length: 710 mm
width: 710 mm
height: 450 mm
weight of the machine approx.: 314 kg
dimensions: 710 x 710 x 450 mm
T-slots according to DIN 650:
- horizontal: a=20mm; h=39mm; b=40mm; c=17mm
- vertical: a=20mm; h=39mm; b=40mm; c=17mm
Very good and clean used condition!
table length 645 ( 350 ) mm
table width 18,5 mm
table height 1045 mm
T-slots 40 x 18 x 8,0 mm
weight ~ 650 kg
- 2x pieces of robust clamping angles (T-shape)
- rear ribs
- 7x T-slots 40 x 18.0 x 8.0 mm per bracket
length 140 mm
width 140 mm
height 500 mm
weight of the machine ca. 0,1 t
clamping cube for machining centre , 4 pcs. available. price per piece
There is a socket of 300 x 200 x 120 mm, totaly hight 620 mm
length: 1000 mm
width: 800 mm
height: 630 mm
weight of the machine approx.: 1139 kg
Drill cube material made of cast steel.
The cube can be pivoted 90°.
T-slots according to DIN 650: a=28mm; h=52mm; b=49mm; c=20mm
- clamping surface vertical: LxW: 1000 x 400mm
- clamping surface horizontal: LxW: 1000 x 800mm
- Clamping cube for radial drilling machine
- plate surface well preserved
- inclination adjustment by hand crank with clamping lever
- angle display
- length approx. 710 mm
- width approx. 710 mm
- height approx. 630 mm
- Height inclined approx. 900 mm
- 6 pcs. T-grooves in table surface length 710 mm
- 3 T-slots in table side length 710 mm
- Center distance of T-slots in table surface 125 mm each
- center distance of the T-slots table side surface each ...
Dimensions tower: 400 x 400 x 800 mm
Dimensions base plate: 400 x 400 mm
clamping device: 2 x vice grefors 160
dimensions tower: 310 x 310 x 500 mm
dimensions base plate: 400 x 400 mm
Clamping device: 4-cornered tower welded
No. 1, 6, 28, 31, 34, 64
dimensions base plate: 400 x 400
Grid: 50 x 50 mm
plate width 1500 mm
plate depth 1500 mm
plate height 600 mm
weight / kg
Clamping cube - T-slot plates
1500 x 1500 x 600 mm
If you have not found the size you are looking for, you can also
send us an e-mail with the completed PDF form. With this form we can produce an
individual plate for you.
Parameters can be combined as desired.
Clamping plate : 1500 x 1500 x 600 mm
T-slots - width: 28mm
T-slot spacing: 140mm
Edge distance: 40mm
Number of grooves: 10
Casting quality: HT250
