 20 - 9,000 rpm Main spindle drive power: 9 / 13 kW Tool holder: ISO 40 DIN 69871 Table dimensions: 700 x 500 mm Swiveling B: 105° (-10°/+95°) manual Rotating: 360° manual Max. table load: 200 kg Number of T-slots: 7 T-slot spacing: 63 mm T-slot width: 14H7 mm Centering bore: 30H7 mm Number of tool stations: 16 positions Tool holder: ISO 40 DIN 69871 Max. tool length: 290 mm Nkodjx Auvvjpfx Aahet Max. tool weight: 6.0 kg Max. total tool weight: 50 kg Feed rate max.: 10,000 mm/min Rapid traverse: 12 m/min Minimum input unit: 0.01 mm Total power consumption: 17 kW Machine weight approx.: 3.2 t Space requirement approx.: 4.0 x 4.0 x 2.5 m - 5 axes (3 + 2) - Swivel rotary table with angle display (axes B+C manually by handwheel) Available immediately. Including tool holders and zero point clamping system.

Condition: excellent (used), Year of construction: 1999, operating hours: 37,300 h, functionality: fully functional, X-travel 500 mm Y-travel 400 mm Z-travel 400 mm Control: Heidenhain TNC Speed range - main spindle 20 - 9,000 rpm Drive power - main spindle 9 / 13 kW Table diameter 700 x 500 mm Swiveling B: 105° (-10°/+95°) manually Rotatable 360° manually Max. table load 200 kg Number of T-slots: 7 Centering hole 30H7 mm Number of tool positions: 16 positions Tool holder ISO 40 DIN 69871 Max. tool length 290 mm Max. tool weight 6.0 kg Max. total weight 50 kg Max. feed rate 10,000 mm/min Total power requirement 17 kW Machine weight approx. 3.2 t Space requirement approx. 4.0 x 4.0 x 2.5 m Nkodpswm Nqrofx Aahet

Condition: used, Year of construction: 2001, x-travel 2.000 mm y-travel 1.200 mm z-travel 1.400 mm Control Heidenhain 426 spindle tunring speed 3.000 U/min tool taper SK 50 number of tool places 20 Pos. In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features & Accessories: - Controlled rotary table - Milling head with stepless positioning along the B-axis - Automatic tool changer with 20 magazine positions - 2x chip conveyors in longitudinal direction, ejection on the left - Coolant system - Fully enclosed - Various tools Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Nksdpexu Nxvofx Aahst Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: new, FACTORY-NEW MACHINING CENTER Nsdshy Aunjpfx Aahskt HEIDENHAIN TNC 640 CNC control HEIDENHAIN package (motors, measuring systems, and handwheel) X-axis: 3,000 mm Z-axis: 2,000 mm Y-axis (cross beam): 1,300 mm V-axis (column): 1,000 mm Rotary table (C-axis): 2,000 x 2,000 mm Max. workpiece weight: 15,000 kg Automatic universal swivel head 1° x 1° Spindle taper: SK50 DIN 69871/A Spindle speed: 6,000 rpm (oil cooled) Max. spindle motor power: 53 kW ICS – internal coolant supply – 36 bar Rapid traverse X, Y, V & Z: 30,000 mm/min Positioning accuracy: ± 0.015 mm Repeatability: ± 0.010 mm Chain-type tool changer: 60 positions Double hinged belt chip conveyor (longitudinal) Perimetric enclosure (top open) Only inquiries from Germany will receive a response.

