Used center lathes 600-799mm turning diameter over bed for sale (96)

Condition: good (used), Year of construction: 2013, Centre height: 330 mm Centre distance: 2000 mm Spindle bore diameter: 103 mm Max. turning diameter over bed: 660 mm Max. turning diameter over carriage: 420 mm Spindle speed range: 36 – 1600 rpm (12 steps) Spindle nose: ISO 702/II No. 8 Longitudinal feed range: 0.063 – 2.52 mm/rev (65 steps) Cross feed range: 0.027 – 1.07 mm/rev (65 steps) Metric threads: 1 – 14 mm (22 steps) Inch threads: 28 – 2 TPI (25 steps) Gtslhcex Ux D Dodwzet Module threads: 0.5 – 7 mm (18 steps) Diametral pitch: 56 – 4 DP (24 steps) Motor power: 7.5 kW Weight: 3200 kg Dimensions: 3635 x 1050 x 1450 mm

Condition: used, Year of construction: 1971, functionality: fully functional, Center distance: 2.000 mm turning diameter: 1.200 mm turning diameter in the gap (with guide spindle pulled out to the right): approx. 1.460 max. width of the adjustable bed: 900 mm spindle bore: 85 mm turning rate: 14 - 710 U/min dimensions: 4.705 x 2.060 x 2.000 mm Gelhcdwox Tdkaozjtt equipment: 4 fold tool clamping system, HEIDENHAIN three-axis digital readout, Three jawchuck FORKARDT F400, Vibration damping elements

Condition: good (used), functionality: fully functional, spindle bore: 110 mm, turning length: 3,000 mm, total length: 6,000 mm, total width: 1,400 mm, total height: 2,000 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 9 rpm, overall weight: 8,000 kg, HEIDENREICH & HARBECK HAMBURG 540 lead and feed screw lathe - Center height over bed: 300 mm - Swing diameter over bed: 600 mm - Center height over carriage: approx. 200 mm - Swing diameter over carriage: approx. 400 mm - Includes tailstock, a Multifix tool holder, and a three-jaw chuck, diameter: 310 mm - Includes a two-axis digital readout by SONY and a steady rest, steady rest diameter: approx. 200 mm Gjlhcox Tz T Ssdwzstt Attention: The item must be collected, bindingly, between 18 and 26 February 2026 on a date to be agreed. FCA D-78087 Mönchweiler – loaded onto truck

Condition: used, Year of construction: 1970, total height: 1,400 mm, total length: 3,650 mm, total width: 1,300 mm, Empty weight: 2.200 kg - Year: 1970 - Documentation available: No - CE certificate present: No - Drive system: Conventional - Power [kW]: 9.0 - Centre height [mm]: 330 - Swing over bed [mm]: 660 - Distance between centres [mm]: 2000 - Spindle bore [mm]: 88 - Min. spindle speed [rpm]: 5.6 - Max. spindle speed [rpm]: 3200 - Transport dimensions: 3650mm x 1300mm x 1400mm (l x w x h) - Transport weight [kg]: 2200kg Gtslhjwxwd Recdwzot Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Year of construction: 2005, Ref. -No.: 10314 Manufacturer: PINACHO Type: S-90/ 310-155 Year of construction: 2005 Type of control: Konventionell Storage location: Halberstadt Country of origin: Spain Gjlhcdox Sw Dqowzjtt Bar passage: 90 mm Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Tip length: 3000 Cross Movement. (X-Axis): 365 mm Spindle Bore: 155 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm Jaw chuck diameter: 380 mm Turning Speed Range: 16 - 750 rpm Further information: - The lathe has two jaw chucks on the headstock - metric, Whitworth and inch trapezoidal threads can be turned - adjustable feeds for cross face and longitudinal face turning (0.05 to 1.5 mm/u)

Condition: new, The Sinus 330/1500 D is a top-tier Conventional Horizontal Lathe within the Engine Lathes category, renowned for its robust design and superior performance. Built on a solid one-piece cast machine bed, this lathe excels in heavy-duty tasks with a maximum turning diameter of 660 mm and a workpiece length capacity of 1,500 mm, making it ideal for machining large parts and flanges. The integrated removable bridge facilitates the machining of workpieces with diameters up to 1,035 mm, while features such as its manual multi-disc clutch, rapid traverse on two axes, and taper turning attachment enhance versatility and efficiency. Safety is prioritized with well-designed functions and overload protection for the feed shaft and leadscrew. As part of your operational setup, the Sinus 330/1500 D includes essential standard equipment like a reliable 3-axis position indicator, a high-quality 3-jaw chuck, and a comprehensive toolbox. With its precision, durability, and range of functionalities, this KNUTH lathe is the perfect choice for your machining needs. Order online today to elevate your machining capabilities with this exceptional Engine Lathe. Gtolhcdwjp Atuzozet

