Used Pinacho for sale (27)

Condition: used, three-jaw chuck diameter: 250 mm, Brand: Pinacho Model: S90-260 Distance between centers: 1150 mm Swing over bed: 530 mm Swing over carriage: 475 mm Swing over gap: 780 mm Spindle bore: 68 mm Spindle speeds: 30–1,500 rpm Fsdpfxeyzq Tks Afzega Morse taper 4 for the tailstock. Foot pedal brake. Fagor 20i-T digital readout – 2 axes (X, Z) Includes: - TdeG 250 mm 3-jaw chuck - All tools shown in the pictures and micrometers - Emergency stop - Chuck guard with microswitch

Condition: good (used), 8-position tool turret, manually indexable, for retrofitting 8 x turning tool holders 8 x drilling tool holders Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 Fgodpfxswg Rv Ne Afzja DE – 44143 Dortmund - Wambel / Germany

Condition: used, L + Z Lathe PINACHO Type L-11/260 Machine No. 13222 Year approx. 1988 Centre distance 1500 mm Swing over bed 520 mm Centre height over bed 260 mm Swing over cross slide 320 mm Centre height over cross slide 160 mm Spindle bore 72 mm Spindle speed 30 - 1800 rpm, 12 steps Chuck flange: short taper DIN 55027 size 5 Tailstock taper MK 5 Motor power 9 kW Electrical connection 400 Volt, 50 Hz - 2-axis digital readout NEWALL ELECTRONICS, type Digipac 5 - Digital readout for 3 axes: Z+Z1 and X - 3-jaw scroll chuck RÖHM Ø 250 mm with turning and drilling jaws, 1 set of base jaws with soft top jaws - Multifix quick-change tool post size B with 2 holders - Automatic longitudinal and facing feed - Rapid traverse - Electric spindle brake - Coolant system integrated in machine base - Chuck guard - Splash guard wall Dimensions (L x W x H): 3050 x 1100 x 1550 mm Fgsdpeyy Dfwofx Afzoa Weight: 1750 kg Bedways not worn, in good condition. Spindle gearbox on the chuck side is leaking oil at the main spindle.

Condition: excellent (used), Year of construction: 2009, Heidenhain digital display Working area Centre height: 310 mm Centre distance: 1625 mm Max. turning diameter in the gap: 880 mm Max. turning diameter over bed: 620 mm Turning diameter in front of the longitudinal carriage: 580 mm Fgsdpfx Ajyyv N Usfzea Turning diameter over cross slide: 425 mm Bed width: 350 mm Length of the gap in front of the faceplate: 200 mm Main spindle bore: 80 mm Spindle mounting: DIN 55027/8 Optional Camlock spindle mounting: DIN 55029/8 12 spindle speeds: 30 – 1500 rpm Cross slide travel: 365 mm Top slide travel: 165 mm Drive power: 5.5 kW Coolant pump motor power: 0.06 kW Weight: 1805 kg

Condition: good (used), Used Pinacho L1-260 lathe Distance between points: 1625 mm Max. turning on bed: 520 mm Length of neckline: 350 mm Fgsdpoudw Iisfx Afzoa Tilting on longitudinal carriage: 470 mm Turning on the transversal carriage: 320 mm Swing in dive: 770 mm Reed pitch: 68 mm Main engine power: 7.5 hp *It will be delivered with 3-jaw chuck. *Price can be requested with or without CE regulations.

Condition: ready for operation (used), Year of construction: 2017, controller manufacturer: FANUC, number of axes: 2, This Pinacho STH 400-105×3000 was manufactured in 2017. A robust horizontal turning machine with a swing over bed of 400 mm and a distance between centers of 3000 mm. Features a high-torque spindle and CNC-controlled feed for precise heavy-duty turning. Ideal for machining shafts, pipes, and flanges. Consider the opportunity to buy this Pinacho STH 400-105×3000 horizontal turning machine. Contact us for more information. • Max. swing over bed: approx. 400 mm • Max. turning diameter: approx. 400 mm • Distance between centers: 3,000 mm • Bar capacity: approx. 105 mm • Spindle • Main spindle: horizontal • Spindle bore: approx. 105 mm • Spindle nose: A2-type (depending on configuration) • Speed range: variable (CNC-controlled) • High-torque spindle suitable for heavy turning Fjdpfxjybbiue Afzoga • Axes • X-axis: cross slide • Z-axis: longitudinal slide • CNC-controlled feed and rapid traverse • Tool system • Turret: CNC tool turret • Number of tool stations: depending on configuration • Suitable for internal and external turning • Control system • CNC control: Fanuc / Siemens (depending on configuration) • Full CNC contouring and threading capability • Application • Medium to heavy-duty turning • For shafts, pipes, flanges, and general production parts • Suitable for series and job-shop production