Condition: good (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 75 m/min, rapid traverse Z-axis: 75 m/min, nominal power (apparent): 17 kVA, total height: 2,300 mm, total length: 1,500 mm, total width: 2,600 mm, overall weight: 3,400 kg, spindle speed (max.): 30,000 rpm, spindle nose: HSK40, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, CNC machining center CHIRON FZ08 KS Magnum High Speed Plus (HSP) TECHNICAL CHARACTERISTICS: Year of manufacturing: 2007 CNC control : FANUC 18i-MB5 Number of axes : 7 Stroke X axis : 450 [mm] Stroke Y axis : 270 [mm] Stroke Z axis : 310 [mm] Traversing feeds X, Y and Z axes : 75000 [mm/min] Max. bar diameter in turning spindle : 32 [mm] Main spindle max. speed : 8000 [rpm] Main spindle max. power : 12 [kW] Angular A axis stroke : 360 [°] A axis indexing precision : 0.001 [°] B axis swivelling stroke : -20° / +115 [°] B axis indexing precision : 0.001 [°] Spindle type : HSK40 Nkodpfx Aasx U U Hbjhot Max. spindle speed : 30000 [rpm] Tool changer magazin number of stations : 40 Part turnaround by robot (6th side machining) : Yes RS232 Interface : Yes Total power required : 17 [kVA] Supply voltage : 400 [V] Dimensions : 1500 x 2600 x 2300 [mm] Weight : 3400 [Kg] More information available upon request.

Condition: new, Year of construction: 2024, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,400 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, New machine HDC3000 with 6 axes • Travel ranges: X=3000 mm, Y=1500 mm, Z=1400 mm • Heidenhain iTNC 640 with handwheel • NC rotary table for 5-sided machining 1250 mm x 1600 mm • 2-axis NC universal drilling and milling head, fully simultaneous and positioning operation • Spindle 10,000 rpm HSK100, S1=220 Nm spindle torque • Tool change system HSK100 / 60 stations – 800 mm tool length • Chip conveyor • Optimized for 5-sided machining including deep hole drilling • Coolant supply system • Internal/external air blow-off device • ICS 60 bar for deep hole machining Nkjdpjx U Sm Eefx Aahst • Fully enclosed • Large interference circle 2300 mm • Including mounts • Including wash gun • Including warranty • Short delivery time, subject to prior sale

Condition: good (used), Year of construction: 2010, operating hours: 9,000 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,250 mm, Travel distances X=2000 mm, Y=1500 mm, Z=1250 mm (see image 3 for the machine with clamping fixture for serial parts) - Siemens 840 DsL control system - NC rotary table for 4-sided machining 1250 mm x 1250 mm - Horizontal spindle HSK100 - Spindle 2500 rpm HSK 100, 2200 Nm spindle torque - Approx. 9500 spindle hours - Tool change system HSK 100 / 40 positions - Chip conveyor - Coolant supply - Internal/external air blast unit - Through-spindle coolant (IKZ) 60 bar for deep hole drilling - Full enclosure - Large interference contour 2300 mm - 2-station pallet changer - Short delivery time, subject to prior sale - Year of manufacture 2010 Nedpsx U Smrsfx Aahekt

Condition: reconditioned (used), Year of construction: 2010, • Traveling distances X=3100 mm, Y=1950 mm, Z=1390 mm • Heidenhain iTNC 530 with handwheel HR 410 • Machine table for multi side working 3000 mm x 1600 mm • 2-axis NC-universal milling head, for simultaneous and positioning working • Spindel 10.000 U/min HSK 100, 130 Nm Spindle torque • Tool change system HSK 100 / 40 places for 750 mm long tools • Chip conveyor (screw type) in X-axis, for transport into • Chip conveyor scraper belt type (traverse conveyor), Fabr. Knoll • Coolant container 900 l, Fabr. Knoll • Outside air at spindle • IKZ 60 bar for deep hole drilling function • Covering with safety glass pane, open at the top for loading by crane • 2 part sliding doors at the operator side • 2 part sliding doors at the front side, for easy loading • Radio-controlled measuring probe RMP 60 • incl. washing gun • incl. podiums at the front side and operator side • complete factory overhauled and painted new • short time delivery after arrangement • used machine • Y-axis ball screw in September 2021 incl. bearings renewed • X-axis new linear guiding system, July 2023 changed, renewed • Spindle overhauled at Mai 2023 (clamping system new, clamping cartridge new, rotation unit new, general tests) (at 23105 spindle hours)) • can be visited under power at 72793 Pfullingen • optional fixators • optional installation at customers plant • optional transport Nsdpfx Ajx U Sfneahskt • 23122 spindle hours in total • 53991 machine hours in total • Year of construction 2010 Subject to prior sale