Condition: good (used), Year of construction: 2007, Manufacturer: Volz BMT Year of manufacture: 2007 Control: conventional with digital readout (DRO) Country of origin: Taiwan Swing diameter: 660 mm Max. turning length: 2000 mm Spindle bore: 85 mm Spindle mount: D1-8 Spindle motor: 7.5 kW Spindle speed: 17–1200 rpm with steady rest Gtsljx Uw S Hshcdwzot with digital readout (DRO) with thread cutting function

Condition: good (used), Code: 0242 Brand: MVM - ITALY Model: T 1500 - CE Standard Professional wood turning lathe with copying device for wood, plaster, composite materials and various - CE Standard Technical data: Single-phase motor 220 Volt - Kw 2,5 Copying device: the copying device is a unit mounted on the rear bench. It can reproduce weather with wooden samples or with metallic templates thanks to its modern view. It is a practical and manageable tool, it permits large time saving, in batch production or mass production, too. The feed is given by a confortable wheel rotation, the wheel is mounted on the machine fore side Distance between centres mm 1500 Height of centre mm 220 Gtelhcexykwkedwzet Tool support Spindle revolutions 4 speeds Spindle cone n° 2 Counter centre n° 3 Overall dimensions mm 2350 x 650 x 1200 h Weight kg 325

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 700 mm turning diameter over support: 350 mm turning length: 3000 mm center height measured in bed: 320 mm spindle bore of work spindle: 70 mm spindle speed max.: 10 - 1250 / 24 step U/min cross feed: 0,0256 ... 0,378 mm/U longitudinal feeds:: 0,064...1,025 mm/U tailstock quill adjustment:: 240 mm tailstock taper MT: MK5 total power requirement: 14,0 kW weight of the machine ca.: 5,0 t Gtslhcdju Trb Ajwzjt dimension machine xH: 5,1 x 1,8 x 1,6 m Travel Support: Support lengthwise=3000mm Support transverse=400mm Tool support=220mm Tool slide can be swiveled 90° right/left Equipment: digital path measuring device Heidenhain 4-fold tool holder machine lamp Coolant device with pump Accessories: 1x steady rest open 160mm and 1x steady rest closed 400mm 3-jaw chuck Ø 335 with soft jaws 18 sets of used, soft jaws *

Condition: used, total length: 4,500 mm, total width: 1,600 mm, total height: 1,500 mm, Empty weight: 5.000 kg Price: On request Gtolhcjx Ryv Tjdwzjt - Documentation available: No - CE certificate present: No - Serial number: 0440922 - Drive system: Conventional - Power [kW]: 18.5 - Centre height [mm]: 315 - Swing over bed [mm]: 630 - Carriage turning diameter [mm]: 400 - Distance between centres [mm]: 3000 - Bed width [mm]: 580 - Spindle bore [mm]: 82 - Min. spindle speed [rpm]: 9 - Max. spindle speed [rpm]: 1120 - Options: Three-jaw chuck, Four-jaw chuck - Transport dimensions: 4500mm x 1600mm x 1500mm (l x w x h) - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, spindle bore: 90 mm, turning diameter: 630 mm, turning diameter over bed slide: 630 mm, turning diameter over top slide: 380 mm, turning length: 2,000 mm, total length: 3,900 mm, total width: 1,420 mm, total height: 1,590 mm, overall weight: 3,400 kg, workpiece weight (max.): 1,500 kg, The universal lathe FAT TUR 630M/2M has been comprehensively rebuilt and modernized, has technical parameters in accordance with the technical and operational documentation DTR of a new machine, WOT technical acceptance conditions and the Polish Standard and also meets EU requirements. The machine is covered by a full 12-month warranty on spare parts and electrical components. Availability: on stock available, under power, technical inspection anytime after appointment Technical specifications: - distance between centers/turning length: 2000 mm - turning diameter over bed: 630 mm - turning diameter over support: 380 mm - spindle bore diameter: 90 mm - maximum workpiece weight between centers: 1500 kg - number of spindle speeds: 21 - range of rotational speeds (rpm): 18 - 1800 - range of feeds (mm/rev): longitudinal: 0.05 – 3,26 transverse: 0.25 – 1,63 - engine power: 15 kW - overall dimensions: total length: 3900 mm width: 1420 mm height: 1500 mm total weight: 3400 kg Gtelhcdsd Ead Tswzjt Standard equipment: tailstock, coolant pump, tool post, chuck cover Additional equipment available at extra charge: - 3- or 4-jaw chucks, various diameters and variants - Digital readout on 2 axes with assembly and calibration - Steady rest, 10-140 mm, with rollers - Steady rest, 10-180 mm, with rollers - Steady rest, 140-300 mm, with rollers - MULTIFIX quick change tool post