Condition: ready for operation (used), Year of construction: 2018, spindle speed (max.): 1,250 rpm, total height: 2,110 mm, overall weight: 2,250 kg, controller manufacturer: SIEMENS, This Pinacho SE325 was manufactured in 2018. A reliable horizontal turning machine, it offers consistent performance for various machining tasks. Ideal for workshops seeking a dependable solution for turning operations. Contact us for more information. • Revolver: 8 pcs Fgjdpfx Afjx D Nqdozsa • Centre height: 325 mm • Distance between centres: 1000 mm • Bar capacity: 105 mm • steady Rest:10-180 mm • 8-positionings turret headMachine still under power Additional equipment • Ethernet Port • USB Port • Swarf Conveyor • Color Display 7.5 inch Dimensions Machine Depth 3010 mm

Condition: ready for operation (used), Year of construction: 2012, spindle speed (max.): 4,000 rpm, total height: 1,650 mm, overall weight: 1,200 kg, controller manufacturer: FAGOR, controller model: 8055tc, number of axes: 2, This Pinacho Smart Turn 180/42 1000 was manufactured in 2012. A robust horizontal turning machine featuring a turning length of 1000mm, spindle clearance of 42mm, and a turning diameter of 360mm. It includes an 8-fold tool changer and Fagor 8055tc control. Dimensions are 2.5 x 1.15 x 1.65 m, weighing approximately 1.2t. Consider the opportunity to buy this Pinacho Smart Turn 180/42 1000 horizontal turning machine. Contact us for more information. Fgodpfsx D Ivfjx Afzsa • Turning diameter: 360 mm • Turning length: 1000 mm • Tool changer: 8-fold vdi20 • Machine still under power • chuck: 200 mm in diameter. Dimensions Machine Depth 2500 mm

Condition: used, Year of construction: 1990, turning diameter over bed 0520 mm Fjdsyn R Exspfx Afzega turning diameter over slide rest 300 mm turning length 1625 mm spindle bore 68 mm spindle turning speed range 23- 1250 U/min total power requirement 7,5 kW weight of the machine ca. 3 t dimensions of the machine ca. 2,8 x 1 x 1,4 m With Multifix holder, chuck und chuck safety cover.

Condition: used, Year of construction: 2016, Technical details: turning diameter over bed: 402 mm turning dia. over face-slide: 245 mm turning length: 1000 mm centre distance: 1000 mm centre height: 200 mm swing diameter: in Kröpfung: 560 mm throat: Breite: 120 mm revolution per minute: 40 - 345 / 345 - 1015 / 1015 - 2800 U/min feed: längs: 0,05 - 0,752 + quer: 0,025 - 0,376 mm/U spindle diameter: Ø 42 mm tailstock taper ISO: MK4 tailstock quill stroke: 180 mm total power requirement: 4,1 kW Weight approx.: 1,2 t dimension machine xH: 2,4 x 1,0 x 1,7 m Die Drehmaschine verfügt über keinen Eilgang. Fgodpfx Afjvav Sdezsa Positionierung über 2-Achsen Anzeige über Pinacho Lathe Controller Multifix-Stahlhalter mit Drehmeißel Kühlmittelanlage Fußtaster Gewindeschneiden möglich (metrisch, Whitworth, Modul, Pitch) *

Year of construction: 2006, condition: used, functionality: fully functional, Pinacho Smart 180 lathe in excellent working condition Fgodoygq R Sspfx Afzoa

Condition: excellent (used), Tailstock for PINACHO Lathe Centre height: 180 mm Cone: CM3 Spindle exit: 160 mm Sole dimensions: Length 210 mm x Width 160 mm Fgedpjyr E Dwofx Afzja V Spacing: 135 mm In very good condition