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 80 m/min, rapid traverse Y-axis: 80 m/min, rapid traverse Z-axis: 50 m/min, controller manufacturer: Heidenhain, controller model: iTNC530, table load: 400 kg, spindle speed (max.): 24,000 rpm, operating hours of spindle: 17,917 h, number of slots in tool magazine: 60, Equipment: rotational speed infinitely variable, Machine Description: - Universal 5-axis milling machine with linear drives in the X and Y axes, achieving 80 m/min traverse speed - Spindle and machine geometry in excellent condition - Regularly serviced - Last spindle replacement: 08/2020 / New control panel installed: 09/2025 - Current machine hours: Power ON: 58,985 h / Spindle ON: 17,917 h - Machine location: Lower Austria (near Vienna) Travel paths: X-axis (longitudinal): 600 mm Y-axis (cross): 500 mm Z-axis (vertical): 500 mm Clamping Table / Work Area: Integrated NC rotary table: 600 x 500 mm Table load capacity: 400 kg CNC Control: Heidenhain iTNC530 Spindle: Speed range: 24,000 rpm Tool interface: HSK63 Coolant System and Chip Disposal: External coolant with 3 nozzles: 4 bar Internal coolant: 40 bar Paper band filter Chip conveyor, scraper belt design Automatic Tool Changer: Tool interface: HSK63 Number of tool pockets: 60 Dimensions and Weight: Machine: Length 2,900 x Width 2,611 x Height 2,865 mm Weight: approx. 9,800 kg Nodpfx Aasya U Ibohjkt Additional Equipment and Accessories: › Heidenhain TS 649 probe › Heidenhain handwheel › Blum laser for tool measurement on the table › Chip flushing gun › 3D Quick Set › ATC cycle package › Operating mode 4 › Integrated oil mist extraction › Operating manual / documentation › Dynamics package for linear drive, 80 m/min, incl. active cooler

Condition: like new (used), Year of construction: 2023, functionality: fully functional, travel distance X-axis: 1,760 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 850 mm, Travel Paths X-axis: 1760 mm Y-axis: 600 mm Z-axis: 850 mm Vertical distance table – spindle nose: 0 – 820 mm Horizontal distance table – spindle nose: 180 – 1030 mm Spindle & Drives Spindle speed range: 30–12000 rpm Swivel head B-axis: interpolating B-axis travel range: -100 to 100 Max. torque at 40% duty cycle: 191.0 Nm Nsdpfx Aaeydmprjhokt Max. torque at 100% duty cycle: 127.0 Nm Max. power at 40% duty cycle: 40.0 kW Max. power at 100% duty cycle: 26.6 kW Rotary Table RTA 4-TF-630 Table diameter (vertical rotary axis): 630 mm Weight: 595 kg Tool Changer Tool holder: HSK A 63 Tool pockets: 42 Machine Dimensions Length / width / height: 6850 / 3450 / 3100 mm Weight: 19 t Accessories: – Documentation – Measuring probe

Condition: used, Year of construction: 2016, controller manufacturer: Heidenhain, controller model: TNC 640, _____ Description: Year of manuf. : 2016 Control : Heidenhain TNC 640 Speed : 12000 rpm Movement X/Y/Z : 400/350/350 mm Nkedpfx Aasyad A Ishot Spindle: Technology:Directdrive Speed:12.000 rpm Power (max.):13 kW Torque (max.):95 Nm Taper:SK40 NC-Swivelroundtable: B-Axis:-50°/+110° C-Axis:360° Clampingsurface:ø450 mm Tableloading (max.):200 kg In general: Toolmagazine:48 Stations Rapid travers in X/Y/Z:48 m/min Equipment/Accessory: Positionsensor:Direct Scales in X/Y/Z Chipmanagement:Chip conveyor Coolingmanagement:Internal cooling unit with filter and High-pressure, 30 bar Workpiecemeasurement:Touch probe, Heidenhain TS740 Toolmeasurement:Laser, Renishaw NC4 TX Setup operations:Electronic Handwheel Further Equipment:Spindlechiller Further Accessory:Misc. used Toolholder