Condition: ready for operation (used), Year of construction: 2010, FAT TUR 630AMN x 2000 CNC Siemens 840D Yom: 2010 Turning diameter: 630 mm Turning diameter over top slide: 370 mm Turning length: 2,000 mm Gteljw Ecuuohcdwzst

Condition: new, Parallel lathe with clutch and display Fervi T085F10 with mechanical clutch, 3-axis display and semi-norton gear box. Possibility of 2000 and 3000 mm distance between centers. WITH MECHANICAL CLUTCH, 3-AXIS DISPLAY AND SEMI-NORTON GEAR BOX. EQUIPPED WITH JOYSTICK FOR ENTERING RAPID FEEDS. WITH SINGLE-BLOCK CAST IRON BASE. Center height 330 mm Max. diameter over bed 660 mm Max. diameter over carriage 420 mm Max. diameter over pocket 870 mm Tool height 32 mm Distance between centers 1000 mm Bar passage 105 mm Spindle attachment Camlock D1-8 Spindle speed (12) 36 - 1600 rpm Longitudinal feeds 0.063 - 2.52 mm/rev Cross feeds 0.027 - 1.07 mm/rev Metric threads (22) 1 - 14 mm Inch threads (26) 2 - 28 TPI Tailstock taper CM 5 Motor 400V 50 Hz 7.5 kW Coolant pump 400V 50 Hz 90 W Dimensions 3000 x 1400 x 1600 mm Net weight 3330 Kg Accessories included: Gtjlhcdsvbqt Sjwzst Self-centering chuck with 3 reversible jaws Ø320 mm Platform with 4 independent jaws Ø 400 mm Flange Ø 600 mm Mobile steady rest Fixed steady rest Rotating tailstock CM 5 Thread comparator Lead screw protection Turret protection Spindle protection Rear splash guard Quick change turret type C LED lamp Cooling system Electro-mechanical foot brake Quick locking tailstock carriage Oil bath gears Adjustable leveling feet

Condition: new, Year of construction: 2025, The CORMAK 660 x 2000 (CJ6266YB/2000) universal lathe is a versatile machine that provides exceptional precision in low-speed turning of various materials. It is ideal for internal and external machining, taper turning, polishing, threading (metric, inch, modular and DP), as well as drilling and broaching. The low speed of this lathe makes it an excellent choice for tasks requiring maximum accuracy and stability of work. Solid construction The lathe bed is made of high-quality cast iron, which effectively dampens vibrations, which is crucial for low-speed operation of the machine. Thanks to the hardened and precisely ground bed, the lathe provides exceptional resistance to torsion and vibration, enabling precise turning even at the lowest rotational speeds. Advanced features Gtelhovxgc Djcdwzst The central feed switching system, including the lead screw and feed shaft, allows for efficient threading, even at low speeds. The accelerated longitudinal and cross feed can be easily controlled by the joystick, which facilitates precise machining, especially at low speeds. The digital readout in three axes (longitudinal, cross and upper slide) with an on-screen display allows for precise control over every movement of the lathe, especially during slow-speed operations. The high-quality bearing system with ball bearings and the modern bearing of the main spindle ensure stable and safe operation of the lathe. Efficiency and precision Thanks to the large spindle passage (82 mm), center spacing (2000 mm), 3-jaw lathe chuck (315 mm) and a powerful 7.5 kW engine, the CORMAK lathe guarantees high machining efficiency, even at a slow work pace. The rapid longitudinal and transverse feed system significantly shortens the machining time, but also allows for precise execution of details at low speeds. Technical data Turning diameter over bed [mm] 660 Turning diameter over support [mm] 440 Turning diameter in bridge recess [mm] 900 Turning length in bridge recess [mm] 250 Centre spacing [mm] 2000 Induction hardened bed Bed width [mm] 400 Lathe chuck diameter [mm] 315 Spindle passage diameter 82 Spindle nose [mm] D1 - 8 Spindle socket [mm] 113 (1:20) / MT5 Spindle speed range [rpm] 9 - 1600 24 gears Maximum tool dimensions [mm] 25 x 25 Longitudinal feed range [mm/rev] 0.044 - 1.48 Cross feed range [mm/rev] 0.022 - 0.74 Metric thread [mm] 0.45 - 120 Inch thread 7/16 - 80 T.P.I. Modular thread 0.25 - 60 M.P. D.P. thread 7/8 - 160 D.P. Accelerated feed [m/min] longitudinal 4.2 ; transverse 1.9 Tailstock quill diameter [mm] 90 Tailstock quill stroke [mm] 235 Tailstock quill tip MT 5 Main motor power S1/S6 [kW] 7.5/9 Coolant pump power [kW] 0.1 Dimensions (L x W x H) [mm] 3710 x 1135 x 1440 Net weight [kg] 3600