Condition: excellent (used), Year of construction: 2008, turning diameter over cross slide: 260 mm, spindle bore: 65 mm, turning length: 1,000 mm, turning diameter: 450 mm, PINACHO Smart Turn 6 CNC lathe Fanuc Oi Main Features Fgedpfjypv Twjx Afzja Industrial CNC lathe Manufacturer: PINACHO Model: Smart Turn 6 Year: 2008 CNC Control: Fanuc Oi Mate TC Machining capacities: Distance between centers: 1,000 mm Center height: 225 mm Swing over bed: 450 mm Swing over cross slide: 260 mm Spindle: Spindle bore: 65 mm Two speed ranges: 0 – 675 rpm 675 – 3,000 rpm Feed rates: 0 – 10,000 mm/min 4-position automatic turret Main motor power: 7.5 kW Machine in very good condition Suitable for precision CNC production

Condition: used, Year of construction: 2006, Technical details: turning diameter: 360 mm turning length: 1000 mm total power requirement: 5,5 kW centre height: 180 mm swing diameter over longit. slide guides: 335 mm max. turning dia. over cross-slide: 198 mm bed width: 250 mm main spindle bore: 42 mm spindle turning speed range: 1-4000 U/min Tailstock diameter: 58 mm Fjdpsyfg Udofx Afzoga Morse taper tailstock: MK 3

Condition: good (used), Year of construction: 2015, functionality: fully functional, turning diameter over cross slide: 360 mm, turning diameter: 570 mm, swing diameter over cross slide: 570 mm, quill diameter: 95 mm, rapid traverse Z-axis: 12 m/min, spindle speed (max.): 2,500 rpm, feed length X-axis: 7 mm, feed rate X-axis: 7 m/min, type of input current: three-phase, overall weight: 2,970 kg, Technical Data: - Swing diameter - Centre distance - Spindle speed - Power - Feed - Rapid traverse - Quill diameter - Quill stroke - Quill taper - Tool turret - 570 mm over bed - 360 mm over cross slide Fedpfx Aoymtbgofzjga - 2000 mm - max. 2500 rpm - 11 kW - max. 7.5 m/min (longitudinal) - max. 7.5 m/min (cross) - 12 m/min (longitudinal) - 15 m/min (cross) - 95 mm - 220 mm - Morse Taper 5 (MK 5) - automatic - 8-position (see also options) - CAPTO turret disk Technical Description: - Machine bed - Cross slide - Tailstock - Operator station - Control system - Accuracy - Electrical equipment - Machine enclosure - Paintwork 2) Additional Features / Options - Accessories - made from pearlitic cast iron GG-26 - high rigidity due to heavy ribbing - guideways hardened and ground - automatic lubrication of bedways - manual - quick clamping - two movable handwheels on the control panel - one movable handwheel - CNC control "Siemens 828 D" - Siemens "Comfort" (incl. ShopTurn and rest material detection) - as per DIN 8605 - electronic handwheels (X and Z axes) - low-voltage lighting - full enclosure - RAL 7035 (light grey) / RAL 9023 (pearl dark grey) - Options - coolant system - chip tray - chip conveyor - operating manual - 3-jaw wedge-bar chuck, Ø 250 mm Condition: all existing base jaws / top jaws from Sommer must be compatible! - Removable tool turret (can be exchanged for Multifix) Dimensions: 3.8 m x 1.3 m x 2 m (L x W x H) Weight: 2.97 t Tools are not included in this offer!

Condition: used, Year of construction: 2001, turning diameter 420 mm turning length 1200 mm Fodpfx Ash N D Unefzjga control Fanuc bore diameter 60 mm

Condition: used, Year of construction: 2003, - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-fold tool turret VDI40 - Year of construction 2003 Technical data Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Fedouwrz Hjpfx Afzega Headstock: - Bore of main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: 5 - Spindle speeds: 2 - Constant cutting speed: 0-700 / 700-3000 rpm Feed rates: - Working feed Z/X: 0 - 7000 mm/min - Rapid traverse Z/X: 10 m/min Tailstock: - Tailstock shank Ø: 58 mm - Tailstock shank travel: 155 mm - Morse taper tailstock: 4 Motors: - Main motor power: 7.5 kW - DC motor Z-axis power: 12 Nm - DC motor X-axis power: 4 Nm - Motor pump power: 0.57 kW Dimensions: - Machine weight: approx. 2200 kg - Dimensions WxHxD: 2980 x 1730 x 1610 mm

