CNC-Turning-Boring-Milling Centre

WFL M120X MILLTURN 3000mm

WFL Millturn M120X/3000

WORKING RANGE
centre distance = 3000mm
Swing over bed = 1220mm
Swing over slide top = 1140mm
Longitudinal travel (Z) = 3330mm
Face travel (X) = 920mm
Distance spindle nose to tailstock tip = 3812mm

ROTATING SPINDLE
Spindle head DIN 55026 form size A15
spindle bore 165mm

MAIN DRIVE
AC-drive with 2-stage gearbox
Drive power 100% ED 60kW
Max. Spindle speed 1600 1min
Max. Spindle torque 100% ED 4472 NM

C-AXIS. SERVO-CONTROLLED MAIN SPINDLE
Smallest programmable increment 0.001°.
Max. Speed 20min-1
Max. Torque on spindle 100% ED Nm 3000
Holding torque of disc brake Nm 6000

Fgsdpol Smhlefx Ac Hji
FEED DRIVE
Cross slide, rotary drilling-milling unit:
AC servo drive
Feed force longitudinal (Z) kN 30.0
Feed force plane (X) kN 31,5
Feed force Y-axis 55kW kN 25.0
Rapid traverse speed: longitudinal (Z) m/min 15.0
plane (X) m/min 15.0
Y-axis m/min 12.5
Rapid traverse B-axis °/s 90

BALL SCREW
LENGTH (Z axis) ø x pitch mm 63X20
PLAN (X-axis) ø x pitch mm 63X10

RIDGE STOCK
Quill diameter mm 180
Quill stroke mm 200
Quill force (adjustable) N 5400-40000
Quill with built-in bearing MK 6

TOOL CARRIER
(single tool carrier, rotary drilling-milling unit)
AC drive, drive power 100% ED kW 55
Spindle speed max. min-1 3200
Max. Torque at spindle 100% ED Nm 730
Travel perpendicular to X/Z plane (Y axis) 55kW mm 650(-300/+350)
Tilting angle of the milling spindle (B axis) ° -110/+90
Spindle head for tools according to DIN 69893 HSK-A100
Milling spindle diameter in front bearing mm 130

TEMPERATURE STABILISATION
through controlled cooling circuit with compressor - cooling unit

EXTERNAL TOOL MAGAZINE: Number of
Storage spaces (space-coded) Size HSK100 pcs 90
Max. Tool length mm 500(800)

DIMENSIONS
Length(max. tool magazine with chip conveyor) m 13
Height m 4,1