Condition: used, Year of construction: 1960, Technical details: turning diameter over bed: 630 mm turning diameter over support: 320 mm turning length: 2800 mm centre distance: 2800 mm turning dia. in gap: 700 mm length of gap: 450 mm spindle bore of work spindle: 70 mm weight of the machine ca.: 4,4 t dimension machine xH: 4,7 x 1,5 x 1,5 m Thread cutting possible Accessories: Gjlhcsu Ix A Esdwzjtt 4-jaw chuck various tips Gear wheels Jaws and small parts *

Condition: used, Year of construction: 2008, total height: 1,800 mm, total length: 5,500 mm, total width: 1,700 mm, Empty weight: 4.600 kg Price: On request - Year: 2008 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Drive system: Conventional - Power [kW]: 11.0 - Centre height [mm]: 315 - Swing over bed [mm]: 630 - Distance between centres [mm]: 4000 - Spindle bore [mm]: 103 - Min. spindle speed [rpm]: 16 - Max. spindle speed [rpm]: 1250 - Options: Digital readout, Removable bed - Swing over removable bed [mm]: 800 - Type of digital readout: Newall - Transport dimensions: 5500mm x 1700mm x 1800mm (l x w x h) - Transport weight [kg]: 4600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Gslhowqgbijcdwzstt Lukas van Rossum

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, spindle bore: 90 mm, turning diameter: 630 mm, turning diameter over bed slide: 630 mm, turning diameter over top slide: 380 mm, turning length: 3,000 mm, quill diameter: 90 mm, total length: 4,900 mm, total width: 1,420 mm, total height: 1,590 mm, rotational speed (max.): 1,800 rpm, rotational speed (min.): 18 rpm, overall weight: 3,700 kg, workpiece weight (max.): 1,500 kg, spindle mount: MK 6, The universal lathe FAT TUR 630M/3M has been comprehensively rebuilt and modernized, has technical parameters in accordance with the technical and operational documentation DTR of a new machine, WOT technical acceptance conditions and the Polish Standard and also meets EU requirements. The machine is covered by a full 12-month warranty on spare parts and electrical components. Availability: in stock, under power, ready for technical acceptance. Technical specifications: - distance between centers/turning length: 3000 mm - turning diameter over bed: 630 mm - turning diameter over support: 380 mm - spindle bore diameter: 90 mm - maximum workpiece weight between centers: 1500 kg - number of spindle speeds: 21 - range of rotational speeds (rpm): 18 - 1800 - range of feeds (mm/rev): Gtjlhcdod Eaa Ejwzet longitudinal: 0.05 – 3,26 transverse: 0.25 – 1,63 - engine power: 15 kW - overall dimensions: total length: 4900 mm width: 1420 mm height: 1500 mm total weight: 3650 kg Standard equipment: tailstock, coolant pump, tool post, chuck cover Additional equipment available at extra charge: - 3- or 4-jaw chucks, various diameters and variants - Digital readout on 2 axes with assembly and calibration - Steady rest, 10-140 mm, with rollers - Steady rest, 10-180 mm, with rollers - Steady rest, 140-300 mm, with rollers - MULTIFIX quick change tool post

Condition: ready for operation (used), Year of construction: 1984, spindle bore: 81 mm, center height: 315 mm, center width: 2,000 mm, overall weight: 3,100 kg, Heidenhain 2-axis digital readout, external electrical cabinet, capacity 2000x725 mm, spindle bore 81 mm, multifix turret, steady rest Gtslhcex H Sdnedwzst