Condition: good (used), Year of construction: 2005, Ref. -No.: 10314 Manufacturer: PINACHO Type: S-90/ 310-155 Year of construction: 2005 Type of control: Konventionell Fgjdpfxex Sw Dqe Afzja Storage location: Halberstadt Country of origin: Spain Bar passage: 90 mm Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Tip length: 3000 Cross Movement. (X-Axis): 365 mm Spindle Bore: 155 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm Jaw chuck diameter: 380 mm Turning Speed Range: 16 - 750 rpm Further information: - The lathe has two jaw chucks on the headstock - metric, Whitworth and inch trapezoidal threads can be turned - adjustable feeds for cross face and longitudinal face turning (0.05 to 1.5 mm/u)

Year of construction: 2006, condition: ready for operation (used), A Pinacho CNC precision parallel lathe is available. Center height: 180mm, center width: 750mm-1000mm, turning diameter over guide bed/longitudinal slide/cross slide: 360mm/335mm/198mm, bed width: 250mm, bore: 42mm, speed: 4000rpm, feed X/Z: 10m/min, rapid traverse X/Z: 10m/min. Tailstock shank diameter: 58mm, tailstock shank length: 200mm, Morse taper: MK3, min. travel of moving/fixed steady rest: 10mm, max. travel of moving/fixed steady rest: 70mm/114mm, control: Fanuc 0i. Documentation available. On-site inspection is possible Fjdpfswftcvjx Afzsga

Condition: excellent (used), Year of construction: 2021, CNC controller: FAGOR 8055 I PACKAGE FOR SE/SMS Main Spindle: Spindle Bore (I.D.): 80 mm Spindle Nose: ASA A2-8 Turret: 4-Position Automatic Turret SQT-190-87-C Fgsdpew Hurzsfx Afzja Chuck (front): 3-Jaw Universal Chuck ASA8 Diameter: Ø 315 mm Speed: 1250 RPM Inner Diameter (I.D.): 103 mm Accessories: Set 3 Base Jaws Ø 315 mm Accessories: Set 3 Hard Top Jaws Ø 315 mm Accessories: Set 3 Soft Top Jaws Ø 315 mm Chuck (rear): Universal Rear Chuck 3-Jaw Diameter: Ø 315 Inner Diameter (I.D.): 103 mm

Condition: excellent (used), Year of construction: 1995, Digital display Turning diameter 120 mm Turning length 700 mm Fedpfjwhrg Ssx Afzjga Spindle speed 2000 min-1 Tailstock

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 42999, spindle bore: 80 mm, turning diameter over bed slide: 50 mm, center width: 1,500 mm, controller manufacturer: Fanuc, empty load weight: 3,900 kg, TECHNICAL DETAILS Max. swing diameter: 50 mm Centre distance: 1,500 mm Spindle bore: 80 mm MACHINE DETAILS CNC manufacturer: Fanuc Fedpfxjxdahae Afzoga Machine weight: approx. 3,900 kg EQUIPMENT 6-position tool changer

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 53364, turning length: 1,500 mm, turning diameter: 300 mm, controller manufacturer: FAGOR, TECHNICAL DETAILS Max. turning diameter: 300 mm Turning length: 1,500 mm MACHINE DETAILS Fgjdpfoxdaycsx Afzja Control manufacturer: FAGOR

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 28958, turning diameter over cross slide: 210 mm, spindle bore: 52 mm, turning diameter over bed slide: 400 mm, rotational speed (max.): 2,300 rpm, controller model: FAGOR 800T, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine on time between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Swing diameter over cross slide: 210 mm Spindle bore: 52 mm Swing diameter over bed slide: 400 mm Quill diameter: 58 mm Fgedpjxp Nnasfx Afzsa Quill travel: 155 mm Center height: 200 mm Bed width: 300 mm Max. spindle speed: 2,300 rpm Center distance: 1,150 mm Swing diameter in gap: 600 mm MACHINE DETAILS Controller model: FAGOR 800T Tailstock quill taper: MK 4 EQUIPMENT Tool cabinet with accessories

Condition: like new (used), Year of construction: 2020, operating hours: 400 h, functionality: fully functional, from company closure as good as new Pinacho STS18-180 lathe with Fagor control and revolver Year of construction 2020 Turning hours 400 Turning diameter above bed 360 mm Turning diameter above slide 190 mm Center length 1000 mm Turning length 840 mm Spindel through 42 mm Weight 2500 kg equipped with 3-jaw chuck, 8-fold revolver, Fagor control Fgsdpfxewdhn Rj Afzoa price excluding VAT, loaded on truck
