Centre lathe

TOS SUS 63/5000

Condition: good (used), Year of construction: 2005, Tool holder BT 40, 12.000 rpm, Ffodpfx Ajwbaqlebrjt 60 tool places in tool changer, 70 bar IKZ, laser Renishaw OMI-2. Parts shown by hand not come.

Condition: used, Year of construction: 2000, Technical details: x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm b-axis: manuell positionierbar ° c-axis: manuell positionierbar control: Heidenhain TNC 124 tool changer with: nein Plätze spindle taper MT: SK40 Revolution per minute: 4500 U/min. feed speeds infinitely variable: X/Y/Z: max. 14000 mm/min rapid traverse:: 5,0 m/min table-size: 700 x 500 mm total power requirement: 17 kVA Weight approx.: 2,91 t dimension machine xH: 2,0 x 2,0 x 2,5 m CNC universal vertical milling machine The machine has 5 axes. B- and C-axis manual with measuring system. B-axis table swivel -10° / +95° and C-axis table rotate 360° (not interpolatable, manually selectable via control). Fjdpfsu Idffex Abreft Cooling device (without pump) Operation via swiveling boom *

Condition: excellent (used), Tuscan LC38 x 3000mm CNC Lathe Swing Over Bed 970mm Swing Over Cross Slide 420mm Centre Height 490mm Distance Between Centres 3000mm 12 Station Duplimatic Turret Tailstock Ffedpfsvtw Imox Abrjt Boring Bat Attachment Boring Bar 2 x 3 Point Fixed Steady 1 x Travelling Steady Fanuc OiTC Control C Axis & Driven Tools Serial Number LC223806086 Year 2010 /10

Condition: used, Year of construction: 2008, Mazak QTN-100MSY Year: 2008 X/Y/Z/B: 185/100/455/460 mm Max. turning diameter: 280 mm Bar capacity up to 51 mm diameter Main spindle Speed range: 6000 rpm Main drive power: 11 kW Max. torque: 184 Nm Spindle bore diameter: 61 mm C-axis spindle positioning: 0.001° Second spindle Speed range: 6000 rpm Drive power: 11 kW Max. torque: 89 Nm Indexing: 0.001° Tool turret Number of tool stations: 12 Fedoxn Svdspfx Abrjft Driven tools Speed range: 4500 rpm Drive power: 5.5 kW Max. torque: 35 Nm Travel paths X-axis: 185 mm Y-axis: 100 (+/- 50) mm Z-axis: 455 mm W-axis: 460 mm Toolsetter Parts catcher Chip conveyor, right side Coolant pump Barfeeder interface

Condition: ready for operation (used), total height: 3,300 mm, total width: 3,450 mm, total length: 6,000 mm, controller manufacturer: Siemens, empty load weight: 17,000 kg, Model: FTV 850 Fjdpfowxz D Uox Abrjft Koeling door spindel Het werkgebied kan in twee secties worden verdeeld 2 magnetische tafels Bewegende kolom, vergelijkbaar met Mazak VTC / Unisign / Hedelius Zware chassisstructuur Longitudinal travel X-axe: 1800 mm Crosstravel Y -axe: 850 mm Travel Z-axe (Height): 800 mm Dimensions clamping space - table: 2300 x 900 mm Universal (2x 360°): ISO 50 Boring head (1 x90°): 19 kW

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 155436, Positioning B-axis with minimum increment 0.001 degrees Ffjdowb Epaspfx Abrot Bar Feeder Interface Automatic part pick-up Synchronized tapping for live tools Coolant through milling head 15 bar Rear belt chip conveyor

Condition: used, Year of construction: 2017, New spindel 2025-08 yearly service by Mazak Servicecenter. includes bar feeder Super 80 Max swing Ø 658 mm Swing over X-slide Ø 658 mm Swing when Y-axis is operating Ø 658 mm Max turning diameter Ø 658 mm Max turning diameter from bar Ø 51 mm (option Ø 65) Max part length 1011mm X axis: 615mm Y axis: +/-130mm z axis: 1077mm B axis: 0,0001Deg / 240° Spindle 1 Spindle nose JIS A2-6 Spindle bore 76 mm Through-hole 51 mm (option Ø 65) Spindle motor AC 22 kW 40% ED Speed range 35-5000 rpm Number of speed ranges Direct drive Max torque 467 Nm 25% ED Max part weight including chuck 300 kg Center height from floor 1235 mm Spindle 2 Spindle nose JIS A2-6 Spindle bore 76 mm Through-hole Not applicable (option Ø 65) Spindle motor AC 18.5 kW 40% ED Speed range 33-5000 rpm Number of speed ranges Direct drive Max torque 325 Nm 40% ED Max part weight including chuck 300 kg Center height from floor 1235 mm C-axis 1 Type Direct drive Rapid feed 555 rpm Working feed 1-5000 degrees/min Minimum programmable increment 0.0001 degree C-axis 2 Type Direct drive Rapid feed 555 rpm Working feed 1-5000 degrees/min Minimum programmable increment 0.0001 degree W-axis Movement 1066 Rapid feed 30 m/min B-axis B-movement 240 degrees Max machining feed (ISO) 40 rpm Minimum programmable increment 0.0001 degree Tool Holder Type: Tool changer Tool Shank Size: 25 x 25 mm Tool Change Time, tool to tool: 1.3 seconds Chip-to-chip time, average: 8 seconds Tool Holder for rotating tools: Capto C6 Tool Holder for turning tools: Capto C6 Max Tool Weight: 12 kg Max Tool Length: 400 mm Clamping Force for Tool (Capto C6): 33 kN Tool Magazine: Number of tool positions: 36 pcs Max Tool Diameter: 90 mm Max Tool Diameter when the position before and after is empty: 125 mm Max Tool Length: 400 mm Max Tool Weight: 12 kg Max Torque for Tool: 9.8 Nm Other: Length: 3990/4910 mm Width: 2800 mm Height: 2720 mm Weight: 13100/16600 kg Power Requirement, continuous: 72.34 kVA Air Requirement, min: 5 kg/cm², 410 liters/min Ffsdpfxox Hfl Ej Abrjt Tool Magazine: 36 tools Standard Equipment: B-axis Capto C6 ATC Auto Recovery Auto power on/off, heating schedule 19” LCD touchscreen Mazak tool identification system including 10 ID chips (for Capto C6) Measurement arm for tool length setting, automatic compensation, and tool breakage detection 8” Chuck Type: Kitagawa B208A6 8” Chuck Type: Kitagawa B208A6 Coolant Tank Coolant Pressure for Upper Turret: Max 5 bar, 23 l/min Set of Manuals: (digital) Smooth Standard Software: Mazacc 2D software (shape comp) Mazacc 2D software för roterande axlar (shape comp) Mazacc 3D High Speed software High Smoothing Control Seamless Corner Control Variable Acceleration Control Ultra High Speed Machining Mode Rapid Overlap ISO/EIA Programming: Lathe and milling spindle start unsynchronized Synchronized threading with rotating tools Macro interruption allowing event-driven ISO/EIA programs Macro programming with 600 additional variable pairs for ISO/EIA Helix interpolation for ISO/EIA Coordinate rotation with G68 for ISO/EIA Polar coordinates, G122 for ISO/EIA Synchronized interpolation X-C-axis G12.1 for ISO/EIA Coordinate systems G54 - G59 + 300 additional for ISO/EIA Direct input of drawing dimensions, e.g. starting corner for ISO/EIA Inverse Time Feed (G93) 3D Cutter Compensation (G40-G42)

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Max. machining length : 180 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 10000 [rpm] Fedjuha Sljpfx Abrsft - Spindle power : 1.5 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 9 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - X/Y stroke : 50/325 [mm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 4 POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of hours under power : 31902 [h] - Number of spindle hours : 12146 [h] EQUIPMENT - CNC : Fanuc 32-iB - Interface : USB - Parts catcher - Parts conveying strip - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump * with paper filtering unit - Bar loader : IEMCA 338-HD - Cooling unit - Electric transformer - Number of turning tool holders : 3

Condition: excellent (used), X 885, Y 800, Z 500mm, A 30-120dg, C 360dg. HSK 63 Big Plus, 15,000Rpm, ATC 60 pos, Renishaw probe, Heidenhain TNC 530. Fjdpfx Abswzv Igoroft

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning diameter over cross slide: 700 mm, turning length: 6,000 mm, spindle motor power: 30 W, The lathe is in good technical condition, connected and ready for testing. It features digital readout, faceplate, and steadies. Specifications: Swing diameter over bed: 1,090 mm Distance between centers: 6,000 mm Swing diameter over cross slide: 700 mm Main drive motor power: 30 kW Dimensions (L x W x H): 8,200 x 1,800 x 1,855 mm Ffsdpfxjx A S Sbj Abrst Machine weight: 11,000 kg