Condition: used, Year of construction: 1980, VDF Wohlenberg Type:V1400 Parts . Gtjlhcdstttigswzot Top support : Overall height : 600 mm Overall length : 650 mm Base plate : 350 mm X 350 mm Base plate holes diameter : 22 mm Spacing: width 240 mm lengthwise : 290 mm Tool holder mounting : 100 mm X 45 mm Thread tool holder M30 . Tailstock: Center height : 630 mm Quill diameter : 100 mm Base plate : 500 mm X 400 mm . Faceplate : Diameter 1000 mm Width : 125 mm with 3 jaws Spindle holder 250 mm 4 bores diameter 20 mm pitch circle 200 mm . Sale individually or in a package possible .

Condition: new, Year of construction: 2025, Main advantages: - The CORMAK GOLIAT 660 x 4000 universal lathe can be used for many tasks, such as turning internal and external surfaces, cones, polishing, metric, inch modular and DP threading, drilling and broaching. - The solid cast iron bed construction ensures maximum vibration reduction. Additionally, the bed is hardened and precisely ground. The device bed is extremely resistant to twisting and does not vibrate, which is the basic condition for precise turning. - Central feed switching system, lead screw and feed shaft for threading - The digital readout works in (3) three axes of movement: longitudinal, transverse, upper slide. The processed electronic signal from the optical rulers visualizes the obtained values ​​from movements along the axes on the digital screen. - The lathe is equipped with a high-quality, reinforced spindle bearing system. Modern main spindle bearing with ball bearings - Optimal work results are ensured by a large spindle passage of 105 mm, a 4000 mm center spacing, a 3-jaw lathe chuck of 320 mm, and a powerful 7.5 kW engine. - The rapid longitudinal and transverse feed system significantly shortens the machining time and increases productivity. - Hardened and ground gears in the spindle gear - ensures long-term stability of work. - Equipped with a lead screw and a feed shaft for threading, automatic longitudinal and transverse feed. - Easy adjustment of the spindle speed and automatic feed from the ergonomic control panel on the gear. - Possibility of machining a wide range of threads without the need to replace the change wheels in the guitar. Wide range of threads: metric (22) 1 - 14 mm, inch (25) 2-28 T.P.I, modular (18) 0.5-7 M.P., D.P. thread (24) 4-56 D.P. Turning right and left threads. - Thread turning clock designed for accurate counting of turns. The function is to save time so that in several passes you can unscrew the lead screw nut to manually quickly return the support to its original position. - The bed has a replaceable bridge for turning larger elements, e.g. a disc. This lathe model allows for machining with a maximum diameter of 870 mm with the bridge removed. Technical data Max. turning diameter over bed Ø660 mm Max. turning diameter over support Ø420 mm Max. turning diameter in bridge slot Ø870 mm Slot length 240 mm Centre spacing 4000 mm Max. turning length 3950 mm Spindle bore Ø105 mm Spindle taper diameter and angle Ø113 mm 1:20 Spindle nose D1-8 CAMLOCK Spindle speeds 12 speeds (36-1600 rpm) Number and range of longitudinal feeds 65 (0.063-2.52 mm/rev.) Number and range of cross feeds 65 (0.027-1.07 mm/rev.) Metric thread 22 (1-14mm) Inch thread 25 (28-2 TPI-pitches per inch) Modular thread 18 (0.5-7mm) Gslhcdwsvw Abgjzett DP thread 24 (56-4 DP) Rapid longitudinal feed 4.5 m/min. Rapid cross feed 1.9 m/min. Lead screw pitch 12 mm Spindle axis distance from tool surface 28 mm Tool dimension 25x25 mm Max. top slide travel 145 mm Max. cross slide travel 380 mm Tailstock quill diameter 75 mm Tailstock taper MT5 Max. tailstock quill travel 150 mm Tailstock cross travel ±15 mm Main motor S1/S6 7.5/9 kW / 400V Rapid feed motor 250W Coolant pump 60W, 25 L/min. Dimensions L/W/H 5500 x 1100 x 1450 mm Weight 5 200 kg

Condition: used, Year of construction: 1963, Technical details: turning diameter over bed: 1000 mm turning diameter over support: 620 mm turning length: 3150 mm centre distance: 3150 mm turning diameter in the gap: 1200 mm length of gap: 800 mm weight of the machine ca.: 11,5 t Gelsu Ix Arohcdwzstt dimension machine xH: 7,5 x 1,5 x 1,7 m incl. 2x steady rests and various tips *

Condition: used, Year of construction: 1991, total length: 5,200 mm, total width: 1,700 mm, total height: 1,400 mm, Empty weight: 4.500 kg Price: On request - Year: 1991 - Documentation available: No - CE certificate present: No - Serial number: 4411T Gelhcdex A H Ahswzstt - Drive system: Conventional - Centre height [mm]: 355 - Swing over bed [mm]: 710 - Carriage turning diameter [mm]: 350 - Distance between centres [mm]: 3000 - Bed width [mm]: 510 - Spindle bore [mm]: 75 - Min. spindle speed [rpm]: 25 - Max. spindle speed [rpm]: 1250 - Options: Fixed steady, Four-jaw chuck, Quick-change tool post, Three-jaw chuck - Transport dimensions: 5200mm x 1700mm x 1400mm (l x w x h) - Transport weight [kg]: 4500kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2021, turning diameter over cross slide: 440 mm, turning diameter: 680 mm, center height: 340 mm, turning length: 3,000 mm, total length: 4,700 mm, total height: 1,450 mm, spindle speed (min.): 1,000 rpm, metric thread diameter (min.): 14 mm, bed width: 458 mm, rotational speed (max.): 1,000 rpm, rotational speed (min.): 12 rpm, type of input current: three-phase, swing diameter over bed slide: 680 mm, overall weight: 4,500 kg, quill mount: MK 6, spindle mount: MK 6, center height over top slide: 220 mm, EQUIPMENT of the used machine Machine No. WAG-C1-188 year of construction 2021 STANDARD EQUIPMENT : - Complete electrical equipment 400 V. / 50 Hz. - Chuck protection electrically fused - Quadruple tool holder or optional Quick change tool holder (Multifix system) - Rapid traverse in X and Z axis - Fixed steady rest - Moving steady rest - Complete coolant system - Spindle brake - Rear chip guard - Machine light - Operating tool and instruction manual - CE standard Additional equipment of the used machine - Three-axis digital display Article 601233 - 3-jaw chuck diameter 400 mm - Faceplate diameter 500 mm - Fixed steady rest 70 - 250 mm - Fixed steady rest 150 - 380 mm Quill ends adapted for sliding inserts Article 601223 - Quick change tool holder head Multifix size C Article 605934 TECHNICAL DATA center height 340 mm Swing over bed 680 mm Swing diameter over cross slide 440 mm center width 3000 mm spindle bore 105 mm (option 155 mm) spindle nose ASA A1-11 (D-11) Number of spindle revolutions 12 spindle speed 12 - 1000 rpm. (opt. 10 -800 rpm for KK 15) Longitudinal feeds 0.05 - 0.7 mm/rev. transverse feeds 0.025 - 0.035 mm/rev. Bed width 458 mm cross travel 390 mm Top slide travel 255 mm Thread pitches: metric 0.8 - 14 mm Withworth Gg/1" 2 - 28 Module, mod. 0.5 - 7 Diametral Pitch, DP 4 - 56 Lead screw dia. 105 mm Number of stages 28 Tailstock quill MK6 Drive power 11,25 kW (opt. 15 kW) Transport dimensions 4700 x 1240 x 1450 mm Gtoljw Rpd Ejhcdwzst weight 4500 kg Transport costs on request. You have the possibility to visit the offered machine in our demonstration center Renchen, by appointment.

Condition: good (used), Year of construction: 1970, LZ-Lathe Fabr.SCHAERER Type:UD500 Year 1970 overhauled 1991 With Forkadt chuck 315mm tool holder Multifix size C. Center height : 250 mm Center width : 1500 mm spindle bore: 65 mm Gtjlhceu Rdurodwzst Spindle speed : 18 - 900 rpm. Machine in good condition .

Condition: used, total height: 1,700 mm, total length: 5,100 mm, total width: 1,500 mm, Empty weight: 5.000 kg Price: On request - Documentation available: No - CE certificate present: No - Drive system: Conventional Gtelhcowqfkvedwzst - Centre height [mm]: 360 - Swing over bed [mm]: 710 - Distance between centres [mm]: 3000 - Spindle bore [mm]: 75 - Min. spindle speed [rpm]: 10 - Max. spindle speed [rpm]: 1000 - Options: Digital readout, Removable bed - Swing over removable bed [mm]: 1000 - Type of digital readout: Mitutoyo - Transport dimensions: 5100mm x 1500mm x 1700mm (l x w x h) - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum
